Marantz PM8003 User manual
Integrated Amplifier
PM8003
ENGLISHFRANÇAISESPAÑOL
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE
PARTS INSIDE REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPON-
DANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
NOTE:
Changes or modifications may cause this unit to fail
to comply with Part 15 of the FCC Rules and may
void the user's authority to operate the equipment.
DECLARATION OF CONFORMITY
U.S. Responsible Party: Marantz America, Inc.
100 Corporate Drive,
Mahwah, NJ, 07430, U.S.A.
TEL: 201-762-6500
Type of Product:
Model:
Integrated Amplifier
PM8003
This device complies with Part 15 of the FCC rules. Operation is subject to the
following conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numerique de la Classe B est conforme
a la norme NMB-003 du Canada.
Additional Safety Information!
s 4HISPRODUCTSHOULDNOTBEPLACEDINABUILTININSTALLATIONSUCHASABOOKCASEORRACKUNLESSPROPER
ventilation is provided or the manufacturer’s instructions have been adhered to.
s !PPARATUSSHALLNOTBEEXPOSEDTODRIPPINGORSPLASHINGANDTHATNOOBJECTSlLLEDWITHLIQUIDSSUCHAS
vases, shall be placed on the apparatus.
s 7HENTHESWITCHISINTHE/&&POSITIONTHEAPPARATUSISNTCOMPLETELYSWITCHEDOFFFROMTHE-!).3
s 4HEEQUIPMENTSHALLBEINSTALLEDNEARTHEPOWERSUPPLYSOTHATTHEPOWERSUPPLYISEASILYACCESSIBLE
s $ONOTTOUCHHOTAREASESPECIALLYAROUNDTHEhHOTSURFACEMARKvDURINGANDIMMEDIATELYAFTERUSE
s $URINGANDIMMEDIATELYAFTERUSETHISPRODUCTISHOTINAREASOTHERTHANTHECONTROLSANDREARPANEL
connection jacks.
s $ONOTTOUCHHOTAREASESPECIALLYAROUNDTHEhHOTSURFACEMARKvANDTHETOPPANEL#ONTACTWITHHOT
areas can cause burns.
Hot surface mark
s $ONOTEXPOSETHEUNITANDBATTERIESTOEXCESSIVEHEATSUCHASDIRECTSUNLIGHTlREORTHELIKE
s -AKEASPACEOFABOUTINCHSMAROUNDTHEUNIT
IMPORTANT SAFETY
INSTRUCTIONS
READ BEFORE OPERATING EQUIPMENT
This product was designed and manufactured to meet strict quality and safety standards.
There are, however, some installation and operation precautions which you should be particularly aware of.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
AMP_080708U2
1
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
ENGLISH
UUser Guide
UWarranty Card
USA x 1
Canada x 1
FEATURES ................................................................................................................................................... 2
BEFORE USE ............................................................................................................................................... 2
USAGE OF REMOTE CONTROLLER .............................................................................................................................................3
NAMES AND FUNCTIONS.......................................................................................................................4
FRONT PANEL.................................................................................................................................................................................. 4
REMOTE CONTROLLER.................................................................................................................................................................. 5
REAR PANEL .................................................................................................................................................................................... 6
BASIC CONNECTIONS ............................................................................................................................. 7
CONNECTING AUDIO COMPONENTS ....................................................................................................................................... 7
CONNECTING SPEAKER SYSTEMS............................................................................................................................................ 8
WIRING SPEAKER CABLE............................................................................................................................................................. 8
CONNECTING OF AC POWER CABLE......................................................................................................................................... 8
BASIC OPERATION ...................................................................................................................................9
PLAYBACK........................................................................................................................................................................................ 9
ADVANCED CONNECTIONS..................................................................................................................10
CONNECTING POWER DIRECT IN JACKS............................................................................................................................... 10
CONNECTING PRE OUT JACKS................................................................................................................................................. 10
BI-WIRE CONNECTIONS............................................................................................................................................................. 11
CONNECTING REMOTE CONTROL JACKS.............................................................................................................................. 11
REMOTE CONTROLLER OPERATION ...................................................................................................12
TROUBLESHOOTING...............................................................................................................................13
OTHERS .....................................................................................................................................................14
SPECIFICATIONS & DIMENSIONAL DRAWINGS .................................................................................................................. 14
INTRODUCTION
Thank you for selecting the Marantz PM8003 Integrated amplifier for your Audio system.
Please read these operating instructions carefully. We recommend that you read the entire user guide before
you attempt to connect or operate the amplifier.
After you have reviewed the contents of this manual, we suggest that you make all system connections
before you attempt to operate the unit.
ACCESSORIES CHECK
Before use, check the below accessories were included in the package.
URemote controller
USize
“AAA”batteries x 2
UAC Power cord
CONTENTS
2
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
ENGLISH
This section must be read before any connection is
made to the mains supply.
EQUIPMENT MAINS WORKING SETTING
Your Marantz product has been prepared to comply
with the household power and safety requirements
that exist in your area.
PM8003 can be powered by 120V AC only.
COPYRIGHT
Recording and playback of any material may
require consent. For further information refer to the
following:
—Copyright Act 1956
—Dramatic and Musical Performers Act 1958
—Performers Protection Acts 1963 and 1972
—Any subsequent statutory enactments and
orders
DO NOT LOCATE IN THE FOLLOWING
PLACES
To ensure long-lasting use, do not locate the unit
where:
UExposed to direct sunlight.
