McQuay MCW200 User manual

Ceiling Concealed Chilled Water
Fan Coil Unit (50Hz)
Technical Manual
Engineered for flexibility and performance.TM
MCW - C/F/H - 2008
(50Hz)
Models: MCW200 MCW300 MCW400
MCW600 MCW800 MCW1000
MCW1200
Air Flow: 112~2040m3/h

1
“McQuay” is a registered trademark of McQuay International. All rights reserved throughout the world.
© 2008 McQuay International
“Bulletin illustrations cover the general appearance of McQuay International products at the time of publication
and we reserve the right to make changes in design and construction at any time without notice.”
Note: Installation and maintenance are to be performed only by qualied personnel who are
familiar with local codes and regulations, and experienced with this type of equipment.
Caution: Sharp edges and coil surfaces are a potential injury hazard. Avoid contact with them.
Warning: Moving machinery and electrical power hazard. May cause severe personal
injury or death. Disconnect and lock off power before servicing equipment.
Literature No.: TM-MCW(C/H/F)-0805B
Supersedes: TM-MCW(C/H/F)-0708A
Part No.: M08039110020
Contents
Nomenclature …………………………………………………………………………………… 2
Features ………………………………………………………………………………………… 3
Electric Heater Power ………………………………………………………………………… 3
Specications …………………………………………………………………………………… 4
Sound Data ……………………………………………………………………………………… 8
Performance Data-Cooling …………………………………………………………………… 9
Performance Data-Heating …………………………………………………………………… 18
Air Flow vs ESP Curve ………………………………………………………………………… 21
Operating Limits………………………………………………………………………………… 22
Water Flow Rate vs Pressure Drop Chart ………………………………………………… 23
Outlines and Dimensions……………………………………………………………………… 25
Electrical Data…………………………………………………………………………………… 27
Wiring Diagrams………………………………………………………………………………… 28
Installation ……………………………………………………………………………………… 30
Exploded View & Part List …………………………………………………………………… 32
Guide Specications…………………………………………………………………………… 35

2
MCW 200 C D 10 －8 R B F A A F1 E
Nomenclature
Export
Description of Products
A-Standard Drain Pan
F1-Drain Pan Extended 100mm
F2-Drain Pan Extended 200mm
Material of Drain Pan
A-Standard Material
S-Stainless Steel
Power Supply
A-220V/1Ph/50Hz
F-With Filter
X-Without Filter
B-Back Return Air Plenum
D-Bottom Return Air Plenum
X-Back return air plenum & bottom draw lter
C-Without return air plenum
Pipe Connection
R-Facing Air Flow Right Hand
L-Facing Air Flow Left Hand
0-0Pa External Static Pressure
3-30Pa External Static Pressure
6-60Pa External Static Pressure
8-80Pa External Static Pressure
"-"-Original Design
"A"-First Design Improve
Electric Heater Power
10-10x100 W
With Electric Heater
C-3 Rows and 2 Pipes(3+0)
H-4 Rows and 4 Pipes(3+1)
F-4 Rows and 2 Pipes(4+0)
Nominal Air Flow (CFM)
(CFM,1CFM=1.7m3/h)
McQuay Ceiling Concealed Chilled Water FCU

3
Features
Extra Low Noise Design
Enlarged fan wheels design allows lower fan RPM selection for the same external static pressure and airow
requirement. Thereby, noise level is signicantly reduced.
Flexibility
Water connection side can be changed easily in the eld by changing positions of fan-motor assembly or
the supply air ange assembly. Fan-motor assembly is not cased allowing back return or bottom return
installations.
High Efciency Heat Exchanger
A boundary layer lm of air adhering to the n surface will insulate the n surface and severally reduces the
heat exchange efciency. Mcquay slit n design eliminates this boundary layer of air and creates continuous
for best heat exchange efciency.
Variable External Static Pressure
Four types of external static pressure are available for every unit:0PA, 30Pa,,60Pa,80Pa.
Compact Design
This series of fan coil units are designed to suit most ceiling concealed installations. Unit height is only
251mm across the entire model range. The feature also maximizes provisions for drain fall requirements.
New design realizes all the lters removal both from the side and bottom(Option).
Auxiliary Electric Heater (Only For Type C)
The heating source of Mcquay fan coil unit is PTC (Positive Temperature Coefcient) heater.
1. Safety
A fuse (135°C,10A) is connected in each PTC main wiring circuit. A thermostat (50°C,10A) is connected in
the control wiring circuit. If the fan of the units is not running, the thermostat or fuse will cut off the power
of the unit. In addition the surface of the PTC heater is without electric power. So the fan coil unit is safe
enough.
2. Save Energy
Quick heating spread, strong heating capacity, steady performance and save energy are characters of
PTC heater.
3. Easy To Install And Maintain
Needn’t remove the air duct when maintain the electric components of the units. Please refer to the
corresponding sections for installation and maintenance.
Electric Heater Power
Unit Size Power Supply kW kW kW kW kW kW kW kW kW kW kW kW kW
MCW200CD 220-240V/1Ph/50Hz 1.0 1.5 2.0 2.5 - - - - - - - - -
MCW300CD 220-240V/1Ph/50Hz 1.0 1.5 2.0 2.5 3.0 3.5 - - - - - -
MCW400CD 220-240V/1Ph/50Hz 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 - - - - -
MCW600CD 380-415V/3Ph/50Hz - - 2.0 2.5 3.0 3.5 4.0 4.5 - - - - -
MCW800CD 380-415V/3Ph/50Hz - - 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 - - -
MCW1000CD 380-415V/3Ph/50Hz - - 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 - - -
MCW1200CD 380-415V/3Ph/50Hz - - - - 3.0 3.5 4.0 4.5 5.0 5.5 6.0 7.0 8.0

