Matrix R5x-04 User manual

R5X-04 BIKE
SERVICE MANUAL

CHAPTER 1: SERIAL NUMBER LOCATION ................................................................... 1
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
2.1 Read and Save These Instructions ........................................................................... 3
2.2 Electrical Requirements ............................................................................................ 4
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 Recommended Cleaning Tips ................................................................................... 5
3.2 Check for Damaged Parts ......................................................................................... 5
3.3 Care and Maintenance Instructions .......................................................................... 6
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.1 Console Description .................................................................................................. 7
4.2 Workout Setup Steps - Manual.................................................................................. 8
4.3 Workout Setup Steps - Fat Burn................................................................................ 8
4.4 Workout Setup Steps - Level Based.......................................................................... 8
4.5 Workout Setup Steps - Fitness Test........................................................................... 9
4.6 Workout Setup Steps - Target Heart Rate ................................................................. 10
4.7 Workout Setup Steps - Constant Watts ..................................................................... 10
CHAPTER 5: MANAGER MODE
5.1 Using Manager Mode ................................................................................................ 11
5.2 Manager Mode Overview........................................................................................... 11
CHAPTER 6: ENGINEERING MODE
6.1 Using Engineering Mode............................................................................................ 12
CHAPTER 7: SERVICE MODE
7.1 Using Service Mode................................................................................................... 13
CHAPTER 8: TROUBLESHOOTING
8.1 Electrical Diagram ..................................................................................................... 14
8.2 Error Codes on the Console ...................................................................................... 18
8.3 LCB LED Indicators.................................................................................................... 19
8.4 LCB Wiring Connections ............................................................................................ 20
8.5 Troubleshooting - Error 04A0..................................................................................... 21
8.6 Troubleshooting - Error 04B0..................................................................................... 22
8.7 Troubleshooting - Error 0248 ..................................................................................... 23
8.8 Troubleshooting - Error 02B4..................................................................................... 24
8.9 Troubleshooting - Error 02AB .................................................................................... 25
8.10 Troubleshooting - Error 01AC .................................................................................... 26
8.11 Troubleshooting – No Resistance .............................................................................. 27
8.12 Troubleshooting - Heart Rate Issues ......................................................................... 28
8.13 Troubleshooting - Seat Issues ................................................................................... 29
8.14 Troubleshooting - No Power to the Console.............................................................. 30
8.15 Troubleshooting - Keypad Issues............................................................................... 31
CHAPTER 9: PART REPLACEMENT GUIDE
9.1 Console Replacement................................................................................................ 32
9.2 Handlebar Replacement ........................................................................................... 33
9.3 Cup Holder Replacement .......................................................................................... 34
9.4 Console Keypad / Overlay Replacement................................................................... 35
TABLE OF CONTENTS

III
9.5 Console Mast Replacement............................................................................................ 37
9.6 Seat Pad Replacement ................................................................................................... 38
9.7 Back Pad Replacement .................................................................................................. 39
9.8 HR Handlebar Replacement........................................................................................... 40
9.9 HR Grips Replacement ................................................................................................... 41
9.10 Upper Seat Frame Replacement ................................................................................... 42
9.11 Lower Seat Frame Replacement.................................................................................... 43
9.12 Seat Adjustment Handle Replacement........................................................................... 45
9.13 Rear Shrouds Replacement ........................................................................................... 46
9.14 Pedal Replacement ........................................................................................................ 47
9.15 Front Shroud Replacement............................................................................................. 48
9.16 Lower Control Board Replacement ................................................................................ 49
9.17 Battery Replacement ...................................................................................................... 50
9.18 Drive Belt Replacement .................................................................................................. 51
9.19 Generator Belt Replacement .......................................................................................... 52
9.20 Generator Replacement.................................................................................................. 53
9.21 Pulley Axle Set Replacement.......................................................................................... 54
9.22 Crank Axle Set Replacement.......................................................................................... 56
9.23 Testing the Bike............................................................................................................... 57
CHAPTER 10: BIKE SPECIFICATIONS AND ASSEMBLY GUIDE
10.1 R5x-04 Bike Specifications ........................................................................................ 58
10.2 Fasteners and Assembly Tools .................................................................................. 59
10.3 Assembly Instructions ............................................................................................... 60
10.4 Adjusting the Pedal Straps and Seat ......................................................................... 64
10.5 Leveling the Bike........................................................................................................ 65
10.6 TV Bracket Installation Instructions............................................................................ 66
CHAPTER 11: SOFTWARE UPGRADE GUIDE
11.1 Software Upgrade Procedure..................................................................................... 71
TABLE OF CONTENTS

