Mapmyindia MAPPLS NavAudio User manual

USER MANUAL

INDEX
Introduction 1
In the Box 1
Features 1
Appearance 2
Start using your device 2
Charge the NavAudio 2
Charging Status 3
Basic Operations 3
Power On and Off 3
Pairing with Phone 4
Volume Control 4
Installation 5
Functionality 5
Phone Calls 5
Call Answer 5
Call Reject 5
Call End 6
Last call redial 6
Voice Assistant 6
Priority 7
Music Control 7
Play/Pause 7
Music Switch 7
Mappls App 8
Other 8
Battery Safety 8
Warranty Terms 9
Safety and Usage Information 12

The User agrees and acknowledges that the 2Wheeler Navigation product/aid
called the Navisor and NavAudio is for aiding the user with directions on roads.
The User understands and further acknowledges that there is always a possibili-
ty of new roads being constructed/ turns being closed/opened which may not be
captured/updated in the product. The Company (C.E. Info Systems Limited)
strongly advises you to direct all your attention to the ride, drive or transport, and
to follow the local traffic regulations and safety requirements and does not pro-
vide any warranty with respect to the exactness of the product. The Company
and its group companies disclaims all liability with respect to any loss of
property, injury and death caused to the User or anyone else by use of these
products.

NavAudio 1 unit Cable *1 Unit
QSG
Velcro patch * 2 Unit QSG
INTRODUCTION
In the box
Features
 Works on Bluetooth low energy mode (BLE 5)
 Works upto 120km per hour speed
 Bluetooth calling (Auto receives after 6 rings or you can reject
by pressing the button)
 Listen to music /calls
 Long press : Support Google assistant or Siri
 20 Hours battery back up
 Charging time 2.5hrs
 Wind noise cancellation
 Stereo sound
 250hrs standby
 400mAh battery
1

Speaker
Volume+
Indicator
Charging
Power ON/ Phone Button
Volume-
Appearance
START USING YOUR DEVICE
Charge the NavAudio
Your device is powered by a rechargeable Li-Ion battery.
 Insert the USB cable into the USB charger port.
 Connect the USB cable to the charging head, and then plug the charging
head into a standard outlet.
 Insert the Micro USB end of the cable in the NavAudio.
2

Low Battery Indication Charging Indication
Charging
Full
Red light always on
Red light off
Red light quickly flashes twice
“ Low battery”
1 Sec
Charging Status
Basic Operations
Power On and Off
Power On Bluetooth On
3
ON
“Ding~Ding~Ding~Ding~Ding~”
Standby
 Blue light flashes slow
OFF
Press the <Volumes -> &
<Power button> simultaneously
for 1 sec
 Indicator light off
Long-press for
1 s
1 Sec 5 Sec
Simultaneously
press for 5s



Turn on the “Bluetooh” of the
cellphone, find and pair the
NavAudio
Bluetooth
NavAudio
5 Sec
2
1
Pairing Successful
 Blue light slow flashes twice
“pairing Successful”
“connected”
Press to minimize the volume Press to maximize the volume
Current battery status will
Show on the cellphone
(The cellphone must
support HFP)
Pairing with Phone
Volume Control
4
To pair/connect Navaudio with
your phone:
1. Press and hold the Power
Button for 5 seconds to enable
Bluetooth or enter pairing
mode. When the blue and red
LEDs blink continuously,
NavAudio will be discoverable
by your mobile phone's Blue
tooth
2. Turn on "Bluetooth" on your
phone and connect it to
NavAudio.
3.If no device is paired within
2 minutes, pairing mode will
be disabled, and the device
will enter standby mode.
While in standby mode,
Navaudio will not be discover
able by other phones.
Red and Blue light flash
quickly “Pairing”

Call Answer
Auto answering within 8s
if no other action is taken
Long press for 2 second
2 Sec
2. Adjust the mic position for a better fit
1. Stick the NavAudio on both sides
inside the helmet
FUNCTIONALITY
or
Call Reject
Phone Calls
INSTALLATION
5

Call End
Last call redial
Voice Assistant
1 Sec
Voice
assistant
Turn on the voice assistant
12
Press the <Phone button> for 1s
Press to End call
Press to redial last call
6

Priority
Music Control
Music InterruptCall Music RestoreHang up
2 Sec 2 Sec
Play/Pause
Music Switch
Press to Play/Pause
the music
To play previous track,
press for 2 second
To play next track,
press for 2 second
7

