MT10 Linear Image Barcode Scan Engine, Integration Guide, V1.9
MT10
MT10
(3.3V
(3.3V Linear Linear Image Image Barcode Barcode Scan Scan Engine) Engine)
Integration
Integration Guide Guide
Version 1.9 DATE: 2018/09/03

MT10 Linear Image Barcode Scan Engine, Integration Guide, V1.9
TABLE OF CONTENTS
1.
1. INTRODUCTION INTRODUCTION..................................................................................................... 1 1
1-1.
1-1. MT10 MT10 Block Block Diagram Diagram................................................................................ 1 1
1-2.
1-2. Electric Electric Interface Interface........................................................................................2 2
1-2-1.
1-2-1. Pin Pin Assignment Assignment.............................................................................. 2 2
1-2-2.
1-2-2. Electric Electric Characteristics Characteristics................................................................ 5 5
1-2-3.
1-2-3. Flex Flex Cable Cable........................................................................................ 5 5
1-3.
1-3. Operational Operational Timing Timing................................................................................... 6 6
1-3-1.
1-3-1. Power Power Up Up.......................................................................................... 6 6
1-3-2.
1-3-2. Sleep Sleep (Idle) (Idle) Mode Mode........................................................................... 6 6
1-3-3.
1-3-3. Decode Decode Timing Timing................................................................................ 6
6
1-3-4.
1-3-4. Summary Summary of of Operation Operation Timings Timings................................................. 7 7
2.
2. SPECIFICATIONS SPECIFICATIONS.................................................................................................. 7 7
2-1.
2-1. Introduction Introduction................................................................................................ 7 7
2-2.
2-2. Technical Technical Specifications Specifications......................................................................... 7 7
2-3.
2-3. Interface Interface....................................................................................................... 9 9
2-3-1.
2-3-1. UART UART Interface Interface............................................................................... 9 9
2-3-2.
2-3-2. USB USB Interface Interface................................................................................ 10 10
2-4.
2-4. Operation Operation Method Method....................................................................................11 11
2-5.
2-5. Mechanical Mechanical Dimension Dimension........................................................................... 11 11
2-6.
2-6. Scanning Scanning Range Range...................................................................................... 12 12
2-6-1.
2-6-1. Typical
Typical Scanning Scanning Range Range............................................................ 12 12
2-6-2.
2-6-2. Guaranteed Guaranteed Scanning Scanning Range Range................................................... 13 13
2-7.
2-7. Pitch Pitch Angle, Angle, Roll Roll Angle Angle and and Skew Skew Angle Angle.......................................... 14 14
2-8.
2-8. Specular Specular Dead Dead Zone Zone............................................................................... 15 15
2-9.
2-9. Curvature Curvature Degree Degree.................................................................................... 16 16
2-10.
2-10. Flex Flex Cable Cable Specification Specification..................................................................... 16 16
2-11.
2-11. Connector Connector Specification Specification......................................................................17 17
3.
3. INSTALLATION INSTALLATION.................................................................................................... 18 18
3-1.
3-1. Electrostatic Electrostatic Discharge Discharge Cautions Cautions....................................................... 18 18
3-2.
3-2. Mechanical Mechanical Dimension Dimension.......................................................................... 18 18
3-3.
3-3. Window Window Materials Materials.................................................................................... 19 19
3-4.
3-4. Window Window Specifications Specifications.......................................................................... 20 20
3-5.
3-5. Window Window Care Care............................................................................................ 22 22
4.
4. REGULATIONS REGULATIONS.................................................................................................... 22 22
5.
5. DEVELOPMENT DEVELOPMENT KIT KIT........................................................................................... 23 23
6.
6. SLEEP SLEEP (IDLE) (IDLE) MODE MODE.......................................................................................... 24 24
7.
7. PARAMETER PARAMETER SETUP SETUP.......................................................................................... 25 25
8.
8. VERSION VERSION HISTORY HISTORY............................................................................................ 26 26

