model no. 058-8691-0
OPERATING
MANUAL
IMPORTANT:
For your own safety, read and follow all of the Safety Guidelines
and Operating Instructions before operating this nailer. Keep this
manual for future reference.
AIR-POWERED BRAD NAILER

3
TABLE OF CONTENTS
4
5
9
10
13
14
19
20
22
23
24
TABLE OF CONTENTS
TECHNICAL SPECIFICATIONS
SAFETY GUIDELINES
KEY PARTS DIAGRAM
TECHNICAL INFORMATION
TYPES OF NAILS
OPERATING INSTRUCTIONS
MAINTENANCE
TROUBLESHOOTING
EXPLODED VIEW
PARTS LIST
WARRANTY

54
SAFETY GUIDELINES TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
These precautions are intended for the personal safety of the user and others working with the
user. Please take time to read and understand them.
Make sure you read and understand this manual before using this tool. Make sure other users
read and understand this manual before they use the tool.
SAFETY GUIDELINES
PERSONAL SAFETY
Potential hazard that will result in serious
injury or death.
Potential hazard that could result in
serious injury or death.
Potential hazard that may result in
injury or damage to equipment.
Note: The word “Note” is used to inform the readers of something
they need to know about the tool.
WARNING!
CAUTION!
DANGER!
This manual contains information that relates to PROTECTING PERSONAL SAFETY and
PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual carefully and
understand it thoroughly before using the product. The symbols listed below are used to
indicate this information.
100 Nails
18–gauge brad nails (5/8–2")
70–110 PSI (4.8 - 7.5 bar)
120 PSI (8.3 bar)
0.03 CF/cycle @ 90 PSI
1/4" (6.4 mm) – 18 NPT
3 lb 6 oz (1.55 kg)
CAPACITY (QTY.)
NAIL SIZE
OPERATION PRESSURE
MAXIMUM PRESSURE
AIR CONSUMPTION
AIR INLET
WEIGHT
CF : Cubic Feet (the volumetric flow rate of air corrected to standardized conditions of
temperature and pressure).
NPT: National Pipe Thread.
model no. 058-8691-0 | contact us 1-800-689-9928

76
Do not use oxygen or any other combustible or bottled
gas to power air-powered tools. Failure to observe this
warning can cause explosion and serious personal
injury or death. Use only compressed air to power
air-powered tools. Use a minimum of 25' (7.6 m) of
hose to connect the tool to only compressor. Failure to
comply will result in serious injury or death.
Risk of inhalation: Never directly inhale the air produced by the
compressor.
Risk of electric shock: Do not expose a compressor to rain.
Store it indoors. Disconnect the compressor from the power
source before servicing. The compressor must be grounded.
Do not use grounding adaptors.
Keep children away from the work area. Do not allow children to handle
power tools.
Do not use this tool in the presence of flammable liquids or gases. Sparks
that are created during use may ignite gases.
Do not point the tool towards yourself or other people, even when the tool
has stopped. Keep hands, feet, and all other parts of the body clear from
work area.
Do not attempt to clear nailer jams while the air hose is connected.
Do not keep the trigger or the safety stand pressed while loading nails.
Unintentional firing of a nail could cause serious personal injury or death.
Do not disconnect or reconnect the air hose with the trigger pressed. The
Air-powered Brad Nailer may fire when it is reconnected to the air supply.
Risk of personal injury: Do not direct compressed air from the air hose
towards the user or other people or animal.
Risk of burns: The pump and the manifold generate high temperatures. In
order to avoid burns or other injuries, do not touch the pump, the manifold,
or the transfer tube while the compressor is running. Allow the parts to cool
down before handling or servicing. Keep children and pets away from the
compressor at all times.
Risk of bursting: Do not adjust the pressure switch or safety valve for any
reason. They have been preset at the factory for this compressor’s maximum
pressure. Tampering with the pressure switch or the safety valve may cause
personal injury or property damage.
Risk of bursting: Make sure the regulator is adjusted
so that the compressor outlet pressure is set lower
than the maximum operating pressure of the tool.
Before starting the compressor, pull the ring on the
safety valve to make sure the valve moves freely.
Drain water from the tank after each use. Do not weld
nor repair the tank. Relieve all pressure in the hose
before removing or attaching accessories.
Do not allow inexperienced or untrained individuals to operate an Air-
powered Brad Nailer or any other air-powered tool.
Keep hands and other parts of the body away from the firing head
during use. Keep hands, feet, and all other parts of the body at least
8" (20 cm) away from the firing head. Nails or objects in the
workpiece can cause serious injury if they are deflected by the
workpiece or if they are driven away from the point of entry.
Do not overload the tool. Allow the tool to operate at its optimum
speed for maximum efficiency.
Locate the compressor in a well-ventilated area for cooling, at a
minimum of 12" (30 cm) away from the nearest wall.
Protect the air hose and the power cord from damage and puncture.
Inspect them for weak or worn spots before every usage, and replace
them if necessary.
Always wear eye and hearing protection when using the air
compressor. Failure to do so may result in hearing loss.
Do not carry the compressor while it is running.
Do not operate the compressor if it is not in a stable position.
Do not operate the compressor on a rooftop or in an elevated position
that could allow the unit to fall or be tipped over.
Always replace a damaged gauge before operating the unit again.
SAFETY GUIDELINES
WARNING!
DANGER!
SAFETY GUIDELINES SAFETY GUIDELINES
model no. 058-8691-0 | contact us 1-800-689-9928
Potential hazard that will result in serious injury or death.

