mavili maxlogic User manual

BASED ON
EN 54-14
PROJECT MANUAL
generating confidence

www.mavili.com.tr 02
avili Elektronik A.S. has been GENERATING
CONFIDENCE
for since 1987 with Mavili, Mavigard,
Maxlogic, Maxlogic & Mavigard brand names.
The company which is improving continuously its
service network infrastructure, has of�ices in
Ankara, Izmir, Antalya, Diyarbakir, Samsun, Bursa,
Istanbul (Europian side), Russian central of�ice in
Moscow and Factory showroom in Istanbul Perpa
Trade Center.
Mavili products are exported in more than 60
countries and different regions in the world, in
addition we always provide pre-sales and after
sales support for our
CUSTOMERS AND
DISTRIBUTORS.
Mavili continues manufacturing high quality
products and maintaining services by its dynamic
staff. More than 250 people, composed of
technicians and engineers, are working hard for
CUSTOMER SATISFACTION.
*The ISO 9001:2015 Quality Management System of Mavili Elektronik A.S has been audited and
conformed by LPCB (Loss prevention Certi�ication Board) / ENGLAND.
*Our Fire Detection and Alarm System products were EN 54 and CPR certi�ied by LPCB and Dedal, thus
approving our quality by internationally accredited institutions.
* TSE / TURKEY (Turkish Standards Institute) entitled us to get TS EN 54 certi�icates for Intelligent
Addressable and Conventional Fire Alarm System products, TS EN 50194 certi�icates for our gas
detectors.
* OUR SERVICES are awarded with TS 12849 for Place of Service and Sales Service Quali�ication
certi�icate.
*All marine products have, TURK LLOYD (SOLAS 74 and FSS) and IACS (International Association of
Classi�ication Societies Ltd.) member “Russian Maritime Register of Shipping” type approval certi�icate.
* Our products have Licenses for Usage from Ministries of many countries.
Certi�icates and Approvals
M

In conventional system, the largest zone area should not be over than 1600 m².
In conventional system, each building should be de�ined at least 1zone.
1600m² (max.)
1st Zone 2nd Zone
www.mavili.com.tr 03
Power
On
General
Fault
Power
Fault
System
Fault
Earth
Fault
FIRE Silence
Alarm
Silence
Buzzer
ML-22116
Conventional Fire
Alarm Control Panel
Lamp
Test
SilenceAlarm/
Alarm
Silence
Buzzer
Reset
FIREZONEFIREZONE
FAULTZONEFAULTZONE
Button
Control
Enable
Disable
Disable
Disable
SounderFault/
Disable
1 9
2 10
311
4 12
5 13
6 14
7 15
8 16
Power
On
General
Fault
Power
Fault
System
Fault
Earth
Fault
FIRE Silence
Alarm
Silence
Buzzer
ML-22116
Conventional Fire
Alarm Control Panel
Lamp
Test
SilenceAlarm/
Alarm
Silence
Buzzer
Reset
FIREZONEFIREZONE
FAULTZONEFAULTZONE
Button
Control
Enable
Disable
Disable
Disable
SounderFault/
Disable
1 9
2 10
311
4 12
5 13
6 14
7 15
8 16

In conventional system, each story should be at least 1zone.
In conventional systems, in case one zone covers more than one �ire compartment, zone
boundaries should match with the �ire compartments and base area of the zone should
not be over 400m².
1st Zone
2nd Zone
3rd zone
400m² (max.)
FIRE DOOR
www.mavili.com.tr 04
Power
On
General
Fault
Power
Fault
System
Fault
Earth
Fault
FIRE Silence
Alarm
Silence
Buzzer
ML-22116
Conventional Fire
Alarm Control Panel
Lamp
Test
SilenceAlarm/
Alarm
Silence
Buzzer
Reset
FIREZONEFIREZONE
FAULTZONEFAULTZONE
Button
Control
Enable
Disable
Disable
Disable
SounderFault/
Disable
1 9
2 10
311
4 12
5 13
6 14
7 15
8 16
Power
On
General
Fault
Power
Fault
System
Fault
Earth
Fault
FIRE Silence
Alarm
Silence
Buzzer
ML-22116
Conventional Fire
Alarm Control Panel
Lamp
Test
SilenceAlarm/
Alarm
Silence
Buzzer
Reset
FIREZONEFIREZONE
FAULTZONEFAULTZONE
Button
Control
Enable
Disable
Disable
Disable
SounderFault/
Disable
1 9
2 10
311
4 12
5 13
6 14
7 15
8 16

