Matrix 0850 User manual

User
Manual
0850/0850-T1 External Thread Grinder

Edition: 08/2013
Foreword
The information in this manual refers to equipment supplied by:
MATRIX MACHINE TOOL (COVENTRY) LIMITED
Matrix House, A2 Earlplace Business Park
Fletchamstead Highway, Coventry, CV4 9XL
UNITED KINGDOM
[email protected]
http://www.matrix-machine.com
Preface
The Health & Safety section of this manual must be read and all safety related precautions
observed before proceeding with the installation of this machine.
Support
Tel: [phone]
Fax: [phone]
Email: [email protected]
If you have any queries or suggestions regarding the 0850 User Manual, please contact our
Technical Publications Department: [email protected]
This manual describes the use of the 0850 External Thread Grinder. Any options taken or
deviations from the standard are documented in each machines individual set of manuals.
Matrix Machine Tool (Coventry) Limited reserves the right to modify its products without
notification and consequently to supply machines which are not in every detail in accordance
with the descriptions and procedures in this publication.
(This manual was written using Calibri font , size 12)

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 3 / 231
Edition: 08/2013
Symbols & References
The table below lists symbols used throughout this document. Bold square brackets [ ] have been
used in this manual to denote a button or key function on the operator control console.
symbol
[ ] ref
meaning
General caution
Indicates general cautionary, warning, or danger level
information
Electrical shock caution
Indicates possibility of electric shock under specific conditions
[JOG]
JOG mode selection
[MDA]
MDA mode selection
[AUTO]
AUTO mode selection
[TEACHIN]
TEACHIN mode selection
[SBLK]
SINGLE BLOCK mode selection
[RESET]
RESET program cycle, alarm message
[CYCLE
START]
CYCLE start request

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 4 / 231
Edition: 08/2013
[SPINDLE
START]
Grinding spindle start request
[SPINDLE
STOP]
Grinding spindle stop request
[SP.INC]
Increase grinding spindle speed override in 10% increments
SP.DEC]
Reduce grinding spindle speed override in 10% decrements
[SP.100%]
Set grinding spindle speed override to 100%
[Hand Unit Enable]
MPG/hand unit ON/OFF toggle function
[Coolant OFF]
Coolant delivery ON/OFF toggle function
[Lights
ON/OFF]
General machine lighting ON/OFF toggle function
YES
[YES]
Dialog prompt acknowledge button
[Unlock Door]
Unlock guard door request
[Gear ON/OFF]
Gearbox ON/OFF toggle function
[SETUP]
Setup mode toggle function.
Generally selected when using any of the setting cycles
[FIN]
Acknowledge button used during setting and grinding cycle
instruction prompts or to confirm the completion of a setting
cycle sequence
[AUTO REF]
Starts referencing all machine axes in a pre-defined order

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 5 / 231
Edition: 08/2013
[ROTATE]
Workpiece continuous rotate
[TAILSTOCK
ADV/RET]
Tailstock advance/retract toggle
[STEADY
OPEN/CLOSE]
Workpiece steady open/close toggle
[PROBE
ADV/RET]
Probe advance/retract toggle
WARM
UP
[WARM-UP]
Machine warm-up cycle select
X
[X]
machine X axis select
Z
[Z]
machine Z axis select
C
[C]
machine C axis select
A
[A]
machine A axis select
W2
[W2]
tailstock axis select
Menu selection
">" is used to denote the sequence of softkey presses required to get a specific screen.
Example: Matrix > Main Menu > Part Data