UNear to sources of heat such as heaters.
UHighly humid or poorly ventilated.
UDusty.
USubjected to mechanical vibrations.
UOn wobbly, inclined or otherwise unstable
surfaces.
URadiated heat is blocked such as in cramped
audio racks.
To ensure proper heat radiation, ensure the below
clearance from walls and other equipment.
Left
8 inchs (0.2 m) or more
Above
8 inchs (0.2 m) or more
Right
8 inchs (0.2 m) or more
Rear
8 inchs (0.2 m) or more
KEEP OBJECTS OFF
Keep objects off the unit. Blocking the vent can
result in accident and damage.
DO NOT TOUCH HOT SPOTS DURING AND
IMMEDIATELY AFTER USE
During and immediately after use, the unit is hot
in areas other than the controls and rear panel
connection jacks. Do not touch hot spots and
especially the top panel. Contact with hot areas can
cause burns.
FEATURES
ALL-DISCRETE CURRENT-FEEDBACK
AMPLIFIER
Marantz’proprietary current-feedback circuit, using
discrete components, is adopted in the pre amplifier
and power amplifier. It is a high-speed amplifier
using the latest technology developed for the
higher-grade amplifiers.
HDAM-SA3 TECHNOLOGY
The V/I converter circuit, which is the key block
of the current-feedback pre-amplifier and power
amplifier, is equivalent to the HDAM-SA3 amp-
module developed for such higher-grade models as
the SC-11S1.
CD DIRECT BUFFER AMPLIFIER
An input buffer amplifier exclusive for CD is mounted
near the CD input jacks. This is a high-speed buffer
amplifier made with discrete components, which
avoids interference between right and left channels
and can send the signals to the pre-amplifier with
very high fidelity.
IMPROVED MOMENTARY CURRENT
SUPPLY ABILITY
It is generally known that the sound quality is not
necessarily the same even if amplifiers have the
same specifications. Marantz considers the cause
to be the power to drive speakers. The power
amplifier of this unit has the ability to momentarily
supply current of 25 A or more to drive speakers
strongly.
SHORT-POWER-LINE LAYOUT
For strong momentary current supply, a short
power-line layout unifies the power circuit and
output stage of the power amplifier section. This
layout allows connecting the large-current lines via
the shortest route while to arranging the left and
right channels symmetrically.
ALL-DISCRETE CURRENT-FEEDBACK
PHONO EQUALIZER
As a phono equalizer amplifier for MM cartridges,
a constant current-feedback PHONO equalizer of
quality equal to that of the higher-grade model SC-
11S1 is used.
DOUBLE-SHIELDED TOROIDAL
TRANSFORMER
The unit is equipped with a toroidal power
transformer to minimize vibration and leakage flux
specific to the transformer. Especially to reduce
leakage flux, which affects sound quality, the
periphery is double-shielded, using a core ring and
a short ring.
BLOCK CONDENSER OF LARGE CAPACITY
A large-capacity condenser of 18,000μF is used in
the power circuit of the power amplifier. In the pre-
amplifier, a 4,700μF condenser is used.
HIGH-PERFORMANCE VOLUME
CAPACITOR FOR HIGH QUALITY SOUND
DOUBLE-LAYERED CHASSIS
HIGH-GRADE SPEAKER TERMINALS
BEFORE USE
3
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
ENGLISH
BEFORE USE
USAGE OF REMOTE CONTROLLER
LOADING BATTERIES
Before using the remote controller for the first time,
load the batteries in the remote controller. The
batteries provided are used to verify the operations
of the remote controller only.
1. Remove the battery cover.
2. Insert the batteries with correct +/–
orientation.
3. Close the battery cover until it clicks shut.
CAUTIONS ON HANDLING BATTERIES
Misuse of the batteries can result in electrolyte
leakage, rupturing, corrosion, etc.
Bear in mind the following points when using
batteries.
URemove the batteries from the remote control
unit if the unit is not going to be used for a
prolonged period (a month or more).
UDo not use an old battery together with a new
one.
UInsert the batteries while ensuring that their
Vand spoles are properly aligned with the
corresponding markings on the remote control
unit.
UBatteries with the same shape may have different
voltages. Do not use different types of batteries
together.
UIf electrolyte has leaked, thoroughly wipe the
inside of the battery compartment, and then
insert new batteries.
UWhen batteries which are no longer required are
to be discarded, follow the directions (regulations)
laid down by the local authorities in the area
concerned for their disposal.
OPERATIONAL RANGE
Operate the unit with the remote controller within
the range of the illustration below.
Approx. 16.4 ft.
