6" CAR POLISHER
172042
Owner’s Manual
PRODUCT SPECIFICATIONS
Rating:
120V, 60Hz, AC
Amperes:
0.5 AMP
No load speed:
3,600 OPM
Pad diameter:
6"
Weight:
2 lb 14 oz (1.3 kg)
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665 Monday –Friday from 9am to 5pm
Eastern Standard Time
Technical questions
Replacement parts
Parts missing from package
Manufactured For and Distributed By
True Value®Company, Chicago, IL
©2013 True Value Company
Made in China

2
Product specifications ………….………………………………………………………………...
1
Table of contents ……………………………………………………………………..................
2
General safety warnings …………………………………………………………………………
3
General power tool safety rules ……………………………………………………………......
4
Eye, ear & lung protection ……………………………………………………………………….
4
Electrical safety …………………………………………………………………………………...
4
Power tool safety ……………………………………………………………………..................
5–6
General safety rules ……………………………………………………………………………...
5
Work area safety ………………………………………………………………….………………
5
Electrical safety …………………………………………………………………………………...
5
Personal safety …………………………………………………………………………………...
5
Power tool use and care.…………………………………………………………………………
6
Service …………………………………………………………………………………………….
6
Specific safety rules ……………………………………………………………………………...
6
Extension cord safety ………………………………………………………….…………………
7
Symbols ……………………………………………………………………………………………
8
Know your polisher ………………………….........................................................................
9
Assembly and operating …………………………………………………………………………
10–13
Wash vehicle or boat …………………………………………………………………………….
10
Attaching the wax applicator bonnet to the foam pad ………………………………………..
10
Applying paste wax to the bonnet ………………………………………………………………
10
Applying liquid wax to the bonnet ………………………………………………………………
10
Turning polisher ON & OFF ……………………………………………………………………..
11
Applying wax to the surface to be polished ……………………………………………………
11–12
Attaching the polishing bonnet to the foam pad ………………………………………………
12
Buffing and polishing –removing the wax from the surface …………………………………
12–13
Car care tips ………………………………………………………………………………………
13
Maintenance ………………………………………………………………………………………
14–15
Replacing the pad assembly ……………………………………………………………………
14
Exploded view ………………………………………………………………………...................
16
Parts list …………………………………………………………………………………………..
17
Warranty ……………………………………………………………………….………………….
17
TABLE OF CONTENTS

3
READ AND UNDERSTAND ALL SAFETY AND OPERATIONAL
INSTRUCTIONS. Failure to follow the safety rules listed below and other basic
safety precautions may result in serious personal injury. KEEP THIS MANUAL,
SALES RECEIPTS AND APPLICABLE WARRANTY FORMS FOR FUTURE
REFERENCE.
Safety Symbols
The purpose of safety symbols is to alert you of the potential safety RISKS.
Recognize and understand them. Follow the instructions provided.
SYMBOL
MEANING
Failure to obey a DANGER safety alert WILL result in
serious personal injury or death to you or to others.
Always obey all messages following this symbol to
reduce the risk of serious personal injury or death.
Failure to obey a WARNING safety alert MAY result in
serious personal injury or death to you or to others.
Always obey all messages following this symbol to
reduce the risk of potential serious personal injury or
death.
Failure to obey a CAUTION safety alert MAY result in
personal injury or property damage to you or to others.
Always obey all messages following this symbol to
reduce the risk of personal injury or property damage.
Failure to obey a NOTICE or a CAUTION (without a
safety alert) MAY result in property damage to you or to
others. Always obey all messages following this
symbol to reduce the risk of property damage.
GENERAL SAFETY WARNINGS
This instruction manual includes the following:
General Safety Rules
Specific Safety Rules and Symbols
Functional Description
Assembly
Operation
Maintenance
Accessories
SAVE THESE INSTRUCTIONS FOR REFERENCE

