Makita LS0815F User manual

1
GB Slide Compound Miter Saw INSTRUCTION MANUAL
S
Skjutbar kap- och geringskombinationssåg BRUKSANVISNING
N
Skyvbar gjæringssag for kombinasjonssaging BRUKSANVISNING
FIN Ristikelkkasaha KÄYTTÖOHJE
LV Slīdrāmja kombinētais leņķzāģis LIETOŠANAS INSTRUKCIJA
LT
Kombinuotas nuleidžiamas skersavimo
ir kampųsuleidimo pjūklas
NAUDOJIMO INSTRUKCIJA
EE Liuglõike eerungisaag KASUTUSJUHEND
RUS
Торцовочная пила консольного типа РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
LS0815F
LS0815FL

2
1
1 010228
11
2 011382
1
3 014305
1
4 010386
1
5 010387
1
2
6 014287
12
3
45
7 001800
1
2
8 014306
2
1
3
9 001540
12
10 010233
12
3
4
11 010234
1
12 014281
3
1
4
2
13 014307
1
2
3
14 014308
1
15 011352

3
1
23
4
16 010429
12
3
17 010388
1
18 014271
1
19 014270
1
20 014274
1
2
21 014282
1
22 014303
12
3
4
5
23 010390
1
2
3
45
24 010391
123
4
25 010392
1
2
3
45
6
26 014309
12
3
4
5
27 010560
1
2
3
28 014283
12
29 001549
1
2
30 014595

4
1
31 014647
1 2
3
4
5
32 014289
12
33 014284
34 014276
123
35 001555
2
(1)
(2)
(1)
(2) (2)
(1)
(2)
(1)
(1)
(2)
(3)(4)
1
36 001557
1
2
3
4
5
37 010404
1
38 001563 39 014292
1
2
3
40 014273
12
41 014298
1
2
3
42 014277
1
2
43 014299
1
2
44 014295
1
2
3
45 001819

5
1
2
3
46 014286
12
47 014296 48 007834
1
2
49 010256

6
ENGLISH
Contents
SPECIFICATIONS........................................................8
General Power Tool Safety Warnings ...........................9
ADDITIONAL SAFETY RULES FOR TOOL..................9
INSTALLATION...........................................................10
FUNCTIONAL DESCRIPTION....................................11
ASSEMBLY ................................................................13
OPERATION...............................................................15
MAINTENANCE .........................................................19
OPTIONAL ACCESSORIES .......................................20
SVENSKA
Innehåll
SPECIFIKATIONER....................................................22
Allmänna säkerhetsvarningar för maskin ....................23
YTTERLIGARE SÄKERHETSANVISNINGAR FÖR
MASKINEN.................................................................23
INSTALLATION...........................................................24
FUNKTIONSBESKRIVNING.......................................25
MONTERING..............................................................27
ANVÄNDNING............................................................29
UNDERHÅLL..............................................................32
VALFRIA TILLBEHÖR ................................................33
NORSK
Innhold
TEKNISKE DATA........................................................36
Generelle advarsler angående sikkerhet for
elektroverktøy.............................................................37
YTTERLIGERE SIKKERHETSREGLER FOR
MASKINEN.................................................................37
MONTERING..............................................................38
FUNKSJONSBESKRIVELSE .....................................39
MONTERING..............................................................41
BRUK .........................................................................43
VEDLIKEHOLD ..........................................................47
VALGFRITT TILBEHØR .............................................48
SUOMI
Sisällys
TEKNISET TIEDOT ....................................................50
Sähkötyökalujen käyttöä koskevat varoitukset............51
LISÄÄ TURVAOHJEITA KONEELLE ..........................51
ASENNUS ..................................................................52
TOIMINTOJEN KUVAUS ............................................53
KOKOONPANO..........................................................55
TYÖSKENTELY..........................................................57
KUNNOSSAPITO .......................................................61
LISÄVARUSTEET.......................................................62
LATVIEŠU
Saturs
SPECIFIKĀCIJAS.......................................................64
Vispārējie mehanizēto darbarīku drošības brīdinājumi65
PAPILDUS DROŠĪBAS NOTEIKUMI DARBARĪKA
LIETOŠANAI ..............................................................65
UZSTĀDĪŠANA ..........................................................66
FUNKCIJU APRAKSTS..............................................67
MONTĀŽA..................................................................70
EKSPLUATĀCIJA.......................................................71
APKOPE ....................................................................75
PAPILDU PIEDERUMI................................................76
LIETUVIŲKALBA
Turinys
SPECIFIKACIJOS ......................................................78
Bendrieji perspėjimai darbui su elektriniais įrankiais ...79
PAPILDOMOS ĮRANKIO SAUGOS TAISYKLĖS ........79
SUMONTAVIMAS.......................................................80
VEIKIMO APRAŠYMAS .............................................81
SURINKIMAS.............................................................84
NAUDOJIMAS............................................................85
TECHNINĖPRIEŽIŪRA .............................................89
PASIRENKAMI PRIEDAI............................................90
EESTI
Sisu
TEHNILISED ANDMED ..............................................92
Üldised elektritööriistade ohutushoiatused..................93
TÄIENDAVAD TÖÖRIISTA OHUTUSNORMID ...........93
PAIGALDAMINE.........................................................94
FUNKTSIONAALNE KIRJELDUS...............................95
KOKKUPANEK...........................................................98
TÖÖRIISTA KASUTAMINE.........................................99
HOOLDUS................................................................103
VALIKULISED TARVIKUD........................................104
РУССКИЙ ЯЗЫК
Содержание
ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ .....................106
Общие рекомендации по технике безопасности для
электроинструментов .............................................107
ДОПОЛНИТЕЛЬНЫЕ ПРАВИЛА ТЕХНИКИ
БЕЗОПАСНОСТИ ДЛЯ ИНСТРУМЕНТА ................107
УСТАНОВКА............................................................109
ОПИСАНИЕ ФУНКЦИОНИРОВАНИЯ ....................109
МОНТАЖ ................................................................. 113
ЭКСПЛУАТАЦИЯ..................................................... 115
ТЕХОБСЛУЖИВАНИЕ ............................................ 119
ДОПОЛНИТЕЛЬНЫЕ ПРИНАДЛЕЖНОСТИ..........120

