Marmitek TV Anywhere 5.8GHz User manual

T
V ANYWHER
E
20349/20100525 • TV ANYWHERE™ Wireless Audio/Video System
ALL RIGHTS RESERVED MARMITEK ©
USER MANUAL 3
GEBRAUCHSANLEITUNG 13
GUIDE UTILISATEUR 25
MODO DE EMPLEO 37
MANUALE D’ISTRUZIONE 49
GEBRUIKSAANWIJZING 61
TV ANYWHERE™
2.4 /5.8GHZ
Wireless Audio/Video System with built-in tuner

2© MARMITEK
TV Anywhere 2.4GHz / TV Anywhere 5.8GHz

ENGLISH
3TV Anywhere™
SAFETY WARNINGS
• This product should only be used indoor and only in dry areas. Do not expose the components
to rain or moisture. Do not use the product close to a bath, swimming pool etc.
• Do not cover or expose the components of your systems to extremely high temperatures
• Do not open the product
• In case of improper usage or if you have opened, altered and repaired the product yourself,
all guarantees expire. Marmitek does not accept responsibility in the case of improper usage
of the product or when the product is used for purposes other than specified.
• Adapters: Only connect the adapter to the mains after checking your the mains voltage is
the same as the values on the identification tags. Never connect an adapter or power cord
when it is damaged.
• Batteries: keep batteries out of the reach of children. Dispose of batteries as chemical
waste. Never use old and new batteries or different types of batteries together. Remove the
batteries when you are not using the system for a longer period of time.
Check the polarity (+/-) of the batteries when inserting them in the product.
CONTENT
1. The TV Anywhere system _________________________________________________ 4
2. Installing the system______________________________________________________ 4
2.1 Installing the transmitter without extra equipment ________________________ 5
2.2 Installing the transmitter with extra equipment___________________________ 5
2.3 Installing the receiver_________________________________________________ 6
2.4 Universal Remote Control ____________________________________________ 7
3. TV Anywhere channel setup _______________________________________________ 7
3.1 Re-arranging the TV channels _________________________________________ 8
3.2 Fine tuning _________________________________________________________ 9
3.3 Re-scan ____________________________________________________________ 9
3.4 Selecting a different TV system ________________________________________ 9
3.5 Master reset ________________________________________________________ 9
4 Moving the receiver to the final location_____________________________________ 9
5 Changing the code of the 6in1 remote for use with the TV Anywhere____________ 9
6. Frequently Asked Questions ______________________________________________ 11
7. Technical Specifications __________________________________________________ 12

4© MARMITEK
1. THE TV ANYWHERE SYSTEM
The TV Anywhere system includes a transmitter with built-in tuner and a receiver for antenna
signals and A/V signals. With the TV Anywhere system, you can transmit audio and video
signals throughout your house to a remote (2nd) TV, without additional coaxial cables. The
built-in tuner converts the antenna signal into a standard audio/video signal. This A/V signal
is transmitted by the unit on a 2.4 GHz or 5,8 GHz frequency (model dependend). The TV
Anywhere transmitter can be connected directly to your antenna wall socket. The receiver is
connected to the A/V input of your remote (2nd) Television.
Applications: Place your TV wherever you want, without having to worry about the
location of the aerial point.
RADIO/ TV
See chapter 2.1
Multisource and remote control
Additional A/V equipment can be connected to the transmitter as well (e.g.Set-Top Box, DVD player
or satellite receiver). The source can be selected with the remote control supplied, even from another
room. The supplied remote is a 6in1 universal remote and can be used locally (for your connected TV)
as well as for various other equipment (e.g. DVD, Set-Top Box, satellite receiver, etc.) connected to the
transmitter in another room. This remote control is also used to select channels on the TV Anywhere.
The TV Anywhere has a built-in IR (infrared) extender to use your original IR remotes as well.
Extra connections for a settop box, satellite receiver, decoder, HDD recorder, DVD player etc,.
RADIO/ TV SAT /HDD / SETTOPBOX /DVD
TV1
TV2
See chapter 2.2
2.INSTALLING THE SYSTEM
Attention: During set up, install the TV Anywhere transmitter and receiver in the same room
with a TV connected. After successful installation the receiver can be placed to wherever you
wish to connect your remote (2nd) TV.

