Parts Breakdown LS1214
Page 1 of 5 2/8/2008

Parts Breakdown LS1214
Page 2 of 5 2/8/2008

Parts Breakdown LS1214
Fig # Part ID Part Name Quantity
1 265995-6 TAPPING SCREW 4X18, 4323K 2
2 416075-3 REAR COVER, LS1013 1
3 265995-6 TAPPING SCREW 4X18, 4323K 1
4 631237-4 CONTROLLER, LS1212 1
6 911373-5 P.H. SCREW M6X50, LS1013 4
7 153907-0 MOTOR HOUSING CPL., LS1214 1
8 181047-4 CARBON BRUSH SET 154,5402A 1
9 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
10 860629-2 NAME PLATE, LS1214 1
11 596156-0 FIELD ASS'Y 115V, LS1212 1
12 266059-9 T. SCREW, FLANGE 5X75,2414B 2
13 416264-0 BAFFLE PLATE, LS1212 1
14 211061-7 B. BEARING 6000LLB, 6222DWE 1
15 681642-5 INSULATION WASHER, LS1013 1
16 516736-6 ARMATURE ASS'Y 115V, LS1212 1
17 240001-8 FAN 80, LS1013F 1
18 911223-4 P.H. SCREW M5X16, 4301BV 2
19 285686-3 BEARING RETAINER 94, LS1013 1
20 211275-8 BALL BEARING 6003DDW, LS1013 1
21 961057-5 RETAINING RING S-17, 2711 1
22 231928-3 RING SPRING 8, LS1013 1
23 256633-1 PIN 6, LS1013 1
24 231240-1 COMP. SPRING 7, 2414B 1
25 961018-5 STOP RING E-5, LS1011 1
26 253804-1 F. WASHER 6, 6012HDW 1
27 257163-5 RING 6, LS1011 1
28 345419-9 LINK PLATE, LS1214 1
29 922331-6 H.S.H. BOLT M6X20, LS1013 1
30 253804-1 F. WASHER 6, 6012HDW 1
31 257163-5 RING 6, LS1011 1
32 316470-6 SPRING HOLDER, LS1211 1
33 233187-5 COMPRESSION SPRING 34, LS1212 1
47 411478-6 SWITCH BUTTON, LS1011 1
48 182910-4 HANDLE SET, LS1013 1
49 682505-8 CORD GUARD, 2711 1
50 664463-0 CORD (2X14X8 SJ), 2414B 1
51 687052-4 STRAIN RELIEF, HM1500B 1
52 265995-6 TAPPING SCREW 4X18, 4323K 2
53 414546-4 CAM, LS1011 1
54 416000-4 LOCK OFF LEVER, LS1040 1
56 231457-6 COMP. SPRING 3, HR2400 1
58 651923-1 SWITCH, LS1211 1
60 415999-0 SWITCH LEVER, LS1040 1
61 265995-6 TAPPING SCREW 4X18, 4323K 6
62 182910-4 HANDLE SET, LS1013 1
63 921467-8 HEX BOLT M8X45, LS1013 1
64 262003-4 RUBBER RING 6, LS1013 1
65 911323-0 P.H. SCREW M6X16, LS1211 1
66 421562-9 GRIP, LS1013 1
67 344420-1 GRIP HOLDER, LS1013 1
68 911323-0 P.H. SCREW M6X16, LS1211 1
69 911114-9 P.H. SCREW M4X10, 2012 1
70 419277-0 DUST NOZZLE, LS1013 1
70 416133-5 DUST NOZZLE, LS1013 1
71 213460-9 O RING 35, HM1500 1
72 911113-1 P.H. SCREW M4X10, 4301BV 1
73 265717-4 SCREW M6X43, LS1211 1
74 262001-8 RING 5, 6906 1
75 317176-9 STOPPER ARM, LS1212 1
76 344045-1 STOPPER ARM PLATE, LS1211 1
Page 3 of 5 2/8/2008

