Marpo Kinetics VMX User guide

VMX
ROPE TRAINER
Maintenance
and Safety Procedures
Marpo Kinetics Inc., 258 LINDBERGH Ave, Livermore, CA. 94551 • 925-606-6919 tel. •877-275-1005 fax •
All rights reserved
Disclaimer: MARPO KINETICS makes no representations or warranties regarding the contents of this manual. We reserve the right
to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any
person of such revisions or changes.

Table Of Contents
1. Using your Marpo Kinetics - VMX ............................................................................................1
2. Safety Information .....................................................................................................................1
3. General Exercise Guidelines.....................................................................................................3
4. Transmission Source Replacement .........................................................................................4
5. Frame and Upholstery Maintenance.........................................................................................4
6. Maintenance Procedures ..........................................................................................................5
7. Warranty Information .................................................................................................................6

It is very important that you read these Maintenance and Safety Procedures before operating
the Product. Remember to perform the periodic maintenance requirements specified in these
Maintenance and Safety Procedures to assure proper operation and your continued satisfaction.
MAXIMUM USER WEIGHT: 350 LB (160 KG).
STOP

1. USING YOUR MARPO KINETICS - VMX
First time users:
1. Set rope speed to level 1-7. Since handle is spring loaded,
always hold it firmly when changing speeds.
2. Sit or kneel on the seat.
3. Grasp the rope with both hands and SLOWLY start pulling.
4. You may change the position of the rope from VERTICAL to
DIAGONAL to HORIZONTAL by lowering the CARRIAGE located
on the BOOM.
5. While in VERTICAL position the rope can be pulled in reverse
as well.
6. Always perform the exercise in a slow, controlled manner
and breathe normally.
Rope speed
Selector
Light headedness and dizziness can be signs of over-exertion or other medical conditions. If this
occurs, STOP using the machine immediately and consult a physician. Always rest between sets.
WARNING: KEEP HANDS AWAY FROM ALL WHEELS,
PULLEYS, CABLES AND WEIGHTS, AS THEY MAY
CAUSE INJURY.
CONSULT YOUR PHYSICIAN PRIOR TO
STARTING ANY EXERCISE REGIMEN.
OBTAIN INSTRUCTION FROM AN
AUTHORIZED TRAINER PRIOR TO USE OF THIS
MACHINE.
2. SAFETY INFORMATION
Safety Information
Read the Maintenance and Safety Procedures carefully before assembling, servicing or using the
MARPO KINETICS equipment. MAXIMUM USER WEIGHT: 350 LB (160 KG).
!WARNING!
Serious injury could occur if the following safety precautions are not observed.
 Do not use any equipment in any way other than designed or intended by the
manufacturer. It is imperative that all MARPO KINETICS equipment is used
properly to avoid injury.
 Keep all extremities clear from moving parts to avoid injury. Use appropriate
positioning, speed and controlled movements.
 DO NOT use any equipment that is damaged and/or has worn or broken parts.
Use only replacement parts supplied by MARPO KINETICS.
 DO NOT wear loose or dangling clothing while using the MARPO KINETICS
equipment. Keep away from all moving parts.
 Obtain a medical exam prior to beginning an exercise program.
Marpo Kinetics, Inc. 1 4/30/2012

 If at any time during exercise you feel faint, dizzy or experience pain, stop and
consult your physician.
 Children must not be allowed to operate these machines. All minors and those with
known physical limitations must be supervised.
 DO NOT attempt to fix a broken or jammed machine. Notify authorized facility staff
or contact Marpo Kinetics Customer Service.
 Use the machine only for the intended use. Obtain instruction and DO NOT modify
the machine(s).
Maintain Labels and Nameplates
Do not remove labels for any reason. They contain important information. If unreadable or missing,
contact MARPO KINETICS for a replacement.
Securing Equipment
All MARPO KINETICS equipment must be secured to the floor to stabilize and eliminate
rocking or tipping. This must be performed by a licensed contractor. DO NOT use the
equipment if it is not set up and located on a solid, level surface.
Make sure that each machine is set up and operated on a solid, level surface. DO NOT
install equipment on an uneven surface.
NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8" grade 2
bolts or better).
NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim
any leg or frame not in contact with surface using flat washers.
Maintenance
Preventative maintenance is necessary for optimal performance of equipment as well as
minimizing risk of injury. Inspect the MARPO KINETICS equipment prior to use. DO NOT use if
damaged or inoperable.
Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is
qualified to do so. Substitutes are to be avoided and will void any warranty agreement.
Routinely inspect the following:
Rope to ensure that the connection of the two rope ends is not showing
any fraying or tearing of individual strands or that the connecting chain is not
worn. Replace at first sign of wear.
Rope to ensure the entire length of rope has no loose strands and there
are no foreign objects stuck in the strands which could cause cuts to the
hands.
Cables and belts; these pose an extreme liability if used when frayed.
Always replace any cable or belt at first sign of wear (consult MARPO
KINETICS if uncertain).
Belts and roller chain inside the covers of the mechanism, for any signs
of wear. Replace any belt or chain at first sign of wear (consult MARPO
KINETICS if uncertain).
If your MARPO KINEITCS equipment includes a quick release seat, make certain that the seat is
properly secured on the frame .
Marpo Kinetics, Inc. 2 4/30/2012

