mariel Idea Tronic User manual

INSTRUCTIONS FOR USE

Index
Description of the device 4
Components 5
Connection of the base to the vacuum pump 6
Switching on the equipment 7
Language and/or contrast modication 7
Connection of 1 - 2 kg. cylinders 8
Connection of 5 - 10 - 12 - 40 kg. cylinders 9
Choice of refrigerant uid - BT, TN, AC and charge method 10
System check up 11
Vacuum 11
Charge
Charge by weight 12
Charge by pressure 13
Refrigerant recovery procedure 14
Check of special systems 15
Display light 16
Switching o the equipment 16
Batteries replacement 16
Decommissioning / Waste disposal 17
Warranty 17
Optional 18 - 19
3

4
DESCRIPTION OF THE DEVICE
IDEA TRONIC is an “integrated” device composed by two connected parts, a base and a
hand-held equipment which, once connected to any refrigerating or air-conditioning system
will allow you, without more disconnecting, to: 1) RECOVER THE REFRIGERANT GAS,
2) MAKE THE VACUUM, 3) CHECK FOR POSSIBLE LEAKS, 4) MAKE THE CHARGE
WITH GRAM ACCURACY, 5) CHECK IF THE CARRIED OUT CHARGE IS CORRECT.
1. SYSTEM CONNECTION OR
2. EXTENSION
3. VACUUM TAP
4. GAS TAP
5. VACUUM GREEN LED
6. VACUUM RED LED
12. FORWARD KEY
13. BACKWARD KEY
15. BASE CONNECTION
14. THERMOMETER
SENSOR
10. DISPLAY LIGHT
11. ENTER KEY
9. PROGRESS PRESSURES
BAR
8. DISPLAY
7. SWITCH On / O

1) 1/4” - 5/16” adapter
for R410A
4) 20 cm. hose 1/4”M - 1/4”F for
R22 - R422B - R407C - R404A
- R134a
5) 20 cm. hose, 1/4”M - 5/16”F
R22 - R422B - R407C - R404A - R134a
6) Connecting hose for vacuum
pump
7) Batteries mod. AA
3) Nipple for cylinders of
5 - 10 - 12 - 40 Kg.
2) 1/4” - 1/4” adapter for
R22 - R422B - R407C - R404A
- R134a
5
Q.ty DESCRIPTION Pic. CODE
1Complete device, 2 parts: base / hand-held equipment IDEAT
1Brass adapter 5/16” F - 1/8“ M. - with aerosol M. connection 1ADATTATORI5/16
1Brass adapter 1/4” F - 1/8“ M. - with aerosol M. connection 2ADATTATORI
1Nipple 1/4” M - 1/4” M. for the connection of 5 - 10 - 12 - 40 kg. cylinders 3MA30
1Connecting hose of 20 cm., 1/4” sae M. - 5/16” F. 4 D20008
1Connecting hose of 20 cm., 1/4” sae M. - 1/4” sae F 5 D20007
1Yellow connecting hose for vacuum pump 6 D20005
4Battery of 3 Volts mod. AA 7D70001
COMPONENTS OF THE KIT

CONNECTION OF THE BASE TO THE VACUUM PUMP
6
1 - Screw the 1A nut (point 6) on the vacuum pump connecting port.
2 - Put the bracket (point 5) on the base of the 1A nut and screw it with 1B nut +
washer (point 4).
3 - Connect the yellow hose (point 1) to the 1A nut and to the vacuum connecting port
of the Idea Tronic (point 2).
4 - Select the appropriate reduction before screwing the cylinder (check page 8).
5. Bracket
6. 1A nut
Example of an appropriate connection
4. 1B nut + washer
3. Cylinder connecting port
(use the adapter if necessary)
1. Hose for vacuum
pump connection
2. Vacuum port of Idea
Tronic base

7
SWITCHING ON OF THE EQUIPMENT
Move the power switch to position “1” and wait for instructions that appear on the
display (starting screen).
LANGUAGE AND/OR CONTRAST MODIFICATION
If you need to change the language or to increase / decrease the display contrast, press
the two keys with icons “ “ contemporaneously and all available languages will appear
on the display.
Slide the arrow keys “ “ until the desired choice has reached, then press the “en key to
validate the preference. e same procedure must be made to increase or decrease the
brightness of the display, dealing on the bar that appears on the display. en press “ente
key to switch to the second screen, that is the choice of refrigerant fluid and charge
(selectable in charge by weight or charge by pressure).
OFFON

CONNECTION OF 1 - 2 KG. CYLINDERS
NB: Connect the appropriate adapter
R134 - R600a: do not connect any adapter.
R22 - R422B - R407C - R404A : 1/4” F. Sae adapter
R410A : 5/16” SAE F. adapter
8

