Marson MT581 User manual

MT581 User’s Manual V1.1
MT581
2D Wireless Ring Scanner
User’s Manual
Version 1.1 DATE: 2021/10/12

MT581 User’s Manual V1.1
2
Table of Content
CHAPTER 1 INTRODUCTION ....................................................................................................................................... 7
SPECIFICATIONS ..................................................................................................................................................................................... 7
BEEPER INDICATION ............................................................................................................................................................................... 9
LED INDICATION..................................................................................................................................................................................... 9
CHAPTER 2 GENERAL SETTINGS .............................................................................................................................11
BARCODE CONFIGURABILITY............................................................................................................................................................... 11
FACTORY DEFAULT .............................................................................................................................................................................. 11
CHECK VERSION................................................................................................................................................................................... 11
BUTTO N PREFERENCE ......................................................................................................................................................................... 12
GOOD READ INDICATOR ...................................................................................................................................................................... 12
Beep Tone ...................................................................................................................................................................................... 12
Beep Mode ..................................................................................................................................................................................... 13
DATA FORMAT....................................................................................................................................................................................... 14
UTF-8 to Unicode Conversion ................................................................................................................................................... 14
HT/CR/ESC Converts to TAB/ENTER/ESCAPE................................................................................................................... 14
Function Code Conversion ......................................................................................................................................................... 14
Numeric Key................................................................................................................................................................................... 15
Capslock Mode.............................................................................................................................................................................. 15
Keyboard Layout........................................................................................................................................................................... 16
Intercharacter Delay..................................................................................................................................................................... 18
Interblock Delay............................................................................................................................................................................. 18
BCC (Binary Check Character).................................................................................................................................................. 19
IMAGING SETTINGS............................................................................................................................................................................... 19
Inverse Barcode ............................................................................................................................................................................ 19
CHAPTER 3 INTERFACE .............................................................................................................................................20
BT HID .................................................................................................................................................................................................. 20
Getting Connected........................................................................................................................................................................ 20
Pincode Setup ............................................................................................................................................................................... 21
BT SPP................................................................................................................................................................................................. 22
Getting Connected........................................................................................................................................................................ 22
Set SPP Pincode........................................................................................................................................................................... 23
GENERAL BLUETOOTH SETTINGS ....................................................................................................................................................... 24
Power Off Timeout........................................................................................................................................................................ 24
Set Bluetooth Device ID .............................................................................................................................................................. 25
Check Bluetooth Firmware Version .......................................................................................................................................... 25
Check Device MAC Address...................................................................................................................................................... 26
Check Host MAC Address .......................................................................................................................................................... 26
ScanLink ......................................................................................................................................................................................... 26
MEMORY MODE .................................................................................................................................................................................... 27

MT581 User’s Manual V1.1
3
Delete Last Record....................................................................................................................................................................... 27
Clear All Record ............................................................................................................................................................................ 27
Data Format ................................................................................................................................................................................... 28
Field Separator.............................................................................................................................................................................. 28
Date Format ................................................................................................................................................................................... 29
Time Format................................................................................................................................................................................... 29
Date & Time Setup ....................................................................................................................................................................... 30
USB HID............................................................................................................................................................................................... 30
USB VCP.............................................................................................................................................................................................. 30
CHAPTER 4 READING MODE .....................................................................................................................................31
TRIGGER MODE .................................................................................................................................................................................... 31
PULSE MODE ........................................................................................................................................................................................ 31
Trigger / Pulse Mode – LED Auto-Off Timeout ...................................................................................................................... 31
BATCH MODE ........................................................................................................................................................................................ 32
CONTI NUO US MODE ............................................................................................................................................................................. 32
AUTO-SENSING MODE.......................................................................................................................................................................... 32
Auto-sensing Mode – Sensitivity ............................................................................................................................................... 33
Continuous / Auto-sensing Mode – Identical Read Interval................................................................................................ 33
CHAPTER 5 DATA FORMAT.......................................................................................................................................35
CODE ID ................................................................................................................................................................................................ 35
SET ID ................................................................................................................................................................................................... 35
DATA LENGTH ....................................................................................................................................................................................... 38
PREAMBLE ............................................................................................................................................................................................. 38
POSTAMBLE........................................................................................................................................................................................... 38
Clear Preamble/Postamble......................................................................................................................................................... 39
TERMINATOR ......................................................................................................................................................................................... 39
CHAPTER 6 SYMBOLOGIES.......................................................................................................................................40
GENERAL SETTINGS ............................................................................................................................................................................. 40
UPC-A................................................................................................................................................................................................... 41
Enable/Disable UPC-A ................................................................................................................................................................ 41
Check Digit ..................................................................................................................................................................................... 41
Lead Digit........................................................................................................................................................................................ 41
Supplement .................................................................................................................................................................................... 41
UPC-E................................................................................................................................................................................................... 42
Enable/Disable UPC-E ................................................................................................................................................................ 42
Check Digit ..................................................................................................................................................................................... 42
Lead Digit........................................................................................................................................................................................ 43
Supplement .................................................................................................................................................................................... 43
UPC-E to UPC-A........................................................................................................................................................................... 44
EAN-8 ................................................................................................................................................................................................... 44