It is the purchaser's responsibility to properly instruct his/her end users and supervising personnel
as to the proper operating procedures of all MARPO KINETICS equipment. It is recommended that
the end users physical condition be evaluated prior to beginning any exercise program.
Perform regular maintenance checks on the MARPO KINETICS
equipment. Pay close attention to all areas most susceptible to wear.
Keep a repair log of all maintenance activities.
Immediately replace worn or damaged components. If unable to do so,
remove the MARPO KINETICS equipment from service until repairs are made.
Make sure that all users are properly trained on how to use the MARPO
KINETICS equipment.
Make sure that there is enough room for safe access and operation of
the MARPO KINETICS equipment.
Use only MARPO KINETICS supplied components to maintain/repair the
MARPO KINETICS equipment.
UNDERSTANDING ALL WARNINGS TO THE FULLEST IS IMPORTANT. IF ANY OF THESE
WARNINGS ARE UNCLEAR, CONTACT MARPO KINETICS PERSONNEL FOR
CLARIFICATION.
NOTE: It is the responsibility of the user/owner or facility operator to ensure that regular
maintenance is performed.
3. General Exercise Guidelines
Using MARPO KINETICS VMX
Like most exercise, strength training involves an element of risk. Use this information to assist you
and your members in making the experience on VMX both productive and safe. Prior to engaging
in any strength-training program, individuals with known health conditions and/or individuals whom
are unfamiliar with the risk(s) involved with weight training, should first consult with a physician.
All training sessions should be supervised by trained personnel. Be certain that the warning
stickers affixed on your VMX, remain unaltered and on the product. Also, be certain that all stickers
(safety, instructional or otherwise) are read and understood by each user.
All users should be instructed on the proper use of VMX as well as those actions that should be
avoided. Each VMX machine has factored in adjustments to accommodate for a wide variety of
fitness levels. Prior to use, make sure that the user understands their range in which to operate the
equipment. To minimize user and/or bystander injury:
Do not lean against framework, or any component whether it is dynamic or static.
Stay clear of any components while in motion. Keep hands and feet away from cables, belts, cams
and pulleys and/or any converging action. The convergence of these transmission-based
components can cause serious injury.
Do NOT operate unit without the main protective plastic covers as serious injury could occur.
Product Maintenance and Use
Repair of any MARPO KINETICS equipment should be performed only by authorized persons.
Never modify any MARPO KINETICS equipment or attempt to make adjustment(s) to, or the repair,
of any MARPO KINETICS equipment without first contacting MARPO KINETICS. Always notify
someone authorized to make such repair. Instruct users to report any equipment or training
irregularities to supervisory personnel immediately.
Marpo Kinetics, Inc. 3 4/30/2012