(5 m)
Remote controller
Precautions
s$O NOT ALLOW DIRECT SUNLIGHT AN INVERTER
mUORESCENTLIGHTOROTHERSTRONGSOURCEOFLIGHTTO
SHINEONTOTHEPLAYERSINFRAREDSIGNALRECEPTION
WINDOWREMOTESENSOR/THERWISETHEOPERATION
OFTHEREMOTECONTROLUNITMAYBEDISABLED
s "EAR IN MIND THAT OPERATING THE REMOTE CONTROL
UNITMAYCAUSEOTHERDEVICESOPERATEDBYINFRARED
RAYSTOBEOPERATEDBYMISTAKE
s 4HEREMOTECONTROLUNITCANNOTBEOPERATEDIFTHE
SPACE BETWEEN THE CONTROLLER AND THE PLAYERS
REMOTESENSORISOBSTRUCTED
s $O NOT PLACE ANY OBJECTS ON TOP OF THE REMOTE
CONTROL UNIT $OING SO MAY CAUSE ONE OR MORE
BUTTONS TO BE HELD DOWN WHICH WILL CAUSE THE
BATTERIESTORUNDOWN
4
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
NAMES AND
FUNCTIONS
ENGLISH
NAMES AND FUNCTIONS
INTEGRATED AMPLIFIER PM8003
AUX/DVD MUTERECORDER 21TUNERPHONO CD
POWER AMP DIRECT
INPUT SELECTOR VOLUME
MAXMIN
SOURCE DIRECT
STANDBY
POWER ON/OFF
PHONES
BALANCE
RL
TREBLEBASS
+
-
+
-
OFF
A+B
A
SPEAKERS
B
:@ B>. 2
8
; =
:POWER ON/OFF button
Pressing this button once turns power to the
amplifier ON, and pressing it again turns power to
the amplifier OFF. When the button is in the ON
position, power can be switched ON/OFF using the
remote controller.
If the power is switched OFF using the remote
controller, the amplifier engages in standby mode.
When in this mode, you cannot switch the power
ON by pressing the POWER ON/OFF button. The
amplifier remains in standby mode even if this
button is pressed. To switch the power ON, either
turn the INPUT SELECTOR knob or press the
POWER ON button on the remote controller.
@STANDBY indicator
This indicator is lit red when the amplifier is in
standby mode. When in standby mode, you can
switch the power ON by using the POWER ON
button on the remote controller. If the amplifier’s
protective circuit activates, this indicator flashes.
.INPUT SELECTOR knob
This knob selects the input source for playback. The
selected input source is displayed on the function
indicator. The amplifier memorize the selected input
source when the power is turned OFF, and then re-
selects the same input source when the power is
turned ON again.
;Function indicator
This indicator displays the input source currently
selected by the INPUT SELECTOR knob.
=MUTE indicator
When the MUTE button on the remote controller
is pressed, the MUTE function is activated and
the volume is lowered. Pressing the MUTE button
again releases the MUTE function. Moreover, the
MUTE function can also be released by pressing
the VOLUME +/– button on the remote controller.
If the amplifier’s protective circuit activates, this
indicator flashes for approx. 15 seconds and the
MUTE function activates. While this indicator is
flashing, the VOLUME knob automatically turns and
the volume decreases.
BPOWER AMP DIRECT button
The POWER DIRECT IN jacks are provided on the
rear panel of the unit. Holding this button pressed
for more than 3 seconds lights the indicator around
the button, and this unit functions as the power
amplifier.
In this status, the sound volume cannot be adjusted
by turning the VOLUME knob.
To release POWER AMP DIRECT mode, hold this
button pressed for more than 3 seconds again.
>SOURCE DIRECT button
Pressing this button lights the indicator around the
button. The signal bypasses the balance and tone
control circuits, boosting sound quality. When this
button is set to ON, the BALANCE, BASS, and
TREBLE knobs are disabled.
2VOLUME knob
Turning this knob clockwise increases the volume,
while turning it counterclockwise decreases the
volume. The volume can also be adjusted using the
remote controller. If the amplifier’s protective circuit
activates, the VOLUME knob automatically turns for
approx. 15 seconds and the volume decreases.
8Infrared Receptor Window
This is the receptor of control signals sent from
the remote controller. Point the remote controller
towards this window to properly transmit signals.
BALANCE knob
This knob is used to adjust the sound level from
one of either the L (left) or R (right) channels. If the
BALANCE knob is turned all the way round to one
side, sound is not output from the opposite side.
Please note that this knob does not function when
the SOURCE DIRECT button is in the ON position.
Tone Control knobs
(BASS/TREBLE)
These knobs are used to adjust the BASS and
TREBLE sound level. Turning the knobs clockwise
increases the sound level, and turning them
counterclockwise decreases the sound level.
Please note that these knobs do not function when
the SOURCE DIRECT button is in the ON position.
SPEAKERS knob
This knob is for selecting the speakers connected
to the SPEAKERS SYSTEM A and/or B terminals on
the rear panel. When you use headphones, set the
knob to OFF.
PHONES jack
This jack is for connecting headphones with a
standard stereo plug. To listen with headphones, turn
the speaker output OFF by setting the SPEAKERS
knob in the OFF position.
FRONT PANEL
5
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS NAMES AND
FUNCTIONS
ENGLISH
NAMES AND FUNCTIONS
z
x
c
b
v
x
b
Using this remote controller, you can control this unit
and Marantz CD players, DVD players, tuners, tape
decks etc. that have a remote control receptor. The
operations possible by remote controller may differ
with each component; therefore see the instruction
manual that came with the component.
The remote controller buttons are laid out as shown
below.
CPOWER ON/STANDBY buttons
POWER ON button
Turns the unit power on when it is in the standby
mode.
POWER OFF button
Sets the unit power to the standby mode when it is
set to the power-on mode.
SOURCE POWER button
Switching the mode of a CD player, DVD player or
other Marantz component equipped with a power
standby function between power-on and standby
is enabled by pressing this button after the INPUT
SOURCE button corresponding to the component
has been pressed.
When this button is pressed after pressing the
TUNER button, the tuner’s power is turned on;
when it is pressed again, the tuner is set to the
standby mode.
When this button is pressed after pressing the AMP
button, the unit is switched from the power-on
mode to the standby mode or vice versa.
* The remote controller cannot be used to turn the
primary power of the amplifier ON and OFF.
