Makita DUN500W User manual

DUN500W
DUN600L
EN Cordless Pole Hedge Trimmer INSTRUCTION MANUAL 9
ZHCN 充电式高枝绿篱机 使用说明书 21
ID Alat Pemotong Tanaman
Pagar Tanpa Kabel PETUNJUK PENGGUNAAN 34
VI Máy Cắt Tỉa Hàng Rào Cầm
Tay Hoạt Động Bằng Pin TÀI LIỆU HƯỚNG DẪN 47
TH   60

DUN600L
DUN500W
6
7
8
9
3
4
5
1
14
4
5
6
7
9
1
2
10 11
13 12
Fig.1
1 2
3
Fig.2
1
2
Fig.3
2

1
2
Fig.4
1
2
Fig.5
1
2
Fig.6
1
2
Fig.7
1
2
Fig.8
1
2
Fig.9
1
2
3
4
5
Fig.10
1
Fig.11
3

2
1
3
4
Fig.12
1
2
Fig.13
1
34
2
Fig.14
Fig.15
1
2
Fig.16
1
1
Fig.17
1
Fig.18
4

2
1
4
3
Fig.19
1
2
Fig.20
2
3
1
Fig.21
1
2
3
Fig.22
1
2
Fig.23
1
2
Fig.24
1
1
Fig.25
5

1
Fig.26
1
Fig.27
1
Fig.28
Fig.29
1
2
Fig.30
Fig.31
1
Fig.32
(1)
(2)
Fig.33
6

Fig.34
Fig.35
15 m
Fig.36
15 m
Fig.37
15 m
Fig.38
15 m
Fig.39
Fig.40
Fig.41
7

Fig.42
Fig.43
1
2
Fig.44
1
2
Fig.45
1
Fig.46
1
Fig.47
21
Fig.48
8

9ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: DUN500W DUN600L
Blade length 500 mm 600 mm
Strokes per minute 2,000 / 3,600 / 4,400 min-1
Cutting blade angle 115° (up 45°, down 70°) –
Overall length 2,115 mm 2,050 mm
Rated voltage D.C. 18 V
Net weight 3.9 - 4.3 kg 3.7 - 4.1 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
withoutnotice.
• Specicationsmaydi󰀨erfromcountrytocountry.
• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
Applicable battery cartridge and charger
Batterycartridge BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /
BL1840B / BL1850 / BL1850B / BL1860B
Charger DC18RC/DC18RD/DC18RE/DC18SD/DC18SE/DC18SF/
DC18SH
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof
residence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
Recommended battery adapter
Batteryadapter PDC01
• Thebatteryadapter(s)listedabovemaynotbeavailabledependingonyourregionofresidence.
• Beforeusingthebatteryadapter,readinstructionandcautionarymarkingsonthebatteryadapter.
Symbols
Thefollowingsshowthesymbolswhichmaybeused
fortheequipment.Besurethatyouunderstandtheir
meaningbeforeuse.
Readinstructionmanual.
Do not expose to moisture.
Wearahelmet,gogglesandearprotection.
Bewareofpinching.
Bewareofelectricallines,riskofelectrical
shock.
Keepdistanceatleast15m.
Ni-MH
Li-ion
OnlyforEUcountries
Donotdisposeofelectricequipmentor
batterypacktogetherwithhouseholdwaste
material!
InobservanceoftheEuropeanDirectives,
onWasteElectricandElectronic
EquipmentandBatteriesandAccumulators
andWasteBatteriesandAccumulators
andtheirimplementationinaccordance
withnationallaws,electricequipmentand
batteriesandbatterypack(s)thathave
reachedtheendoftheirlifemustbecol-
lectedseparatelyandreturnedtoanenvi-
ronmentallycompatiblerecyclingfacility.
Intended use
Thetoolisintendedfortrimminghedges.

