Makita XTR01 User manual

INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Cordless Trimmer
Recortadora Inalámbrica
XTR01
Read before use.
Lea antes de usar.
IMPORTANT: Read Before Using.
IMPORTANTE: Lea antes de usar.

2ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: XTR01
Collet chuck capacity 1/4" or 3/8"
No load speed 10,000 - 30,000/min
Overall length 226 mm (8-7/8")
Rated voltage D.C. 18 V
Standard battery cartridge BL1815N / BL1820B / BL1830 / BL1830B / BL1840B /
BL1850B / BL1860B
Net weight 1.8 - 2.1 kg (3.9 - 4.6 lbs)
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsandbatterycartridgemaydifferfromcountrytocountry.
• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided with this
power tool. Failure to follow all instructions listed below
mayresultinelectricshock,reand/orseriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.Thereisanincreasedriskofelec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a ground fault circuit inter-
rupter (GFCI) protected supply. Use of a GFCI
reduces the risk of electric shock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However, users of pacemakers and other similar
medical devices should contact the maker of their
device and/or doctor for advice before operating
this power tool.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication.Amomentofinattentionwhileoperating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on.Awrenchorakeyleft
attached to a rotating part of the power tool may
resultinpersonalinjury.

3ENGLISH
5. Do not overreach. Keep proper footing and
balance at all times.Thisenablesbettercontrol
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8.
Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.Acarelessactioncan
causesevereinjurywithinafractionofasecond.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application.Thecorrect
powertoolwilldothejobbetterandsaferatthe
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and off.Anypowertoolthatcannot
be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool. Power tools are dangerous in the
hands of untrained users.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
8.
Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled.Theentangle-
ment of cloth work gloves in the moving parts may
resultinpersonalinjury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer.Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskofre
when used with another battery pack.
2. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
may exhibit unpredictable behaviour resulting in
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
perature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions. Charging improperly or at temperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts.Thiswillensurethatthesafetyofthepower
tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
3. Follow instruction for lubricating and chang-
ing accessories.
4. Keep handles dry, clean and free from oil and
grease.
Cordless trimmer safety warnings
1. Hold power tool by insulated gripping surfaces,
because the cutter may contact hidden wiring.
Cutting a "live" wire may make exposed metal parts
of the power tool "live" and shock the operator.
2. Use clamps or another practical way to secure
and support the workpiece to a stable plat-
form. Holding the work by your hand or against
the body leaves it unstable and may lead to loss of
control.
3. Wear hearing protection during extended
period of operation.
4. Handle the trimmer bits very carefully.
5. Check the trimmer bit carefully for cracks or
damage before operation. Replace cracked or
damaged bit immediately.
6. Avoid cutting nails. Inspect for and remove all
nails from the workpiece before operation.
7. Hold the tool rmly.
8. Keep hands away from rotating parts.
9. Make sure the trimmer bit is not contacting the
workpiece before the switch is turned on.

4ENGLISH
10. Before using the tool on an actual workpiece,
let it run for a while. Watch for vibration or
wobbling that could indicate improperly
installed bit.
11. Be careful of the trimmer bit rotating direction
and the feed direction.
12. Do not leave the tool running. Operate the tool
only when hand-held.
13. Always switch off and wait for the trimmer bit
to come to a complete stop before removing
the tool from workpiece.
14. Do not touch the trimmer bit immediately after
operation; it may be extremely hot and could
burn your skin.
15. Do not smear the tool base carelessly with
thinner, gasoline, oil or the like. They may
cause cracks in the tool base.
16. Use trimmer bits of the correct shank diameter
suitable for the speed of the tool.
17. Some material contains chemicals which may
be toxic. Take caution to prevent dust inhala-
tion and skin contact. Follow material supplier
safety data.
18. Always use the correct dust mask/respirator
for the material and application you are work-
ing with.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Symbols
Thefollowingsshowthesymbolsusedfortool.
volts
direct current
no load speed
revolutions or reciprocation per minute
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
Tapeormaskoffopencontactsandpackupthe
battery in such a manner that it cannot move
around in the packaging.
11. Follow your local regulations relating to dis-
posal of battery.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causingres,personalinjuryanddamage.Itwill
also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).

5ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: Always switch off the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridgermlymaycausethemtoslipoffyourhands
and result in damage to the tool and battery cartridge
andapersonalinjury.
1
2
3
►1. Red indicator 2. Button 3. Battery cartridge
Toremovethebatterycartridge,slideitfromthetool
while sliding the button on the front of the cartridge.
Toinstallthebatterycartridge,alignthetongueonthe
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
itmayaccidentallyfalloutofthetool,causinginjuryto
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
1
2
►1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
catetheremainingbatterycapacity.Theindicatorlamps
light up for few seconds.
Indicator lamps Remaining
capacity
Lighted Off Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
ambient temperature, the indication may differ slightly
from the actual capacity.
Tool / battery protection system
Thetoolisequippedwithatool/batteryprotectionsys-
tem.Thissystemautomaticallycutsoffpowertothe
motortoextendtoolandbatterylife.Thetoolwillauto-
matically stop during operation if the tool or battery is
placed under one of the following conditions:
Overload protection
When the battery is operated in a manner that causes
it to draw an abnormally high current, the tool automat-
ically stops without any indication. In this situation, turn
the tool off and stop the application that caused the tool
tobecomeoverloaded.Thenturnthetoolontorestart.

6ENGLISH
Overheat protection
When the tool or battery is overheated, the tool stops
automatically and the lamp blinks. In this case, let the
tool and battery cool before turning the tool on again.
Overdischarge protection
When the battery capacity is not enough, the tool stops
automatically. In this case, remove the battery from the
tool and charge the battery.
Switch action
Toturnonthetool,pressthelock/unlockbutton.The
toolturnsintothestandbymode.Tostartthetool,press
thestart/stopbuttoninthestandbymode.Tostopthe
tool,pressthestart/stopbuttonagain.Thetoolturns
intothestandbymode.Toturnoffthetool,pressthe
lock/unlock button in the standby mode.
21
►1. Lock/unlock button 2. Start/stop button
NOTE: If the tool is left for 10 seconds without any
operation in the standby mode, the tool automatically
turns off and the lamp goes off.
NOTE: You can also stop and turn off the tool by
pressing the lock/unlock button while the tool is
operating.
Lighting up the front lamp
CAUTION: Do not look in the light or see the
source of light directly.
Toturnonthelamp,pressthelock/unlockbutton.To
turn off the lamp, press the lock/unlock button again.
NOTICE: When the tool is overheated, the lamp
ickers. Cool down the tool fully before operating
the tool again.
NOTE: Use a dry cloth to wipe the dirt off the lens of
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
Speed adjusting dial
Therotationspeedofthetoolcanbechangedbyturn-
ingthespeedadjustingdial.Thetablebelowshows
the number on the dial and the corresponding rotation
speed.
1
►1.Speedadjustingdial
Number Speed
110,000/min
215,000/min
320,000/min
425,000/min
530,000/min
NOTICE: If the tool is operated continuously at
low speed for a long time, the motor will get over-
loaded, resulting in tool malfunction.
NOTICE: When changing the speed dial from "5"
to "1", turn the dial counterclockwise. Do not turn
the dial clockwise forcibly.
Electronic function
Thetoolisequippedwiththeelectronicfunctionsfor
easy operation.
• Constantspeedcontrol
Thespeedcontrolfunctionprovidestheconstant
rotation speed regardless of load conditions.
• Softstart
Thesoft-startfunctionminimizesstart-upshock,
and makes the tool start smoothly.
Adjusting cutting depth
Toadjustthecuttingdepth,openthelocklever,then
movethetoolbaseupordownbyturningtheadjusting
screw.Aftertheadjustment,closethelockleverrmly.
2
1
►1. Lock lever 2.Adjustingscrew