98
CAUTION!
Potential hazard that may result in injury or damage to
equipment.
Disconnect the tool from the air supply and turn off the
compressor before performing any maintenance,
loading or changing nails, when the tool is not in use,
when it is being handed to another person, and when it
is left unattended. Failure to comply may result in injury
or damage to equipment.
Use safety goggles and ear protection:
Wear safety glasses with side shields when operating
the tool and verify that others in the work area are also
wearing safety glasses. Safety glasses must conform to
American National Standards Institute (ANSI Z87.1)
requirements and must provide protection from flying
particles from the front and the sides.
Air-powered tools are loud and the sound can cause
hearing damage. Always wear ear protection to help
prevent hearing damage and loss. Failure to comply may
result in injury.
Note: Recycle unwanted materials rather than disposing of them as waste. Sort
the tools, hoses, and packaging in specific categories and take them to the local
recycling centre or dispose of them in an environmentally safe way.
SAFETY GUIDELINES KEY PARTS DIAGRAM
3
4
3
2
1
6
5
3
7
3
8
Air inlet plug
Magazine latch
Magazine
Safety tip
1
2
3
4
5
6
7
8
Quick release handle
Depth adjustment dial
Trigger
Air deflector
model no. 058-8691-0 | contact us 1-800-689-9928

1110
Compatible compressors
Air system
General use
GUIDELINES FOR PROPER USE AND OPERATION
Potential hazard that could result in serious injury or death.
Be sure to use a proper air compressor with Mastercraft®air-powered tools. The
compressor should be able to supply a minimal air delivery of 2.0 CFM@ 90 PSI to ensure
the compressor can run continuously with the Mastercraft®Air-powered Pin Nailer.
Air Compressor
Size and Power
Wood Density Nail Size Compressor Air Pressure
0.6g/cm3
0.6g/cm3
Quick connector
Quick coupler
Air hose
Lubricator
Regulator (0 to 8.5 bar)
Filter
Cut-off valve
Air compressor
Always use clean, dry, regulated, compressed air at 4.8 to 7.5 bar (70 to 110 PSI).
Do not exceed the maximum or minimum pressures. Operating the tool at the wrong
pressure (too low or too high) will cause excessive noise or rapid wear.
WARNING!
Keep hands and other parts of the body away from the tool’s discharge
and working areas when connecting the air supply. Failure to comply
could lead to serious injury or death.
Heavy-duty and
continuous use
Medium-duty and
intermittent use
Light-duty and
intermittent use
Light-duty and
intermittent use
Light-duty and
intermittent use
Light-duty and
intermittent use
Medium-duty and
intermittent use
Medium-duty and
intermittent use
Medium-duty and
intermittent use
15+ Gallons
8–11 Gallons
2–6 Gallons
1/3–1 1/3 HP 1 1/2–2 HP 2+HP
TECHNICAL INFORMATION TECHNICAL INFORMATION
90 PSI (6.3 bar)
100 PSI (7 bar)
70 PSI (4.8 bar)
90 PSI (6.3 bar)
Mastercraft® Air-powered Brad Nailer
<1 1/4”(32 mm) brad nails
<1 1/4”(32 mm) brad nails
<1 1/4”(32 mm) brad nails
<1 1/4”(32 mm) brad nails
model no. 058-8691-0 | contact us 1-800-689-9928
This Mastercraft®Air-powered Brad Nailer includes a die cast aluminum body that is strong and
lightweight, and a comfort grip rubber handle for improved control and comfort, even during
extended use. The tool has a magazine that accepts 18-gauge and 5/8 - 2" (15 to 50 mm) long
brad nails, without adjustment. A hardened one-piece drive blade is provided for professional
application, and an adjusting wheel for controlling the depth of the nails. A touch-strike security
system is included for ensuring safety of the operator. The tool features a 360º air deflector that
is adjustable in any direction, and a quick-release handle for clearing jams. The Air-powered
Brad Nailer is best suited for installing door and window trim, decorative trim, cabinet work,
finish paneling, framing, scribe molding, upholstery, beading, chair rail, flooring works, etc.

