MBM BOOKLETMAKER Jr. User manual

Operation Manual
Kee
p
this manual sot that it can be retrieved whenever neede
d
BOOKLETMAKER Jr.
FOR
1-800-223-2508
www.mbmcorp.com

C
A
U
TION
When the machine is running, never put you
r
hands near or under the rollers.
Do not remove the bottom lid, front and rear
covers from the machine. The inside of the
machine contains high voltage parts or
hazardous moving parts, which may cause
electric shock or personal injury.
A
socket-outlet shall be installed near the
equipment and shall be easil
y
accessible.

Warning
Warning:
hazardous moving parts keep hands
and other body parts away.
Warn:
The surface of the motor is hot.
Be careful, Don t touch
,
Caution
Caution:
For continued protection
against risk of fire, replace only with
the same type and rating of fuse.

No. Description Qty
11
22
1
1
1
1
1
Warning Label 1
Cover Label
3Label
4Model Label
5Fuse Label
6 Caution Label
7 Warning Label 2
8Warning Label 3 1
Brand

Main Operating Parts
(1) Safety Cover
(2) Back Cover
(3) Stapling Handle
(
4) Side Guide (B)
(5) Sub Holding Shaft
(7) Stapling Head
(8) Paper Guide
(9) Table
(10) Side Guide (A)
(11) Front Cover
(12) On
/
Off Switch
(13) Rubber Feet
12
345
6789 10
111213

Wa rning ha za rd o us m o ving p a rts ke e p
handsand other body partsaway
Do not remove the cover
Doing so may result in personal in
j
ury
3
4
2
1
MODEL
BOOKLETMAKERJr.
N. Charleston, SC29418
800-223-2508

C
A
UTION:
Warn:
The surface of the motor is hot.
Be careful, Don t touch
,
Warn:
The surface of the motor is hot.
Be careful, Don t touch
,
7
8
5
6

Operation Procedures
1. Before Operating
1.1 Fit stapling handle: First insert the end of the stapling
handle at the main holding shaft then
press in the sub-holding shaft.
1.2 Load Staples
1.3 Connect the power cable
2.1 Switch on the machine
2.2 Choose the correct staple position according to the sheet size.
2.3
2.4 Set the paper guides to hold the sheets in position.
2.5 Press down the stapling handle to complete the stapling.
2.6 Lift up the stapling handle and firmly press down to the other side
and hold. The stapled sheets will be fed up through the fold rollers
to complete the booklet.
2.7 Repeat steps 2.3-2.6 for further booklets.
2.8 Switch off the machines after finishing.
Set the paper guides; place the sheets under the rollers and align
the sheets to side guide (A).

3. Side Stapling
3.1 Choose and fix the staple position according to the sheet size.
3.2 Place the sheets under the rollers.
3.3 Depending on the stapling position, align the sheets to side
guide (A)or side guide (B)
3.4 Set the side distance and hold the sheets.
3.5 Press down the stapling handle for stapling.
3.6 Repeat steps 3.2-3.5 for further side stapling.
4. Repair & Maintenance
4.1 Always clean up machine after used.

Specifications
Min.197mmx273mm (7.8 x 10.8 )
Max. 297mmx420mm ( 11.7 x 16.5 )
10 sheets of 70gsm paper*
10 sheets of 70gsm paper
[40 pages booklet]
*
A
C110V0.8
A
60Hz
40W
500mmx235mmx395mm
Weight
*
T
his may vary depending upon paper quality
Paper size
Max. Stapling
A
mount
Max. Folding
A
mount (20 lbs. paper)
( lbs. paper)
Power source
Watt
(19.7 x 9.3 x 15.6 )
Dimensions
15Kg
( 33lbs.)
20
Bond
Bond