10 ENGLISH
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool.Failuretofollowallinstructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm“powertool”inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless)powertool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
darkareasinviteaccidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust.Powertoolscreatesparks
whichmayignitethedustorfumes.
3. Keep children and bystanders away while
operating a power tool.Distractionscancause
youtolosecontrol.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduceriskofelectricshock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.Thereisanincreasedriskofelec-
tricshockifyourbodyisearthedorgrounded.
3. Do not expose power tools to rain or wet con-
ditions.Waterenteringapowertoolwillincrease
theriskofelectricshock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts.Damagedorentangledcords
increasetheriskofelectricshock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use.Useof
acordsuitableforoutdoorusereducestheriskof
electricshock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.UseofanRCDreduces
theriskofelectricshock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However,usersofpacemakersandothersimilar
medicaldevicesshouldcontactthemakeroftheir
deviceand/ordoctorforadvicebeforeoperating
this power tool.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication.Amomentofinattentionwhileoperating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection.Protectiveequipmentsuch
asadustmask,non-skidsafetyshoes,hardhator
hearingprotectionusedforappropriateconditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the o󰀨-position before connecting
to power source and/or battery pack, picking
up or carrying the tool.Carryingpowertoolswith
yourngerontheswitchorenergisingpowertools
thathavetheswitchoninvitesaccidents.
4. Remove any adjusting key or wrench before
turning the power tool on.Awrenchorakeyleft
attachedtoarotatingpartofthepowertoolmay
resultinpersonalinjury.
5. Do not overreach. Keep proper footing and
balance at all times.Thisenablesbettercontrol
ofthepowertoolinunexpectedsituations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
longhaircanbecaughtinmovingparts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.Useof
dustcollectioncanreducedust-relatedhazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.Acarelessaction
cancausesevereinjurywithinafractionofa
second.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.

11 ENGLISH
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application.Thecorrect
powertoolwilldothejobbetterandsaferatthe
rateforwhichitwasdesigned.
2. Do not use the power tool if the switch does
not turn it on and o󰀨.Anypowertoolthatcannot
becontrolledwiththeswitchisdangerousand
must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools.Suchpreventivesafetymeasuresreduce
theriskofstartingthepowertoolaccidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool.Powertoolsaredangerousinthe
handsofuntrainedusers.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may a󰀨ect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Manyaccidentsarecausedbypoorlymaintained
power tools.
6. Keep cutting tools sharp and clean.Properly
maintainedcuttingtoolswithsharpcuttingedges
arelesslikelytobindandareeasiertocontrol.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed.Useofthepowertool
foroperationsdi󰀨erentfromthoseintendedcould
resultinahazardoussituation.
8. Keep handles and grasping surfaces dry,
clean and free from oil and grease.Slippery
handlesandgraspingsurfacesdonotallowfor
safehandlingandcontrolofthetoolinunexpected
situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled.Theentangle-
mentofclothworkglovesinthemovingpartsmay
resultinpersonalinjury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer.Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskofre
whenusedwithanotherbatterypack.
2. Use power tools only with specically desig-
nated battery packs.Useofanyotherbattery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another.Shortingthebatterytermi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
mayexhibitunpredictablebehaviourresultingin
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
peratureabove130°Cmaycauseexplosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions.Chargingimproperlyorattemperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts.Thiswillensurethatthesafetyofthepower
tool is maintained.
2. Never service damaged battery packs.Service
ofbatterypacksshouldonlybeperformedbythe
manufacturerorauthorizedserviceproviders.
3. Follow instruction for lubricating and chang-
ing accessories.
Cordless Pole Hedge Trimmer
Safety Warnings
1. Keep all parts of the body away from the blade.
Do not remove cut material or hold material
to be cut when blades are moving. Blades
continuetomoveaftertheswitchisturnedo󰀨.A
momentofinattentionwhileoperatingthehedge
trimmermayresultinseriouspersonalinjury.
2. Carry the hedge trimmer by the handle with the
blade stopped and taking care not to operate
any power switch.Propercarryingofthehedge
trimmerwilldecreasetheriskofinadvertentstart-
ingandresultantpersonalinjuryfromtheblades.
3. When transporting or storing the hedge trim-
mer, always t the blade cover.Properhandling
ofthehedgetrimmerwilldecreasetheriskof
personalinjuryfromtheblades.
4. When clearing jammed material or servicing
the unit, make sure all power switches are o󰀨
and the battery pack is removed or discon-
nected.Unexpectedactuationofthehedgetrim-
merwhileclearingjammedmaterialorservicing
mayresultinseriouspersonalinjury.
5. Hold the hedge trimmer by insulated gripping
surfaces only, because the blade may contact
hidden wiring.Bladescontactinga“live”wire
maymakeexposedmetalpartsofthehedgetrim-
mer“live”andcouldgivetheoperatoranelectric
shock.
6. Keep all power cords and cables away from
cutting area.Powercordsorcablesmaybehid-
deninhedgesorbushesandcanbeaccidentally
cutbytheblade.
7. Do not use the hedge trimmer in bad weather
conditions, especially when there is a risk of
lightning.Thisdecreasestheriskofbeingstruck
bylightning.