AInput selector buttons
Input source Button
These buttons are for directly selecting the input
source.
Caution:
3OMEINPUTJACKSOFTHISUNITANDTHECORRESPONDING
INPUT SELECTOR BUTTONS ON THE REMOTE CONTROLLER
DIFFERASSHOWNBELOW
The unit Buttons on the
remote controller
AUX/DVD AUX, DVD
RECORDER2 TAPE, MD
&OR THE INPUT SOURCES SHOWN IN THE TABLE ABOVE
ALTHOUGHTHESAMEJACKSAREUSEDFOR TWOTYPESOF
SOURCESONTHEUNITSEPARATEBUTTONSAREPROVIDED
ONTHEREMOTECONTROLLER
7HENUSINGTHEREMOTECONTROLLERFOROPERATIONOFA
-ARANTZCOMPONENTCONNECTEDTOTHEUNITSELECTTHE
INPUTSOURCElRSTTHENPERFORMOPERATIONS
INPUT 3Button
This button is for forward-feeding the input source
indications to select a desired source.
The input source indication, which is displayed on
the function indicator on the main frame, is fed to
the right.
INPUT 4Button
This button is for backward-feeding the input source
indications to select a desired source.
The input source indication, which is displayed on
the function indicator on the main frame, is fed to
the left.
,VOLUME adjustment buttons
MUTE Button
This button activates the mute function. Pressing
this button again releases the MUTE function.
The MUTE function can also be released by pressing
either the VOLUME + or – buttons.
VOLUME + Button
This button increases the volume level.
VOLUME – Button
This button decreases the volume level.
?SOURCE DIRECT button
This button is for switching Source Direct mode
ON or OFF.
+Component operating buttons
These buttons are for performing basic operations
of a Marantz CD player, DVD player, etc. The
function of each button changes to match the
component selected as the input source using the
input selector buttons.
For details, see page 12.
REMOTE CONTROLLER
6
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
NAMES AND
FUNCTIONS
ENGLISH
NAMES AND FUNCTIONS
/PHONO Input jacks
These jacks are for connecting to an analog record
player. MM cartridges can be used.
4PHONO GND terminal
Connect the grounding wire from an analog record
player.
)PRE OUT jacks
These jacks are for connection via the input jacks of
another main amplifier or active subwoofers. These
jacks cannot be used in Power Amp Direct mode.
0POWER AMP DIRECT IN jacks
These jacks are used as input jacks when you use
this unit as a power amplifier in Power Amp Direct
mode. If you use another preamplifier, connect it via
these jacks. In this status, the sound volume cannot
be adjusted by turning the VOLUME knob.
1SPEAKERS SYSTEM A, B
output terminals
You can connect 2 speaker systems, SYSTEM A and
SYSTEM B. Speaker output can be turned ON/OFF
from the SPEAKERS knob on the front panel.
6AC IN socket
Connect the supplied AC power cable to this socket
and a power outlet.
2REMOTE CONTROL jacks
These jacks are for connecting to other Marantz
components such as a CD player or DVD player that
has a remote control connector (D.BUS jack).
You can use the remote controller supplied with the
unit to control the system.
For more details, see page 11.
*RECORDER 1/RECORDER 2 output
jacks
These jacks are for connecting to the recording input
jacks of a CD-R recorder, MD deck, tape deck, etc.
-RECORDER 1/RECORDER 2 input
jacks
These jacks are for connecting to the output jacks of
a CD-R player, MD deck, tape deck, etc.
AUX/DVD input jacks
These jacks are for connecting to the output jacks of
a DVD player or other audio component.
TUNER input jacks
These jacks are for connecting to the output jacks of
a tuner or other audio component.
CD input jacks
These jacks are for connecting to the output jacks of
a CD player or similar component.
REAR PANEL
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
/ ) 0 1 6
2*
-
4
7
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS BASIC
CONNECTIONS
ENGLISH
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
Record Player
Tuner
DVD Player
CD-R, etc.
MD or Tape deck, etc.
To LINE OUT jacks
To LINE OUT jacks
To LINE OUT jacks
To LINE OUT jacks
To LINE IN jacks
To LINE OUT jacks
To LINE IN jacks
CD player
BASIC CONNECTIONS
CONNECTING AUDIO COMPONENTS Caution:
s $ONOTCONNECTTHEPOWERCORDOFTHISAMPLIlERORANYOFTHEOTHERCOMPONENTSTOTHEPOWERSUPPLYUNTILALLOF
THECONNECTIONSARECOMPLETED
s )NSERTTHEPLUGSOFTHECONNECTIONSCORDSlRMLYINTOTHECONNECTINGJACKS)NCORRECTINSERTIONMAYCAUSENOISE
s #ONNECTTHEWIRESCORRECTLYTOTHE,LEFTAND2RIGHTCHANNELS
s -AKESURETHATINPUTANDOUTPUTARECONNECTEDCORRECTLY
s 2EFERALSOTOTHEINSTRUCTIONMANUALSOFCOMPONENTSTOCONNECTEQUIPMENTCORRECTLY
8
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
BASIC
CONNECTIONS
ENGLISH
Notes:
s 4OPREVENTDAMAGETOCIRCUITRYDONOTLETTHEBARE
SPEAKER WIRES TOUCH EACH OTHER AND DO NOT LET
THEMTOUCHANYMETALPARTOFTHISUNIT
s$O NOT TOUCH THE SPEAKER TERMINALS WHEN THE
POWER IS ON )T MAY CAUSE YOU TO RECEIVE AN
ELECTRICSHOCKS
s"E SURE TO CONNECT THE POSITIVE AND NEGATIVE
CABLESFORTHESPEAKERPROPERLY)FTHEYAREMISS
CONNECTEDTHESIGNALPHASEWILLBEREVERSEDAND
THESIGNALQUALITYWILLBECORRUPTED
WIRING SPEAKER CABLE
UPeel off the coating of speaker cable as shown
below.