4
Specications
General Data
MCW-C
NoteS:
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL THE UNITS ARE BEING TESTED UNDER FOLLOWING CONTITION:
a) COOLING: 27°C DB/19.5°C WB INDOOR AND WATER INLET 7°C OUTLET 12°C
b) HEATING: 21°C DB INDOOR AND WATER 60°C INLET.WATER FLOW:SAME WITH COOLING CONDITION.
MODEL MCW200 MCW300 MCW400 MCW600 MCW800 MCW1000 MCW1200
Air Flow
HIGH m3/h 390 530 760 1040 1420 1620 2040
CFM 229 312 447 612 835 953 1200
MEDIUM m3/h 260 370 490 780 1090 1140 1500
CFM 153 218 288 459 641 671 882
LOW m3/h 190 240 340 500 740 830 1020
CFM 112 141 200 294 435 488 600
EXTERNAL STATIC
PRESSURE
Pa 0,30,60,80
in.wg 0,0.12,0.24,0.32
TOTAL COOLING
CAPACITY
W 2200 3200 4390 6160 7810 8830 10700
Btu/h 7507 10919 14979 21019 26649 30129 36510
SENSIBLE COOLING
CAPACITY
W 1738 2359 3242 4401 6040 6409 7763
Btu/h 5930 8049 11062 15017 20609 21868 26488
TOTAL HEATING
CAPACITY
W 3500 5100 7300 9960 13080 14780 19170
Btu/h 11942 17402 24909 33985 44631 50431 65411
WATER FLOW RATE
m3/h 0.4 0.6 0.8 1.1 1.4 1.6 1.9
USGPM 1.8 2.5 3.4 4.8 6.1 6.9 8.5
HEAD LOSS (COOLING) kPa 14.6 12.0 21.6 38.2 18.4 21.0 32.7
in.wg. 58.4 48.0 86.4 152.8 73.6 84.0 130.8
DIMENSIONS
UNIT
DIMEN-
SIONS
HEIGHT mm 251 251 251 251 251 251 251
WIDTH mm 714 884 1014 1214 1464 1564 1824
DEPTH mm 556 556 556 556 556 556 556
PACKING
DIMEN-
SION
HEIGHT mm 260 260 260 260 260 260 260
WIDTH mm 724 894 1024 1224 1474 1574 1834
DEPTH mm 570 570 570 570 570 570 570
UNIT WEIGHT
(Without plenum)
kg 19.0 20.0 26.0 30.0 41.0 44.0 46.0
lb 41.9 44.1 57.3 66.1 90.4 97.0 101.4
UNIT GROSS WEIGHT
(Without plenum)
kg 21.7 24.8 29.5 33.6 44.0 47.8 51.2
lb 47.8 54.7 65.0 74.1 97.0 105.4 112.9
UNIT WEIGHT
(With plenum)
kg 20.0 24.0 28.0 33.0 44.0 47.0 50.0
lb 44.1 52.9 61.7 72.8 97.0 103.6 110.2
UNIT GROSS WEIGHT
(With plenum)
kg 22.7 28.8 31.5 36.6 47.0 50.8 55.2
lb 50.0 63.5 69.4 80.7 103.6 112.0 121.7
CONDENSATE DRAIN PIPE SIZE R3/4

5
NoteS:
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL THE UNITS ARE BEING TESTED UNDER FOLLOWING CONTITION:
a) COOLING: 27°C DB/19.5°C WB INDOOR AND WATER INLET 7°C OUTLET 12°C
b) HEATING: 21°C DB INDOOR AND WATER 60°C INLET.WATER FLOW:SAME WITH COOLING CONDITION.
MCW-H
MODEL MCW200 MCW300 MCW400 MCW600 MCW800 MCW1000 MCW1200
Air Flow
HIGH m3/h 360 510 750 1010 1380 1570 2000
CFM 212 300 441 594 812 924 1176
MEDIUM m3/h 250 350 470 770 1070 110 1470
CFM 147 206 276 453 629 653 865
LOW m3/h 180 230 330 490 720 820 1010
CFM 106 135 194 288 424 482 594
EXTERNAL STATIC
PRESSURE
Pa 0,30,60,80
in.wg 0,0.12,0.24,0.32
TOTAL COOLING CAPACITY W 2130 3100 4260 5980 7580 8570 10380
Btu/h 7268 10578 14536 20405 25864 29242 35418
SENSIBLE COOLING
CAPACITY
W 1683 2285 3146 4272 5862 6220 7531
Btu/h 5742 7798 10735 14578 20002 21224 25696
TOTAL HEATING
CAPACITY (1 ROW)
W 1350 2280 3210 4290 5120 6940 8490
Btu/h 4606 7780 10953 14638 17470 23680 28969
WATER FLOW RATE
(3 ROWS)
m3/h 0.4 0.6 0.8 1.1 1.4 1.6 1.9
USGPM 1.8 2.5 3.4 4.8 6.1 6.9 8.5
WATER FLOW RATE
(1 ROW)
m3/h 0.2 0.2 0.2 0.2 0.2 0.5 0.5
USGPM 1.1 1.1 1.1 1.1 1.1 2.2 2.2
HEAD LOSS (COOLING)
(3 ROWS)
KPa 12.0 21.6 38.2 18.4 21.0 32.7 12.0
in.wg. 58.4 48.0 86.4 152.8 73.6 84.0 130.8
DIMENSIONS
UNIT
DIMEN-
SIONS
HEIGHT mm 251 251 251 251 251 251 251
WIDTH mm 714 884 1014 1214 1464 1564 1824
DEPTH mm 556 556 556 556 556 556 556
PACKING
DIMEN-
SION
HEIGHT mm 260 260 260 260 260 260 260
WIDTH mm 724 894 1024 1224 1474 1574 1834
DEPTH mm 570 570 570 570 570 570 570
HEAD LOSS (HEATING)
(1 ROW)
KPa 12.0 13.5 14.8 20.7 4.0 12.8 14.6
in.wg. 48 54 59 83 16 51 59
UNIT WEIGHT
(Without plenum)
kg 20.0 24.0 28.0 32.0 44.0 47.0 49.0
lb 44.1 52.9 61.7 70.5 97.0 103.6 108.0
UNIT GROSS WEIGHT
(Without plenum)
kg 22.7 26.8 31.5 35.6 47.0 50.8 54.2
lb 50.0 59.1 69.4 78.5 103.6 112.0 119.5
UNIT WEIGHT (With plenum) kg 22.0 27.0 31.0 36.0 48.0 52.0 56.0
lb 48.5 59.5 68.3 79.4 105.8 114.6 123.5
UNIT GROSS WEIGHT
(With plenum)
kg 24.7 29.8 34.5 39.6 51.0 55.8 61.2
lb 54.5 65.7 76.1 87.3 112.4 123.0 134.9
CONDENSATE DRAIN PIPE SIZE R3/4