7ENGLISH
NOTICE: If the tool is not secured after closing
the lock lever, tighten the hex nut, and then close
the lock lever.
1
►1. Hex nut
Adjusting cutting depth with the
plunge base
Optional accessory
1. Placethetoolontheatsurface.
2. Select the stopper screw by rotating the stopper
base.
1
2
►1. Stopper screw 2. Stopper base
3. Loosenthestopperpolexingnut,thenpullupthe
stopper pole while pressing the feed button.
2
3
1
►1. Stopper pole 2. Fixing nut 3. Feed button
4. Push down the tool until the tip of the trimmer bit
touchestheatsurface,andthenturnthexingleverto
secure the tool.
12
►1. Fixing lever 2.Trimmerbit
5. Press down the stopper pole while pressing the
feed button until it contacts the stopper screw.
2
3
1
►1. Stopper pole 2. Stopper screw 3. Feed button
6. Slide the depth pointer so that the pointer indi-
cates "0" on the scale.
1
►1. Depth pointer
7. Adjustthecuttingdepthbypullingupthestopper
pole while pressing the feed button.

8ENGLISH
1
2
►1. Stopper pole 2. Feed button
8. Toperformneadjustmentofthecuttingdepth,
turn the dial on the stopper pole so that it indicates "0".
1
►1. Dial
9. Turntheheadofthestopperpoletoobtainthe
desireddepth.Toincreasethedepth,turnthehead
counterclockwise.Todecreasethedepth,turnthehead
clockwise.
1
►1. Head of the stopper pole
10. Tightenthestopperpolexingnut.
1
►1. Fixing nut
11. Releasethexinglever.
1
►1. Fixing lever
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before carrying out any work on the tool.
Installing or removing trimmer bit
NOTICE: Do not tighten the collet nut without
inserting the bit.Thecolletconemaybreak.
Insert the trimmer bit all the way into the collet cone.
Press the shaft lock and tighten the collet nut with the
wrench or tighten the collet nut securely with the two
wrenches.Toremovethebit,followtheinstallation
procedure in reverse.

9ENGLISH
12
3
4
5
►1. Shaft lock 2. Loosen 3.Tighten4. Wrench
5. Collet nut
12
3
1
4
►1. Wrench 2. Loosen 3.Tighten4. Collet nut
NOTE:Theshaftlockmaynotreturntotheoriginal
position when you tighten the collet nut at the instal-
lationofthetrimmerbit.Theshaftlockreturnstothe
original position when you start the tool.
1
►1. Shaft lock
Installing or removing the trimmer
base
1. Open the lock lever of the trimmer base, then
insert the tool into the trimmer base aligning the groove
on the tool with the protrusion on the trimmer base.
1
►1. Lock lever
2. Close the lock lever.
3. Attachthedustnozzletothetrimmerbase,and
then tighten the thumb screw.
12
►1. Dust nozzle 2.Thumbscrew
Toremovethebase,followtheinstallationprocedure
in reverse.

10 ENGLISH
Installing or removing the offset
base
Optional accessory
1. Press the shaft lock, then loosen the collet nut.
1
2
3
►1. Collet nut 2. Shaft lock 3. Wrench
2. Remove the collet nut and the collet cone.
1
2
►1. Collet nut 2. Collet cone
3. Install the pulley on the tool by pressing the shaft
lock and tightening the pulley with the wrench.
1
2
3
►1. Wrench 2. Pulley 3. Shaft lock
4. Loosen the screws on the base plate, and then
remove the base plate.
1
►1. Base plate
5. Open the lock lever of the offset base, then insert
the tool into the offset base.
1
►1. Lock lever
6. Mount the belt to the pulley by rotating the belt
manually.
2
1
►1. Pulley 2. Belt
7. Close the lock lever.

