McQuay MCW200D User manual

CEILING CONCEALED
Chilled Water Fan Coil Unit
Models: MCW200D MCW800D
MCW300D MCW900D
MCW400D MCW1000D
MCW500D MCW1200D
MCW600D MCW1400D
Technical Manual
Engineered for flexibility and performance.TM
MCWD-2007

1
Nomenclature.............................................................................................................................. 2
Main Features ............................................................................................................................. 3
Specications ............................................................................................................................. 4
Sound Pressure Level................................................................................................................ 6
Performance Data....................................................................................................................... 7
Air Flow vs ESP Table ................................................................................................................ 8
Operating Limits......................................................................................................................... 9
Water Flow vs Pressure Drop Chart ....................................................................................... 10
Outlines and Dimensions ........................................................................................................ 11
Wiring Diagrams ....................................................................................................................... 12
Installation................................................................................................................................. 13
Exploded-view & Part List ....................................................................................................... 15
Guide Specications................................................................................................................ 17
Contents
“McQuay” is a registered trademark of McQuay International. All rights reserved throughout the world.
© 2007 McQuay International.
Bulletin illustrations cover the general appearance of McQuay International products at the time of publication. We reserve the right to change
design and construction specications at any time without notice.
Note: Installation and maintenance are to be performed only by qualied personnel who are familiar with
local codes and regulations, and experienced with this type of equipment.
Caution: Sharp edges and coil surfaces are a potential injury hazard. Avoid contact with them.
Warning: Moving machinery and electrical power hazard may cause severe personal injury or death.
Disconnect and lock off power before servicing equipment.

2
Nomenclature
MCW 200 D- 8 R X F-A A F1 - E
Export
1-100mm Extended Drain Pan
2-200mm Extended Drain Pan
Omitted for Standard Drain Pan
Description of Products:
A-Standard Drain Pan
F-Extended Drain Pan
G-Extended Drain pan+2Way Valve
H-Extended Drain Pan+3Way Valve
I-Standard Drain Pan+2Way Valve
J-Standard Drain Pan+3Way Valve
K-Standard Drain Pan+Controller
L-Extended Drain Pan+Controller
M-Extended Drain Pan+2 Way Valve+Controller
N-Extended Drain Pan+3 Way Valve+Controller
O-Standard Drain Pan+2 Way Valve+Controller
P-Standard Drain Pan+3 Way Valve+Controller
Material of Drain Pan
A-Standard Material
S-Stainless Steel
Power Supply: A-220V/1PH/50Hz
With Filter
Back Rerurn Air Plenum With Bottom Removal Filter
Pipe Connection: R-Right Hand
L-Left Hand(Facing Air Flow)
75Pa External Static Pressure
Design Series: D-4 Rows and 2 Pipes
Nominal Air Flow(CFM)
McQuay Horizontal Ceiling concealed Fan Coil Unit

3
Main Features
General
The new MCW-D FCUs are specically designed to satisfy high cooling capacity application requirement. They
represent one of the most cost effective solutions to provide a comfortable environment for both commercial and
residential applications. Their quiet operation, compact dimensions and particularly low height, make units ideal
for ceiling concealed installation even in buildings with narrow ceiling spaces. Units are standard supplied with
soundproofed suction plenum and air lter. Centrifugal fans, with forward-curved blades, are statically and dynamically
balanced and driven by single-phase motors with three speeds.They feature elegant design, advanced structure,
high efciency, low noise, convenient installation and low maintenance. They are widely used in houses, shopping
malls, hospitals and ofce etc.
Higher Cooling Capacity in High Delta T Application
These units are particularly suitable for high External Static Pressure and high Delta T(chilled water temperature
difference) applications. They can delivery more cooling capacity in high Delta T conditions with the specially designed
fans & motors, coils and excellent combination of them.
Low Chilled Water Pressure Drop
In order to meet even the most demanding customer requirements, the new FCUs adopt the most reasonable
and optimization water circuit design and utilize the national level thermal test room to guarantee both the perfect
performance and a low chilled water pressure drop.
Extra High Air Flow Volume at High ESP
These units can supply more air ow at high ESP. 10 models of MCW-D cover an air ow range from 340 to 2380CMH
at medium speed with ESP of 75Pa in wet coil condition.
Air Filter
All units can provide up to one-inch thick washable lters. Filters are held by a removable metal strip and can be
easily pulled out from the bottom for cleaning or replacement.
High Efciency Heat Exchanger
A boundary layer lm of air adhering to the n surface will insulate the n surface and severely reduces the heat
exchange efciency. McQuay slit n design eliminates this boundary layer of air and creates continuous turbulence
for best heat exchange efciency.
Flexibility
Units are available with left or right hand water connections, which can be easily switched in the eld by changing the
positions of the fan-motor assembly and the supply air ange assembly if required.
Compact Design
The low height design makes this fan coil unit series ideally suited for the tight ceiling concealed installation
Low Noise Design
Enlarged fan wheels design allows lower fan RPM selection for the same external static pressure and airow
requirement. Thereby noise level is signicantly reduced.

