Matrix U7X-01 User manual

U7X-01 BIKE
SERVICE MANUAL

CHAPTER 1: SERIAL NUMBER LOCATION ................................................................... 1
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
2.1 Read and Save These Instructions ........................................................................... 3
2.2 Electrical Requirements ............................................................................................ 4
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 Recommended Cleaning Tips ................................................................................... 5
3.2 Check for Damaged Parts ......................................................................................... 5
3.3 Care and Maintenance Instructions .......................................................................... 6
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.1 Console Description .................................................................................................. 7
4.2 Workout Setup Steps - Manual.................................................................................. 8
4.3 Workout Setup Steps - Fat Burn................................................................................ 8
4.4 Workout Setup Steps - Training Workouts................................................................. 8
4.5 Workout Setup Steps - Fitness Test........................................................................... 9
4.6 Workout Setup Steps - Target Heart Rate ................................................................. 10
4.7 Workout Setup Steps - Constant Watts ..................................................................... 10
CHAPTER 5: MANAGER MODE
5.1 Manager Mode Overview .......................................................................................... 11
5.2 Manager Mode - About Tab........................................................................................ 12
5.3 Manager Mode - Time Tab......................................................................................... 13
5.4 Manager Mode - Defaults Tab.................................................................................... 14
5.5 Manager Mode - Language Tab................................................................................. 15
5.6 Manager Mode - TV Tab ............................................................................................ 16
CHAPTER 6: ENGINEERING MODE
6.1 Engineering Mode Overview...................................................................................... 17
6.2 Engineering Mode - Errors Tab .................................................................................. 18
6.3 Engineering Mode - Statistics Tab ............................................................................. 19
6.4 Engineering Mode - Self Power Tab .......................................................................... 20
6.5 Engineering Mode - Clubs Tab................................................................................... 21
6.6 Engineering Mode - Club ID Tab................................................................................ 22
CHAPTER 7: SERVICE MODE
7.1 Service Mode Overview ............................................................................................. 23
7.2 Service Mode - Setup Tab.......................................................................................... 24
7.3 Service Mode - Test Tab ............................................................................................ 25
7.4 Service Mode - Date & Time Tab ............................................................................... 26
7.5 Service Mode - Log Tab ............................................................................................. 27
TABLE OF CONTENTS
i

iv
TABLE OF CONTENTS
CHAPTER 8: TROUBLESHOOTING
8.1 Electrical Diagram ...................................................................................................... 28
8.2 Error Codes on the Console ....................................................................................... 29
8.3 LCB LED Instructions.................................................................................................. 30
8.4 Troubleshooting - Display Issues................................................................................ 31
8.5 Troubleshooting - Error Ox04A0 ................................................................................. 32
8.6 Troubleshooting - Keypad Issues................................................................................ 33
8.7 Troubleshooting - Entertainment Keypad Issues ........................................................ 34
8.8 Troubleshooting - Resistance Issues.......................................................................... 35
8.9 Troubleshooting - Pedal Slipping ................................................................................ 36
8.10 Troubleshooting - Noise Issues................................................................................... 36
8.11 Troubleshooting - Heart Rate Issues .......................................................................... 37
8.12 Troubleshooting - TV Issues ....................................................................................... 38
CHAPTER 9: PART REPLACEMENT GUIDE
9.1 Console Replacement................................................................................................. 39
9.2 Heart Rate Handlebar Replacement .......................................................................... 40
9.3 Heart Rate Grip Replacement ................................................................................... 41
9.4 Cup Holder Replacement............................................................................................ 42
9.5 Console Keypad / Overlay Replacement.................................................................... 43
9.6 Console Mast Removal............................................................................................... 46
9.7 Seat Pad Replacement ............................................................................................... 47
9.8 Seat Post Replacement .............................................................................................. 48
9.9 Seat Post Insert Replacement ................................................................................... 49
9.10 Pedal Replacement..................................................................................................... 50
9.11 Shrouds Removal........................................................................................................ 51
9.12 Lower Control Board Replacement ............................................................................ 52
9.13 Drive Belt Replacement .............................................................................................. 53
9.14 ECB (Electronic Brake) Belt Replacement ................................................................. 54
9.15 ECB (Electronic Brake) Replacement......................................................................... 55
9.16 Pulley Axle Set Replacement ......................................................................................... 56
9.17 Crank Axle Set Replacement.......................................................................................... 58
9.18 Rear Stabilizer Replacement.......................................................................................... 59
9.19 Front Stabilizer Replacement ......................................................................................... 60
9.20 Testing the Bike............................................................................................................... 61
CHAPTER 10: BIKE SPECIFICATIONS AND ASSEMBLY GUIDE
10.1 U7x-01 Bike Specifications ......................................................................................... 62
10.2 Fasteners and Assembly Tools ................................................................................... 63
10.3 Assembly Instructions ................................................................................................ 64
10.4 Adjusting the Pedal Straps and Seat.......................................................................... 68
10.5 Leveling the Bike......................................................................................................... 69
10.6 TV Programming Instructions ..................................................................................... 70
CHAPTER 11: SOFTWARE UPGRADE GUIDE
11.1 Software Upgrade Instructions.................................................................................... 72
ii

