Marantz SR6012 User manual

.
AV Surround Receiver
SR6012
Owner’s Manual
Contents Connections Playback Settings Tips Appendix
1
Front panel Display Rear panel Remote Index

Accessories 8
Inserting the batteries 9
Operating range of the remote control unit 9
Features 10
High quality sound 10
High performance 11
Easy operation 15
Part names and functions 16
Front panel 16
Display 20
Rear panel 22
Remote control unit 26
Connections
Speaker installation 30
Connecting speakers 37
Before connecting speakers 37
Speaker configuration and “Amp Assign” settings 41
Connecting 5.1-channel speakers 43
Connecting 7.1-channel speakers 44
Connecting 9.1-channel speakers 48
Connecting 11.1-channel speakers 55
Connecting 7.1-channel speakers: Bi-amp connection of front
speakers 59
Connecting 7.1-channel speakers: Second pair of front speakers 60
Connecting multi-zone speakers 61
Connecting a TV 64
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) 65
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) 66
Connection 3 : TV equipped without an HDMI connector 67
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Connecting a playback device 68
Connecting a set-top box (Satellite tuner/cable TV) 69
Connecting a DVD player or Blu-ray Disc player 70
Connecting a video camcorder or game console 71
Connecting a turntable 72
Connecting a device with a multi-channel output connector 73
Connecting a USB memory device to the USB port 74
Connecting an FM/AM antenna 75
Connecting to a home network (LAN) 77
Wired LAN 77
Wireless LAN 78
Connecting an external control device 79
REMOTE CONTROL jacks 79
DC OUT jack 80
Connecting the power cord 81
Playback
Basic operation 83
Turning the power on 83
Selecting the input source 83
Adjusting the volume 84
Turning off the sound temporarily (Muting) 84
Playback a DVD player/Blu-ray Disc player 84
Playing a USB memory device 85
Playing files stored on USB memory devices 86
Listening to music on a Bluetooth device 89
Playing music from Bluetooth device 90
Pairing with other Bluetooth devices 91
Reconnecting to this unit from a Bluetooth device 92
Listening to FM/AM broadcasts 93
Listening to FM/AM broadcasts 94
Tuning in by entering the frequency (Direct Tune) 95
Changing the tune mode (Tune Mode) 96
Tuning in to stations and presetting them automatically (Auto
Preset Memory) 96
Presetting the current broadcast station (Preset Memory) 97
Listening to preset stations 97
Specify a name for the preset broadcast station (Preset Name) 98
Skipping preset broadcast stations (Preset Skip) 99
Cancelling Preset Skip 100
Listening to Internet Radio 101
Listening to Internet Radio 102
Playing back files stored on a PC or NAS 103
Playing back files stored on a PC or NAS 104
Contents Connections Playback Settings Tips Appendix
3
Front panel Display Rear panel Remote Index

Getting the HEOS App 107
HEOS Account 108
Playing from streaming music services 109
Listening to the same music in multiple rooms 112
AirPlay function 116
Playing songs from your iPhone, iPod touch or iPad 117
Playing iTunes music with this unit 117
Selecting multiple speakers (devices) 118
Perform iTunes playback operations with the remote control unit
of this unit 118
Spotify Connect function 119
Playing Spotify music with this unit 119
Convenience functions 120
Adding to HEOS Favorites 121
Playing back HEOS Favorites 121
Deleting a HEOS Favorites 122
Adjusting the volume of each channel to match the input source
(Channel Level Adjust) 123
Adjusting the tone (Tone) 124
Displaying your desired video during audio playback (Video
Select) 125
Adjusting the picture quality for your viewing environment (Picture
Mode) 126
Playing the same music in all zones (All Zone Stereo) 127
Selecting a sound mode 128
Selecting a sound mode 129
Direct playback 130
Pure Direct playback 130
Auto surround playback 131
Description of sound mode types 132
Sound mode that can be selected for each input signal 136
HDMI Control function 140
Setting procedure 140
Smart Menu function 141
Sleep timer function 143
Using the sleep timer 144
Smart select function 145
Calling up the settings 146
Changing the settings 147
Panel lock function 148
Disabling all key button operations 148
Disabling all button operations except VOLUME 148
Canceling the Panel lock function 149
Remote lock function 150
Disabling the sensor function of the remote control unit 150
Enabling the remote sensor function 150
Playback in ZONE2 (Separate room) 151
Connecting ZONE2 151
Playback in ZONE2 153
Contents Connections Playback Settings Tips Appendix
4
Front panel Display Rear panel Remote Index