1312
ACCEPTABLE NAILS
NAIL TYPE ICON
WARNING!
WARNING!
It is recommended that a filter-regulator-lubricator be used and be located as close to the tool
as possible.
If a filter-regulator-lubricator is not installed, place up to 6 drops of compressor oil into the air
inlet plug before each use.
If a filter-regulator-lubricator is installed, keep the air filter clean. A dirty filter will reduce the
air pressure to the tool, which will cause a reduction in power, efficiency, and general
performance.
For optimal performance, install a quick connector to the tool and a quick coupler on the
hose, if applicable.
Verify that all of the connections in the air supply system are sealed in order to prevent air
leakage.
Read this Instruction Manual carefully before using the Air-powered Pin Nailer.
• Read and follow all the safety instructions at the beginning of this manual. Inspect the
Air-powered Pin Nailer prior to each use in order to:
– ensure that the proper power source is being used.
– verify that the tool is in proper working order.
•
•
•
•
•
Potential hazard that could result in serious injury or death.
• Do not use the tool if it is not in proper working order.
• Do not use oxygen or any other combustible or bottled gas to
power this tool.
• Do not use this tool in the presence of any flammable liquids or
gases.
• Keep hands and other parts of the body away from the firing
head during use.
• Do not point the tool towards the operator or other people.
• Do not attempt to clear a jammed nail when the air hose is
connected.
• Do not drive a nail on top of an existing nail. Failure to comply
could lead to serious injury or loss of life.
Note: Icons are colour coded. Please refer to the actual tool for the
specific colour.
Potential hazard that could result in serious injury or death.
• The use of any other types of nails will cause the nailer to
jam and could lead to serious injury or death.
OPERATING INSTRUCTIONS TYPES OF NAILS
2”
5/8”
Length: 5/8 - 2" (15 to 50 mm)
These Icons are used to select the proper nails for this specific nailer.
model no. 058-8691-0 | contact us 1-800-689-9928

1514
Potential hazard that will result in serious injury or death.
DANGER!
fig. A
Loading nails
1. Disconnect the tool (1) from the air
supply (2) (Fig. A).
fig. B
fig. C
fig. D
5.
Disconnect the tool from the compressed air source before
loading nails.
Do not point the tool towards the operator or other people while
changing nails.
Do not hold the tool with the trigger pressed while changing
nails. Failure to comply will lead to serious injury or death.
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
2
1
1
2
Hold the Air-powered Brad Nailer firmly
with one hand, and use the other hand
to press the latch (1) on the magazine
(2) and slide it back (fig B).
1
2
1
fig. E
1
Insert a strip of nails (1) into the
magazine. After ensuring that the points
of the nails are facing down, close the
magazine. The tool is now ready for use
(fig C).
Plug in compressor, turn it on, set the
pressure regulator to 90 PSI, attach one
end of the air hose to the compressor
and the other end of the air hose (1) to
the tool (2). Use plumber’s tape to
prevent air leaks (fig D).
Test the driving depth of the tool against
a sample piece of wood by pressing the
trigger (1) before working on the
workpiece. If the nails are being driven
too deep or not deep enough, adjust the
regulator in the air supply in order to
provide more or less air pressure, as
required (fig E).
model no. 058-8691-0 | contact us 1-800-689-9928

