MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
1
1
1. . I IN NT TR RO OD DU UC CT TI IO ON N
The MT40 Linear Image Barcode Scan Engine is designed for 1D high performance
barcode scanning with optimal performance and easy integration. MT40 is ideal for
integration into data terminals and other small mobile devices. Wide-angle version
(MT40W) is also available.
The MT40 consists of 2 illumination LEDs, a high-quality linear image sensor and a
microprocessor that contains powerful firmware to control all aspects of operations
and enable communication with the host system over the standard set of
communication interfaces.
Two interfaces, UART & USB, are available. UART interface communicates with the
host system over TTL-level RS232 communication; USB interface emulates a USB
Keyboard device and communicates with the host system over USB.
1
1- -1 1. . M MT T4 40 0 B Bl lo oc ck k D Di ia ag gr ra am m

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
2
1
1- -2 2. . E El le ec ct tr ri ic c I In nt te er rf fa ac ce e
1
1- -2 2- -1 1. . P Pi in n A As ss si ig gn nm me en nt t
Trigger
BZ
CTS
USB_D+
LED
TXD
RTS
R XD
Power_enable
VCC
USB_D-
1
2
3
4
5
6
7
8
9
10
11
12
Pin# UART USB I/O Description Schematic Example
1 VCC VCC ------------ Supply voltage input.
Must always be
connected to 3.3 or 5V
power supply.
3V3 / 5V
2 RXD ------------ Input UART TTL data input.
Sipex®Vendor P/N: SP232ACT
3 Trigger Trigger Input High: Power-up/Standby
Low: Scanning Operation
*Warning:
1. Pull low at power-up
will prompt the scan
engine into firmware
update mode.
Once trigger is pressed (pull low), scanning
operation continues until a barcode is
successfu
lly decoded or the trigger is released
(pull high). To proceed to the next scanning
operation, release (pull high) first and press (pull
low) the trigger again.
Pin12
Pin1
(Top View of MT40)

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
3
Pin# UART USB I/O Description Schematic Example
4 Power
Enable
Power
Enable
Input High: Scan Engine Off
Low: Scan Engine On
*Except:
1. During data
transmission
2. Writing parameters to
non-volatile memory.
When Power Enable pin is pull high, scan engine
will be shut down with power consumption of less
than 1uA.
5 TXD ------------ Output UART TTL data output.
Sipex®Vendor P/N: SP232ACT
6 RTS ------------ Output When handshaking is
enabled, MT40
requests permission
from host to transmit
data on TXD line.
Sipex®Vendor P/N: SP232ACT
7 GND GND ------------ Power and signal
ground.
8------------ USB D+ Bidirectional Differential Signal
Transmission
USB_D+
USB_D-
GND
GND
VIN_5V
USB_Port
4
3
2
1
56

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
4
Pin# UART USB I/O Description Schematic Example
9LED LED Output Active high, it indicate
s
the status of Power-Up
or a successful
barcode decoded
(Good Read).
LED1
GREEN
12
Q4
2N3904
R11
330R
R13 4K7
Decode LED
VCC
10 CTS ------------ Input When handshaking is
enabled, host
authorizes MT40 to
transmit data on TXD
line.
Sipex®Vendor P/N: SP232ACT
11 Buzzer Buzzer Output Active high: Power-Up
or a successful
barcode decoded.
PWM controlled signal
can be used to drive an
external buzzer for a
successful barcode
decoded (Good Read).
R3
10R
Buzzer
Q1
2N3904
Q2
2N3904
R6 2K7
R7 6K8
R8
3K3
BZ
BZ1
BZ_2.7K
2 1
HD1
1N 4148
1 2
+C8
10uF
+
-
VCC
12 ------------ USB D- Bidirectional Differential Signal
Transmission
USB_D+
USB_D-
GND
GND
VIN_5V
USB_Port
4
3
2
1
56

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
5
1
1- -2 2- -2 2. . E El le ec ct tr ri ic c C Ch ha ar ra ac ct te er ri is st ti ic cs s
Symbol
Ratings
Min
Max
Unit
VIH Input high level VDD x 0.65 VDD + 0.4 V
VIL Input low level - 0.4 VDD x 0.35 V
VOH Output high level VDD - 0.4 - V
VOL Output low level - 0.4 V
VESD Electrostatic discharge voltage
(human body mode) - 4000 + 4000 V
*Note:
1. Power Supply:VDD= 3.3 or 5 V
2. Exposure to maximum rating conditions for extended periods may affect device reliability.
1
1- -2 2- -3 3. . F Fl le ex x C Ca ab bl le e
The flex cable is used to connect MT40 with the host side. There are 12
pins on both the engine (MT40) side and the host side. Please see
Chapter 2-10 for more details of flex cable.
Flex cable
(P/N: 67XX-1009X12)
Pin# Pin Assignment To Host
1 VCC
2 RXD
3 Trigger
4 Power Enable
5 TXD
6 RTS
7 GND
8 USB D+
9 LED
10 CTS
11 Buzzer
12 USB D-
*Note: Conforms to MARSON MT742(L)/MT752(L) pin assignment.