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 6 / 231
Edition: 08/2013
Table of Contents
1Health & Safety.................................................................................................................................10
1.1 General Safety......................................................................................................................................10
1.2 Understanding Safety Rules & Regulations..........................................................................................11
1.3 Know your machine .............................................................................................................................11
1.4 Maintain a safe working area...............................................................................................................11
1.5 Electricity..............................................................................................................................................12
1.6 Workshop hygiene ...............................................................................................................................12
1.7 Cancer of the skin caused by oil...........................................................................................................13
1.8 Machine Guards...................................................................................................................................13
1.9 Grinding Wheels...................................................................................................................................14
1.10 Machine User .......................................................................................................................................16
1.11 Service and Maintenance.....................................................................................................................16
2Liability Exclusions ............................................................................................................................17
3Machine Overview............................................................................................................................18
3.1 General layout......................................................................................................................................18
3.2 Axis configuration ................................................................................................................................21
3.3 Machine configuration.........................................................................................................................22
3.4 Machine floor layout (with 800L coolant system) ...............................................................................23
3.5 Machine floor layout (with optional high pressure 3000L coolant system) ........................................24
3.6 Minimum workshop height requirement ............................................................................................25
4Technical Data ..................................................................................................................................26
5Dresser System .................................................................................................................................29
5.1 Fixed Helix backplate (standard)..........................................................................................................29
5.2 Adjustable Helix backplate (option).....................................................................................................31
5.3 Dressing Spindle...................................................................................................................................34
5.4 Single-point diamond holder (option) .................................................................................................35
6Grinding Spindle ...............................................................................................................................37
6.1 Spindle Warm-Up.................................................................................................................................38
6.2 Grinding Wheel Speed Chart................................................................................................................39
6.3 Handling Grinding Wheels ...................................................................................................................40
6.4 Checking the grinding wheel................................................................................................................41
6.5 Mounting the grinding wheel ..............................................................................................................41
7Workhead.........................................................................................................................................42
7.1 Standard Workhead .............................................................................................................................42
7.2 Power operated workhead chuck (option)..........................................................................................43
7.2.1 3-Jaw chuck arrangement....................................................................................................................43
7.2.2 Opening and closing the chuck manually.............................................................................................44
8Powered workpiece support steady (option) .....................................................................................45
8.1 Operating the steady ...........................................................................................................................46
8.2 Fine Adjustment Screws.......................................................................................................................47
8.3 Procedure for fine alignment of the steady rest..................................................................................48
8.4 Steady Clamping Pressure....................................................................................................................49
9Tailstock ...........................................................................................................................................50
9.1 Manual Tailstock (standard) ................................................................................................................50
9.2 Pneumatic Tailstock (option) ...............................................................................................................52
9.2.1 Manual Operation Procedure ..............................................................................................................54
9.3 Travelling Tailstock (option).................................................................................................................55
9.3.1 Manual Operation Procedure ..............................................................................................................56
9.3.2 Setting the tailstock advance and retract positions.............................................................................57
9.4 Taper Adjust Procedure .......................................................................................................................58
10 Workpiece probing (option) ..........................................................................................................59
10.1 Fitting the probe unit to the work table ..............................................................................................60