4
ALWAYS WEAR EYE PROTECTION THAT CONFORMS
WITH CSA REQUIREMENTS or ANSI SAFETY
STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage.
Prescription eyeglasses ARE NOT a replacement for
proper eye protection.
Non-compliant eyewear can cause serious injury if
broken during the operation of a power tool.
Use hearing protection, particularly during extended
periods of operation of the tool, or if the operation is
noisy.
WEAR A DUST MASK THAT IS DESIGNED TO BE
USED WHEN OPERATING A POWER TOOL IN A
DUSTY ENVIRONMENT.
Dust that is created by power sanding, sawing, grinding,
drilling, and other construction activities may contain
chemicals that are known to cause cancer, birth defects,
or other genetic abnormalities. These chemicals include:
Lead from lead-based paints, Crystalline silica from bricks,
cement, and other masonry products, Arsenic and
chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies,
according to how often this type of work is performed. In
order to reduce exposure to these chemicals, work in a
well-ventilated area, and use approved safety equipment,
such as a dust mask that is specifically designed to filter
out microscopic particles.
To avoid electrical hazards, fire hazards or damage to
the tool, use proper circuit protection.
This tool is wired at the factory for 120 V AC operations. It
must be connected to a 120 V AC, 15 A circuit that is
protected by a time-delayed fuse or circuit breaker. To
avoid shock or fire, replace power cord immediately if it is
worn, cut or damaged in any way.
GENERAL POWER TOOL SAFETY RULES
SAVE THESE INSTRUCTIONS FOR REFERENCE

5
WARNING: Read all safety warnings
and instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
Work area safety
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of a ground fault
circuit interrupter (GFCI) reduces the risk of
electric shock.
Personal safety
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in
moving parts.
If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
POWER TOOL SAFETY
!

6
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified
repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
WARNING: This product contains
chemicals known to the State of California to
cause cancer and birth defects or other
reproductive harm.
WARNING: Some dust created by power
sanding, sawing, grinding, drilling, and other
construction activities contain chemicals
known to cause cancer, birth defects, or
other reproductive harm. Some samples of
these chemicals are:
lead from lead-based paints,
crystalline silica from bricks and
cement and other masonry products,
and
arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well-ventilated area, and
work with approved safety equipment, such as
those dust masks that are specially designed to
filter out microscopic particles.
Always wear eye protection. Any power tool can
throw foreign objects into your eyes and cause
permanent eye damage. ALWAYS wear safety
goggles (not glasses) that comply with ANSI
safety standard Z87.1. Everyday glasses have
only impact resistant lenses. They ARE NOT
safety glasses.
WARNING: Glasses or goggles not in
compliance with ANSI Z87.1 could cause
serious injury when they break.
Never allow fingers or clothing to contact the
buffing/polishing pads while tool is
operating.
Always use two hands to control the
buffer/polisher to avoid loss of control.
Never submerge the buffer/polisher in water
or any other liquid. The tool will be damaged
and fire could result.
SAVE THESE INSTRUCTIONS FOR REFERENCE
POWER TOOL SAFETY
SPECIFIC SAFETY RULES
!
!
!

7
WARNING: Know your polisher. Do not
plug in the polisher until you have read and
understand this Instruction Manual. Learn the
tool’s applications and limitations, as well as the
specific potential hazards related to this tool.
Following this rule will reduce the risk of electric
shock, fire, or serious injury.
WARNING: Use of this tool can generate
and/or disburse dust, which could cause
serious and permanent respiratory or other
injury. Always use NIOSH/OSHA approved
respiratory protection appropriate for the dust
exposure. Direct particles away from face and
body.
WARNING: Always use NIOSH/OSHA
approved hearing protection when
buffing/polishing particularly during extended
periods of operation. Failure to heed this
warning could result in permanent hearing loss.
WARNING: Always unplug the tool from
the power source before changing the
buffing/polishing pad and when cleaning the
tool.
Do not wear gloves, neckties or loose clothing.
WARNING: Keep the extension cord
clear of the working area. Position the cord so
it will not get caught on the workpiece, tools or
any other obstructions while you are working
with the power tool.
Make sure any extension cord used with this
tool is in good condition. When using an
extension cord, be sure to use one of heavy
enough gauge to carry the current the tool will
draw. An undersized cord will cause a drop in
line voltage resulting in loss of power and
overheating.
The table at right shows the correct size to use
according to cord length and nameplate ampere
rating. If in doubt, use the next heavier gauge.
The smaller the gauge number the heavier the
cord.
Be sure your extension cord is properly wired
and in good condition. Always replace a
damaged extension cord or have it repaired by a
qualified electrician before using it. Protect your
extension cord from sharp objects, excessive
heat and damp or wet areas.
Use a separate electrical circuit for your power
tools. This circuit must not be less than 14
gauge wire and should be protected with either
a 15 AMP time delayed fuse or circuit breaker.
Before connecting the power tool to the power
source, make sure the switch is in the OFF
position and the power source is the same as
indicated on the nameplate. Running at lower
voltage will damage the motor.
WARNING: Repair or replace damaged
or worn extension cords immediately.
Select the appropriate extension cord gauge
and length using the chart below.
When operating a power tool outdoors, use an
outdoor extension cord marked “W-A” or “W”.
These cords are rated for outdoor use and
reduce the risk of electric shock.
WARNING: Keep the extension cord
clear of the working area. Position the cord
so it will not get caught on the workpiece,
tools or any other obstructions while you are
working with the power tool.
MINIMUM GAUGE (AWG)
EXTENSION CORDS (120V use only)
Amperage
rating
Total length
More
than
Not
more
than
25'
(7.5 m)
50'
(15 m)
100'
(30 m)
150'
(45 m)
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
EXTENSION CORD
SAFETY
!
!
!
!
!
!
!
EXTENSION CORD
SAFETY
SPECIFIC SAFETY RULES