1716
WARNING!
Potential hazard that will result in serious injury or death .
Potential hazard that may result in moderate injury or
damage to equipment.
Fasteners depth adjustment fig. F
The safety tip must be in contact with the workpiece before
activating the tool.
Do not operate the tool if the nails are not loaded, as doing so
may damage the tool.
Do not fire nails into the air, as doing so may cause injury to
the operators or others, apart from damaging the tool.
Load the correct type of nails only. Failure to comply could lead
to serious injury or loss of life.
When operating any air-powered tool below freezing temperature:
CAUTION!
Operate the tool with utmost care when connected with the
air compressor. Failure to comply may result in moderate
injury or damage to equipment.
Cold weather operation
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
• Verify that the compressor tanks have been properly drained prior to use.
• Keep the tool as warm as possible using any safe, convenient method.
• Place up to 6 drops of pneumatic tool oil into the tool’s air inlet.
• Maintain the operating level of the air pressure as recommended (see section “Technical
specification”).
• Load the nails into the magazine (if required).
• Actuate the tool 5 to 6 times into a scrap wooden piece in order to lubricate the O-rings.
• Adjust the pressure up to the operating level (do not exceed 120 PSI) and use the tool normally.
• Relubricate the tool, as described in the maintenance section.
• Drain the compressor tanks at least once per day.
fig. G fig. H
The Mastercraft® Air-powered Brad Nailer
has a depth adjustment dial below the trigger
to adjust the firing depth of the fasteners.
Note: Refer to the graphic imprinted below
the trigger and adjust the firing depth
accordingly (fig F).
DECREASING FASTENER DEPTH INCREASING FASTENER DEPTH
Turn the depth adjustment dial
counterclockwise (with the discharge area of
the tool facing away from the operator) (fig G).
Turn the depth adjustment dial clockwise (with
the discharge area of the tool facing away from
the operator) (fig H).
model no. 058-8691-0 | contact us 1-800-689-9928

1918
Note: If the nails continue to jam, call 1-800-689-9928.
Note: When temperatures are below freezing, keep the tools warm
using any safe, convenient method.
WARNING!
DANGER!
Potential hazard that will result in serious injury or death .
Potential hazard that will result in serious injury or death .
Clearing a jammed nail
Disconnect the tool from the air supply line before clearing a
jammed nail. Failure to comply could cause them to be fired
out of the tool causing serious injury.
Do not point the tool towards the operator or other people.
Serious personal injury could result if these instructions are
not followed.
Disconnect the tool from the air supply line.
Remove the non-jammed nails that are stored in the tool’s magazine.
Operate the magazine latch and slide the pusher back to open the magazine for checking the
jammed nails.
Use pliers or any appropriate tool to remove the jammed nails.
Close the magazine cover and slide the pusher to its original position.
Reload the nails into the tool magazine.
Reconnect the air supply line to the tool’s air inlet.
Test fire 3 to 5 nails into a piece of scrap wood in order to ensure a proper operation.
To clear a jammed nail
None X
X X
X
See below X
MAINTENANCE
REQUIRED
TOOLS OR
MATERIALS
REQUIRED
DESCRIPTION Each Use or
every 2 Hrs
MAXIMUM SERVICE INTERVAL
Monthly As
Needed
General inspection-
free movement
In-depth inspection
Replace worn or
broken parts
Lubrication
Trigger, spring,
safety mechanism
Worn or broken
parts
Pneumatic tool
oil
Maintenance
Lubrication: If the Air-powered Pin Nailer and the
compressor are not equipped with an in-line
lubrication system, place up to 6 drops of
pneumatic tool oil into the air inlet before each
work day or after every 2 hours of continuous use,
depending on the characteristics of the workpiece
and type of nails used.
Air-operated tools must be inspected periodically and worn or broken parts must be
replaced in order to keep tools operating safely and efficiently.
Inspect and replace worn or damaged O-rings, seals, etc. Tighten all screws and caps
frequently in order to help prevent personal injury.
Inspect the trigger, spring, and safety mechanism for free movement on a regular basis in
order to ensure that the safety system is fully functional. Verify that no parts are lose or
missing and no parts are sticking or jammed.
Keep the magazine and the safety tip of the tool clean and free of any dirt or abrasive
particles.
Disconnect the tool from the air compressor before
performing maintenance/service, adjusting, clearing jams,
reloading, and when it is not in use.
Repairs must be performed by a qualified service technician
only. Failure to comply will lead to serious injury or death.
OPERATING INSTRUCTIONS MAINTENANCE
model no. 058-8691-0 | contact us 1-800-689-9928