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
1
1.
1. INTRODUCTION INTRODUCTION
The MT10 Linear Image Barcode Scan Engine is designed for 1D barcode middle
range reading, and high performance barcode scanning with optimal performance and
easy integration. MT10 is ideal for integration into data terminals and other small
mobile devices.
The MT10 consists of 2 illumination LEDs, a high-quality linear image sensor and a
microprocessor that contains powerful firmware to control all aspects of operations
and enable communication with the host system over the standard set of
communication interfaces.
Two interfaces, UART & USB, are available. UART interface communicates with the
host system over TTL-level RS232 communication; USB interface emulates a USB
Keyboard device and communicates with the host system over USB.
1-1
1-1. .MT10 MT10 Block Block Diagram Diagram

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
2
1-
1-2 2. .Electric Electric Interface Interface
1-2-1.
1-2-1. Pin Pin Assignment Assignment
(Back View of MT10)
Pin# UART USB I/O Description Schematic Example
1 VCC VCC ------------ Supply voltage input.
Must always be
connected to a 3.3V
power supply.
+3V3
2 GND GND ------------ Power and signal
ground.
3 RXD ------------ Input UART TTL data input.
Sipex®Vendor P/N: SP232ACT
4 TXD ------------ Output UART TTL data output.
Sipex®Vendor P/N: SP232ACT
Pin13
Pin1

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
3
Pin# UART USB I/O Description Schematic Example
5 CTS Input When handshaking is
enabled, host
authorizes MT10 to
transmit data on TXD
line.
Sipex®Vendor P/N: SP232ACT
USB D+ Bidirectional Differential Signal
Transmission
------------------------------------------
6 RTS Output When handshaking is
enabled, MT10
requests permission
from host to transmit
data on TXD line.
Sipex®Vendor P/N: SP232ACT
USB D- Bidirectional Differential Signal
Transmission
------------------------------------------
7Power
down
Power
down
Output Active high, it indicates
that the MT10 is in
Sleep Mode (See
Chapter 6 for details)
------------------------------------------
8 Buzzer Buzzer Output Active high: Power-Up
or a successful
barcode decoded.
PWM controlled signal
canbeusedtodrivean
external buzzer for a
successful barcode
decoded (Good Read).
R3
10R
Buzzer
Q1
2N3904
Q2
2N3904
R6 2K7
R7 6K8
R8
3K3
BZ
BZ1
BZ_2.7K
2 1
HD1
1N 4148
1 2
+ C8
10uF
+
-
VCC

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
4
Pin# UART USB I/O Description Schematic Example
9 LED LED Output Active high, it indicates
the status of Power-Up
or a successful
barcode decoded
(Good Read).
LED1
GREEN
12
Q4
2N3904
R11
330R
R13 4K7
Decode LED
VCC
10 Boot 0 Boot 0 Input Reserved for
production only.
------------------------------------------
11 Trigger Trigger Input High: Power-up/Standby
Low: Scanning Operation
*Note:
1. Scanning operation
continues until a barcode
is successfully decoded
or the trigger is released
(pull high). To proceed to
the next scanning
operation, release (pull
high) first and press (pull
low) the trigger again.
2. Pull low at power-up
will prompt the scan
engine into firmware
update mode.
12 Reset Reset Input Reserved for
production only.
------------------------------------------

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
5
1-2-2.
1-2-2. Electric Electric Characteristics Characteristics
Symbol Ratings Min Max Unit
VIH Input high level 2.0 3.6 V
VIL Input low level 0 1.1 V
VOH Output high level 2.9 V
VOL Output low level 0.4 V
|△VDDx|Variations between different VDD
power pins 50 mV
*Note:
1. Power Supply:V
DD=3.3
2. Exposure to maximum rating conditions for extended periods may affect device reliability.
1-2-
1-2-3 3. .Flex Flex Cable Cable
The flex cable is used to connect MT10 to the host side. There are 13
pins on the MT10 (engine) side and 12 pins on the host side. Please
see 2-10 for more details of flex cable.
Flex cable
(P/N: 6351-0501113)
Pin# Pin Assignment To Host
1VCC
2GND
3RXD
4TXD
5USBD+/CTS
6USBD-/RTS
7PowerDown
8 Buzzer
9LED
10 Boot0
11 Trigger
12 Reset
*Note: Conforms to MARSON MT700/MT710D’s pin assignment.
112121
(contact)
(contact)
Host
Engine