Approx. 1 cm
Cut the coating
of cable.
Peel off the edge
of cable.
Twist
conductors.
UWiring with speaker cable.
Turn counter-
clockwise to
loosen.
Insert conductor
of cable.
Turn clockwise
to tighten.
BASIC CONNECTIONS
USet the SPEAKERS knob on the front panel in the A or A+B position.
CONNECTING SPEAKER SYSTEMS
Your speaker system must satisfy the below conditions. If it does not, this unit’s protective circuit will active,
whereby preventing proper playback. In some cases, the amplifier and speakers may be damaged.
UIf using 1 set of speakers, total speaker impedance must be 4Ωor more.
UIf using 2 sets of speakers, total speaker impedance must be 8Ωor more.
CONNECTING OF AC POWER CABLE
1. Plug the supplied AC power cable to the
AC IN socket on the rear panel of the main
unit.
AC IN
OUT
IN
REMOTE
CONTROL
M
ODEL NO. PM8003
2. Plug the power cable into an AC outlet.
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
To power outlet
R CH
speaker
L CH
speaker
9
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS BASIC
OPERATION
ENGLISH
BASIC OPERATION
PLAYBACK
To explain how to play back input sources, representative examples are given with an CD player and analog
record player. Before starting either procedure, check the component is correctly connected to the unit.
DISC PLAYBACK ON AN CD PLAYER
1. Press the power ON/OFF button of the CD
player to activate power to it.
2. Press the POWER ON/OFF button :to
activate power to it. Approximately 8
seconds after power has been activated,
the muting turns OFF and audio output is
enabled.
3. Select the CD with the INPUT SELECTOR
knob ..
4. To use the speakers connected to the
SPEAKERS SYSTEM terminals, set the
SPEAKERS knob .
5. Load a disc into the CD player and press the
play button to start playback.
6. Adjust the volume with from the VOLUME
knob 2.
7. Adjust bass/treble as desired with the
BASS and TREBLE knobs . Be sure to first
set the SOURCE DIRECT button >in the
OFF position.
DISC PLAYBACK ON AN ANALOG RECORD
PLAYER
1. Press the POWER ON/OFF switch :to
activate power to it. Approximately 8
seconds after power has been activated,
the muting turns OFF and audio output is
enabled.
2. Select
“PHONO”as the input source with
the INPUT SELECTOR knob .. To prevent
unexpected accidents, it is recommended
to set the volume level to MIN. by turning
the VOLUME knob 2until muting the
volume level.
3. MM type cartridges can be connected. Use
a step-up transformer when using an MC
cartridge.
4. To use the speakers connected to the
SPEAKERS SYSTEM terminals, set the
SPEAKERS knob .
5. Set a record on the analog record player
and play it.
6. Adjust the volume level with the VOLUME
knob 2.
7. Adjust bass/treble as desired with the
BASS and TREBLE knobs . Be sure to first
set the SOURCE DIRECT button >in the
OFF position.
INTEGRATEDAMPLIFIER PM8003
AUX/DVD MUTERECORDER 21TUNERPHONO CD
POWER AMP DIRECT
INPUT SELECTOR VOLUME
MAXMIN
SOURCE DIRECT
STANDBY
POWER ON/OFF
BALANCE
RL
TREBLEBASS
+
-
+
-
OFF
A+B
A
SPEAKERS
B
: >. 2
A
A,
10
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
ADVANCED
CONNECTIONS
ENGLISH
ADVANCED CONNECTIONS
CONNECTING POWER DIRECT IN JACKS
If you use a preamplifier, connect it as shown below, and then you can use this unit as a power amplifier.
Set the POWER AMP DIRECT IN button on the front panel of the unit to its ON position.
For details on operations of the preamplifier, refer to the instruction manual supplied with the preamplifier
to be used.
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
Set the SPEAKERS knob on the front panel to the A
position.
R CH
speaker
L CH
speaker
To power outlet
To PRE OUT Jacks
Pre-amplifier
Note:
)FYOUUSETHISUNITASAPOWERAMPLIlERTHEPREAMPLIlERSECTIONDOESNOTFUNCTIONANDTHE).0543%,%#4/2
3/52#%$)2%#46/,5-%"!3342%",%AND"!,!.#%KNOBSAREDISABLED
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
Speaker Power-amplifier
To input jacks
Speaker
To power outlet
CONNECTING PRE OUT JACKS
If you use a power amplifier, connect it as shown below, and then you can use this unit as a preamplifier.
For connecting speaker systems, refer to the instruction manual supplied with the power amplifier to be
used.
11
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS ADVANCED
CONNECTIONS
ENGLISH
ADVANCED CONNECTIONS
BI-WIRE CONNECTIONS
BI-WIRE connection is a technique for improving sound quality. It connects speaker systems and an amplifier,
using two speaker cables; one for mid-to-high range speakers and another for bass speakers.
It eliminates the influence on a mid-to-high range speaker unit due to back electromotive force generated
by the bass speaker unit.