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 7 / 231
Edition: 08/2013
10.2 Enabling the probe system signal interface.........................................................................................62
10.3 Setting the probe offsets .....................................................................................................................62
10.3.1 Probe Offsets screen............................................................................................................................62
10.3.2 Procedure for establishing offsets .......................................................................................................63
10.3.3 Part Offset ............................................................................................................................................67
10.3.4 Testing Auto Pitch-in and correcting the Probe 1 offset .....................................................................68
11 Automatic doors (option) ..............................................................................................................70
11.1 Manual door operation........................................................................................................................71
12 Two-hand auto cycle start (option)................................................................................................72
12.1 Procedure for starting an automatic cycle using two-handed start buttons.......................................73
13 ANDON Light (option) ...................................................................................................................74
14 Standard coolant system (800L, upto 5bar working pressure).........................................................75
14.1 Switching on the coolant system .........................................................................................................76
14.2 Stage 1 - magnetic separator filtration ................................................................................................77
14.3 Stage 2 –centrifugal filtration..............................................................................................................77
14.4 Stage 3 –oil cooling .............................................................................................................................77
14.5 Stage 4 - Oil distribution.......................................................................................................................78
14.6 Stage 5 - Oil Return ..............................................................................................................................78
15 Optional HP coolant system (3000L, upto 70bar working pressure).................................................79
15.1 Switching on the coolant system .........................................................................................................79
16 Automatic Fire System (option) .....................................................................................................82
16.1 Principle of operation...........................................................................................................................82
16.2 What happens in the event of a fire? ..................................................................................................83
16.3 Fire System Low Maintenance .............................................................................................................83
16.4 Manual triggering of the fire extinguisher...........................................................................................84
17 Operator Console..........................................................................................................................85
17.1 HMI panel.............................................................................................................................................85
17.2 Machine Control Panel (MCP)..............................................................................................................87
17.3 CNC operating modes ..........................................................................................................................89
17.4 Program Cycle Start/Reset...................................................................................................................90
17.5 Axis selection and speed controls........................................................................................................91
17.6 Axis Reference......................................................................................................................................93
17.7 Grinding Spindle Controls ....................................................................................................................94
17.8 Command functions.............................................................................................................................95
17.9 Handheld Unit ......................................................................................................................................99
18 Automatic Wheel Balancer (SBS 4500) ......................................................................................... 100
18.1 Block diagram.....................................................................................................................................100
18.2 Integral Balancer Unit ........................................................................................................................101
18.3 Vibration sensor location...................................................................................................................102
18.4 Control Panel......................................................................................................................................103
19 Dialog Programming.................................................................................................................... 104
19.1 Displaying the Main Menu .................................................................................................................104
19.2 Work piece Manager..........................................................................................................................105
19.2.1 Create and Load a new workpiece.....................................................................................................105
19.2.2 Load an existing workpiece................................................................................................................106
19.2.3 Unload the workpiece........................................................................................................................106
19.3 Part Data ............................................................................................................................................107
19.3.1 Edit and Verify Part Data....................................................................................................................107
19.3.2 Explanation of the Input Parameters.................................................................................................108
19.3.3 Taper In/ Taper Out............................................................................................................................110
19.4 Thread Data (PMHMI)........................................................................................................................112
19.4.1 Create New Thread ............................................................................................................................112
19.4.2 Thread Parameter List........................................................................................................................118
19.4.3 Thread Type 1.....................................................................................................................................119
19.4.4 Thread Type 2.....................................................................................................................................120

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 8 / 231
Edition: 08/2013
19.4.5 Thread Type 3.....................................................................................................................................121
19.4.6 Thread Type 4.....................................................................................................................................122
19.4.7 Thread Type 5.....................................................................................................................................123
19.4.8 Thread Type 6.....................................................................................................................................124
19.5 Create New Tool.................................................................................................................................125
19.6 Grinding Cycle Overview....................................................................................................................130
19.6.1 Part Counter (option).........................................................................................................................131
19.7 Dressing Cycle Overview ....................................................................................................................132
19.8 Setting Cycles Menu...........................................................................................................................133
19.9 New Wheel Cycle ...............................................................................................................................135
19.9.1 Explanation of the Input Parameters.................................................................................................136
19.9.2 Procedure for executing the NEW WHEEL setting cycle - if diamond ROLL fitted.............................141
19.9.3 Procedure for executing the NEW WHEEL setting cycle - if diamond DISC fitted .............................142
19.10 Work Datum Setting Cycle .................................................................................................................143
19.10.1 Explanation of the Input Parameters.................................................................................................143
19.10.2 Setup method 1 –grind direction from right-to-left .........................................................................144
19.10.3 Setup method 2 –grind direction from left-to-right .........................................................................144
19.10.4 Procedure for executing the WORK DATUM setting cycle ................................................................145
19.11 Barelling function (option).................................................................................................................146
19.11.1 Explanation of the Input Parameters.................................................................................................147
19.12 Probe system setup (option)..............................................................................................................148
19.12.1 Explanation of the Input Parameters.................................................................................................148
19.12.2 Procedure for setting up the probe system.......................................................................................149
19.13 Pitch-IN Setting Cycle.........................................................................................................................151
19.13.1 Explanation of the Input Parameters.................................................................................................151
19.13.2 Pitch-in to workpiece with a pre-cut thread......................................................................................152
19.13.3 Pitch-in to a blank or non-threaded workpiece.................................................................................152
19.13.4 Procedure for executing the PITCH-IN setting cycle..........................................................................153
19.14 Next Wheel Setting Cycle (option).....................................................................................................154
19.15 Auto Dress Utility Cycle......................................................................................................................155
19.15.1 Explanation of input parameters .......................................................................................................156
19.15.2 Procedure for using the Auto Dress cycle..........................................................................................157
19.16 Correction Utilities Menu...................................................................................................................158
19.17 Lead Correction..................................................................................................................................159
19.17.1 Explanation of input parameters .......................................................................................................159
19.17.2 Procedure...........................................................................................................................................161
19.17.3 Applying lead correction ....................................................................................................................162
19.18 Taper Correction ................................................................................................................................163
19.18.1 Explanation of input parameters .......................................................................................................164
19.18.2 Positive Taper Error............................................................................................................................165
19.18.3 Negative Taper Error..........................................................................................................................165
19.18.4 Procedure...........................................................................................................................................166
19.19 Diameter Correction ..........................................................................................................................167
19.19.1 Explanation of input parameters .......................................................................................................167
19.19.2 Applying diameter correction ............................................................................................................168
19.19.3 Procedure...........................................................................................................................................168
19.20 Profile Correction...............................................................................................................................169
19.20.1 Explanation of input parameters .......................................................................................................170
19.20.2 Procedure...........................................................................................................................................171
19.21 Barrelling Correction..........................................................................................................................172
19.21.1 Procedure...........................................................................................................................................172
19.22 Cycle Data - Grind Table.....................................................................................................................173
19.22.1 Procedure to edit Grind cycle variables.............................................................................................174
19.22.2 Grinding Zones ...................................................................................................................................175
19.22.3 Explanation of parameters.................................................................................................................176

