Mastercare MC 001-7060 User manual

The Original Nordic
Human Handling Concept
MC 001-7060 128744 5744001974148
MC 001-7060
ISO 12 31 03 17
UDI-DI/GTIN
(UK) User Manual
01_22230102_UK
Regulation MDR 2017/745 for medical devices class 1
Article no. Name - Size
HMI no.
Master Glide Sif
Master Glide Sif

Thank you for choosing a product from master care A/S.
We recommend reading the user manual thoroughly before using the
product (-s).
The information in this user manual applies to the shown products
provided that the products have not been modied or customized
and that the products have been used as recommended in this user
manual.
If the costumer changes, repairs or uses the product in other combi-
nations than recommended by master care A/S the CE-approval no
longer applies and the guarantee becomes void.
In case of doubt, contact master care A/S or our distributor in your
area.
MDR (EU) 2017/745:
Products in this user manual are CE-approved and follows the harmo-
nized standards. This means that the products are in compliance with
the essential health and safety directives. The product(-s) comply with
the standards in the Medical Device Regulation MDR (EU) 2017/745 –
Class 1.
The intended use of the product/-s:
1) The product is places in pairs underneath the user’s thighs to reduce
friction when the user moves or is moved backwards on the seat.
2) Place the pair under the user’s thighs. Slide the leg strap of the sling
between the plates to minimize the risk of shear injuries.
Correct use of the product:
The product is intended for users who has problems with moving
backward on the seat or where mounting of the sling may cause risk
of shear injuries.
If the user isn’t able to move backwards in the seat, place 1-2 plates
under the thigh(-s). If possible, have the user lean away from the side
where the plate is mounted. Users who are active in one side of the
body, placement of a Sif plate in the opposite side may be enough.
Otherwise place a plate underneath both thighs.
Warning:
If the product is used for users with high risk of shear injuries a sliding
sheet is recommended between the user and the product.
Risk assessment:
Always make a risk assessment and a functional assessment of the
user prior to using the product. This way using the product for trans-
ferring or moving a user, is ergonomic and legally sound.
Knowledge of the product/transferring:
It is important that the user of the product has been properly instruc-
ted in the use of the product and has read the user manual thoroughly
prior to using the product.
master care A/S and our distributors provide education in the use of
products and on our website all user manuals can be found.
Life span:
The expected life span of products with normal wear and tear is 2-5
years. The products life span depends on the use and the user’s load.
Products with insufcient friction reduction, broken material or other
deciencies must be discarded. This way you will always keep a
sound and healthy work environment for both helper and user.
Make visual inspections frequently and preferably before every use.
Guarantee:
master care A/S provide a 2-year guarantee covering material defects
and manufacturing defects if the product has been used correctly.
Unintended events and injuries when misusing the products:
Unintended events must always be reported to the appropriate Na-
tional Authority and to master care A/S or the distributor in the current
country.
master care A/S and our distributors take no responsibility for per-
sonal injuries or product damages if the product(-s) have been used
in contravention of the by the manufacturer recommended intended
purpose or proper use of the product.
master-care.dk

User Manual - Master Glide Sif
Page 3
Placing a sling sheet using Master Glide Sif:
8. Remove the Master Glide Sif one at a time.
Repeat on the opposite side.
7. Insert the leg strap between the two Master
Glide Sif and pull it into place under the user´s
thigh.
5. Remove the Master Glide Sif on both sides by
rotating it and pulling it out. The user can lean
backwards again.
6. Place the sling sheet behind the user´s back
- Master Glide Thor can be used. Place the two
Master Glide Sif together under the user´s thigh
by pushing the tip of the boards into the surface.
3. The helper places them self in front of the user
and helps the user lean forward to free the back
from the backseat of the wheelchair.
4. The helper places the hands or the knee next
to the user´s knee and the user can easily be
pushed backwards into the correct position. The
more active user can push them self backwards.
2. If possible, ask the user to lean to the opposite
side. The helper places one Master Glide Sif un-
der each thigh by pushing the tip of the plate into
the cushion and then twisting it under the thigh.
1. Master Glide Sif is the perfect aid to help a
user backwards in a wheelchair. To erase the
pressure under the thighs, place the feet on the
chair´s footplates or e.g., on a Master Step On -
PMA-8091.
Move backwards in the wheelchair (1-2 helpers):
master-care.dk

HUMAN HANDLING CONCEPT
We support the Sustainable Development Goals
User Manual - Master Glide Sif
User Weight:
Recommended max. user weight: 200 kg
Maintenance:
Make visual inspections frequently and
preferably before every use. Check that the
product is not broken, has big scratches or
the like. Products with high friction or other
deciencies must be discarded.
Surface cleaning:
The surface of this product can be cleaned
with a wet cloth and soap.
User Manual:
Always read the User Manual thoroughly
before using the product.
Disinfectants:
This product tolerates alcoholic disinfectants
with a pH level between 5-9.
Disposal:
Always make sure to follow local guidelines
when disposing or discarding the product.
For more information, videos
Quick Guide etc., visit
www.master-care.dk
Reservations are made for printing errors.
WARNINGS
MC 001-7060 Master Glide Sif L 45 x W 20 x H 0,3 cm 1 200 kg
Max. User Weight
Number of
handles:
Size:Article no. - Product Name
Materials:
Polyethylene
Technical Specikations
Find us on:
Never leave the user on
the product when lying on the
edge of the bed.
Never leave the product
on the oor.
Make sure that all relevant brakes
are activated before transferring
the user.
CE-certication:
This product is CE-approved and
follows the harmonized standards.
This means that the products are
in compliance with the essential
health and safety directives.
The product(-s) comply with the
standards in the Medical Device
Regulation (EU) 2017/745 – class 1.
master care A/S, Soenlystvej 3, DK 8340 Malling, Denmark
Tel. [phone], E-mail: [e-mail]
master-care.dk
