Silverado VS80 User manual

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
1
Table of Contents
1. One-Year Limited Warranty.............................................2
2.1 Conventions Used...................................................................... 5
2.2 Important Safety Instructions ..................................................... 5
4. Introduction ...................................................................9
4.1 About OBDII/EOBD.................................................................... 9
4.2 About the Code Reader ........................................................... 11
5. Data Review ................................................................26
6. OBDII/EOBD Diagnosis ................................................28
6.1 Reading DTCs ......................................................................... 31
6.2 Clearing DTCs ......................................................................... 32
6.3 Live Datastream....................................................................... 34
6.4 Viewing Freeze Data................................................................ 44
6.5 Reading I/M Readiness Status Data........................................ 45
6.6 O2 Monitor Test ....................................................................... 48
6.7 On-Board Monitor Test ............................................................ 49
6.8 Component Test ...................................................................... 52
6.9 Reading Vehicle Information.................................................... 53
6.10 Modules Present.................................................................... 55
7. Updating and Printing...................................................56
7.1 Updating the Code Reader ...................................................... 56
7.2 Printing..................................................................................... 58
8 Troubleshooting............................................................59
8.1 Error Message ......................................................................... 59
8.2 Code Reader Does Not Power Up........................................... 60
8.3 Battery Replacement ............................................................... 60

