Maxum 2500SCR User manual

Engine Serial Number: _____________________________________________
Hull Identification Number:__________________________________________
Hull Identification Number
The Hull Identification Number (HIN) is located on the starboard side of the transom. Be sure to record the HIN (and
the engine serial numbers) in the space provided above. Please refer to the HIN for any correspondence or orders.
© 2002 Maxum Marine Technical Publications. All rights reserved.
No part of this publication may be reproduced, stored in any retrieval system, or transmitted in any form by any means, electronic, mechanical, photocopying,
recording or otherwise, without prior written permission of Maxum. Printed in the U.S.A.
General Notes
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Maxum assumes no liability resulting from errors or omissions in this document, or from the useof information contained herein.
Due to our commitment to product improvement, Maxum reserves the right to make changes in the product design, specifications and equipment at any time with-
out notice or obligation. Illustrations and/or photos may show optional equipment. All Maxum products meet or exceed USCG (Unites States Coast Guard) and/or
NMMA (National Marine Manufacturer’s Association) construction standards. Manufactured with 1,1,1 Trichloroethane, a substance which harms public health
and environment during the manufacturing process by destroying ozone in the upper atmosphere.
Proprietary Rights
This document discloses subject matter in which Maxum has proprietary rights. The information and design disclosed herein were originated by and are the prop-
erty of Maxum. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any
information contained therein, or to construct boats or any item from it, except by written permission from or written agreementwith Maxum. This document is to
be returned upon request to Maxum.
2500 SCR
HIN LOCATION

CONTENTS
Chapter 1: Welcome Aboard!
1 Dimensions and Tank Capacities
1 Layout View
1 Dealer Service
1 About Your Limited Warranty
2 Boating Experience
2 Safety Standards
2 Engine & Accessories Guidelines
3 Qualified Maintenance
3 Structural Limitations
3 Special Care For Moored Boats
3 Sacrificial Anodes (Zincs)
4 Carbon Monoxide (CO)
5 Sources of CO
5 Carbon Monoxide Alarm System
5 What To Do If Carbon Monoxide Is Detected
Chapter 2: Locations
6 Exterior Views
6HullViews
7 Forward Deck Views
8 Aft Deck Views
9Helm
10 Component Locations
Chapter 3: Propulsion & Related Systems
11 Engine
11 Engine Room Ventilation System
12 Fire Suppression System (If Equipped)
13 Fuel System
13 Fuel Fill and Vent
14 Fuel Filters
14 Anti-siphon Valve
15 Quick Oil Drain System
Chapter 4: Controls
16 Steering
16 Shift/Throttle
16 Power Trim and Tilt
17 Trim Tabs
Chapter 5: Navigation &
Communication Equipment
18 VHF Radio
18 Compass
18 Depth Finder
18 Global Positioning System (GPS)
(If Equipped)

Chapter 6: Plumbing
19 Bilge Pumps
21 Autofloat Switches
22 Seawater Systems
22 Seacocks
22 Seawater Strainers
23 Freshwater System
24 Winterizing the Freshwater System
25 Transom Shower
25 Water Heater
25 City Water Inlet
26 Drain Systems
26 Deck Drains
26 Sink Drains
26 Shower Drain
26 Sump Box Cleaning
26 Sump System Winterization
27 Gray Water Recovery System (If Equipped)
28 Marine Head with Holding Tank
29 Macerator (If Equipped)
30 VacuFlush (If Equipped)
Chapter 7: Deck Equipment
31 Windlass (If Equipped)
32 Canvas
33 Bimini Top
33 Camper Canvas
33 Windshield Curtain
33 Side Curtains
33 Windshield Wiper
33 Cleats and Tow Eyes
Chapter 8: Appliances &
Entertainment Systems
34 Refrigerator
34 Electric Stove (If Equipped)
35 Alcohol/Electric Stove (If Equipped)
35 Audio & Visual Equipment
Chapter 9: Convertible Seats,
Beds, & Tables
36 Dinette/Mid Berth
Chapter 10: Lights
37 Care and Maintenance
37 Navigation Lights
37 Interior & Exterior Lights
37 Spotlight (If Equipped)
Chapter 11: Heating & Air Conditioning
38 Air Conditioning System (If Equipped)
Chapter 12: Electrical System
40 12-Volt DC System
40 Batteries
40 Fuses and Circuit Breakers
40 Battery Switch
40 Battery Switch Positions
41 Alternator
41 Battery Charger
41 12-Volt Accessory Outlet
41 Fuses and Circuit Breakers
42 120-Volt AC System
43 Shore Power
45 Connecting To Shore Power
46 Transfer Switch (If Equipped
With Dual Shore Power)
47 Electrical Routings
47 Deck Electrical Harness
48 Hull Electrical Harness
48 120-Volt AC System
49 Battery System
49 Bonding Harness
50 Wire Diagrams
50 120-Volt AC Electrical System
51 12-Volt DC Electrical System
52 Engine Electrical System
53 Fire Suppression System, Five
Circuit Shutdown (If Equipped)

