Manitowoc K00180 User manual

K00180
IB-0620/0820/1020
ON A CORNELIUS 44.38” WIDE ICE DISPENSER (ENDURO 300)
Installation Instructions
1. Set adapter on top of the dispenser. Be sure to position the adapter with the backside flange tight to the dispenser.
2. Install bracket under adapter and align front edge.
3. Using the slotted holes in the adapter as a template, drill four (4) 9/64” diameter holes at the bottom of the slots.
NOTE: Do not drill deeper than 1/4” past the sheet metal. Use a drill stop!
4. Fasten adapter to dispenser using the four (4) #8 screws supplied with the adapter kit.
5. Set the ice machine on top of the adapter. Align holes in ice machine front angle with the rivnuts on the adapter.
6. Secure the ice machine to the adapter with two (2) #8-32 thumbscrews supplied with the ice machine.
7. Set the front bin covers onto the dispenser. Set the left side cover down first and then the right side cover. The
covers will latch together at the center seam and also to the adapter along the back flange of the covers.
8. Rotate retaining arms into position, as shown for normal ice machine operation.
Manitowoc Ice, Inc.
2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 8005913
Web Site - www.manitowocice.com Rev. 04/12/02
#8-32 Thumbscrew
Two (2) Places
Left Bin
Cove
r
Adapter
LH Retaining Arm
#8 Screw
4 Places
Right Bin
Cove
r
RH Retaining
Ar
m
Bracket