12 ENGLISH
8. To reduce the risk of electrocution, never use
the pole hedge trimmer near any electrical
power lines.Contactwithorusenearpowerlines
maycauseseriousinjuryorelectricshockresult-
ing in death.
9. Always use two hands when operating the pole
hedge trimmer. Hold the pole hedge trimmer with
bothhandstoavoidlossofcontrol.
10. Always use head protection when operating
the pole hedge trimmer overhead.Fallingdebris
canresultinseriouspersonalinjury.
Additional Safety Instructions
Preparation
1. THIS HEDGE TRIMMER CAN CAUSE SERIOUS
INJURIES. Read the instructions carefully
for the correct handling, preparation, main-
tenance, starting and stopping of the tool.
Become familiar with all controls and the
proper use of the tool.
2. Check the hedges and bushes for foreign
objects, such as wire fences or hidden wiring
before operating the tool.
3. The tool must not be used by children or
young persons under 18 years of age. Young
personsover16yearsofagemaybeexempted
fromthisrestrictioniftheyareundergoingtraining
underthesupervisionofanexpert.
4. In the event of an emergency, switch o󰀨
the tool and remove the battery cartridge
immediately.
5. DANGER - Keep hands away from blade.
Contactwithbladewillresultinseriouspersonal
injury.
6. Only use with handle and guard properly
assembled to the tool.Theuseofthetool
withouttheproperguardorhandleprovidedmay
resultinseriouspersonalinjury.
7. First-time users should have an experienced
user show them how to use the tool.
8. Before operation, examine the work area for
wire fences, stones, or other solid objects.
They can damage the blades.
9. Use the tool only if you are in good physical
condition.Ifyouaretired,yourattentionwillbe
reduced.Beespeciallycarefulattheendofa
workingday.Performallworkcalmlyandcarefully.
Theuserisresponsibleforalldamagestothird
parties.
10. Before starting work, check to make sure that
the tool is in good and safe working order.
Ensure guards are tted properly. The tool
must not be used unless fully assembled.
11. Avoid dangerous environment. Don't use the
tool in damp or wet locations or expose it to
rain. Water entering the tool will increase the
risk of electric shock.
Personal protective equipment
1. Work gloves of stout leather are part of the
basic equipment of the tool and must always
be worn when working with it. Also wear
sturdy shoes with anti-skid soles.
2. Wear ear protection such as ear mu󰀨s to pre-
vent hearing loss.
3. Wear protective goggles, safety helmet and
protective gloves to protect yourself from
ying debris or falling objects.
4. When touching blades or adjusting the blade
angle, wear protective gloves.Bladescancut
barehandsseverely.
Operation
1. Always use two hands to operate the tool tted
with two handles.Usingonehandcouldcause
lossofcontrolandresultinseriouspersonalinjury.
2. While operating the tool, always ensure that
the operating position is safe and secure.
Overreaching with the tool, particularly from
a ladder, is extremely dangerous. Do not work
from anything wobbly or inrm.
3. Do not simultaneously wear multiple belt har-
nesses and/or shoulder harnesses when oper-
ating the tool.
4. During operation, keep bystanders or animals
at least 15 m away from the tool. Stop the tool
as soon as someone approaches.
5. If cutting tool strikes any object or the tool
starts making unusual noise or vibration,
switch o󰀨 the tool and remove the battery car-
tridge immediately and allow the tool to stop.
And then take the following steps:
• inspect for damage
• check for, and tighten, any loose parts
• have any damaged parts replaced or
repaired with genuine spare parts.
6. Only use the tool for its intended purpose. Do
not use the tool for any other purpose.
7. Switch o󰀨 the tool and remove the battery
cartridge before:
• cleaning or when clearing a blockage,
• checking, carrying out maintenance or
working on the tool,
• adjusting the working position of the
shear blades,
• leaving the tool unattended.
8. Ensure that the tool is correctly located in a
designated working position before starting
the tool.
9. Do not operate the tool with a damaged or
excessively worn shear blades.
10. Always ensure that all handles and guards
are tted when using the tool. Never attempt
to use an incomplete tool or one tted with an
unauthorized modication.
11. Always be aware of your surroundings and
stay alert for possible hazards of which you
may not be aware due to the noise of the tool.
12. Be careful not to accidentally contact a metal
fence or other hard objects during operation.
Thebladewillbreakandmaycauseseriousinjury.
13. Avoid unintentional starting. Do not carry the
tool when the battery cartridge is installed
and with nger on the switch. Make sure that
the switch is o󰀨 when installing the battery
cartridge.
14. Do not grasp the exposed cutting blades or
cutting edges when picking up or holding the
tool.