21
20
Note: For further repair information, please call 1-800-689-9928.
DANGER!
Potential hazard that will result in serious injury or death .
The following chart lists common issues and solutions. Please read it carefully and
follow all instructions carefully.
Air leakage at the
top of the tool or in
the trigger area.
The tool does not
operate properly - it
does not drive the
nails or operates
sluggishly.
The tool skips nails.
The tool jams.
Air leakage between
the bottom and the
cylinder cap.
Air leakage near the
bottom of the tool.
O-rings in the trigger valve are
damaged.
The trigger valve heads are
damaged.
Trigger valve stem, seal, or
O-rings are damaged.
The screws are loose.
The O-rings or the bumper are
worn or damaged.
The screws are loose.
The O-rings or the seals are worn
or damaged.
1.
2.
3.
1.
2.
3.
4.
1.
2.
3.
1.
2.
Tighten the screws.
Inspect and replace the O-rings or the seals.
1.
2.
Tighten the screws.
Inspect and replace the O-rings or the
bumper.
1.
2.
1.
2.
Inspect and replace the O-ring.
Inspect and replace trigger valve heads.
Inspect and replace the trigger valve stem,
seal, or O-ring.
Disconnect the tool from the air supply before making any adjustments.
If any of the following symptoms appear while the tool is in use,
turn it off and disconnect it from the air supply immediately.
Failure to comply will lead to serious injury or death.
Repairs must be performed by a qualified service technician
only.
PROBLEM POSSIBLE CAUSES SOLUTIONS
PROBLEM POSSIBLE CAUSES SOLUTIONS
The nails are being
driven too deep.
The bumper is worn.
The air pressure is too high.
The depth adjustment knob is not
adjusted properly.
1.
2.
3.
1.
2.
3.
Replace the bumper.
Adjust the air pressure.
Adjust the depth setting by turning the depth
adjustment knob counterclockwise (see
section “Adjusting nail depth” for more
detailed instructions).
The air supply is inadequate.
Lubrication is inadequate.
The O-rings or seals are worn or
damaged.
The exhaust deflector in the
cylinder head is blocked.
1.
2.
3.
4.
5.
1.
2.
3.
4.
1.
2.
3.
4.
The bumper is worn or the spring
is damaged.
There is dirt in the front plate.
Nails cannot move freely in the
magazine due to dirt or wear.
The O-ring on the piston is worn
or dry or lubrication is insufficient.
The cylinder cover seal Is leaking.
Improper nails are used, or nails are
damaged.
The driver guide is damaged or worn.
The magazine screw is loose.
There is dirt in magazine.
1.
2.
3.
4.
Verify that the air supply is adequate.
Pour up to 6 drops of oil into the air inlet.
Inspect and replace O-rings or seals.
Replace the damaged internal parts.
1.
2.
3.
4.
5.
Replace the bumper or spring.
Clean the drive channel on the front plate.
Clean the magazine.
Replace the O-ring.
Replace the sealing washer.
Use proper nails.
(see section “Clearing a jammed nail.”)
Inspect and replace the driver.
Tighten the magazine.
Open and clean the magazine.
TROUBLESHOOTING TROUBLESHOOTING
model no. 058-8691-0 | contact us 1-800-689-9928