11 ENGLISH
1
►1. Lock lever
8. Attachthebaseplatebytighteningthescrews.
1
►1. Base plate
9. Insert the collet cone and the trimmer bit into the
offset base, and then tighten the collet nut.
1
2
3
►1.Trimmerbit2. Collet nut 3. Collet cone
10. Insert the hex wrench into the hole of the offset
base, and then tighten the collet nut with the wrench.
1
2
3
►1. Collet nut 2. Wrench 3. Hex wrench
Toremovethebase,followtheinstallationprocedureinreverse.
NOTE: You can also mount the belt to the pulley with-
outremovingthebaseplateasshowninthegure.
2
1
►1. Pulley 2. Belt
Installing or removing the plunge base
Optional accessory
1.
Open the lock lever of the plunge base, then insert
the tool into the plunge base all the way aligning the
groove on the tool with the protrusion on the plunge base.
1
►1. Lock lever

12 ENGLISH
2. Close the lock lever.
Toremovethebase,followtheinstallationprocedure
in reverse.
Installing or removing the parallel
ruler on the plunge base
Optional accessory
Insert the guide bars into the holes in the plunge base,
andthentightenthewingbolts.Toremovetheruler,
follow the installation procedure in reverse.
1
2
►1. Wing bolt 2. Guide bar
Installing or removing the dust
nozzle on the plunge base
Insert the dust nozzle into the plunge base so that the
protrusiononthedustnozzletsinthenotchinthe
plunge base, and then tighten the thumb screw on the
dustnozzle.Toremovethenozzle,followtheinstalla-
tion procedure in reverse.
1
2
3
►1. Protrusion 2. Dust nozzle 3.Thumbscrew
OPERATION
Using the tool with the trimmer base
Set the tool base on the workpiece without the trimmer
bitmakinganycontact.Turnthetoolonandwaituntil
the bit attains full speed. Move the tool forward over
theworkpiecesurface.Keepthetoolbaseushwhile
moving the tool.
When cutting the edge, be sure to keep the workpiece
surface on the left side of the trimmer bit in the feed
direction.
NOTE: Before cutting on the actual workpiece, it is
recommendedtomakeasamplecut.Theproperfeed
speed depends on the bit size, the kind of workpiece,
and depth of cut. Moving the tool forward too fast may
cause a poor quality of cut, or damage to the bit or
motor. Moving the tool forward too slowly may burn
and mar the cut.
When using the trimmer shoe, the straight guide, or the
trimmer guide, be sure to keep it on the right side in the
feeddirection.Thiswillhelptokeepitushwiththeside
of the workpiece.

13 ENGLISH
1
3
2
►1.Trimmerbit2. Workpiece 3. Straight guide
NOTICE: Since excessive cutting may cause
overload of the motor or difculty in controlling
the tool, the depth of cut should not be more than
3 mm (1/8") at a pass when cutting grooves. When
you wish to cut grooves more than 3 mm (1/8") deep,
make several passes with progressively deeper bit
settings.
Using the straight guide
Optional accessory
1. Assemblethestraightguidewiththeboltandthe
wing nut.
2
1
►1. Bolt 2. Wing nut
2. Attachthestraightguidetothetrimmerbasewith
the clamp screw.
1
►1. Clamp screw
3. Loosen the wing nut on the straight guide and
adjustthedistancebetweenthebitandthestraight
guide.Atthedesireddistance,tightenthewingnut.
1
►1. Wing nut
4. Movethetoolwiththestraightguideushwiththe
side of the workpiece.
Ifthedistance(A)betweenthesideoftheworkpiece
and the cutting position is too wide for the straight
guide, or if the side of the workpiece is not straight, the
straight guide cannot be used.
Inthiscase,rmlyclampastraightboardtothework-
piece and use it as a guide against the trimmer base.
Feed the tool in the direction of the arrow.
A