1
1.1 SERIAL NUMBER LOCATION
A serial number plate is located below the bottom of the console mast beneath a rubber boot. There is also a serial number tag on the middle
of the main frame pointed towards the floor.
CHAPTER 1: SERIAL NUMBER LOCATION

2
CONSOLE SERIAL NUMBER LOCATION
1.1 SERIAL NUMBER LOCATION
CHAPTER 1: SERIAL NUMBER LOCATION
SN # PLACEMENT

3
CAUTION! If you experience chest pains, nausea, dizziness,
or shortness of breath, stop exercising immediately and con-
sult your physician before continuing.
CAUTION! Any changes or modifications to this equipment
could void the product warranty.
2.1 READ AND SAVE THESE INSTRUCTIONS
To ensure your safety and protect the equipment, read all
instructions before operating the MATRIX R5x-04 Bike.
To ensure proper use of the Matrix R5x-04 Bike, make sure that all
users read this manual. Remind the users that before undertaking
any fitness program, they should obtain complete physical
examinations from their physicians. If, at any time while exercising,
the user experiences dizziness, pain, or shortness of breath,
nausea or feels faint, he or she must stop immediately.
* This bike is only to be used for its intended purpose described
in this manual. Do not use attachments that have not been recom-
mended by Matrix.
* Never drop or insert objects into any opening. Keep hands away
from moving parts. If the item cannot be reached, contact a Matrix
authorized dealer for assistance.
* Never operate the unit if it is damaged, not working properly, when
it has been dropped, or has been dropped in water.
* Keep hands and feet clear at all times from moving parts to avoid
injury.
* Do not use this product outdoors, near swimming pools or in areas
of high humidity.
* Do not operate where aerosol (spray) products are being used or
when oxygen is being administered.
* Do not use this product in bare feet. Do not wear shoes with heels,
leather soles, cleats, or spikes while exercising.
* Do not remove the side covers. Service should only be done by an
authorized service technician.
* Close supervision is necessary when used near children, invalids,
or disabled people.
* When the bike is in use, young children and pets should be kept at
least 3 meters / 10 feet away.
* Assemble and operate the bike on a solid, level surface.
* Never face backward while using the Matrix R5x-04 Bike.
* Use the stationary handlebars when mounting or dismounting the
bike.
* Do not wear clothing that might catch on any moving parts of this
bike.
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS

4
2.2 ELECTRICAL REQUIREMENTS
GROUNDING INSTRUCTIONS:
The Matrix R5x-04 Recumbent Bike must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. The Bike is equipped with a cord having an equipment grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances. If the user does not follow these grounding instructions, the user could void the Matrix limited warranty.
DANGER: Improper connection of the equipment grounding conductor can result in the risk of electric shock. Check with a qualified electrician
if the user is in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product if it will not fit the outlet,
have a proper outlet installed by an electrician.
The Matrix 5x Series Recumbent Bike is designed to be self powered. NOTE: If an add on TV (using a bracket) is added to the unit, it must be
plugged in, or the TV will not operate correctly. If the Bike will be plugged in, follow the requirements below.
MATRIX DEDICATED CIRCUIT/ELECTRICAL REQUIREMENT INFO
All Matrix Bikes require the use of a 15 amp or 20 amp “dedicated circuit,” with a non-looped (isolated) neutral/ground, for the power requirement.
Quite simply this means that each outlet you plug Bikes into should not have anything else running on that same circuit besides other Bikes (up to
3 per 15 amp circuit and 4 per 20 amp circuit). The easiest way to verify this is to locate the main circuit breaker box, and turn off the breaker(s)
one at a time. Once a breaker has been turned off, the only thing that should not have power to it are the Bikes in question. No lamps, vending
machines, fans, sound systems, or any other item should lose power when you perform this test.
Non-looped (isolated) neutral/grounding means that each circuit must have an individual neutral/ground connection coming from it, and terminating
at an approved earth ground. You cannot “jumper” a single neutral/ground from one circuit to the next.
In addition to the dedicated circuit requirement, the proper gauge wire must be used from the circuit breaker box, to each outlet that will have the
maximum number of units running off of it. If the distance from the circuit breaker box, to each outlet, is 100 ft or less, then 12 gauge wire may be
used. For any distance greater than 100 ft from the circuit breaker box to the outlet, 10 gauge wire must be used.
For your safety and Bike performance, the ground on this circuit must be non-looped. Please refer to NEC article 210-21 and 210-23. Your Bike is
provided with a power cord with a plug listed below and requires the listed outlet. Any alterations of this power cord could void all warranties for
this product. Multiple Bikes can be powered on one dedicated circuit. (3 units per 15 Amp and 4 units per 20 Amp dedicated circuit.)
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS

5
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 RECOMMENDED CLEANING TIPS
In order to maximize life span, and minimize down time, all Matrix Fitness Equipment requires regularly
scheduled cleaning.
YOU WILL NEED:
- Mild dish soap and water mixture in a spray bottle (10:1 water to soap ratio).
- Lint free 100% cotton cleaning cloths or Microfiber cleaning cloths.
- Vacuum / Shop Vac with extendable hose and soft brush attachment.
- Corrosion Block (available from Matrix - part # ZMS4001374).
DAILY:
1. Wipe down the unit after each use with a mild dish soap and water mixture. NOTE: Spray the soap / water mixture onto the cloth.
NEVER spray directly onto the equipment. We recommend that you do NOT allow customers to use spray bottles to clean the equipment. If
the cleaner is sprayed directly on the equipment or over spray is present, it may cause your equipment to rust and / or cause damage to con-
sole overlays.
2. With a clean dry 100% lint free cloth and water / soap mixture, wipe any dust or dirt from the out of the seat wheel track (Figure A).
WEEKLY:
1. With a clean dry 100% lint free cloth and water / soap mixture, wipe down the entire frame so it is free of dust, dirt, and sweat.
2. With a clean dry 100% lint free cloth and water / soap mixture, wipe down the entire console area including the hand grips and hand rails.
MONTHLY:
1. Vacuum under and around the Bike. If you need to move it, unplug the unit first.
2. Remove the shrouds and use a vacuum to remove any dust or dirt built up under the covers. NOTE: Be careful not to damage or unplug
any of the wiring.
3. Apply Corrosion Block to the metal part of the iPod cable.
DO NOT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems.
MAINTAIN LABELS AND NAMEPLATES. Do not remove labels for any reason. They contain important information. If unreadable or missing,
contact Matrix Fitness Systems for a replacement. 1-866-693-4863, www.matrixfitness.com
MAINTAIN ALL EQUIPMENT Preventative maintenance is the key to smooth operating equipment. Equipment needs to be inspected at regular
intervals. Defective components must be replaced immediately. Improperly working equipment must be kept out of use until it is repaired.
Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so. Matrix Fitness Systems will
provide service and maintenance training at our corporate facility upon request or in the field if proper arrangements are made.
3.2 CHECK FOR DAMAGED PARTS
FIGURE A

6
3.3 CARE AND MAINTENANCE INSTRUCTIONS
CHAPTER 3: PREVENTATIVE MAINTENANCE
In order to maximize life span, and minimize down time, all MATRIX equipment requires regular cleaning, and maintenance items performed on
a scheduled basis. This section contains detailed instructions on how to perform these items and the frequency of which they should be done.
Some basic tools and supplies will be necessary to perform these tasks which include (but may not be limited to):
* Metric Allen wrenches
* #2 Phillips head screwdriver
* Adjustable wrench
* Commercial Pedal wrench (available from Matrix - part # ZMS4001254)
You may periodically see addendums to this document, as the Matrix Technical Support Team identifies items that require specific attention, the
latest version will always be available on the Matrix web site at www.matrixfitness.com.
DAILY MAINTENANCE ITEMS
1) Look and listen for loose fasteners, unusual noises, and any other indications that the equipment may be in need of service.
2) Attempt to wobble the unit from side to side and front to back. Level if needed (see Section 10.5).
WEEKLY MAINTENANCE ITEMS
1) Check the pedal straps for damage.
2) Clean the grooves on the foot pedals.
MONTHLY MAINTENANCE ITEMS
1) Frequently vacuum the floor beneath the unit to prevent the accumulation of dust and dirt which can affect the smooth operation of the unit.
2) Check that the pedal and crank assembly are tight with no free play or wobble in them. Make sure to use a commercial grade pedal wrench to
get the pedals as tight as possible.
3) Check the condition of the seat upholstery. Make sure that the seat adjustment mechanism is operating correctly.
4) Check the seat for looseness. Tighten the seat rollers if needed (see Section 8.13).
YEARLY MAINTENANCE ITEMS
1) Remove the front shrouds and check the belt for damage, alignment, and proper tension.