Hazard Boxes & Symbols
The hazard boxes and symbols shown below are used throughout this supplement to call attention to potentially dan-
gerous situations which could lead to either personal injury or product damage. Read ALL warnings carefully and
follow all safety instructions.
DANGER!
!
This box alerts you to immediate hazards which WILL cause severe personal injury or death if
the warning is ignored.
This box alerts you to hazards or unsafe practices which COULD result in severe personal
injury or death if the warning is ignored.
WARNING!
!
This box alerts you to hazards or unsafe practices which COULD result in minor personal
injury or cause product or property damage if the warning is ignored.
CAUTION!
!
NOTICE
This box calls attention to installation, operation or maintenance information, which is impor-
tant to proper operation but is not hazard related.
EXPLOSION
HAZARD!
NO OPEN
FLAME!
HOT
HAZARD!
ROTATING
PROPELLER HAZARD!
FALLING
HAZARD!
ELECTRICAL
HAZARD!
CO POISONING
HAZARD!
FIRE
HAZARD!
RUN BILGE BLOWERS
FOR 4 MINUTES!

1
Chapter 1: Welcome Aboard!
This Owner’s Manual Supplement provides specific information about your boat that is not covered in theCruiser &
Yacht Owner’s Manual. Please study the Cruiser & Yacht Owner’s Manual and this supplement carefully. Keep the
Cruiser & Yacht Owner’s Manual and this supplement on your boat in a secure, yet readily available place.
Dimensions andTank Capacities
Layout View
Dealer Service
•Ask your dealer to explain all systems before taking delivery of your boat.
•Your dealer is your key to service.
•Contact your dealer if you have any problems with your new boat.
•If your dealer cannot help, call our customer service hotline: [phone] or send usa FAX: [phone].
•Buy replacement parts from any authorized Maxum dealer.
About Your Limited Warranty
•Maxum offers a Limited Warranty on each new Maxum purchased through an authorized Maxum dealer.
•A copy of the LimitedWarranty was included in your owner’s packet.
•If you did not receive a copy of the Limited Warranty, please contact your dealer or call 507-825-2155 for a copy.
Overall
Length Bridge Clearance Beam Draft (Drive Up) Draft(Drive Down) Fuel Capacity (gal.) Freshwater Capacity (gal.) Waste Holding Tank Capacity (gal.)
25' 6" 6' 4" 8' 6" 1' 9" 3' 0" 74 20 20
V-BERTH
HEAD
SINK
STOVE
HELM SEAT
TRANSOM DOOR
TRANSOM SEAT
LOUNGE SEAT
STEP

2 CHAPTER 1: WELCOME ABOARD!
Boating Experience
If this is your first boat or if you are changing to a type of boat you are not familiar with, for your own comfort and
safety, obtain handling and operating experience before assuming command of the boat.
Take one of the boating safety classes offered by the U.S. Power Squadrons or the U.S. Coast Guard Auxiliary. For
more course information, including dates and locations of upcoming classes, contact the organizations directly:
•U.S. Power Squadrons: 1-888-FOR-USPS (1-888-367-8777) or on the Internet at: http://www.usps.org
•U.S. Coast Guard Auxiliary: 1-800-368-5647 or on the Internet at: http://www.cgaux.org
Outside the United States, your selling dealer, national sailing federation or local boat club can advise you of local
sea schools or competent instructors.
Safety Standards
Your boat’s mechanical and electrical systems were designed to meet safety standards in effect at the time it was
built. Some of these standards were mandated by law, all of them were designed to insure your safety, and the safety
of other people, vessels and property.
In addition to this owner’s manual supplement, please read the Cruiser & Yacht Owner’s Manual and all acces-
sory instructions for important safety standards and hazard information.
Engine & Accessories Guidelines
Your boat’s engine and accessories were selected to provide optimum performance and service. Installing a different
engine or other accessories may cause unwanted handling characteristics. Should you choose to install a different
engine or to add accessories that will affect the boat’s running trim, have an experienced marine technician perform a
safety inspection and handling test before operating your boat again.
Certain modifications to your boat can result in cancellation of your warranty protection. Always check with
your dealer before making any modifications to your boat.
The engine and accessories installed on your boat come with their own operation and maintenance manuals. Read
and understand these manuals before using the engine and accessories.
CONTROL HAZARD! A qualified operator must be in control of the boat at all times. DO NOT
operate your boat while under the influence of alcohol or drugs.
WARNING!
!
DANGER
PERSONAL SAFETY HAZARD! DO NOT allow anyone to ride on parts of the
boat not designated for such use. Sitting on seat backs, lounging on the forward
deck, bow riding, gunwale riding or occupying the transom platform while
underway is especially hazardous and will cause personal injury or death.
DANGER!
!
DANGER
PERSONAL SAFETY HAZARD! ALWAYS secure the anchor and other loose objects before get-
ting underway. The anchor and other items that are not properly secured can come loose when
the boat is moving and cause personal injury or death.
DANGER!
!
NOTICE
When storing your boat please refer to your engine’s operation and maintenance manuals.