14 ENGLISH
Using the straight guide for circular
work
For circular work, assemble the straight guide as shown
inthegures.Theminimumandmaximumradiusof
circles to be cut (distance between the center of circle
and the center of bit) are as follows:
• Minimum:70mm(2-3/4")
• Maximum:221mm(8-11/16")
For cutting circles between 70 mm (2-3/4") and 121
mm (4-3/4") in radius.
1
►1. Center hole
For cutting circles between 121 mm (4-3/4") and 221
mm (8-11/16") in radius.
1
►1. Center hole
NOTE: Circles between 172 mm (6-3/4") and 186 mm
(7-5/16") in radius cannot be cut using this guide.
Alignthecenterholeinthestraightguidewiththe
center of the circle to be cut. Drive a nail less than 6
mm (1/4") in diameter into the center hole to secure
the straight guide. Pivot the tool around the nail in the
clockwise direction.
2
1
►1. Nail 2. Center hole
Using the templet guide
Optional accessory
Thetempletguideallowsforrepetitivecutwithtemplet
patterns by using a templet.
1. Loosen the screws on the base plate, and then
remove the base plate from the trimmer base.
2. Place the templet guide on the base, and then
attach the base plate by tightening the screws.
1
2
►1. Base plate 2.Templetguide
3. Place the tool on the templet and move the tool
with the templet guide sliding along the side of the
templet.

15 ENGLISH
NOTE:Theactualcutsizeontheworkpieceisslightly
differentfromthetemplet.Thedifferenceisthedis-
tance (X) between the trimmer bit and the outside of
thetempletguide.Thedistance(X)canbecalculated
by using the following equation:
Distance (X) = (outside diameter of templet guide -
trimmer bit diameter) / 2
12
3
4
►1.Trimmerbit2.Templetguide3. Distance (X)
4. Outside diameter of templet guide
Using the trimmer guide
Optional accessory
Thetrimmerguideallowsfortrimmingcurvedsidelike
veneers for furniture by moving the guide roller along
the side of the workpiece.
1. Loosen the clamp screw, then install the trimmer
guide on the trimmer base, and then tighten the clamp
screw.
1
►1. Clamp screw
2. Loosentheclampscrewandadjustthedistance
between the trimmer bit and the trimmer guide by turn-
ingtheadjustingscrew(1mm(3/64")perturn).Atthe
desired distance, tighten the clamp screw to secure the
trimmer guide.
1
2
►1.Adjustingscrew2. Clamp screw
3. Move the tool with the guide roller riding the side
of the workpiece.
1
2
3
►1. Workpiece 2. Bit 3. Guide roller
z

16 ENGLISH
Using the tool with the offset base
Theoffsetbaseisconvenientforworkinatightarea
such as a corner.
Using the trimmer base with the
offset base plate and grip
Theoffsetbaseplatecanalsobeusedwithatrimmer
base and a grip attachment (optional accessory) for
more stability.
1. Loosen the screws on the base plate, then remove
the base plate from the offset base.
12
►1. Offset base plate 2.Trimmerbaseplate
2. Attachtheoffsetbaseplatetothetrimmerbaseby
tightening the screws.
3. Attachthegripattachmentandthebartypegripto
the offset base plate by tightening the screws.
2
1
►1. Bar type grip 2. Grip attachment
Theknobtypegripremovedfromtheplungebasecan
be installed on the offset base instead of the bar type
grip.
1
2
►1. Screw 2. Knob type grip
Using the tool with the plunge base
Alwaysholdthegripsrmlywithbothhandsduring
operation. Operate the tool in the same way as the
trimmer base.
Using the straight guide
Optional accessory
1. Install the straight guide to the guide holder by
tightening the wing nut. Insert the guide holder into the
holes in the plunge base, and then tighten the wing
bolts.