7
4.1 CONSOLE DESCRIPTION
WORKOUT KEYS: Simple program view and selection buttons.
GO: One touch Start.
UP / DOWN LEVEL: Easy information and level selection.
UP / DOWN TIME: Easy information and time adjustment.
STOP: Ends workout and shows workout summary data.
NUMBER KEYPAD: Workout data input for workout setup. Level adjustment during workout.
COOL DOWN: Puts bike into Cool Down mode.
FAN: Allows for fan speed selection (fan has 3 operating speeds).
TOGGLE DISPLAY: Allows user to select what information is displayed on the console.
LANGUAGE: Select Language.
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION

8
4.2 WORKOUT SETUP STEPS - MANUAL 4.4 WORKOUT SETUP STEPS - LEVEL BASED
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
GO - Press to immediately begin a workout. Workout, resistance
level, and time will automatically go to default settings. Pressing
GO will not prompt user for age, weight, or level settings.
1) Start pedaling and press the GO key to begin your workout. 2)
The display will read 3, 2, 1, Begin and then the program will start.
MANUAL - Manual allows the user to input more information
while defining their own workout. Calorie expenditure will be more
accurate when inputting information in Manual than by pressing GO.
1) Start pedaling, press the MANUAL key. Then press ENTER.
2) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
3) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
5) Press GO, and then the display will read 3, 2, 1, Begin and then
the program will start.
FAT BURN - Fat burn is a level based program that is designed
to help users burn fat through various resistance level changes.
1) Start pedaling and press the FAT BURN key. Then press
ENTER.
2) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
3) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
5) Press GO, then the display will read 3, 2, 1, Begin and then the
program will start.
4.3 WORKOUT SETUP STEPS - FAT BURN
ROLLING HILLS - The Rolling Hills program is a level based
program that automatically adjusts the resistance level to simulate
real terrain.
1) Start pedaling and press the ROLLING HILLS key. Then press
ENTER.
2) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
3) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
5) Press Go, then the display will read 3, 2, 1, Begin and then the
program will start.
INTERVAL TRAINING - The Interval Training program is a
level based program that automatically adjusts the resistance of the
machine from low to high intensity settings at regular intervals.
1) Start pedaling and press the INTERVAL TRAINING key. Then
press ENTER.
2) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
3) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
5) Press GO then the display will read 3, 2, 1, Begin and then the
program will start.
RANDOM - Random is a level based workout that randomly
adjusts the resistance of the machine.
1) Start pedaling and press the key next to RANDOM key. Then
press ENTER.
2) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
3) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
5) Press GO, then the display will read 3, 2, 1, Begin and then the
program will start.

9
4.5 WORKOUT SETUP STEPS - FITNESS TEST
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
FITNESS TEST -The Cooper Fitness Test measures cardiovascular fitness and proves an estimated sub-maximal VO2 result. It is based
on power output according to ACSM standards and was developed by the Cooper Institute© (www.cooperinstitute.org). User RPMs must
remain between 60-80 RPM during the test. The test will end when the user can no longer maintain this speed. Use of a heart rate strap is
optional but provides more data.
The test starts at a low intensity level and gradually increases in intensity (difficulty) every 2 minutes. As it increases, the user must maintain
60-80 RPM to advance to the next level. The test could take upwards of 30+ minutes for very fit individuals. Once the test ends a recovery
period (cool down) will begin and the user's results are calculated and displayed. Results are based on the number of stages completed.
Incline will not be adjustable during the test.
1) Start pedaling and press the FITNESS TEST key. Then press ENTER.
2) Select Age by using the UP or DOWN LEVEL keys and press ENTER.
3) Select Gender by using the UP or DOWN LEVEL keys and press ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press ENTER.
5) Press GO, then the display will read 3, 2, 1, Begin and then the program will start.
6) Once the workout is complete, the display will read the results of the Fitness Test.
STAGES COMPLETED:
1 Well Below Average
2 Well Below Average
3 Below Average
4 Below Average
5 Average
6 Average
7 Above Average
8 Above Average
9+ Well Above Average