4
Specications
General Data
MODEL 200D 300D 400D 500D 600D 800D 900D 1000D 1200D 1400D
AIR FLOW
HIGH
m3/h 332 606 757 894 1154 1446 1622 2115 2455 2748
CFM 195 356 445 526 679 851 954 1244 1444 1616
MEDIUM
m3/h 311 527 709 859 1120 1408 1538 1980 2217 2576
CFM 183 310 417 505 659 828 905 1165 1304 1515
LOW
m3/h 237 331 501 616 770 1096 1201 1465 1569 1870
CFM 139 195 295 362 453 645 706 862 923 1100
TOTAL COOLING CAPACITY
W 2044 3350 4402 5003 6300 8087 9022 10808 11939 13523
BTU/h 6974 11430 15020 17070 21496 27593 30783 36877 40736 46140
SENSIBLE COOLING CAPACITY
W 1224 2150 2897 3450 4502 5468 6428 7710 8898 10084
BTU/h 4176 7336 9885 11771 15361 18657 21932 26307 30360 34407
WATER FLOW RATE
m3/h 0.223 0.341 0.439 0.499 0.632 0.803 0.889 1.067 1.223 1.368
USGPM 0.981 1.500 1.932 2.196 2.781 3.533 3.912 4.695 5.381 6.019
WATER PRESSURE DROP
(COOLING)
KPa 5.7 12.0 24.6 11.1 18.2 15.8 19.9 29.0 22.2 30.3
PSI 0.827 1.740 3.567 1.610 2.639 2.291 2.886 4.205 3.219 4.394
EXTERNAL STATIC PRESSURE
Pa 75 75 75 75 75 75 75 75 75 75
in.wg 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
RATED POWER INPUT W 74 98 107 123 167 268 275 304 501 555
SOUND PRESSURE LEVEL DB(A) 42.9 43.1 45.9 46.2 47.9 50.0 48.8 49.1 53.3 53.0
CONDENSATE DRAIN PIPE R3/4
DIMENSION
LENGTH mm 714 934 1014 1114 1214 1464 1564 1664 1464 1664
WIDTH mm 534 534 534 534 534 534 534 534 599 599
HEIGHT mm 251 251 251 251 251 251 251 251 295 295
PACKING DIMENSION
LENGTH mm 737 957 1037 1137 1237 1487 1587 1687 1487 1687
WIDTH mm 553 553 553 553 553 553 553 553 618 618
HEIGHT mm 276 276 276 276 276 276 276 276 321 321
NET WEIGHT
kg 21 25 29 31 33 44 46 49 53 57
lb 46.2 55 63.8 68.2 72.6 96.8 101.2 107.8 116.6 125.4
GROSS WEIGHT
kg 23 28 32 34 37 48 51 54 58 63
lb 50.6 61.6 70.4 74.8 81.4 105.6 112.2 118.8 127.6 138.6
OPERATING WEIGHT kg 22 26 31 33 35 46 49 52 56 61
Notes:
1.ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2. ALL THE UNITS ARE BEING TESTED UNDER FOLLOWING CONDITION:
a) COOLING: 27°C DB/19.5°C WB INDOOR AND WATER INLET 7°C OUTLET 12°C
b) HEATING: 21°C DB INDOOR AND WATER 60°C INLET.WATER FLOW:SAME WITH COOLING CONDITION.
3. THE NOMINAL AIR FLOW, POWER INPUT AND CAPACITY TEST IS UNDER THE POWER SUPPLY OF 220V/1PH/50HZ.