7
ENGLISH (Original instructions)
Explanation of general view
1-1. Stopper pin
2-1. Bolts
3-1. Adjusting bolt
4-1. Blade guard
5-1. Blade guard
6-1. Kerf board
6-2. Screw
7-1. Saw blade
7-2. Blade teeth
7-3. Kerf board
7-4. Left bevel cut
7-5. Straight cut
8-1. Adjusting bolt
8-2. Turn base
9-1. Top surface of turn base
9-2. Periphery of blade
9-3. Guide fence
10-1. Stopper arm
10-2. Adjusting screw
11-1. Miter scale
11-2. Pointer
11-3. Lock lever
11-4. Grip
12-1. Lever
13-1. Lever
13-2. Arm
13-3. Pointer
13-4. Bevel scale
14-1. Pointer
14-2. Release button
14-3. Bevel scale
15-1. Locking screw
16-1. Lock-off button
16-2. Lever
16-3. Switch trigger
16-4. Hole for padlock
17-1. Lock-off button
17-2. Switch trigger
17-3. Hole for padlock
18-1. Switch for laser
19-1. Light
20-1. Switch for light
21-1. Socket wrench with hex wrench
on its other end
21-2. Wrench holder
22-1. Stopper pin
23-1. Socket wrench
23-2. Blade case
23-3. Center cover
23-4. Hex bolt
23-5. Blade guard
24-1. Blade case
24-2. Socket wrench
24-3. Hex bolt
24-4. Arrow
24-5. Shaft lock
25-1. Blade case
25-2. Arrow
25-3. Arrow
25-4. Saw blade
26-1. Hex bolt (left-handed)
26-2. Outer flange
26-3. Saw blade
26-4. Ring
26-5. Inner flange
26-6. Spindle
27-1. Socket wrench
27-2. Blade case
27-3. Center cover
27-4. Hex bolt
27-5. Blade guard
28-1. Dust nozzle
28-2. Dust bag
28-3. Fastener
29-1. Support
29-2. Turn base
30-1. Sliding fence
30-2. Clamping screw
31-1. Sliding fence
32-1. Vise arm
32-2. Vise knob
32-3. Vise rod
32-4. Screw
32-5. Guide fence
33-1. Holder
33-2. Screw
35-1. 52/38 ﾟtype crown molding
35-2. 45 ﾟtype crown molding
35-3. 45 ﾟtype cove molding
36-1. Inside corner
36-2. Outside corner
37-1. Guide fence
37-2. Vise
37-3. Spacer block
37-4. Aluminum extrusion
37-5. Spacer block
38-1. Cut grooves with blade
40-1. Guide fence
40-2. Hex bolts
40-3. Grip
41-1. Guide fence
41-2. Triangular rule
42-1. Screw
42-2. Pointer
42-3. Miter scale
43-1. Lever
43-2. Arm
44-1. 0 ﾟadjusting bolt
44-2. Left 45 ﾟbevel angle adjusting
bolt
45-1. Triangular rule
45-2. Saw blade
45-3. Top surface of turn table
46-1. Screw
46-2. Pointer
46-3. Bevel scale
47-1. Right 5 ﾟbevel angle adjusting
bolt
47-2. Left 45 ﾟbevel angle adjusting
bolt
49-1. Screwdriver
49-2. Brush holder cap

8
SPECIFICATIONS
Model LS0815F / LS0815FL
Blade diameter 216 mm
Blade thickness 1.5 - 2.5 mm
Hole diameter
- For all countries other than European countries 25.4 mm
- For European countries 30 mm
Max. Miter angle Left 50° Right 60°
Max. Bevel angle Left 48° Right 5°
Max. Cutting capacities (H x W) with 216 mm in diameter
Bevel angle
Miter angle 45° (left) 5° (right) 0°
0° 50 mm x 305 mm 60 mm x 305 mm 65 mm x 305 mm
45° 50 mm x 215 mm - 65 mm x 215 mm
60° (right) - - 65 mm x 150 mm
Rated voltage 220 - 240 V, 50 - 60 Hz
Rated input 1,400 w, S6 40% 5 min
No load speed (min-1) 5,000
Laser Type (LS0815FL only) Red Laser 650 nm, 1mW ( Laser Class 2 )
Dimensions (L x W x H) 755 mm x 450 mm x 488 mm
Net weight For all countries other than European countries•••14.1 kg
For European countries•••LS0815F 14.1 kg
••• LS0815FL 14.2 kg
Safety class /II
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END223-4
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･Read instruction manual.
･DOUBLE INSULATION
･To avoid injury from flying debris, keep
holding the saw head down, after
making cuts, until the blade has come
to a complete stop.
･When performing slide cut, first pull
carriage fully and press down handle,
then push carriage toward the guide
fence.
･Do not place hand or fingers close to
the blade.
･Adjust sliding fences clear of blade and
blade guard properly.
･LASER RADIATION: Do not stare into
beam. Direct laser beam may injure
your eyes.
･Only for EU countries
Do not dispose of electric equipment
together with household waste
material!
In observance of the European
Directive, on Waste Electric and
Electronic Equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE006-1
Intended use
The tool is intended for accurate straight and miter
cutting in wood. With appropriate saw blades, aluminum
can also be sawed.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.