13 ENGLISH
15. Do not force the tool.Itwilldothejobbetterand
withlesslikelihoodofariskofinjuryattheratefor
whichitwasdesigned.
16. Do not use the tool in the rain or in wet or
very damp conditions.Theelectricmotorisnot
waterproof.
17. Hold the tool rmly when using the tool.
18. Do not operate the tool at no-load
unnecessarily.
19. Before checking the shear blades, taking care
of faults, or removing foreign objects caught
in the shear blades, always switch o󰀨 the tool
and remove the battery cartridge.
20. Never point the shear blades to yourself or
others.
21. If the blades stop moving due to the stuck of
foreign objects between the blades during
operation, switch o󰀨 the tool and remove the
battery cartridge, and then remove the foreign
objects using tools such as pliers. Removing
theforeignobjectsbyhandmaycauseaninjury
forthereasonthatthebladesmaymoveinreac-
tiontoremovingtheforeignobjects.
Maintenance and storage
1. When the tool is stopped for servicing, inspec-
tion or storage, switch o󰀨 the tool and remove
the battery cartridge, and make sure all mov-
ing parts have come to a stop. Allow the tool
to cool before making any inspections, adjust-
ment, etc.
2. Always allow the tool to cool down before
storing.
3. When not in use, attach the blade cover to the
tool and store the tool indoors in dry, and high
locked-up place, out of reach of children.
4. Maintain the tool with care. Keep cutting edge
sharp and clean for best performance and to
reduce the risk of injury. Follow instructions
for lubricating and changing accessories.
Keep handles dry, clean, and free from oil and
grease.
5. Check damaged parts. Before further use of
the tool, any part which is damaged should be
carefully checked to determine that it will oper-
ate properly and perform its intended function.
Check for alignment of moving parts, binding
of moving parts, breakage of parts, mounting
and any other condition that may a󰀨ect its
operation.Aguardorotherpartthatisdamaged
shouldbeproperlyrepairedorreplacedbyyour
authorizedservicecenter.
6. Use genuine spare parts only.
7. When moving the tool to another location,
including during work, always remove the
battery cartridge and put the blade cover on
the shear blades. Never carry or transport the
tool with the blades running. Never grasp the
blades with your hands.
8. Clean the tool and especially the shear blades
after use, and before putting the tool into stor-
age for extended periods. Lightly oil the shear
blades and put on the blade cover.
9. Do not dispose of the battery(ies) in a re. The
cell may explode. Check with local codes for
possible special disposal instructions.
10. Do not open or mutilate the battery(ies).
Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be
toxic if swallowed.
11. Do not charge battery in rain, or in wet
locations.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper the battery
cartridge.Itmayresultinare,excessiveheat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge.Suchconductmayresultina
re,excessiveheat,orexplosion.
9. Do not use a damaged battery.

14 ENGLISH
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwardingagents,specialrequirementonpack-
aging and labeling must be observed.
Forpreparationoftheitembeingshipped,consult-
inganexpertforhazardousmaterialisrequired.
Pleasealsoobservepossiblymoredetailed
national regulations.
Tapeormasko󰀨opencontactsandpackupthe
batteryinsuchamannerthatitcannotmove
aroundinthepackaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge.Itmayresultinpoorperformanceor
breakdownofthetoolorbatterycartridge.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near high-voltage electri-
cal power lines.Itmayresultinamalfunctionor
breakdownofthetoolorbatterycartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Useofnon-genuineMakitabatteries,orbatteriesthat
havebeenaltered,mayresultinthebatterybursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).
PARTS DESCRIPTION
►Fig.1
1Head 2Frontgrip 3Hanger 4Lever
5Batterycartridge 6Rear grip 7Switchtrigger 8Slide sleeve
9Shear blades 10 Speedindicator 11 Powerlamp 12 Reverse button
13 Main power button 14 Handle ----
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge.Failuretoholdthetoolandthebattery
cartridgermlymaycausethemtoslipo󰀨yourhands
andresultindamagetothetoolandbatterycartridge
andapersonalinjury.
►Fig.2: 1.Redindicator2. Button 3.Batterycartridge
Toremovethebatterycartridge,slideitfromthetool
whileslidingthebuttononthefrontofthecartridge.

