Parts Breakdown PV7001C
Page 1 of 2 2/8/2008

Parts Breakdown PV7001C
Fig # Part ID Part Name Quantity
1 743052-5 PAD 165, 9227C 1
2 324081-3 SPINDLE, GV7000C 1
3 152690-6 BEARING RETAINER CPL., GV7000C 1
4 211129-9 BALL BEARING 6201DDW, N9501B 1
5 152691-4 GEAR HOUSING CPL. PV7001C 1
5 153318-9 GEAR HOUSING COMPLETE 1
6 257707-1 SLEEVE 12, PV7001C 1
7 226536-3 HELICAL GEAR 43,PV7001C 1
8 253215-0 F. WASHER 8, 2030S 1
9 226141-6 GEAR COMPLETE 21-44,PV7001C 1
10 152491-2 GRIP, GV5000 1
11 266211-9 TAPPING SCREW 5X40, HK0500 4
12 417837-2 GASKET, PV7001C 1
12 442132-1 GASKET, GV7000C 1
13 153319-7 GEAR HOUSING COVER COMPLETE 1
13 152692-2 GEAR HOUSING COVER,PV7001C 1
14 210005-4 BALL BEARING 608DDW, 9031 1
15 240020-4 FAN 65, GV7000C 1
16 413077-0 BAFFLE PLATE, GV7000C 1
16 419721-7 BAFFLE PLATE, GV7000C 1
17 516431-8 ARMATURE ASS'Y,PV7001C 1
18 266056-5 T. SCREW FLANGE PT5X45,9046 2
19 594386-7 FIELD ASS'Y 115V, PV7001C 1
20 681660-3 INSULATION WASHER, GV7000C 1
21 253139-0 F. WASHER 8, 6510LVR 1
22 210005-4 BALL BEARING 608DDW, 9031 1
23 265995-6 TAPPING SCREW 4X18, 4323K 2
24 417450-6 HANDLE COVER, GV7000C 1
25 631426-1 CONTROLLER, PV7001C 1
26 417449-1 LEVER, PV7001C 1
27 232201-4 LEAF SPRING, PV7001C 1
28 183300-4 MOTOR HOUSING SET,PV7001 1
29 819063-3 MAKITA LABEL, 6992DWDE 1
30 852808-6 NAME PLATE, PV7001C 1
31 819063-3 MAKITA LABEL, 6992DWDE 1
32 643750-0 BRUSH HOLDER CAP, HM1100C 2
33 191963-2 CARBON BRUSH CB-303 SET, 9227C 1
34 651297-0 SWITCH, GV7000C 1
35 682559-5 CORD GUARD 8, 6824 1
36 664630-7 CORD 3X18X8 SJ, 9820-2 1
37 687063-9 STRAIN RELIEF, 4323K 1
38 265995-6 TAPPING SCREW 4X18, 4323K 2
41 265995-6 TAPPING SCREW 4X18, 4323K 1
42 265995-6 TAPPING SCREW 4X18, 4323K 2
43 652014-1 P.H. SCREW M4X8, 2708 2
44 265995-6 TAPPING SCREW 4X18, 4323K 1
45 654571-5 TERMINAL BLOCK, 9227C 1
46 652014-1 P.H. SCREW M4X8, 2708 1
47 417793-6 COVER, PV7001C 1
48 256157-7 PIN 3, 6222DWE 1
1,001 781008-0 WRENCH 17, 9217SPC 1
5,001 810134-9 N/A 1
Page 2 of 2 2/8/2008
