MCCOY KT14K User manual

MCCOYGLOBAL.COM
TECHNICAL MANUAL
KT14-75K
14” (356 mm) 75,000 lb-ft
Hydraulic Power Tong
SPECIFICATIONS | OPERATION | MAINTENANCE | PARTS

KT14-75K HYDRAULIC POWER TONG
iii
Technical Manual
MOVING GLOBAL ENERGY FORWARD
This Technical documenT applies To The following models:
Tong model ReV descRipTion
80-1001-10 0 Tong with hydraulic motor, motor valve, lift cylinder valve, & rigid sling.
80-1001-29 0 Tong with hydraulic motor, motor valve, lift cylinder valve, & rigid sling. CLOSED CENTRE HYDRAULICS
THIS EQUIPMENT USES A DOOR SWITCH SYSTEM DESIGNED TO INTERRUPT TONG ROTATION WHEN
TONG DOOR IS OPENED
McCoy has made an effort ensure that all illustrations are accurate, but please note that some illustrations
used in this manual may not exactly visually match your equipment.
PATENTED & PATENTS PENDING
ORIGINAL INSTRUCTIONS

This page intentionally
left blank

KT14-75K HYDRAULIC POWER TONG
v
Technical Manual
MOVING GLOBAL ENERGY FORWARD
WARNING
ANY REPLACEMENT FASTENER (BOLTS, NUTS, CAP SCREWS, MACHINE SCREWS, ETC.) USED DURING
MAINTENANCE OR OVERHAUL MUST BE GRADE 8 OR EQUIVALENT UNLESS OTHERWISE SPECIFIED.
WHEN RE-ASSEMBLING LOAD-BEARING DEVICES (CHAIN SLINGS, RIGID SLINGS, BACKUP LEGS, ETC.)
NOTE THAT THE ASSOCIATED FASTENERS MUST BE TIGHTENED TO THE CORRECT TORQUE SPECIFIED
FOR THAT SIZE OF FASTENER (SEE SECTION 3 - OVERHAUL). ANY THREADED FASTENER IN A LOAD-
BEARING DEVICE MUST BE SECURED WITH RED OR BLUE LOCTITE™.
A “LOAD-BEARING DEVICE” IS A CHAIN SLING, RIGID SLING, SPREADER BAR ASSEMBLY, FRAME, OR
ANY OTHER DEVICE THAT BEARS THE PARTIAL OR TOTAL WEIGHT OF THE EQUIPMENT FOR WHICH THIS
MANUAL HAS BEEN PRODUCED
THE LOAD-BEARING DEVICE SUPPLIED BY MCCOY GLOBAL IS DESIGNED TO SUPPORT THE EQUIPMENT
DESCRIBED IN THIS MANUAL. MCCOY GLOBAL WILL NOT GUARANTEE THE ABILITY OF THE LOAD-BEAR-
ING DEVICE TO SUPPORT ANY OTHER PART, ASSEMBLY OR COMBINATION OF PARTS AND ASSEMBLIES.
MCCOY GLOBAL WILL NOT GUARANTEE THE ABILITY OF THE LOAD-BEARING DEVICE TO LIFT OR SUP-
PORT THE EQUIPMENT DESCRIBED IN THIS MANUAL IF THERE ARE ANY MODIFICATIONS TO THE LOAD-
BEARING DEVICE, OR ANY ADDITIONS TO THE EQUIPMENT DESCRIBED IN THIS MANUAL THAT ADD
WEIGHT TO THE EQUIPMENT, UNLESS SUPPLIED BY MCCOY GLOBAL.
READ BEFORE USING EQUIPMENT
AUTHORIZED USE ONLY
Only authorized personnel deemed competent to operate, maintain, and repair this
equipment shall do so.
Do not operate equipment without fully reviewing and complying with all safety guide-
lines contained within this manual.