4. TRANSMISSION SOURCE REPLACEMENT
Transmission Sources
MARPO KINETICS uses several types of transmissions sources. These sources may include some
or all of the following components: sprockets and roller chains, gears and belts, cables, cams,
pulleys, tie rods, flange bearings and rod ends. These components should be checked and
lubricated on a regular basis where applicable.
General Guidelines
Worn belts and cables can be dangerous. Unexpected failure of a transmission source can result in
injury. It is the responsibility of the owner and/or the person managing the goodwill of the product to
frequently inspect transmission source(s) for loose fittings and/or worn areas. Replace cables and
belts at first sign of wear. When replacing and/or tightening a transmission source, be certain to
check that connections are tight.
The life of any transmission source is conditional to use. Each facility is different and as a result,
MARPO KINETICS cannot estimate the life of any one transmission source. Therefore, this
responsibility must be managed at the site of the facility.
When tightening or changing cables, termination bolt should never exceed 1/4” thread exposure.
This is the inside measurement between lock nut and head of bolt. Check and adjust accordingly
and be certain that lock nut is tight. The tool needed for this procedure is a ¾” box wrench.
5. FRAME AND UPHOLSTERY MAINTENANCE
Framework Maintenance
All MARPO KINETICS frameworks should be wiped down on a daily basis. By doing so, it will not
only improve the longevity of your finish(s) but aid in identifying fatigue cracks in a frame or
component, loose bolts, worn cables or belts and other areas which may require attention.
Frames and components can be wiped down with a damp cloth daily. Every three to four months,
use an easy application car wax. This (wax) protection may preserve the powder coating from
premature rusting due to corrosives found in perspiration and allow loose particles to be more
easily removed when simply wiping your product down with a damp cloth. Do not use lacquer
thinner, acetone and/or other solvents. These chemicals may dull the product and possess agents
which may remove the epoxy-based powder from the frame.
To repair a scratch or chip on a frame or component, first determine the severity of the damage.
Some scratches can be removed with an automotive rubbing compound. A scratch which is too
deep to rub out, like a chip, can be filled with a touch-up bottle available from MARPO KINETICS.
Typically, solid colors are the easiest to repair in contrast to textured powders. To apply touch-up
paint, fill area in sparingly. Two coats are better than one heavy coat. Once area is dried, aesthetic
choices as to its finishing are optional. The repair can stand-alone or, efforts to blend and color
sand the repair can be attempted. This process is a difficult one and should be practiced by
someone knowledgeable in this field.
Upholstery Maintenance
Due to corrosive agents in perspiration, upholstery should be cleaned daily with a 10% diluted
consistency of lanolin hand cleaner in warm water. Do not use products such as Lysol®, Armor
Alll®, Windex® or other abrasive detergents as they will dry out and eventually cause premature
cracks. When cleaning upholstery, wipe down top and sides with solution and follow up with a dry
towel to remove residue(s).
Marpo Kinetics, Inc. 4 4/30/2012

To replace or remove any MARPO KINETICS upholstery pads and/or protective wear guard(s) use
a single 5/16” box or socket head.
6. MAINTENANCE PROCEDURES
Cleaning
Proper cleaning will help ensure the life of your product. The following parts should be cleaned
daily:
Upholstery; using a solution of mild soap and water.
Rope; using rubbing (medical) alcohol on a cloth wipe down the rope to remove hand oil and
grease.
Daily Part Inspection
Inspect the following parts daily for wear or damage:
Cables; inspect for wear or damage and proper tension (should not exceed 3/4" deflection). Pay
close attention at bends and attachments points.
Hardware; inspect for looseness. Tighten as required using the proper tools.
Frames; inspect for wear or damage.
Rope; inspect for any snags, tears or fraying, cracks in the end caps or wear of the connecting
chain links where the two link overlap.
Routine Inspection and Maintenance
The following maintenance should be performed approximately once a week:
Visually inspect all hardware for loosening, tampering or wear.
Check jam nut on all locations.
Once a month open the system covers and inspect:
All gears and sprockets to make sure they have no play on the axis. For this, check each
connecting screw or set screw with the proper Allen wrench or screwdriver. If a screw or set screw
is found loose remove one at a time, add LocTite to the treads and tighten back in place. Check the
two metal wings attached to the break mechanism and ensure they are not bending or distorting in
any way. Look for signs of metal fatigue or small cracks. If any of this is observed STOP using the
unit and contact Marpo Kinetics for replacement parts.
Check the 4 lead weights attached to the wings of the brake mechanism. Make sure the bolts are
tight and the weights should not be free to spin on the bolt. If you are able to twist the lead weights
on the bolt, remove the bolt and inspect the hole in the lead weights. The hole should be round. If
the hole has an oval shape the lead weights must be replaced. If the holes are still round shape re-
tighten the bolts onto the lead weight so that you could not twist the lead weights once done
tightening the bolts.
Check cables for stretch and adjust as necessary. Support the seat 24” from the floor. Loosen the
3 set screws on one of the cable connectors. Push the cable into the connector until cable is tight.
Tighten back the 3 set screws to complete the adjustment. Make sure the setscrews always grip
onto bare wire strands and NOT onto the plastic cover on the cable. Securing a setscrew on the
plastic sleeve may cause the sleeve to tear and the cable to come loose.
Note: Use polishing compound (such as car wax) to clean and remove scuffs from powder-coated
surfaces as necessary.
Marpo Kinetics, Inc. 5 4/30/2012

