1) Important Safety Instructions
READ AND SAVE THESE INSTRUCTIONS
•This Cycle is intended to for commercial use
•To insure your safety and protect the equipment, read all instructions before operating the
MATRIX Cycle.
When using an electrical product, basic precautions should always be followed, including
the following:
DANGER To reduce the risk of electric shock:
•Always unplug this equipment from the electrical outlet immediately after using and
before cleaning.
Your MATRIX Cycle is self-generating (requiring no external power source) and must be ped-
aled to power up the console.
WARNING To reduce the risk of burns, fire, electrical shock or injury to persons that may be
associated with using this product:
•An appliance should never be left unattended when plugged in. Unplug from outlet when
not in use and before putting on or taking off parts.
•This product must be used for its intended purpose described in this Owner’s Guide. Do not
use other attachments that are not recommended by the manufacturer. Attachments may
cause injury.
•To prevent electrical shock, never drop or insert any object into any opening.
•Do not remove the side covers. Service should only be done by an authorized service technician.
•Never operate the Cycle with the air openings blocked, Keep the air openings clean, free of
lint, hair and the like.
•Never operate product if it has a damaged cord or plug, if it is not working properly, if it has
been damaged, or immersed in water. Return the appliance to a service center for examination
and repair.
•Do not carry this appliance by supply cord or use cord as handle.
•Keep any power cord away from heated surfaces.
•Keep hands and loose clothing away from moving parts.
•Close supervision is necessary when Cycle is used by or near children, invalids, or disabled persons.
•Do not use outdoors.
•Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
•To disconnect, turn all controls to the off position, then remove plug from outlet
•Connect this Cycle to a properly grounded outlet only.
CAUTION If you experience chest pain, nausea, dizziness or shortness of breath, STOP exercis-
ing immediately and consult a physician before continuing.
SETTING UP THE CYCLE
Assembly instructions have been provided with your Cycle. For your safety, please read and fol-
low each of the steps in the assembly guide. To obtain a copy of the assembly guide, please
contact MATRIX FITNESS SYSTEMS.
1.1 INSTALLATION REQUIREMENTS
Your MATRIX Cycle is designed to be self contained and does not require a power
supply to operate.
Fit ConnexionTM requires a 9 volt battery and a 110 volt power supply to operate the monitor.
Use only the power supply provided by the manufacturer, please contact MATRIX FITNESS for
a replacement.
CAUTION Use of the wrong power supply may cause damage to your Cycle and/or entertain-
ment device.
Locate a level stable surface to position Cycle. The Cycle has four leveling feet located under
the foot support. If your Cycle wobbles in the location where you intend to use it, loosen the
lock nut on the adjusting foot and adjust the feet until stable. Once level, lock the adjusting
feet by tightening the lock nut to the frame.
1.2 PREVENTATIVE MAINTENANCE AND CLEANING TIPS
Preventative maintenance and daily cleaning will prolong the life and look of your Matrix fit-
ness equipment.
Please read and follow these tips.
•Position the equipment away from direct sunlight. The intense UV light can cause discoloration
of plastics.
•Locate your equipment in an area with cool temperatures and low humidity.
•Clean with a soft 100% cotton cloth.
•Clean with non-ammonia based cleaners.
•Wipe seats, handles, heart rate grips, and handlebars clean after each use.
•Do not pour liquids directly onto your equipment. This can cause damage to the equipment
and in some cases electrocution.
•Check pedal safety straps weekly for wear.
•Adjust leveling feet when equipment wobbles or rocks.
•Maintain a clean area around equipment free from dust and dirt.
1