This page intentionally
left blank

KT14-75K HYDRAULIC POWER TONG
vii
Technical Manual
MOVING GLOBAL ENERGY FORWARD
Summary Of Revisions
Date Section Page Description Of Revision Approved
JULY 2013 N/A N/A Initial Release (model 80-1001-09) Bin Ma
DEC 2013
Preamble iii Listed model 80-1001-10, removed obsolete model 80-1001-9
R. Rahman
2 2.25 Updated safety door testing procedure, subsection 2.H.5
3
3.15-3.20 Updated assembly instructions to reflect new model (model 80-1001-10)
3.15 Replaced lower support roller assembly drawing (model 80-1001-10)
3.20 Replaced upper support roller assembly drawing (model 80-1001-10)
5
5.2 Updated Critical spare parts list
5.3 Updated Recommended One-Year spare parts list
5.4 - 5.5 Updated Overhaul required parts list
5.7 Updated part number for rotary gear (model 80-1001-10)
5.9 Updated part numbers for support roller components (model 80-1001-10)
5.23 Updated part number for rotary gear (model 80-1001-10)
5.24-5.25 Replaced illustrations, 3-½ - 5-½” jaws, updated B.O.M.
5.26-5.27 Inserted illustrations and B.O.M., 6-⅝” to 13-⅝” jaw die kits
5.28-5.29 Inserted illustrations and B.O.M., 14-⅜” jaw die kit
MAR 2016
Preamble iii Added model 80-1001-29
D. Sonnier
11.7 Added warnings for closed-centre hydraulic configuration
1.8 Added updated lubricant specifications
22.12 Updated hydraulic B.O.M. to include components for closed-centre configuration,
added maximum hydraulic supply warning
2.13 Added hydraulic schematic, closed-centre configuration
Published by McCoy Global, Technical Publications Department
14755 - 121AAvenue • Edmonton,AB, Canada, T5L 2T2
Copyright © 2013 - 2016 McCoy Global, including its wholly owned subsidiaries, (“McCoy”), all rights reserved. This document is the property
of McCoy and is supplied as reference information for users of our products. This document and the contents within are considered confidential
information, not to be disclosed, copied, transmitted, transcribed in any form, or stored on any type of data storage media without the express
written consent of McCoy.
McCoy has made every effort to ensure the information contained in this document is accurate and current. This manual is intended to provide
equipment operation and safety instructions for your equipment. However, McCoy does not warrant or guarantee that the information is either
complete or accurate in every respect and the user of the manual should consult with its McCoy sales representative for any clarifications and
updates.
The user of the manual shall protect, indemnify, and hold harmless McCoy and its directors, officers, employees, and agents from and against
all liability for personal injury, death, or property damage resulting directly or indirectly from the use of the information contained in this manual.
Observance of all descriptions, information and instructions set out in this manual is the full responsibility of the user. This manual is intended
for guidance and informational purposes and must be used in association with adequate training and on-the-job supervision to provide safe and
effective equipment use.
It is the responsibility of the user to conform to all regulations and requirements issued by an authority or agency which may affect the operation,
safety or equipment integrity, that may overrule the content of this documentation.
The user will acknowledge and obey any general legal or other mandatory regulation in force relating to accident prevention, safety, and equip-
ment integrity.

