Mayline CSII P Table User manual

COMPONENTS:
REF. # QTY. DESCRIPTION PART No.
1 1 WORK SURFACE CALL~~**
2 1 MODESTY PANEL B7485**
3 1 LEG C733**
4 1 LEG (extra mounting holes) C734**
5 1 POST LEG B5185**
6 1 JOINING PLATE B7522
7 1 MODESTY PANEL B7892**
HARDWARE BAG (PART No. A7807) *for individual part, order that part number
REF. # QTY DESCRIPTION PART No.
E1 25 #10 X 3/4 SCREW X11*
E2 8 #10-24- X 3/8 SCREW X147*
E3 8 #10-24 KEPS NUT T2*
E4 4 GLIDE Q630*
E5 2 CABLE CLAMP F191*
E6 2 SCREW, #6 X 3/8 PPHTS X5126*
ASSEMBLY INSTRUCTIONS
CS II "P" Table and "P" Table w/ Conference End
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
** Denotes Color Code
~~Denotes Size
CATALOG No:
C383R02 CATALOG No: C383L01
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
R.H. SHOWN L.H. SHOWN
(1)

"P" Desk Assembly:
NOTE: Shape and size may vary but assembly
procedure remains the same. Legs are
universal and may be placed on Right or Left
side.
"P" Table and "P" Table with Conference
End Assembly:
NOTE: Shape and size may vary but
assembly procedure remains the same.
1. Place the Work Surface (1) face down
onto a clean, protected surface.
2. Place Leg (3) along the 'LONG' edge
of the Work Surface. Place Leg (4) along
the 'SHORT' edge of the Work Surface,
extra holes toward outside. Position
Legs (3 & 4) approximately 3/16 from
their respective edges and align the
holes in the Leg with the pre-drilled holes
in the Work Surface. Attach each Leg
to Work Surface with six Screws (E1).
DO NOT tighten screws at this time.
3. Position the Modesty Panel (2)
between the Legs (3). Align the holes in
the Panel with the pre-drilled holes in the
Work Surface. Secure Panel with
Screws (E1). DO NOT tighten screws at
this time.
4. Attach the Modesty Panel (2) to each
Leg (3) with three Screws (E2) and three
KEPS Nuts (E3) at each end.
5. Tighten all screws at this time.
6. Install two Glides (E4) into each Leg.
7. Align the holes in the Post Leg (5)
mounting plate with the pre-drilled holes
in the Work Surface. Secure the
mounting plate with four Screws (E1).
Thread the Post Leg onto the mounting
plate stud.
SHORT SIDE OF
WORK SURFACE
LONG SIDE OF
WORK SURFACE
EXTRA HOLES
TO THIS SIDE
(2)

8. Attach short end of Modesty Panel (7) to small flange on Modesty Panel (2) using
Screws (E2) and Nuts (E3). Use Screws (E1) to secure Modesty Panel to the
Worksurface (1). Fasten Modesty Panel (7) to Peninsula Leg using self drilling Screws
(E6).
(3)

8. Place the assembled desk in the upright position. MAYLINE
recommends that a minimum of two people perform this task.
9. Place the desk at the location where it will be used. MAYLINE
recommends that a minimum of two people perform this task.
10. Level the assembly by adjusting the Leg glides and the Post Leg glide.
11. Two Cable Clamps (E5) are included to position cables away from
work area. Attach the clamps to the Work Surface with one Screw (E1) per
clamp.
12. OPTIONAL: Secure the "J" Table to the adjacent table using eight
Screws (E1) through the Joining Plate (6) into the pre-drilled holes in the
underside of the Work Surfaces.
(4)
