Maxima 09368450 User manual

AUTOMATIC

SAUSAGE STUFFER

Model:

09368450

09368460

READ THIS USER MANUAL CAREFULLY BEFORE USING

USER MANUAL

TABLE OF CONTENTS

Introduction ............................................................................................................................................................................................ 3

Specifications.................................................................................................................................................................................3

Features ...........................................................................................................................................................................................4

Safety Guidelines ..........................................................................................................................................................................5

First Time Use................................................................................................................................................................................6

Installation.......................................................................................................................................................................................6

Operation.........................................................................................................................................................................................6

Cleaning and Maintenance.........................................................................................................................................................7

Guarantee........................................................................................................................................................................................8

Product: MAXIMA AUTOMATIC SAUSAGE STUFFER

Model Dimensions

(cm)

Weight

(kg)

Power

(kW)

Electrical

Input

Piston Speed

(mm/s) Capacity

09368450 W37 x D33 x

H64 28,00,06 230V / 50Hz

1Phase

Up: 710 Litres

09368460 W37 x D33 x

H77 29,8 0,06 230V / 50Hz

1Phase 15 Litres

SPECIFICATIONS

INTRODUCTION

Thank you for purchasing this product from Maxima. To ensure your own safety and to get the best out of

your purchase, please read the instructions carefully before attempting to install or use this product.

All Maxima products are manufactured with great care and are CE certified. As a result, our products meet

the legal requirements regarding health, safety and the environment, as set out by the European Commission.

In addition, all products are thoroughly tested prior to shipment to ensure product quality and safety.

Maxima is committed to offering the best products and service available. Customer satisfaction is our number

one priority. We hope you enjoy using this product and thank you for choosing Maxima as your preferred

supplier.

Down: 2 - 7

Up: 7

Down: 2 - 7

FEATURES

A Control panel

B Foot pedal 2 pin connection

C Emergency stop

D Removable bucket

E Triangular locking ring

SAFETY GUIDELINES

This machine may only be used for the purpose for which it was designed and intended. The manufacturer

and supplier are not liable for any damage caused by incorrect operation and improper use.

This is a commercial product and must only be used by trained professionals who have read and fully

understand this manual. It must not be used by children, or persons with reduced physical, sensory

or mental capabilities without supervision.

This device is intended for indoor use only.

Keep the appliance and electrical plug away from water and other liquids. If either is exposed to a liquid,

immediately disconnect the power supply and have the appliance checked by a certified technician.

Not following these instructions may result in electric shock, or even death.

Do not use the appliance after it has fallen or if is damaged in any way. Have it checked and repaired

by a certified technician.



Do not move the appliance while in operation and never move or carry the appliance by the power cord.

Do not open the casing or try to repair the appliance yourself, unless instructed to by a Maxima

technician. This may void the warranty, cause damage to the machine or result in a hazardous situation.

Do not insert objects in the casing or openings of the appliance.



Do not use any additional devices or accessories that are not supplied with the appliance or designed

to work with the appliance.

Never put your hands or other body parts near the moving parts of the appliance while operational

and always keep an eye on the appliance when in use.



Keep all packaging away from children and dispose of packaging in accordance with local and national

regulations.

Avoid overloading the appliance.

The electrical installation must comply with the relevant regulations.

Switch off the appliance before pulling the power plug out of the socket.

Always disconnect the power supply when the appliance is not in use. To remove the plug from the

socket, always pull the plug itself and not the cable.

Do not touch the power plug with damp or wet hands.



Keep the power cable away from the range of operation and do not cover the cable. Also make sure the

power cable does not come in contact with hot or sharp objects and keep it away from open flames.

Note that while the plug is in the electrical socket, the appliance is connected to the electric grid.

FIRST TIME USE

Unpack and examine your product immediately after receiving it. If there are any latent defects or

damage to the machine, contact your supplier immediately. Save all packaging materials in case the

machine needs to be returned or inspected by the carrier.

Remove any protective film from all surfaces (if applicable).