5
COMPONENTS DATA
MODEL 200D 300D 400D 500D 600D 800D 900D 1000D 1200D 1400D
FAN
TYPE CENTRIFUGAL (BLADE: FORWARD-CURVED)
QUANTITY 1 2 3 4 3
MATERIAL GALVANIZED STEEL
DRIVE DIRECT DRIVE
DIAMETER
mm 160 200
in 6.299 7.875
LENGTH
mm 200 160 200 160 190
in 7.874 6.299 7.874 6.299 7.480
MOTOR
TYPE Split-capacitoR motoR with ball beaRing
NUMBER OF MOTORS 1 2
POWER SUPPLY 220-240V/1/50
IP/INSULATION CLASS IP20/Class B
COIL
TYPE Seamless copper tube mechanically bonded to congurated aluminum n
TESTING PRESSURE Pressure test:3.3MPa for 1 minute; Leakage test:1.6MPa for 5 minutes
TUBE
MATERIAL COPPER
DIAMETER
mm 9.52
in 3/8
THICKNESS
mm 0.3
in 0.012
FIN
MATERIAL ALUMINIUM
THICKNESS
mm 0.11
in 0.0043
FACE AREA
m20.1 0.14 0.16 0.18 0.20 0.25 0.27 0.29 0.25 0.29
ft21.06 1.54 1.71 1.93 2.15 2.70 2.91 3.13 2.70 3.13
ROW 4
FIN PER INCH 11
AIR FILTER
(OPTIONAL) SIZE
LENGTH
mm 502 722 802 902 1002 1252 1352 1452 1252 1452
in 19.76 28.43 31.57 35.51 39.45 49.29 53.23 57.17 49.29 57.17
WIDTH
mm 244 244 244 244 244 244 244 244 244 244
in 9.61 9.61 9.61 9.61 9.61 9.61 9.61 9.61 11.34 11.34
THICKNESS
mm 25 25 25 25 25 25 25 25 25 25
in 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98

6
Sound Pressure Level
NOTES:
1. MICROPHONE POSITION: 1M IN FRONT OF THE UNIT AND 1M BELOW THE VERTICAL CENTER LINE OF THE UNIT.
2. THE SOUND LEVEL IS TESTED UNDER 11.5DBA BACKGROUND NOISE IN A BAFFLE CHAMBER WITH ESP OF 50 PA
AND 75PA.
3. THE NOMINAL AIR FLOW, POWER INPUT AND CAPACITY TEST IS UNDER THE POWER SUPPLY OF 220V/1PH/50HZ.
ESP 50Pa 75Pa
UNIT SPEED
1/1 Octave Sound pressure level(dBA, ref 20μPa) Overall
dB(A)
1/1 Octave Sound pressure level(dBA, ref 20μPa) Overall
dB(A)
63 125 250 500 1k 2k 4k 8k 63 125 250 500 1k 2k 4k 8k
200D
HIGH 18 27 37 39 39 33 24 15 43.4 22 28 37 39 38 33 26 17 43.5
MEDIUM 18 27 35 37 38 32 22 14 42.3 19 30 37 38 38 32 25 16 42.9
LOW 16 24 32 35 34 28 17 12 38.9 16 24 34 35 34 27 19 12 39.6
300D
HIGH 16 29 36 38 38 34 24 15 43.3 18 30 36 38 39 37 33 24 44.1
MEDIUM 16 27 35 37 37 33 23 15 42.1 17 29 35 37 38 36 31 22 43.1
LOW 15 25 32 34 33 29 19 13 38.7 16 28 33 35 36 33 26 17 40.8
400D
HIGH 19 31 40 42 41 38 28 18 46.5 19 32 39 41 41 38 32 25 46.2
MEDIUM 18 31 40 41 40 37 27 17 45.9 19 32 39 41 40 37 29 20 45.9
LOW 17 30 37 39 38 34 23 15 43.4 18 30 37 39 38 35 25 17 43.8
500D
HIGH 21 31 41 42 41 38 29 20 46.9 21 30 40 41 41 38 32 24 46.6
MEDIUM 21 31 40 42 41 38 28 19 46.5 21 31 40 41 40 38 31 23 46.2
LOW 18 29 38 40 39 35 25 16 44.4 20 30 38 40 38 36 28 19 44.6
600D
HIGH 22 31 41 42 43 40 30 20 48.0 24 32 42 42 43 40 32 23 48.3
MEDIUM 22 31 41 42 43 40 30 19 47.6 24 32 42 42 42 39 31 22 47.9
LOW 19 30 38 39 40 37 26 15 44.7 23 31 40 41 41 37 28 19 46.2
800D
HIGH 24 34 43 47 45 41 31 24 50.5 24 35 43 47 44 41 33 27 50.4
MEDIUM 23 33 43 46 44 40 31 24 50.1 23 35 43 46 44 41 33 26 50.0
LOW 22 32 41 45 43 39 29 21 48.6 23 34 42 45 43 39 31 24 49.1
900D
HIGH 22 35 43 44 43 40 31 21 49.0 23 36 44 44 43 40 31 20 49.2
MEDIUM 22 35 42 44 43 40 30 20 48.6 23 35 43 44 43 40 31 20 48.8
LOW 21 33 40 42 41 38 28 17 46.7 22 35 42 42 41 38 29 18 47.4
1000D
HIGH 24 36 43 43 45 39 31 21 49.2 25 35 43 43 45 40 31 21 49.4
MEDIUM 24 36 43 43 44 39 31 21 49.0 23 36 43 43 44 39 31 20 49.1
LOW 22 35 41 42 42 36 28 18 47.1 23 34 41 42 43 37 29 18 47.4
1200D
HIGH 28 35 45 48 51 44 37 29 53.9 29 35 46 48 51 45 37 30 54.0
MEDIUM 26 34 44 47 50 43 36 28 53.2 26 34 45 47 50 44 36 29 53.3
LOW 23 31 40 44 46 39 30 22 49.5 27 31 41 45 47 39 31 22 49.9
1400D
HIGH 27 38 45 47 50 45 41 36 53.7 27 39 45 47 50 45 41 36 53.6
MEDIUM 26 38 44 46 50 44 40 35 53.1 27 38 45 46 49 44 40 35 53.0
LOW 23 34 41 43 46 41 36 29 49.6 24 36 41 44 47 41 37 30 50.3