CONNECTION OF 5 - 10 - 12 - 40 KG. CYLINDERS
Preparation of the base
1. Screw the 1/4” F. Sae
adapter for 1 kg. cylinder to
the base
1. Double valve cylinder
2. Single valve cylinder
Use the cylinder in vertical position if
the valve has a dual output, Blue - Red.
In this case, connect the hose to the Red
output to use the refrigerant uid in the
liquid phase.
1. Open the gas tap
2. Turn the cylinder upside-down to use
the refrigerant uid in the liquid phase.
SUGGESTIONS FOR THE CHARGE BY PRESSURE PROCEDURE
If you use a cylinder bigger than 2 kg., the “charge by pressure” is recommended.
If you know the exact quantity to ll inside the system, it is possible to reduce the charging time,
using a 80 kg. scale (optional at page 18).
Aer vacuum procedure, open the GAS tap to make charge procedure without disconnecting
from the system.
It is at the operator discretion to keep the IDEA TRONIC switched on or switched o.
1. Screw the 1/4” M. Sae
nipple to the adapter
1. Connect the 1/4” Sae M.
hose to the cylinder
9

SCREEN 2
CHOICE OF REFR. FLUID – BT, TN, AC AND CHARGE METHOD
Set up the kind of refrigerant uid and the charge method, sliding the arrow keys “ “
and pressing “enteraer choosing the convenient option.
N.B.: for some refrigerant uids it is possible to select TN (positive temperature) suitable
for refrigeration cabinets for drinks etc., BT (negative temperature) suitable for domestic
refrigerators etc. or AC, suitable for air-conditioning systems.
You will then be asked to select the opportune charge method, it means by weight, if you
work with 1 or 2 kg. cylinders screwed on IDEA TRONIC, or by pressure, if you do not
know the quantity of refrigerant uid to ll inside the system and/or if you use cylinders
bigger than 2 kg.
SCREEN 3
MAIN MENU
In this screen you can select the type of operation
to be performed by sliding the arrow keys
Selections available:
1) System check
2) Vacuum
3) Charge
10
Use of 1 or 2 kg. cylinder Use of bigger cylinder

SYSTEM CHECK
In this screen you can analyze the state of the system on which you will operate; the
display will show the following options:
1) Adequate gas
2) Too much gas
3) Problems
N.B.: e system check procedure must be carried out with the system switched on
(compressor running) after having waited for a few minutes so that the internal
pressure has stabilized.
System check - Wait System check - Diagnosis
11
VACUUM
If you need to perform the vacuum procedure, slide the arrow keys “” up and down
and conrm the “VACUUM” option by pressing the “entkey.
Open the vacuum tap and switch on the pump, then press “ente key.
e electronic bar will start to empty out until reaching -0,8 Bar; aer that a green
LED will light up if any leak is detected and so you can set the desired time up to 60
minutes.
On the contrary, if the red LED lights up, it means that the system on which you are
working has some leaks. Press “entekey and go back to vacuum menu.
Switch o the system, repair the leak and repeat the process from the beginning.

CHARGE BY WEIGHT
If you selected the “charge by weight” option in “SCREEN 2”, proceed with the charge,
screwing the refrigerant uid cylinder on the holder of the IDEA TRONIC device.
Set up the refrigerant gas charge in grams which you need to ll inside the system, by sliding
the “ ” keys.
en press the “ent key and the empty electronic bar will appear on the display.
Open the refrigerant gas tap very slowly and the empty electronic bar will start to gradually
ll up until the preset quantity visible at the end of the bar is reached.
Guide the lling procedure with the hand and close the refrigerant gas tap quickly, avoiding
to release a greater quantity of uid than preset.
is charge procedure can be performed with the system o; anyway, if at some point you
are unable to ll the preset quantity (especially in small systems), you need to switch it on
for a few minutes.
N.B.: e refrigerant uid ends during the charge procedure. If by any chance the refrigerant
uid contained in the cylinder ends before nishing the charging procedure, the written
word “empty cylinder” will appear on the display.
Press enterkey and replace the cylinder. e system stores the refrigerant gas quantity already
lled, so complete the charge.
ATTENTION: the written word “empty cylinder” can also be shown if the refrigerant uid
does not enter inside the system. Switch on the compressor to guide the lling.
N.B.: Once the gas charge procedure has been completed, if you desire to “check the system”,
let the equipment running for at least 15 minutes, then proceed.
ATTENTION: ACCIDENTALLY TOUCHING THE REFRIGERANT CYLINDER DURING
THE CHARGE MAY INVALIDATE THE PROCEDURE DUE TO THE POSSIBLE RESETTING
OF THE DEVICE.
Picture 1:
Setting of the refrigerant
quantity
Picture 2: Press enter key with the
compressor running and open
the gas tap slowly
Picture 3: Monitor the progress
of the charge on the display.
Close the tap when the charge is
reached.
12