2) Using Manager Preference Mode
2.0 USING MANAGER PREFERENCE MODE
Your MATRIX Cycle is designed to allow you to customize settings for your preferences and
diagnostics. The Manager Preference Mode can only be accessed while the Cycle is powered
up. Follow the instructions to adjust the Cycle computer for your desired settings.
STEP 1 Power up the Cycle and Hold the UP and DOWN arrow keys for 3 seconds. The word
Manager will appear in the alphanumeric window and will enter into the Manager
Preference Setting automatically after 3 seconds. Continue to pedal until finished.
STEP 2 Select information you would like to view or change from the following list, by using
the UP or DOWN arrows. Press ENTER to select.
Manager preference mode will allow you to view and set the following.
DISPLAYCODE: INFORMATION USER DEFINABLE DEFAULT VALUE MIN. MAX.
Manager P0: Maximum program time Y 95 min 5 95
P1: Default time Y 20 min 5 95
P2: Default level Y L1 L1 L20
P3: Default weight Y150 lbs 80 lbs 400 lbs
P4: Speed Y Miles Miles KM
P5: Machine YBI BI RE, EL
P6: TV IR YOn On Off
P7: Cardio Entertainment Y On On Off
P8: Accumulated Distance
P9: Accumulated Time
P10: Software Version
STEP 3 Use UP or DOWN arrows to increase or decrease values.
STEP 4 Press START to save and enter selected values and exit to STEP 2.
STEP 5 Exit by pressing Start. Screen will reset to Start up.
2.1 USING CSAFE s
Matrix is the leader in entertainment availability. On the back of the console are three RJ45
receptacles. They are marked CSAFE IN, CSAFE OUT, and ENTERTAINMENT.
Use the CSAFE IN to plug in any CSAFE device using the RJ45 connector CSAFE OUT allows
CSAFE products to be daisy chained together from one unit to the next. The connection is as follows;
2.2 SETTING UP FIT CONNEXION™
Fit ConnexionTM
Your equipment is preset to offer you the maximum benefit of your desired entertainment offering.
Whether it is FIT CONNEXIONTM or other CSAFE entertainment packages, Matrix makes it easy
to connect. Look on the back of the console and locate the receptacle labeled ENTERTAINMENT.
This port is specific for audio and visual entertainment devices. CSAFE ready products can plug
in and utilize the volume, channel and headphone connector
When installing Fit Connection make sure you are using the power cord supplied with your
package. Other power cords could cause malfunctions with your product.
Assemble the Fit Connection bracket by following the instructions supplied in your package.
Make sure you feed the power cord and coaxial cable through the round hole at the top of the
bracket. Insert the monitor and fasten with the screw provided.
Connect the coaxial cable and the power cord to the monitor.
Take the Fit ConnexionTM audio cord and plug it into the audio out on the back side of the mon-
itor. The RJ45 needs to now be plugged into the Jack labeled Entertainment. This cord provides
the audio to your headphones.
At the front base of the unit you will see the Fit Connexion TM coaxial cable and power supply con-
nectors. Connect the coaxial cable and the power supply. Turn the monitor on and see if it has power.
Follow the instructions provided with your monitor to select language and input device options.3.0
2
CSAFE IN
CSAFE OUT CSAFE IN
CSAFE OUT CSAFE IN
CPU
UNIT 1
UNIT 2
UNIT 3

3) Adjusting the Seat Height
3.0 ADJUSTING THE SEAT HEIGHT
Your MATRIX Cycle is designed for ease of use. We have incorporated seat height adjustments
that are easily located and simple to adjust.
3.1 UPRIGHT SEAT HEIGHT
To adjust the seat height on the Upright Cycle, locate the red pull pin before you mount the
Cycle. To lower the seat down, pull the red knob while holding the seat with the other hand
and slide up or down accordingly. To adjust seat height up, simply raise the seat to desired
position. Our automatic seat lock will set. Make sure you are not seated when you pull the
knob or pull seat up.
3.2 RECUMBENT SEAT HEIGHT
To adjust you’re seat height on the Recumbent Cycle locate the red lever under the right side
of the seat before you mount the Cycle. Place your right hand on the red adjustment handle
under the right side of the seat. Place feet on the ground while seated and slide forward if
needed. Place feet on pedals, gently lift lever under the right side of the seat. Using legs slow-
ly push and slide the seat up or down to desired position. Release lever and allow to lock into
place.
3.3 RECUMBENT LUMBAR SUPPORT
The red knob on the side of the seat is for adjusting the lumbar support. To adjust, simply turn
the knob located on the back rest. Turn the knob forward to increase support and backward to
decrease support until desired comfort has been achieved.
3