7
Cooling Capacity ( The table below is an example)
Performance Data
NOTES:
1. COOLING CAPACITY AND HEATING CAPAITY ARE GIVEN WITH ESP OF 75PA AT MEDIUM SPEED.
2. COOLING CAPACITY IS BASED ON 5.5°C ENTERING WATER TEMPERATURE AND 14.5°C LEAVING WATER TEM-
PERATURE.
ON COIL CONDITIONS ARE SHOWN IN THE TABLES
3. HEATING CAPACITY IS BASED ON 21°C ENTERING AIR TEMPERATURE(DB) AND 60 °C ENTERING WATER TEM-
PERATURE WITH THE SAME AMOUNT OF WATER FLOW VOLUME AS COOLING
4. CAPACITY UNDER DIFFERENT ENTERING WATER TEMPERATURE AND SPEED CAN BE DERIVED BY SELECT
SOFTWARE.
Model ESP Entering air
Temperature(°C)
Water
Temperature(°C) Cooling Capacity (kw) Water ow Water Pressure Drop
(Pa) DB WB In Out Total Sensible m3/h kPa
MCW200D 75 24.0 17.9 5.5 14.5 1.5 1.0. 0.167 3.5
MCW300D 75 24.0 17.9 5.5 14.5 2.7 1.8 0.270 8.0
MCW400D 75 24.0 17.9 5.5 14.5 3.4 2.4 0.344 15.8
MCW500D 75 24.0 17.9 5.5 14.5 3.8 2.7 0.389 7.2
MCW600D 75 24.0 17.9 5.5 14.5 5.0 3.7 0.482 11.4
MCW800D 75 24.0 17.9 5.5 14.5 6.2 4.6 0.618 10.0
MCW900D 75 24.0 17.9 5.5 14.5 6.9 5.0 0.685 12.7
MCW1000D 75 24.0 17.9 5.5 14.5 8.3 6.2 0.825 21.0
MCW1200D 75 24.0 17.9 5.5 14.5 8.8 7.1 0.899 12.9
MCW1400D 75 24.0 17.9 5.5 14.5 10.0 7.8 1.031 18.4
Model ESP Entering air
Temperature(°C)
Water
Temperature(°C) Cooling Capacity (kw) Water ow Water Pressure Drop
(Pa) DB WB In Out Total Sensible m3/h kPa
MCW200D 75 27.0 19.5 5.5 14.5 2.1 1.3 0.223 5.7
MCW300D 75 27.0 19.5 5.5 14.5 3.4 2.2 0.341 12.0
MCW400D 75 27.0 19.5 5.5 14.5 4.4 2.9 0.439 24.6
MCW500D 75 27.0 19.5 5.5 14.5 5.0 3.4 0.499 11.1
MCW600D 75 27.0 19.5 5.5 14.5 6.3 4.5 0.632 18.2
MCW800D 75 27.0 19.5 5.5 14.5 8.0 5.7 0.803 15.8
MCW900D 75 27.0 19.5 5.5 14.5 8.9 6.2 0.889 19.9
MCW1000D 75 27.0 19.5 5.5 14.5 10.8 7.7 1.067 29.0
MCW1200D 75 27.0 19.5 5.5 14.5 11.7 8.9 1.223 22.2
MCW1400D 75 27.0 19.5 5.5 14.5 13.1 9.7 1.368 30.3