MT581 User’s Manual V1.1
4
Enable/Disable EAN-8 ................................................................................................................................................................. 44
Check Digit ..................................................................................................................................................................................... 44
Supplement .................................................................................................................................................................................... 44
EAN-13................................................................................................................................................................................................. 45
Enable/Disable EAN-13............................................................................................................................................................... 45
Check Digit ..................................................................................................................................................................................... 45
Supplement .................................................................................................................................................................................... 45
ISBN................................................................................................................................................................................................. 46
ISSN................................................................................................................................................................................................. 46
CODE 128 ............................................................................................................................................................................................. 47
Enable/Disable Code 128 ........................................................................................................................................................... 47
Code128 Min/Max Length........................................................................................................................................................... 47
GS1-128(UCC/EAN 128).................................................................................................................................................................. 48
Enable/Disable GS1-128............................................................................................................................................................. 48
GS1-128 Min/Max Length........................................................................................................................................................... 48
AIM 128 ................................................................................................................................................................................................ 49
Enable/Disable AIM 128.............................................................................................................................................................. 49
AIM 128 Min/Max Length ............................................................................................................................................................ 49
CODE 39................................................................................................................................................................................................ 50
Enable/Disable Code 39.............................................................................................................................................................. 50
Verification...................................................................................................................................................................................... 50
Start/Stop........................................................................................................................................................................................ 50
Full ASCII Code39 ........................................................................................................................................................................ 51
Code39 Min/Max Length ............................................................................................................................................................. 51
CODE 32................................................................................................................................................................................................ 52
Enable/Disable Code 32.............................................................................................................................................................. 52
Leading/Tailing .............................................................................................................................................................................. 52
CODE 93................................................................................................................................................................................................ 53
Enable/Disable Code 93.............................................................................................................................................................. 53
Verification...................................................................................................................................................................................... 53
Code 93 Min/Max Length............................................................................................................................................................ 53
CODE 11................................................................................................................................................................................................ 54
Enable/Disable Code 11.............................................................................................................................................................. 54
Verification...................................................................................................................................................................................... 54
Check Digit ..................................................................................................................................................................................... 54
Code 11 Min/Max Length............................................................................................................................................................ 55
CODABAR (NW -7)................................................................................................................................................................................ 56
Enable/Disable Codabar ............................................................................................................................................................. 56
Verification...................................................................................................................................................................................... 56
Start/Stop........................................................................................................................................................................................ 56
Codabar Min/Max Length............................................................................................................................................................ 57
INTERLEAVED 2OF 5............................................................................................................................................................................ 58