KT14-75K HYDRAULIC POWER TONG
viii Technical Manual MOVING GLOBAL ENERGY FORWARD
SECTION ONE: INTRODUCTION
Introduction & Contact Information................................................................................................................................... 1.3
Equipment Specications ................................................................................................................................................. 1.4
SECTION TWO: SETUP & OPERATION
2.A INITIAL RECEIPT AND INSPECTION OF EQUIPMENT........................................................................................... 2.3
2.B MAJOR COMPONENT IDENTIFICATION................................................................................................................. 2.3
2.C SLING / LOAD BEARING DEVICE SAFETY............................................................................................................. 2.6
2.C.1 Inspection Of Slings..................................................................................................................................... 2.7
2.C.2 Proper Use Of Load-Bearing Devices......................................................................................................... 2.8
2.C.3 Storage Of Load-Bearing Devices............................................................................................................... 2.8
2.D LIFT CYLINDER INSTALLATION AND SAFETY
2.D.1 Installation Procedure.................................................................................................................................. 2.9
2.D.2 Lift Cylinder Hydraulic Connection............................................................................................................... 2.10
2.D.3 Lift Cylinder Safety....................................................................................................................................... 2.10
2.E HYDRAULICS
2.E.1 Hydraulic Schematics .................................................................................................................................. 2.12
2.E.2 Hydraulic Component Identification............................................................................................................. 2.14
2.E.3 Hydraulic Connections................................................................................................................................. 2.16
2.E.4 Hydraulic Circuit Description........................................................................................................................ 2.17
2.F TONG JAW AVAILABILITY & INSTALLATION
2.F.1 Jaw Availability............................................................................................................................................. 2.18
2.F.2 Tong Jaw Installation & Removal................................................................................................................. 2.19
2.G TONG RIG-UP & LEVELING
2.G.1 Suspension & Restraint ............................................................................................................................... 2.20
2.G.2 Tong Leveling............................................................................................................................................... 2.22
2.H TONG OPERATION
2.H.1 Operator Training......................................................................................................................................... 2.23
2.H.2 Operator Safety............................................................................................................................................ 2.23
2.H.3 Valve Operation............................................................................................................................................ 2.23
2.H.4 Shifting Gears.............................................................................................................................................. 2.24
2.H.5 Pre-Operational Checks............................................................................................................................... 2.25
2.H.6 General Comments...................................................................................................................................... 2.27
2.I MAKING AND BREAKING CONNECTIONS
2.I.1 Making A Connection ................................................................................................................................... 2.26
2.I.2 Breaking A Connection................................................................................................................................. 2.31
2.J EXTREME COLD WEATHER OPERATION PROCEDURES.................................................................................... 2.33
SECTION THREE: MAINTENANCE
3.A GENERAL MAINTENANCE SAFETY PRACTICES.................................................................................................. 3.3
3.B CLEANING................................................................................................................................................................. 3.3
3.C PREVENTIVE MAINTENANCE PRACTICES............................................................................................................ 3.3
3.D HYDRAULIC SYSTEM DE-PRESSURIZATION........................................................................................................ 3.4
3.E LUBRICATION INSTRUCTIONS ............................................................................................................................... 3.4
3.F ADJUSTMENTS
3.F.1 Brake Band Adjustment ............................................................................................................................... 3.10
3.F.2 Shifter Detent Force Adjustment:................................................................................................................. 3.11
3.G RECOMMENDED PERIODIC CHECKS
3.G.1 Door Stop Springs........................................................................................................................................ 3.11
3.G.2 Backing Pin .................................................................................................................................................. 3.11
3.G.3 Shifting Shaft................................................................................................................................................ 3.11
3.G.4 Torque Gauge Assembly.............................................................................................................................. 3.11
3.H REMOVAL OF TOP PLATE FOR OVERHAUL.......................................................................................................... 3.12
3.I ASSEMBLY PROCEDURES...................................................................................................................................... 3.14
3.J DAILY INSPECTION & MAINTENANCE CHECKLIST (POWER TONG).................................................................. 3.33
3.K MONTHLY MAINTENANCE CHECKLIST - POWER TONG..................................................................................... 3.35
3.L TUBULAR CONNECTION EQUIPMENT DE-COMMISSIONING & SHIPPING PROCEDURE................................ 3.38
3.M TUBULAR CONNECTION EQUIPMENT RE-COMMISSIONING PROCEDURE ..................................................... 3.42
SECTION FOUR: TROUBLESHOOTING
4.A TONG WILL NOT DEVELOP SUFFICIENT TORQUE .............................................................................................. 4.3
4.B RELIEF VALVE IS INCORRECTLY SET OR NOT FUNCTIONING .......................................................................... 4.4
4.C SAFETY DOOR DOES NOT OPERATE OR IS MALFUNCTIONING....................................................................... 4.6
4.D TONG RUNNING TOO SLOWLY............................................................................................................................... 4.7
4.E FAILURE OF JAWS TO GRIP PIPE.......................................................................................................................... 4.8
4.F FAILURE OR DIFFICULTY OF TONG TO SHIFT..................................................................................................... 4.9
4.G GENERAL COMMENTS............................................................................................................................................ 4.10
Continued on next page ...
Table of ConTenTs

KT14-75K HYDRAULIC POWER TONG
ix
Technical Manual
MOVING GLOBAL ENERGY FORWARD
SECTION FIVE: PARTS AND ASSEMBLIES
Critical Spare Parts List.................................................................................................................................................... 5.2
Recommended One-Year Spare Parts List...................................................................................................................... 5.3
Recommended Overhaul Spare Parts List....................................................................................................................... 5.4
Gear Train Layout ............................................................................................................................................................ 5.6
Support Half-Rollers......................................................................................................................................................... 5.8
Rotary Idler....................................................................................................................................................................... 5.10
Pinion Idler ...................................................................................................................................................................... 5.12
Pinion Assembly............................................................................................................................................................... 5.14
Clutch Assembly............................................................................................................................................................... 5.16
Lay (Drive) Assembly....................................................................................................................................................... 5.18
Manual Shifting Assembly................................................................................................................................................ 5.20
Cage Plate Assembly....................................................................................................................................................... 5.22
Jaw Assembly, 3-½” to 5-½”............................................................................................................................................. 5.24
Jaw Assembly, 6-⅝” to 13-⅝”........................................................................................................................................... 5.26
Jaw Assembly, 14”........................................................................................................................................................... 5.28
Motor & Motor Mount Assembly....................................................................................................................................... 5.30
Hydraulic Supports........................................................................................................................................................... 5.32
Brake Bands..................................................................................................................................................................... 5.34
Door Latch Assembly....................................................................................................................................................... 5.36
Safety Door Components................................................................................................................................................. 5.37
Tong Door Assembly........................................................................................................................................................ 5.38
Rigid Sling Assembly........................................................................................................................................................ 5.40
SECTION SIX: TORQUE MEASUREMENT
A. BASIC TORQUE MEASUREMENT .......................................................................................................................... 6.3
B. TROUBLESHOOTING............................................................................................................................................... 6.7
C. PERIODIC INSPECTION AND MAINTENANCE
1. Inspection............................................................................................................................................................. 6.8
2. Fluid Recharge..................................................................................................................................................... 6.8
3. Reference Checking The Torque Measurement System ..................................................................................... 6.8
4. Repair And Calibration......................................................................................................................................... 6.9
SECTION SEVEN: OEM DOCUMENTATION
Table of ConTenTs