CHAPTER 1: WELCOME ABOARD! 3
Qualified Maintenance
Failure to maintain your boat’s systems (listed in the warning above) as designed could violate the laws in your juris-
diction and could expose you and other people to the danger of bodily injury or accidental death. Follow the instruc-
tions provided in the Cruiser & Yacht Owner’s Manual, this Owner’s Manual Supplement, the engine owner’s manual
and all accessory instruction sheets and manuals included in your owner’s packet.
Structural Limitations
The transom platform and bow platform are designed to be lightweight for proper boat balance. The load limit for
these platforms is 30 pounds per square foot, evenly distributed.
Special Care For Moored Boats
Whether moored in saltwater or freshwater, your boat will collect marine growth on its hull bottom. This will detract
from the boat’s beauty, greatly affect its performance and may damage the gelcoat. There are two methods of slowing
marine growth:
•Periodically haul the boat out of the water and scrub the hull bottom with a bristle brush and a solution of soap
and water.
•The hull below the waterline may have anti-fouling paint applied by the factory. Occasionally you will need to re-
paint it with a good grade of anti-fouling paint.
Sacrificial Anodes (Zincs)
Your boat is equipped with sacrificial anodes (zincs) to protect underwater metal parts from excessive deterioration.
Check the zincs regularly and replace them if they have deteriorated more than 70%.
There are many factors that affect the rate at which the zincs deteriorate, including:
•Water temperature
•Salinity
•Water pollution
Stray electrical current from the boat or dock may cause complete deterioration in just a few weeks. If there is rapid
zinc deterioration, measure the electrolytic corrosion around your boat with a Corrosion Test Meter. If the zincs are
not bonded correctly, they will not provide protection.
To maintain the integrity and safety of your boat, allow only qualified personnel to perform
maintenance on, or in any way modify: The steering system, propulsion system, engine control
system, fuel system, environmental control system, electrical system or navigational system.
WARNING!
!
NOTICE
•To help seal the hull bottom and reduce the possibility of gelcoat blistering on moored boats,
apply an epoxy barrier coating, such as INTERLUX, Interprotect 2000E/2001E. The barrier
coating should be covered with several coats of anti-fouling paint.
•Many states regulate the chemical content of bottom paints in order to meet environmental
standards. Check with your local dealer about recommended bottom paints, and about the
laws in effect in your area.
Do not paint between the zinc and the metal surface it contacts and do not paint over the zincs.
NOTICE

4 CHAPTER 1: WELCOME ABOARD!
Carbon Monoxide (CO)
•CO poisoning causes a significant number of boating deaths each year.
•Called the "silent killer", CO is an extremely toxic, colorless, odorless and tasteless gas.
•Breathing CO blocks the ability of your blood to carry oxygen.
•The effects are cumulative, even low levels of exposure can result in injury or death.
Factors increasing the effects of CO poisoning include:
•Age
•Smokers or people exposed to high concentrations of cigarette smoke
•Consumption of alcohol
•Lung disorders
•Heart problems
•Pregnancy
DANGER
CARBONMONOXIDEPOISONING HAZARD!
Carbon monoxide gas (CO) is colorless, odorless, and extremely dangerous. All
engines, and fuel burning appliances produce CO as exhaust. Direct and prolonged
exposure to CO will cause BRAIN DAMAGE or DEATH.
Signs of CO poisoning include:
•Headache
•Nausea
•Dizziness
•Drowsiness
DANGER!
!