Settings
Menu map 155
Menu operations 159
Audio 160
Dialog Level Adjust 160
Subwoofer Level Adjust 160
Surround Parameter 161
M-DAX 164
Audio Delay 165
Volume 166
Audyssey®167
Graphic EQ 170
Video 172
Picture Adjust 172
HDMI Setup 174
Output Settings 179
On Screen Display 182
4K Signal Format 183
TV Format 185
Inputs 186
Input Assign 186
Source Rename 188
Hide Sources 189
Source Level 189
Input Select 190
Speakers 191
Audyssey® Setup 191
Procedure for speaker settings (Audyssey® Setup) 193
Error messages 199
Retrieving Audyssey® Setup settings 201
Manual Setup 202
Amp Assign 202
Speaker Config. 208
Distances 212
Levels 214
Crossovers 215
Bass 216
Front Speaker 217
Network 218
Information 218
Connection 218
Wi-Fi Setup 219
Settings 221
Network Control 222
Friendly Name 223
Diagnostics 223
Contents Connections Playback Settings Tips Appendix
5
Front panel Display Rear panel Remote Index

HEOS Account 225
You have not signed in 225
You have already signed in 225
General 226
Language 226
ECO 226
ZONE2 Setup 229
Zone Rename 231
Smart Select Names 231
Trigger Out 232
Front Display 232
Firmware 233
Information 236
Usage Data 237
Save & Load 238
Setup Lock 238
Limiting the operating zone with the remote control 239
Tips
Tips 241
Troubleshooting 243
Power does not turn on / Power is turned off 244
Operations cannot be performed through the remote control unit 245
Display on this unit shows nothing 245
No sound comes out 246
Desired sound does not come out 247
Sound is interrupted or noise occurs 249
No video is shown on the TV 250
The menu screen is not displayed on the TV 252
AirPlay cannot be played back 253
USB memory devices cannot be played back 254
Bluetooth cannot be played back 255
The Internet radio cannot be played back 256
Music files on PC or NAS cannot be played back 257
Various online services cannot be played 258
The HDMI Control function does not work 258
Cannot connect to a wireless LAN network 259
When using HDMI ZONE2, the devices does not function properly 260
Update/upgrade error messages 261
Resetting factory settings 262
Resetting network settings 263
Contents Connections Playback Settings Tips Appendix
6
Front panel Display Rear panel Remote Index

Appendix
About HDMI 264
Video conversion function 267
Playing back a USB memory devices 269
Playing back a Bluetooth device 270
Playing back a file saved on a PC or NAS 271
Playing back Internet Radio 272
Personal memory plus function 272
Last function memory 272
Sound modes and channel output 273
Sound modes and surround parameters 275
Types of input signals, and corresponding sound modes 278
Explanation of terms 281
Trademark information 289
Specifications 291
Index 297
License 300
Contents Connections Playback Settings Tips Appendix
7
Front panel Display Rear panel Remote Index

Thank you for purchasing this Marantz product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
Quick Start Guide Safety Instructions Notes on radio Warranty
(for USA/for CANADA)
Cable labels
Power cord FM indoor antenna AM loop antenna Sound calibration
microphone
Sound calibration
microphone stand
Remote control unit
(RC035SR)
R03/AAA batteries External antennas for
Bluetooth/wireless
connectivity
Contents Connections Playback Settings Tips Appendix
8
Front panel Display Rear panel Remote Index

Inserting the batteries
1Remove the rear lid in the direction of the arrow and
remove it.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
30°
Approx. 23 ft/7 m
Contents Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Features
High quality sound
0With discrete circuit technology, the power amplifier provides
identical quality for all 9-channels (150 Watts x 9-channels)
For optimum realism and stunning dynamic range, the power amplifier
section features discrete power devices (not integrated circuitry).
By using high current, high power discrete power devices, the amplifier
is able to easily drive high quality speakers.
0Current feedback amplifier
This unit uses a high-speed current feedback amplifier circuit for its
preamplifier so that signals from a Blu-ray Disc player and other
equipment that support high-definition audio formats can be amplified
with high fidelity. The high-speed current feedback amplifier also
reproduces a natural sound space.
0Dolby Atmos (v p. 282)
This unit is equipped with a decoder that supports Dolby Atmos audio
format. The placement or movement of sound is accurately reproduced
by the addition of overhead speakers, enabling you to experience an
incredibly natural and realistic surround sound field.
0DTS:X (v p. 284)
This unit is equipped with the DTS:X decoder technology. DTS:X
brings the home theater experience to new heights with its immersive
object based audio technology which removes the bounds of channels.
The flexibility of objects allows for sound to be scaled large or small
and moved around the room with greater accuracy than ever before
leading to a richer immersive audio experience.
0Audyssey LFC™ (Low Frequency Containment) (v p. 169)
Audyssey LFC™ solves the problem of low frequency sounds
disturbing people in neighboring rooms or apartments. Audyssey
LFC™ dynamically monitors the audio content and removes the low
frequencies that pass through walls, floors and ceilings. It then applies
psychoacoustic processing to restore the perception of low bass for
listeners in the room. The result is great sound that no longer disturbs
the neighbors.
0Discrete subwoofers and Audyssey Sub EQ HT™ (v p. 192)
The unit has two subwoofer output capability and can adjust the level
and delay for each subwoofer individually.
Audyssey Sub EQ HT™ makes the integration seamless by first
compensating for any level and delay differences between the two
subwoofers and then applying Audyssey MultEQ® XT32 to both
subwoofers together for improved deep bass response and detail.
Contents Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index