9
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN61029:
Sound pressure level (LpA) : 87 dB (A)
Sound power level (LWA) : 110 dB (A)
Uncertainty (K) : 3 dB (A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN61029:
Vibration emission (ah) : 2.5 m/s2or less
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
ENH103-1
For European countries only
EC Declaration of Conformity
Makita declares that the following Machine(s):
Designation of Machine:
Slide Compound Miter Saw
Model No./ Type:
LS0815F, LS0815FL
Conforms to the following European Directives:
2006/42/EC, 2006/95/EC, 2006/108/EC,
2006/65/EC
They are manufactured in accordance with the following
Standard or standardized documents:
EN61029, EN 55014-1, EN 55014-2,
EN 61000-3-2, EN 61000-3-3
The Technical file in accordance with 2006/42/EC is
available from:
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
20.12.2013
000331
Yasushi Fukaya
Director
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
GEA010-1
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for
future reference.
ENB034-7
ADDITIONAL SAFETY RULES
FOR TOOL
1. Wear eye protection.
2. Keep hands out of path of saw blade. Avoid
contact with any coasting blade. It can still
cause severe injury.
3.
Do not operate saw without guards in place.
Check blade guard for proper closing before each
use. Do not operate saw if blade guard does not
move freely and close instantly. Never clamp or
tie the blade guard into the open position.
4. Do not perform any operation freehand. The
workpiece must be secured firmly against the turn
base and guide fence with the vise during all
operations. Never use your hand to secure the
workpiece.
5. Never reach around saw blade.
6. Turn off tool and wait for saw blade to stop
before moving workpiece or changing
settings.
7. Unplug tool before changing blade or
servicing.
8. Always secure all moving portions before
carrying the tool.
9. Stopper pin which locks the cutter head down
is for carrying and storage purposes only and
not for any cutting operations.
10.
Do not use the tool in the presence of flammable
liquids or gases.
The electrical operation of the tool
could create an explosion and fire when exposed to
flammable liquids or gases.
11. Check the blade carefully for cracks or
damage before operation.
Replace cracked or damaged blade
immediately.

10
12. Use only flanges specified for this tool.
13. Be careful not to damage the arbor, flanges
(especially the installing surface) or bolt.
Damage to these parts could result in blade
breakage.
14. Make sure that the turn base is properly
secured so it will not move during operation.
15.
For your safety, remove the chips, small
pieces, etc. from the table top before operation.
16. Avoid cutting nails. Inspect for and remove all
nails from the workpiece before operation.
17. Make sure the shaft lock is released before
the switch is turned on.
18. Be sure that the blade does not contact the
turn base in the lowest position.
19. Hold the handle firmly. Be aware that the saw
moves up or down slightly during start-up and
stopping.
20. Make sure the blade is not contacting the
workpiece before the switch is turned on.
21. Before using the tool on an actual workpiece,
let it run for a while. Watch for vibration or
wobbling that could indicate poor installation
or a poorly balanced blade.
22. Wait until the blade attains full speed before
cutting.
23. Stop operation immediately if you notice
anything abnormal.
24. Do not attempt to lock the trigger in the on
position.
25. Be alert at all times, especially during
repetitive, monotonous operations. Do not be
lulled into a false sense of security. Blades
are extremely unforgiving.
26. Always use accessories recommended in this
manual. Use of improper accessories such as
abrasive wheels may cause an injury.
27. Do not use the saw to cut other than wood,
aluminum or similar materials.
28. Connect miter saws to a dust collecting
device when sawing.
29. Select saw blades in relation to the material to
be cut.
30. Take care when slotting.
31. Replace the kerf board when worn.
32. Do not use saw blades manufactured from
high speed steel.
33. Some dust created from operation contains
chemicals known to cause cancer, birth
defects or other reproductive harm. Some
examples of these chemicals are:
• lead from lead-based-painted material and,
• arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
34. To reduce the emitted noise, always be sure
that the blade is sharp and clean.
35. The operator is adequately trained in the use,
adjustment and operation of the machine.
36. Use correctly sharpened saw blades. Observe
the maximum speed marked on the saw blade.
37. Refrain from removing any cut-offs or other
parts of the workpiece from the cutting area
whilst the tool is running and the saw head is
not in the rest position.
38. Use only saw blades recommended by the
manufacturer which conform to EN847-1.
39. Wear gloves for handling saw blade (saw
blades shall be carried in a holder wherever
practicable) and rough material.
40. Keep the floor area free of loose material e.g.
chips and cut-offs.
41. When fitted with laser, no exchange with
different type of laser is permitted. Repairs
shall only be carried out correctly.
SAVE THESE INSTRUCTIONS.
INSTALLATION
Bench mounting
Fig.1
When the tool is shipped, the handle is locked in the
lowered position by the stopper pin. Release the
stopper pin by simultaneously applying a slight
downward pressure on the handle and pulling the
stopper pin.
WARNING:
• Ensure that the tool will not move on the
supporting surface. Movement of the miter saw
on the supporting surface while cutting may result
in loss of control and serious personal injury.
Fig.2
This tool should be bolted with four bolts to a level and
stable surface using the bolt holes provided in the tool's
base. This will help prevent tipping and possible injury.
Fig.3
Turn the adjusting bolt clockwise or counterclockwise so
that it comes into a contact with the tool surface to keep
the tool stable.