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
2
1. One-Year Limited Warranty
Subject to the conditions of this limited warranty, Silverado Company
(“Silverado”) warrants its customer that this product is free of defects in
material and workmanship at the time of its original purchase for a
subsequent period of one (1) year.
In the event this product fails to operate under normal use, during the
warranty period, due to defects in materials and workmanship, Silverado
will, at its sole option, either repair or replace the product in accordance
with the terms and conditions stipulated herein.
Terms and Conditions
1. If Silverado repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period. No charge will be made to the customer for replacement parts or
labor charges incurred by Silverado in repairing or replacing the
defective parts.
2. The customer shall have no coverage or benefits under this limited
warranty if any of the following conditions are applicable:
a) The product has been subjected to abnormal use, abnormal
conditions, improper storage, exposure to moisture or dampness,
unauthorized modifications, unauthorized repair, misuse, neglect,
abuse, accident, alteration, improper installation, or other acts which
are not the fault of Silverado, including damage caused by shipping.
b) The Product has been damaged from external causes such as
collision with an object, or from fire, flooding, sand, dirt, windstorm,
lightning, earthquake or damage from exposure to weather
conditions, an Act of God, or battery leakage, theft, blown fuse,
improper use of any electrical source, or the product was used in
combination or connection with other product, attachments, supplies
or consumables not manufactured or distributed by Silverado.
3. The customer shall bear the cost of shipping the product to Silverado.
And Silverado shall bear the cost of shipping the product back to the
customer after the completion of service under this limited warranty.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
3
4. Silverado does not warrant uninterrupted or error-free operation of the
product. If a problem develops during the limited warranty period, the
consumer shall take the following step-by-step procedure:
a) The customer shall return the product to the place of purchase for
repair or replacement processing; contact your local Silverado
distributor to get further information.
b) The customer shall include a return address, daytime phone number
and/or fax number, complete description of the problem and original
invoice specifying date of purchase and serial number.
c) The customer will be billed for any parts or labor charges not covered
by this limited warranty.
d) Silverado will repair the Product under the limited warranty within 30
days after receipt of the product. If Silverado cannot perform repairs
covered under this limited warranty within 30 days, or after a
reasonable number of attempts to repair the same defect, Silverado
at its option, will provide a replacement product or refund the
purchase price of the product less a reasonable amount for usage.
e) If the product is returned during the limited warranty period, but the
problem with the product is not covered under the terms and
conditions of this limited warranty, the customer will be notified and
given an estimate of the charges the customer must pay to have the
product repaired, with all shipping charges billed to the customer. If
the estimate is refused, the product will be returned freight collect. If
the product is returned after the expiration of the limited warranty
period, Silverado’ normal service policies shall apply and the
customer will be responsible for all shipping charges.
5. ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR FITNESS
FOR A PARTICULAR PURPOSE OR USE, SHALL BE LIMITED TO
THE DURATION OF THE FOREGOING LIMITED WRITTEN
WARRANTY. OTHERWISE, THE FOREGOING LIMITED WARRANTY
IS THE CONSUMER’S SOLE AND EXCLUSIVE REMEDY AND IS IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
SILVERADO SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL,
PUNITIVE OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
4
LIMITED TO LOSS OF ANTICIPATED BENEFITS OR PROFITS, LOSS
OF SAVINGS OR REVENUE, LOSS OF DATA, PUNITIVE DAMAGES,
LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED
EQUIPMENT, COST OF CAPITAL, COST OF ANY SUBSTITUTE
EQUIPMENT OR FACILITIES, DOWNTIME, THE CLAIMS OF ANY
THIRD PARTIES, INCLUDING CUSTOMERS, AND INJURY TO
PROPERTY, RESULTING FROM THE PURCHASE OR USE OF THE
PRODUCT OR ARISING FROM BREACH OF THE WARRANTY,
BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT, OR ANY
OTHER LEGAL OR EQUITABLE THEORY, EVEN IF Silverado KNEW
OF THE LIKELIHOOD OF SUCH DAMAGES. Silverado SHALL NOT
BE LIABLE FOR DELAY IN RENDERING SERVICE UNDER THE
LIMITED WARRANTY, OR LOSS OF USE DURING THE PERIOD
THAT THE PRODUCT IS BEING REPAIRED.
6. Some states do not allow limitation of how long an implied warranty
lasts, so the one-year warranty limitation may not apply to you (the
Consumer). Some states do not allow the exclusion or limitation of
incidental and consequential damages, so certain of the above
limitations or exclusions may not apply to you (the Consumer). This
limited warranty gives the Consumer specific legal rights and the
Consumer may also have other rights which vary from state to state.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
5
2. Safety Information
For your safety, and to prevent damage to the equipment and vehicles,
read this manual thoroughly before operating your VS80 EOBD code
reader. The safety messages presented below and throughout this
user’s manual are reminders to the operator to exercise extreme care
when using this device. Always refer to and follow safety messages and
test procedures provided by the manufacturer of the vehicle or
equipment being tested. Read, understand and follow all safety
messages and instructions in this manual.
2.1 Conventions Used
We provide safety messages to help prevent personal injury and
equipment damage. Below are signal words we used to indicate the
hazard level in a condition.
No.
Signal Word
Hazard Level
1
Indicates an imminently hazardous
situation which, if not avoided, will result
in death or serious injury to the operator
or to bystanders.
2
Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury to the
operator or to bystanders.
3
Indicates a potentially hazardous
situation which, if not avoided, may result
in moderate or minor injury to the
operator or to bystanders.
2.2 Important Safety Instructions
And always use your code reader as described in the user’s manual,
and follow all safety messages.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
6
Do not route the test cable in a manner that would interfere
with driving controls.
Do not exceed voltage limits between inputs specified in
this user’s manual.
Always wear ANSI approved goggles to protect your eyes
from propelled objects as well as hot or caustic liquids.
Fuel, oil vapors, hot steam, hot toxic exhaust gases, acid,
refrigerant and other debris produced by a malfunction engine can
cause serious injury or death. Do not use code reader in areas where
explosive vapor may collect, such as in below-ground pits, confined
areas, or areas that are less than 18 inches (45 cm) above the floor.
Do not smoke, strike a match, or cause a spark near the
vehicle while testing and keep all sparks, heated items and open flames
away from the battery and fuel / fuel vapors as they are highly
flammable.
Keep a dry chemical fire extinguisher suitable for gasoline,
chemical and electrical fires in work area.
Always be aware of rotating parts that move at high speed
when an engine is running and keep a safe distance from these parts as
well as other potentially moving objects to avoid serious injury.
Do not touch engine components that get very hot when an
engine is running to avoid severe burns.
Block drive wheels before testing with engine running. Put
the transmission in park (for automatic transmission) or neutral (for
manual transmission). And never leave a running engine unattended.
Do not wear jewelry or loose fitting clothing when working
on engine.
Make sure to turn off ignition before connecting or
disconnecting the code reader.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
7
3. Using This Manual
We provide instructions for the usage of your code reader in this manual.
Below is a list of conventions we used in the manual.
Safety Information
See Safety Information on page 5-6.
Bold Text
Bold emphasis is used in procedures to highlight selectable items such
as buttons and menu options.
Example:
Use the UP/DOWN key to select the desired measurement unit.
Bold-Italic Text
Bold-italic text is used in the procedures to highlight the menus on the
code reader screen.
Example:
Use the UP/DOWN key to select Language from System Setup
screen.
Symbols and Icons
√Check Note
Additional information about the subject in the preceding paragraph is
introduced by a √Check Note.
Example:
√The code reader is set to display English menus by default.
●Solid Spot
Operation tips and lists that apply to specific tool are introduced by a
solid spot ●.
Example:
System Setup allows you to:
●Select menu languages.
●Change measurement unit.
●Adjust display contrast.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
8
IMPORTANT
IMPORTANT indicates a situation which, if not avoided, may result in
damage to the test equipment or vehicle.
Example:
IMPORTANT Do not soak keypad as water might find its way
into the code reader.
NOTE
NOTE provides helpful information such as additional explanations,
tips, and comments.
Example:
NOTE Not all data are supported by all vehicles.
Screens
Some help messages, information, and data displayed on the code
reader are also shown in graphical text boxes. The screens presented
are examples only and actual test screen may vary for each vehicle
being tested.
Example:
Arrow Icon
An arrow icon indicates a procedure.
Example:
To change menu language:
1. Use the UP/DOWN key to select Language from System
Setup screen.
Main Menu
Diagnostics
Review Data
Print Data
Code Lookup
System Setup
Tool Information