10
4.6 WORKOUT SETUP STEPS - TARGET HEART RATE 4.7 WORKOUT SETUP STEPS - CONSTANT WATTS
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
TARGET HEART RATE - The Matrix R5x-04 Bike comes with
standard digital contact heart rate sensors and are POLAR telemetry
compatible. The heart rate control workout mode allows the user to
program their desired heart rate zone, and the bike will automatically
adjust the level based upon the user's heart rate. The heart rate
zone is calculated using the following equation: (220-Age)8%=target
heart rate zone. The user must wear a POLAR telemetric strap or
continually hold onto the contact heart rate grips for this workout.
Locate the metal sensors on the handlebars of the bike. Notice
that there are two separate pieces of metal on each grip. You must
be making contact with both pieces of each grip to get an accurate
heart rate reading. You can grab these sensors in any program to
view your current heart rate.
1) Start pedaling and press the HEART RATE key. Then press
ENTER.
2) Select Age by using the UP or DOWN LEVEL keys and press
SELECT.
3) Select Target HR Percentage by using the UP or DOWN LEVEL
keys and press SELECT.
4) Select Time by using the UP or DOWN LEVEL keys and press
SELECT.
5) Select Weight by using the UP or DOWN LEVEL keys and press
SELECT.
6) Press GO, then the display will read 3, 2, 1, Begin and the
program will start.
CONSTANT WATTS - Constant Watts is a unique program
that allows you to vary your cadence or RPM and the bike's
resistance level will adjust accordingly to your selected goal. The
quicker you pedal, the less resistance for the goal selected.
1) Start pedaling and press the CONSTANT WATTS key. Then
press ENTER.
2) Select Watts by using the UP or DOWN LEVEL keys and press
SELECT.
3) Select Time by using the UP or DOWN LEVEL keys and press
SELECT.
4) Select Weight by using the UP or DOWN LEVEL keys and
press SELECT.
5) Press GO, then the display will read 3, 2, 1, Begin and the
program will start.

11
5.1 USING MANAGER MODE
The Manager's Custom Mode allows the club owner to customize the bike for the club.
1) To enter Manager Mode, press and hold down the UP and DOWN LEVEL keys. Continue to hold down these two keys until the display
reads Manager Mode and hit ENTER (Figure A).
2) To scroll through the list of options in Manager Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the
display.
3) To select a custom setting, press the ENTER key when the desired setting is shown.
4) To change the value of the setting, use the UP and DOWN LEVEL keys.
5) To confirm and save the value of the setting, press the ENTER key.
6) To exit the setting without saving, press the BACK key.
7) Press and hold the STOP key for 3-5 seconds to return to normal operation.
5.2 MANAGER MODE OVERVIEW
CUSTOM SETTING DEFAULT MINIMUM MAXIMUM DESCRIPTION
Maximum Time 60 min 5 min 95 min Sets the total run time of any program.
Default Time 30 min 5 min Maximum
Time
Setting
Workout time when GO is pressed or when no time is selected
during program set up.
Default Level 1 1 30 Starting resistance when GO is pressed or when no resistance is
selected during program set up.
Default Age 30 10 100 Starting age when GO is pressed or when no age is selected during
program set up.
Default User Weight 150 lbs /
75 kg
80 lbs / 36
kg
400 lbs /
181 kg
Weight used for program calorie expenditure calculations.
Accumulated Distance N/A 0 99,999
Miles
Total distance for all programs.
Accumulated Time N/A 0 999,999
hours
Total time for all programs displayed in hours.
Software Version N/A N/A N/A Current version of console software.
Timer Mode Up Up Down Determines whether the timer counts up or down.
Speed / Distance Mode Mile Mile Kilometer Displays distance in miles or kilometers.
Out of Order Off On Off Locks the machine when out of order.
Gender Male Male Female Determines the gender of the user when not selected during program
set up.
Language English English English Sets the language for the console. Select between English, Spanish,
German, French, Italian, and Dutch.
Sound Mode On On Off Turns the chime on / off when a button is pressed.
CHAPTER 5: MANAGER MODE