11
FUNCTIONAL DESCRIPTION
WARNING:
• Always be sure that the tool is switched off
and unplugged before adjusting or checking
function on the tool. Failure to switch off and
unplug the tool may result in serious personal
injury from accidental start-up.
Blade guard
Fig.4
When lowering the handle, the blade guard rises
automatically. The blade guard returns to its original
position when the cut is completed and the handle is
raised.
WARNING:
• Never defeat or remove the blade guard or the
spring which attaches to the guard. An exposed
blade as a result of defeated guarding may result
in serious personal injury during operation.
In the interest of your personal safety, always maintain
the blade guard in good condition. Any irregular
operation of the blade guard should be corrected
immediately. Check to assure spring loaded return
action of guard.
WARNING:
• Never use the tool if the blade guard or spring
are damaged, faulty or removed. Operation of
the tool with a damaged, faulty or removed guard
may result in serious personal injury.
If the see-through blade guard becomes dirty, or
sawdust adheres to it in such a way that the blade
and/or workpiece is no longer easily visible, unplug the
saw and clean the guard carefully with a damp cloth. Do
not use solvents or any petroleum-based cleaners on
the plastic guard because this may cause damage to
the guard.
If the blade guard becomes dirty and needs to be
cleaned for proper operation follow the steps below:
With the tool switched off and unplugged, use the
supplied socket wrench to loosen the hex bolt holding
the center cover. Loosen the hex bolt by turning it
counterclockwise and raise the blade guard and center
cover.
Fig.5
With the blade guard so positioned, cleaning can be
more completely and efficiently accomplished. When
cleaning is complete reverse procedure above and
secure bolt. Do not remove spring holding blade guard.
If guard becomes damaged through age or UV light
exposure, contact a Makita service center for a new
guard. DO NOT DEFEAT OR REMOVE GUARD.
Positioning kerf board
Fig.6
Fig.7
This tool is provided with the kerf boards in the turn
base to minimize tearing on the exit side of a cut. The
kerf boards are factory adjusted so that the saw blade
does not contact the kerf boards. Before use, adjust the
kerf boards as follows:
First, unplug the tool. Loosen all the screws (3 each on
left and right) securing the kerf boards. Re-tighten them
only to the extent that the kerf boards can still be easily
moved by hand. Lower the handle fully and push in the
stopper pin to lock the handle in the lowered position.
Loosen the screw which secures the slide poles. Pull
the carriage toward you fully. Adjust the kerf boards so
that the kerf boards just contact the sides of the blade
teeth. Tighten the front screws (do not tighten firmly).
Push the carriage toward the guide fence fully and
adjust the kerf boards so that the kerf boards just
contact the sides of blade teeth. Tighten the rear screws
(do not tighten firmly).
After adjusting the kerf boards, release the stopper pin
and raise the handle. Then tighten all the screws securely.
NOTICE:
• After setting the bevel angle ensure that the
kerf boards are adjusted properly. Correct
adjustment of the kerf boards will help provide
proper support of the workpiece minimizing
workpiece tear out.
Maintaining maximum cutting capacity
This tool is factory adjusted to provide the maximum
cutting capacity for a 216 mm saw blade.
Unplug the tool before any adjustment is attempted.
When installing a new blade, always check the lower
limit position of the blade and if necessary, adjust it as
follows:
Fig.8
Fig.9
First, unplug the tool. Push the carriage toward the guide
fence fully and lower the handle completely. Use the hex.
wrench to turn the adjusting bolt until the periphery of the
blade extends slightly below the top surface of the turn
base at the point where the front face of the guide fence
meets the top surface of the turn base.
With the tool unplugged, rotate the blade by hand while
holding the handle all the way down to be sure that the
blade does not contact any part of the lower base. Re-
adjust slightly, if necessary.
WARNING:
• After installing a new blade and with the tool
unplugged, always be sure that the blade does
not contact any part of the lower base when
the handle is lowered completely. If a blade
makes contact with the base it may cause
kickback and result in serious personal injury.

12
Stopper arm
Fig.10
The lower limit position of the blade can be easily
adjusted with the stopper arm. To adjust it, move the
stopper arm in the direction of the arrow as shown in the
figure. Adjust the adjusting screw so that the blade
stops at the desired position when lowering the handle
fully.
Adjusting the miter angle
Fig.11
Loosen the grip by turning counterclockwise. Turn the
turn base while pressing down the lock lever. When you
have moved the grip to the position where the pointer
points to the desired angle on the miter scale, securely
tighten the grip clockwise.
CAUTION:
• After changing the miter angle, always secure the
turn base by tightening the grip firmly.
NOTICE:
• When turning the turn base, be sure to raise the
handle fully.
Adjusting the bevel angle
Fig.12
To adjust the bevel angle, loosen the lever at the rear of
the tool counterclockwise. Unlock the arm by pushing
the handle somewhat strongly in the direction that you
intend to tilt the saw blade.
NOTE:
• Lever can be adjusted to a different lever angle by
removing the screw holding the lever and securing
the lever at a desired angle.
Fig.13
Tilt the saw blade until the pointer points to the desired
angle on the bevel scale. Then tighten the lever
clockwise firmly to secure the arm.
Fig.14
To tilt the saw blade to right 5 ﾟor left 48 ﾟ: set the saw
blade to 0 ﾟfor right 5 ﾟ, or 45 ﾟfor left 48 ﾟ. Then
slightly tilt the saw blade to the opposite side. Push the
release button and tilt the saw blade to the desired
position. Tighten the lever to secure the arm.
CAUTION:
• After changing the bevel angle, always secure the
arm by tightening the lever clockwise.
NOTICE:
• When tilting the saw blade be sure the handle is
fully raised.
• When changing bevel angles, be sure to position
the kerf boards appropriately as explained in the
"Positioning kerf boards" section.
Slide lock adjustment
Fig.15
To lock the slide pole, turn the locking screw clockwise.
Switch action
For European countries
Fig.16
To prevent the switch trigger from being accidentally
pulled, a lock-off button is provided. To start the tool,
push the lever to the left, press in the lock-off button and
then pull the switch trigger. Release the switch trigger to
stop.
WARNING:
• Before plugging in the tool, always check to
see that the switch trigger actuates properly
and returns to the "OFF" position when
released. Do not pull the switch trigger hard
without pressing in the lock-off button. This
can cause switch breakage. Operating a tool
with a switch that does not actuate properly can
lead to loss of control and serious personal injury.
A hole is provided in the switch trigger for insertion of
padlock to lock the tool off.
For all countries other than European countries
Fig.17
To prevent the switch trigger from being accidentally
pulled, a lock-off button is provided. To start the tool,
press in the lock-off button and pull the switch trigger.
Release the switch trigger to stop.
WARNING:
• Before plugging in the tool, always check to
see that the switch trigger actuates properly
and returns to the "OFF" position when
released. Do not pull the switch trigger hard
without pressing in the lock-off button. This
can cause switch breakage. Operating a tool
with a switch that does not actuate properly can
lead to loss of control and serious personal injury.
A hole is provided in the switch trigger for insertion of
padlock to lock the tool off.
WARNING:
• Do not use a lock with a shank or cable any
smaller than 6.35 mm in diameter. A smaller
shank or cable may not properly lock the tool in
the off position and unintentional operation may
occur resulting in serious personal injury.
• NEVER use tool without a fully operative
switch trigger. Any tool with an inoperative switch
is HIGHLY DANGEROUS and must be repaired
before further usage or serious personal injury
may occur.
• For your safety, this tool is equipped with a lock-off
button which prevents the tool from unintended
starting. NEVER use the tool if it runs when you