KT14-75K HYDRAULIC POWER TONG
xTechnical Manual MOVING GLOBAL ENERGY FORWARD
lisT of illusTraTions
Illustration 1.A.1: KT14-75K Tong ............................................................................................................................................ 1.3
Illustration 1.A.2: KT14-75K Dimensions.................................................................................................................................. 1.4
Illustration 1.A.3: KT14-75K Hazard Areas............................................................................................................................... 1.5
Illustration 1.A.4: FARR® CE Nameplate................................................................................................................................. 1.6
Illustration 2.B.1: Major Component Identication 01............................................................................................................... 2.3
Illustration 2.B.2: Major Component Identication 02............................................................................................................... 2.4
Illustration 2.B.3: Major Component Identication 03............................................................................................................... 2.5
Illustration 2.C.1: Sling Angle ................................................................................................................................................... 2.6
Illustration 2.D.1: Lift Cylinder & Spring Hanger Installation..................................................................................................... 2.9
Illustration 2.D.2: Lift Cylinder Hydraulic Connection ............................................................................................................... 2.10
Illustration 2.E.1: Hydraulic Schematic..................................................................................................................................... 2.12
Illustration 2.E.2: Hydraulic Schematic, Closed Centre............................................................................................................ 2.13
Illustration 2.E.3: Hydraulic Component Identication 01......................................................................................................... 2.14
Illustration 2.E.4: Hydraulic Component Identication 02......................................................................................................... 2.14
Illustration 2.E.5: Hydraulic Component Identication 03......................................................................................................... 2.15
Illustration 2.E.6: Hydraulic Component Identication 04......................................................................................................... 2.15
Illustration 2.E.7: Hydraulic Connections 01............................................................................................................................. 2.16
Illustration 2.E.7: Hydraulic Connections 02............................................................................................................................. 2.16
Illustration 2.F.1: Jaw Removal ................................................................................................................................................ 2.17
Illustration 2.F.2: Jaw Die Removal.......................................................................................................................................... 2.17
Illustration 2.G.1: Tong Suspension Relative To Axial Centre.................................................................................................. 2.21
Illustration 2.G.2: Tong Suspension Relative To Vertical Centre ............................................................................................. 2.21
Illustration 2.G.3: Tong Leveling 01.......................................................................................................................................... 2.22
Illustration 2.G.4: Tong Leveling 02.......................................................................................................................................... 2.22
Illustration 2.H.1: Tong Rotation Control Valve ........................................................................................................................ 2.24
Illustration 2.H.2: Tong Lift Cylinder Control Valve................................................................................................................... 2.24
Illustration 2.H.3: Tong Manual Shift Control............................................................................................................................ 2.25
Illustration 2.I.1: Master Lifting Link.......................................................................................................................................... 2.27
Illustration 2.I.2: Backing Pin Set To “Make-up” Position ......................................................................................................... 2.28
Illustration 2.I.3: Lift Cylinder Control (Raise)........................................................................................................................... 2.29
Illustration 2.I.4: Opening Tong Doors...................................................................................................................................... 2.29
Illustration 2.I.5: Motor Control - Make-up ................................................................................................................................ 2.30
Illustration 2.I.6: Motor Control - Releasing Jaws..................................................................................................................... 2.31
Illustration 2.I.7: Lift Cylinder Control - Lower........................................................................................................................... 2.31
Illustration 2.I.8: Setting Backing Pin To “Break-Out” Position ................................................................................................. 2.32
Illustration 2.I.9: Rotation Control - Break-Out.......................................................................................................................... 2.33
Illustration 2.I.10: Releasing Tong Jaws Following Break-out & Un-threading......................................................................... 2.33
Illustration 2.I.11: Lowering Tong Using Lift Cylinder Control................................................................................................... 2.34
Illustration 3.E.1: Guide Ring Lubrication................................................................................................................................. 3.4
Illustration 3.E.2: Support Roller Lubrication............................................................................................................................ 3.5
Illustration 3.E.3: Rotary Idler Lubrication................................................................................................................................. 3.5
Illustration 3.E.4: Pinion Idler Lubrication................................................................................................................................. 3.6
Illustration 3.E.5: Pinion Lubrication......................................................................................................................................... 3.6
Illustration 3.E.6: Clutch Lubrication......................................................................................................................................... 3.7
Illustration 3.E.7: Motor Mount Lubrication............................................................................................................................... 3.7
Illustration 3.E.8: Shifter Component Lubrication..................................................................................................................... 3.8
Illustration 3.E.9: Lay Gear Lubrication .................................................................................................................................... 3.8
Illustration 3.E.10: Door Spring Cylinder (Exploded)................................................................................................................ 3.9
Illustration 3.F.1: Brake Band Adjustment ................................................................................................................................ 3.10
Illustration 3.F.2: Shifter Detent Force Adjustment................................................................................................................... 3.11
Illustration 3.I.1: Bottom Support Roller Assembly Drawing..................................................................................................... 3.15
Illustration 3.I.2: Bottom Support Roller Installation.................................................................................................................. 3.16
Illustration 3.I.3: Clutch Assembly Drawing.............................................................................................................................. 3.16
Illustration 3.I.4: Pinion Assembly Drawing .............................................................................................................................. 3.17
Illustration 3.I.5: Pinion Idler Assembly Drawing ...................................................................................................................... 3.18
Illustration 3.I.6: Pinion Bearing Race Installation.................................................................................................................... 3.19
Illustration 3.I.7: Rotary Idler Assembly Drawing...................................................................................................................... 3.19
Illustration 3.I.8: Top Support Roller Assembly Drawing.......................................................................................................... 3.20
Illustration 3.I.9: Top Plate Fastener Installation ...................................................................................................................... 3.21
Illustration 3.I.10: Lay Gear Assembly Drawing........................................................................................................................ 3.22
Illustration 3.I.11: Shifting Fork Assembly Drawing .................................................................................................................. 3.23
Illustration 3.I.12: Cage Plate Spacer Installation..................................................................................................................... 3.24
Illustration 3.I.13: Safety Door Cam & Lower Reinforcement Installation................................................................................. 3.25
Illustration 3.I.14: Door Latch Installation ................................................................................................................................. 3.26
Illustration 3.I.15: Door Installation........................................................................................................................................... 3.27
Illustration 3.I.16: Safety Door Switch Installation .................................................................................................................... 3.28
Illustration 3.I.17: Hydraulic Support Installations..................................................................................................................... 3.29
Continued on next page ...