ENGLISH
5TV Anywhere™
2.1 Installing the TV Anywhere transmitter
RADIO/ TV
8
7
9
A 3 6
1. Connect a coaxial cable [A] to your antenna wall socket.
2. Connect a coaxial cable to the Antenna Input [3] of your TV Anywhere transmitter.
3. Select a channel using the Channel Selector slide switch [9] (see page 2), e.g. C.
4. Connect the power adapter to the TV Anywhere transmitter [6].
5. Switch on the unit with the ON/OFF switch [7].
6. Make sure the TV Anywhere transmitter is placed some distance away from other
equipement which may interfere. Do not place the transmitter on top of your audio and/or
video equipment.
7. Direct the flat antenna [8] at the receiver.
8. See chapter 2.3 Installing the receiver.
2.2 Installing the TV Anywhere transmitter with extra equipment (satellite receiver,
Set-Top Box, DVD player, etc )
RADIO/ TV SAT /HDD /SETTOPBOX /DVD
TV1
A 3C
B
F
E
4 D
This setup allows you to watch all sources both in the main room TV and the second room TV.
1. Connect a coaxial cable [A] to one side of the antenna splitter [B].
2. Connect the other end of the coaxial cable [A] to the antenna input [3] of the TV Anywhere
transmitter.
3. Connect the existing coaxial cable (C) to the other end of the splitter.

6© MARMITEK
4. Connect the audio/video output [D] from your extra equipment to the audio/video input [4]
of the TV Anywhere transmitter [MultiSource function]. An RCA/RCA cable [E] is supplied.
5. Connect the audio/video output [5] of the extra equipment to the audio/ video input
(SCART) [F] of your TV. To make this connection, you can use the cable you originally used
for connecting your extra equipment to your TV.
SAT /HDD /SETTOPBOX /DVD
00.00.00 12:3 4
7
8
26
9
IR LED
6. Insert the plug of the infrared extender cable to the output [2] on the TV Anywhere
transmitter.
7. Locate the small IR LED’s on the IR sensors of the equipment connected. The IR emitters
have adhesive tape on the back. Remove the protective label and press the emitter lightly
to the front of your equipment. You may have to make some adjustments to find the right
location.
8. Select a channel using the Channel Selector slide switch [9], e.g. C.
9. Connect the power adapter to the TV Anywhere transmitter [6].
Attention: The power adapters for the transmitter and receiver are different!
10.Switch on the unit with the ON/OFF switch [7].
11. Make sure the TV Anywhere transmitter is placed some distance away from other equipment
which may interfere. Do not place the transmitter on top of your audio and/ or video
equipment.
12.Direct the flat antenna [8] at the receiver.
13.See chapter 2.3 Installing the receiver.
2.3 Installing the TV Anywhere receiver
TV2
816
18
17
15
1. Connect the RCA cable to the A/V output on the TV Anywhere receiver [15] to a TV A/V
input. Match the color of the plugs with the color code on the jacks of the receiver.
2. If connected to the Scart input use the Scart adapter marked “Receiver”

ENGLISH
7TV Anywhere™
3. Select the corresponding channel [16] with your transmitter (set both units to e.g. “C”).
4. Connect the power adapter to the TV Anywhere receiver [17].
5. Switch on the unit with the ON/OFF switch [18]. The red indicator lights up.
6. Direct the flat antenna [8] at the transmitter.
! To receive the signals from your TV Anywhere, switch the TV connected to your TV Anywhere
receiver (remote TV) on to the A/V channel (on some TV’s use channel “0”). If connected and if
no channel is programmed on your TV Anywhere a blue screen will appear.
2.4 Universal Remote Control
1. Open the battery compartment on the back of the remote.
2. Insert 2 batteries (AAA size, not included). Note the correct polarity/position.
3. Close the battery compartment.
3.TV ANYWHERE CHANNEL SETUP
1. When you power up the TV Anywhere for the first time, the memory does not contain any
TV channels. In this case the unit will display the screen below:
CHOOSE YOUR TV SYSTEM
[1] PAL-BG (western EU)
[2] PAL-I (uk, irl)
[3] PAL-DK (eastern EU)
[4] SECAM-L (france)
[5] SECAM-DK (russia)
2. Press the CBL button on the TV Anywhere remote control.
3. Press button 1-5, depending on the TV system used in your country. Don’t forget to aim
at the receiver when using the remote. If you don’t know which TV system is used, choose
option 1 (PAL-BG).
4. You will be asked to confirm your choice. Press the Enter key (ENT) on the remote control.
If you made the wrong choice, re-enter 1, 2, 3, 4 or 5 followed by ENT.
5. The following screen is displayed:
NO TV CHANNELS
Press [SCAN] to search
6. Press SCAN to have your TV Anywhere search for channels. This procedure may take up to 7
minutes, depending on the number of channels available. The TV Anywhere will automatically