13
simply pull the switch trigger without pressing the
lock-off button. A switch in need of repair may
result in unintentional operation and serious
personal injury. Return tool to a Makita service
center for proper repairs BEFORE further usage.
• NEVER defeat the lock-off button by taping down
or some other means. A switch with a defeated
lock-off button may result in unintentional
operation and serious personal injury.
Electronic function
Soft start feature
• This function allows the smooth start-up of the tool
by limiting the start-up torque.
Laser beam action
For model LS0815FL only
NOTE:
• Before the first use, install the dry cells provided
separately from the tool in the cell box. Refer to
the section titled "Replacing the dry cells for laser
unit" for the installment.
CAUTION:
• When not in use, be sure to turn off the laser
Fig.18
CAUTION:
• Never look into the laser beam. Direct laser beam
may injure your eyes.
• LASER RADIATION, DO NOT STARE INTO THE
BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS, CLASS 2M LASER PRODUCT.
• Before shifting the laser line or performing
maintenance adjustment, be sure to unplug the
tool.
To turn on the laser beam, press the upper position
(ON) of the switch. To turn off the laser beam, press the
lower position (OFF) of the switch.
Laser line can be shifted to either the left or right side of
the saw blade by loosening the screw holding the laser
unit box and shifting it in the desired direction. After
shifting, be sure to tighten the screw.
1
014275
Laser line is factory adjusted so that it is positioned
within 1 mm from the side surface of the blade (cutting
position).
NOTE:
• When laser line appears dim and hard to see
because of direct sunlight, relocate the work area
to a place where there is less direct sunlight.
Cleaning of the lens for the laser light
If the lens for the laser light becomes dirty, or sawdust
adheres to it in such a way that the laser line is no
longer easily visible, unplug the saw and remove and
clean the lens for the laser light carefully with a damp,
soft cloth. Do not use solvents or any petroleum-based
cleaners on the lens.
NOTE:
• When laser line is dim and almost or entirely
invisible because of the direct sunlight in the
indoor or outdoor window-by work, relocate the
work area to a place not exposed to the direct
sunlight.
Light action
Fig.19
Fig.20
To turn on the light, press the upper position (ON) of the
switch. To turn off the light, press the lower position
(OFF) of the switch.
CAUTION:
• Do not look in the light or see the source of light
directly.
NOTE:
• Use a dry cloth to wipe the dirt off the lens of lamp.
• Be careful not to scratch the lens of lamp, or it
may to lower the luminance.
ASSEMBLY
WARNING:
• Always be sure that the tool is switched off
and unplugged before working on the tool.
Failure to switch off and unplug the tool may result
in serious personal injury.
Storage of socket wrench with hex wrench on
its other end
Fig.21
The socket wrench is stored as shown in the figure.
When the socket wrench is needed it can be pulled out
of the wrench holder. After using the socket wrench it
can be stored by returning it to the wrench holder.
1. Screw holding the laser unit bo
x

14
Installing or removing saw blade
WARNING:
• Always be sure that the tool is switched off
and unplugged before installing or removing
the blade. Accidental start up of the tool may
result in serious personal injury.
• Use only the Makita socket wrench provided to
install or remove the blade. Failure to use the
wrench may result in overtightening or insufficient
tightening of the hex bolt and serious personal
injury.
Fig.22
Lock the handle in the raised position by pushing in the
stopper pin.
Fig.23
To remove the blade, use the socket wrench to loosen
the hex bolt holding the center cover by turning it
counterclockwise. Raise the blade guard and center
cover.
WARNING:
• Do not remove any screw other than the hex
bolt illustrated. If you mistakenly remove another
screw and the blade guard comes off, make sure
to re-assemble the blade guard.
Fig.24
Press the shaft lock to lock the spindle and use the
socket wrench to loosen the hex bolt clockwise. Then
remove the hex bolt, outer flange and blade.
NOTE:
• If the inner flange is removed be sure to install it
on the spindle with its protrusion facing away from
the blade. If the flange is installed incorrectly the
flange will rub against the machine.
WARNING:
• Before mounting the blade onto the spindle,
always be sure that the correct ring for the
blade's arbor hole you intend to use is
installed between the inner and the outer
flanges. Use of the incorrect arbor hole ring may
result in the improper mounting of the blade
causing blade movement and severe vibration
resulting in possible loss of control during
operation and in serious personal injury.
Fig.25
To install the blade, mount it carefully onto the spindle,
making sure that the direction of the arrow on the
surface of the blade matches the direction of the arrow
on the blade case.
Install the outer flange and hex bolt, and then use the
socket wrench to tighten the hex bolt (left-handed)
securely counterclockwise while pressing the shaft lock.
For all countries other than European countries
Fig.26
CAUTION:
• The ring 25.4 mm in outer diameter is factory-
installed as shown in the figure.
For European countries
CAUTION:
• The ring 30 mm in outer diameter is factory-
installed between the inner and outer flanges.
Install the outer flange and hex bolt, and then use the
socket wrench to tighten the hex bolt securely
counterclockwise while pressing the shaft lock.
Fig.27
Return the blade guard and center cover to its original
position. Then tighten the hex bolt clockwise to secure
the center cover. Release the handle from the raised
position by pulling the stopper pin. Lower the handle to
make sure that the blade guard moves properly. Make
sure the shaft lock has released spindle before making
cut.
Dust bag
Fig.28
The use of the dust bag makes cutting operations
cleaner and dust collection easier. To attach the dust
bag, fit it onto the dust nozzle.
When the dust bag is about half full, remove the dust
bag from the tool and pull the fastener out. Empty the
dust bag of its contents, tapping it lightly so as to
remove particles adhering to the insides which might
hamper further collection.
NOTE:
If you connect a vacuum cleaner to your saw, cleaner
operations can be performed.
Securing workpiece
WARNING:
• It is extremely important to always secure the
workpiece correctly with the proper type of
vise or crown molding stoppers. Failure to do
so may result in serious personal injury and cause
damage to the tool and/or the workpiece.
• After a cutting operation do not raise the blade
until it has come to a complete stop. The
raising of a coasting blade may result in serious
personal injury and damage to the workpiece.
• When cutting a workpiece that is longer than
the support base of the saw, the material
should be supported the entire length beyond
the support base and at the same height to
keep the material level. Proper workpiece
support will help avoid blade pinch and possible
kickback which may result in serious personal
injury. Do not rely solely on the vertical vise and/or

