Mastervolt MasterView Read Out User manual

USER’S MANUAL
MasterView
Read Out
Charger Remote Panel for the MasterBus network
MASTERVOLT
Snijdersbergweg 93,
1105 AN Amsterdam
The Netherlands
Tel.: [phone]
Fax.: [phone]
www.Mastervolt.com Copyright © 2011 Mastervolt, v 1.4 January 2011
ENGLISH: PAGE 1
NEDERLANDS: www.mastervolt.nl
DEUTSCH: www.mastervolt.de
FRANÇAIS: www.mastervolt.fr
CASTELLANO: www.mastervolt.es
ITALIANO: www.mastervolt.it

2January 2011 / MasterView Read Out / EN
1 GENERAL INFORMATION
1.1 Use of this manual
This manual serves as a guideline for the safe and
effective operation of the MasterView Read Out .
Keep this manual at a secure place!
1.2 Guarantee specifications
Mastervolt guarantees that this product was built
according to the legally applicable standards and
stipulations. If you fail to act in accordance with the
regulations, instructions and stipulations in this
user’s manual, damage can occur and/or the
product will not fulfil the specifications. This may
mean that the guarantee will become null and void.
IMPORTANT: Additional warranty agreements, like
“Mastervolt system warranty” may contain
restrictions which forbid resetting of historical data
The standard guarantee period is two years after
date of purchase.
1.3 Liability
Mastervolt does not accept liability for:
•consequential damage due to use of the
MasterView Read Out;
•possible errors in the manuals and the results
thereof;
•use that is inconsistent with the purpose of the
product.
CAUTION!
Never remove the identification label.
2 OPERATION
The MasterView Read Out operation is entirely MasterBus based. The table below shows the Read Out
MasterBus functions, accessible via the free downloadable MasterAdjust software.
For information about MasterAdjust, MasterBus and the MasterBus event structure, see www.mastervolt.com.
Monitoring Description Factory settings Range
Charger State Charger state can be On, Off or alarm.
On: on-bulk charge LED illuminating,
Alarm: red failure LED illuminating.
Off On/ Off/
Alarm*
Configuration
Mode Mode Dotted means the led at the actual
level illuminates, Bar means the LEDs from
the bottom up to the actual level illuminate.
Dotted Bar/ Dotted
Language Set the Read Out menu language. English See specifications
Device name Any name you wish with 12 characters max Read out 6 12 characters max
Set up The way to configure the charger for use with
the read out. Choose “manual” for custom
programming.
Automatic Automatic, Manual
* When the charger is in alarm, it sends out a signal to the read out.
3 EC DECLARATION OF CONFORMITY
This product is in conformity with the provision of the EC EMC directive 89/336/EEC
and amendments 92/31/EEC, 93/68/EEC, standards applied:
generic emission standard: EN 50081-1:1992,
generic Immunity standard: EN 50082-1:1997,
safety directive 2006/95/EC, with the following standard:
Low voltage standard: EN 60950: 2000.

EN / MasterView Read Out / January 2011 3
4 DISPLAY FUNCTIONS
5 INSTALLATION
What you need:
MasterView Read Out
MasterBus Terminator
 ChargeMaster with MasterBus connections
(not included)
 MasterBus connection cable (not included)
Installation:
Step 1. Disconnect the charger AC,
Step 2. Connect the Read Out panel to the
ChargeMaster, using (1) a MasterBus
cable and (2) two MasterBus Terminators,
Step 3. Reconnect the charger AC.
The charger will recognize the read out and be
configured automatically to use this panel (Set up
automatic, see chapter 2).
MasterBus connections of the MasterView Read Out , front and back side
State of charge: Float
State of charge: 60-80%
State of charge: Absorption
State of charge: 20-40%
Charger On,
State of charge: Bulk
Continuously red:
Charger in Failure,
Blinking red:
Charger in alarm
No LED illuminating: Charger Off
on
failure
float
bulk
absorption
Charger Control
Charger Control
on - bulk chargeon - bulk charge
failure
float
absorption
Charger ControlCharger Control
MasterBus connectors

6 SPECIFICATIONS
Model: MasterView Read Out (OEM)
Article number: 77010050 (OEM: 77010030)
Delivery also includes: MasterBus Terminator, English user’s manual (other languages: see front page)
Function of instrument: Charger Remote Panel for the MasterBus network
Compatible with: ChargeMaster 12/70-3, 12/100-3, 24/40-3, 24/60-3, 24/80-3 & 24/100-3
Languages available: English,Nederlands,Deutsch,Français,Castellano,Italiano,Norsk,Svenska,Suomi,Dansk
Power consumption: 144 mW
MasterBus Powering: No
MasterVision mounting: Yes (not the OEM device)
Protection degree: IP 21
Dimensions: See drawing below
Weight Approx. 70 gr [0.15 lb]
Dimensions in mm [inch]
Dimensions OEM device in mm [inch]
Snijdersbergweg 93, 1105 AN Amsterdam, The Netherlands
Tel : + 31-20-3422100
Fax : + 31-20-6971006
Email : [email protected]