Important Reminders
DO NOT use abrasive or highly alkaline cleaners on the plastic or rubber components, or on the
rope.
Never scrape plastic components with razor blades or other sharp instruments.
Benzene, gasoline, acetone or carbon tetrachloride should never be used on the plastic or rubber
components, or on the rope.
Removal of Paint, Marking Pen, Labels
Butyl cellosolve works well for removal of paints and inks. Labels, stickers, and other adhesives
may be removed using kerosene. When the solvent will not penetrate sticker material apply heat
(hair dryer) to soften the adhesive and promote removal. Be sure to use any solvents according to
directions. GASOLINE SHOULD NOT BE USED.
7. WARRANTY INFORMATION
Warranty and Disclaimer
MARPO KINETICS warranty is as follows: lifetime limited on the frame, not including coatings, 1
years on mechanical parts, 1 year labor, 90 days on upholstery stitching only, cables and belts.
Warranty is good and available to the original purchaser only as noted by MARPO KINETICS
invoice and is not transferable or assumable. MARPO KINETICS cannot warrant products that
have been abused, neglected and/or poorly maintained. All equipment should be reviewed at the
time of delivery for damage, breakage, loosening of nuts and bolts, components and/or any other
moving parts. Any and all claims for warranty must be received in writing within 70 days of defect.
Do not alter, modify or redesign any MARPO KINETICS products or use any replacement parts or
materials other than those components original to MARPO KINETICS as it will limit the warranty
and liability of MARPO KINETICS. MARPO KINETICS reserves the right to change, replace or
modify products, parts, accessories and/or design without notice. Deposits on cancelled orders will
be subject to handling and restocking charges.
WHAT IS COVERED
This MARPO KINETICS commercial exercise equipment (Product.) is warranted to be free of all
defects in material and workmanship.
WHO IS COVERED
The original purchaser or any person receiving the Product as a gift from the original purchaser.
WHO PAYS TRANSPORTATION AND INSURANCE FOR SERVICE
If the Product or any covered part must be returned to a service facility for repairs, We, MARPO
KINETICS, will pay all transportation and insurance charges for the first year. You are responsible
for transportation and insurance charges for all subsequent years.
WHAT WE WILL DO TO CORRECT COVERED DEFECTS
We will ship to you any new or rebuilt replacement part or component, or, at our option, replace the
Product. Such replacement parts are warranted for the remaining portion of the original warranty
period.
WHAT IS NOT COVERED
Any failures or damage caused by unauthorized service, misuse, accident, negligence, improper
assembly or installation, debris resulting from any construction activities in the Products
environment, rust or corrosion as a result of the Product(s) location, alterations or modifications
without our written authorization or by failure on your part to use, operate and maintain the Product
as set out in this document.
Marpo Kinetics, Inc. 6 4/30/2012

Parts and Service
You will receive information on how to get a replacement part, arrange for service where your
Product is located or advise you on how and where to ship the Product for service. All labor costs
for warranty work must be pre-approved by Marpo Kinetics. Marpo Kinetics reserves the right to
arrange for labor services and any labor costs not approved by Marpo Kinetics will not be
reimbursed. Please include your name, phone number, and model number of your Product for all
correspondence. Customer Support is available Monday through Friday from 8:00 a.m. to 5:00 p.m.
Pacific Standard Time.
Call: 925-606-6919
Fax: [phone]
E-mail: [e-mail]
Shipping
Before shipping:
Obtain a Return Authorization Number (RA#) from Customer Support
Securely pack your Product (use the original shipping carton, if possible)
Write the RA# on the outside of the carton
Insure the Product, and include a letter explaining the defect or problem
and a copy of your proof of purchase if you believe the service is covered by
warranty
Exclusive Warranty
THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND EITHER
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND ALL OTHER
OBLIGATIONS OR LIABILITIES ON OUR PART. We neither assume nor authorize any person to
assure for us any other obligation or liability concerning the sale of this Product. Under no
circumstances shall we be liable under this warranty, or otherwise, of any damage to any person or
property, including any lost profits or lost savings, for any special, indirect, secondary, incidental or
consequential damages of any nature arising out of the use of or inability to use this Product. Some
states do not allow the exclusion or limitation of implied warranties or of liability for incidental or
consequential damages, so the above limitations or exclusions may not apply to you.
Changes in Warranty Not Authorized
No one is authorized to change, modify or extend the terms of this limited warranty.
Effect of State Laws
This warranty gives you specific legal rights and you may have other rights, which vary, from state
to state.
Our Pledge to You
Our products are designed and manufactured to the highest standards.
MARPO KINETICS wants you to be completely satisfied with our products and will do everything
possible under the terms of this warranty to keep you secure in knowing you have bought the best!
Marpo Kinetics, Inc. 7 4/30/2012