CHARGE BY PRESSURE
If you selected the “charge by pressure” option in “SCREEN 2”, aer entering in the
CHARGE MENU, connect the cylinder located on the floor to the IDEA TRONIC
device through a exible hose.
If the cylinder does not have the dip tube, perform the charge turning the container
upside-down to use the liquid refrigerant uid part.
Switch on the system to be repaired, ensure that the compressor is running, then press
the “ent key.
At this point, the empty electronic bar will appear on the display (Picture 1),
through which the operator will visualize the status of the system charge.
e procedure ends when the bar will be completely lled up.
Open the refrigerant gas tap very slowly (liquid phase) and close it as soon as the
electronic bar will be completely lled up and on the display will appear the “wait for
compensation” written words (Picture 2).
Keeping the refrigerant gas tap closed, let the equipment running for a few minutes to
allow the refrigerant uid to stabilize inside the system. In the meantime, with the
compressor running, the electronic bar will automatically empty from the top.
Repeat the operations for a few times until the Bars shown at the end of the electronic
bar are the same (or very close) to those indicated above xxx Bar Bar xxx
At this stage the IDEA TRONIC device will emit an acoustic signal indicating that the
performance is completed (Picture 3).
Use with 5 - 12 - 40 Kg. cylinders
Picture 1: Charge by
pressure progress
Picture 2: Pressure
compensations
Picture 3:
Aer each partial
charge, wait for pressure
compensations until
reaching the complete
charge.
13

RECOVERY OF THE REFRIGERANT FLUID
If you need to perform the refrigerant fluid recovery operation, you must use the 3
ways adapter supplied as optional (Picture 2), which connects the IDEA TRONIC
device, the recovery unit and the vacuum pump simultaneously.
Once connected all equipment, it will be then possible to perform all operations
without never disconnecting them; in fact, you will be able to operate both with one
or the other device, according to the opening direction of the tap. If the tap is
positioned at the center, the transfer will be closed from both sides.
Pitcure 1
14
Pitcure 2

CHECK OF SPECIAL SYSTEMS
Idea Tronic has been developed in order to
operate in traditional equipment and condi-
tions.
The diagnosis displayed on the screen,
ADEQUATE GAS, TOO MUCH GAS etc. has
been calculated on an average operating
process for each refrigerant fluid.
If the installation of the circuit has been
effected in abnormal conditions (poor
ventilation, different length of hoses, etc.),
the working pressures may be different,
altering the correct reading of the hand-held
equipment.
In these special situations it is possible to
connect a gauge for a double reading , as
shown to the side.
OPTIONAL check page 19
3 WAYS ADAPTER
R134a - R404A - R407C - R22 GAUGE
R410A GAUGE
GAUGE R600a
1
2
1
2
2
2
15

DISPLAY LIGHT
If, during all performances, the light of the display switches o, press the “bulb” key.
SWITCHING OFF OF THE EQUIPMENT
Move the power switch to position “0”.
NOTES
1. e device can be switched o at any stage of the performances. You need to start
again from the beginning aer switching it on.
2. IMPORTANT: do not leave any residue of refrigerant uid aer use to avoid danger
BATTERIES REPLACEMENT
e IDEA TRONIC device operates with n. 4 batteries
mod. AA situated in the reverse side.
When the batteries are going to deplete, in the display
starts to ash a visual symbol (Picture 1).
16
Depleting batteries symbol
(Picture 1)

WASTE DISPOSAL / DEMOLITION
e waste disposal or the demolition of the electronic hand-held KIT for the diagnosis
and maintenance of air-conditioning and refrigeration systems mod. IDEA TRONIC
must be made by skilled technicians.
WASTE DISPOSAL:
1 - Remove batteries;
2 - Drain all components from refrigerant uid residuals;
3 - Ensure that the hydraulic circuit and the exible hoses have been completely emptied
and drained.
DEMOLITION:
1 - Follow all operations described in “waste disposal” paragraph;
2 - Disassemble the dierent components of the IDEA TRONIC device taking care of
separating them for typology (e.g.: ferrous components, PVC, aluminium, etc.).NOTE:
For disposal, dispose this equipment in a facility that complies with local, state and
federal regulations.
WARRANTY
1 - e validity of the warranty is of n. one (01) year from the purchase order. e date
on the purchase document will attest the warranty.
2 - e warranty falls into decline in case of not proper use of the equipment (use of the
product on systems which are dierent from the refrigeration or air-conditioning and/
or in the event of electrical fault caused by the operator), or in case of unmistakable signs
of not authorized opening of the equipment.
3 - e equipment must be sent to the manufacturer or the authorized supplier for the
inspection and/or the eventual repairing FREE OF CHARGE.
4 - e warranty will be conrmed only aer the inspection of the equipment.
17

MPDRP2
45 l./min. double stage vacuum pump.
BM80C
portable electronic scale complete with ABS case.
Features:
Max. capacity: 80 kg.
Accuracy: +/- 5 g.
Weight: kg. 2,7
Dimensions: cm. 11 x 32 x 43
RE12A
Refrigerant recovery unit for domestic, industrial and
automotive air-conditioners.
Oil-less and air-cooled compressor; it recovers all
commonly used refrigerant fluids, including R410A.
Protection of the compressor in case of abnormalities and
excessive pressure.
OPTIONAL
18
Please check the catalogue for further information

MA28
3 ways valve for vacuum pump and recovy unit simultaneous
connection
MA29
3 ways adapter for gauge connection
D1004
Blue low pressure gauge (R600a)
D1006
Blue low pressure gauge (R410A)
D1008
Blue low pressure gauge
(R134a-R404A-R422B-R407C)
19

Manufactured by
MARIEL srl
Via Olubi, 5
28013 Gattico (NO) ITALY
www.mariel.it