8
Air Flow vs ESP Table
Model Fan Speed
Air Flow (m3/h) at ESP (Pa)
20 30 40 50 60 70 75 80 90 100
200D
H555 527 501 466 428 354 332 322 285 245
M519 468 441 399 363 323 311 297 259 211
L406 380 347 307 282 248 237 211 192 177
300D
H868 822 777 732 679 624 606 562 505 408
M807 762 720 670 618 565 527 511 448 350
L601 549 515 446 403 359 331 310 259 213
400D
H1088 1026 969 920 844 778 757 711 649 579
M1009 942 895 848 791 735 709 670 602 526
L673 645 617 587 565 484 501 449 397 349
500D
H1230 1159 1105 1046 985 919 894 837 763 659
M1201 1149 1083 1009 949 892 859 821 742 655
L842 806 766 722 675 632 616 570 508 424
600D
H1551 1501 1439 1345 1273 1213 1154 1142 1061 945
M1448 1401 1323 1263 1208 1145 1120 1080 1000 895
L848 846 841 827 809 782 770 742 692 623
800D
H1959 1890 1813 1656 1554 1453 1446 1329 1248 1183
M1947 1867 1783 1651 1536 1420 1408 1347 1241 1120
L1496 1413 1365 1281 1233 1143 1096 1088 1002 892
900D
H2197 2113 2027 1920 1795 1683 1622 1560 1455 1325
M2078 1994 1902 1814 1685 1586 1538 1477 1370 1247
L1525 1474 1423 1375 1311 1241 1201 1169 1048 940
1000D
H2663 2594 2502 2400 2304 2189 2115 2055 1913 1741
M2536 2466 2377 2283 2193 2031 1980 1915 1802 1661
L1655 1644 1636 1609 1570 1498 1465 1435 1352 1245
1200D
H2784 2715 2656 2605 2545 2475 2455 2422 2358 2267
M2421 2394 2365 2322 2283 2235 2217 2196 2146 2081
L1636 1632 1622 1615 1592 1580 1569 1536 1518 1493
1400D
H3144 3067 3016 2939 2876 2812 2748 2735 2639 2556
M2830 2794 2758 2709 2662 2605 2576 2555 2489 2419
L1977 1962 1948 1927 1904 1876 1870 1834 1808 1766
NOTES:
1. AIR FLOW IS IN DRY COIL CONDITIONS.
2. CORRECTION FACTORS FOR AIR FLOW IN WET COIL CONDITIONS:
3. THE NOMINAL AIR FLOW, POWER INPUT AND CAPACITY TEST IS UNDER THE POWER SUPPLY OF 220V/1PH/50HZ.
Model 200D 300D 400D 500D 600D 800D 900D 1000D 1200D 1400D
Factor 0.93 0.93 0.88 0.93 0.89 0.95 0.94 0.85 0.95 0.93

9
Operating Limits
OPERATING LIMITS
Maximum water-side pressure 16 bar
Minimum entering water temperature 3°C
Maximum entering water temperature 95°C
Minimum air inlet temperature 5°C
Maximum air inlet temperature 43°C
Power supply 220-240V/ 1Ph / 50Hz

10
Water Flow vs Pressure Drop Chart
Water Pressure Drop Curves
0
10
20
30
40
50
60
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
Water Flow (m3/h)
Water Pressure Drop (kPa)
400D
300D
200D
600D
500D
900D
800D
1400D
1200D
1000D
Note:
The pressure drop is for the coil only and excludes water connections and valves.