High performance
04K 60Hz input/output supported
.
When 4K Ultra HD (High Definition) is used, an input/output speed of 60
frames per second (60p) is achieved for video signals. When connected
to 4K Ultra HD and 60p video signal input compatible TV, you can enjoy
the sense of realism only available from high-definition images, even
when viewing fast-moving video.
This unit also supports image processing for 4K 60p, 4:4:4 and 24-bit
videos. By processing the video at the original resolution, this unit lets
you enjoy flawless, high-definition picture quality.
This unit also supports HDR (High Dynamic Range) and BT.2020 wide
color gamut.
0HDCP 2.2
This unit is compatible with HDCP 2.2 copyright protection standard.
0Digital video processor upscales analog video signals (SD
resolution) to HD (720p/1080p) and 4K (v p. 181)
.
4K
Up scaling
Up to 1080p
This unit is equipped with a 4K video upscaling function that allows
analog video or SD (Standard Definition) video to be output via HDMI at
4K (3840 × 2160 pixels) resolution. This function enables the device to
be connected to a TV using a single HDMI cable, and produces high
definition images for any video source.
0Equipped with HDMI ZONE2 output (v p. 151)
The ZONE2 multi-room output includes an HDMI output that lets you
enjoy a different A/V source in that room, with another program playing
in the main room.
Contents Connections Playback Settings Tips Appendix
11
Front panel Display Rear panel Remote Index

0HDMI connections enable connection to various digital AV
devices (8 inputs, 3 outputs)
.
83
OutIn
For connection to a broad range of digital sources, this unit features 8
HDMI inputs, including 1 on the front panel that lets you quickly and
conveniently connect a camcorder, game console or other HDMI-
equipped device. There are dual HDMI outputs for the main room, and a
third HDMI output for ZONE2.
0The device is equipped with a AirPlay® function in addition to
network functions such as Internet radio etc. (v p. 116)
.
You can enjoy a wide variety of content, including listening to Internet
Radio, playing audio files stored on your PC.
This unit also supports Apple AirPlay which lets you stream your music
library from an iPhone®, iPad®, iPod touch® or iTunes®.
0Playback of DSD and FLAC files via USB and networks
This unit supports the playback of high resolution audio formats such as
DSD (5.6 MHz) and FLAC 192 kHz files. It provides high quality
playback of high resolution files.
Contents Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

0Wireless connection with Bluetooth devices can be carried out
easily (v p. 89)
.
You can enjoy music simply by connecting wirelessly with your
smartphone, tablet, PC, etc.
0Multi-Room audio (v p. 127)
.
GMAIN ZONEHGZONE2H
You can select and play back the respective inputs in MAIN ZONE and
ZONE2.
In addition, when the All Zone Stereo function is used, the music being
played back in MAIN ZONE can be enjoyed in all the zones at the same
time. This is useful when you want to let the BGM propagate throughout
the whole house.
0Energy-saving design
This unit is equipped with an ECO Mode function that allows you to
enjoy music and movies while reducing the power consumption during
use, and also an auto-standby function that automatically turns off the
power supply when the unit is not in use. This helps reduce
unnecessary power use.
Contents Connections Playback Settings Tips Appendix
13
Front panel Display Rear panel Remote Index