2322
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
EXPLODED VIEW＆PARTS LIST
PARTS LIST
2
15 22
25
27
28
29
30
32
33
35
34
36
26
24
23
16
17
18
19
12
20
21
12
4
5
6
6
8
9
10
11
12
13
14
1
82
81
80
78
79
74 73 69
70
68
55 72 66
77
76
67
65
64
63
62
61
60
59
5856
52
51
53 57
71
54
50
48
47
31
49
746
45
44
43
42
41
37
38
39
40
24 75
16 23 42
43
44
45
46
51
52
53
54
47
49
50
17 24
25
18
19
20
21
22
8
9
12
13
6
26
27
28
29
30
31
32
33
34
35
36
37
39
40
55
38
48
60 61
62
63
67
71 72 73
70 74
75
76
77
80
81
82
83
84 77
85
86 94
78
79
2
15 22
25
27
28
29
30
32
33
35
34
36
26
24
23
16
17
18
19
12
20
21
12
4
5
6
6
8
9
10
11
12
13
14
1
82
81
80
78
79
74 73 69
70
68
55 72 66
77
76
67
65
64
63
62
61
60
59
5856
52
51
53 57
71
54
50
48
47
31
49
746
45
44
43
42
41
37
38
39
40
24 75
Ball Dw=2.5
Compressed Spring A
Bolt
Compressed Spring
Air deflector
Bolt M5 x 20
Spring Washer 5
Cylinder Cover
Sealing Washer
O-ring 17 x 2.65
3
1
1
1
1
4
6
1
1
1
Compressed Spring
O-ring 33.6 x 2
Switch Valve
Washer
O-ring 24.2 x 3.1
Main Piston
Sealing washer
Collar
Cylinder
Bumper
1
4
1
1
1
1
1
1
1
1
Sealing Washer
Gun Body
Guide Stand
Pin 3 x 26
Washer II
Compressed Spring
Pusher Pipe
Adjustable Stand
Norm Pin 1.5 x 8
Compressed spring B
Adjustable Nut
Snap retainer 2
Adj. stem
Safety Stand
Guide Sleeve
Bolt M3 x 8
O-ring 7 x 1.5
Trigger Valve Guide
Screw Spring
O-ring 1.9 x 1.1
Switch Lever
O-ring 11.2 x 1.6
Trigger Valve Seat
O-ring 11.7 x 2.4
Compressed Spring
Fixed Driver Guide Cover
Bolt M5 x 25
Pin Sleeve
Pin
Bolt M4 x 16
Quick Release Handle
1
1
1
3
1
1
1
1
2
2
1
1
1
1
1
1
2
1
1
2
1
1
1
1
1
1
2
1
1
2
1
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
Movable Driver Guide Cover
O-RING 1.9 x 1.2
Pin
Driver Guide
Safety Nozzle
Inlay Slice
Movable Magazine
Bolt M4 x 12
Pusher A
Pusher Pipe
Compressed Spring
Bolt M4 x 10
Position Seat
Torsion spring
Pin 3 x 18
Fixed Lever
Fixed Lever Jacket
Bolt M4 x 8
Fixed Seat
Bolt M4 x 6
Fixed Magazine
Pin 3 x 17.5
Safety Spacer
Trigger II
Nut M4
Bolt M4 x 14
Rubber Handle Case
O-ring 36.3 x 3.55
End Cap
Air Inlet Plug
Air Inlet Plug Cap
1
1
1
1
1
1
1
2
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
model no. 058-8691-0 | contact us 1-800-689-9928

2524
3-Year Limited Warranty
This product is guaranteed for a period of 3 years from the date of original retail purchase
against defects in workmanship and materials, except for the following component:
Component A: Accessories, which are guaranteed for a period of 1-year from the date of
original retail purchase against defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if returned to us
with proof of purchase within the stated warranty period and if covered under this
warranty, will be repaired or replaced (with the same model, or one of equal value or
specification), at our option. We will bear the cost of any repair or replacement and any
costs of labor relating thereto.
These warranties are subject to the following conditions and limitations:
A bill of sale verifying the purchase and purchase date must be provided.
This warranty will not apply to any product or part thereof which is worn or broken or
which has become inoperative due to abuse, misuse, accidental damage, neglect, or lack
of proper installation, operation, or maintenance (as outlined in the applicable instruction
manual or operating instructions), or which is being used for industrial, professional,
commercial, or rental purposes.
This warranty will not apply to normal wear and tear or to expendable parts or accessories
that may be supplied with the product which are expected to become inoperative or
unusable after a reasonable period of use.
This warranty will not apply to routine maintenance and consumable items such as, but
not limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids,
tune-ups, or adjustments.
This warranty will not apply where damage is caused by repairs made or attempted by
others (i.e., persons not authorized by the manufacturer).
This warranty will not apply to any product that was sold to the original purchaser as a
reconditioned or refurbished product (unless otherwise specified in writing).
a)
b)
c)
d)
e)
f)
This warranty will not apply to any product or part thereof if any part from
another manufacturer is installed therein or any repairs or alterations have
been made or attempted by unauthorized persons.
This warranty will not apply to normal deterioration of the exterior finish, such
as, but not imited to, scratches, dents, paint chips, or to any corrosion or
discoloring by heat, or abrasives and chemical cleaners.
This warranty will not apply to component parts sold by and identified as the
product of another company, which shall be covered under the product
manufacturer’s warranty, if any.
g)
h)
i)
This warranty applies only to the original purchaser and may not be
transferred. Neither the retailer nor the manufacturer shall be liable for any
other expense, loss or damage, including, without limitation, any indirect,
incidental, consequential, or exemplary damages arising in connection with
the sale, use, or inability to use this product.
This warranty gives you specific legal rights, and you may have other rights,
which may vary from province to province. The provisions contained in this
warranty are not intended to limit, modify, take away from, disclaim, or
exclude any statutory warranties set forth in any applicable provincial or
federal legislation.
Additional limitations
Notice to consumer
Made in China
Imported by Mastercraft Canada Toronto, Canada M4S 2B8
WARRANTY WARRANTY
model no. 058-8691-0 | contact us 1-800-689-9928