11
Outlines and Dimensions
15 15
WATER SUPPLY
CONNECTION Rc 3/4
WATER RETURN
CONNECTION Rc 3/4
CONDENSATE
DRAIN R 3/4
6-R5*16
MOUNTING HOLES
FILTER
TERMINAL BOX
FAN MOTOR
FAN
38 187 190
D
E
F
G
H
I
20
262
131
K
J
25
24
A(A1)
B 46
C
a
MODEL A A1 B C D E F G H I J K Fan No.
Filters
Size Qty
200D 714 814 484 448 487 547 534 150 251 105.5 143 218 1 502x244x25 1
300D 934 1034 704 668 707 767 534 150 251 105.5 143 218 2 722x244x25 1
400D 1014 1114 784 748 787 847 534 150 251 105.5 143 218 2 802x244x25 2
500D 1114 1214 884 848 887 947 534 150 251 94 143 218 2 902x244x25 2
600D 1214 1314 984 948 987 1047 534 150 251 94 143 218 2 1002x244x25 3
800D 1464 1564 1234 1198 1237 1297 534 150 251 94 143 218 3 1252x244x25 3
900D 1564 1664 1334 1298 1337 1397 534 150 251 94 143 218 3 1352x244x25 3
1000D 1664 1764 1434 1398 1437 1497 534 150 251 94 143 218 4 1452x244x25 3
1200D 1464 1564 1234 1198 1237 1297 599 200 295 94 193.8 262 3 1252x288x25 3
1400D 1664 1764 1434 1398 1437 1497 599 200 295 94 193.8 262 3 1452x288x25 3
Notes:
1. All dimensions are in mm;
2. Allstandardunitsarewithbackairplenumandbottomremovallters;
3. A1 is the dimension for 100mm extended drain pan units;
4. Left hand coil connection shown;
5. Wiring connection side is the same as coil and drain connections.

12
Electrical wiring connection must be done according to the following wiring diagram. The unit must be GROUNDED
to the earth system of the building. All eld wiring must be installed in accordance with the national wiring regulation
and Fire Department regulation.
Wiring Diagrams
Note:
For MCWD series, (H. M. L.) are connected to (SHF. HF. MF.) respectively.
MODEL: MCW 200~1400
POWER
SOURCE
ORANGE
DRAWING NO.:M08024067082
N
L
MF
LF
SHF
HF
L
M
BROWN
H
YELLOW
FAN
BLACK
FAN SPEED
SWITCH
NOTE:
MOTOR
1BLACK
FAN MOTOR
CAPACITOR
MOTOR CAPACITOR
2BLACK
FAN MOTOR
BLACK
FAN
RED
RED
YELLOW
BROWN
ORANGE
BLUE
BLUE
HF: HIGH SPEED
MF: MEDIUM SPEED
LF: LOW SPEED
SHF: SUPER HIGH SPEED
FIELD WIRING
FAN MOTOR2 APPLY TO 800~1400 UNITS
50~60Pa UNITS: (H,M,L) CONNECT TO (HF,MF,LF)
70~80Pa UNITS: (H,M,L) CONNECT TO (SHF,HF,MF)