6
NoteS:
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL THE UNITS ARE BEING TESTED UNDER FOLLOWING CONTITION:
a) COOLING: 27°C DB/19.5°C WB INDOOR AND WATER INLET 7°C OUTLET 12°C
b) HEATING: 21°C DB INDOOR AND WATER 60°C INLET.WATER FLOW:SAME WITH COOLING CONDITION.
MCW-F
MODEL MCW200 MCW300 MCW400 MCW600 MCW800 MCW1000 MCW1200
Air Flow
HIGH m3/h 360 510 750 1010 1380 1570 2000
CFM 212 300 441 594 812 924 1176
MEDIUM m3/h 250 350 470 770 1070 110 1470
CFM 147 206 276 453 629 653 865
LOW m3/h 180 230 330 490 720 820 1010
CFM 106 135 194 288 424 482 594
EXTERNAL STATIC
PRESSURE
kPa 0,30,60,80
in.wg 0,0.12,0.24,0.32
TOTAL COOLING
CAPACITY
W 2622 3418 5277 7185 8691 10261 12791
Btu/h 8948 11661 18007 24517 29653 35013 43644
SENSIBLE COOLING
CAPACITY
W 1783 2406 3536 5047 6365 7297 9382
Btu/h 6085 8210 12066 17222 21719 24899 32011
TOTAL HEATING
CAPACITY
W 4196 5468 8444 11496 13905 16418 20465
Btu/h 14317 18658 28811 39227 47445 56020 69830
WATER FLOW RATE m3/h 0.5 0.6 0.9 1.3 1.5 1.8 2.3
USGPM 2.0 2.7 4.1 5.5 6.8 8.0 10.1
HEAD LOSS (COOLING) kPa 1.3 6.0 1.3 27.0 8.8 12.0 20.0
in.wg. 5.2 24.1 5.2 108.3 35.3 48.1 80.2
DIMENSIONS
UNIT
DIMEN-
SIONS
HEIGHT mm 251 251 251 251 251 251 251
WIDTH mm 714 884 1014 1214 1464 1564 1824
DEPTH mm 556 556 556 556 556 556 556
PACKING
DIMEN-
ENSION
HEIGHT mm 260 260 260 260 260 260 260
WIDTH mm 724 894 1024 1224 1474 1574 1834
DEPTH mm 570 570 570 570 570 570 570
UNIT WEIGHT
(Without plenum)
kg 20.0 24.0 28.0 32.0 44.0 47.0 49.0
lb 44.1 52.9 61.7 70.5 97.0 103.6 108.0
UNIT GROSS WEIGHT
(Without plenum)
kg 22.7 26.8 31.5 35.6 47.0 50.8 54.2
lb 50.0 59.1 69.4 78.5 103.6 112.0 119.5
UNIT WEIGHT
(With plenum)
kg 22.0 27.0 31.0 36.0 48.0 52.0 56.0
lb 48.5 59.5 68.3 79.4 105.8 114.6 123.5
UNIT GROSS WEIGHT
(With plenum)
kg 24.7 29.8 34.5 39.6 51.0 55.8 61.2
lb 54.5 65.7 76.1 87.3 112.4 123.0 134.9
CONDENSATE DRAIN PIPE SIZE R3/4

7
NoteS:
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
Components Data
MCW-C/H/F
MCW200 MCW300 MCW400 MCW600 MCW800 MCW1000 MCW1200
FAN
TYPE CENTRIFUGAL (BLADE: FORWARD)
QUANTITY 1 2 3 4
MATERIAL GALVANIZED STEEL
DRIVE DIRECT DRIVE
DIAMETER mm 160
in 6.25
LENGTH mm 200
in 7.875
MOTOR
TYPE SINGLE PHASE CAPACITOR RUNNING
QUANTITY 1 2
IP/INSULATION GRADE IP20/E
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 9.52
in 3/8
THICK-
NESS
mm 0.30
in 0.012
FIN
MATERIAL HYDROPHILIC ALUMINUM
THICK-
NESS
mm 0.11
in 0.0043
FACE
AREA
m20.09 0.13 0.15 0.19 0.24 0.26 0.32
ft20.98 1.35 1.64 2.07 2.62 2.84 3.41
ROW C 3
H/F 4
FIN PER INCH 11
AIR
FILTER
(Option)
TYPE NYLON/ALUMINIUM FRAME
SIZE
LENGTH mm 462 632 762 962 1212 1311 1572
in 18.19 24.88 30.00 37.87 47.72 51.61 61.89
WIDTH mm 205
in 8.07
THICK-
NESS
mm 8
in 0.31

8
NoteS:
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) SOUND PRESSURE LEVELS ARE TESTED IN SEMI-ANECHOIC ROOM,WITH BACKGROUND LEVEL: 11.5dB(A),
MICROPHONE POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
MCW-C/H/F
Sound Data
ESP 0Pa 30Pa
Unit Speed
1/1 Octave Sound pressure level
(dBA, ref 20μPa) Total
dB (A)
1/1 Octave Sound pressure level
(dBA, ref 20μPa) Total
dB (A)
63 125 250 500 1k 2k 4k 8k 63 125 250 500 1k 2k 4k 8k
200
High 15 19 23 28 28 23 14 13 33 15 19 24 28 29 24 15 13 33
Medium 14 18 19 24 24 19 14 13 29 12 17 22 26 26 23 15 13 31
Low 13 14 17 20 18 14 13 13 25 15 18 18 20 20 15 12 13 26
300
High 16 21 26 32 34 30 19 14 37 16 21 26 32 34 30 19 14 37
Medium 15 19 23 28 28 23 14 13 33 12 17 22 26 26 23 15 13 31
Low 15 15 19 23 23 18 11 11 28 14 18 19 24 24 19 14 13 29
400
High 14 20 25 31 32 28 16 14 36 16 21 28 33 34 31 20 13 38
Medium 12 17 22 26 26 23 15 13 31 13 20 26 29 31 27 18 14 35
Low 15 18 18 20 20 15 12 13 26 15 19 24 28 29 24 15 13 33
600
High 15 25 30 35 37 33 25 18 41 16 28 32 36 39 37 30 21 43
Medium 14 24 28 33 35 32 22 16 39 14 24 28 33 35 32 22 16 39
Low 15 19 23 28 28 23 14 13 33 14 18 23 27 28 23 15 13 32
800
High 14 23 29 34 37 32 21 15 40 15 25 30 35 37 33 25 18 41
Medium 16 21 28 33 34 31 20 13 38 16 21 28 33 34 31 20 13 38
Low 14 18 23 27 28 23 15 13 32 15 19 24 28 29 24 15 13 33
1000
High 15 25 30 35 37 33 25 18 41 16 28 32 36 39 37 30 21 43
Medium 16 21 28 33 34 31 20 13 38 16 21 26 32 34 30 19 14 37
Low 15 19 23 28 28 23 14 13 33 14 20 23 28 30 27 16 13 34
1200
High 16 28 32 36 39 37 30 21 43 17 28 32 37 41 38 28 21 44
Medium 14 23 29 34 37 32 21 15 40 14 24 28 33 35 32 22 16 39
Low 13 20 26 29 31 27 18 14 35 15 19 24 28 29 24 15 13 33
ESP 60Pa 80Pa
Unit Speed
1/1 Octave Sound pressure level
(dBA, ref 20μPa) Total
dB(A)
1/1 Octave Sound pressure level
(dBA, ref 20μPa) Total
dB(A)
63 125 250 500 1k 2k 4k 8k 63 125 250 500 1k 2k 4k 8k
200
High 16 21 26 32 34 30 19 14 37 16 21 28 33 34 31 20 13 38
Medium 14 20 23 28 30 27 16 13 34 13 20 26 29 31 27 18 14 35
Low 12 17 22 26 26 23 15 13 31 14 18 23 27 28 23 15 13 32
300
High 16 21 28 33 34 31 20 13 38 14 24 28 33 35 32 22 16 39
Medium 13 20 26 29 31 27 18 14 35 14 20 25 31 32 28 16 14 36
Low 12 17 22 26 26 23 15 13 31 14 18 23 27 28 23 15 13 32
400
High 15 25 30 35 37 33 25 18 41 16 30 34 38 42 38 29 22 45
Medium 14 20 25 31 32 28 16 14 36 15 25 30 35 37 33 25 18 41
Low 15 19 23 28 28 23 14 13 33 13 20 26 29 31 27 18 14 35
600
High 19 36 36 41 43 40 30 26 47 19 35 40 43 46 43 34 31 50
Medium 17 28 32 37 41 38 28 21 44 18 34 35 40 42 39 31 20 46
Low 16 21 28 33 34 31 20 13 38 18 26 31 36 38 35 27 16 42
800
High 19 36 36 41 43 40 30 26 47 18 34 39 42 45 43 34 30 49
Medium 17 28 32 37 41 38 28 21 44 19 36 36 41 43 40 30 26 47
Low 14 24 28 33 35 32 22 16 39 17 28 32 37 41 38 28 21 44
1000
High 18 34 39 42 45 43 34 30 49 18 34 39 42 45 43 34 30 49
Medium 18 34 35 40 42 39 31 20 46 18 32 38 40 44 42 36 29 48
Low 14 23 29 34 37 32 21 15 40 16 30 34 38 42 38 29 22 45
1200
High 18 34 39 42 45 43 34 30 49 18 34 39 42 45 43 34 30 49
Medium 16 30 34 38 42 38 29 22 45 18 32 38 40 44 42 36 29 48
Low 18 26 31 36 38 35 27 16 42 16 30 34 38 42 38 29 22 45

