MCO Home
MCO Home Glass Touch Switch
GEN5 (2 Buttons)
SKU: MCOETPS412
Quickstart
This is a Binary Power Switch for XXXQFrequencyName. To run this device please connect it to your mains power supply. AThis device is a Z-Wave
Actuator. To include or exclude the device you only need to press and hold any key for 8 seconds.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat
sources.
Product Description
The TPS412 by MCO Home is a wall switch with 2 integrated switch relays. The relays can be controlled both with the touch switches, which are integrated into
the glass surface, and via Z-Wave commands. The relays can switch two loads with up to 1,100 watts each. Beside local switching the device can be used to
control two groups of directly associated devices. A blue LED on every button indicates the switching status.
The wall switch can be easily connected to an electrical load without installing a flush mounted module separately. The relays are located inside a module
which is directly connected to the glass touch button. With that MCO Home wall switch you can replace any switch insert or toggle switch. The wall switch can
be mounted on any flush box.
With the stylish glass wall switches by MCO Home you can easily integrate your already installed lights into your home automation network. Without installing
any news cable, you can switch your lighting as usual via wall switch – but thanks to Z-Wave technology also via remote control, smartphone or sensor-
controlled automation.
Installation
Important: Please make sure you have cut off power supply before you start to install the device.
Connect Hot Line to "L"
Connect Neutral Line to "N"
Connect Load wire to "L1"

06-10-2020 14:09
Pagina 2 van 5http://manuals-backend.z-wave.info/make.php?lang=en&sku=MCOETPS412&cert=&type=mini
Connect Load wire to "L2"
1. Remove the steel frame from the device, and secure it onto the junctions box with tow screws.
2. Insert all wires into the right terminals and tighten screws.
3. Attach the wired device on "A" points of the steel frame as shown first, and then push the whole device into junction box.
4. Confirm the device is well mounted, power on and it is ready to operate.
Product Usage
The actuator is operated by the local switching Touch pannels or wirelessly using Z-Wave commands.
Scene Function:
1. Scene Response Device
As a Scene Response device, it supports “Scene Activation CC” and “Scene Actuator Conf
CC” ,which make the device can be added into any scene , and supports 255 Scene ID. In parameter
item 0x10, users can configure which external switch button will respond the scene CC.
2. Scene Activate Device
As a Scene Activate device, when pressing the switch button, it will send “Scene Activation” to
Association Group 1 (normally associated to the gateway) to activate corresponding scenes, and the
scene ID is set by configuration parameter. This function is disabled by default, to activate it, please
refer to the configuration parameter table item 17-19.
3. Central Scene Activate Device
As a Central Scene Activate device, it supports “Central Scene CC”. When pressing the switch
button, it will send “Central Scene Notification” to Association Group 1 (normally associated to
gateway). This function is always being activated and cannot be disabled.
Reset to factory default XXXResetDescription
Inclusion To include the device you only need to press and hold any key for 8 seconds.
Exclusion To exclude the device you only need to press and hold any key for 8 seconds.
NIF XXXNIF
Wakeup XXXWakeupDescription
Protection XXXProtection
FirmwareUpdate XXXFirmwareUpdate
SetAssociation XXXSetAssociation
Association Groups:
Group Number Maximum Nodes Description
11Lifeline
25 Associate with Key 1 - send Basic Set Command to associated devices
55 Associate with Key 2 - send Basic Set Command to associated devices
Configuration Parameters
Parameter 2: Switch state saved or not when power failure
Size: 1 Byte, Default Value: 1

06-10-2020 14:09
Pagina 3 van 5http://manuals-backend.z-wave.info/make.php?lang=en&sku=MCOETPS412&cert=&type=mini
Setting Description
0not savedswitch will be off when powered again
1savedswitch will keep the same state when powered again
Parameter 3: ALL ON/ALL OFF
Size: 1 Byte, Default Value: 255
Setting Description
0forbid ALL ON, forbid ALL OFF
1forbid ALL ON, allow ALL OFF
2allow ALL ON, forbid ALL OFF
255 allow ALL ON, allow ALL OFF
Parameter 4: LED Backlit brightness level
Size: 1 Byte, Default Value: 10
Setting Description
0LED disabled
1 - 10 Min level-Max level
Parameter 5: Key Mode
This function works for corridor or stairwell situation.
Size: 1 Byte, Default Value: 0
Setting Description
0single click to switch on/off status
1Key default as off state. When it is turned on, then it will be turned off automatically after a time period , which
can be set in item 6
2Key default as on state. When it is turned off, then it will be turned on automatically after a time period , which
can be set in item 6
3hold >3s then key is on, and off once released
4single click to switch on/off status + hold >3s then key is on, and off once released
Parameter 6: Key On duration
Size: 2 Byte, Default Value: 0
Setting Description
0infinite
1 - 65535 unit sec
Parameter 8: Basic CC integration setting
This parameter works for integration with different gateways/systems. If do not know how to use, pls keep as default.
Size: 1 Byte, Default Value: 0