17 ENGLISH
1
23
4
►1. Wing bolt 2. Guide holder 3. Wing nut 4. Straight
guide
2. Loosen the wing nut on the straight guide and
adjustthedistancebetweenthebitandthestraight
guide.Atthedesireddistance,tightenthewingnut.
1
►1. Wing nut
3. Operate the tool in the same way as the straight
guide for the trimmer base.
Using the templet guide
Optional accessory
1. Loosen the screws on the base and remove them.
Place the templet guide on the base, and then tighten
the screws.
1
2
►1. Screw 2.Templetguide
2. Operate the tool in the same way as the templet
guide for the trimmer base.
Using the parallel ruler
Theparallelruleriseffectivelyusedforstraightcuts
whenchamferingorgrooving.Adjustthedistance
betweenthebitandtheparallelruler.Atthedesired
distance, tighten the wing bolts to secure the parallel
ruler. When cutting, move the tool with the parallel ruler
ushwiththesideoftheworkpiece.
Ifthedistance(A)betweenthesideoftheworkpiece
and the cutting position is too wide for the parallel ruler,
or if the side of the workpiece is not straight, the parallel
ruler cannot be used.
Inthiscase,rmlyclampastraightboardtothework-
piece and use it as a guide against the plunge base.
Feed the tool in the direction of the arrow.

18 ENGLISH
A
Changing knob type grip to bar type
grip
Toinstallthebartypegripontheplungebase,loosen
the screw of the knob type grip, then remove the knob
type grip, and then install the bar type grip by tightening
it.
12
3
►1. Knob type grip 2. Screw 3. Bar type grip
MAINTENANCE
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Straightandgrooveformingbits
• Edgeformingbits
• Laminatetrimmingbits
• Straightguideassembly
• Trimmerguideassembly
• Trimmerbaseassembly
• Plungebaseassembly
• Offsetbaseassembly
• Gripattachment
• Templetguide
• Colletcone1/4"
• Colletcone3/8"
• Wrench13
• Wrench22
• Makitagenuinebatteryandcharger
NOTE: Some items in the list may be included in the
toolpackageasstandardaccessories.Theymay
differ from country to country.

19 ENGLISH
MAKITA LIMITED ONE YEAR
WARRANTY
Warranty Policy
Every Makita tool is thoroughly inspected and tested
before leaving the factory. It is warranted to be free of
defects from workmanship and materials for the period
ofONEYEARfromthedateoforiginalpurchase.
Should any trouble develop during this one year period,
returntheCOMPLETEtool,freightprepaid,toone
ofMakita’sFactoryorAuthorizedServiceCenters.If
inspection shows the trouble is caused by defective
workmanship or material, Makita will repair (or at our
option, replace) without charge.
ThisWarrantydoesnotapplywhere:
• repairshavebeenmadeorattemptedbyothers:
•
repairs are required because of normal wear and tear:
• thetoolhasbeenabused,misusedorimproperly
maintained:
• alterationshavebeenmadetothetool.
INNOEVENTSHALLMAKITABELIABLEFORANY
INDIRECT,INCIDENTALORCONSEQUENTIAL
DAMAGESFROMTHESALEORUSEOFTHE
PRODUCT.THISDISCLAIMERAPPLIESBOTH
DURINGANDAFTERTHETERMOFTHIS
WARRANTY.
MAKITADISCLAIMSLIABILITYFORANYIMPLIED
WARRANTIES,INCLUDINGIMPLIEDWARRANTIES
OF"MERCHANTABILITY"AND"FITNESSFORA
SPECIFICPURPOSE,"AFTERTHEONEYEARTERM
OFTHISWARRANTY.
ThisWarrantygivesyouspeciclegalrights,andyou
may also have other rights which vary from state to
state. Some states do not allow the exclusion or lim-
itation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
Some states do not allow limitation on how long an
implied warranty lasts, so the above limitation may not
apply to you.