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
6
1-3.
1-3. Operational Operational Timing Timing
This chapter describes the timing associated with the various operating modes of
the MT10 including Power Up, Sleep Mode, and Decode Timing.
1-3-
1-3-1 1. .Power Power Up Up
When power is initially applied, the MT10 is activated and begins the
process of initialization. Once initialization (duration ≦10mS) is
completed, the MT10 enters Standby Mode and is ready for barcode
scanning.
1-3-
1-3-2 2. .Sleep Sleep (Idle) (Idle) Mode Mode
The MT10 will enter Sleep (Idle) Mode and output a Power Down signal
(Active high) after a programmable time period has elapsed without any
activity. Please see Chapter 6 for more details about Sleep Mode.
1-3-
1-3-3 3. .Decode Decode Timing Timing
In Standby Mode, The MT10 is activated by the Trigger signal which MUST
be kept low for at least 20 ms until the successful scan is achieved, as
indicated by the Buzzer/LED signals.
In Sleep Mode, the MT10 can be waken up by the Trigger signal which
MUST be kept low for at least 20 mS until the successful scan is achieved,
as indicated by the Buzzer/LED signal.
The total scan and decode time is approximately equal to the time from the
Trigger signal going low to the Buzzer/LED signal going high. This time will
vary slightly based on several factors including barcode quality, barcode
type and the distance between MT10 and the barcode scanned.
Upon a successful scan, the MT10 outputs the Buzzer/LED signal and
keeps this signal for the duration of the transmission of the data decoded to
the host side. The duration is about 75 ms.
Therefore, the total duration of a typical scanning operation (from Trigger
turning low to the end of Buzzer PWM signal) is also approximately 120mS.

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
7
1-3-
1-3-4 4. .Summary Summary of of Operation Operation Timings Timings
1. The maximum duration of initialization is 10mS.
2. The maximum duration of scanning operation in Standby Mode is 120mS.
3. The minimum duration of waking up MT10 from Sleep Mode by
Trigger signal is about 2 ms.
4. The maximum duration of waking up MT10 from Sleep Mode by Trigger
signal and completing decode (when barcode is within optimal focus) is
about 120ms
2.
2. SPECIFICATIONS SPECIFICATIONS
2-1.
2-1. Introduction Introduction
This chapter provides technical specifications of the MT10 scan engine.
Operating method, scanning range and scan angle are also presented.
2-2.
2-2. Technical Technical Specifications Specifications
Optic & Performance
Light Source 625nm visible red LED
Sensor Linear Image Sensor
Scan Rate 650 Scans/ sec
Resolution 4mil/ 0.1mm
Scan Angle 41°
Print Contrast Ratio 30%
Width of Field 140mm (13Mil Code39)
Typical
Depth Of Field
(Environment: 800 lux)
4 Mil Code39: 36 ~ 70mm (4 digits)
5 Mil Code39: 30 ~ 95mm (4 digits)
10 Mil Code39: 21 ~ 201mm (4 digits)
15 Mil Code39: 35 ~ 285mm (4 digits)
13 Mil UPC/ EAN: 34 ~ 239mm (13 digits)
Guaranteed
Depth Of Field
(Environment: 800 lux)
4 Mil Code39: 45 ~ 70mm (4 digits)
5 Mil Code39: 40 ~ 95mm (4 digits)
10 Mil Code39: 35 ~ 195mm (4 digits)
15 Mil Code39: 45 ~ 275mm (4 digits)
13 Mil UPC/ EAN: 40 ~ 230mm (13 digits)
Physical Characteristics