Mappls App
Battery Safety
OTHER
If you are using NavAudio with Navisor, you can enjoy the Turn-By-Turn Audio
Navigation on the NavAudio via Mappls MapmyIndia Application Inside-Side
 Use the original battery supplied by MapmyIndia only. The use of any
non-original accessories may damage the device, in which case we will
assume no repair liabilities for such damages.
 Avoid contacts with metal objects as they may cause short circuits on
battery contacts.
 Do not remove the cover of the battery.
 Do not soak the battery in water or expose it to fire.
 It is forbidden to use batteries that are deformed, discolored, spilled, or pack
age-damaged. If such an exception, such as over-temperature, deformation,
discoloration, spillage, etc., occurs during use, charging, or storage of the
battery, please stop using the device immediately and contact the aftersales
center for a replacement.
 It is forbidden to dismantle, or modify, or change (in any other method other
than stated) the battery.
8

Warranty Terms
Terms and Conditions of Limited Warranty:
 This warranty is applicable within India only
 This warranty card along with the original proof of purchase and/or original
invoice must be presented to the service staff when requesting service and or
repair
 The warranty extends only against manufacturing defects and/or failure of
its mechanical and/or electrical components for a period of 1 year from the date
of purchase wherein the warranty card is duly filled and stamped.
 The warranty does not extend to any product that has been damaged and/or
rendered defective:
 As a result of accidents and/ or misuse and/or abuse,
 As a result of an act of God
 By operation outside the usage parameters stated in the product’s user
manual.
 By the use of parts not manufactured and/or sold by the authorized manu-
facturers:
 By modification of the product
 As a result of service other than CE Info Systems Ltd
 The warranty card shall be rendered invalid if found to be altered and/or
defaced
 The warranty shall immediately cease and shall be rendered void in the
event the product is found to have been tampered and/or modified and/or the
serial number defaced and/or removed and/or repaired by an unauthorized
person and/or entity.
9

Warranty Terms
 This warranty shall be subject to following limitations and/or exclusions and
shall not apply to:
 Malfunctions and/or damages and/or defects as a result of exposure to fire
and water.
 Malfunctions and/or damages and/or defects as a result of using wrong elec-
trical supply, wrong and/or duplicate electrical gadgets such as charger, etc.
 Dealer's display and/or showroom sets.
 Commercial and/or industrial use.
 Dismantling of the device for repairs and/or repairs by an unauthorized
person and or entity.
 Demonstration on use of appliance and/or product
 Accessories such as but not limited to car charger, wall charger, mount, bat-
tery USB cable and any free gift items.
 Parts subject to normal and inevitable wear and tear of fuses seals dia-
phragm knobs, rubber parts, etc.
 Non-conformance to the warranty to company's satisfaction, based on exam-
ination.
 Damages caused by discs, magnetic tapes and/ or any other related equip-
ment.
 This warranty extends only to you, the original purchaser it is non-transfera-
ble.
 Except as expressly set forth in this warranty, "Out of warranty" products shall
be repaired upon services at the manufacturers service center. The purchaser
shall be required to pay for the expenses of transportation of the product
including the courier expenses arising there from.
10

Warranty Terms
 Makes no other warranties, expressed and/or implied, including any implied
warranties and or merchantability and fitness for a particular purpose. CE Info
Systems Ltd. expressly disclaims a not stated in this limited warranty. Any
implied warranties that may be imposed by law are limited to the terms of this
express limited warranty.
 Warranty does not cover:
 If the product serial number or warranty seal is illegible or has been removed
erased, defaced altered and/or tempered or any accessory or external part of the
product is missing.
 Out of warranty" products shall be repaired upon services at the CE Info
Systems Ltd. authorized service centers. The purchaser shall be required to pay
for the expenses of transportation of the product including the courier expens-
es arising there from.
11

Safety and Usage Information
 Use only MapmyIndia approved accessories
 Handle and dispose batteries and chargers with care
1. Use only MapmyIndia approved batteries and chargers, these are specially
designed for your device. Incompatible batteries and chargers may cause
serious injuries or damages to your device
2. Never place batteries or devices on fire or in heating devices, such as micro
wave ovens, stoves, or radiators, Batteries may explode when overheated
3. Correct disposal of batteries of the device
4. (Waste Electrical and Electronic Equipment Directive Applicable in the Euro-
pean Union and other European countries with separate battery return sys-
tems.) This symbol in the manual indicates that this product and its accessories
(such as chargers, batteries and USB cable) should not be disposed of with
other household wastes when they reach the end of their life. If batteries are not
properly disposed of, these wastes may cause harm to human health and the
environment. To prevent the harm, please dispose of or recycle them separately
from other wastes.
Support Details
For questions and technical support
E-mail: [email protected]
Contact: [phone]
12

27
Learn more
about NavAudio
For questions and technical support
E-mail: [email protected]
Contact: [phone]
website: about.mappls.com