0Compatible with the “Marantz 2016 AVR Remote” Appz for
performing basic operations of the unit with an iPad, iPhone or
Android™ devices (Google, Amazon Kindle Fire)
.
Along with many new features, the graphics and user interface have
been completely overhauled. The new app gives you full control of the
AVR as well as access to its setup menu for detailed adjustments from
your phones or tablets. “Marantz 2016 AVR Remote” App also gives
you quick access to the receiver's status display, option menus,
Marantz Blu-ray Disc player control, and online owner's manual for your
convenience.
zDownload the appropriate “Marantz 2016 AVR Remote” App for your iOS or
Android devices. This unit needs to be connected to the same LAN or Wi-Fi
(wireless LAN) network that the iPhone or iPod touch is connected to.
0HEOS provides streaming music from your favorite online music
sources
.
HEOS wireless multi-room sound system that enables you to enjoy your
favorite music anywhere and everywhere around your home. By utilizing
your existing home network and the HEOS App (available for iOS,
Android and Amazon devices), you can explore, browse, and play
music from your own music library or from many online streaming music
services.
When multiple HEOS devices are connected to the same network,
HEOS devices can be grouped to play back the same music on all
devices simultaneously, or different music can be played on each
separate HEOS device.
Contents Connections Playback Settings Tips Appendix
14
Front panel Display Rear panel Remote Index

Easy operation
0“Setup Assistant” provides easy-to-follow setup instructions
First select the language when prompted. Then simply follow the
instructions displayed on the TV screen to set up the speakers, network,
etc.
0Easy to use Graphical User Interface
This unit is equipped with a Graphical User Interface for improved
operability.
Contents Connections Playback Settings Tips Appendix
15
Front panel Display Rear panel Remote Index

Part names and functions
Front panel
.
u
e ytrq w
For details, see the next page.
Contents Connections Playback Settings Tips Appendix
16
Front panel Display Rear panel Remote Index

.
eytrq w
u
APower operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 83)
BPower indicator
This is lit as follows according to the power status:
0Off: Power on
0Red: Normal standby
0Orange:
0When “HDMI Pass Through” is set to “On” (v p. 174)
0When “HDMI Control” is set to “On” (v p. 176)
0When “Network Control” is set to “Always On” (v p. 222)
CINPUT SELECTOR knob
This selects the input source. (v p. 83)
DDisplay
This displays various pieces of information. (v p. 20)
ERemote control sensor
This receives signals from the remote control unit. (v p. 9)
FVOLUME knob
This adjusts the volume level. (v p. 84)
GDoor
When you are using buttons and/or connectors behind the door, press
the bottom of the door to open it. Be careful not to catch your fingers
when closing the door.
.
Contents Connections Playback Settings Tips Appendix
17
Front panel Display Rear panel Remote Index

With the door open
.
qwert y u i o Q0
APURE DIRECT button
This switches the sound mode between Direct, Pure Direct and Auto
surround.
0“Direct playback” (v p. 130)
0“Pure Direct playback” (v p. 130)
0“Auto surround playback” (v p. 131)
BPURE DIRECT indicator
This lights when the “Pure Direct” mode is selected as the sound mode.
(v p. 130)
CM-DAX button
This switches the M-DAX mode. (v p. 164)
DM-DAX indicator
This lights when the M-DAX mode is selected. (v p. 164)
EZONE2 ON/OFF button
This turns the power of ZONE2 (separate room) on/off. (v p. 153)
FZONE2 SOURCE button
This selects the input source for ZONE2. (v p. 153)
GTuner preset channel buttons
(TUNER PRESET CH +, –)
These select preset broadcast stations. (v p. 97)
HDIMMER button
Each press of this switches the brightness of the display. (v p. 232)
ISTATUS button
Each press of this switches the status information that is shown on the
display.
JSOUND MODE button
Switching the sound mode. (v p. 128)
Contents Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

.
Q11 Q2 Q3 Q4 Q5
KHeadphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the PRE OUT
connectors.
NOTE
0To prevent hearing loss, do not raise the volume level excessively when using
headphones.
LSETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v p. 194)
MUSB port (T)
This is used to connect USB storages (such as USB memory devices).
(v p. 74)
NAUX1-HDMI connector
This is used to connect HDMI output compatible devices such as video
camcorders and game consoles. (v p. 71)
OAUX1 INPUT connectors
Used to connect analog output compatible devices such as video
camcorders and game consoles. (v p. 71)
Contents Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

Display
The input source name, sound mode, setting values and other information are displayed here.
oStandard display
.
q w
AVolume indicator
BInput source indicator
The currently selected input source name is displayed.
If the input source name has been changed using “Source Rename” in
the menu, the input source name after the change is displayed.
(v p. 188)
oTuner display
These light up according to the reception conditions when the input
source is set to “Tuner”.
.
er
CLights up when the broadcast is properly tuned in.
DIn the FM mode, this lights up when receiving stereo broadcasts.
Contents Connections Playback Settings Tips Appendix
20
Front panel Display Rear panel Remote Index