For BI-WIRE connection, a speaker system must comply with the BI-WIRE connection specifications. Refer
tothe instruction manual supplied with the speaker system.
Connect a mid-to-high range speaker via the SYSTEM A terminals and a bass speaker via the SYSTEM B
terminals. Then set the SPEAKER knob on the front panel in the A+B position.
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
MF / HF
LF
MF / HF
LF
Remove shorting
bar.
Remove shorting bar.Remove
shorting bar.
CD Player
To Line output jacks
R CH
speaker
L CH
speaker
To power outlet
CONNECTING REMOTE CONTROL JACKS
The REMOTE CONTROL jacks are for connecting components that are capable of remote control (D.BUS
jacks) such as a Marantz CD Player or DVD Player. This enables these other components to be operated
with the remote controller included with the unit. The unit comes with the system remote controller that
can operate the basic features of Marantz CD Players and DVD Players. Here, a brief explanation of how to
control the unit and CD Player using this remote controller is provided.
As shown in the illustration below, connect the REMOTE CONTROL “IN”jack of the CD Player to the
REMOTE CONTROL “OUT”jack of the unit, and set the CD Player switch to “EXTERNAL”.
Both this model and CD Player can be operated by pointing the remote controller at the receptor of this
model.
R
SPEAKERS
SYSTEM A
L
L
R
GND
CD AUX
/
DVD
TUNER
OUTIN
RECORDER 1
OUTIN
RECORDER 2
R
L
L
R
PHONO
AC IN
OUT
IN
REMOTE
CONTROL
R L
R
L
POWER AMP
DIRECT IN
PRE OUT
R
L
MODEL NO. PM8003
AC IN
DIGITAL AUDIO OUT
R L IN
OUT
REMOTE CONTROLANALOG OUTPUT
OPTICALCOAXIAL
INTERNAL
EXTERNAL
AC IN
DIGITAL AUDIO OUT
IN
OUT
REMOTE CONTROL
Set to “EXTERNAL”
For details connecting the speakers, see page 8.
12
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
REMOTE CONTROLLER
OPERATION
ENGLISH
REMOTE CONTROLLER OPERATION
CD
When the CD button is pressed, the buttons in
group +function as indicated in the table below.
These buttons can only be used when a Marantz CD
player is connected to the CD input jacks.
BUTTON NAME FUNCTION
Skips to the start of the current
track
ESkips to the next track
Stops playback
2Starts playback
Pauses a disc that's playing
P.SCAN/A.TUNE Not for use
MENU Not for use
3/TUNE+ Not for use
4/TUNE- Not for use
1/PRESET- Not for use
2/PRESET+ Not for use
ENTER Not for use
CAT Not for use
BAND Not for use
0-9 Inputs the numeric
CLEAR Not for use
MEMO Not for use
DISPLAY Not for use
PTY Not for use
F.DIRECT Not for use
T.MODE Selects the sound mode
TUNER
When the TUNER button is pressed, the buttons in
group +function as indicated in the table below.
These buttons can only be used when a Marantz
tuner is connected to the TUNER input jacks.
BUTTON NAME FUNCTION
Not for use
ENot for use
Not for use
2Not for use
Not for use
P.SCAN/A.TUNE Starts preset scan
MENU Not for use
3/TUNE+ Tuning (frequency) increase
4/TUNE- Tuning (frequency) decrease
1/PRESET- Preset stations forward feed
2/PRESET+ Preset stations backward feed
ENTER Not for use
CAT Not for use
BAND Selects the band
0-9 Inputs the numeric
CLEAR Clears the inputting
MEMO Enters the tuner preset memory
numbers
DISPLAY Selects the display mode in
RDS
PTY
Displays the programme type
information of the current
station
F.DIRECT Selects the "frequency direct
input"
T.MODE Selects the auto stereo mode or
mono mode
DVD
When the DVD button is pressed, the buttons in
group +function as indicated in the table below.
These buttons can only be used when a Marantz
DVD player is connected to the AUX/DVD input
jacks.
BUTTON NAME FUNCTION
Skips to the start of the current
track or chapter
ESkips to the next track or
chapter
Stops playback
2Starts playback
Pauses a disc that's playing
P.SCAN/A.TUNE Not for use
MENU Displays a DVD disc menu
3/TUNE+ Move the cursor upward
4/TUNE- Move the cursor downward
1/PRESET- Move the cursor leftward
2/PRESET+ Move the cursor rightward
ENTER Selects the current menu option
CAT Not for use
BAND Not for use
0-9 Inputs the numeric
CLEAR Not for use
MEMO Not for use
DISPLAY Displays the disc playback
information
PTY Not for use
F.DIRECT Not for use
T.MODE Not for use
TAPE
When the RECORDER 2 (TAPE) button is pressed,
the buttons in group +function as indicated in the
table below. These buttons can only be used when a
Marantz tape deck is connected to the RECORDER
2 (TAPE) jacks.
BUTTON NAME FUNCTION
Fast backward
EFast forward
Stops playback
2Starts playback
Pauses a tape that's playing
P.SCAN/A.TUNE Not for use
MENU Not for use
3/TUNE+ Not for use
4/TUNE- Not for use
1/PRESET- Not for use
2/PRESET+ Not for use
ENTER Not for use
CAT Not for use
BAND Not for use
0-9 Not for use
CLEAR Resets counter
MEMO Not for use
DISPLAY Not for use
PTY Not for use
F.DIRECT Not for use
T.MODE Not for use
13
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERS
TROUBLESHOOTING
ENGLISH
TROUBLESHOOTING
ABOUT THE PROTECTIVE CIRCUIT
This unit is equipped with a protective circuit to
protect the amplifier circuits and speaker system
against damage.