4) Using the Cycle or Recumbent
4.1 CONSOLE DESCRIPTION
PROGRAMS Simple program view and selection buttons. Matrix Cycles feature seven programs.
START / QUICK START One touch Quick Start and Start any time during preference selection.
UP / DOWN Easy information and level selection.
ENTER / SELECT SCREEN / RESET This multi-function button enters information when setting up
programming options, toggles information displayed and if held down for 5 seconds resets
the Cycle to Start-up mode.
DISPLAY VIEW These three buttons allow the user to customize the way the unit’s lights are dis-
played.
ENTERTAINMENT Control the CHANNEL and VOLUME of your attached TV or entertainment
system. (Must have Fit ConnexionTM or entertainment source connected)
HEAD PHONE JACK Located at the base of the console, just plug in a headset and use the
ENTERTAINMENT buttons to adjust VOLUME. (Must have Fit ConnexionTM or entertainment
source connected)
4.2 MANUAL OPERATION
MATRIX design makes using the programs as easy as one touch of a button.
QUICK START Start pedaling and press QUICK START to begin workout.
MANUAL MODE allows you enter desired time, level, and weight.
STEP 1 Select Manual program button on left of panel.
Press Enter or wait 5 seconds.
NOTE Selecting START will start program.
STEP 2 Select Time by using the UP or DOWN arrow keys. When finished
Press Enter or wait 5 seconds.
NOTE Selecting START will start program.
STEP 3 Select Level by using UP or DOWN arrow keys. You can change the level at any time
during workout. When finished,
Press Enter or Wait 5 seconds.
NOTE Selecting START will start program.
STEP 4 Select Weight by using the UP or DOWN arrow keys.
Press START or ENTER to begin workout.
Display
TIME
Starting 3
Starting 2
Starting 1
4.3 OPERATING LEVEL BASED PROGRAMS
Your MATRIX Cycle offers versatile programs to keep the user motivated.
The following Instructions will guide you through simple steps to select INTERVALS, ROLLING,
FAT BURN, and RANDOM programs.
STEP 1 Select the program button on left of panel.
Press ENTER or wait 5 seconds.
NOTE Selecting START will begin program.
STEP 2 Select Time by using the UP or DOWN arrow keys. When finished
Press ENTER or wait 5 seconds.
NOTE Selecting START will begin workout.
STEP 3 Select Level by using UP or DOWN arrow keys. You can change the level at any time
during workout. When finished,
Press ENTER or Wait 5 seconds.
NOTE Selecting START will begin workout.
STEP 4 Select Weight by using the UP or DOWN arrow keys.
Press START or ENTER to begin workout.
Display
4

4) Using the Cycle or Recumbent
TIME
Starting 3
Starting 2
Starting 1
4.4 HEART RATE CONTROL
For your convenience, MATRIX FITNESS CYCLES come standard with digital contact heart rate
sensors and POLAR telemetry compatible.
Locate the metal sensors on the handrail of the Cycle. Notice there are two separate pieces of
metal on each grip. You must be making contact on both pieces of each grip to get an accu-
rate heart rate reading. You can grab these sensors in any program to view your current heart
rate located in the lower left hand window marked Heart Rate.
Heart Rate Program
Follow these easy Steps to enter into the Heart Rate Program.
STEP 1 Select TARGET HR program button on left of panel.
Press Enter or wait 5 seconds.
NOTE Selecting START will start program.
STEP 2 Select Time by using the UP or DOWN arrow keys. When finished
Press Enter or wait 5 seconds.
NOTE Selecting START will start program.
STEP 3 Using the following chart, select Target Heart Rate by using UP or DOWN arrow keys.
You can change the Target Heart Rate at any time during workout. When finished,
Press Enter or Wait 5 seconds.
NOTE Selecting START will start program.
STEP 4 Select Weight by using the UP or DOWN arrow keys.
Press START or ENTER to begin workout.
Display
TIME
Starting 3
Starting 2
Starting 1
4.5 CONSTANT WATTS
Constant Watts program is a unique program that allows you to vary your cadence or RPM and
the Cycles resistance will adjust accordingly to your selected goal. The quicker you pedal the
less resistance for the goal selected.
Follow these easy Steps to enter into the Constant Watts Program.
STEP 1 Select CONSTANT WATTS program button on left of panel.
Press Enter or wait 5 seconds.
NOTE Selecting START will start program.
STEP 2 Select Time by using the UP or DOWN arrow keys. When finished
Press Enter or wait 5 seconds.
NOTE Selecting START will start program.
STEP 3 Select Constant Watts goal by using UP or DOWN arrow keys. You can change the
watts target at any time during workout. When finished,
Press Enter or Wait 5 seconds.
NOTE Selecting START will start program.
STEP 4 Select Weight by using the UP or DOWN arrow keys.
Press START or ENTER to begin workout.
Display
TIME
Starting 3
Starting 2
Starting 1
5
POLAR TARGET HEART RATE ZONE
HEAVY MODERATE LIGHT
220
20
AGE
HR BEATS
PER MINUTE
25 30 35 40 45 50 55 60 65
200
180
160
140
120
100
80