Audible and/or visual warning devices wiring should provide at least one audible and /
or visual operating warning device in case of a short or open circuit in the system.
www.mavili.com.tr 05
In addressable systems, the detection circuit should be designed so that no more than
20 addressable devices will be disconnected in case of short or open circuit.
1600m² 1600m² 1600m²
1600m² 1600m²
Short
circuit
isolator
Short
circuit
isolator
Short
circuit
isolator
Short
circuit
isolator
Short
circuit
isolator

Ceiling height (m)
≤4,5 < 4,5
≤6
< 6
≤8
< 8
≤11
< 11
≤25 > 25
Operation radius (m)
Detector type
Heat Detector
EN 54-5 Type A
Photo-electric
Detector, EN 54-7
Beam type smoke
Detector, EN 54-12
555NC SA SA
7,5 7,5 7,5 7,5 NC SA
7,5 7,5 7,5 7,5 7,5 SA
*
* Generally a second detector layer is required approximately at the half of the
ceiling height.
NC - Not applicable in given height range.
SA - Used only for special applications.
Limits of operation radius and ceiling height for �ire detectors.
www.mavili.com.tr 06
h=0,1xH
h
7,5m
7,5m
H
Transmitter
Receiver h
7,5m
7,5m
100m
TABLE A.
Beam type smoke detectors are composed of 1 receiver and 1 emitter. Receiver and emitter
should see each other in max. 100m distance. Receiver and emitter horizontally protects
7.5 m in both sides. With 1 pair of beam detector approximately an area of 1500m² can
be protected.

www.mavili.com.tr 07
A smoke detector covers a 7.5 m radius circle area. To avoid “blind points” among coverage
areas, detectors’ coverage areas should be overlapping as shown in the �igure above. Thus,
every detector covers a square of 10.6m x 10.6m, equaling to 112m².
7,5m
Smoke detector
5,3m 10,6m 10,6m x 10,6m = 112m²
A heat detector covers a 5 m radius circle area. To avoid “blind points” among coverage
areas, detectors’ coverage areas should be overlapping as shown in the �igure above. Thus,
every detector covers a square of 7.1m x 7.1m, equaling to 50m².
Heat detector
3,55m 7,1m 7,1m x 7,1m = 50m²
5m

www.mavili.com.tr 08
Smoke detector
7,5m 7,5m 7,5m
Max. 15mMax. 15m
< 2m
Heat detector
5m 5m 5m
Max. 10m Max. 10m
If corridors have less than 2 m width, smoke detectors can be mounted max. 15 m gap.
There is no need to overlap the coverage area of the detectors. If corridors have more
than 2 m width, smoke detectors are mounted in 10 m gaps according to the Table A.
If corridors have less than 2 m width, heat detectors can be mounted with max. 10 m gap.
There is no need to overlap the coverage area of the detectors. If corridors have more
than 2 m width, heat detectors are mounted with 7 m gaps according the Table A.
< 2m

www.mavili.com.tr 09
Ceiling height: 3m
Ceiling height: 3m
Chamber holes
> 150mm
< 10mm
Thermistor
> 150mm
< 10mm
Due to cold air layer present just under the ceiling, heat detectors should not be deeply
mounted all the way into the ceiling and should be in the range of 5% of the ceiling height
to provide healthy operation of the thermistor.
Due to cold air layer present just under the ceiling, smoke detectors should not be deeply
mounted all the way into the ceiling and should be in the range of 5% of the ceiling height
to provide healthy operation of the optical chamber.

www.mavili.com.tr 10
Beam Beam
H
h
h ≤0,05xH
h > 0,05xH
PARTITION
< 500mm
< 300mm
> 500mm
> 500mm
> 500mm
Detectors should be mounted in the range of 5% of upper part of the room height.
Detectors should be mounted 500mm away from walls or partitions. If the top edge of
walls, partitions, racks etc. are less than 300mm from ceiling, they are accepted as walls.
In every vertical downward and horizontal direction from a detector, 500mm gaps should
be provided.

www.mavili.com.tr 11
h
H
D
D>0,25 (H-h) : 1 detector for each cell
D<0,25 (H-h): 2 detectors for each cell
D<0,13 (H-h): 3 detectors for each cell
(Values are in metres)
If the beam height (h) is 5% less than ceiling height (H), ceiling should be treated as �lat
and radius values in Table A should be applied. If the beam height (h) is 5% more than
ceiling height (H), then the conditions in the �igure should be applied.
Detectors should not be mounted adjacent to an air inlet if it is closer than 1 m or if there
is an air �low in the medium more than 1 m/s.
<1m
>1m
Air conditioner / Ventilation
Beam Beam Beam Beam