1
1.1 SERIAL NUMBER LOCATION
CHAPTER 1: SERIAL NUMBER LOCATION
A serial number plate is located below the bottom of the console mast beneath a rubber boot. There is also a serial number tag on the middle
of the main frame pointed towards the floor.

2
CONSOLE SERIAL NUMBER LOCATION
1.1 SERIAL NUMBER LOCATION
CHAPTER 1: SERIAL NUMBER LOCATION

3
CAUTION! If you experience chest pains, nausea, dizziness,
or shortness of breath, stop exercising immediately and con-
sult your physician before continuing.
CAUTION! Any changes or modifications to this equipment
could void the product warranty.
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
2.1 READ AND SAVE THESE INSTRUCTIONS
To ensure your safety and protect the equipment, read all
instructions before operating the MATRIX U7x-01 Bike.
To ensure proper use of the Matrix U7x-01 Bike, make sure that all
users read this manual. Remind the users that before undertaking
any fitness program, they should obtain complete physical
examinations from their physicians. If, at any time while exercising,
the user experiences dizziness, pain, or shortness of breath,
nausea or feels faint, he or she must stop immediately.
* This bike is only to be used for its intended purpose described
in this manual. Do not use attachments that have not been recom-
mended by Matrix.
* Never drop or insert objects into any opening. Keep hands away
from moving parts. If the item cannot be reached, contact a Matrix
authorized dealer for assistance.
* Never operate the unit if it is damaged, not working properly, when
it has been dropped, or has been dropped in water.
* Keep hands and feet clear at all times from moving parts to avoid
injury.
* Do not use this product outdoors, near swimming pools or in areas
of high humidity.
* Do not operate where aerosol (spray) products are being used or
when oxygen is being administered.
* Do not use this product in bare feet. Do not wear shoes with heels,
leather soles, cleats, or spikes while exercising.
* Do not remove the side covers. Service should only be done by an
authorized service technician.
* Close supervision is necessary when used near children, invalids,
or disabled people.
* When the bike is in use, young children and pets should be kept at
least 3 meters / 10 feet away.
* Assemble and operate the bike on a solid, level surface.
* Never face backward while using the Matrix U7x-01 Bike.
* Use the stationary handlebars when mounting or dismounting the
bike.
* Do not wear clothing that might catch on any moving parts of this
bike.

4
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
2.2 ELECTRICAL REQUIREMENTS
The Matrix U7x-01 Bike can operate without power; however, the
machine must boot the software with each new user. This can mean
a delay of up to 35 seconds while the machine's operating system
prepares for a workout. It's similar to turning your cell phone on for
the first time of the day. These units can also be AC powered. This
will power the console at all times and requires no minimum RPM
for operation. A powered product lowers the starting resistance and
is easier to use for beginners. These units can be daisy chained
together, up to 4 units per dedicated 15 amp circuit, using a Matrix
daisy chain cord adapter (sold separately).
For your safety and for the performance of your Matrix bike, the
ground on your circuits must be non looped. Please refer to NEC
articles 210-21 and 210-23. Any alterations to the standard Matrix
power cords will void all warranties.
GROUNDING INSTRUCTIONS:
The Matrix U7x-01 Bike must be grounded. If it should malfunction
or break down, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. The bike is
equipped with a cord having an equipment grounding conductor and
a grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with
all local codes and ordinances. If the user does not follow these
grounding instructions, the user could void the Matrix limited
warranty.
DANGER: Improper connection of the equipment grounding
conductor can result in the risk of electric shock. Check with a
qualified electrician if the user is in doubt as to whether the product
is properly grounded. Do not modify the plug provided with the
product if it will not fit the outlet, have a proper outlet installed by an
electrician