9
MCW-C
Performance Data-Cooling
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB27ºC, WB19.5ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 5.6 1940 1420 1820 1400 1720 1370 1590 1310 1400 1260
0.33 9.7 2190 1600 2080 1560 1940 1550 1800 1520 1660 1480
0.42 14.8 2370 1740 2210 1700 2080 1660 1940 1640 1790 1610
0.51 21.6 2500 1830 2270 1800 2190 1750 2030 1700 1880 1680
MCW300
0.36 4.0 2910 2150 2730 2100 2510 2050 2300 2020 2250 1990
0.48 9.2 3230 2380 3020 2330 2820 2300 2600 2270 2520 2220
0.6 13.2 3480 2550 3240 2490 3020 2450 2780 2410 2680 2390
0.72 18.7 3660 2700 3420 2630 3170 2600 2920 2550 2820 2490
MCW400
0.42 7.3 3650 2660 3410 2600 3200 2550 2950 2510 2570 2460
0.6 13.8 4190 2970 3940 3040 3690 3010 3410 2990 3130 2930
0.78 21.6 4580 3360 4390 3320 3980 3280 3710 3240 3410 3200
0.96 31.0 4850 3510 4530 3490 4230 3450 3900 3410 3590 3380
MCW600
0.72 18.7 5850 4260 5480 4220 5100 4180 4670 4110 4270 3970
0.9 32.7 6310 4410 5890 4360 5460 4260 5070 4200 4650 4110
1.08 38.2 6670 4660 6160 4460 5780 4400 5330 4360 4900 4350
1.26 50.0 6970 4830 6490 4780 6030 4700 5560 4680 5090 4600
MCW800
1.14 12.5 7780 5720 7300 5630 6740 5570 6060 5450 5530 5320
1.44 18.7 8410 5880 7900 5800 7370 5750 6820 5700 6220 5680
1.74 26.2 8920 6320 8340 6250 7750 6200 7200 6120 6620 5980
2.04 34.5 9320 6520 8710 6460 8100 6410 7500 6370 6910 6220
MCW1000
1.2 13.6 8610 5710 8040 6190 7410 6300 6820 6140 6280 6030
1.5 20.1 9280 6550 8710 6440 8080 6410 7460 6340 6780 6240
1.8 26.5 9850 6890 9190 6780 8520 6720 7900 6710 7230 6690
2.1 33.7 10300 7210 9610 7080 8920 7010 8210 6970 7550 6940
MCW1200
1.56 21.5 10710 7490 10010 7400 9280 7360 8490 7270 7740 7190
1.92 32.7 11480 8470 10700 8240 9970 8140 9170 8070 8380 7710
2.28 40.7 12110 8710 11290 8650 10460 8580 9610 8460 8820 8120
2.64 54.3 12600 8950 11750 8810 10890 8710 10020 8620 9140 8410
NoteS:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200C MCW300C MCW400C MCW600C MCW800C MCW1000C MCW1200C
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

10
NoteS:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200C MCW300C MCW400C MCW600C MCW800C MCW1000C MCW1200C
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB28ºC, WB21ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
WWWWWWW W
MCW200
0.24 5.6 2160 1580 2020 1560 1910 1520 1770 1460
0.33 9.7 2430 1780 2310 1730 2160 1720 2000 1690
0.42 14.8 2630 1930 2460 1890 2310 1840 2160 1820
0.51 21.6 2780 2030 2740 2000 2430 1940 2260 1890
MCW300
0.36 4 3230 2390 3030 2330 2790 2280 2560 2240
0.48 9.2 3590 2640 3360 2590 3130 2560 2890 2520
0.6 13.2 3870 2830 3600 2770 3360 2720 3090 2680
0.72 18.7 4070 3000 3800 2920 3520 2890 3240 2830
MCW400
0.42 7.3 4060 2960 3790 2890 3560 2830 3280 2790
0.6 13.8 4660 3300 4380 3380 4100 3340 3790 3320
0.78 21.6 5090 3730 4880 3690 4420 3640 4120 3600
0.96 31 5390 3900 5030 3880 4700 3830 4330 3790
MCW600
0.72 18.7 6500 4730 6090 4690 5670 4640 5190 4570
0.9 32.7 7010 4900 6540 4840 6070 4730 5630 4670
1.08 38.2 7410 5180 6840 4960 6420 4890 5920 4840
1.26 50 7740 5370 7210 5310 6700 5220 6180 5200
MCW800
1.14 12.5 8640 6360 8110 6260 7490 6190 6730 6060
1.44 18.7 9340 6530 8780 6440 8190 6390 7580 6330
1.74 26.2 9910 7020 9270 6940 8610 6890 8000 6800
2.04 34.5 10360 7240 9680 7180 9000 7120 8330 7080
MCW1000
1.2 13.6 9570 6340 8930 6880 8230 7000 7580 6820
1.5 20.1 10310 7280 9680 7160 8980 7120 8290 7040
1.8 26.5 10940 7660 10210 7530 9470 7470 8780 7460
2.1 33.7 11440 8010 10680 7870 9910 7790 9120 7740
MCW1200
1.56 21.5 11900 8320 1120 8220 10310 8180 9430 8080
1.92 32.7 12760 9410 11890 9160 11080 9040 10190 8970
2.28 40.7 13460 9680 12540 9610 11620 9530 10680 9400
2.64 54.3 14000 9940 13060 9790 12100 9680 1130 9580