Parts Breakdown LS1214
77 819064-1 MAKITA MARK, HM1100C 1
77 819215-6 MAKITA LOGO LABEL, LS1214L 1
78 183896-5 BLADE CASE, LS1214 1
78 188379-0 N/A 1
79 345611-7 GUARD PLATE, LS1214L 1
79 345415-7 GUARD PLATE, LS1214 1
80 421916-0 GUARD, LS1013L 1
80 423332-2 GUARD, LS1214 1
81 211031-6 BALL BEARING 608LLB, HR2400 1
82 961054-1 RETAINING RING S-14, 6302 1
83 226750-1 SPIRAL BEVEL GEAR 35, LS1212 1
84 262074-1 RUBBER RING 20, LS1013 1
85 267035-6 F. WASHER 14, 6805BV 1
86 213675-8 O RING 54, LS1214 1
87 316473-0 HOUSING W/O BEARING, LS1211 1
88 254202-2 KEY 4, 9924DB 1
89 322989-5 SPINDLE, LS1212 1
90 211278-2 BALL BEARING 6203DDW, 5077B (T2) 1
91 285828-9 BEARING RETAINER 66, LS1211 1
92 257022-3 RING 16, LS1013 1
93 911223-4 P.H. SCREW M5X16, 4301BV 2
94 224333-1 FLANGE 53, LS1040 1
95 257060-5 RING 15.88,LS1013 1
96 224333-1 FLANGE 53, LS1040 1
97 265405-3 H.F.H. BOLT M10X20, LS1211 1
98 344473-0 CENTER PLATE, LS1212 1
99 344038-8 CENTER COVER, LS1211 1
100 265324-3 H.F.H. BOLT M8X12, LS1030 1
101 265008-3 SCREW M5, LS1011 1
102 231613-8 T. SPRING 45, LS1211 1
103 450131-9 SAFETY COVER, LS1214F 1
103 418614-5 SAFETY COVER, LS1214 1
104 253977-0 F. WASHER 6, LS1011 1
105 911213-7 P.H. SCREW M5X12, LS1040 1
106 331428-4 PIPE, LS1211 1
107 252105-4 HEX LOCK NUT M8-13, HM1800 1
108 941201-0 F. WASHER 8, 5037NB 1
109 153908-8 ARM CPL., LS1214 1
109 154780-1 ARM CPL., LS1214L 1
110 322988-7 STOPPER PIN, LS1220 1
111 213011-8 O RING 7, HR2511 1
112 687095-6 STRAIN RELIEF, LS1220 1
113 266026-4 TAPPING SCREW 4X12,9046 1
115 251961-9 H.S.H. SCREW M6X10, LS1040 1
116 265371-4 HEX BOLT M8X30, LS1011 2
117 265412-6 HEX. BOLT M8X20, LS1013 2
118 216003-6 STEEL BALL 10, 2401B, LS1013 2
119 345418-1 GUIDE PLATE, LS1013 1
120 231626-9 TORSION SPRING 28, LS1013 1
121 413067-3 INDICATION PLATE, LS1013 2
122 911114-9 P.H. SCREW M4X10, 2012 2
123 233168-9 COMPRESSION SPRING 5, LS1013 2
124 266131-7 HEX SOCKET HEAD BOLT M12X12, LS1013 2
125 151459-5 ARM HOLDER COMPLETE, LS1013 1
126 251662-9 H. BOLT M10X100, 2030N 1
127 911113-1 P.H. SCREW M4X10, 4301BV 1
128 416006-2 LEVER 100, LS1040 1
129 252144-4 HEX. NUT M10-17, LS1013 1
130 253024-7 F. WASHER 10, LS0714 1
131 231266-3 COMP. SPRING 5, LS711DWBEK 1
132 152542-1 SQUARE ROD COMPLETE, LS1013 1
Page 4 of 5 2/8/2008

Parts Breakdown LS1214
133 921356-7 HEX BOLT M6X35, LS1013 2
134 153832-5 TURN BASE CPLT., LS1013 1
135 152540-5 BEARING BOX B COMPLETE, LS1013 1
136 922451-6 H.S.H. BOLT M8X30, LS1013 2
137 253852-0 F. WASHER 8, LS1211 1
138 265442-7 HEX BOLT M8X40, LS1013 1
139 415209-5 KERF BOARD, LS1013,LS1013F 2
140 266026-4 TAPPING SCREW 4X12,9046 4
141 911108-4 P.H. SCREW M4X8, LS1013 1
142 252014-7 HEX LOCK NUT M6-10, LS1040 1
143 344463-3 SUB FENCE PLATE, LS1013 1
144 153892-7 SUB-FENCE CPL., LS1214 1
145 921451-3 HEX BOLT M8X30, LS1011 4
146 317757-9 GUIDE FENCE, LS1214 1
147 912357-6 C.S.H. SCREW M6X35, LS1013 1
148 253715-0 F. WASHER 6, NHP1310 1
149 251887-5 SCREW M6X10, LS1030 1
150 266026-4 TAPPING SCREW 4X12,9046 2
151 816326-8 MITER SCALE PLATE, LS1013 1
152 266132-5 SCREW M8X320, LS1013 1
153 931402-8 HEX NUT M8, 5037NB 1
154 271314-6 KNOB 40, LS1212 1
155 941201-0 F. WASHER 8, 5037NB 1
156 152541-3 KNOB 48 COMPLETE, LS1013 1
158 331491-7 PIPE 9-200, LS1013 1
159 421563-7 CAP 10, LS1013 1
160 322924-3 COIL SPRING, LS1013 1
161 322909-9 LOCK PIN, LS1013 1
162 253804-1 F. WASHER 6, 6012HDW 1
163 231307-5 COMP. SPRING 6, LS1013 1
164 961018-5 STOP RING E-5, LS1011 1
165 316899-6 PIN HOLDER, LS1013 1
166 266034-5 TAPPING SCREW 4X16, 9524NB 2
167 344411-2 SLIDE STOPPER, LS1013 1
168 251267-5 P.H. SCREW M6, LS1013 1
169 256196-7 PIN 5, LS1013 1
170 331493-3 TURN STOPPER, LS1013 1
171 344412-0 STOPPER HOLDER, LS1013 1
172 266034-5 TAPPING SCREW 4X16, 9524NB 1
173 266026-4 TAPPING SCREW 4X12,9046 1
174 816128-2 POINTER, LS1013 1
175 344477-2 SLIDE PLATE, LS1013 2
176 266034-5 TAPPING SCREW 4X16, 9524NB 1
177 232075-3 LEAF SPRING, LS1011 1
178 251887-5 SCREW M6X10, LS1030 2
179 153833-3 BASE CPL., LS1013 1
180 286212-1 CAP 20, LS1011 4
1,001 122523-9 DUST BAG, LS1040 1
1,002 122540-9 VISE ASS'Y, LS1212 1
1,003 153898-5 SUB-FENCE R CPL., LS1214 1
1,004 411478-6 SWITCH BUTTON, LS1011 2
1,005 762001-3 TRIANGLE RULE, LS1011 1
1,006 251887-5 SCREW M6X10, LS1030 2
1,007 322932-4 HOLDER 255, LS1013 2
1,008 A-85472 T.C.T. SAW BLADE 60T 1
1,008 A-94443 12X70T Q.MAKBLADE,LS1214F 1
1,009 782212-4 SOCKET WRENCH 13, LS1011 1
5,003 941202-8 F. WASHER 8, 5037NB 4
5,004 810151-9 N/A 1
Page 5 of 5 2/8/2008