CHAPTER 1: WELCOME ABOARD! 5
Sources of CO
Sources of CO include:
To correct stationary situations (a) and/or (b):
•Close all of the windows, portlights and hatches.
•If possible, move your boat away from the source of the CO.
To correct running situations (c) and/or (d):
•Trim the bow down.
•Open the windows and canvas.
•When possible, run the boat so that the prevailing winds will help dissipate the engine exhaust.
Immediately take corrective action if CO is detected or suspected (see, Carbon Monoxide Alarm System, below).
Carbon Monoxide Alarm System
•Your boat features a carbon monoxide (CO) alarm system.
•Do not disconnect the alarm system.
•Read and understand the manufacturer’s instructions for your CO alarm system. If you did not receive an instruc-
tion manual, call [phone] and one will be mailed to you.
•If your boat is not equipped with a carbon monoxide alarm, consider purchasing one from your dealer or marine
supply store.
What To Do If Carbon Monoxide Is Detected
•Immediately ventilate and evacuate any enclosed spaces that are occupied by people and reset your CO alarm.
•Immediately move anyone showing any symptoms of CO poisoning into fresh air.
•See a doctor if any symptoms persist. If the person is unconscious, immediately administer oxygen or CPR and
call for emergency help.
c. Running boat with
trim angle of bow
too high.
a. Using engine or generator
when boat is moored in a
confined space.
b. Mooring close to
another boat that
is using its engine,
generator or any
other CO source.
d. Running boat with-
out through ventila-
tion (station wagon
effect).

6
Chapter 2: Locations
Exterior Views
Hull Views
STERN EYES
BOARDING
LADDER
TRIM TAB
MACERATOR DISCHARGE
(IF EQUIPPED)
BILGE DRAIN
PLUG
TRANSOM VIEW
PORT HULL SIDE VIEW
BOW EYE
GALLEY SINK DRAIN
PORTLIGHT
DECK
DRAIN
WATER HEATER
OVERFLOW
WATER TANK
VENT
GRAY WATER
VENT (IF EQUIPPED)
BOW EYE
ANCHOR
LOCKER
DRAIN
PORTLIGHTS
HEAD SINK
MID BILGE DRAIN DRAIN
SUMP BOX DRAIN
ENTRY SLIDER
DRAIN
DECK
DRAIN
AFT BILGE
DRAIN
HOLDING TANK VENT
PORTLIGHT
AIR CONDITIONER
STARBOARD HULLSIDE VIEW
DRAINS (IF EQUIPPED)
FUEL TANK VENT
TRIM TAB

CHAPTER 2: LOCATIONS 7
Forward Deck Views
CLEATS
NAVIGATION
LIGHT
ANCHOR ROLLER
WINDLASS
(IF EQUIPPED)
CLEAT
HIDDEN HORN
NAVIGATION LIGHT
BOW RAIL
SPOTLIGHT
(IF EQUIPPED)
ANCHOR LOCKER
DECK HATCH

8 CHAPTER 2: LOCATIONS
Aft Deck Views


CLEAT
FUEL FILL FITTING
WASTE PUMP-OUT FITTING
SWIM STEP
GRAB RAIL
SHORE POWER
INLET(S)
WATER FILL FITTING AFT GRAB RAIL
CIRCUIT
BREAKERS

CHAPTER 2: LOCATIONS 9
Helm
TYPICAL HELM LAYOUT SHOWN
ACTUAL LAYOUT MAY VARY DEPENDING
ON ENGINE AND ACCESSORY OPTIONS
NOTE:
TEMPERATURE
GAUGE
OIL
GAUGE
SWITCH
PANEL
CIRCUIT
BREAKER
PANEL
ACCESSORY
SWITCHES
VHF
12-VOLT
ADAPTER
TRIM TAB
SWITCHES
IGNITION
SWITCH
BILGE BLOWER
SWITCH
FUEL
VOLT
TACHOMETER
TRIM
GAUGE
COMPASS
DEPTH SOUNDER
(IF EQUIPPED)
SPEEDOMETER
GAUGE
GAUGE
RADIO

10 CHAPTER 2: LOCATIONS
Component Locations
12-Volt Accessory Outlet: At the helm, on the dash panel.
Air Conditioner Seawater Intake Seacock: In the engine compartment.
Air Conditioner Unit: Access is through the storage compartment under the helm seat.
Batteries: On the starboard side of the engine compartment.
Battery Charger: In the engine compartment, above the fuel tank.
Battery Switch: In the storage compartment under the entertainment center sink.
Bilge pump - Aft: In the engine compartment.
Bilge pump - Forward: Access is through the floor hatch under the entry steps.
Carbon Monoxide Detector: In the aft berth, on the ceiling.
DC Circuit Breakers: At the helm, under the dash panel.
Depth Sounder Transducer: In the engine compartment.
Engine Circuit Breaker: On the engine.
Fuel Fill: On the starboard aft corner of the deck.
Fuel Tank: In the engine compartment, forward of the engine.
Macerator Underwater Discharge Seacock: In the engine compartment.
Marine Head (Electric) Seawater Intake Seacock: Access is through the aft floor hatch in the V-berth.
Navigation Lights: Red and green lights at the bow.
Waste Holding Tank: In the engine compartment, on the starboard side.
Water Fill: On the port aft corner of the deck.
Water Heater: In the engine compartment, on the port side.
Water Pump: In the engine compartment, on the starboard side.
Water Pump Switch: In the galley, below the sink.
Water Tank: In the engine compartment, on the port side.