20 ESPAÑOL
ESPAÑOL (Instrucciones originales)
ESPECIFICACIONES
Modelo: XTR01
Capacidaddelapinzadesujeción 1/4″o3/8″
Velocidad sin carga 10 000 r/min - 30 000 r/min
Longitud total 226mm(8-7/8″)
Tensiónnominal 18 V c.c.
Batería estándar BL1815N / BL1820B / BL1830 / BL1830B / BL1840B /
BL1850B / BL1860B
Peso neto 1,8 kg - 2,1 kg (3,9 lbs - 4,6 lbs)
• Debidoanuestrocontinuoprogramadeinvestigaciónydesarrollo,lasespecicacionesaquíincluidasestán
sujetasacambiosinprevioaviso.
• Lasespecicacionesyelcartuchodebateríapuedenvariardepaísapaís.
• Elpesopuedevariarenfuncióndelosaccesorios,incluidoelcartuchodebatería.Enlatablasemuestrala
combinacióndepesomásligeroymáspesadoconformealprocedimiento01/2014deEPTA.
ADVERTENCIAS DE
SEGURIDAD
Advertencias generales de
seguridad para herramientas
eléctricas
ADVERTENCIA: Lea todas las advertencias
de seguridad, instrucciones, ilustraciones y espe-
cicaciones suministradas con esta herramienta
eléctrica. El no seguir todas las instrucciones indi-
cadasacontinuaciónpodríaocasionarunadescarga
eléctrica, incendio y/o lesiones graves.
Conserve todas las advertencias
e instrucciones como referencia
en el futuro.
En las advertencias, el término “herramienta eléctrica”
sereereasuherramientaeléctricadefuncionamiento
conconexiónalaredeléctrica(concableadoeléctrico)
o herramienta eléctrica de funcionamiento a batería
(inalámbrica).
Seguridad en el área de trabajo
1. Mantenga el área de trabajo limpia y bien ilu-
minada. Las áreas oscuras o desordenadas son
propensas a accidentes.
2. No utilice las herramientas eléctricas en
atmósferas explosivas, tal como en la presen-
cia de líquidos, gases o polvo inamables. Las
herramientas eléctricas crean chispas que pueden
prender fuego al polvo o los humos.
3. Mantenga a los niños y curiosos alejados
mientras utiliza una herramienta eléctrica. Las
distracciones le pueden hacer perder el control.
Seguridad eléctrica
1.
Las clavijas de conexión de las herramientas
eléctricas deberán encajar perfectamente en la
toma de corriente. No modique nunca la clavija
de conexión de ninguna forma. No utilice ninguna
clavija adaptadora con herramientas eléctricas
que tengan conexión a tierra (puesta a tierra). La
utilizacióndeclavijasnomodicadasyqueencajen
perfectamente en la toma de corriente reducirá el
riesgo de que se produzca una descarga eléctrica.
2. Evite tocar con el cuerpo supercies conecta-
das a tierra o puestas a tierra tales como tubos,
radiadores, cocinas y refrigeradores. Si su cuerpo
es puesto a tierra o conectado a tierra existirá un
mayor riesgo de que sufra una descarga eléctrica.
3. No exponga las herramientas eléctricas a la
lluvia ni a condiciones húmedas. La entrada de
agua en una herramienta eléctrica aumentará el
riesgo de que se produzca una descarga eléctrica.
4. No maltrate el cable. Nunca utilice el cable
para transportar, jalar o desconectar la herra-
mienta eléctrica. Mantenga el cable alejado del
calor, aceite, objetos cortantes o piezas móvi-
les. Los cables dañados o enredados aumentan
el riesgo de sufrir una descarga eléctrica.
5.
Cuando utilice una herramienta eléctrica en
exteriores, utilice un cable de extensión apro-
piado para uso en exteriores.Lautilizacióndeun
cable apropiado para uso en exteriores reducirá el
riesgo de que se produzca una descarga eléctrica.
6. Si no es posible evitar usar una herramienta
eléctrica en condiciones húmedas, utilice un
alimentador protegido con interruptor de cir-
cuito de falla a tierra (ICFT).ElusodeunICFT
reduce el riesgo de descarga eléctrica.
7.
Las herramientas eléctricas pueden producir cam-
pos electromagnéticos (CEM) que no son dañinos
para el usuario. Sin embargo, si los usuarios tienen
marcapasos y otros dispositivos médicos similares,
deberán consultar al fabricante de su dispositivo y/o a
su médico antes de operar esta herramienta eléctrica.