15
horizontal vise to secure the workpiece. Thin
material tends to sag. Support workpiece over its
entire length to avoid blade pinch and possible
KICKBACK.
Fig.29
Guide fence (SLIDING FENCES) adjustment
Fig.30
WARNING:
• Before operating the tool, make sure that the
sliding fence is secured firmly.
• Before bevel-cutting, make sure that no part of
the tool, especially the blade, contacts the
sliding fence. when fully lowering and raising
the handle in any position and while moving
the carriage through its full range of travel. If
the blade makes contact the sliding fence may
result in kickback or unexpected movement of
the material and serious personal injury.
Fig.31
CAUTION:
• When performing bevel cuts, slide the sliding
fence to the left and secure it as shown in the
figure. Otherwise, it will contact the blade or a part
of the tool, causing possible serious injury to the
operator.
This tool is equipped with the sliding fence which should
ordinarily be positioned as shown in the figure.
However, when performing left bevel cuts, set it to the
left position as shown in the figure if the tool head
contacts it.
When bevel-cutting operations are complete, don't
forget to return the sliding fence to the original position
and secure it by firmly tightening the clamping screw.
Vertical vise
Fig.32
The vertical vise can be installed on either the left or
right side of the guide fence. Insert the vise rod into the
hole in the guide fence and tighten the screw on the
back of the guide fence to secure the vise rod.
Position the vise arm according to the thickness and
shape of the workpiece and secure the vise arm by
tightening the screw. If the screw to secure the vise arm
contacts the guide fence, install the screw on the
opposite side of vise arm. Make sure that no part of the
tool contacts the vise when lowering the handle fully
and pulling or pushing the carriage all the way. If some
part contacts the vise, re-position the vise.
Press the workpiece flat against the guide fence and the
turn base. Position the workpiece at the desired cutting
position and secure it firmly by tightening the vise knob.
WARNING:
• The workpiece must be secured firmly against
the turn base and guide fence with the vise
during all operations. If the workpiece is not
properly secured against the fence the material
may move during the cutting operation causing
possible damage to the blade, causing the
material to be thrown and loss of control resulting
in serious personal injury.
Holders
Fig.33
The holders can be installed on either side as a
convenient means of holding workpieces horizontally.
Slip fully the holder rods into the holes in the base. Then
tighten the holders securely with the screws.
WARNING:
• Always support a long workpiece so it is level
with the top surface of the turn base for an
accurate cut and to prevent dangerous loss of
tool control. Proper workpiece support will help
avoid blade pinch and possible kickback which
may result in serious personal injury.
OPERATION
NOTICE:
• Before use, be sure to release the handle from the
lowered position by pulling the stopper pin.
• Do not apply excessive pressure on the handle
when cutting. Too much force may result in
overload of the motor and/or decreased cutting
efficiency. Push down handle with only as much
force as is necessary for smooth cutting and
without significant decrease in blade speed.
• Gently press down the handle to perform the cut. If
the handle is pressed down with force or if lateral
force is applied, the blade will vibrate and leave a
mark (saw mark) in the workpiece and the
precision of the cut will be impaired.
• During a slide cut, gently push the carriage toward
the guide fence without stopping. If the carriage
movement is stopped during the cut, a mark will
be left in the workpiece and the precision of the
cut will be impaired.
WARNING:
• Make sure the blade is not contacting the
workpiece, etc. before the switch is turned on.
Turning the tool on with the blade in contact with
the workpiece may result in kickback and serious
personal injury.

16
1. Press cutting (cutting small workpieces)
1
014290
Workpieces up to 90 mm high and 60 mm wide
can be cut in the following manner.
Push the carriage toward the guide fence fully and
tighten the locking screw clockwise to secure the
carriage. Secure the workpiece correctly with the
proper type of vise. Switch on the tool without the
blade making any contact and wait until the blade
attains full speed before lowering. Then gently
lower the handle to the fully lowered position to cut
the workpiece. When the cut is completed, switch
off the tool and WAIT UNTIL THE BLADE HAS
COME TO A COMPLETE STOP before returning
the blade to its fully elevated position.
WARNING:
• Firmly tighten the knob clockwise so that the
carriage will not move during operation.
Insufficient tightening of the knob may cause
possible kickback which may result in serious
personal injury.
• Never cut so small workpiece which cannot be
securely held by the vise. Improperly held
workpiece may cause kickback and serious
personal injury.
2. Slide (push) cutting (cutting wide workpieces)
1
014291
Loosen the locking screw counterclockwise so that
the carriage can slide freely. Secure the workpiece
with the proper type of vise. Pull the carriage
toward you fully. Switch on the tool without the
blade making any contact and wait until the blade
attains full speed. Press the handle down and
PUSH THE CARRIAGE TOWARD THE GUIDE
FENCE AND THROUGH THE WORKPIECE.
When the cut is completed, switch off the tool and
WAIT UNTIL THE BLADE HAS COME TO A
COMPLETE STOP before returning the blade to
its fully elevated position.
WARNING:
• Whenever performing a slide cut, first pull the
carriage full towards you and press the handle
all the way down, then push the carriage
toward the guide fence. Never start the cut with
the carriage not pulled fully toward you. If you
perform the slide cut without the carriage pulled
fully toward you unexpected kickback may occur
and serious personal injury may result.
• Never attempt to perform a slide cut by pulling
the carriage towards you. Pulling the carriage
towards you while cutting may cause unexpected
kickback resulting in possible serious personal
injury.
• Never perform the slide cut with the handle locked
in the lowered position.
• Never loosen the locking screw which secures
the carriage while the blade is rotating. A loose
carriage while cutting may cause unexpected
kickback resulting in possible in serious personal
injury.
1. Locking screw 1. Locking screw