Read this instruction manual in its entirety before attempting to install and operate this appliance.

When in doubt, contact your supplier.



Before using the appliance for the first time, it is recommended to properly clean it (See chapter

“Cleaning and Maintenance”).

INSTALLATION

1 The appliance must be positioned on a flat and stable surface.

2 Choose a surface where the appliance is not exposed to direct sunlight or close to a direct source of

heat, such as a cooker, oven or radiator.

3 When positioning the appliance, maintain a distance of 10cm (4") between the appliance and walls,

or other objects, for ease of use.

4 Position the appliance in such a way that the plug is accessible at all times.

5 Plug the power cord into a grounded and compatible socket.

OPERATION

1 Press the “up” button followed by the “start” button. The appliance will now lift the pressure plate to

the highest point and stop automatically.

Connect the pedal into the 2 pin connector located below the control panel.

2 Once the pressure plate has been lifted entirely and the appliance is no longer in use, tilt the bucket

to the right of the appliance and lift it out of place to remove it from the casing.

3 Fill the bucket with diced or minced meat. Place the bucket back into its original location and lock

in place.

Always secure the bucket back into place and align the pressure plate to avoid serious damage to

the machine or yourself.

Tighten the exhaust pin before using the appliance. This will maintain the air pressure in the bucket.

4 Remove the triangular locking ring from the front of the appliance.

5 Slide the desired filling nozzle inside the ring and secure it by screwing it onto the appliance.

Press the down arrow and use the “+” and “-” icons to adjust the decending speed of the pressure plate.

7 Using the foot pedal, drop the pressure plate until the meat reaches the end of the nozzle.

Do not touch the moving parts while the appliance is in use as this may cause serious injuries.

8 Once the appliance is ready, hold the sausage casing on the nozzle and use the foot pedal to push

the filling out of the nozzle.

Use the emergency stop button in case the appliance is not responding and in motion.

9 When finished, follow the cleaning instructions. This machine requires cleaning after every use.

CLEANING AND MAINTENANCE

Regularly check and clean the appliance, parts and accessories.

Unscrew the exhaust pin on the pressure plate to release the pressure in the appliance.

Press the “up” button and then the “start” button, the appliance will now lift the pressure plate to the

highest point and stop automatically.

Always switch off and disconnect the power- and/or gas supply before cleaning or maintenance.

Once the pressure plate has been lifted entirely and the appliance is no longer in use, tilt the bucket

to the right of the appliance and lift it out of place to remove it from the casing.

Clean the pressure plate, bucket and nozzle thoroughly with warm water and a food safe detergent.

Never use aggressive cleaning agents or abrasives. Do not use solvents or petrol-based cleaning

agents. Some cleaning agents may leave harmful residue or cause damage to the machine. Use a

food-safe cleaning product instead.

Do not use a scourer or any sharp objects during cleaning as this may cause damage to the machine.

Never hose down the machine or immerse it in water or any other liquid. Do not use a steamer to

clean the machine.

Never let the power cable or power plug get wet.

 Clean the exhaust valve in the pressure plate. If clogged, this may cause problems during use.

Once the parts and accessories are dry, reassemble them for the next use.

GUARANTEE

We offer a 12 month warranty from the date of purchase, as indicated on your purchase invoice.

Under the warranty, we will deliver additional spare parts in case of: material defects, manufacturing defects

or other quality issues. This only relates to the correct use of the product and for original parts only.

The following is not covered by the warranty:

1 Damage due to transportation or incorrect installation and connection.

2 Component damage caused by incorrect electrical or water connection.

3 Damage as a result of disassembly and/or modification to the original machine without permission.

4 Damage as a result of misuse, poor cleaning or improper maintenance.

Damage as a result of fire, building collapse, lightning, flooding, power surges, vermin or other events.

6 Failure to read or follow the user manual.

7 Consumables and parts prone to wear and tear.

8 An altered invoice or no invoice.

For the purpose of product development and improvement, we reserve the right to; change the product, packaging, or documentation without prior notice.