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 9 / 231
Edition: 08/2013
19.22.4 End-threading parameters.................................................................................................................178
19.22.5 How to set the start and end points for end-thread grinding ...........................................................179
19.23 Cycle Data –Dress Table ....................................................................................................................180
19.23.1 Procedure to edit Dress cycle variables.............................................................................................180
19.23.2 Explanation of parameters.................................................................................................................181
19.24 Load and Run the Grind Cycle............................................................................................................182
19.25 Cycle Stop/interrupt...........................................................................................................................183
19.25.1 Procedure for Cycle Interrupt ............................................................................................................184
19.25.2 Resume the cycle ...............................................................................................................................185
19.25.3 Make a correction to the diameter and then resume the cycle........................................................185
20 Access Level Key Switch .............................................................................................................. 186
21 Programming M/S/T Codes ......................................................................................................... 187
22 Maintenance............................................................................................................................... 189
22.1 Lubrication System.............................................................................................................................189
22.2 Electrical Control Cabinet (ECC) .........................................................................................................190
22.3 Services Cabinet (SC)..........................................................................................................................191
22.4 Fume Extractor...................................................................................................................................192
22.5 Recommended oils/fluids/additives ..................................................................................................193
22.6 Coolant System ..................................................................................................................................195
22.7 Preparing the Spindle Chiller Unit......................................................................................................196
1.1.1 Oil Cooler Unit ...............................................................................................................................197
2.1.1 Working Mode Of Cooler Unit Controller......................................................................................197
22.8 General Maintenance Schedule.........................................................................................................200
22.9 Pressurised air supply to machine .....................................................................................................202
22.10 Cleaning the coolant system centrifuge.............................................................................................203
22.11 Power Chuck maintenance ................................................................................................................208
23 Troubleshooting Guide................................................................................................................ 209
23.1 Oil Cooler Unit fault codes .................................................................................................................209
23.2 Machine Diagnostic Screens ..............................................................................................................213
23.3 Alarm Messages .................................................................................................................................217
23.4 Recovering from an axis software travel limit condition...................................................................228
23.5 Air conditioning unit alarm codes......................................................................................................229
23.6 Coolant System Technical Data..........................................................................................................230