8© MARMITEK
recognize and store all TV channels available on your antenna system. A status bar will indicate
the progress. At 100% the search will be completed within 1 minute.
SCANNING
Please wait
vhf uhf
7. When the SCAN procedure is finished, the TV Anywhere will show how many TV channels
were found. The screen below will be displayed for 4 seconds.
SCAN COMPLETE
FOUND xx CHANNELS
8. After the “Scan complete” screen has disappeared, you can select TV channels by pressing
the PROG+ and PROG- buttons or by using the numeric keys on the remote control.
! Because the tuner will also cover weak channels, there is a chance that the list will contain
some “empty” channels. If you see any of these channels, you can delete them by pressing the
CHANNEL DELETE button on your remote control. If you press this button, the word “DELETED”
will be displayed on the screen. 4 seconds later the TV channel will be deleted from the list.
3.1. Re-arranging the TV channels
The TV Anywhere lets you re-arrange the order of the TV channels, to create your favorite list.
1. Move up or down the TV channels using PROG+ and PROG- and look for the TV channel
you want to move to position 1 on the list.
2. When you have found the TV channel of your choice, press COPY. The screen now reads
“COPIED. READY TO MOVE”.
3. Now move to position 1. You can do this by using PROG+ and PROG- or by pressing 1 on
your remote control.
4. When you have arrived at position 1, press PASTE. The channel has now been moved from its
original position to position 1 on the list. The screens show “ADDED TO PROGRAM LIST”.
! The original TV channel on position 1 is automatically moved to position 2, the channel on
position 2 is moved to 3, etc. This means that the complete list is automatically being moved
down and that no channels are lost.
5. Repeat steps 1 to 4 to move TV channels to positions 2, 3, .... etc.

ENGLISH
9TV Anywhere™
3.2 Fine tuning
It may be that you feel you can improve the picture quality by manually fine tuning the
image.
1. Press FINE TUNE+ and FINE TUNE-. The text FINE TUNE + 1..12 or FINE TUNE - 1..12 will
appear on screen. You will gradually see the picture quality change.
2. Store the new settings by pressing COPY followed by PASTE.
3. When you don’t want to store the new settings, just move to a new channel by PROG+ or
PROG-.
3.3 Re-scan
If you have accidentally removed TV channels from the list, you can execute a new SCAN.
Press the SCAN button twice to restart scanning the frequency band. Be aware that you will
have to re-order the TV channels again to create your favorite list (3.1).
3.4 Selecting a different TV system
When no channels have been found, you may have chosen the wrong TV system (PAL-BG
/PAL-I /PAL-DK or SECAM-DK/ SECAM). To select a different TV system, you will have to
clear the memory of the TV Anywhere by doing a Master reset (3.5). After you executed the
Master Reset, you can choose a different TV system.
3.5 Master reset
1. Switch the TV Anywhere transmitter off and on again (by using the ON/OFF switch [7]).
2. Press the SOURCE and CHAN DOWN buttons (middle button) at the front of the transmitter
at the same time.
3. Keep the buttons pressed unit the text “DELETED” appears on your screen.
4.MOVING THE RECEIVER TO THE FINAL LOCATION
You are now ready to move your receiver to the final location. The maximum distance between
transmitter and receiver depends on local circumstances, but on average the distance is up
to 30m, through walls and floors.
When you feel that the image quality is poor or your TV Anywhere doesn’t react to the
remote, try to re-position the receiver or transmitter. Moving the receiver or transmitter a few
centimeters can make a difference in operating range.
5.CHANGING THE CODE OF THE 6IN1 REMOTE FOR
USE WITH THE TV ANYWHERE
! You only have to change the code of the 6in1 remote if another TV Anywhere system is
used in your immediate neighbourhood (within 100 meters).

10 © MARMITEK
! You can only access the screen below / change the handset code AFTER you programmed
the TV Anywhere .
The default setting of the remote is “0636”. To change the code of both the 6in1 remote and
your TV Anywhere system:
1. Press and hold SETUP until the LED stays lit.
2. Press CBL.
3. Enter one of the following codes:
0639
0638
0637
0636 (default)
4.
Switch the TV Anywhere transmitter off and then on again (by using the ON/OFF switch [7])
5. Press the SOURCE and CHAN UP buttons (right button) at the front of the transmitter at
the same time.
6. The following text will appear on your screen:
CODE WXYZ ACCEPTED
7. Press “SET”. The following text will appear on your screen:
PRESS [SET] AGAIN TO
CONFIRM
8. Press “SET” again.
9. The following text will appear on your screen (where WXYZ is the new code):
HANDSET CODE 0636
PRESS [SET] TO CHANGE
OR
ANY OTHER KEY TO CONTINUE
10.Test the connection by pressing PROG+ or PROG-.