KT14-75K HYDRAULIC POWER TONG
xi
Technical Manual
MOVING GLOBAL ENERGY FORWARD
lisT of illusTraTions
Illustration 3.I.18: Hydraulic Valve Assembly Installation ......................................................................................................... 3.30
Illustration 3.I.19: Rigid Sling Leveling Bolt Installation............................................................................................................ 3.31
Illustration 3.L.1: Shipping Instructions - Pallet......................................................................................................................... 3.40
Illustration 3.M.2: Shipping Instructions - Wrapping Chain Sling & Strapping To Pallet........................................................... 3.41
Illustration 4.B.1: Relief Valve Troubleshooting - Temporary Gauge Installation..................................................................... 4.4
Illustration 5.1: Gear Train ISO View........................................................................................................................................ 5.6
Illustration 5.2: Gear Train Top & Side View ............................................................................................................................ 5.7
Illustration 5.3: Support Half-Rollers Exploded ........................................................................................................................ 5.8
Illustration 5.4: Support Half-Rollers ........................................................................................................................................ 5.9
Illustration 5.5: Rotary Idler Exploded....................................................................................................................................... 5.10
Illustration 5.6: Rotary Idler Gear Assembly............................................................................................................................. 5.11
Illustration 5.7: Pinion Idler Exploded....................................................................................................................................... 5.12
Illustration 5.8: Pinion Idler Gear Assembly ............................................................................................................................. 5.13
Illustration 5.9: Pinion Gear Assembly Exploded...................................................................................................................... 5.14
Illustration 5.10: Pinion Gear Assembly ................................................................................................................................... 5.15
Illustration 5.11: Clutch Gear Assembly Exploded ................................................................................................................... 5.16
Illustration 5.12: Clutch Gear Assembly .................................................................................................................................. 5.17
Illustration 5.13: Lay Gear Assembly Exploded........................................................................................................................ 5.18
Illustration 5.14: Lay Gear Assembly ....................................................................................................................................... 5.19
Illustration 5.15: Shifter Assembly Exploded............................................................................................................................ 5.20
Illustration 5.16: Shifter Assembly ........................................................................................................................................... 5.21
Illustration 5.17: Cage Plate Assembly Exploded..................................................................................................................... 5.22
Illustration 5.18: Cage Plate Assembly .................................................................................................................................... 5.23
Illustration 5.19: 3-½” to 5-½” Jaw Assembly Exploded ........................................................................................................... 5.24
Illustration 5.20: 3-½” to 5-½” Jaw Assembly .......................................................................................................................... 5.25
Illustration 5.21: 6-⅝” to 13-⅝” Jaw Assembly Exploded ......................................................................................................... 5.26
Illustration 5.22: 6-⅝” to 13-⅝” Jaw Assembly ........................................................................................................................ 5.27
Illustration 5.23: 14” Jaw Assembly Exploded.......................................................................................................................... 5.28
Illustration 5.24: 14” Jaw Assembly ......................................................................................................................................... 5.29
Illustration 5.25: Motor & Mount Exploded................................................................................................................................ 5.30
Illustration 5.26: Motor & Mount................................................................................................................................................ 5.31
Illustration 5.27: Hydraulic Supports Exploded......................................................................................................................... 5.32
Illustration 5.28: Hydraulic Supports......................................................................................................................................... 5.33
Illustration 5.29: Brake Bands Exploded................................................................................................................................... 5.34
Illustration 5.30: Brake Bands................................................................................................................................................... 5.35
Illustration 5.31: Door Latch Assembly Exploded..................................................................................................................... 5.36
Illustration 5.32: Safety Door Components Exploded............................................................................................................... 5.37
Illustration 5.33: Door Assembly Exploded............................................................................................................................... 5.38
Illustration 5.34: Door Assembly............................................................................................................................................... 5.39
Illustration 5.35: Rigid Sling Exploded...................................................................................................................................... 5.40
Illustration 5.36: Rigid Sling...................................................................................................................................................... 5.41
Illustration 6.A.1: Torque Gauge .............................................................................................................................................. 6.3
Illustration 6.A.2: Tension Load Cell......................................................................................................................................... 6.3
Illustration 6.A.3: Compression Load Cell ................................................................................................................................ 6.3
Illustration 6.A.4: Tension Load Cell Exploded......................................................................................................................... 6.5
Illustration 6.A.6: Turn Counter Encoder Mount Exploded....................................................................................................... 6.6

