K00347 ICE DEFLECTOR KIT
Installation Instructions
The K00347, ice deflector kit, must be used with the S-0300, S-0450, S-0500, S-0600, S-0850, and S-1000 ice machines,
when the ice machine is used on a non-Manitowoc ice storage bin.
1. Remove both front panels.
2. Examine the ice machine to see if the machine has four screws on the lower front plastic panels (see drawing).
3. If there are screws, remove them from the countersunk holes on the front surface of the machine. Save the screws.
4. Install the deflector, using the four screws that were removed in step 3.
5. Four screws and two backing plates are in the kit.
6. If there are no screws on the ice machine (step 2), pierce the thin plastic countersunk holes, install the backing
plates, and install the deflector, using the screws from the kit.
7. Replace the front panels.
New Ice
Deflector
Screws
Screws
Backing Plate
to be Inserted
into Side Pocket
of Bulkhead
Backing Plate to be
Inserted into Side
Pocket of Bulkhead