SPECIFICATIONS
Product Name R5
Foot Print 49"H x 62"L x 25"W
Weight 132 lbs
Max User Weight 400 lbs = 181 kg
Frame Construction Aluminum/Steel
Self Contained Yes
Resistance Type Generator
Resistance Levels 20
PROGRAMS
One Button Quick Start Yes
Random (20 profiles) Yes
Target Heart Rate Yes
Interval Yes
Constant Watts Yes
Rolling Yes
Fat Burn Yes
HEART RATE
Polar Telemetry Yes
Contact Heart Rate Yes
ENTERTAINMENT READY
Volume Control Yes
Channel Control Yes
Display View Control 3 Views
Coaxial Cable Connection Yes
Acc TV Power Connection Yes
Monitor Mount Yes
IR Port Yes
Head Phone Jack yes
5) Equipment Specifications
>recumbent cycle
MX-R5
MACHINE WEIGHT SIZE
132 lbs inches = 49” x 62” x 25”
60 kg cm = 128.5 x 157.5 x 63.5
6

5) Equipment Specifications
> upright cycle
MX-U5
MACHINE WEIGHT SIZE
106 lbs inches = 57” x 44” x 63.5”
48 kg cm = 144.8 x 111.8 x 25
7
SPECIFICATIONS
Product Name U5
Foot Print 57"H x 44"L x 25"W
Weight 106 lbs
Max User Weight 400 lbs = 181 kg
Frame Construction Aluminum/Steel
Self Contained Yes
Resistance Type Generator
Resistance Levels 20
PROGRAMS
One Button Quick Start Yes
Random (20 profiles) Yes
Target Heart Rate Yes
Interval Yes
Constant Watts Yes
Rolling Yes
Fat Burn Yes
HEART RATE
Polar Telemetry Yes
Contact Heart Rate Yes
ENTERTAINMENT READY
Volume Control Yes
Channel Control Yes
Display View Control 3 Views
Coaxial Cable Connection Yes
Acc TV Power Connection Yes
Monitor Mount Yes
IR Port Yes
Head Phone Jack Yes

