MCCOY FARR KT14-50K User manual

TECHNICAL MANUAL
©2011 McCoy Corporation. All rights reserved.
Published by McCoy Corporation, Technical Publications Department
14755 - 121A Avenue • Edmonton, AB, Canada, T5L 2T2 mccoyglobal.com
KT14 -50K
14” (35.6 cm) 50K Lbs.-Ft.
Hydraulic Power Tong
• Specications
• Operation
• Maintenance
• Assembly

KT14”-50K Tong
Section contentS iii
technical Manual
This manual covers the following models:
tonG MoDel ReV DeScRiPtion
80-1001 4Tong with Rineer GA37/26 motor & motor valve.
80-1001-1 3Tong with Rineer GA37/26 motor, motor valve, lift cylinder valve, & safety door
80-1001-2 3Tong with Rineer GA37/26 motor, motor valve, lift cylinder valve, safety door &
optional dump valve.
80-1001-3 3Tong with Rineer GA37/26 motor, motor valve, & lift cylinder valve.
80-1001-6 1Tong with Rineer GA37/26 motor, motor valve, lift cylinder valve, & safety door.
CLOSED CENTRE.
NOTE: Some illustrations used in this manual may not exactly match
your equipment.
PATENTED & PATENTS PENDING

This page intentionally
left blank

KT14”-50K Tong
Section contentS v
technical Manual
WARNINGS
ANY REPLACEMENT FASTENER (BOLTS, NUTS, CAP SCREWS, MACHINE SCREWS, ETC.)
USED DURING MAINTENANCE OR OVERHAUL MUST BE GRADE 8 OR EQUIVALENT UNLESS
OTHERWISE SPECIFIED.
WHEN RE-ASSEMBLING LOAD-BEARING DEVICES (CHAIN SLINGS, RIGID SLINGS, BACKUP
LEGS, ETC.) NOTE THAT THE ASSOCIATED FASTENERS MUST BE TIGHTENED TO THE
CORRECT TORQUE SPECIFIED FOR THAT SIZE OF FASTENER (SEE SECTION 3 - OVER-
HAUL). ANY THREADED FASTENER IN A LOAD-BEARING DEVICE MUST BE SECURED WITH
RED OR BLUE LOCTITE™.
A “LOAD-BEARING DEVICE” IS A CHAIN SLING, RIGID SLING, SPREADER BAR ASSEMBLY,
FRAME, OR ANY OTHER DEVICE THAT BEARS THE PARTIAL OR TOTAL WEIGHT OF THE
EQUIPMENT FOR WHICH THIS MANUAL HAS BEEN PRODUCED
THE LOAD-BEARING DEVICE SUPPLIED BY MCCOY DRILLING & COMPLETIONS IS DESIGNED
TO SUPPORT THE EQUIPMENT DESCRIBED IN THIS MANUAL. MCCOY DRILLING & COMPLE-
TIONS WILL NOT GUARANTEE THE ABILITY OF THE LOAD-BEARING DEVICE TO SUPPORT
ANY OTHER PART, ASSEMBLY OR COMBINATION OF PARTS AND ASSEMBLIES. MCCOY
DRILLING & COMPLETIONS WILL NOT GUARANTEE THE ABILITY OF THE LOAD-BEARING
DEVICE TO LIFT OR SUPPORT THE EQUIPMENT DESCRIBED IN THIS MANUAL IF THERE ARE
ANY MODIFICATIONS TO THE LOAD-BEARING DEVICE, OR ANY ADDITIONS TO THE EQUIP-
MENT DESCRIBED IN THIS MANUAL THAT ADD WEIGHT TO THE EQUIPMENT, UNLESS SUP-
PLIED BY MCCOY DRILLING & COMPLETIONS.

This page intentionally
left blank

KT14”-50K Tong
Section contentS vii
technical Manual
Summary Of Revisions
Date Section Page Description Of Revision
JULY 2008 N/A N/A Intial Release
DEC 2008 7.0 7.47 Added part numbers for items “L” & “M”
AUG 2009
Intro iii Added information for model 80-1001-6 (closed centre)
2.0 All Moved assembly section to “Maintenance” section (section 3). Re-assigned section
numbers.
2.0 2.1 Added load-bearing device safety
Appendices Added tong daily & monthly maintenance checklists, power unit daily maintenance,
tong decommissioning & recommissioning checklists
OCT 2009 2.0 2.8 Added Motor Section DVA35 HI BOY 10-0001 to item table (applies only to model 80-
1001-6)
JUNE 2011
All All Re-branded manual
Intro ix Added Table of Illustrations
All All Improved warnings throughout manual
2 2.13 Replaced jaw removal and jaw die removal images
2 2.14 Re-titled Section 2.F.1 “Suspension and Tong Restraint”, and added detailed tie-off
instructions.
2 2.20 Added Section “Making and Breaking Connections”
3 3.1 Added Section “ Preventive Maintenance Practices”
3 3.6 Added door spring cylinder lubrication instruction
3 3.7 Removed “Door Latch Adjustment” references - does not apply to this tong
3 3.10 Replaced graphic - Shifter Detent Force Adjustment
3 3.13 Revised Section: “Assembly Procedures”
3 3.24 Moved maintenance checklists from appendices to Maintenance section
5 5.2 - 5.3 Replaced gear train layout images to reflect support roller changes
5 5.4 Updated support roller array image to reflect support roller changes
5 5.6 - 5.17 Replaced support roller images and bills of material to reflect changes
6 6.1 - 6.8 Complete revision of torque measurement section
OCT 2011 2 2.15 Added new Section G.1, “Operator Training”
5 5.9 Updated part# for Item G
© Copyright 2011 McCoy Drilling & Completions, a wholly-owned subsidiary of McCoy Corporation, all rights reserved. This document is
the property of McCoy Drilling & Completions and is supplied as reference information for users of our products. This document and the
contents within are considered confidential information, not to be disclosed, copied, transmitted, transcribed in any form, or stored on any
type of data storage media without the express written consent of McCoy Drilling & Completions.
McCoy Drilling & Completions has made every effort to ensure the information contained in this document is accurate and current. This
manual is intended to provide equipment operation and safety instructions for your equipment. However, McCoy Drilling & Completions
does not warrant or guarantee that the information is either complete or accurate in every respect, and the user of the manual shall protect,
indemnify, and hold harmless McCoy Drilling & Completions, and all their directors, officers, employees, and agents from and against all
liability for personal injury, death, or property damage resulting directly or indirectly from the use of the information contained in this manual.
Observance of all descriptions, information and instructions set out in this manual is the full responsibility of the user. This manual is
intended for guidance and informational purposes and must be used in association with adequate training and on-the-job supervision to
provide safe and effective equipment use.
It is the responsibility of the user to conform to all regulations and requirements issued by an authority or agency which may affect the
operation, safety or equipment integrity, that may overrule the content of this documentation.
The user will acknowledge and obey any general legal or other mandatory regulation in force relating to accident prevention, safety, and
equipment integrity.