11
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB25ºC, WB18ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 5.6 1750 1280 1640 1260 1550 1230 1430 1180 1260 1130
0.33 9.7 1970 1440 1870 1400 1750 1400 1620 1370 1490 1330
0.42 14.8 2130 1570 1990 1530 1870 1490 1750 1480 1610 1450
0.51 21.6 2250 1650 2220 1620 1970 1580 1830 1530 1690 1510
MCW300
0.36 4 2620 1940 2460 1890 2260 1850 2070 1820 2030 1790
0.48 9.2 2910 2140 2720 2100 2540 2070 2340 2040 2270 2000
0.6 13.2 3130 2300 2920 2240 2720 2210 2500 2170 2410 2150
0.72 18.7 3290 2430 3080 2370 2850 2340 2630 2300 2540 2240
MCW400
0.42 7.3 3290 2390 3070 2340 2880 2300 2660 2260 2310 2210
0.6 13.8 3770 2670 3550 2740 3320 2710 3070 2690 2820 2640
0.78 21.6 4120 3020 3950 2990 3580 2950 3340 2920 3070 2880
0.96 31 4370 3160 4080 3140 3810 3110 3510 3070 3230 3040
MCW600
0.72 18.7 5270 3830 4930 3800 4590 3760 4200 3700 3840 3570
0.9 32.7 5680 3970 5300 3920 4910 3830 4560 3780 4190 3700
1.08 38.2 6000 4190 5540 4010 5200 3960 4800 3920 4410 3920
1.26 50 6270 4350 5840 4300 5430 4230 5000 4210 4580 4140
MCW800
1.14 12.5 7000 5150 6570 5070 6070 5010 5450 4910 4980 4790
1.44 18.7 7570 5290 7110 5220 6630 5180 6140 5130 5600 5110
1.74 26.2 8030 5690 7510 5630 6980 5580 6480 5510 5960 5380
2.04 34.5 8390 5870 7840 5810 7290 5770 6750 5730 6220 5600
MCW1000
1.2 13.6 7750 5140 7240 5570 6670 5670 6140 5530 5650 5430
1.5 20.1 8350 5900 7840 5800 7270 5770 6710 5710 6100 5620
1.8 26.5 8870 6200 8270 6100 7670 6050 7110 6040 6510 6020
2.1 33.7 9270 6490 8650 6370 8030 6310 7390 6270 6800 6250
MCW1200
1.56 21.5 9640 6740 9010 6660 8350 6620 7640 6540 6970 6470
1.92 32.7 10330 7620 9630 7420 8970 7330 8250 7260 7540 6940
2.28 40.7 10900 7840 10160 7790 9410 7720 8650 7610 7940 7310
2.64 54.3 11340 8060 10580 7930 9800 7840 9020 7760 8230 7570
NoteS:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200C MCW300C MCW400C MCW600C MCW800C MCW1000C MCW1200C
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

12
MCW-H
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB27ºC, WB19.5ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 5.6 1882 1377 1765 1358 1668 1329 1542 1271 1358 1222
0.33 9.7 2124 1552 2018 1513 1882 1504 1746 1474 1610 1436
0.42 14.8 2299 1688 2144 1649 2018 1610 1882 1591 1736 1562
0.51 21.6 2425 1775 2202 1746 2124 1698 1969 1649 1824 1630
MCW300
0.36 4 2823 2086 2648 2037 2435 1989 2231 1959 2183 1930
0.48 9.2 3133 2309 2929 2260 2735 2231 2522 2202 2444 2153
0.6 13.2 3376 2474 3143 2415 2929 2377 2697 2338 2600 2318
0.72 18.7 3550 2619 3317 2551 3075 2522 2832 2474 2735 2415
MCW400
0.42 7.3 3541 2580 3308 2522 3104 2474 2862 2435 2493 2386
0.6 13.8 4064 2881 3822 2949 3579 2920 3308 2900 3036 2842
0.78 21.6 4443 3259 4258 3220 3861 3182 3599 3143 3308 3104
0.96 31 4705 3405 4394 3385 4103 3347 3783 3308 3482 3279
MCW600
0.72 18.7 5675 4132 5316 4093 4947 4055 4530 3987 4142 3851
0.9 32.7 6121 4278 5713 4229 5296 4132 4918 4074 4511 3987
1.08 38.2 6470 4520 5975 4326 5607 4268 5170 4229 4753 4220
1.26 50 6761 4685 6295 4637 5849 4559 5393 4540 4937 4462
MCW800
1.14 12.5 7547 5548 7081 5461 6538 5403 5878 5287 5364 5160
1.44 18.7 8158 5704 7663 5626 7149 5578 6615 5529 6033 5510
1.74 26.2 8652 6130 8090 6063 7518 6014 6984 5936 6421 5801
2.04 34.5 9040 6324 8449 6266 7857 6218 7275 6179 6703 6033
MCW1000
1.2 13.6 8352 5539 7799 6004 7188 611 6615 5956 6092 5849
1.5 20.1 9002 6354 8449 6247 7838 6218 7236 6150 6577 6053
1.8 26.5 9555 6683 8914 6577 8264 6518 7663 6509 7013 6489
2.1 33.7 9991 6994 9322 6868 8652 6800 7964 6761 7324 6732
MCW1200
1.56 21.5 10389 7265 9710 7178 9002 7139 8235 7052 7508 6974
1.92 32.7 1136 8216 10379 7993 9671 7896 8895 7828 8129 7479
2.28 40.7 11747 8449 10951 8391 10146 8323 9322 8206 8555 7876
2.64 54.3 12222 8682 11398 8546 10563 8449 9719 8361 8866 8158
NoteS:
1) TTHE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200H MCW300H MCW400H MCW600H MCW800H MCW1000H MCW1200H
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