5
Preventative maintenance and daily cleaning will prolong the life and
look of your MATRIX U7x-01 Bike
Please read and follow these tips.
* Position the equipment away from direct sunlight. The intense UV
light can cause discoloration on plastics.
* Locate your equipment in an area with cool temperatures and low
humidity.
* Clean with a soft 100% cotton cloth.
* Clean with soap and water or other non-ammonia based all pur-
pose cleaners.
* Wipe seats, pedals, console, heart rate grips, and the handlebar
clean after each use.
* Do not pour liquids directly onto your equipment. This can cause
damage to the equipment and in some cases electrocution.
* Check pedal straps weekly for wear.
* Adjust leveling feet when equipment wobbles or rocks.
* Maintain a clean area around the equipment, free from dust and
dirt.
DO NOT use any equipment that is damaged or has worn or
broken parts. Use only replacement parts supplied by Matrix
Fitness Systems.
MAINTAIN LABELS AND NAMEPLATES. Do not remove labels
for any reason. They contain important information. If unreadable
or missing, contact Matrix Fitness Systems for a replacement at
866-693-4863 or www.matrixfitness.com.
MAINTAIN ALL EQUIPMENT. Preventative maintenance is the
key to smoothly operating equipment. Equipment needs to be
inspected at regular intervals. Defective components must be
kept out of use until they are repaired. Ensure that any person(s)
making adjustments or performing maintenance or repair of any
kind is qualified to do so. Matrix Fitness Systems will provide
service and maintenance training at our corporate facility upon
request or in the field if proper arrangements are made.
3.2 CHECK FOR DAMAGED PARTS
3.1 RECOMMENDED CLEANING TIPS
CHAPTER 3: PREVENTATIVE MAINTANANCE

6
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.3 CARE AND MAINTENANCE INSTRUCTIONS
In order to maximize life span, and minimize down time, all MATRIX
equipment requires regular cleaning, and maintenance items
performed on a scheduled basis. This section contains detailed
instructions on how to perform these items and the frequency of
which they should be done. Some basic tools and supplies will be
necessary to perform these tasks which include (but may not be
limited to):
* Metric Allen wrenches
* #2 Phillips head screwdriver
* Adjustable wrench
* Torque wrench (capability to read foot lbs and inch lbs)
* Lint free cleaning cloths
* Teflon based spray lubricant such as "Super Lube" or other Matrix
approved products.
* Mild water soluable detergent such as "Simple Green" or other
Matrix approved products
* Vacuum cleaner with an extendable hose and crevasse tool
attachment.
You may periodically see addendums to this document, as the
Matrix Technical Support Team identifies items that require specific
attention, the latest version will always be available on the Matrix
web site at www.matrixfitness.com.
DAILY MAINTENANCE ITEMS
1) Look and listen for loose fasteners, unusual noises, and any
other indications that the equipment may be in need of service.
2) Clean the bike before and after each use, including:
a. Use a damp, soft cloth with water or mild liquid detergent
to clean all exposed surfaces. DO NOT use ammonia, chlorine, or
any acid based cleaners.
b. Keep the console display free of fingerprints and salt build
up caused by sweat.
WEEKLY MAINTENANCE ITEMS
1) Frequently vacuum the floor beneath the unit to prevent the
accumulation of dust and dirt which can affect the smooth operation
of the unit.
2) Check the pedal straps for damage.
3) Clean the grooves on the foot pedals.
MONTHLY MAINTENANCE ITEMS
1) Inspect the console, seat, pedals, and shrouds for damage.
2) Tighten the pedals onto their respective cranks using a 15 mm
wrench.
3) Adjust the leveling feet if equipment rocks or wobbles.
QUARTERLY MAINTENANCE ITEMS
1) Remove the front shrouds and check the belt for damage,
alignment, and proper tension.