15 ENGLISH
Toinstallthebatterycartridge,alignthetongueonthe
batterycartridgewiththegrooveinthehousingandslip
itintoplace.Insertitallthewayuntilitlocksinplace
withalittleclick.Ifyoucanseetheredindicatoronthe
uppersideofthebutton,itisnotlockedcompletely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen.Ifnot,
itmayaccidentallyfalloutofthetool,causinginjuryto
youorsomeonearoundyou.
CAUTION: Do not install the battery cartridge
forcibly.Ifthecartridgedoesnotslideineasily,itis
notbeinginsertedcorrectly.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
►Fig.3: 1.Indicatorlamps2.Checkbutton
Pressthecheckbuttononthebatterycartridgetoindi-
catetheremainingbatterycapacity.Theindicatorlamps
lightupforafewseconds.
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
mayhave
malfunctioned.
NOTE:Dependingontheconditionsofuseandthe
ambienttemperature,theindicationmaydi󰀨erslightly
fromtheactualcapacity.
NOTE:Therst(farleft)indicatorlampwillblinkwhen
thebatteryprotectionsystemworks.
Tool / battery protection system
Thetoolisequippedwithatool/batteryprotectionsys-
tem.Thissystemautomaticallycutso󰀨powertothe
motortoextendtoolandbatterylife.Thetoolwillauto-
maticallystopduringoperationifthetoolorbatteryis
placedunderoneofthefollowingconditions:
Status Indicator lamps
On O󰀨 Blinking
Overload
Overheat
Over
discharge
Overload protection
Ifthetoolisoverloadedbyentangledbranchesorother
debris,theindicatorsfor“2”and“3”startblinkingand
thetoolautomaticallystops.
Inthissituation,turnthetoolo󰀨andstoptheapplication
thatcausedthetooltobecomeoverloaded.Thenturn
the tool on to restart.
NOTICE: Depending on the usage conditions,
the tool is automatically turned o󰀨 without any
indication if the tool is overloaded by entangled
branches or debris. In this case, switch o󰀨 the
tool and remove the battery cartridge, and then
remove entangled branches or debris using tools
such as pliers. After removing the branches or
debris, install the battery cartridge and turn on
the tool again.
Overheat protection for tool or
battery
Therearetwotypesofoverheating;tooloverheating
andbatteryoverheating.Whenthetooloverheating
occurs,allspeedindicatorsblink.Whenthebattery
overheatingoccurs,indicatorfor“1”blinks.
Iftheoverheatingoccurs,thetoolstopsautomatically.
Letthetooland/orbatterycooldownbeforeturningthe
tool on again.
Overdischarge protection
Whenthebatterycapacitybecomeslow,thetoolstops
automaticallyandindicatorfor“1”blinks.
Ifthetooldoesnotoperateevenwhentheswitchesare
operated,removethebatteryfromthetoolandcharge
thebattery.

16 ENGLISH
Power switch action
WARNING: For your safety, this tool is
equipped with lever which prevents the tool from
unintended starting. NEVER use the tool if it runs
when you simply pull the switch trigger without
pressing the lever. Return the tool to our autho-
rized service center for proper repairs BEFORE
further usage.
WARNING: NEVER tape down or defeat pur-
pose and function of lever.
WARNING: Before installing the battery
cartridge on the tool, always check to see that
the switch trigger and lever actuate properly
and return to the “OFF” position when released.
Operatingatoolwithaswitchthatdoesnotactuate
properlycanleadtolossofcontrolandseriousper-
sonalinjury.
CAUTION: Never put your nger on the
switch when carrying.Thetoolmaystartuninten-
tionallyandcauseinjury.
NOTICE: Do not pull the switch trigger hard
without pressing the lever. This can cause switch
breakage.
Pressthemainpowerbuttontoturnonthetool.The
powerlamplightsupwhenthetoolisturnedon.Toturn
o󰀨thetool,pressandholdthemainpowerbutton.The
powerlampgoeso󰀨whenthetoolisturnedo󰀨.
►Fig.4: 1.Powerlamp2. Main power button
NOTE:Thetoolisautomaticallyturnedo󰀨ifthetoolis
notoperatedforacertainperiod.
Topreventtheswitchtriggerfrombeingaccidentally
pulled,aleverisprovided.Tostartthetool,pullthe
switchtriggerwhilepressingthelever.Releasethe
switchtriggertostop.
►Fig.5: 1. Lever 2.Switchtrigger
Speed adjusting
Youcanadjustthetoolspeedbypressingthemain
powerbutton.Eachtimeyoupressthemainpower
button,thelevelofspeedchanges.
►Fig.6: 1.Speedindicator2. Main power button
Indicator Mode Stroke speed
High 4,400 min-1
Medium 3,600 min-1
Low 2,000 min-1
Reverse button for debris removal
WARNING: If the entangled branches or
debris cannot be removed by the reverse func-
tion, switch o󰀨 the tool and remove the battery
cartridge, and then remove the entangled
branches or debris using tools such as pliers.
Failuretoswitcho󰀨thetoolandremovethebat-
terycartridgemayresultinseriouspersonalinjury
fromaccidentalstart-up.Removingtheentangled
branchesordebrisbyhandmaycauseaninjury,
sincetheshearbladesmaymoveinreactionto
removing them.
Thistoolhasareversebuttontochangethedirection
ofshearbladesmovement.Itisonlyforremoving
branchesanddebrisentangledinthetool.
Toreversetheshearbladesmovement,pressthe
reverse button when the shear blades have stopped,
andthenpulltheswitchtriggerwhilepressingthelever.
Thepowerlampstartsblinking,andtheshearblades
moveinreversedirection.
Whenentangledbranchesanddebrisareremoved,
the tool returns to the regular movement and the power
lamp stops blinking and lights up.
►Fig.7: 1.Powerlamp2. Reverse button
NOTE:Iftheentangledbranchesordebriscannotbe
removed,releasetheswitchtrigger,thenpressthe
reversebutton,andthenpulltheswitchtriggeruntil
theyareremoved.
NOTE:Ifyoutapthereversebuttonwhiletheshear
bladesarestillmoving,thetoolcomestostopandto
bereadyforreversemovement.
Adjusting the cutting angle
CAUTION: Always be sure that the tool is
switched o󰀨 before folding or unfolding the head.
CAUTION: When folding the head for carrying
the tool or after using the tool, be sure to attach
the blade cover before folding the head.
CAUTION: When folding the head, be careful
not to pinch your ngers between the head and
the slide sleeve.
For DUN500W
Theangleoftheheadcanbeadjustedin6steps.To
changetheangleofthehead,followthestepsbelow.
1. Hold the head and the slide sleeve as shown in
thegure.
►Fig.8: 1. Head 2. Slide sleeve
2. Move the head while holding down the slide
sleeve, and then release the slide sleeve.
3. Movetheheadslightlyuntilitislockedwithaclick.
NOTE:Makesurethattheheadissecurelylocked
beforeoperatingthetool.