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 10 / 231
Edition: 08/2013
1Health & Safety
This machine carries the CE Mark and complies with the Machinery Directive 89/392 as amended by
the EC Directive 91/368.
The Safety Provisions are based on the draft European provisional standard for grinding machinery
designated as document CEN/TC143/N141E.
The standard provides for both Operating and Setting modes and these are described in the
Operating section of this manual.
Matrix Machine Tool has a safety record of which it is justly proud and in issuing this user manual
they would like to bring to your operator’s attention to Section 7 of the Health & Safety at Work Act
1974, which requires that the supplied machine is designed and constructed as far as reasonably
practicable to be safe and without risk to health.
1.1 General Safety
Matrix machines are constructed for maximum operator safety under standard operating conditions,
when recommended instructions are followed in the assembly and operation of the machine and its
equipment.
All personnel engaged in the use of the machine should become familiar with its operation as
described in this manual. Proper operation of the machine promotes safety for the operator and all
workers in the vicinity.
Particular attention must be paid to the appropriate pages of this manual where the following
symbols are shown.
Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury or damages to the machine. The information described following
the caution symbol must be strictly observed.
Indicates risk of electrical shock
Power source work must be entrusted to an electrician with a license to carry out
electrical work. If a person without knowledge of electrical safety practices attempts
this work, he or she could be electrocuted and possibly seriously injured or the
machine could be seriously damaged.
Become familiar with material, inspection and mounting of grinding wheels, wheel speed limitations
and correct setting and securing of wheel guards.
Many factories have wheel mounting specialists who because of their experience and knowledge, are
designated the responsibility for properly mounting the wheel. When possible, such persons with this
responsibility should be consulted to supervise or perform the work.
In reading the following guidelines for safety, it should be recognized that it is the responsibility of
each individual to observe the prescribed rules as outlined. All warning and danger signs must be
observed and obeyed. All actual or potential danger areas must be reported to your immediate
supervisor.

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 11 / 231
Edition: 08/2013
1.2 Understanding Safety Rules & Regulations
Understand and obey safety regulations set out by your employer. Read the operating instructions in
this and the CNC controller manuals.
1.3 Know your machine
An experienced operator will have knowledge of:
alignment and mounting of work pieces or devices
setting, operation and monitoring of the grinding machine
selection and use of abrasive products
recording of data for the machining of work pieces and optimisation of the machining process
special hazards and safety requirements
Observe all warning plates on the machine. Understand these warnings and follow their directions as
you operate the machine.
1.4 Maintain a safe working area
Your working area should be clean and uncluttered. Give yourself room for a firm, well balanced
stance.
Check all guards are in position and securely fastened
Be sure all guards are in correct position before operating the machine
Do not operate a machine with missing guards
Be sure that all fasteners are being used and they are firmly tightened.
Always wear safety glasses.
Always make sure that you have no loose clothing when working on the machine, especially
with the front door open and the axis moving, i.e. setting the part to run true with the C axis
rotating.
CAUTION
DO NOT open the wheel guard while the grinding wheel is rotating
DO NOT adjust the grinding coolant nozzles when the wheel is rotating
Be certain that the component is mounted securely and the driver is in place and secure.
Never try to stop a coasting grinding wheel with your hand or hand held object.
Stop coolant flow before stopping wheel.
DO NOT:
run coolant on a stationary wheel.
modify the drive to get higher wheel speeds.
use special pulleys, high speed motors or speed control devices which have been altered or
made inactive.
Use standard wheel dressers.

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 12 / 231
Edition: 08/2013
1.5 Electricity
WARNING
ORANGE WIRING IS LIVE WHEN MAINS ISOLATOR IS SWITCHED TO THE OFF
OR ON POSITION!
ALL ORANGE coloured wiring is LIVE at all times. This applies even when the electrical isolator on the
machine is OFF position.
For all repairs and servicing turn the power off, at all sources of electrical and pneumatic supplies
before servicing. Exceptions would be in the few cases where the machine must be in operation to
make adjustments, and in these cases, the utmost care should be taken at such times.
WARNING
Switch off the main isolator before removing any panels or carrying out any
electrical repair work on the machine.
Switching the main isolator OFF does not erase data from the CNC controller’s memory and it can be
used to isolate the electrical supply at any time.
1.6 Workshop hygiene
The adjustment setting, general operation of machines, wheel changing together with the removal of
grinding debris are tasks which bring people into contact with oil.
There may be exposure to oil fumes or oil mist. Naked skin could come into contact with oil through
splash, handling of wet work-pieces or drips from guarding.
WARNING
Soluble oil emulsions provide a breeding ground for aerobic or anaerobic
bacteria and infected systems may develop considerable quantities of slime,
gums and sludge.
In addition to health problems and foul odours, the performance of the
cutting fluid will be reduced and corrosion problems will occur.
The useful life of fluids can be reduced to weeks instead of months. The
source of infection is invariably the residues from previous changes of
emulsion, so the simplest and most beneficial step is effective draining,
cleaning (both flushing with a chemical cleaner and physical cleaning) and
preferably sterilising between changes.
Industrial dermatitis can arise, especially amongst persons sensitive to skin
irritations but a more fundamentally serious problem is the possibility of skin
cancer of the scrotum.