13
Installation
RECEIVING
All units leaving the McQuay plant have been inspected to ensure the shipment of high quality products
and reasonable means are utilized to properly pack the fan coil units to protect them in transit.
Carefully inspect all shipments immediately upon delivery. When damage is visible, note this fact on the
carrier’s freight bill and request that the carrier sends a representative to inspect the damage. This may be
done by telephone or in person, but should always be conrmed in writing.
The shipment should be unpacked in the presence of the agent so that the damage or loss can be
determined. The carrier’s agent will make an inspection report and a copy will be given to the consignee for
forwarding to the carrier with a formal claim.
LOCATION
Before installation, please check the following:
1. There must be enough space for unit installation and maintenance. Please refer to the unit’s drawings and
dimensions and g.1 for the minimum distance between the unit and obstacle.
2. Please ensure enough space for piping connection and electrical wiring.
3. Please make sure that the hanging rods can support weight of the unit.
INSTALLATION
1. The unit is designed for concealed ceiling installation.
2. There are holes on the top of the unit for hanging. Please refer to Fig.1. Fig.2 and Fig.3.
3. Make sure that the top of the unit is level.
INSULATION
1. Use proper insulation material only.
2. Chilled water pipes and all parts on the pipes should be insulated.
3. It is also necessary to insulated air ducted.
4. Adhesive for insulation should work under range 0°F (-18°C) to 200°F (93.3°C).
CEILING
OBST ACLE OBST ACLE
A 200mm B 400mm C 400mm
Fig. 1

14
Fig.3 DETAIL A:
FAN COIL
NUT
EXPANSION SCREW
HANGING ROD
FLAT WASHER
:$7(5,1/(7
:+(13 , 3, 1* 
:$7 (5 2 8 7 /( 7
&211(&7 25  : ,7 +  7, *+ 7  )2 5 & (
&$87, 2 1
%(&$5( )8 /  12 7  72 ' $ 0 $* (  7+ ( 
Terminal block
Ceiling access panel
ceiling
Fig. 2 WITH AND WITHOUT PLENUM FORM:
Discharge air Return air
AIR DUCT CONNECTION
1. Circulatory air pressure drop should be within External Static Pressure
2. Galvanized steel air ducts are suitable.
3. Make sure there is no leak of air.
4. Air duct should e reproof, refer to concerned country national and local regulations.
PIPE CONNECTION
1. Using suitable ttings as water pipe connections. Refer to the specication.
2. The water inlet is on the bottom while outlet on top.
3. The connection must be concealed with rubberized fabric to avoid leakage.
4. Drainpipe can be PVC or steel.
5. The suggested slope of the drainpipe is at least 1:50.
WIRING
1. Wiring connection must be done according to the wiring diagram on the unit.
2. The unit must be GROUNDED well.
3. An appropriate strain relief device must be used to attach the power wires to the terminal box.
4. A 7/8” knockout hole is designed on the terminal box for eld installation of the strain relief device.
5. Field wiring must be complied with the national security regulations.

15
Exploded-view & Part List
8.FAN
6.FILTER
7.MOTOR
2.FANDECK
4.PLENUM
1.TOP PLATE
3.DRAIN GUIDE PLATE
5.COIL
9.DRAIN PAN
10. HEDER OUTLET
11. HEADER NLET