11
Chapter 3: Propulsion & Related Systems
Engine
The owner’s packet contains detailed engine operation and maintenance manuals. Be sure to read and understand
these manuals before starting or doing any maintenance on the engine.
Engine Room Ventilation System
•The bilge blower removes
explosive fuel fumes from the
engine compartment.
•Fresh air is drawn into the compart-
ment through the deck vents.
•The blower switch is at the helm.
To make sure the engine compartment
is ventilated with fresh air, run the
bilge blower:
•For at least four minutes before
starting the engine.
•During starting.
•Anytime your boat is running
below cruising speed.
FIRE/EXPLOSION HAZARD
•Use of the blower system is NOT A GUARANTEE that explosive fumes have been removed.
•If you smell fuel, DO NOT start the engine and DO NOT turn on any electrical devices.
•If you smell fuel and the engine is already running, SHUT OFF the engine and TURN OFF
all electrical devices. Investigate immediately.
•DO NOT obstruct or modify the ventilation system.
WARNING!
!
BILGE BLOWER SYSTEM
BILGE BLOWER
VENTILATION
HOSES

12 CHAPTER 3: PROPULSION & RELATED SYSTEMS
Fire Suppression System (If Equipped)
The fire suppression system is designed to extinguish a fire in the engine compartment.
Before using your boat for the first time, read and understand the fire suppression system’s instruction and mainte-
nance manual and follow all warnings.
Observe the following:
•The system will go off automatically whenever direct heat from a fire is detected in the engine compartment.
•The system can be set off manually by pulling the T-handle (labeled “FIRE”) at the helm.
•The system can only be set off once during a fire. After the system is discharged it must be refilled and refurbished
before it can be used again.
FIXED FIRE
EXTINGUISHER
TO MANUAL
DISCHARGE
T-HANDLE
INDICATOR LIGHT FOR
FIRE SUPPRESSION SYSTEM
MANUAL DISCHARGE
T-HANDLE

CHAPTER 3: PROPULSION & RELATED SYSTEMS 13
Fuel System
Fuel Fill and Vent
•The fuel fill fitting is marked “GAS”.
•The fuel tank vent is located below the fuel fill.
•If you experience difficulty filling the fuel tank, check to see that the fuel fill hose and vent hose are free of
obstructions and kinks.
FIRE, EXPLOSION AND OPEN FLAME HAZARD!
•It is very important that the fuel system be inspected thoroughly the first time it is filled and
at each subsequent filling.
•The fueling instructions in the Cruiser & Yacht Owner’s Manual and the fuel recommenda-
tions in the engine operation manual must be followed.
WARNING!
!
CAUTION
Avoid the storage or handling of gear near the fuel lines, fittings and tank.
!
FUEL SYSTEM ROUTING
FUEL FEED
HOSE
FUEL TANK
VENT
FUEL TANK
FUEL FILL

14 CHAPTER 3: PROPULSION & RELATED SYSTEMS
Fuel Filters
•The fuel pickup tube (located inside the fuel tank) is equipped with a fine mesh screen filter.
•In addition, when supplied by the engine manufacturer, a fuel filter is installed on the engine.
•Periodically replace the fuel filters to make sure they remain clean and free of debris.
•Consult with your selling dealer or local marina concerning fuel additives that help to prevent fungus or other
buildup in your fuel tank.
Anti-siphon Valve
•The fuel system is equipped with an anti-siphon valve.
•The valve is located at the point where the fuel feed line attaches to the fuel tank.
•The valve is spring loaded and is opened by fuel pump vacuum.
•This valve will prevent fuel from siphoning from the tank in the event of a fuel line rupture.
NOTICE
•If an engine running problem is diagnosed as fuel starvation, check the anti-siphon valve. If
the valve is stuck or clogged, change or replace it while the engine is shut down.
•NEVER run the engine with the anti-siphon valve removed, except in an emergency.