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
9
4. Introduction
VS80 is developed by the most distinguished mind of the industry. It is
specially designed to support all 9 OBDII service modes, including live
data, O2 sensor test and more, on OBDII/EOBD compliant cars, SUVs,
light-duty truck and mini-vans sold worldwide since 1996.
4.1 About OBDII/EOBD
What is OBD?
The first generation of On-Board Diagnostics or OBD I was introduced in
early 1980's to control engine functions and diagnose engine problems
by vehicle manufacturers. As the OBDI lacked standardization of
protocols and interface, it allowed different interpretations among
vehicle manufacturers.
OBDII, the second generation On-Board Diagnostics, improved in both
capability and standardization, is a system developed in mid 1990’s by
the Society Automotive Engineers (SAE) to standardize automotive
electronic diagnosis. EOBD is European version of OBDII required in
Europe since2001.
The OBDII standard specifies:
●A generic diagnostic port (Data Link Connector) and its pinout;
●The protocols and the messaging format;
●A standard list of vehicle parameters identifications;
●A standard list of diagnostic trouble codes (DTCs);
Data Link Connector
The Data Link Connector (DLC) is a standard 16-pin interface located
under the dashboard on the driver's side of the passenger compartment.
If the DLC is not located under the dashboard as stated, a decal
describing its location should be attached to the dashboard in the area
the DLC should have been located.
NOTE On some Asian and European vehicles the DLC is located
behind the “ashtray”, which must be removed to access it, or on the

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
10
far left corner of the dash. If the DLC cannot be found, consult the
vehicle’s service manual for the location.
Diagnostic Trouble Codes (DTCs)
Diagnostic Trouble Codes (DTCs) are faults stored by vehicle
computers when problems that affect engine performance and
emissions are detected. DTCs are used to help identify the cause of a
trouble or troubles with a vehicle, and determine the fault location(s).
DTCs consist of a five-digit alphanumeric code. Please see below for the
DTCs format and code types.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
11

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
12
4.2 About the Code Reader
Code Reader Controls
A. OBD II Port - provides communication for vehicle DLC.
B. LCD Display – shows menus, test results and operation tips.
C. UP Key - moves selection up. Scrolls back and forth through codes
retrieved. Press it from home screen to enter the DTC update mode
when doing upgrading.
D. DOWN Key - moves selection down. Scrolls back and forth through
codes retrieved. Press it from home screen to do language selection.
E. HELP Key – accesses to the Help function.
F. BACK Key - cancels an action and returns to previous screen or
level. Also, press it to enter system setup menu from home screen.
G. ENTER Key – confirms an action or movement and moves to next
level. Starts recording live data under manual trigger mode. Selects
or deselects PID when viewing or recording custom PID(s). Hold the

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
13
ENTER key for 2 seconds to view or record customized PID list.
When doing playback of live data, use this key to scroll back and
forth through frames of data. Use the key to view PID graphs when
the Gicon appears. Also, press it to go to next screen of information
when code definition covers more than 1 screen.
H. Power Switch - Turns on/off the scan tool when powered by cell
battery; resets the code reader when powered by vehicle battery.
I. USB Port – provides a USB connection between the code reader
and PC or laptop.
J. Rear Decal – provides serial number of code reader.
K Battery Compartment – installs cell battery to provide power to
the code reader when disconnected from vehicle.
IMPORTANT Do not use solvents such as alcohol to clean
keypad or display. Use a mild nonabrasive detergent and a soft
cotton cloth.
IMPORTANT Do not soak keypad as water might find its way
into the code reader.