www.mavili.com.tr 12
If the ratio of “h” and “H” is less than 5%, ceiling is accepted as �lat and detectors are
mounted according to the radius values of the Table A. If the ratio of “h” and “H” is
bigger than 5%, ceiling is accepted as inclined and for each degree of the ceiling slope,
detectors are mounted by modifying the radius values of the Table A. Radius values can
be modi�ied up to 25% of the actual values.
Flat ceiling Inclined ceiling
h/H<0,05 h/H>0,05
hh
H H
TCV<V
H
h
Heat detector
V=6m² x (H-h)
Photo-electric
smoke detector
V=12m² x (H-h)
THH
V: Volume (m³)
H: Room height (m)
h: Cell height (m)
TCV: Total cell
volume (m³)
If the ceiling is composed of a group of cells, a point type detector within the limits of
radius in the Table A can enclose a group of cells. However, the total volume of cells
enclosed by a detector should not exceed the V value in �igure.

www.mavili.com.tr 13
Main stories of each stairs landing, 1detector should be placed.
Detector should be mounted inside area of circle, enclosing elevator doors, which has
1.5 m radius.
ELEVATORELEVATOR
1,5m

Supervisor; is a specially designed software which shows �ire and fault events and makes possible to monitor and
control the �ire alarm system as in architectural and graphical way.
IP cameras at the point where the �ire alarm is activated in case of �ire within the scenario can be automatically
turned on or manually controlled with IP camera systems working with ONVIF protocol via software integration.
◗ ◗
◗
◗
◗
◗
◗
◗
◗
1000 different intelligent addressable �ire
detection system can be monitored and
managed with single supervisor.
Projects on computer can be transferred to
system as maps (all picture formats).
Determined areas can be monitored graphical
and it provides to exchange between maps in
case of �ire and fault events.
Remote commands can be sent in situations
that require intervention.
Animations, device types and event voices can
be changed by users.
In case of �ire and fault events; e-mail and/or
sms report can be sent to the authorized people
at determined periods or instantly.
The communication between PC and �ire alarm
system can be done via RS-232 or RS-485 and
for longer distance GPRS or TCP-IP ports can be
used.
All events records can be monitored, �iltered,
printered, back-up with date/time information
by Supervisor.
10 different users can be de�ined.
Supervisor Graphic Monitoring and Control Software
Intagrated with environmental Systems and Managing

www.mavili.com.tr 15
Possibility to communicate with other
panels telephone modules ad �ire�ighter’s
telephone units. Also, conference call can
be done all telephones within network.
In case of any event, the event location map
is shown on screen and detailed alarm
information is provided to the user for exact
determination.
Arhitectural site plans of the building are
de�ined to the Supervisor graphic software
program as maps and all the �ire alarm
system devices are �igured on these maps.
Can be integrated to all kinds of CCTV systems, (all brands and models)
with remote monitoring software.
In determined areas present CCTV cameras can be monitored manually
or automatically through automation ability.
With ONVIF integration, �ire detection system can be software integrated
and operate with all ONVIF based security systems.

Maxlogic addresaable �ire detection system can work as network up to 64 panels.
Thus can be easily applied in big sites such as hospital,warehouse,university etc.
Max. 130.048 devices can be used in Maxlogic Addressable �ire detection system.
◗
◗
◗
ML-12516.NPTA
Fire alarm control panel
ML-1110.SCI
Photo-electric
smoke detector,
short circuit isolator
ML-1362.SCI
Switch monitor,
1 input,
short circuit isolator
ML-1730.SCI
Addressable
manual call point
weatherproof (IP67)
resettable,
short circuit isolator
ML-1170.SCI
Intelligent addressable
beam type smoke
detector (transmitter),
short circuit isolator
Beam Type Smoke
Detector Re�lector, 1
Beam Type Smoke
Detector Re�lector, 4
Fire automation inputs
Sprinkler system information
Pressure ventilation system ON/OFF information
Smoke damper ON/OFF information
Urgent security announcement system information
Emergency lighting system information
Gas-stop system
Earthquake early warning system
Alarm system
Extinguishing system
ML-1248.NP
Fire alarm control panel
GCU panel
ML-1632.X
Supervisor graphic monitoring and
control software intagrated with
environmental systems and managing
Modbus / Bacnet
Server
ML-1140.SCI
Multisensor detector,
short circuit isolator
ML-1280
7” TFT mimic panel
ML-12012.UART
Other system
SGC module,
UART output
Other System
ML-12012.C
Other system
SGC module,
TCP/IP output
ML-1102
Loop powered base
sounder beacon
ML-1140.SCI
Multisensor detector,
short circuit isolator
ML-1390
Short circuit
isolator module
1
64
RS-232 / RS-485
GPRS
BACNET
MODBUS
TCP-IP
3
TCP-IP
UART
24V
2
24V
ML-12516.NPTA
1
Fire alarm control panel
2
Other System
environmental systems and managing
RS-232 / RS-485
GPRS
TCP-IP
TCP-IP
UART
GCU panel
64
2x0.75 LIHCH FE
180 / PH 120
1x2x1,5+0,8 mm²
JH(st)H FE 180
www.mavili.com.tr 16