17
3. Miter cutting
Refer to the previously covered "Adjusting the
miter angle".
4. Bevel cut
Fig.34
Loosen the lever and tilt the saw blade to set the
bevel angle (Refer to the previously covered
"Adjusting the bevel angle"). Be sure to retighten
the lever firmly to secure the selected bevel angle
safely. Secure the workpiece with a vise. Make
sure the carriage is pulled all the way back toward
the operator. Switch on the tool without the blade
making any contact and wait until the blade attains
full speed. Then gently lower the handle to the
fully lowered position while applying pressure in
parallel with the blade and PUSH THE CARRIAGE
TOWARD THE GUIDE FENCE TO CUT THE
WORKPIECE. When the cut is completed, switch
off the tool and WAIT UNTIL THE BLADE HAS
COME TO A COMPLETE STOP before returning
the blade to its fully elevated position.
WARNING:
• After setting the blade for a bevel cut, before
operating the tool ensure that the carriage and
blade will have free travel throughout the
entire range of the intended cut. Interruption of
the carriage or blade travel during the cutting
operation may result in kickback and serious
personal injury.
• While making a bevel cut keep hands out of
the path of the blade. The angle of the blade may
confuse the operator as to the actual blade path
while cutting and contact with the blade will result
in serious personal injury.
• The blade should not be raised until it has
come to a complete stop. During a bevel cut the
piece cut off may come to rest against the blade.
If the blade is raised while it is rotating the cut-off
piece maybe ejected by the blade causing the
material to fragment which may result in serious
personal injury.
NOTICE:
• When pressing down the handle, apply pressure in
parallel with the blade. If a force is applied
perpendicularly to the turn base or if the pressure
direction is changed during a cut, the precision of
the cut will be impaired.
• Before bevel-cutting, an adjustment of sliding
fence maybe required. Refer to the section titled
"Guide fence adjustment".
5. Compound cutting
Compound cutting is the process in which a bevel
angle is made at the same time in which a miter angle
is being cut on a workpiece. Compound cutting can be
performed at the angle shown in the table.
Miter angle Bevel angle
Left 0 - 45
Left and Right 0 - 45
010340
When performing compound cutting, refer to
"Press cutting", "Slide cutting", "Miter cutting" and
"Bevel cut" explanations.
6. Cutting crown and cove moldings
Crown and cove moldings can be cut on a
compound miter saw with the moldings laid flat on
the turn base.
There are two common types of crown moldings
and one type of cove moldings; 52/38° wall angle
crown molding, 45° wall angle crown molding and
45° wall angle cove molding. See illustrations.
Fig.35
There are crown and cove molding joints which are
made to fit "Inside" 90° corners ((1) and (2) in Fig. A)
and "Outside" 90° corners ((3) and (4) in Fig. A).
(1) (2) (3)(4)
1 2
Fig.A
001556
Fig.36
Measuring
Measure the wall length and adjust workpiece on
table to cut wall contact edge to desired length.
Always make sure that cut workpiece length at the
back of the workpiece is the same as wall length.
Adjust cut length for angle of cut. Always use
several pieces for test cuts to check the saw
angles.
When cutting crown and cove moldings, set the
bevel angle and miter angle as indicated in the
table (A) and position the moldings on the top
surface of the saw base as indicated in the table
(B).
In the case of left bevel cut
Molding
positionin
Fig. A
Bevel angleMiter angle
Foroutside
corner
Forinside
corner
52/38° type45° type
Right 31.6°
45° type
Left 33.9° Left 30°
52/38° type
Left 31.6° Left 35.3°
Right 35.3°
Right 35.3°Right 31.6°
(1)
(2)
(3)
(4)
Table(A)
006361
1. Inside corner
2. Outside corner

18
Molding
positionin
Fig. A
Molding edge against
guide fence
(1) Ceiling contactedge should
beagainstguide fence.
Ceiling contactedge should
beagainstguide fence.
For
outside
corner
Finished piece
will beonthe
Left side of
blade.
Finished piece
will beonthe
Right side of
blade.
Forinside
corner
Wall contactedge shouldbe
againstguide fence.
Finished piece
(2)
(3)
(4)
Table(B)
006362
Example:
In the case of cutting 52/38° type crown
molding for position (1) in Fig. A:
• Tilt and secure bevel angle setting to
33.9° LEFT.
• Adjust and secure miter angle setting to
31.6° RIGHT.
• Lay crown molding with its broad back
(hidden) surface down on the turn base
with its CEILING CONTACT EDGE
against the guide fence on the saw.
• The finished piece to be used will
always be on the LEFT side of the
blade after the cut has been made.
7. Cutting aluminum extrusion
Fig.37
When securing aluminum extrusions, use spacer
blocks or pieces of scrap as shown in the figure to
prevent deformation of the aluminum. Use a
cutting lubricant when cutting the aluminum
extrusion to prevent build-up of the aluminum
material on the blade.
WARNING:
• Never attempt to cut thick or round aluminum
extrusions. Thick or round aluminum extrusions
can be difficult to secure and may work loose
during the cutting operation which may result in
loss of control and serious personal injury.
8. Wood facing
Use of wood facing helps to assure splinter-free
cuts in workpieces. Attach a wood facing to the
guide fence using the holes in the guide fence.
See the figure concerning the dimensions for a
suggested wood facing.
15mm Over 450 mm
62mm-65mm
18 mm
45mm 103mm 65mm103mm
11
014279
CAUTION:
• Use straight wood of even thickness as the wood
facing.
WARNING:
• Use screws to attach the wood facing to the
guide fence. The screws should be installed
so that the screw heads are below the surface
of the wood facing so that they will not
interfere with the positioning of the material
being cut. Misalignment of the material being cut
can case unexpected movement during the cutting
operation which may result in a loss of control and
serious personal injury.
NOTICE:
• When the wood facing is attached, do not turn the
turn base with the handle lowered. The blade
and/or the wood facing will be damaged.
9. Groove cutting
Fig.38
A dado type cut can be made by proceeding as
follows:
Adjust the lower limit position of the blade using
the adjusting screw and the stopper arm to limit
the cutting depth of the blade. Refer to "Stopper
arm" section described previously.
After adjusting the lower limit position of the blade,
cut parallel grooves across the width of the
workpiece using a slide (push) cut as shown in the
figure. Then remove the workpiece material
between the grooves with a chisel.
WARNING:
• Do not attempt to perform this type of cut by
using a wider type blade or dado blade.
Attempting to make a groove cut with a wider
blade or dado blade could lead to unexpected
cutting results and kickback which may result in
serious personal injury
• Be sure to return the stopper arm to the
original position when performing other than
groove cutting. Attempting to make cuts with the
stopper arm in the incorrect position could lead to
unexpected cutting results and kickback which
may result in serious personal injury.
CAUTION:
• Be sure to return the stopper arm to the original
position when performing other than groove
cutting.
Carrying tool
Fig.39
Make sure that the tool is unplugged. Secure the blade
at 0° bevel angle and the turn base at the full right miter
angle position. Secure the slide poles so that the lower
slide pole is locked in the position of the carriage fully
pulled to operator and the upper poles are locked in the
1. Holes