13
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB28ºC, WB21ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 5.6 2095 1533 1959 1513 1853 1474 1717 1416 1513 1358
0.33 9.7 2357 1727 2241 1678 2095 1668 1940 1639 1785 1591
0.42 14.8 2551 1872 2386 1833 2241 1785 2095 1765 1930 1736
0.51 21.6 2697 1969 2658 1940 2357 1882 2192 1833 2027 1814
MCW300
0.36 4 3133 2318 2939 2260 2706 2212 2483 2173 2425 2144
0.48 9.2 3482 2561 3259 2512 3036 2483 2803 2444 2716 2396
0.6 13.2 3754 2745 3492 2687 3259 2638 2997 2600 2891 2580
0.72 18.7 3948 2910 3686 2832 3414 2803 3143 2745 3036 2687
MCW400
0.42 7.3 3938 2871 3676 2803 3453 2745 3182 2706 2774 2648
0.6 13.8 4520 3201 4249 3279 3977 3240 3676 3220 3376 3162
0.78 21.6 4937 3618 4734 3579 4287 3531 3996 3492 3676 3453
0.96 31 5228 3783 4879 3764 4559 3715 4200 3676 3870 3647
MCW600
0.72 18.7 6305 4588 5907 4549 5500 4501 5034 4433 4598 4278
0.9 32.7 6800 4753 6344 4695 5888 4588 5461 4530 5015 4433
1.08 38.2 7188 5025 6635 4811 6227 4743 5742 4695 5277 4685
1.26 50 7508 5209 6994 5151 6499 5063 5995 5044 5490 4957
MCW800
1.14 12.5 8381 6169 7867 6072 7265 6004 6528 5878 5956 5733
1.44 18.7 9060 6334 8517 6247 7944 6198 7353 6140 6703 6121
1.74 26.2 9613 6809 8992 6732 8352 6683 7760 6596 7139 6441
2.04 34.5 10049 7023 9390 6965 8730 6906 8080 6868 7450 6703
MCW1000
1.2 13.6 9283 6150 8662 6674 7983 6790 7353 6615 6771 6499
1.5 20.1 10001 7062 9390 6945 8711 6906 8041 6829 7304 6722
1.8 26.5 10612 7430 9904 7304 9186 7246 8517 7236 7789 7207
2.1 33.7 11097 7770 10360 7634 9613 7556 8846 7508 8138 7479
MCW1200
1.56 21.5 11543 8070 10786 7973 10001 7935 9147 7838 8342 7750
1.92 32.7 12377 9128 11533 8885 10748 8769 9884 8701 9031 8313
2.28 40.7 13056 9390 12164 9322 11271 9244 10360 9118 9506 8749
2.64 54.3 13580 9642 12668 9496 11737 9390 10796 9293 9855 9060
NoteS:
1) TTHE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED
MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200H MCW300H MCW400H MCW600H MCW800H MCW1000H MCW1200H
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

14
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB25ºC, WB18ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 5.6 1698 1242 1591 1222 1504 1193 1387 1145 1222 1096
0.33 9.7 1911 1397 1814 1358 1698 1358 1571 1329 1445 1290
0.42 14.8 2066 1523 1930 1484 1814 1445 1698 1436 1562 1407
0.51 21.6 2183 1601 2153 1571 1911 1533 1775 1484 1639 1465
MCW300
0.36 4 2541 1882 2386 1833 2192 1795 2008 1765 1969 1736
0.48 9.2 2823 2076 2638 2037 2464 2008 2270 1979 2202 1940
0.6 13.2 3036 2231 2832 2173 2638 2144 2425 2105 2338 2086
0.72 18.7 3191 2357 2988 2299 2765 2270 2551 2231 2464 2173
MCW400
0.42 7.3 3191 2318 2978 2270 2794 2231 2580 2192 2241 2144
0.6 13.8 3657 2590 3444 2658 3220 2629 2978 2609 2735 2561
0.78 21.6 3996 2929 3832 2900 3473 2862 3240 2832 2978 2794
0.96 31 4239 3065 3958 3046 3696 3017 3405 2978 3133 2949
MCW600
0.72 18.7 5112 3715 4782 3686 4452 3647 4074 3589 3725 3463
0.9 32.7 5510 3851 5141 3802 4763 3715 4423 3667 4064 3589
1.08 38.2 5820 4064 5374 3890 5044 3841 4656 3802 4278 3802
1.26 50 6082 4220 5665 4171 5267 4103 4850 4084 4443 4016
MCW800
1.14 12.5 6790 4996 6373 4918 5888 4860 5287 4763 4831 4646
1.44 18.7 7343 5131 6897 5063 6431 5025 5956 4976 5432 4957
1.74 26.2 7789 5519 7285 5461 6771 5413 6286 5345 5781 5219
2.04 34.5 8138 5694 7605 5636 7071 5597 6548 5558 6033 5432
MCW1000
1.2 13.6 7518 4986 7023 5403 6470 5500 5956 5364 5481 5267
1.5 20.1 8100 5723 7605 5626 7052 5597 6509 5539 5917 5451
1.8 26.5 8604 6014 8022 5917 7440 5869 6897 5859 6315 5839
2.1 33.7 8992 6295 8391 6179 7789 6121 7168 6082 6596 6063
MCW1200
1.56 21.5 9351 6538 8740 6460 8100 6421 7411 6344 6761 6276
1.92 32.7 10020 7391 9341 7197 8701 7110 8003 7042 7314 6732
2.28 40.7 10573 7605 9855 7556 9128 7488 8391 7382 7702 7091
2.64 54.3 11000 7818 10263 7692 9506 7605 8749 7527 7983 7343
NoteS:
1) TTHE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED
MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200H MCW300H MCW400H MCW600H MCW800H MCW1000H MCW1200H
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

15
MCW-F
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB27ºC, WB19.5ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 0.51 2134 1562 2000 1500 1900 1400 1800 1400 1540 1300
0.33 0.96 2400 1700 2200 1600 2100 1584 1900 1596 1800 1495
0.42 1.56 2600 1849 2400 1700 2200 1696 2100 1722 1900 1626
0.51 2.29 2700 1944 2500 1800 2400 1788 2200 1785 2000 1697
MCW300
0.36 2.19 3201 2365 3000 2250 2773 2095 2604 2159 2475 2053
0.48 3.89 3540 2529 3194 2390 3053 2350 2744 2384 2733 2242
0.6 6.08 3818 2709 3519 2490 3194 2504 3009 2531 2845 2414
0.72 8.76 3953 2869 3767 2630 3474 2657 3165 2678 3000 2515
MCW400
0.42 3.08 4015 2926 3747 2786 3535 2606 3340 2682 2827 2538
0.6 6.29 4592 3156 4167 3118 3994 3076 3599 3140 3394 2959
0.78 10.6 5024 3570 4767 3320 4210 3352 4016 3402 3620 3232
0.96 16.1 5238 3729 4989 3490 4636 3526 4227 3581 3819 3414
MCW600
0.72 10.04 6435 4686 6022 4521 5634 4272 5287 4392 4697 4096
0.9 15.69 6915 4686 6230 4472 5910 4353 5352 4410 5042 4151
1.08 22.59 7317 4951 6690 4460 6113 4496 5770 4578 5201 4394
1.26 30.75 7528 5132 7148 4780 6608 4803 6026 4914 5415 4646
MCW800
1.14 5.53 8558 6292 8022 6032 7445 5692 6860 5824 6083 5489
1.44 8.83 9216 6248 8356 5949 7978 5876 7199 5985 6745 5737
1.74 12.89 9786 6715 9057 6250 8197 6336 7794 6426 7027 6040
2.04 17.72 10066 6928 9593 6460 8877 6550 8128 6689 7351 6282
MCW1000
1.2 6.44 9471 6281 8835 6632 8185 6438 7721 6562 6908 6221
1.5 10.1 10170 6959 9213 6605 8746 6550 7874 6657 7352 6302
1.8 14.49 10806 7321 9980 6780 9012 6867 8552 7046 7674 6757
2.1 19.72 1124 7661 10584 7080 9775 7164 8898 7319 8032 7009
MCW1200
1.56 11.21 11781 8239 11000 7929 10251 7521 9611 7769 8514 7418
1.92 16.98 12581 8999 11317 8451 10792 8318 9679 8474 9087 7787
2.28 23.94 13285 9254 12261 8650 11063 8768 10403 8883 9362 8201
2.64 32.1 13608 9509 12941 8810 11934 8901 10859 9051 9723 8494
NoteS:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200F MCW300F MCW400F MCW600F MCW800F MCW1000F MCW1200F
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