THIS PAGE INTENTIONALLY BLANK

>cycles
MX-R5 and MX-U5
6) Parts & Assembly

THIS PAGE INTENTIONALLY BLANK

6.1) MX-R5 Exploded View
AN1
WATER BOTTLE
N10
TV
TV RACK
C27
AC4
C20 C12
D11 AC2
T08
T09
D43
D55 C24
A02
P22
A01
AB1
C31
D13
P07
D46
D55
D44
D56 AD5
F01
F06
AC3
C17
C26
C17
C23
C11
AC1
Q03
C24 C30
F02
T08
T09
F05
D04
D37
C28
P03
P04
P23
N25
P01
FASTENERS AND ASSEMBLY TOOLS
C17 6BUTTON HEAD BOLT (M8 x 15L)
C20 3BUTTON HEAD BOLT (M4 x 10L)
C24 2WASHER (8.2x18.0x1.4t(BED)
C30 2BUTTON HEAD BOLT (M8 x 50L)
D37 2BUTTON HEAD BOLT (M8 x 25L)
D39 2WASHER (SW5 5.1x9.3x1.3t)
D43 4BUTTON HEAD BOLT (M8 x 15L)
D56 3BUTTON HEAD BOLT (M8 x 15L)
D44 4BUTTON HEAD BOLT (M8 x 50L)
WASHER (8.2x18.0x1.5t)D46 4
BUTTON HEAD BOLT (M5 x 12L)
N25 4
C26 BUTTON HEAD BOLT (M4 x 38L) 1
C27 WASHER 1
C28 1SCREW (M4)
C31 2SCREW (M8)
1PHILLIPS DRIVER (4.5 x 50mm)
1OPEN WRENCH (#13)
1OPEN WRENCH (#17)
14mm ALLEN WRENCH
15mm ALLEN WRENCH
16mm ALLEN WRENCH
REFERENCE SKETCH DESCRIPTION QUANTITY
F06 5BUTTON HEAD BOLT (M10 x 20L)
BUTTON HEAD BOLT (M8 x 20L)
F05 6
15mm ALLEN WRENCH
>recumbent cycle
MX-R5
11

12
6.2) Parts List
>recumbent cycle
MX-R5
NO. DESCRIPTION SPECIFICATION
AG1 Hand Pulse Grip Set RB50 (w/HP) w/Texture
AN1 Console Set RB50 (English-Metric)
AN2 Hand Pulse Grip Set CB32 (w/Texture)
AN2 Hand Pulse Grip Set CB32 (w/o Texture)
AU1 Tension Wheel Set RB50
D13 Back Pad Set RB50
D23 Seat Roller Set RB50
D25 Adjustable Roller Set RB50
Q01 Right Side Cover Set RB50
Q02 Left Side Cover Set RB50
R01 Drive Axle Set RB50
R04 Slide Bearing Housing Set CB32
R05 Fixing Bearing Housing Set CB32
T01 Pedal Axle Set CB32
AB1 Frame Set RB50 (Metal Color)
AC1 Console Mast Set RB50 (Metal Color)
AC2 Front Handlebar Set PVC
AC3 TV Bracket (with Cables) MATRIX R5(RB50)
AC4 Console Fixed Plate
AD1 Slide Seat Set RB50 (Metal Color)
AD2 Back Pad Mast Set RB50 (Metal Color)
AD6 Back Pad with Lumbar Set
AZ1 Hardware Kit Include Hand Tools (Purple Round Sticker)
C01 Console Mast
C10 Front Handlebar Axle SS41