16
MODEL 200D 300D 400D 500D 600D
1TOP PLATE PART NO. M01014060791 M01014060792 M01014060793 M01014060795 M01014060860
2FAN DECK PART NO. M01014060801 M01014060802 M01014060803 M01014060805 M01014060804
3DRAIN GUIDE PLATE PART NO. M01014060811 M01014060812 M01014060813 M01014060815 M01014060890
4PLENUM PART NO. M50014060111 M50014060112 M50014060113 M50014060115 M50014060114
5COIL PART NO. M50024060000 M50024060001 M50024060002 M50024060052 M50024060050
6FILTER PART NO. M03084066140 M03084066141 M03084066142 M03084066143 M03084066144
7MOTOR PART NO. YDK36-4Be
M03034065200
YSK56-4B4
M03034065201
YSK71-4B4
M03034065202
YSK100-4B4
M03034065203
YSK150-4B6
M03034065204
7MOTOR PART NO. \\\\\
8FAN,CENTRIFUGAL M03029000980 M03024060001 M03029000980 M03029000980 M03029000980
8FAN,CENTRIFUGAL \ M03024060002 M03029000981 M03029000981 M03029000981
9DRAIN PAN STD M50014063167 M50014063831 M50014063169 M50014063689 M50014063170
9DRAIN PAN ETD100 M50014063738 M50014063746 M50014063740 M50014063745 M50014063741
9DRAIN PAN ETD200 M50014063001 M50014063009 M50014063003 M50014063004 M50014063005
10 HEADER,OUTLET M02124061141 M02124061141 M02124061141 M02124061097 M02124061097
11 HEADER,INLET M02124061142 M02124061142 M02124061142 M02124061198 M02124061198
MODEL 800D 900D 1000D 1200D 1400D
1TOP PLATE PART NO. M01014060796 M01014060797 M01014060798 M01014060796 M01014060798
2FAN DECK PART NO. M01014060806 M01014060807 M01014060808 M01014060809 M01014060810
3DRAIN GUIDE PLATE PART NO. M01014060816 M01014060817 M01014060818 M01014060816 M01014060818
4PLENUM PART NO. M50014060116 M50014060117 M50014060118 M50014060119 M50014060120
5COIL PART NO. M50024060054 M50024060055 M50024060007 M50024060060 M50024060061
6FILTER PART NO. M03084066145 M03084066146 M03084066147 M03084066148 M03084066149
7MOTOR PART NO. YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
YSK240-4B8
M03034065206
YSK280-4B8
M03034065208
7MOTOR PART NO. YDK71-4B4
M03034065205
YDK71-4B4
M03034065205
YSK150-4B6
M03034065204
YDK95-4B6
M03034065207
YDK125-4B6
M03034065209
8FAN,CENTRIFUGAL M03034065204 M03034065204 M03024060001 M03024060003 M03024060003
8FAN,CENTRIFUGAL M03034065205 M03034065205 M03024060002 M03024060004 M03024060004
9DRAIN PAN STD M50014063171 M50014063172 M50014063832 M50014063171 M50014063832
9DRAIN PAN ETD100 M50014063742 M50014063743 M50014063747 M50014063742 M50014063747
9DRAIN PAN ETD200 M50014063006 M50014063007 M50014063010 M50014063006 M50014063010
10 HEADER,OUTLET M02124061099 M02124061099 M02124061099 M02124061138 M02124061138
11 HEADER,INLET M02124061100 M02124061100 M02124061100 M02124061139 M02124061139

17
Unit Description
Factory-assembled, horizontal, blow-thru type, galvanized casing, ceiling ducted fan coil unit is complete with water
coil, fans, motors, drain pan, lters and all required wiring, with full access to internal components.
Quality Assurance
Each coil is factory tested for leakage at 3.3MPa air pressure with coil submerged in water. Each unit and its moving
components (fans and motors) are factory computer-tested and recorded after unit is complete and before it is
packed.
Component Specications
1. Casing
Construction is of 0.8mm thickness galvanized steel, lined on the inside with 5mm PE thermal and acoustical
insulation. Return air plenum is lined with 5mm PE foam and has a 20mm collar for return duct connection. Supply
duct connection also has a 20mm long collar. Removable bottom panel is provided for access to the fan/motor
assembly.
2. Coil
Standard unit is equipped with a 4-row coil for installation in a 2-pipe system. Coil has 3/8 inch seamless copper
tubes, slit type aluminum blue ns bonded to the tubes by mechanical expansion. Each coil has a manual air vent
and two Rc3/4 water pipe connections with a working pressure of 1.6MPa.
3. Fan
Direct-driven centrifugal fan wheel has forward-curved blades which are statically and dynamically balanced. The fan
housing and blades are constructed of high quality hot-galvanizing steel.
4.Motor
Fan motor is 3-speed, 220V-240V, single-phase, 50Hz, permanent split-capacitor type with ball type bearing and
build-in automatic reset thermal overload protection. The motor’s insulation is class B.
5. Drain pan
The drain pan plate body is constructed of cold-rolled steel by way of integral cupping. Both its sides are sprayed
with plastic coating. And its outer wall is lined with 6mm heat insulating PE foam and high quality adhesive by way
of integral adhering and pressing. It extends under the full length and width of the coils and is pitched for positive
drainage with features of high anti-corrosion, anti-condensation and high re reluctance.
6. Filter
Filter is with washable type double-layer nylon media in 25mm thickness aluminum frame.
Guide Specications

©2007 McQuay International [phone] www.mcquay.com
While utmost care is taken in ensuring that all details in the publication are correct at the time of going
to press, we are constantly striving for improvement and therefore reserve the right to alter model
specications and equipment without notice.
Details of specications and equipment are also subject to change to suit local conditions and requirements
and not all models are available in every market.
ISO 9001-2000