16
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB28ºC, WB21ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
MCW200
0.24 0.51 2376 1738 2220 1671 2110 1553 2004 1560 1716 1444
0.33 0.96 2663 1891 2443 1774 2338 1758 211 1775 1995 1656
0.42 1.56 2885 2051 2671 1890 2443 1880 2338 1911 2112 1808
0.51 2.29 3002 2157 3018 2000 2663 1982 2449 1985 2223 1889
MCW300
0.36 2.19 3553 2629 3330 2496 3082 2330 2898 2394 2750 2280
0.48 3.89 3934 2805 3554 2656 3388 2616 3051 2646 3036 2495
0.6 6.08 4246 3007 3910 2770 3554 2780 3345 2814 3163 2687
0.72 8.76 4396 3188 4185 2920 3858 2953 3511 2972 3330 2798
MCW400
0.42 3.08 4466 3256 4165 3096 3933 2892 3713 2982 3146 2817
0.6 6.29 5107 3506 4633 3467 4438 3413 4001 3486 3773 3293
0.78 10.6 5584 3963 5300 3690 4675 3720 4460 3780 4023 3596
0.96 16.1 5821 4144 5540 3880 5151 3914 4693 3980 4245 3798
MCW600
0.72 10.04 7150 5203 6692 5025 6263 4742 5875 4884 5214 4550
0.9 15.69 7682 5206 6917 4964 6571 4834 5943 4904 5606 4616
1.08 22.59 8129 5504 7428 4960 6790 4997 6408 5082 5774 4878
1.26 30.75 8359 5706 7941 5310 7342 5334 6698 5460 6021 5161
MCW800
1.14 5.53 9504 6996 8912 6707 8274 6326 7619 6476 6754 6098
1.44 8.83 10236 6938 9287 6605 8865 6530 8001 6647 7493 6373
1.74 12.89 10872 7459 10067 6940 9107 7041 8660 7140 7812 6706
2.04 17.72 1189 7693 10661 7180 9863 7276 9028 7434 8170 6979
MCW1000
1.2 6.44 10527 6974 9813 7371 9091 7153 8581 7289 7678 6913
1.5 10.1 11299 7735 10238 7344 9721 7276 8751 7392 8165 6999
1.8 14.49 12002 8139 11088 7530 10016 7634 9504 7833 8523 7504
2.1 19.72 12355 8511 11762 7870 10860 7961 9884 8127 8926 7787
MCW1200
1.56 11.21 13090 9152 12220 8807 11389 8359 10675 8635 9460 8244
1.92 16.98 13984 9998 12576 9395 11994 9238 10756 9419 10095 8656
2.28 23.94 14766 10285 13618 9610 12290 9739 11561 9870 10402 9110
2.64 32.1 15120 10561 14383 9790 13260 9892 12062 10059 10809 9433
NoteS:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200F MCW300F MCW400F MCW600F MCW800F MCW1000F MCW1200F
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

17
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kPa)
ENTERING AIR: DB25ºC, WB18ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SEN-SIBLE TOTAL SEN-SIBLE TOTAL SEN-SIBLE TOTAL SEN-SIBLE TOTAL SEN-SIBLE
W W W W W W W W W W
MCW200
0.24 0.51 1925 1408 1802 1350 1712 1257 1619 1261 1386 1166
0.33 0.96 2159 1530 1978 1436 1894 1431 1710 1439 1616 1343
0.42 1.56 2337 1668 2161 1530 1978 1523 1894 1554 1709 1465
0.51 2.29 2430 1753 2445 1620 2159 1615 1983 1607 1798 1525
MCW300
0.36 2.19 2882 2134 2703 2025 2497 1891 2343 1945 2233 1847
0.48 3.89 3189 2274 2877 2154 2749 2115 2470 2142 2461 2020
0.6 6.08 3434 2444 3171 2240 2877 2258 2706 2279 2558 2172
0.72 8.76 3553 2582 3392 2370 3123 2391 2850 2415 2702 2262
MCW400
0.42 3.08 3619 2629 3374 2507 3181 2350 3011 2415 2541 2280
0.6 6.29 4132 2837 3755 2810 3594 2769 3241 2825 3058 2666
0.78 10.6 4520 3209 4290 2990 3787 3015 3615 3066 3259 2909
0.96 16.1 4720 3358 4493 3140 4175 3178 3804 3224 3436 3070
MCW600
0.72 10.04 5797 4213 5418 4071 5070 3842 4755 3954 4224 3683
0.9 15.69 6225 4218 5606 4021 5315 3914 4813 3969 4543 3737
1.08 22.59 6582 4452 6016 4010 5500 4047 5196 4116 4681 3959
1.26 30.75 6772 4622 6432 4300 5951 4323 5419 4421 4872 4181
MCW800
1.14 5.53 7700 5665 7220 5432 6705 5120 6170 5247 5478 4942
1.44 8.83 8296 5621 7520 5354 7177 5293 6481 5387 6072 5161
1.74 12.89 8809 6046 8156 5630 7383 5702 7014 5786 6326 5434
2.04 17.72 9061 6237 8634 5810 7989 5896 7315 6017 6617 5656
MCW1000
1.2 6.44 8525 5654 7956 5968 7368 5794 6951 5910 6215 5602
1.5 10.1 9151 6269 8292 5949 7870 5896 7083 5996 6614 5676
1.8 14.49 9731 6588 8981 6100 8113 6182 7696 6342 6910 6080
2.1 19.72 10012 6896 9526 6370 8800 6448 8009 6584 7234 6313
MCW1200
1.56 11.21 10604 7414 9901 7136 9224 6765 8649 6989 7667 6675
1.92 16.98 11321 8096 10186 7610 9710 7491 8708 7623 8176 7009
2.28 23.94 11958 8330 11033 7790 9953 7889 9363 7991 8428 7383
2.64 32.1 12247 8564 11652 7930 10740 8012 9775 8148 8755 7646
NoteS:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
totAL: TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL MCW200F MCW300F MCW400F MCW600F MCW800F MCW1000F MCW1200F
MEDIUM TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.80 0.80 0.80 0.80
LOW TOTAL 0.66 0.60 0.65 0.65 0.68 0.70 0.71
SENSIBLE 0.58 0.55 0.58 0.60 0.62 0.63 0.66

