Master Tailgaters MR-43-H2 User manual

CONTENTS FEATURES HOW TO INSTALL MIRROR MONITOR HOW TO WIRE
SPECIFICATIONS
The package contains the following:
01 Rearview mirror monitor
02 Wire harness
03 User manual
04 Wire cover
05 Remote control
Screen Size: 4.3 inch
Compatiable Systems: PAL / Auto / NTSC
Resolution: 480(H) X 272(V)
Working Voltage: 12V DC
Display Type: TFT-LCD
02
01
04
05
03
NOTE: Onstar system is the patent and trade mark from GM car factory respectively.
Back up camera display
4.3 inch ultra high brightness display screen
Automatic brightness adjustment
4.0 mm glass and car factory OEM bracket
Adjustable back up guide line
2-way video inputs
Rear View Mirror with Onstar
10 Pin come from mirror
10 Pin 16 Pin
16Pin come from your vehicle
Jumper harness
Two original Onstar connectors which can work with interior rear view mirror,
that is, 10pin and 16pin connectors. Our Onstar mirror’s equipped with 10pin
connector which can match the original 10pin Onstar mirror. A converted wire
harness is available to turn the original 16pin into 10pin.
HOW TO INSTALL REVERSE CAMERA
When a camera needs to be installed at the rear of vehicle, a good position
is usually at the top of the License plate where there is an under ledge.
1BAM 2XX
B
A
M
2
X
License plate
Camera
Rear view mirror monitor
Remove the original mirror
Car factory original mirror The plate on the windshield
Different cars have different brackets. It depends on your vehicle maker and
manufacturer.There are many methods to remove the original rear view
mirror, however, please don’t force the mirror off the bracket.
The manufacturer will not be responsible for damage caused to your car by
wrong installation of the mirror.
Install mirror monitor on the plate
Install rear view mirror along this directionTake down your original mirror, and make
the mirror monitor ready
windshield
Please make sure to install the mirror
to the end of the bottom without any loose
Contrarotate the xed rear view mirror
Torque is about 0.8-1.3 N.m
windshield
windshield
CAUTION!
NOTE: Always use caution, DO NOT force the mount. We will not be
responsible for broken windshields. If you are not sure how to remove
or re-install the mirror seek trained, qualied help.
5
Dangerous Ok
Windshield
Windshield
Dangerous Ok
1.
2.
For the items listed above, please check with your package box. If any
damage, please contact with the distributor or the agent as soon as
possible.
BACK UP CAMERA DISPLAY
AUTOMATIC BRIGHTNESS ADJUSTMENT
When the car is in reverse, the monitor will automatically display back up
camera.
The brightness of screen varies with ambient light, thereby, to make driver
get a clear and comfortable image when reversing.
When ambient light is weak, the screen will automatically
reduce the brightness and get better vision.
When ambient light is strong, the screen will automatically
increase the brightness and get better vision.
WEAK LIGHT
STRONG LIGHT
Original Onstar connector from your vehicle
FUSE
BOX
Black to GND
Red to ignition +12V
Green to reverse trigger
Purple to front trigger
To back up camera
To front camera
GND

MENU SETTING ADJUSTABLE GUIDE LINE
Remote control
Menu setting guidance
Enter the menu
Guide line clockwise
Menu parameter decreases
Menu parameter increases
Guide line up
Guide line left
Enter guide line adjustment
Guide line anti-clockwise
Guide line rig ht
Guide line down
as below.
SYSTEM
SCALE ON
ON
OFF
REAR TRI
PRESET
BRIGHTNESS 50
50
50
CONTRAST
COLOR
00NIGHT BRIGHTN.
About guide line
What the regular guide line is
How to adjust the guide line
Caution: keep the remote control 0.5m-1.0m from rearview mirror
when you usethe remote toadjust the parking lines.
R
Display on the monitor
L
UP Clockwise
Down
Right
left
Move the guide line Rotate the guide line
anticlockwise
Press the button to choose the L or R adjustable guideline
Remote control
3m
1m
2m
0.4m
3m
2m
1m
Right positionWrong position
MXT.71D
Generally, to help drivers estimate the distance from obstacles, there are
three lines for reference -red, yellow and green.Those lines are displayed on
the monitor when reversing. The green line is 3m away from the back of car
and the yellow line is 2m. The distant red line is1m away from the backside
of car while the closedred line is 0.4m. Bothreference lines onthe left and
right should leave 0.2m from the car.
guide lines, especially when camera is mounted on the left or right side of
car backside.
According to the site of standard reference line, we can put references such
as desks in the back side of the car. Compared with the marked references,
we can adjust the sites and angles of two guide lines displayed on the
monitor. You will get the accurate and safety guide lines once it coincides
with the references.
Press setting buttonto enter “guide line adjustment” mode. The system
adjust the rightguide line.
The up , down , left and rightbuttons are to adjust the
corresponding location of guide lines. The clockwise rotationand contra
rotating buttons are to adjust the angles of guide lines. It is easy to
the information.
Press the button, you will talk with on star Customer Service Consultant
then to answer your questions to meet your needs. You can get the
following service s:
2. Navigation route download
3. Real-time on -demand inspection
4. Renewal an d account management
5. Other related services
Press the button, t he full tone hands-free phone function will start to
make your driving call bec omes more secure and convenient. On star
Hands free calls have b een built-in in the vehicle. By pressing this button
you can achieve the following main functions:
1. Call or end the call
2. Answer the cal l
3. Use the s peakerphone voicecommand
4. Use the n avigation voicecommand
When the following emerge ncy occurs, press the button and you will get
the professional help from on Star Customer service consultant.
3. Other emergencies
FUNCTION OF BUTTONS This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference,
(2) this device must accept any interference received, including interference
approved by the party responsible for compliance could avoid the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occurin aparticular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment
should be installed and operated with minimum distance between 20cm the
radiator your body: Use only the supplied antenna.
No entertainment video is permit when driving except the demo
for navigation and backup cameradisplay!
This manual is only for your reference, please check the actual
product as the standard!
Ultra High Brightness
Mirror Monitor
Special for Onstar
U S ER MANUA L
When front camera is connec ted, you can select this input by pressing the
button one time for on, one time for o ff. The front camera input will shut
offin 20 seconds after the button is pushed.
While in reverse mode, if you fast press the b utton the brightness control
will display a nd each press will increase the brightness. Continue to press
and itwillcycle through to low a gain.
When the front c amera display is selected, if you place the car in reverse
the monitor will still automatically switch to the reverse camera for the
drivers safety.
Serial No.: 2018HK-043LAONSTAR0317
When the car is in reverse, short press “ ”, then you can switch among
“PICTURE”, “SYSTEM”, or enter out.
When you enter “PICTURE”,press “ ” to switch among the items.
setting is same as explanation above.
