Parts Breakdown 5090D
Page 1 of 2 2/8/2008

Parts Breakdown 5090D
Fig # Part ID Part Name Quantity
1 182025-7 HOUSING SET, 5081D 1
1 183934-3 HOUSING SET, 5090DW 1
1 188195-0 N/A 1
2 256085-6 PIN 4, 4071D 1
3 342833-0 SET PLATE, 4071D 1
3 163157-9 SET PLATE, DA391D 1
4 191681-2 BATTERY 9000, 6012HDW 1
5 183934-3 HOUSING SET, 5090DW 1
5 182025-7 HOUSING SET, 5081D 1
5 188195-0 N/A 1
8 231749-3 TEN. SPRING 5, 5090DW 1
9 911121-2 P.H. SCREW M4X14, 9217SPC 3
10 164872-8 BLADE CASE, 5090DW 1
11 153132-3 GEAR, 5090DW 1
12 214017-9 P. BEARING 5, 6043D 1
13 232061-4 LEAF SPRING, 5090DW 1
14 856056-9 NAME PLATE, 5090D 1
15 911148-2 P.H. SCREW M4X25, 5057KB 5
16 651866-7 SWITCH 1
17 629574-8 MOTOR, 5090DW 1
18 214019-5 P. BEARING 4, 6043D 1
19 226053-3 GEAR 11-67, 5080DW (TYPE 1) 1
20 214019-5 P. BEARING 4, 6043D 1
21 256625-0 PIN 5, 5090D 1
22 231098-8 COMP. SPRING 6, 5090DW 1
23 961011-9 STOP RING E-4, 4301BV 1
24 164876-0 N/A 1
25 224177-9 OUTER FLANGE, 5090D 1
26 922212-4 H.S.H. BOLT M5X12, AF502 1
27 912222-9 C.S.H. SCREW M5X16, 2711 3
28 253184-5 F. WASHER 5, 5090DW 1
29 922206-9 H.S.H. BOLT M5X10, 5090DW 1
30 163281-8 BASE, 5090DW 1
31 253184-5 F. WASHER 5, 5090DW 1
32 922206-9 H.S.H. BOLT M5X10, 5090DW 1
41 414169-8 LOCK-OFF LEVER, 4390D 1
42 414168-0 SWITCH LEVER, UH3000D 1
43 231390-2 COMP. SPRING 3, UH3000D 1
44 643909-9 BATTERY HOLDER, 6222DWE 1
400 783202-0 HEX WRENCH 4, JR3000V 1
402 414938-7 BATTERY COVER, 6222DWE 1
Page 2 of 2 2/8/2008