MT581 User’s Manual V1.1
5
Enable/Disable Interleaved 2 of 5 ............................................................................................................................................. 58
Verification...................................................................................................................................................................................... 58
Interleaved 2 of 5 Min/Max Length............................................................................................................................................ 59
ITF-14 ................................................................................................................................................................................................... 60
Enable/Disable ITF-14 ................................................................................................................................................................. 60
ITF-6...................................................................................................................................................................................................... 60
Enable/Disable ITF-14 ................................................................................................................................................................. 60
MATRIX 2OF 5...................................................................................................................................................................................... 61
Enable/Disable Matrix 2 of 5 ...................................................................................................................................................... 61
Verification...................................................................................................................................................................................... 61
Matrix 2 of 5 Min/Max Length..................................................................................................................................................... 62
INDUSTRIAL 2OF 5............................................................................................................................................................................... 63
Enable/Disable Industrial 2 of 5................................................................................................................................................. 63
Verification...................................................................................................................................................................................... 63
Industrial 2 of 5 Min/Max Length ............................................................................................................................................... 64
STANDARD 2OF 5(IATA).................................................................................................................................................................... 65
Enable/Disable Standard 2 of 5................................................................................................................................................. 65
Verification...................................................................................................................................................................................... 65
Standard 2 of 5 Min/Max Length ............................................................................................................................................... 66
UK PLESSEY ......................................................................................................................................................................................... 67
Enable/Disable UK Plessey........................................................................................................................................................ 67
Verification...................................................................................................................................................................................... 67
UK Plessey Min/Max Length ...................................................................................................................................................... 67
MSI PLESSEY........................................................................................................................................................................................ 69
Enable/Disable MSI Plessey ...................................................................................................................................................... 69
Verification...................................................................................................................................................................................... 69
Check Digit ..................................................................................................................................................................................... 69
MSI Plessey Min/Max Length..................................................................................................................................................... 70
GS1 DATABAR (RSS-14) ................................................................................................................................................................... 71
Enable/Disable GS1 DataBar..................................................................................................................................................... 71
Prefix AI........................................................................................................................................................................................... 71
QR CODE .............................................................................................................................................................................................. 71
Enable/Disable QR Code............................................................................................................................................................ 71
QR Code Min/Max Length .......................................................................................................................................................... 72
QR Twin Code ............................................................................................................................................................................... 72
MICRO QR CODE ................................................................................................................................................................................. 73
Enable/Disable Micro QR Code................................................................................................................................................. 73
Micro QR Code Min/Max Length............................................................................................................................................... 73
DATA MATRIX ........................................................................................................................................................................................ 74
Enable/Disable Data Matrix........................................................................................................................................................ 74
Data Matrix Min/Max Length ...................................................................................................................................................... 74
Data Matrix Twin Code ................................................................................................................................................................ 74

MT581 User’s Manual V1.1
6
Rectangular Barcode ................................................................................................................................................................... 75
PDF417 ................................................................................................................................................................................................ 75
Enable/Disable PDF417.............................................................................................................................................................. 75
PDF417 Min/Max Length ............................................................................................................................................................ 76
PDF417 Twin Code ...................................................................................................................................................................... 76
AZTEC .................................................................................................................................................................................................... 77
Enable/Disable Aztec................................................................................................................................................................... 77
Aztec Min/Max Length ................................................................................................................................................................. 77
CHAPTER 7 APPENDIX ...............................................................................................................................................78
APPENDIX -NUMB ER S.......................................................................................................................................................................... 78
APPENDIX -UPPER CASE ALPHABETS ............................................................................................................................................... 79
APPENDIX -LOWER CASE ALPHABETS............................................................................................................................................... 81
APPENDIX –CONTROL CODES ............................................................................................................................................................ 83
APPENDIX –SYMBOLS ......................................................................................................................................................................... 85
APPENDIX –FUNCTION KEYS.............................................................................................................................................................. 88
APPENDIX –NAVIGATION KEYS .......................................................................................................................................................... 89
APPENDIX –MODIFIER KEYS............................................................................................................................................................... 90
APPENDIX -ABORT............................................................................................................................................................................... 91
APPENDIX -DEFAULT TABLE ............................................................................................................................................................... 92
APPENDIX -FACTORY ID ..................................................................................................................................................................... 97
APPENDIX -AIM ID .............................................................................................................................................................................. 99
APPENDIX -ASCII TABLE .................................................................................................................................................................. 101
VERSION HISTORY....................................................................................................................................................105