C11 Console Lower Cover-RH ABS (Knurled on Surface)
C12 Console Lower Cover-LH ABS
C13 Spacer 20x26x15L
C14 Console Mast Sleeve Nylon
C17 Screw, Inner Hex Socket M8x1.25Px15L
C18 Rivet (Brass Inserts Nut) ALS7-8125-3.8 (0.5-3.8)
C19 Screw, Oval Hex Socket M8x1.25Px20L
C20 Screw, Round Tapping 4x10L
C21 Fixed Nut AN04 (M20x1.0Px6t) (Bed)
C22 Front Handlebar Cover PVC
C23 Console Cover Nylon
C24 Flat Washer 8.2x_18x1.4t (Bed)
C25 Screw, Oval Hex Socket M8x1.25Px15L
C30 Screw, Round Hex Socket M8x1.25Px50L (30L)
C31 Nylon Nut M8x1.25P (Bed)
C32 2-E.ND Round Key 6x6x16L
D04 Adjust Lever SS41
D11 Seat Pad
NO. DESCRIPTION SPECIFICATION
D12 Seat Pad Fixed Plate SPC (Zinc Plating)
D18 U Sleeve
D21 Knob Nylon + Fiber (Red #1797)
D23 Roller POM
D24 Roller Axle SS41
D25 Adjustable Roller POM
D26 Adjustable Roller Axle SS41
D29 Adjustable Positioning Board SPC
D30 Located Block S45C
D31 Adjustable Spring
D32 Handlebar Long Pearl #4 (Red)
D33 Nylon Nut M6x1.0P (Bed)
D34 Nylon Nut M8x1.25P (Bed)
D35 C Clip-External S-10
D36 Settle Bolt M12x1.75Px12.0L
D37 Screw, Round Hex Socket M5x0.8Px25L
D38 Screw, Round Hex Socket M6x1.0Px30L(15L)
D39 Screw, Plain Head M5x0.8Px10L
D40 Screw, Round Tapping M5x0.8Px12L
D41 Spiral Shells Axle Cover ABS
D43 Screw, Inner Hex Socket M8x1.25Px15L (Bed)
D44 Screw, Oval Hex Socket M8x1.25Px50L
D46 Arc Washer 8.2x18x.15t
D48 Screw, Round Tapping 3x12L
D51 Front Fixed Board for Cable SPC
D52 Steel Cable Fixed Bracket SPC
D53 Foam Grip 25.0x31.0x240L
D54 Foam Grip PVC Sleeve (Red #1797)
D55 Spring Washer SW8 8.0x17.0x1.5t
D56 Screw, Shallow Hex Socket M8x1.25Px15L (Bed)
D57 End Cap PVC Black
F01 Rear Stabilizer Set CB32
F02 Front Stabilizer-RH Set CB32
F03 Front Stabilizer-LH Set CB32
F04 Adjustable Foot Pad No Turn
F05 Screw, Oval Hex Socket M8x1.25Px20L (Bed)
F06 Screw, Oval Hex Socket M10x1.5Px20L
H01 Slide Rail AL
H02 Rail Fixed Plate SPC
H03 Screw, Round Tapping 3x10L
H04 Rail End Cap ABS
H05 Stop Wheel Shaft SS41(Zinc Plating)
H06 Seat Pad Stopper Roller PU