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 13 / 231
Edition: 08/2013
1.7 Cancer of the skin caused by oil
Continuous contact with oil, soluble oil and particularly with straight cutting oils can cause cancer of
the skin.
WARNING
The following precautions must be taken:
DO NOT wear oil soaked clothes
DO NOT put oily rags in trouser pockets
wash all oil from body after work
read the section on Workshop Hygiene
wear protective clothing
avoid unnecessary contact with oil
wear oil resistant gloves
1.8 Machine Guards
Factory employers are required by law to guard and/or fence all dangerous parts of machinery.
Employees are also required by law to use all the guards supplied as above.
DO
Ensure that all fixed and adjustable guarding is secured in its correct position before the
machinery is operated.
Wear the correct protective equipment at all times in the workshop.
DO NOT
Remove fixed guards without permission
Remove adjustable guards except when necessary during setting up operations
Clean any parts of the machine whilst the machine is in motion
Use any machine unless you have been authorised to do so
Leave tools or loose articles on machine tables and slides
If you suspect your machine is defective then STOP it immediately!
Never attempt to repair it yourself, whether it is a mechanical or electrical fault.
Switch off the main isolator switch and report the problem to your supervisor.
CAUTION
DO NOT open the wheel guard while the grinding wheel is rotating
DO NOT adjust the grinding coolant nozzles when the wheel is rotating

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 14 / 231
Edition: 08/2013
1.9 Grinding Wheels
CAUTION
Never run-up the spindle to maximum speed during the start-up time when it is
cold, otherwise, due to different thermal expansion characteristics in the
bearings, stress conditions are produced, which can cause damage to the
spindle.
If there are any doubts about the way in which the spindle is operating then stop
the cycle immediately!
WARNING!
DO NOT EXCEED the maximum surface speed (usually specified in m/s) of
the grinding wheel as recommended by the wheel manufacturer.
The maximum surface speed of the grinding wheel is determined by its usable diameter. The table
below shows the max and min wheel diameters permitted on the machine and associated maximum
surface speeds:
Grinding wheel diameter
Max surface speed @ 2000rpm
500mm (max)
52 m/s
400mm (min)
42 m/s
WARNING!
Only grinding wheels with the following tolerances mounted on Matrix flanges
must be used on this machine. Grinding wheels with a coarser and softer
specification than 80L should not be used without reference to either Matrix or
the grinding wheel manufacture.
Width
+/- 0.20mm
bore diameter up to 75mm
+ 0.025mm
+ 0.100mm
bore diameter 125mm to 200mm
+ 0.050mm
+ 0.150mm
bore diameter 225mm to 250mm
+ 0.050mm
+ 0.178mm
The maximum peripheral speed of the grinding wheel is limited to 50m/s when the machine guard
doors are open.
CAUTION!
Only trained persons that have been instructed in the safe mounting
of grinding wheels are allowed to change and mount grinding wheels.
The programmed speed (RPM) of the wheel must NEVER exceed the maximum
speed of the quill that it is fitted to.

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 15 / 231
Edition: 08/2013
DO
Be certain that the component is mounted securely.
Stop coolant flow before stopping wheel.
Accept machine limits for wheel speed.
Switch the main electrical cabinet isolator OFF or press the machine Emergency Stop push
button to remove power before changing the wheel.
Inspect a new grinding wheel before mounting it on the machine. Look for cracks, nicks or
signs of damage. If you see these or have doubt about the soundness of the wheel, do not use
it.
Inspect wheel adaptor flange before mounting a wheel.
Use light pressure when mounting a wheel.
Check that you have the right wheel and that the machine spindle speed is correct for the
wheel and the quill.
Store wheels in a box and handle carefully.
DO NOT
try to stop a coasting grinding wheel with your hand or hand held object
run coolant on a stationary wheel
modify the drive to get higher wheel speeds
use special pulleys, high speed motors or speed control devices which have been altered or
made inactive
force a wheel on to a wheel adaptor