KT14-75K HYDRAULIC POWER TONG
xii Technical Manual MOVING GLOBAL ENERGY FORWARD
IDENTIFICATION OF WARNINGSAND OTHER NOMENCLATURE OF
IMPORTANCE USED IN THIS TECHNICAL MANUAL
McCoy Global uses three indicators to describe items of three degrees of importance.
A HAZARD to operators or equipment is represented by an exclamation point within a red triangle. identifies items of the highest
importance. Failure to heed information identified by a HAZARD symbol may result in bodily injury, death, catastrophic equip-
ment damage, or any combination of these. A HAZARD may also indicate the potential for dangerous environmental contamina-
tion.
The information presented in this document will provide setup, operating, and maintenance instructions for your
KT14-75K tong. Due to the wide variety of operating conditions, these instructions must be considered guidelines
rather than absolute operating procedures. It is the responsibility of the user to use these guidelines together with
an experienced manager to develop operating procedures that conform to all policies set forth by the operating
authority (ies).
A WARNING is represented by an exclamation point within an orange triangle, and contains information that will alert personnel to a potential
safety hazard that is not life-threatening.AWARNING may also serve to alert the user to information critical to the correct assembly or operation
of the equipment in use.
This identies a HAZARD to operators or equipment
This identies a WARNING to users
A CAUTION is represented by an exclamation point within a yellow triangle and highlights information that may aid the user dur-
ing assembly or operation of your equipment. CAUTIONs are also used to ensure common errors are not made during assembly
or operation of your equipment.
This identies a CAUTION to users
Observance of the following is the full responsibility of the user:
• all descriptions, information and instructions set out in this manual
• any regulation or requirement issued by an authority or agency which may influence operation, safety
or integrity of the equipment that overrules the content of this document.
• any legal or other mandatory regulation in force governing accident prevention or environmental
protection.