8
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Liters
kg
Kilograms
H
Hours
N/cm2
Newtons per square
centimeter
Pa
Pascals
OPM
Oscillations per minute
Min
Minutes
S
Seconds
or a.c.
Alternating current
Three-phase alternating
current
Three-phase alternating
current with neutral
Direct current
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight construction
Protective grounding at
grounding terminal,
Class I tools
Revolutions or
reciprocations per
minute
Diameter
Off position
Arrow
Warning symbol
Wear your safety
glasses
Wear hearing protection
Wear breathing
protection
SYMBOLS
WARNING: Some of the following symbols may appear on the polisher. Study
these symbols and learn their meaning. Proper interpretation of these symbols will
allow for more efficient and safer operation of this tool.
!
This symbol designates that this tool is listed with
U.S. requirements by Underwriters Laboratories.
Conforms to UL Std. 60745-1 and 60745-2-4.
40VJ
E207985
ZS101K

9
Cooling
vents
Wool buffing
bonnet
CP-1502-8
KNOW YOUR POLISHER
Buffing pad
assembly
ON/OFF
switch
Palm
grip
Terry cloth wax
applicator bonnet
CP-1502-7

10
Your polisher is designed with random orbit
technology. The tool will perform better when
less pressure is applied. Applying excessive
pressure will slow down the random motion and
reduce the effectiveness of the tool.
WARNING: Always remove the plug
from the power source while changing
accessories.
WASH VEHICLE OR BOAT
Before applying polish or wax, it is important to
clean and dry all the surfaces to be polished or
waxed.
1. Wash, clean and dry the vehicle or boat.
2. Remove all road tar, grease spots and bug
stains with a general purpose cleaner.
3. Make sure the work area is dry.
ATTACHING THE WAX APPLICATOR
BONNET TO THE FOAM PAD
WARNING: Before changing accessories,
make sure the switch is in the OFF position and
the plug is removed from the power source.
1. Place wax applicator bonnet on foam pad
(Fig. 1).
2. ALWAYS make sure that the elastic strip
on the bottom of the bonnet is securely
tucked on the underside of the foam pad.
WARNING: Read, understand and follow
all instructions and warnings on polishes and
waxes.
APPLYING PASTE WAX TO THE BONNET
WARNING: Do not apply wax directly to
the surface to be polished.
Spread a heaping teaspoon of wax evenly over
the entire surface of applicator bonnet using a
putty knife or any other flat object (Fig. 2).
APPLYING LIQUID WAX TO THE BONNET
WARNING: Do not apply wax directly to
the surface to be polished.
Apply three swirls of wax over applicator bonnet
(Fig. 3).
This should be enough to cover ¼ of the car
surface. For the second and third applications of
wax to the bonnet, only use about half as much
wax as on the first application. The bonnet will
not absorb as much wax on these applications.
ASSEMBLY AND OPERATING
!
!
Fig. 1
!
!
!
Fig. 2
Fig. 3