17 ENGLISH
Hex wrench storage
For DUN600L
Whennotinuse,storethehexwrenchasillustratedto
keepitfrombeinglost.
►Fig.9: 1. Handle 2.Hexwrench
ASSEMBLY
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before carrying out any work on the tool.
CAUTION: When replacing the shear blades,
always wear gloves so that your hands do not
directly contact the blades.
Installing the handle
For DUN600L
1. Attachtheupperandlowerclampsonthedamper.
2. Putthehandleontheupperclampandxitwith
bolts as illustrated.
►Fig.10: 1. Bolt 2. Handle 3.Upperclamp4. Damper
5.Lowerclamp
Installing or removing the shear
blades
CAUTION: Attach the blade cover before
removing or installing the shear blades.
NOTICE: When replacing the shear blades, do
not wipe o󰀨 grease from the gear and crank.
NOTICE:
For DUN500W
Do not install 600 mm shear blades to your tool.
If600mmshearbladesareinstalledtothetool,you
cannotfoldtheheadofthetool.
NOTE:
For DUN500W
Beforeinstallingorremovingtheshearblades,unfold
theheadofthetoolsothattheheadisstraighttothe
toolbody.
1. Placethetoolupsidedown,andthenremove6
bolts.
►Fig.11: 1. Bolt
2. Removethecover,gasket,plateA,andplateB.
►Fig.12: 1. Cover 2. Gasket 3.PlateA4.PlateB
NOTE:Thegasketorplatesmayremainonthecover.
3. Remove the rod and the bearing.
►Fig.13: 1. Rod 2. Bearing
NOTE:Therodorbearingmayremainonthecover.
4. Remove2bolts,2sleeves,andthefeltpad,and
then remove the shear blades.
►Fig.14: 1.Feltpad2. Bolt 3. Sleeve 4. Shear blades
NOTICE: Be careful not to lose the bolts.
5. Removethebladecover,andthenattachittothe
new shear blades.
►Fig.15
6. Adjustthecranksothat2holesarelinedupon
the alignment line.
►Fig.16: 1. Hole 2.Alignmentline
7. Aligntheprotrusionsontheshearbladesvertically
at the same position.
►Fig.17: 1.Protrusion
8. Attachthefeltpadtotheshearblades.
►Fig.18: 1.Feltpad
9. Insert the protrusion on the shear blades to the
holeontherod,thenalignthepositionofthefeltpad
withtheholesonthetool,andthenattachthesleeves.
►Fig.19: 1.Feltpad2.Protrusion3. Hole 4. Sleeve
NOTICE: Apply a small amount of grease to the
inner periphery of the hole of the rod.
NOTICE: Be careful not to lose the sleeves.
10. Aligntheholesonthesleevesandtheshear
blades with the holes on the tool, and then tighten 2
boltstoxtheshearblades.
►Fig.20: 1. Bolt 2. Hole
11. Attachthebearingandtherod.
►Fig.21: 1. Rod 2. Small hole 3. Bearing
NOTICE: Apply a small amount of grease to the
inner periphery of the small hole of the rod.
NOTICE: Make sure that the protrusion on the
shear blades ts in the small hole on the rod.
12. AttachplateB,plateA,andthegasket.
►Fig.22: 1. Gasket 2.PlateA3.PlateB
13. Aligntheholeintheplatewiththeprotrusionon
theshearbladessothattheprotrusiontsinthehole.
►Fig.23: 1.Protrusion2.Plate
14. Attachthecover,andthentighten6bolts.
►Fig.24: 1. Cover 2. Bolt
NOTICE: If the shear blades do not move
smoothly, the shear blades are not engaged with
the rods properly. Install the shear blades again.
NOTICE: If the parts other than the shear
blades such as the rods are worn out, ask Makita
Authorized Service Centers for parts replacement
or repairs.