KT14-75K HYDRAULIC POWER TONG
1.1
Technical Manual
MOVING GLOBAL ENERGY FORWARD
secTion 1: inTRoducTion & specificaTions

This page intentionally
left blank

KT14-75K HYDRAULIC POWER TONG
1: IntroductIon & SpecIfIcatIonS
1.3
Technical Manual
MOVING GLOBAL ENERGY FORWARD
Congratulations on the purchase of your McCoy KT14-75K 14 inch tong. This unit will provide you with years of outstanding performance. Simple
maintenance and care will extend its life and ensure years of excellent performance and reliability. The setup, operating, and maintenance
instructions in this manual will assist you in giving your equipment the care it requires. Please carefully read the manual before installing and
using your equipment. Replacement parts are readily available from McCoy Global Canada in Edmonton, Alberta. Note that many parts are
transferable between McCoy tongs and backups. Should you need replacement parts, or should you experience any difculty not covered in
this manual, please contact:
McCoy Global Canada Corp.
14755 121A Avenue
Edmonton, Alberta
Canada T5L 2T2
Phone: [phone]
Fax: [phone]
Email Engineering: [email protected]
Email Sales: [email protected]
Website: http://www.mccoyglobal.com/drilling-completions
Illustration 1.A.1: KT14-75K Tong

KT14-75K HYDRAULIC POWER TONG 1: IntroductIon & SpecIfIcatIonS
1.4 Technical Manual MOVING GLOBAL ENERGY FORWARD
Illustration 1.A.2: KT14-75K Dimensions
ALL REPLACEMENT FASTENER (BOLTS, NUTS, CAP SCREWS, MACHINE SCREWS, ETC.) USED
DURING MAINTENANCE OR OVERHAUL MUST BE GRADE 8 OR EQUIVALENT UNLESS OTHERWISE
SPECIFIED.
45”
72-½” 38”
39-⅜”

KT14-75K HYDRAULIC POWER TONG
1: IntroductIon & SpecIfIcatIonS
1.5
Technical Manual
MOVING GLOBAL ENERGY FORWARD
Illustration 1.A.3: KT14-75K Hazard Areas
In addition to the HAZARD areas of this equipment that are coated YELLOW, the
rotating cage plate assembly poses a significant hazard when the equipment is
active. Keep hands clear of the cage plate when equipment is energized. SAFE
areas to handle while the equipment is energized are indicated by GREEN coating
Keep hands clear of cage
plate when equipment is
energized
TORQUE GAUGE
MOUNTS IN THIS
LOCATION
SYSTEM
PRESSURE
GAUGE

KT14-75K HYDRAULIC POWER TONG 1: IntroductIon & SpecIfIcatIonS
1.6 Technical Manual MOVING GLOBAL ENERGY FORWARD
CE compliant. Conforms with the essential requirements of the applicable Conformité Européenne directives.
EU Explosive Atmosphere certied
II Equipment Group (surface, non-mining)
2Equipment Category - high level of protection
Gc Gas Group (Acetylene & Hydrogen) - Certied for use in an acetylene / hydrogen environment
T6 Maximum surface temperature of 85 oC.
Illustration 1.A.4: McCoy CE Nameplates
II 2 G IIB T6
©McCoy Global Inc. All Rights Reserved.