11
TURNING POLISHER ON & OFF
To turn the tool ON, push the ON/OFF switch
button (1) downward (Fig. 4). To turn the tool
OFF, pull the ON/OFF switch button upward.
APPLYING WAX TO THE SURFACE TO BE
POLISHED
NOTES:
a) To avoid splashing waxes, ALWAYS start
and stop the buffer/polisher on or against the
surface to be polished.
b) Apply wax in a thin, even coat. Too much wax
does not add any more protection and only
makes the wax removal more difficult.
c) The random orbit motion of the buffer/polisher
provides wax application that cannot be
duplicated, not even “by hand”.
IMPORTANT: DO NOT apply excessive
pressure against the work surface with this tool.
The random orbit motion feature on this tool will
perform better when less pressure is applied.
Applying excessive pressure will slow the
random orbital motion and reduce the
effectiveness of the tool.
1. Place the extension cord (1) over your
shoulder to keep it safely out of your way
(Fig. 5).
2. Turn the buffer/polisher ON.
3. Apply wax in a straight line with either a
side-to-side or back-and-forth motion.
ALWAYS use broad, even strokes when
applying wax (Fig. 6).
ASSEMBLY AND OPERATING
For safety reasons, the operator must
read the sections of this Owner’s Manual
entitled "GENERAL SAFETY
WARNINGS", "POWER TOOL SAFETY",
"SPECIFIC SAFETY RULES", and
"SYMBOLS" before using this polisher.
Verify the following every time the
cordless driver is used:
1. The electrical cord is in good
condition.
2. Safety goggles, dust mask and
hearing protection are being worn.
Failure to observe these safety rules will
significantly increase the risk of injury.
WARNING
!
Fig. 4
Fig. 5
Fig. 6

12
Fig. 7
Fig. 9
APPLYING WAX TO THE SURFACE TO BE
POLISHED –cont’d
4. Start applying wax to the flat surfaces
(hood, trunk and roof) first. Wax one
section at a time (Fig. 7).
5. After flat surfaces are covered with wax, do
the sides. Hold tool with the extension cord
hanging free (Fig. 8).
6. It is easiest to apply the wax to the entire
surface before starting the removal phase,
however, follow the specific
recommendations of the wax or polish
being used.
7. Turn the buffer/polisher OFF when you
have finished applying wax with the
applicator bonnet.
8. Remove the wax applicator bonnet and use
it to apply polish by hand to all the hard-to-
reach surfaces (under bumpers, around
door handles, etc.) (Fig. 9).
9. Properly dispose of wax applicator bonnet.
ATTACHING THE POLISHING BONNET TO
THE FOAM PAD
1. Place the terry cloth bonnet on foam pad
(Fig. 10).
2. ALWAYS make sure that the
elastic strip on the bottom of the bonnet is
securely tucked on the underside of the
foam pad.
BUFFING AND POLISHING –REMOVING THE
WAX FROM THE SURFACE
NOTE: Remove wax in the same order as it was
applied.
1. Place extension cord over your shoulder.
2. Turn buffer/polisher ON.
Left
Right
ASSEMBLY AND OPERATING
Fig. 8
Fig. 10

13
BUFFING AND POLISHING –REMOVING THE WAX
FROM THE SURFACE –cont’d
3. Buff and polish (remove wax) when it has
dried to an even haze.
NOTE: For best results, use long,
sweeping strokes in a crisscross pattern
when removing wax (Fig 11).
4. Buff and polish the entire surface until all
dried wax is removed. Remove the bonnet
from time to time and shake out the dried
wax residue. A bonnet with excess residue
will cause streaking. You may need to
replace the bonnet with a new one if you
can’t get it clean enough to avoid streaking.
5. Use a clean terry cloth bonnet for final
buffing and polishing, or use a foam
polishing bonnet (sold separately) for the
ultimate “showroom” shine.
IMPORTANT: DO NOT apply excessive
pressure against the work surface with this tool.
The random orbital feature on this tool will
perform better when less pressure is applied.
Applying excessive pressure will slow down the
random orbiting motion and reduce the
effectiveness of the tool.
CAR CARE TIPS
1. Wash and polish the car 3 to 4 times a year
to help ensure paint protection.
2. Wash the car at least every two weeks with
a car wash solution that will not harm the
finish or strip the wax. AVOID washing with
household detergents.
3. Wash car with a clean sponge and dry with
a terry cloth towel to help prevent dirt from
scratching the paint. Start on the top and
work down.
4. Remove bugs, bird droppings, tree sap and
tar from the car’s surface on a daily basis.
5. ALWAYS make sure that the car’s surface
is cool before washing.
6. Avoid parking beside sprinklers, because
water spots are difficult to remove.
7. ALWAYS keep glass cleaner chemicals
away from painted surfaces. Spray the
cleaner onto a towel, NOT directly on the
windows.
ASSEMBLY AND OPERATING
Fig. 11