18 ENGLISH
Installing or removing the chip
receiver
Optional accessory
CAUTION: When installing or removing the
chip receiver, always wear gloves so that your
hands do not directly contact the shear blades.
NOTICE: The blade cover cannot be installed if
the chip receiver is installed on the tool. Before
carrying or storing the tool, uninstall the chip
receiver, and then install the blade cover to avoid
blade exposure.
NOTICE: Be sure to remove the blade cover
before installing the chip receiver.
Thechipreceivergathersdiscardedleavesandmakes
clean-upafterwardmucheasier.Itcanbeinstalledon
eithersideofthetool.
Toinstallthechipreceiver,putandpressthechip
receiverontotheshearbladessothatthehookstinto
the grooves on the shear blades.
►Fig.25: 1. Hook
►Fig.26: 1. Hook
NOTICE: Make sure that the chip receiver does
not overlap the branch catcher.
►Fig.27: 1.Branchcatcher
Toremovethechipreceiver,presstheleversonboth
sides to release the hooks.
►Fig.28: 1. Lever
NOTICE: Never try to remove the chip receiver
by an excessive force with its hooks locked in the
grooves of the shear blades.
OPERATION
Attaching the shoulder harness
Optional accessory for DUN500W
CAUTION: Before operation, make sure that
the shoulder harness is properly attached to the
hanger on the tool.
NOTE:Usetheshoulderharnessattachedtothetool.
Beforeoperation,adjusttheshoulderharnessaccord-
ingtotheusersizetopreventfatigue.
1. Weartheshoulderharnessonyourshoulder.
►Fig.29
2. Clasp the hook on the shoulder harness to the
tool's hanger.
►Fig.30: 1. Hook 2. Hanger
3. Adjusttheshoulderharnesstoacomfortable
working position.
►Fig.31
Theshoulderharnessfeaturesameansofquick
release.
Simplysqueezethesidesofthebuckletoreleasethe
toolfromtheshoulderharness.
►Fig.32: 1.Buckle
Operating the tool
WARNING: Do not use the tool near any
electrical power lines.Contactingwithpowerlines
orusingthetoolnearpowerlinesmaycauseserious
injuryorelectricshockresultingindeath.
WARNING: Keep hands away from shear
blades.
WARNING: Be extremely careful to maintain
control of the tool at all times. Do not allow the
tool to be deected toward you or anyone in the
work vicinity.Failuretokeepcontrolofthetool
couldresultinseriousinjurytothebystanderandthe
operator.
CAUTION: Avoid operating the tool in very
hot weather as much as practicable. When operat-
ing the tool, be careful of your physical condition.
CAUTION: Be careful not to accidentally
contact a metal fence or other hard objects while
trimming.Theshearbladesmaybreakandcause
aninjury.
CAUTION: Be careful not to allow the shear
blades to contact the ground.Thetoolmayrecoil
andcauseaninjury.
CAUTION: Overreaching with a hedge trim-
mer, particularly from a ladder, is extremely
dangerous.Donotworkwhilestandingonanything
wobblyorinrm.
NOTICE: Do not attempt to cut branches thicker
than 10 mm in diameter with the tool.Cutbranches
to10cmlowerthanthecuttingheightusingbranch
cuttersbeforeusingthetool.
►Fig.33: (1) Cutting height (2)10cm
NOTICE: Do not cut down dead trees or similar
hard objects.Doingsomaydamagethetool.
NOTICE: Do not trim the grass or weeds while
using the shear blades.Theshearbladesmay
becometangledinthegrassorweeds.
Hold the tool with both hands.
For DUN500W
►Fig.34
For DUN600L
►Fig.35
Pulltheswitchtriggerwhilepressingthelever,andthen
movethetoolforward.
►Fig.36
Forbasicoperation,tilttheshearbladestowardthe
trimmingdirectionandmoveitcalmlyandslowlyatthe
speedrateof3to4secondspermeter.
►Fig.37