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
8
Dimension W14 x L11.9 x H7 mm
Weight 1g
Color Black
Material PC
Cable 13pin to 12pin flex cable
Electrical
Operation Voltage 3.3VDC±0.15VDC
Working Current < 75mA (UART) ; < 85mA (USB)
Standby Current < 35mA (UART) ; < 45mA (USB)
Idle Current
(Sleep Mode)< 300uA (UART) ; < 500uA (USB)
Surge Current <500mA
Connectivity
Interface UART (TTL-level RS232)
USB (HID Keyboard)
User Environment
Operating Temperature -20°C ~ 60°C
Storage Temperature -20°C ~ 60°C
Humidity 0% ~ 95%RH (Non-condensing)
Drop Durability 1.5M ()
Ambient Light 100,000 Lux (Sunlight)
Symbologies
UPC-A/ UPC-E
EAN-8/ EAN-13
Matrix 2 of 5
China Postal Code (Toshiba Code)
Industrial 2 of 5
Interleaved2of5
Standard 2 of 5 (IATA Code)
Codabar
Code 11
Code 32
Standard Code 39
Full ASCII Code 39
Code 93
Code 128
EAN/ UCC 128

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
9
MSI Plessey Code
UK Plessey Code
Telepen Code
GS1 Databar
Regulatory
ESD
Functional after 4KV contact, 8KV air discharge
(it requires housing that is designed for ESD
protection and stray from electric fields.)
EMC FCC – Part15 Subpart B (Class B)
CE – EN55022, EN55024
Safety Approval IEC 62471 (Exempt Group)
Environmental WEEE, RoHS 2.0
2-
2-3 3. .Interface Interface
2-3-1.
2-3-1. UART UART Interface Interface
Below default values of communication parameters apply to both
Standard mode and Command mode firmware.
Baud rate: 9600
Data Bits: 8
Parity: None
Stop Bit: 1
Handshaking: None
Flow Control Timeout: None
ACK/NAK: OFF
BCC: OFF
A. Standard Mode
Firmware version: SM3-d-x.xx (MT10 P/N: 110P-A000000)
Characteristics:
(1) Configurable by scanning configuration barcodes or
Ez Utility®(a PC-based software utility, available for download at
www.marson.com.tw)
(2) Supports hardware trigger only
Interface Configuration Barcode:

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
10
UART
Scanning above barcode will set your MT10 to UART interface.
B. Command Mode
Firmware version: SM3-d-x.xx.CMD (MT10 P/N: 110P-4000000)
Characteristics:
(1) Configurable by commands sent from host or
BEO®(a PC-based software utility, available for download at
www.marson.com.tw)
(2) Supports both hardware and software triggers
Interface Configuration Barcode:
Not supported.
2-3-2.
2-3-2. USB USB Interface Interface
Firmware version: SM3-d-x.xx (MT10 P/N: 110P-A000000)
Characteristics:
(1) Configurable by scanning configuration barcodes or
Ez Utility®(a PC-based software utility, available for download at
www.marson.com.tw)
(2) Supports hardware trigger only
(3) Emulates a USB Keyboard device
Interface Configuration Barcode:
USB HID
Scanning above barcode will set your MT10 to USB interface.

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
11
2
2- -4. 4. Operat Operation ion Method Method
1. At power-up, the MT10 sends the Power-Up signals over Buzzer and LED
pins as an indication that the MT10 enters into Standby Mode and is ready
for operation.
2. Once the MT10 triggered by either hardware or software method, it will emit a
narrow, horizontal slab of light which is aligned with the sensor’s field ofview.
3. The linear image sensor captures the linear image of barcode and produces
an analog waveform, which is sampled and analyzed by the decoder
firmware running on the MT10.
4. Upon a successful barcode decoded, the MT10 turns off the illumination
LEDs, sends the Good Read signals over Buzzer and LED pins and transmits
the decoded data to the host.
5. The MT10 may enter into Sleep Mode (Please see Chapter 6 for more
details) after a period of inactivity in order to reduce power consumption.
2-
2-5 5. .Mechanical Mechanical Dimension Dimension
Front View Side View
Top Vie w

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
12
2-
2-6 6. .S Scanning canning R Range ange
2-
2-6 6-1 -1. .Typical Typical S Scanning canning R Range ange
Test Condition:
Barcode Length: Code39 – 4 characters
EAN/UPC – 13 characters
Bar & Space Ratio: 1 to 2.5
Ambient Light: > 500 lux
Minimum & Maximum Scan Distance
Symbology Resolution Distance No. of Encoded Characters
Standard
Code 39
(w/o checksum)
4Mil 36 ~ 70 mm
4char.
5Mil 30 ~ 95 mm
10 Mil 21 ~ 201 mm
15 Mil 35 ~ 285 mm
EAN 13 13 Mil 34 ~ 239 mm 13 char.
Maximum Scan Width
Symbology Resolution Barcode Length No. of Encoded Characters
Standard
Code 39
(w/o checksum)
13 mil 140 mm 27 char.