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
6
1
1- -3 3. . O Op pe er ra at ti io on na al l T Ti im mi in ng g
This chapter describes the timing associated with the various operating modes of
the MT40 including Power Up, Sleep Mode, and Decode Timing.
1
1- -3 3- -1 1. . P Po ow we er r U Up p
When power is initially applied, the MT40 is activated and begins the
process of initialization. Once initialization (duration ≦10mS) is
completed, the MT40 enters Standby Mode and is ready for barcode
scanning.
1
1- -3 3- -2 2. . S Sl le ee ep p M Mo od de e
The MT40 may enter Sleep Mode after a programmable time period has
elapsed without any activity. Please see Chapter 6 for more details about
Sleep Mode.
1
1- -3 3- -3 3. . D De ec co od de e T Ti im mi in ng g
In Standby Mode, the MT40 is activated by the Trigger signal which MUST
be kept low for at least 20 ms until the successful scan is achieved, as
indicated by the Buzzer/LED signals.
In Sleep Mode, the MT40 can be waken up by the Trigger signal which
MUST be kept low for at least 2 mS, which will prompt the scan engine into
Standby Mode.
The total scan and decode time is approximately equal to the time from the
Trigger signal going low to the Buzzer/LED signal going high. This time will
vary slightly based on several factors including barcode quality, barcode
type and the distance between MT40 and the barcode scanned.
Upon a successful scan, the MT40 outputs the Buzzer/LED signal and
keeps this signal for the duration of the transmission of the data decoded to
the host side. The duration is about 75 ms.
Therefore, the total duration of a typical scanning operation (from Trigger
turning low to the end of Buzzer PWM signal) is also approximately 120mS.

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
7
1
1- -3 3- -4 4. . S Su um mm ma ar ry y o of f O Op pe er ra at ti io on n T Ti im mi in ng gs s
1. The maximum duration of initialization is 10mS.
2. The maximum duration of scanning operation in Standby Mode is 120mS.
3. The minimum duration of waking up MT40 from Sleep Mode by
Trigger signal is about 2 ms.
4. The maximum duration of waking up MT40 from Sleep Mode by Trigger
signal and completing decode (when barcode is within optimal focus) is
about 120ms

MT40 Linear Image Scan Engine, Integration Guide, V2.3
___________________________________________________________________________________
8
2
2. . S SP PE EC CI IF FI IC CA AT TI IO ON NS S
2
2- -1 1. . I In nt tr ro od du uc ct ti io on n
This chapter provides technical specifications of the MT40 scan engine.
Operating method, scanning range and scan angle are also presented.
2
2- -2 2. . T Te ec ch hn ni ic ca al l S Sp pe ec ci if fi ic ca at ti io on ns s
Optic & Performance
Light Source 625nm visible red LED
Sensor Linear Image Sensor
Scan Rate 510 Scans/ sec (Smart Detection)
Resolution MT40: 4mil/ 0.1mm ; MT40W: 3mil/ 0.075mm
Scan Angle MT40: 40°; MT40W: 65°
Print Contrast Ratio 30%
Width of Field (13Mil Code39) MT40: 200mm ; MT40W: 110mm
Typical
Depth Of Field
(Environment: 800 lux)
Code \ Model MT40 MT40W
3 mil Code39 N/A 28 ~ 70mm (13 digits)
4 mil Code39 51 ~ 133mm (4 digits) 19 ~ 89mm (4 digits)
5 mil Code39 41 ~ 172mm (4 digits) 15 ~ 110mm (4 digits)
10 mil Code39 27 ~ 361mm (4 digits) 13 ~ 213mm (4 digits)
15 mil Code39 42 ~ 518mm (4 digits) 22 ~ 295mm (4 digits)
13 mil UPC/ EAN
37 ~ 388mm (13 digits) 21 ~ 231mm (13 digits)
Guaranteed
Depth Of Field
(Environment: 800 lux)
3 mil Code39 N/A 40 ~ 65mm (13 digits)
4 mil Code39 65 ~ 120mm (4 digits) 30 ~ 75mm (4 digits)
5 mil Code39 60 ~ 160mm (4 digits) 30 ~ 95mm (4 digits)
10 mil Code39 40 ~ 335mm (4 digits) 25 ~ 155mm (4 digits)
15 mil Code39 55 ~ 495mm (4 digits) 35 ~ 195mm (4 digits)
13 mil UPC/ EAN
50 ~ 375mm (13 digits) 35 ~ 165mm (13 digits)
Physical Characteristics
Dimension (W)32 x (L)24 x (H)11.6 mm
Weight 8g
Color Black
Material ABS
Connector 12pin (pitch = 0.5mm) ZIF