If the protective circuit is activated, the sound is
instantly muted.
In this case, either the MUTE indicator flashes, or
the STANDBY indicator above the POWER ON/OFF
button flashes.
AT POWER ON
For about 8 seconds after the power is turned on,
the protective circuit is activated muting the sound
togive the amplifier circuits time to stabilize. Once
the amplifier circuits stabilize, the protective circuit
releases and audio is enabled.
IN THE EVENT OF OVERCURRENT
The protective circuit is activated if current exceeding
a certain level is detected, which can happen if
excessive signal flow is input to the amplifier or if
the unit is connected to a speaker system of less
than 4Ωimpedance. The protective circuit is also
activated if a speaker cable shorts.
In these cases, the MUTE indicator flashes, and
the volume is automatically reduced. Approximately
15 seconds later the protective circuit is released,
therefore the volume needs readjusting to continue
normal use.
Moreover,iftheovercurrentcontinues,theamplifier’s
power shuts OFF and the STANDBY indicator above
the POWER ON/OFF button flashes.
IF EXCESSIVE ULTRA-BASS SIGNALS ARE INPUT
The protective circuit is also activated if ultra-
bass signals that exceed the base signal range
settings are input. In this case, the MUTE indicator
flashes, and the volume is automatically reduced.
Approximately 15 seconds later, the protective
circuit is released, therefore the volume needs
readjusting to continue normal use. If excessive
ultra-bass signal input continues or if DC voltage
is detected due to trouble with the amplifier, the
power shuts OFF and the STANDBY indicator above
the POWER ON/OFF button flashes.
IF THE MAIN-AMPLIFIER OVERHEATS
The protective circuit is activated if the temperature
of the main-amplifier section rises above a certain
level, which can happen if the amplifier is continually
used with excessive signal flow being input into
it. The protective circuit is also activated when
the set operating temperature is exceeded, which
can happen if the vents on top of the amplifier are
covered, or if the amplifier is installed on a cramped
audio rack. In these cases, the MUTE indicator
flashes, and the volume is automatically reduced.
Approximately 15 seconds later, the protective
circuit is released, therefore the volume needs
readjusting to continue normal use.
If the temperature does not sufficiently lower
within a certain amount of time after the protective
circuit activation, the power shuts OFF and the
STANDBY indicator above the POWER ON/OFF
button flashes.
IN THE EVENT OF AMPLIFIER TROUBLE
The protective circuit is activated and the power is
automatically shut OFF if an abnormality is detected
in the power circuit. The same happens if the main
fuse inside the amplifier blows. In these cases, the
STANDBY indicator above the POWER ON/OFF
button flashes.
In cases as mentioned above, immediately
disconnect the power cord, and contact the place of
purchase, your nearest Marantz dealer, our customer
service center, or our repair service center.
BEFORE CONSIDERING IT AS A FAILURE
In case of trouble with this component, first check the following before calling for service.
What seems to be a serious malfunction is often due to a simple operation mistake.
If the trouble is not fixed after making the following checks, contact the place of purchase, your nearest
Marantz dealer, our customer service center, or our repair service center.
Phenomenon Causes Actions
Power is not supplied.
The power cable is disconnected. Check the power cable connections.
The unit is in STANDBY mode.
Turn the INPUT SELECTOR knob or
press the POWER ON button on the
remote controller.
The protection circuit is activated.
If the STANDBY indicator is flashing,
turn the power OFF, then ON again
after 1 minute or more.
Power is supplied, but no
sound is heard from the
speaker.
Speaker connection is incomplete. Check the speaker cable connection.
Input cord connection is incomplete. Check the input cable connection.
The INPUT SELECTOR knob is not set
correctly.
Set the INPUT SELECTOR knob
properly.
The VOLUME knob is set to minimum. Turn the VOLUME knob to the proper
level.
UThe SPEKAERS knob is set to OFF.
USetting of the SPEAKERS knob is
incorrect.
Set the SPEAKERS knob properly
according to the SPEAKER terminals
to which the speakers are connected.
Setting of the POWER AMP DIRECT
button is incorrect.
Set the POWER AMP DIRECT button
properly.
The MUTE function is activated.
If the MUTE indicator is lit, press the
MUTE button on the remote controller
to release the MUTE function.
Sound is heard from left or
right speakers only.
Speaker connection is incomplete. Check the speaker connections.
Setting of the BALANCE knob is
incorrect. Set the BALANCE knob properly.
Left and right channels are
reversed.
Connection of left and right speaker
cords or input cords is reversed. Make connections properly.
Noise occurs during record
playing.
Grounding connection from the record
player is improper.
Check the connections to the PHONO
GND terminal.
Connection to the PHONO jacks is
incorrect.
Check the connection to the PHONO
input jacks.
A TV set or the like placed too close to
the record player may affect the sound.
Place the TV set or record player in
another position.
Howling occurs when sound
volume is increased during
record playing.
Speakers are placed too close to the
record player.
Place the speakers away from the
record player as far as possible.
The record player is placed on a rack or
floor that is easily vibrated.
If an insulating pad is not supplied with
the record player, use an insulating pad
available in the market.