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 16 / 231
Edition: 08/2013
1.10 Machine User
Only properly trained and authorised personnel must be allowed to operate and maintain this
equipment. All areas of responsibility for the operation, setting-up and maintenance of this
equipment must be clearly specified and complied with.
CAUTION - RISK OF DANGER!
The relevant section of the user manual must be consulted where this symbol is
marked on the machine.
CAUTION - RISK OF ELECTRIC SHOCK!
The relevant section of the user manual must be consulted where this symbol is
marked on the machine.
Make yourself familiar with the Protection of Eyes Regulations, the Abrasive Wheel Regulation and
the duty of all employees under the Health and Safety at Work Act.
Section 7 states; it shall be the duty of every employee while at work to take reasonable care of the
Health and Safety of himself and other persons who may be affected by acts or omissions at work.
1.11 Service and Maintenance
Repairs to the equipment must only be carried out by trained and qualified personnel in accordance
with the servicing and maintenance guidelines. Machine warranty will become void if any repairs or
modifications are made without the express permission of Matrix.

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 17 / 231
Edition: 08/2013
2Liability Exclusions
Matrix Machine Tool (Coventry) Limited are excluded from all liability where the equipment supplied
has been used in a manner other than intended OR has been modified without the express written
permission of Matrix Machine Tool (Coventry) Limited which has subsequently resulted in the
machine to malfunction, become damaged or caused injury to the user.
Summary of exclusions (but not limited to):
1. Any usage or application beyond the specified scope of the supplied equipment.
2. Any usage or operation of the equipment in a technically imperfect condition.
3. Any usage or operation of the equipment without due provision for safety considerations or
hazards.
4. Any usage or operation of the equipment in contravention of the instructions set out in this
user manual.
5. Any usage or operation of the equipment in contravention of information in any third-party
literature provided with the equipment.
6. Any usage or operation where faults that could affect safety are not remedied before start-
up.
7. Any modification, bypassing or de-commissioning of equipment whose intended purpose is to
ensure proper functioning or safety.
8. Unrestricted usage or operation of the equipment and/or active and passive safety.
The end user is responsible for providing a suitable padlock to secure mains isolator switch in the OFF
position when the machine is not being used for prolonged periods.

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 18 / 231
Edition: 08/2013
3Machine Overview
The 0850 machine is a purpose built multi-axis CNC external thread grinder specifically designed for
the precision grinding of many types of workpiece with an external thread or ballform requirement.
The machine base, sub-slides and headstock are each constructed of single-piece high quality
seasoned cast iron. Featuring a fully enclosed hood with a safety interlocked main operator access
door and service access panels the machine is easily accessible from all sides.
Its basic design embodies the latest technology available from the Siemens 840D SolutionLine CNC
control system and Siemens SINAMICS digital servo drive system thus providing the machine with the
dynamic performance and smooth operating characteristics required for high precision grinding
applications.
3.1 General layout
Front view of machine
1
Machine Control Console
2
Grinding wheel retract pushbutton
3
Power chuck open/close pedals (option)
4
Manual sliding operator access door (standard) with safety interlock
Auto sliding door (option)
5
ANDON light stack (option)
6
Fume extraction unit
1
3
4
5
6
2

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 19 / 231
Edition: 08/2013
RH rear perspective view of machine
7
RH side machine service access door
8
Electrical Control Cabinet with AC unit fitted
to door panel
9
Main electrical power isolator switch
10
Coolant system
11
Stage 1 coolant oil filtration
12
Stage 2 coolant oil filtration
13
High pressure lift pump
14
Coolant system control panel
9
8
10
11
12
13
14
7

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 20 / 231
Edition: 08/2013
LH rear perspective view of machine
15
LH side machine service access door
16
Machine rear service access doors
17
Operator/Setter sliding access doors (for wheel and dressing tool change)
18
Workhead chuck pneumatic services control panel
19
Return coolant oil sub-tank
20
Grinding and dressing spindles chiller unit
Coolant system view (rear of machine)
15
18
17
16
19
20
9