14
1. Terry cloth bonnets can be machine
washed in cold water, using a small
amount of detergent. Then machine dried
at medium temperature. For longer bonnet
life, we recommend hand washing and air
drying.
2. Wax applicator bonnets should only be
used once, and then disposed of properly.
3. To prolong the life of the foam pad,
ALWAYS store the buffer/polisher with the
pad face up.
4. Remove the bonnet from the foam pad
when the buffer/polisher is not in use, so
the pad can dry out and retain its original
shape.
5. DO NOT USE ABRASIVE COMPOUNDS
WITH THIS TOOL.
6. DO NOT apply too much wax to the
bonnet. Applying too much wax causes the
bonnet to become saturated and it will not
last as long. This makes polishing more
difficult and it takes longer.
7. If the bonnet is continually coming off the
pad, you may be using too much wax.
8. If buffing becomes difficult, you have used
too much wax.
9. Use only a mild soap solution and a damp
sponge to clean the buffer/polisher.
10. DO NOT immerse any part of the
buffer/polisher in liquid.
REPLACING THE PAD ASSEMBLY
1. Remove the screw (1), lock washer (2) and
flat washer (3) from the center of the pad
using a #2 screwdriver (Fig. 12).
2. Carefully remove the pad assembly (4)
from the shaft (5).
3. Press the new pad assembly onto the
shaft.
NOTE: Make sure the flat side of the disc
hole is oriented so it will slip over the
matching flat side of the shaft (6).
4. Once the pad assembly is pushed firmly
onto the shaft, fasten the assembly onto
the shaft using the flat washer, lock washer
and screw.
MAINTENANCE
Fig. 12

15
WARNING: When servicing, use only
original equipment replacement parts. Use of
any other part may create a hazard or cause
product damage.
DO NOT abuse power tools. Abusive practices
can damage the tool as well as the workpiece.
WARNING: DO NOT attempt to modify
tools or create accessories. Any such
alteration or modification is misuse and
could result in a hazardous condition
leading to possible serious injury. It will also
void the warranty.
CLEANING
DO NOT use solvents when cleaning plastic
parts. Most plastics are susceptible to damage
from various types of commercial solvents and
may be damaged by their use. Use a clean cloth
to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time allow
brake fluids, gasoline, petroleum-based
products, penetrating oils, etc. to come in
contact with plastic parts. They contain
chemicals that can damage, weaken or
destroy plastic.
WARNING: Inspect product before
every use. If any parts are missing, loose, or
damaged do not use this product until the
parts are replaced. Failure to do so could
result in possible serious personal injury.
WARNING: Disconnect the power
supply before assembling parts, making
adjustments, cleaning, or when it is not in
use. Disconnecting the tool will prevent
accidental starting, which could cause
serious personal injury.
LUBRICATION
All of the bearings in this buffer/polisher are
lubricated with a sufficient amount of high-grade
lubricant for the life of the unit under normal
conditions. Therefore, no further lubrication is
required.
MAINTENANCE
!
!
!
!
!

16
EXPLODED VIEW

17
WARNING: When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the polisher.
Any attempt to repair or replace electrical parts on this polisher may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline, at
1-866-349-8665 Monday –Friday from 9am to 5pm Eastern Standard Time.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
CP-1502-1 Kit
Switch & cover
1
2
CP-1502-2
Bridge rectifier
1
3
CP-1502-3 Kit
Power cord & strain relief
1
4
CP-1502-4 Kit
Brush & holder
2 Kits
5
CP-1502-5 Kit
Armature, fan & bearings
1
6
CP-1502-6 Kit
Foam pad, pad holder, eccentric shaft &
bearing kit
1
7
CP-1502-7
Terry cloth wax applicator bonnet
1
8
CP-1502-8
Wool buffing bonnet
1
PARTS LIST
!
Rev 1.6 10/06/2013
1-Year Limited Warranty:
This product is warranted for one 1-year against any defects in material and
workmanship. If defective; the product will be replaced free of charge.
Simply provide proof of purchase and return the tool to your place of
purchase. Normal wear or damage due to abuse, mishandling, or
unauthorized repair is not covered. This warranty does not apply to
accessories. This warranty gives you specific legal rights and you may
have other rights which vary from state to state.
For technical and product support or parts please call 1-866-FIXTOOL
(1-866-349-8665) Monday –Friday from 9am to 5pm Eastern Standard
Time.
WARRANTY