19 ENGLISH
Tocutahedgesideevenly,cutfromthebottomtotop.
►Fig.38
When trimming to make a round shape (trimming box-
woodorrhododendron,etc.),trimfromtheroottothe
topforabeautifulnish.
►Fig.39
Ifthechipreceiverisattachedtotheshearblades,it
gathersdiscardedleavesandmakesclean-upafter-
wardmucheasier.
►Fig.40
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
CAUTION: When inspecting or maintaining
the tool, always put the tool down.Assemblingor
adjustingthetoolinanuprightpositionmayresultin
seriousinjury.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
Cleaning the tool
Cleanthetoolbywipingo󰀨dustwithadryclothorone
dippedinsoapywaterandwrungout.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Shear blade maintenance
Beforetheoperationoronceperhourduringoperation,
applylow-viscosityoil(machineoil,orspray-typelubri-
catingoil)totheshearblades.
►Fig.41
Afteroperation,removedustfrombothsidesofthe
shearbladeswithawiredbrush,wipeito󰀨withacloth
andthenapplylow-viscosityoil(machineoil,orspray-
typelubricatingoil)totheshearblades.
►Fig.42
NOTICE: Do not wash the shear blades in water.
Doingsomaycauserustordamagetothetool.
NOTICE: Dirt and corrosion cause excessive
blade friction and shorten the operating time per
battery charge.
Storage
Attachthebladecovertotheshearbladessothatthe
bladesarenotexposed.Storethetooloutofthereach
ofchildren.Storethetoolinaplacenotexposedto
moisture or rain.
Grinding the shear blades
NOTICE: If the shear blades have considerably
deformed by grinding, replace the shear blades
with new ones.
1. Installthebatterycartridgetothetool.
2. Turnonandstartthetoolsothattheupperblade
andlowerbladearepositionedalternately.
►Fig.43
3. Turno󰀨thetoolandremovethebatterycartridge
fromthetool.
4. Removethescrew,andthenremovethebranch
catcher.
►Fig.44: 1.Screw2.Branchcatcher
5. Settheangleofaleto45°,andgrindtheupper
bladefrom3directionswiththele.
►Fig.45: (1)File(2) 45°
CAUTION: Before grinding the shear blades,
make sure that the tool is switched o󰀨 and the
battery cartridge is removed from the tool.
6. Placethetoolupsidedown,andthenremovethe
burrsfromtheshearbladeswiththedressingstone.
►Fig.46: 1. Dressing stone
7. Settheangleoftheleto45°,andgrindthelower
bladefrom3directionswiththele.
8. Return the tool to normal position, and then
removetheburrsfromtheshearbladeswiththedress-
ing stone.
9. Attachthebranchcatcherbytighteningthescrew.
Grease lubrication
Interval of lubrication:Every25operatinghours
1. Removetheboltfromtheholeforlubrication.
►Fig.47: 1. Bolt
2. Removethecapfromthegreasevessel.Alignthe
outletofthegreasevesselwiththeholeonthecover,
andthenpresstheoutletofthegreasevesselontothe
hole.
►Fig.48: 1. Grease vessel 2. Hole
3. Applythegreasetothetool(Approximately5gas
a guide).
4. Tightenthebolt.

20 ENGLISH
TROUBLESHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
donotattempttodismantlethetool.Instead,askMakitaAuthorizedServiceCenters,alwaysusingMakitareplace-
mentpartsforrepairs.
State of abnormality Probable cause (malfunction) Remedy
Motor does not run. Batterycartridgeisnotinstalled. Installthebatterycartridge.
Batteryproblem(undervoltage) Rechargethebattery.Ifrechargingisnote󰀨ective,
replacebattery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Motorstopsrunningafteralittleuse. Battery'schargelevelislow. Rechargethebattery.Ifrechargingisnote󰀨ective,
replacebattery.
Overheating. Stopusingoftooltoallowittocooldown.
TooldoesnotreachmaximumRPM. Batteryisinstalledimproperly. Installthebatterycartridgeasdescribedinthis
manual.
Batterypowerisdropping. Rechargethebattery.Ifrechargingisnote󰀨ective,
replacebattery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Shearbladesdonotmove:
stopthemachineimmediately!
Inappropriateangleofshearblades. Makesurethattheheadisproperlyxedinthe
operational angle.
Foreignobjectsarecaughtbetweenthe
shear blades.
1. Use the reverse button.
2.Switcho󰀨thetoolandremovethebatterycar-
tridge,andthenremovetheforeignobjectsusing
toolssuchaspliers.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Abnormalvibration:
stopthemachineimmediately!
Shear blades are broken, bent or worn. Replacetheshearblades.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Shearbladesandmotorcannotstop:
Removethebatteryimmediately!
Electricmalfunction. Removethebatteryandaskyourlocalauthorized
servicecenterforrepair.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessoriesorattachmentsmightpresentariskof
injurytopersons.Onlyuseaccessoryorattachment
foritsstatedpurpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Shearbladeassembly
• Chipreceiver
• Greasevessel
• Shoulderharness
• Makitagenuinebatteryandcharger
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
di󰀨erfromcountrytocountry.