7
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.1 CONSOLE DESCRIPTION
MULTI-PURPOSE KEYS: Keys have different functions depending on
each screen.
GO: One touch Start.
ENTER: To confirm each program setting.
UP / DOWN LEVEL: Easy information and level selection.
UP / DOWN TIME: Easy information and time adjustment.
STOP: Ends workout and shows workout summary data.
NUMBER KEYPAD: Workout data input for workout setup. Level
adjustment during workout.
COOL DOWN: Puts bike into Cool Down mode.
FAN: Allows for fan speed selection (fan has 3 operating speeds).
U7X-01 ENTERTAINMENT ZONE
iPOD®: Will take the user directly to the iPod screen to allow for iPod
control and playlist selection.
VOLUME UP / DOWN: Adjusts the volume output through the
headphone jack of the integrated console TV or iPod output.
NUMBER KEYPAD: Allows for easy TV channel selections.
CHANNEL UP / DOWN: Allows for channel selection.
DISPLAY MODE: Allows user to cycle through console display
options, iPod, TV, or profile display.
LAST CHANNEL: Allows the user to cycle between the current
channel and the previous channel viewed.

8
4.2 WORKOUT SETUP STEPS - MANUAL 4.4 WORKOUT SETUP STEPS - TRAINING WORKOUTS
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
GO - Press to immediately begin a workout. Workout, resistance
level, and time will automatically go to default settings. Pressing
GO will not prompt user for age, weight, or level settings.
1) Start pedaling and press the GO key to begin your workout. 2)
The display will read 3, 2, 1, Begin and then the program will start.
MANUAL - Manual allows the user to input more information
while defining their own workout. Calorie expenditure will be more
accurate when inputting information in Manual than by pressing GO.
1) Start pedaling and press the key next to MANUAL on the
display.
2) Select the key next to Level and follow the prompts to set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.
FAT BURN - Fat burn is a level based program that is designed
to help users burn fat through various resistance level changes.
1) Start pedaling and press the key next to FAT BURN on the
display.
2) Select the key next to Level and follow the prompts to set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.
4.3 WORKOUT SETUP STEPS - FAT BURN
ROLLING HILLS - The Rolling Hills program is a level based
program that automatically adjusts the resistance level to simulate
real terrain.
1) Start pedaling and press the key next to TRAINING
WORKOUTS on the display, and then press the key next to
ROLLING HILLS.
2) Select the key next to Level and follow the prompts to set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.
INTERVALS - The Intervals program is a level based program
that automatically adjusts the resistance of the machine from low to
high intensity settings at regular intervals.
1) Start pedaling and press the key next to TRAINING
WORKOUTS on the display, and then press the key next to
INTERVAL TRAINING.
2) Select the key next to Level and follow the prompts to set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.
RANDOM - Random is a level based workout that randomly
adjusts the resistance of the machine.
1) Start pedaling and press the key next to TRAINING
WORKOUTS on the display, and then press the key next to
RANDOM.
2) Select the key next to Level and follow the prompts to set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.

9
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.5 WORKOUT SETUP STEPS - FITNESS TEST
FITNESS TEST -The Cooper Fitness Test measures cardiovascular fitness and proves an estimated sub-maximal VO2 result. It is based
on power output according to ACSM standards and was developed by the Cooper Institute© (www.cooperinstitute.org). User RPMs must
remain between 60-80 RPM during the test. The test will end when the user can no longer maintain this speed. Use of a heart rate strap is
optional but provides more data.
The test starts at a low intensity level and gradually increases in intensity (difficulty) every 2 minutes. As it increases, the user must maintain
60-80 RPM to advance to the next level. The test could take upwards of 30+ minutes for very fit individuals. Once the test ends a recovery
period (cool down) will begin and the user's results are calculated and displayed. Results are based on the number of stages completed.
Incline will not be adjustable during the test.
1) Start pedaling and press the key next to FITNESS TEST on the display.
2) Select the key next to Age and follow the prompts to set.
3) Select the key next to Gender and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and then the program will begin.
6) Once the workout is complete, the display will read the results of the Fitness Test.
STAGES COMPLETED:
1 Well Below Average
2 Well Below Average
3 Below Average
4 Below Average
5 Average
6 Average
7 Above Average
8 Above Average
9+ Well Above Average