KT14-75K HYDRAULIC POWER TONG
1: IntroductIon & SpecIfIcatIonS
1.7
Technical Manual
MOVING GLOBAL ENERGY FORWARD
Torque Table
Please note that these are ideal values. Actual achieved
torque is highly dependant upon tong efciency and
nal position of rotary gear when full torque load is
reached. Maximum torque is only available in low gear
and full motor displacement.
Pressure High Gear Low Gear
PSI / MPa Lb-ft Nm Lb-ft Nm
1000 / 6.89 4381 5940 22285 30214
1500 / 11.03 8032 10890 40856 55393
2000 / 13.79 11684 15841 59428 80574
2420 / 16.69 14751 20000 75000 101686
MAXIMUM RATED TORQUE: 75000 LB-FT / 101686 Nm
REQUIRED SYSTEM PRESSURE: 2420 PSI / 16.69 MPa
MAXIMUM SYSTEM PRESSURE: 2500 PSI / 17.24 MPa
MAXIMUM SYSTEM FLOW: 60 USGPM / 227.1 LPM
Maximum hydraulic requirements 60 GPM (227.1 LPM)
2500 PSI (17.237 MPa)
Maximum allowable hydraulic return line pressure 200 PSI (1.378 MPa)
Maximum dimensions
Length (doors closed) 72-½” / 1.841 m
Height 45” / 1.143 m
Max Width 39-⅜” / 1.00 m
Maximum elevator diameter Unlimited (tong comes off pipe)
Torque arm length (pipe center to anchor center) 45-½” / 1.156 m
Gear reduction ratio, turn counter encoder to ring gear 14.833 (60-0001 mount)
Dead weight 3150 lb / 1431 kg
Maximum rigid sling load 6500 lb / 2948 kg
Sound level (dBa) 97 dB A @ 1m / 96 dB C @ 1m
Jaws available (inches) All standard sizes from 4-½” to 14-⅜” (See Pg. 2.11)
Recommended spring hanger 85-0106HDS (Capacity = 5900 lb / 2676 kg)
Speed Table
Flow
(GPM/LPM) Low Gear
(RPM) High Gear (RPM)
10 / 37.9 0.7 4
20 / 75.7 1.5 7.9
45 / 170.3 3.3 17.9
60 / 227.1 4.4 23.8
!DANGER
ONLY USE SPRING HANGERS SUPPLIED BY MCCOY GLOBAL.
!DANGER
DO NOT EXCEED MAXIMUM SPECIFIED FLOW OR PRESSURE

KT14-75K HYDRAULIC POWER TONG 1: IntroductIon & SpecIfIcatIonS
1.8 Technical Manual MOVING GLOBAL ENERGY FORWARD
RECOMMENDED LUBRICANT SPECIFICATIONS
Hydraulic Fluid
McCoy Global recommends using high-quality hydraulic fluid containing rust & oxidation inhibitors and foam suppressant that
meets the following requirements. Operating this equipment using hydraulic fluid that does not meet these requirements greatly
accelerates equipment damage due to (but not limited to) premature component wear, premature seal failure, cavitation, and
fluid starvation.
!CAUTION
OPERATING THIS EQUIPMENT USING HYDRAULIC FLUID THAT DOES NOT MEET THE LISTED REQUIREMENTS
GREATLY ACCELERATES EQUIPMENT DAMAGE.
Hydraulic Fluid Standards
Characteristic Requirement
Maximum viscosity at cold startup <1000 cSt (<4600 SUS)
Operating viscosity range 100 to 16 cSt (170 to 80 SUS)
Minimum viscosity (intermittent periods only) 10 cSt (60 SUS)
Hydraulic uid operating temperature range 86 - 140°F (30 - 60°C) - measured in main reservoir
Maximum uid temperature 180°F (82°C)
Fluid cleanliness Filtered to ISO 4406:1999 (22/18/13)
Hydraulic fluid should be chosen with due regard to expected climactic conditions and equipment load. Note that this equipment
may have been tested using hydraulic fluid that does not meet operational requirements beyond those specified in the above
table. Therefore, McCoy recommends purging and flushing the equipment’s hydraulic system before connecting to a hydraulic
supply.
NOTICE
MCCOY GLOBAL RECOMMENDS PURGING AND FLUSHING THE EQUIPMENT’S HYDRAULIC SYSTEM BEFORE
CONNECTING TO A HYDRAULIC SUPPLY.
Gear Fluid
McCoy Global recommends using a high-quality universal gear uid in gearbox and torque hub assemblies. If required, the gear
uid should meet VG150/VG220 or AGMA 4EP/5EP specications. However, in more extreme operating conditions it may be
necessary to ll the gearboxes on the equipment with gear uid more suitable to the ambient operating environment. Refer to
the following table to determine McCoy Global’s recommendations for gear uid selection.
Gear Fluid Standards
Operating Condition Requirement
-4°F to 41°F (-20°C to 5°C) meets ISO VG100 or AGMA 3EP specications
41°F to 104°F (5°C to 40°C) meets VG150/VG220 or AGMA 4EP/5EP specications
greater than 104°F (40°C) meets VG320 or AGMA 6EP specications
Grease
McCoy Global recommends use of a high-quality EP multi-purpose grease with an NLGI consistency grade of "2" and an NLGI
performance grade of "GC-LB" for general lubrication of bearings and metal-to-metal contact.
McCoy Global recommends thoroughly greasing the equipment before first use as per the lubrication instructions in Section 5.