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
14
Accessories Included
No.
Part
Description
1
User’s Manual
Provides operation instructions for the
usage of code reader.
2
USB Cable
Provides USB communications for
updates of software and DTCs.
3
OBDII Cable
Provides connection for vehicle’s DLC.
4
Cell Battery
Provides power to the code reader
when disconnected from vehicle.
Specifications
No.
Item
Specification
1
Display
Backlit, 160 x 105 pixel display with
contrast adjustment.
2
Working
Temperature
0 to 60(32 to 140)
3
Storage
Temperature
-20 to 70 (-4 to 158)
4
External
Power
8-18 Volts powered by vehicle battery
5
Internal Power
9V
6
Dimensions
(L*W*H)
185mm*85mm*35mm
(7.28*3.35*1.38in)
7
Weight
1Kg

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
15
Display Indicators
Below is a list indictors used to help navigate through menus.
No.
Indicator
Description
1
$
Indicates the control module number.
2
Indicates more than one screen of
information is available.
3
?
Indicates help information available.
4
G
Indicates graphic viewing of PID is available.
5
Indicates internal battery volume.
Power
The code reader is powered up by vehicle battery when diagnosing; and
it is powered up by internal battery when off-vehicle reviewing test
results and printing.
√Refer to Code Reader Does Not Power Up on page 62 of
Troubleshooting if there are problems.
Internal Battery
To power on the code reader by internal battery:
1. Install 9V battery.
2. Press the POWER key to turn on the code reader.
√When the icon appears, refer to Battery Replacement in
on page 62 of Troubleshooting to replace the battery.
√When powered from the battery, the code reader disables the
display’s backlighting and turns off automatically after a period
of inactivity.
IMPORTANT If the code reader will not be used for an extended
period of time, remove the battery to prevent battery leakage

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
16
from damaging the battery compartment.
IMPORTANT Do not use a Lithium (Li) battery.
External Power
To power on the code reader by vehicle battery
1. Locate the diagnostic interface on vehicle.
2. Plug in the code reader’s OBDII connector to the DLC.
NOTE A plastic DLC cover may be found on some vehicles.
Remove the cover before plugging the OBD2 cable.
System Setup
System Setup allows you to:
●Select menu languages.
●Change measurement unit.
●Adjust display contrast.
●Change automatic power-off time.
●Turn on/off beeper.
●Check LCD display and operation of keypad.
√ System Setup settings remain until change to the existing
setups are made.
To do system setup:
1. Press the BACK key to enter System Setup from home
screen or use the UP/DOWN key to select System Setup
from Main Menu screen.
Main Menu
Diagnostics
Review Data
Print Data
Code Lookup
System Setup
Tool Information

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
17
√Follow on-screen instructions to program the code reader to
meet your specific needs.
Changing Language
√The code reader is set to display English menus by default.
To change system language:
1. Use the UP/DOWN key to select Language from System
Setup screen.
2. Press the ENTER key to confirm.
3. Use the UP/DOWN key to select desired language.
4. Press the ENTER key to save language setting and return.
Adjusting Display Contrast
To adjust display contrast:
1. Use the UP/DOWN key to select Contrast from System
System Setup
Language
Contrast
Measurement Unit
Auto Power-Off
Beeper
Tool Self-Tests
Language
Deutsch
Dutch
English
Espanol
Francais

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
18
Setup screen.
2. Press the ENTER key to confirm.
3. Use the UP/DOWN key to adjust contrast.
4. Press the ENTER key to save contrast setting and return.
Changing Measurement Unit
√Metric is the default measurement unit.
To change measurement unit:
1. Use the UP/DOWN key to select Measurement Unit from
System Setup screen.
2. Press the ENTER key to confirm.
Contrast
Contrast (30%)
[UP/DOWN] – Adjust
System Setup
Language
Contrast
Measurement Unit
Auto Power-Off
Beeper
Tool Self-Tests

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
19
3. Use the UP/DOWN key to select desired measurement unit.
4. Press the ENTER key to save measurement setting and return.
Changing Auto Power-Off
√The minimum auto power-off time is 1 minute, and the maximum
is 20 minutes.
√The Auto Power-Off function is available only when the code
reader is powered by internal battery.
To change auto power off time:
1. Use the UP/DOWN key to select Auto Power-Off from
System Setup screen.
2. Press the ENTER key to confirm.
System Setup
Language
Contrast
Measurement Unit
Auto Power-Off
Beeper
Tool Self-Tests
Measurement Unit
English
Metric

VS80 OBDII/EOBD Code Reader User’s Guide_English Version_V1.10
20
3. Use the UP/DOWN key to increase or decrease time.
4. Use the ENTER key to save.
Turning on/off Beeper
√The beeper is on by default.
To turn beeper on/off:
1. Use the UP/DOWN key to select Beeper from System
Setup screen.
2. Press the ENTER key to confirm.
Auto Power-off
01 Minute
[UP] – Increase time
[DOWN] – Decrease time
[ENTER] - Confirm
System Setup
Language
Contrast
Measurement Unit
Auto Power-Off
Beeper
Tool Self-Tests