14
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERSOTHERS
ENGLISH
OTHERS
SPECIFICATIONS & DIMENSIONAL DRAWINGS
Power output (20Hz – 20kHz simultaneous drive
of both channels)
....................................70W x 2 (8Ωload)
..................................100W x 2 (4Ωload)
Total harmonic distortion (20Hz – 20kHz
simultaneous drive of both channels, 8Ωload)
........................................................ 0.02%
Output band width (8Ωload, 0.05%)
...............................................5Hz – 60kHz
Frequency response (CD, 1W, 8Ωload)
................................. 5Hz – 100kHz ±3dB
Dumping factor (8Ωload, 20Hz – 20kHz)......100
Input sensitivity/Input impedance
PHONO (MM)............................... 2mV/47kΩ
CD, LINE, TUNER, AUX/DVD, RECORDER
............................................ 200mV/20kΩ
POWER AND DIRECT IN ..............1.6V/20kΩ
Output voltage/Output impedance
PRE OUT........................................1.6V/600Ω
Maximum allowable PHONO input level (1kHz)
MM ......................................................100mV
RIAA deviation (20Hz ~ 20kHz) ........ ±0.5dB
S/N (IHF-A, 1W, 8Ωload)
PHONO (MM) ......................................... 87dB
CD, LINE, TUNER, AUX/DVD, RECORDER
.......................................................... 90dB
POWER AMP DIRECT IN ..................... 106dB
Tone control
Bass (50Hz)......................................... ±10dB
Treble (20kHz) .................................... ±10dB
Power requirement....................... AC 120V 60Hz
Power consumption
(UL60065) .............................................. 200W
Standby power consumption .....................0.3W
Accessories
Remote controller
.........................................1
AAA batteries................................................2
Detachable AC power cable ........................1
Maximum outer dimensions (Amplifier)
Width .......................... 17-5/16 inch (440mm)
Height ......................... 5-1/8 inch (129.8mm)
Depth ................................. 15 inch (379mm)
Weight (Amplifier).............. 26.5 lbs (12.0kg)
Specifications subject to change without prior
notice.
(unit : inch (mm))
INTEGRATED AMPLIFIER PM8003
15 (379)
13-3/4 (328.5)
3/4
(17.5)
5-1/8 (129.8)
4-1/2 (112)
17-5/16 (440)
1-3/8
(33)
41/64
(16.3)
15
NAMES AND
FUNCTIONS
BASIC
CONNECTIONS
BASIC
OPERATION
ADVANCED
CONNECTIONS
REMOTE CONTROLLER
OPERATION
TROUBLESHOOTING
OTHERSOTHERS
ENGLISH
CLEANING OF EQUIPMENT EXTERNAL
SURFACES
The exterior finish of your unit will last indefinitely
with proper care and cleaning, Never use scouring
pads, steel wool, scourging powders or harsh
chemical agents (e.g., lye solution), alcohol, thinner,
benzine, insecticide or other volatile substances as
these wil mar the finish of the equipment. Likewise,
never use cloths containing chemical substances. If
the equipment get dirty, wipe the external surfaces
with a soft, lint-free cloth.
If the equipment becomes heavily soiled:
Udilute some
washing up liquid
in water, in a
ratio of one part
detergent to six
parts water.
Udip a soft, lint
free in the
solution and
wring the it is
damp.
Uwipe the equipment with the damp cloth.
Udry the equipment by wiping it with a dry cloth.
USING HEADPHONES
If the volume in the headphones is too high, it may
injure your ears. Do not set the sound volume too
high.
REPAIRS
Only the most competent and qualified service
technicians should be allowed to service the
factory-trained warranty station personnel have
the knowledge and special facilities needed for
repair and calibration of this precision equipment.
After the warranty period has expired, repairs will
be performed for a charge if the equipment can be
returned to normal operation.
In the event of difficulty, refer to your dealer or write
directly to the nearest location to you that is listed
on the Marantz Authorized Service Station list. If
writing, please include the model and serial number
of the equipment together with a full description of
what you think is abnormal about the equipment’s
behaviour.
OTHERS
You can find your nearest authorized distributor or dealer on our website.
is a registered trademark.
Printed in China 08/2008 541110099026M mzh-d
lDa.antz~
Please
note
that
there
was
a
printing
error
in
the
instruction
book
as
it
relates
to
the
number
you
should
call
for
customer
service.
The
correct
number
is:
(201) 762-6666
Please make
note
of
this
in
your
instruction
book
for
future
reference.
Thank
you
again
for
purchasing
this
Marantz Product. We
sincerely
appreciate
your
patronage.
lDa.antz~
Other manuals for PM8003
4
Table of contents
Other Marantz Amplifier manuals
Marantz
Marantz PM6002 User manual
Marantz
Marantz PM-11S1 User manual
Marantz
Marantz PM8200 User manual
Marantz
Marantz PM17A/F1N User manual
Marantz
Marantz 50 User manual
Marantz
Marantz PM4200 User manual
Marantz
Marantz PM5004 User manual
Marantz
Marantz 240 User manual
Marantz
Marantz PM6003/N1SG User manual
Marantz
Marantz SR2100/C1S User manual
Marantz
Marantz 2440 User manual
Marantz
Marantz PM7000 User manual
Marantz
Marantz 2235B User manual
Marantz
Marantz PM17A/F1N User manual
Marantz
Marantz PM7000 User manual
Marantz
Marantz PM-11S3 User manual
Marantz
Marantz SC-8 User manual
Marantz
Marantz PM8200 User manual
Marantz
Marantz PM8004 User manual
Marantz
Marantz PM-17mk II User manual