All events can be monitored from any panel in network.
All panels can be controlled from any panel in network.
Cause-effect scenarios can be created between devices that are located in network.
◗
◗
◗
ML-1361.SCI
Relay controller
module, 1 output,
short circuit isolator
ML-5020
Announce / Alarm matrix panel
ML-1170.SCI
Intelligent addressable
beam type smoke
detector (receiver),
short circuit isolator
ML-1173.SCI
Intelligent addressable re�lective
beam type smoke detector,
short circuit isolator
Fire automation outputs
Lifts
Pressure ventilation
Smoke dampers
Urgent security announcement
Urgent lighting system
Electrical panels
Solenoid valves
Air conditioning systems
Extinguishing System
ML-1372.SCI
Zone monitor,
1 input,
short circuit isolator
ML-2110
Conventional
photo-electric smoke detector
ML-2130
Conventional
rate of rise heat detector
ML-2140
Conventional
multisensor detector
ML-1430
Intelligent
addressable system
sounder & beacon
ML-1355
8 inputs / 8 outputs smoke
damper control panel
with toggle switch card ML-1130.SCI
Heat detector,
short circuit isolator
ML-1101
Loop powered base
sounder
Super�low air duct
sampling unit
AGD-1224M.VIP
Methane (natural gas)
detector
ML-1371.SCI
Sounder controller
module, 1 output,
short circuit isolator
MG-5400
Electronic alarm bell
ML-2430
Conventional
sounder & beacon
ML-05110
Switched mode
power supply (SMPS)
ML-2490
Conventional sounder & beacon,
weatherproof (IP65)
ML-1390
Short circuit
isolator module
ML-1490.SCI
Intelligent addressable
system sounder & beacon,
weatherproof (IP65),
short circuit isolator
24V
24V
24V
24V
MG-5400
Electronic alarm bell
Speaker
system
Announce
system
power supply (SMPS)
24V
24V
1x2x1,5+0,8 mm²
JH(st)H FE 180
1x2x1,5+0,8 mm²
JH(st)H FE 180
2x1,5 N2XH FE180
2x1,5 N2XH FE180
www.mavili.com.tr 17

www.mavili.com.tr 18
Detections, alarms and other signals can be used to trigger assistive devices as mentioned
below.
Fire alarm system or other assistive devices shouldn’t be hindered in case of any assistive
devices fails.
a) Fire Extinguishing Equipments,
b) Smoke or Fire doors,
c) Smoke Ventilation Equipments,
d) Smoke or Fire Dampers,
e) Closure of ventilation,
f) Lift Control,
g) Security Doors
Control and Monitoring devices should be possible to relate easily and without any
dif�iculties with location of detector or manual callpoint.
RS-232
RS-485
GPRS
TCP/IP
Intelligent Addressable System
16-way I/O Panel
(8 Input / 8 Output)
Graphical Monitoring and
Control Software
Mimic Panel
Intelligent Addressable System
Smoke Damper Control Panel
c/w 16-way I/O Module
(8 Input / 8 Output)
Intelligent Addressable System
Smoke Damper Control Panel
c/w 16-way I/O Module
(8 Input / 8 Output)
c/w Toggle Switch Card

www.mavili.com.tr 19
For the communication with supervisor, GCU panel uses RS-232, RS-485 for close access,
IP based communication like GPRS and TCP/IP communication modules for longer
distance.
With UART connection cable for short distance access, with TCP/IP via internet for long
distance TCP/IP can be connected to Supervisor.
Superviewer Android software enables monitoring and control of �ire alarm system
without the user's need to be at the computer.
Superviewer Android
. . .
. . .
1
1 n
n
1
.
n
Superviewer Graph
Supervisor
Graphical Monitoring and
Control Software

www.mavili.com.tr 20
In case of an emergency, lifting a handset of �ire�ighter’s telephone or inserting a portable
�ire�ighter’s telephone handset in the socket and without the need of dialing any number
automatically calls the security center by "hot line" feature.
Fire�ighter’s Telephones
Fire�ighter’s Telephone Control Unit
1 2 3
32
. . .
Detectors should be mounted two times far away from the light �itting height.
<200mm
100mm
Light Fitting
