K00135 STACKING KIT
Installation Instructions
1. The K00135 stacking kit is used for stacking a J-1300 or J-1800 on a J-1300 or J-1800 ice machine.
NOTE: The bin must be level before proceeding to step 2. Refer to sheet 2 for installation assembly view.
2. Installation of Ice Machines:
A. See install/use/care guide for uncrating and inspection of both ice machines.
B. Remove top cover and top-front support angle from lower ice machine.
C. Set ice machine carefully and squarely on bin.
D. Remove the two screws from top right-side frame angle above control box. Using the same two screws, install
control box shield over control box with insulated side down.
E. Remove backing paper from 1” square of double-sided tape and place tape in center of shim. Remove the
remaining backing paper and match slot in shim to hole in ice machine frame, as shown on sheet 2. Press in
place. Repeat for opposite side.
F. Lower ice machine must have electrical connections completed, at this time. Refer to ice machine install/use/care
guide for electrical hook-up.
G. Set top ice machine carefully and squarely on lower ice machine.
H. Remove front and side panels from both ice machines.
I. Bolt two ice machines together with 1/4-20 x 5/8” long bolt, lockwasher, and nut, provided in kit, one each side.
3. Installation of Ice Chute:
A. Remove angle A from top ice machine and set aside.
B. Set bottom mounting brackets of ice chute over angle B.
C. Reinstall angle A in slots of top mounting brackets and secure in place.
D. Check for free movement of both water curtains.
E. Refer to ice machine install/use/care guide for electrical and water hook-up and start-up procedure.
F. Reattach front and side panels.
G. Add eight sheet metal screws, included with kit, to side panels, four on each side of lower ice machine, where the
top and lower ice machines butt.