10
4.6 WORKOUT SETUP STEPS - TARGET HEART RATE
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.7 WORKOUT SETUP STEPS - CONSTANT WATTS
TARGET HEART RATE - The Matrix U7x-01 Bike comes with
standard digital contact heart rate sensors and are POLAR telemetry
compatible. The heart rate control workout mode allows the user to
program their desired heart rate zone, and the bike will automatically
adjust the level based upon the user's heart rate. The heart rate
zone is calculated using the following equation: (220-Age)8%=target
heart rate zone. The user must wear a POLAR telemetric strap or
continually hold onto the contact heart rate grips for this workout.
Locate the metal sensors on the handlebars of the bike. Notice
that there are two separate pieces of metal on each grip. You must
be making contact with both pieces of each grip to get an accurate
heart rate reading. You can grab these sensors in any program to
view your current heart rate.
1) Start pedaling and press the key next to TARGET HEART RATE
on the display.
2) Select the key next to Age and follow the prompts to set.
2) Select the key next to Percent of HR and follow the prompts to
set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.
CONSTANT WATTS - Constant Watts is a unique program
that allows you to vary your cadence or RPM and the bike's
resistance level will adjust accordingly to your selected goal. The
quicker you pedal, the less resistance for the goal selected.
1) Start pedaling and press the key next to CONSTANT WATTS
on the display.
2) Select the key next to Watts and follow the prompts to set.
3) Select the key next to Time and follow the prompts to set. .
4) Select the key next to Weight and follow the prompts to set.
5) Select the key next to GO and the display will read 3, 2, 1, and
then the program will begin.

11
5.1 USING MANAGER MODE
The Manager's Custom Mode allows the club owner to customize the bike for the club.
1) To enter Manager Mode, press ENTER, 1, 0, 0, 1, ENTER on the upper display. Manager Mode will appear on the display (Figure A).
2) Select the key next to the setting that needs to be changed, and follow the prompts to change.
3) Press the ENTER key once the desired setting is correct to save.
4) Press HOME or press and hold the STOP key for 3-5 seconds to return to normal operation.
FIGURE A
CHAPTER 5: MANAGER MODE

12
5.2 MANAGER MODE - ABOUT TAB
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Versions Software version. Cannot be modified.
Key Sound
Default: On
Controls whether there is a key sound when
a key is pressed and whether it is a beep or
through the speakers.
On / Off
Out of Order
Default: Off
This option allows the club to put the console
into an "out of order" status.
On / Off
MANAGER MODE
About
CHAPTER 5: MANAGER MODE

13
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Versions Software version. Cannot be modified.
Key Sound
Default: On
Controls whether there is a key sound when
a key is pressed and whether it is a beep or
through the speakers.
On / Off
Out of Order
Default: Off
This option allows the club to put the console
into an "out of order" status.
On / Off
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Maximum Time
Default: 60 Minutes
This option allows the club to set the
maximum workout duration limits during
peak and non peak hours.
Maximum: 99 Minutes
Minimum: 5 Minutes
Pause Time
Default: 5 Minutes
This option controls the default pause time. Maximum: 10 Minutes
Minimum: 1 Minute
MANAGER MODE
Time
5.3 MANAGER MODE - TIME TAB
CHAPTER 5: MANAGER MODE

14
FUNCTION & DEFAULTS DESCRIPTION MODIFIED
Level
Default: 1
This option controls the dafault
program level.
Maximum: 1
Minimum: 20
Age
Default: 30
This option controls the default user's
age used in the target HR calculations.
Maximum: 100
Minimum: 10
Weight
Default: 150 lbs / 68 kg
This option controls the default weight
used in the calorie calculations.
Displayed in pounds or kilograms.
Maximum: 400 lbs / 180 kg
Minimum: 80 lbs / 36 kg
Gender
Default: Male
Setting the user as Male or Female. Male or Female
Time This option controls the default
program time.
Maximum: Max Time Setting
Minimum: 5 Minutes.
MANAGER MODE
Defaults
5.4 MANAGER MODE - DEFAULTS TAB
CHAPTER 5: MANAGER MODE

15
MANAGER MODE FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Language Select default language. This option allows the user to select a flag for a
specific language.
N/A
LANGUAGE
English
German
FLAG UNIT
Mile
Mile
KM
KM
KM
LANGUAGE
Spanish
Dutch
Italian
Japanese
FLAG UNIT
KM
KM
KM
KM
KM
LANGUAGE
Chinese
Portuguese
French
FLAG UNIT
KM
KM
KM
KM
KM
5.5 MANAGER MODE - LANGUAGE TAB
CHAPTER 5: MANAGER MODE

16
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Channel
Default: 1
This option controls the default TV channel
on start up.
Channels 1-999
Volume
Default: 1
This option controls the default TV volume
on start up.
Maximum: 17
Minimum: 1
Channel Scan This option scans the local TV system for
channels.
N/A
External TV
Default: Off
This option controls the external TV power. On / Off
MANAGER MODE
TV
5.6 MANAGER MODE - TV TAB
CHAPTER 5: MANAGER MODE
