KH0178 - IB0620/0820/1020 ON A CORNELIUS
24.50” WIDE ICE DISPENSER (ENDURO 175)
Installation Instructions
1. Set adapter on top of the dispenser. Position the bin cover so that the front flange of the bin cover will lock under the
front lip of the dispenser. Adapter may have to be moved towards the back of the dispenser.
2. Using the slotted holes in the adapter as a template, drill four (4) 9/64” diameter holes at the bottom of the slots.
NOTE: Do not drill deeper than 1/4” past the sheet metal. Use a drill stop!
3. Fasten adapter to dispenser using the four (4) #8 screws supplied with the adapter kit.
4. Set the ice machine on top of the adapter. Align holes in ice machine front angle with the rivnuts on the adapter.
5. Secure the ice machine to the adapter with two (2) #8-32 screws supplied with the kit.
6. Set the front bin cover onto the dispenser. The back flange of the bin cover will latch onto the adapter.
7. Rotate retaining arms into position, as shown for normal ice machine operation.
Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 8006743
Web Site - www.manitowocice.com Rev. 06/17/03
Bin Cover
#8-32 Screw
2 Places
Adapter
LH Retaining Arm
#8 Screw
4 Places
RH Retaining Arm
Cornelius ED175 Dispenser