18
Performance Data-Heating
MCW-C
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kpa)
ENTERING AIR: DB21ºC
ENTERING WATER TEMPERATUREºC
40 45 50 55 60 65 70 75 80
WWWWWWWWW
MCW200
0.24 4.5 1560 1970 2380 2790 3190 3600 4020 4420 4830
0.33 7.8 1670 2110 2550 2990 3430 3860 4300 4740 5190
0.42 11.8 1740 2200 2650 3110 3580 4030 4490 4940 5410
0.51 17.3 1790 2260 2730 3190 3670 4140 4610 5080 5550
MCW300
0.36 3.2 2160 2720 3300 3870 4440 5010 5570 6140 6700
0.48 7.4 2410 3050 3690 4330 4970 5600 6230 6880 7520
0.6 10.6 2520 3180 3850 4520 5170 5830 6510 7150 7810
0.72 15.0 2590 3270 3960 4630 5310 6000 6670 7360 8050
MCW400
0.42 5.8 3150 3970 4810 5620 6460 7290 8110 8940 9770
0.6 11.0 3410 4400 5200 6100 7000 7890 8780 9680 10570
0.78 17.3 3550 4500 5430 6470 7300 8240 9180 10120 11040
0.96 24.8 3660 4620 5590 6550 7520 8480 9450 10400 11370
MCW600
0.72 15.0 4510 5710 6900 8090 9280 10460 11650 12840 14030
0.9 26.2 4710 5960 7200 8440 9680 10920 12160 13410 14640
1.08 30.6 4850 6130 7410 8690 9960 11250 12510 13800 15070
1.26 40.0 4960 6270 7570 8870 10180 11480 12790 14090 15400
MCW800
1.14 10.0 6140 7770 9400 11030 12660 14290 15920 17550 19190
1.44 15.0 6400 8120 9820 11520 13220 14920 16620 18330 20030
1.74 21.0 6600 8350 10110 11860 13610 15360 17120 18870 20620
2.04 27.6 6740 8530 10320 12110 13900 15690 17490 19270 21060
MCW1000
1.2 10.9 6860 8700 10530 12370 14210 16050 17880 19720 21560
1.5 16.1 7180 9100 11020 12940 14860 16790 18710 20630 22550
1.8 21.2 7410 9390 11370 13350 15330 17310 19290 21270 23250
2.1 27.0 7580 9600 11630 13660 15680 17700 19730 21770 13740
MCW1200
1.56 17.2 8560 10850 13150 15780 17760 20070 21390 24670 26970
1.92 26.2 9490 11910 14330 16750 19170 21590 24020 26450 28870
2.28 32.6 9780 12280 14780 17270 19770 22270 24760 27260 29750
2.64 43.4 10010 12570 15120 17670 20220 22780 25330 27880 30440
NoteS:
1) THE HEATING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
Heating Capacity Correction Factors:
MODEL MCW200C MCW300C MCW400C MCW600C MCW800C MCW1000C MCW1200C
MEDIUM 0.80 0.78 0.78 0.81 0.83 0.80 0.81
LOW 0.58 0.56 0.57 0.58 0.62 0.60 0.61

19
MCW-H
MODEL
WATER
FLOW
(m³/h)
W.P.D
(kpa)
ENTERING AIR: DB21ºC
ENTERING WATER TEMPERATUREºC
40 45 50 55 60 65 70 75 80
WWWWWWWWW
MCW200
0.12 3.2 430 540 690 830 950 1180 1370 1820 1980
0.18 7.3 530 680 780 940 1160 1360 1800 1980 2180
0.24 12.0 620 760 920 1170 1350 1780 1930 2160 2460
0.36 21.9 800 910 1150 1250 1730 1900 2150 2440 2640
MCW300
0.12 3.7 790 980 1180 1380 1580 1780 1970 2170 2360
0.18 8.2 1000 1240 1490 1740 1990 2240 2490 2740 2980
0.24 13.5 1140 1420 1700 1990 2280 2560 2850 3130 3420
0.36 25.0 1340 1660 1990 2340 2660 3000 3330 3660 3990
MCW400
0.12 5.2 1170 1430 1760 2040 2340 2620 2910 3190 3490
0.18 10.0 1430 1790 2860 2500 2860 3210 3580 3930 4280
0.24 14.8 1610 2010 2410 2790 3210 3600 4030 4420 4820
0.36 29.0 1900 2370 2830 3320 3790 4270 4740 5210 5630
MCW600
0.12 8.2 1570 1980 2380 2760 3140 3570 3990 4370 4770
0.18 14.0 1890 2390 2890 3350 3790 4220 4800 5240 5730
0.24 20.7 2120 2700 3240 3790 4290 4870 5450 5990 6530
0.36 36.0 2520 3200 3850 4540 5180 5860 6530 7120 7830
MCW800
0.12 2.4 1890 2350 2830 3290 3770 4240 4720 5180 5650
0.18 4.8 2270 2840 3400 3970 4540 5100 5660 6240 6800
0.24 7.8 2570 3200 3840 4480 5120 5760 6400 7050 7690
0.36 11.5 3040 3810 4560 5320 6080 6840 7600 8360 9130
MCW1000
0.3 5.5 2070 2600 3290 3800 4360 4790 6070 6440 7430
0.4 8.8 2830 3300 4240 4400 5660 6350 7090 7610 9290
0.5 12.8 3610 4090 5180 5400 6940 7550 9230 9620 10550
0.6 18.5 4060 4900 5290 6340 8510 9370 10150 11300 12380
MCW1200
0.3 6.0 2980 3540 4210 5230 5970 6440 7650 8270 9250
0.4 9.9 3650 4270 5650 6350 7150 7980 9414 10280 11080
0.5 14.6 4300 5200 6490 7580 8490 9400 10900 11900 12980
0.6 20.0 4830 5910 7660 8790 10420 11200 12380 13610 14850
NoteS:
1) THE HEATING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN SPEED MUST
MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
Heating Capacity Correction Factors:
MODEL MCW200H MCW300H MCW400H MCW600H MCW800H MCW1000H MCW1200H
MEDIUM 0.80 0.78 0.78 0.81 0.83 0.80 0.81
LOW 0.58 0.56 0.57 0.58 0.62 0.60 0.61