6.2 Parts List
13
>recumbent cycle
MX-R5
NO. DESCRIPTION SPECIFICATION
H07 Flat Washer _5x_16x1.0t
H08 Screw, Oval Head M4x0.7Px10L
H09 Screw, Oval Hex Socket M8x1.25Px50L(18L)
H11 Bolt M5x0.8Px10L
H12 Flat Washer _6.5x_13x1.5t
H13 Hexagon Socket Headless Set Screws M5x0.8Px15L
L01 Mobile Wheel NYLON+30%FIBER
L02 Screw, Oval Hex Socket M8x1.25Px70L(12L)
L03 Flat Washer 8.2X16x1.0t
L04 Nylon Nut M8x1.25P
N10 Water Bottle Holder ABS
N15 Overlay MX U5/R5/E5 (Holland)
N15 Overlay MX U5/R5/E5 (Germany)
N15 Overlay MX U5/R5/E5 (Italy)
N15 Overlay MX U5/R5/E5 (U.S.A.)
N20 2-in-1 Polar Receiver POLAR 39021539.00 (RB59-P12A)
N21 Sensor Grip CB32-N21F
N22 Heartbeat Sensor Plate 101.5x32 (SUS304) (w/ Texture)
N22 Heartbeat Sensor Plate 101.5x32 (SUS304) (w/o Texture)
N23 End Cap, Hand Pulse Grip Nylon
N26 Screw, Round Tapping M3x0.5Px35L
N27 Hex Nut M3x0.5P
P01 Console Cable 1300(XAP-07V-1+H6657P-2+SMR-08V-B)
P05 Connecting Cable of Controller 750(3.96-5P VH WHITE+HL20P-03)
P06 Power Resistance 400W10_-200(3.96-4P WHITE VH)
P07 Hand Pulse Cable 700 (H6657R1-2+110* F END*2)
P10 CONSOLE MAST CABLE 800(SMP-08V-BC+H6657P1-8)
P12 TV Power Cable 1250 (XAP-02V-1+SMR-02V-B)
P13 TV Power Cable 1250 (RG-6)X2
P18 Ferrite Cord FH0900B-2
P19 Power Transferred Cable 1000 (XAP-02V-1+H6657R1-2)
P20 E-Port Control Board w/PCB Board-DC Bracket & Adapter
P22 Heartbeat Sensor Rail Connecting Cable 1360 (H6657P-2)X4
P23 Connecting Cable for Console Heart Rate 800 (H6657R1-2)X4
P26 Earphone Extended Cable 185 (3.5 3-D Earphones+
Microphone F*Base 3P)
Q03 Console Mast Cover PVC
Q05 Crank Cover PVC (Anthracite)
Q06 Screw, Oval Tapping _4x12L
Q07 C-Clip WUSN-5030
R15 Screw, Round Hex Socket M5x0.8Px10L (Bed)
R16 Flat Washer _5.2x_13x1.5t
R17 Screw, Oval Hex Socket M6x1.0Px12L
NO. DESCRIPTION SPECIFICATION
R18 Flat Washer _6.2x_20x2.0t (HRC47-52)
R19 Ploy V Belt 500-J6 (Carlisle)
R20 Ploy V Belt 440-J8 (Carlisle)
S01 Generator (CB32-KT/RB50-KT)TW Line _190 CE CB/RB MX/600 Series
S01 Generator (JM07-AM1A)USA Line _190 NO CE MX/600 Series (JM07-AMIA)
S02 Eye Hook Screw 1/4”-20UNCx70L Eye Hole 10
S03 Flat Washer _10.2x_15x1.5t
S04 Nut, Hex Head 3/8”-26UNF
S05 Hook Cover for Eye Bolt 1.6t SPC (Bed)(CB32-S05D)
S06 Nylon Nut 1/4"-20UNC (Bed)
S07 Flat Washer _1/4”x_15x1t
S08 Control Board (JE07002) U5-R5-E5-H002 (JE07002)
S09 Hex Nut 3/8”-26UNCx4H
S11 Flat Washer _5.3x_10x1.0t
S12 Screw, Round Hex Socket M5x0.8Px12L
S14 Screw, Round Tapping M5x0.8Px8L
T07 Ball Bearing 6205ZZ (BR6205ZZ)
T08 Pedal & Pedal Strap EX-13 1/2 BR-”MATRIX” logo
T09 Pedal Strap PU (CB32-T09B)
T13 Right Crank Nut SS41 (Zinc Plating)
T15 Front Spacer Powder Metallurgy (CB32-T15I)
T17 Flat Washer _32x_25.3x1.0t
T18 Spacer Tight Nut SS41(ZINC PLATING)
T19 Large Screw, Oval Head M4x0.7Px8L
U04 Pulling Adjustable Plate 2t SPC
U05 Ball Bearing 6206ZZ
U06 C Clip Internal R-62
U07 Ball Bearing 6204ZZ
U08 C Clip-External S-30
U09 C Clip-External S-20
U11 Tension Wheel Spring Zinc Plating SWPB
U12 Screw, Round Hex Socket M5x0.8Px10L (Bed)
V01 Rail Decal
V02 Decal Matrix (Except Italy) (CB32-V04B)
X01 Carton(1) Set
Z02 L-Key Hex Wrench 4MM
Z03 L-Key Hex Wrench 5MM
Z04 Open End Wrench #13
Z05 Screw Driver, Cross Type 4.5*50
Z06 Open End Wrench #15#17x325L
Z07 T Type Wrench 5mm

6.3) Assembly Step 1
STEP 1
AD1
F03
F05 (Green)
F02
>recumbent cycle
MX-R5
14

6.3) Assembly Step 2
F01
AD1
FD6
STEP 2
>recumbent cycle
MX-R5
15

6.3) Assembly Step 3
STEP 3
T08
T09
>recumbent cycle
MX-R5
16

6.3) Assembly Step 4
STEP 4
AC1
C24
C31
Q03
C24 C30
>recumbent cycle
MX-R5
17
