Manitowoc K00344 User manual

K00344 WATER FILTER BIN BRACKET
Installation Instructions
1. Water filter bin bracket can be used to mount all configurations of the Arctic Pure water filter assemblies on either side or back of
any Manitowoc ice bin.
2. Remove foam tape from area where bracket is to be mounted, hang bracket, and install foam tape, provided with kit, over top of
bracket. Locate ice machine, per installation instructions.
3. Using screws provided, fasten water filter assembly to bracket.
4. Using two grommets, insert into holes in bracket.
Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 8014663
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Sheet 1 of 2
Web Site - www.manitowocice.com 07/02/03
AR-10000/20000 Water Filter AR-40000 Water
AR-40000 Water Filter
AR-10000/20000 Water Filter
Screw
Grommet
K00344001 Water Filter Bin Bracket

8014663
Sheet 2 of 2
07/02/03
AR-10000/20000 Water Filter and AR-Pre Filter
AR-40000 Water Filter and AR-Pre Filter
AR-Pre Filter with
AR-40000 Water Filter
AR-10000/20000 Water Filter
with AR-Pre Filter
Screw
Grommet
AR-40000 Water Filter
with AR-Pre Filter
K00344001 Water Filter Bin Bracket