12
6.1 USING ENGINEERING MODE
CHAPTER 6: ENGINEERING MODE
To enter Engineering Mode, hold the LEVEL UP and DOWN keys for 3-5 seconds until Manager Mode appears on the middle LED display.
Press the LEVEL UP or DOWN key to scroll to Engineering Mode. Press ENTER to go into Engineering Mode.
CODE DEFAULT OPTIONS DESCRIPTION
Disable Errors No Yes or No No - Shows A-C class error codes. Yes - Shows only C class error codes.
Speed Units Mile Mile or Kilometer Set for Mile or Kilometer.
Machine Type R5x H5x, R5x, U5x,
E5x-02 or E5x-03
The Recumbent bike should be set for R5x.
Power Save Time 30 Seconds 30-60 Seconds Power saving time for the self powered frame.
Pause Time 30 Seconds 15 - 120 Seconds For non self powered frames only. Not used on this model.
Serial Number N/A N/A Serial Number input is available for both the Console and Frame. Use the number
keys and UP / DOWN LEVEL keys to enter Engineering Mode. Due to the limited
LED characters, 2 layers are used to enter the serial number. First Layer:
- PPPPP V
- PPPPP is the product name.
- V is the version. If the version is A, just leave this blank.
Second Layer
- YY MM nnnnn.
- YY is the year (11, 12).
- MM is the month (e.g. 08, 09, 10).
- nnnnn is the actual serial number.
Use the UP / DOWN LEVEL keys to navigate the layers and the number keys to
input the serial number. The product name is dependent on the Machine Type
setting.
For example, the console is EP612 with ver. A with ver. A and the manufactured
date is 2011.08 with 98765. The frame is RB91 with ver. B and the manufactured
date is 2011.06 with 12345. Their serial numbers are:
Console SN: EP612 1st layer, 110898765 2nd layer.
Frame SN: RB91 1st layer, 110612345 2nd layer.
Club ID N/A N/A This sets the club ID for clubs using Asset Management.
ErP Mode (Sleep
Time)
Off Off or On (1-30
Minutes)
If there is no use of the machine over a period of time, the console LEDs will turn
off (go into ErP mode).
Audio Source Off Off / TV / PC TV /
Remote TV
Manual setting that sets which outside TV will have audio through the console
audio ports.
Volume Control TV/ PCTV:
Output:13
1~ 32 Controls the default TV volume for entertainment wired through the C-Safe port.
a. Input Default (DF : 15 / Range : 1 ~ 15)
b. Max Default (DF : 32 / Range : 1 ~ 32)
c. Output Default (DF : 13 / Range : 1 ~ Max)
Remote TV support a / b / c item. TV and PCTV only support c item.
REMOTE TV
Output:13
1~ 32
REMOTE TV
Input:15
1~ 15
AM System RF Radio WIFI/RF Radio To select AM output device by WIFI or RF Radio.

13
7.1 USING SERVICE MODE
To enter Service Mode, hold the LEVEL UP and DOWN keys for 3-5 seconds until Manager Mode appears on the middle LED display. Press
the LEVEL UP or DOWN key to scroll to Service Mode. Press ENTER to go into Service Mode.
CODE DEFAULT OPTIONS DESCRIPTION
Service 1 Display Test Press the ENTER key repeatedly
to check each set of LEDs on the
display sequentially.
Service 2 Keypad Test Press any key and the display
should show the corresponding
message.
Service 3 Distance / Time Distance:
Mile 0 - 99999
Kilometer 0 - 160898
Time:
0 - 999999
Manually sets the Accumulated
Distance and Time.
Service 4 CSafe / RF Test Press the ENTER key to test
CSAFE. Press the ENTER key
again to test the RF.
Service 5 Error Log Shows the last 10 errors. Press
and LEVEL UP and DOWN for 3
seconds to clear the errors.
Service 6 Set Date / Time Press the LEVEL keys to move
cursor, the number keys to set
date / time, and the ENTER key
to save.
Service 7 Export and Import Parameter Export Parameter - Export all
parameters to a USB device.
Import Parameter 1 - Imports the
engineer parameters to a USB
device except serial number,
accumulated distance and time.
Import Parameter 2 - Imports the
engineer parameters to a USB
device.
Service 8 WiFi Function Automatically detects the
available IP address and displays
it.
CHAPTER 7: SERVICE MODE

14
8.1 ELECTRICAL DIAGRAMS
CHAPTER 8: TROUBLESHOOTING
HURES5X-C ELECTRICAL BLOCK DIAGRAM

15
8.1 ELECTRICAL DIAGRAM - CONTINUED
CHAPTER 8: TROUBLESHOOTING
R5X-F ELECTRICAL BLOCK DIAGRAM

16
8.1 ELECTRICAL DIAGRAMS - CONTINUED
PULSE SENSOR WIRE
CHAPTER 8: TROUBLESHOOTING
POWER RESISTANCE WIRE

17
DIGITAL COMMUNICATION WIRE
8.1 ELECTRICAL DIAGRAMS - CONTINUED
CHAPTER 8: TROUBLESHOOTING
8.1 ELECTRICAL DIAGRAMS - CONTINUED
ECB WIRE
CHAPTER 8: TROUBLESHOOTING