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
13
2-
2-6 6-2 -2. .Guaranteed Guaranteed S Scanning canning R Range ange
Test Condition:
Barcode Length: Code39 – 4 characters
EAN/UPC – 13 characters
Bar & Space Ratio: 1 to 2.5
Ambient Light: > 500 lux
Minimum & Maximum Scan Distance
Symbology Resolution Distance No. of Encoded Characters
Standard
Code 39
(w/o checksum)
4Mil 45 ~ 70 mm
4char.
5Mil 35 ~ 95 mm
10 Mil 35 ~ 195 mm
15 Mil 45 ~ 275 mm
EAN 13 13 Mil 40 ~ 230 mm 13 char.
Maximum Scan Width
Symbology Resolution Barcode Length No. of Encoded Characters
Standard
Code 39
(w/o checksum)
13 mil 140 mm 27 char.

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
14
2
2- -7. 7. P Pitch itch A Angle, ngle, Roll Roll A Angle ngle and and Skew Skew A Angle ngle
Be aware of the tolerance for the pitch, roll and skew angle of bar code you are
trying to scan.
Pitch Angle: ± 30° Roll Angle: ± 20°
Skew Angle: ± 40°

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
15
2
2- -8. 8. Specular Specular Dead Dead Zone Zone
Do not place the MT10 directly over the barcode. The light reflecting directly
back into the MT10 from the barcode is known as specular reflection, which can make
decoding difficult. The specular dead zone of MT10 is up to 5° depending on target
distance and substrate glossiness.
Specular Dead Zone: ± 5°

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
16
2
2- -9. 9. Curvature Curvature Degree Degree
The curvature degree of a scanned barcode is specified as below:
2
2- -10. 10. Flex Flex C Cable able Specification Specification
Below is the drawing of the flat cable(P/N: 6351-0501113) that comes with MT10.
Barcode Code 39 (L=32 mm) Code 39 (L=43 mm)
Resolution 13 mil (0.33 mm) 20 mil (0.51 mm)
RR≧15 mm R ≧20 mm
d40 mm
PCS 0.9 (printed on photographic paper)
Bottom
V
iew Top View Top View
Bottom View
(Stiffener)
(Contact)
(Contact)
(Stiffener)

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
17
2
2- -11. 11. Connector Connector Specification Specification
12-pin Molex®FPC Connector (Molex P/N: 54548-1229), to be installed on Host
side.

MT10 Linear Image Scan Engine, Integration Guide, V1.9
___________________________________________________________________________________
18
3
3. .INSTALLATION INSTALLATION
The MT10 scan engine is designed specifically for integration into customer's housing
for OEM applications. However, the MT10’s performance will be adversely affected or
permanently damaged when mounted into an unsuitable enclosure.
Warning: The limited warranty is void if the following recommendations are not
adhered to when mounting the MT10.
3-1.
3-1. Electrostatic Electrostatic Di Discharge scharge Cautions Cautions
All MT10s are shipped in ESD protective packaging due to the sensitive nature of
the exposed electrical components.
1. ALWAYS use grounding wrist straps and a grounded work area when
unpacking and handling the MT10.
2. Mount the MT10 in a housing that is designed for ESD protection and stray
electric fields.
3-2.
3-2. Mechanical Mechanical Dimension Dimension
When securing the MT10 by utilizing the self-forming screws:
1. Leave sufficient space to accommodate the maximum size of the MT10.
2. Do not exceed 1kg-cm (0.86 lb-in) of torque when securing the MT10 to the
host.
3. Use safe ESD practices when handling and mounting the MT10.
Front View Side View
Top Vie w