06-10-2020 14:09
Pagina 4 van 5http://manuals-backend.z-wave.info/make.php?lang=en&sku=MCOETPS412&cert=&type=mini
Setting Description
0Basic Set receivedkey 1 responds; Basic Get receivedkey 1 sends Basic Report; key 1 will not send
unsolicited Basic ReportNo Endpointto LifeLine Association
1Basic Set receivedkey 1 responds; Basic Get receivedkey 1 sends Basic Report; key 1 will send
unsolicited Basic ReportNo Endpointto LifeLine Association
2Basic Set receivedall keys respond; Basic Get receivednot reply Basic Report; All keys will not send
unsolicited Basic ReportNo Endpointto LifeLine Association
3Basic Set receivedall keys respond; Basic Get receivedkey 1 sends Basic Report; All keys will not send
unsolicited Basic ReportNo Endpointto LifeLine Association
Parameter 16: Scene respond
Size: 1 Byte, Default Value: 0
Setting Description
0Scene respond disabled
1Key1 respond scene
Parameter 17: Key1 Scene Activate Mode Setting
Size: 1 Byte, Default Value: 0
Setting Description
0Scene activate function disabled
1One click key1 always activate scene ID1 no matter what the status of key1 is.
2One click key1,only activate scene ID1 when key1‘s relay output is open
3One click key1,only activate scene ID1 when key1‘s relay output is close
Parameter 18: Key1 Activate Scene ID
Size: 1 Byte, Default Value: 00
Setting Description
0Scene ID is invalid and will not send scene activate command.
1 - 255 Scene ID
Parameter 19: Key1 Activate Scene Duration
Size: 1 Byte, Default Value: 0
Setting Description
0Instantly
1 - 127 Dimming durations from 1 second to 127 seconds in 1-second resolution
128 - 254 Specify dimming durations from 1 minute to 127 minutes in 1-minute resolution.
Parameter 20: Key 2 Scene Activate Mode Setting
Size: 1 Byte, Default Value: 0
Setting Description
0Scene activate function disabled
1One click key2 always activate scene ID1 no matter what the status of key2 is.
2One click key2,only activate scene ID1 when key2‘s relay output is open
3One click key2,only activate scene ID1 when key2‘s relay output is close

06-10-2020 14:09
Pagina 5 van 5http://manuals-backend.z-wave.info/make.php?lang=en&sku=MCOETPS412&cert=&type=mini
Parameter 21: Key2 Activate Scene ID
Size: 1 Byte, Default Value: 00
Setting Description
0Scene ID is invalid and will not send scene activate command.
1 - 255 Scene ID
Parameter 22: Key2 Activate Scene Duration
Size: 1 Byte, Default Value: 0
Setting Description
0Instantly
1 - 127 Dimming durations from 1 second to 127 seconds in 1-second resolution
128 - 254 Specify dimming durations from 1 minute to 127 minutes in 1-minute resolution.
Parameter 255: Factory Reset
Size: 1 Byte, Default Value: 0
Setting Description
85 Factory Reset
Technical Data
Dimensions 86 x 86 x 39 mm
Weight 180 gr
Hardware Platform ZM5101
EAN 4251295700755
IP Class IP 20
Voltage 230V
Load 5A
Device Type On/Off Power Switch
Generic Device Class Binary Switch
Specific Device Class Binary Power Switch
Firmware Version 05.02
Z-Wave Version 04.3e
Z-Wave Product Id 0x015f.0x4121.0x5102
Frequency Europe - 868,4 Mhz
Maximum transmission power 5 mW
EuropeOn/Off Power Switch