19
position of the carriage fully pushed forward to the guide
fence (refer to the section titled "Slide lock adjustment
".) Lower the handle fully and lock it in the lowered
position by pushing in the stopper pin.
Wind the power supply cord using the cord rests.
WARNING:
• Stopper pin is only for carrying and storage
purposes and should never be used for any
cutting operations. The use of the stopper pin for
cutting operations may cause unexpected
movement of the saw blade resulting in kickback
and serious personal injury.
Carry the tool by holding both sides of the tool base as
shown in the figure. If you remove the holders, dust bag,
etc., you can carry the tool more easily.
CAUTION:
• Always secure all moving portions before carrying
the tool. If portions of the tool move or slide while
being carried loss of control or balance may occur
resulting in personal injury.
MAINTENANCE
WARNING:
• Always be sure that the tool is switched off
and unplugged before attempting to perform
inspection or maintenance. Failure to unplug
and switch off the tool may result in accidental
start up of the tool which may result in serious
personal injury.
• Always be sure that the blade is sharp and clean
for the best and safest performance.
Attempting a
cut with a dull and /or dirty blade may cause kickback
and result in a serious personal injury.
NOTICE:
• Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
Adjusting the cutting angle
This tool is carefully adjusted and aligned at the factory,
but rough handling may have affected the alignment. If
your tool is not aligned properly, perform the following:
1. Miter angle
Fig.40
Push the carriage toward the guide fence and
tighten the locking screw to secure the carriage.
Loosen the grip which secures the turn base. Turn
the turn base so that the pointer points to 0° on the
miter scale. Then turn the turn base slightly
clockwise and counterclockwise to seat the turn
base in the 0° miter notch. (Leave as it is if the
pointer does not point to 0°.) Loosen the hex
sockets bolts securing the guide fence using the
socket wrench.
Fig.41
Lower the handle fully and lock it in the lowered
position by pushing in the stopper pin. Square the
side of the blade with the face of the guide fence
using a triangular rule, try-square, etc. Then
securely tighten the hex socket bolts on the guide
fence in order starting from the right side.
Fig.42
Make sure that the pointer points to 0° on the miter
scale. If the pointer does not point to 0°, loosen
the screw which secures the pointer and adjust the
pointer so that it will point to 0°.
2. Bevel angle
(1) 0° bevel angle
Fig.43
Push the carriage toward the guide fence
and tighten the locking screw to secure the
carriage. Lower the handle fully and lock it in
the lowered position by pushing in the
stopper pin. Loosen the lever at the rear of
the tool.
Fig.44
Turn the hex bolt on the right side of the arm
two or three revolutions counterclockwise to
tilt the blade to the right.
Fig.45
Carefully square the side of the blade with
the top surface of the turn base using the
triangular rule, try-square, etc. by turning the
hex bolt on the right side of the arm
clockwise. Then tighten the lever securely.
Fig.46
Make sure that the pointer on the arm point
to 0° on the bevel scale on the arm holder. If
they do not point to 0°, loosen the screw
which secure the pointer and adjust it so that
it will point to 0°.
(2) 45° bevel angle
Fig.47
Adjust the 45° bevel angle only after
performing 0° bevel angle adjustment. To
adjust left 45° bevel angle, loosen the lever
and tilt the blade to the left fully. Make sure
that the pointer on the arm points to 45° on
the bevel scale on the arm holder. If the
pointer does not point to 45°, turn the 45°
bevel angle adjusting bolt on the right side of
the arm holder until the pointer points to 45°.
To adjust the right 5° bevel angle, perform
the same procedure as that described above.

20
Replacing carbon brushes
Fig.48
Remove and check the carbon brushes regularly.
Replace when they wear down to 3 mm in length. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
Fig.49
Use a screwdriver to remove the brush holder caps.
Take out the worn carbon brushes, insert the new ones
and secure the brush holder caps.
After use
• After use, wipe off chips and dust adhering to the
tool with a cloth or the like. Keep the blade guard
clean according to the directions in the previously
covered section titled "Blade guard". Lubricate the
sliding portions with machine oil to prevent rust.
• When storing the tool, pull the carriage toward you
fully.
To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be
performed by Makita Authorized Service Centers,
always using Makita replacement parts.
OPTIONAL ACCESSORIES
WARNING:
• These Makita accessories or attachments are
recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments may result in serious
personal injury.
• Only use the Makita accessory or attachment
for its stated purpose. Misuse of an accessory or
attachment may result in serious personal injury.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Steel & Carbide-tipped saw blades
Miter saw blades Forsmooth and precisecutting invarious materials.
CombinationGeneral purposeblade forfastand smooth rip,
crosscuts and miters.
Crosscutting Forsmoother cross graincuts. Slices cleanly
againstthe grain.
Fine cross cutsForsand-free cuts cleanly againstthe grain.
Non-ferrous metals
miter saw blades
Formiters inaluminum, copper, brass, tubing,
and other non-ferrous metals.
006526
• Vertical vise
• Socket wrench with hex wrench on its other end
• Holder
• Dust bag
• Triangular rule
NOTE:
• Some items in the list may be included in the tool
package as standard accessories. They may differ
from country to country.