MT581 User’s Manual V1.1
7
Chapter 1 Introduction
This user’s manual is dedicated to MT581, a wearable 2D wireless ring scanner that enables
hands-free scanning for mobile operators who work with smartphones or other mobile devices of
iOS and Android platform. With built-in Bluetooth 5.0 technology and disinfectant-ready housing,
MT581 provides 10-meters wireless data transmission and microbe-free scanning experience.
Specifications
Optic & Performance
Light Source White LED
625nm visible red LED
Sensor
640 x 480
Scan Rate
60 Frames/Sec
Resolution 5mil (1D barcode)
6.67mil (2D barcode)
Scan Angle Horizontal 42°
Vertical 31.5°
Pitch Angle
±60°
Skew Angle
±30°
Roll Angle
360°
Print Contrast Ratio
40%
Width of Field
156mm (13Mil Code39)
Memory
2MB (20,000 barcodes)
Guaranteed D.O.F
(Environment: 800 lux)
4 Mil Code 39 : 45 ~ 145mm
5 Mil Code 39 : 45 ~ 145mm
LED Indicator
Function Button/
Power Button
Exit Window
Velcro Strap
Micro USB port
(with protective cover)
Restart Button
(insert pin into the hole)
Touch-Activated
Trigger Button

MT581 User’s Manual V1.1
8
13 Mil UPC/EAN : 65 ~ 345mm
15 Mil QR Code : 35 ~ 165mm
6.67 Mil PDF417 : 55 ~ 120mm
10 Mil Data Matrix : 50 ~ 115mm
Physical Characteristics
Dimension
W27.5 x L46.2 x H26.8 mm
Weight
19.4g
Color
Black/White
Material
PC+ABS
Cable Micro(M) to USB A(M) Cable, 1.5M
Trigger Touch Switches (Trigger Buttons)
Function/Power Button
Indicator
LED, Buzzer
Electrical
Operation Voltage
3.7 VDC ± 5%
Working Current
< 190mA
Standby Current
< 25mA
Battery
3.7V, 240mAh, Li-Polymer Battery
Number of Scan
(per full charge)
4500 scans
(1 scan/ 5 secs, Bluetooth connected)
Connectivity
Radio
Bluetooth 5.0 dual mode (Class 2)
Range
33 ft/ 10m (line of sight)
Interface/ Profile
BT HID
BT SPP
USB HID
USB VCP
Memory
User Environment
Operating Temperature
-10 ~ 50˚C
Storage Temperature
-20 ~ 60˚C
Humidity
0% ~ 95%RH (Non-condensing)
Drop Durability
1.5M
Sealing
IP42
Ambient Light
100,000 Lux (Sunlight)
1D Symbologies
UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2
of 5, Codabar, Matrix 2 of 5, Code 11, Code
93, Code 32, Code 128, Standard Code 39,
Code 39, Interleaved 2 of 5, MSI Plessey
Code, UK Plessey Code, EAN/UCC 128,

MT581 User’s Manual V1.1
9
IATA Code, GS1 Databar
2D Symbologies QR Code, Micro QR Code, PDF417, Data
Matrix, Aztec
Regulatory
ESD
Functional after 4KV contact, 8KV air
discharge
EMC/RF
TBA
Safety Approval
EN/IEC62471
Environmental
WEEE, RoHS 2.0
Medical Compliance
ISO 22196 (JIS Z 2801), ISO 11737-1/2
Beeper Indication
Beeper Status
Single beep
Good read
Single short beep The scanner reads a Code39 ASCII during
multi-step configuration
Two beeps
Wireless connection
The scanner successfully reads a
configuration barcode
Three beeps
Wireless disconnection
Three short beeps
The scanner reads a barcode while
disconnected
The scanner reads an unexpected barcode
during multi-step configuration. (Please
scan “
Abort
” and start over)
Memory Full
Four beeps (Hi-Lo-Hi-Lo)
Out of range / Poor connection
Five beeps
Low power
LED Indication
LED Status
Off
Power off / Standby / Connected
Flashing blue
Disconnected / Discoverable

MT581 User’s Manual V1.1
10
One green flash
Good read
Flashing red
Low power
Solid red
Charging
