McQuay MCW200DA User manual

Ceiling Concealed
Chilled Water Fan Coil Unit
Models: MCW200DA MCW900DA
MCW300DA MCW1000DA
MCW400DA MCW1200DA
MCW500DA MCW1400DA
MCW600DA MCW1600DA
MCW800DA
Technical Manual
Engineered for flexibility and performance.TM
MCW-DA-2009

1
Nomenclature..............................................................................................................................2
Main Features .............................................................................................................................3
Specication ...............................................................................................................................4
Sound Pressure Level................................................................................................................6
Performance Data.......................................................................................................................7
Air Flow vs ESP Table................................................................................................................8
Operating Limit...........................................................................................................................9
Water Flow vs Pressure Drop Chart.......................................................................................10
Outline and Dimension ............................................................................................................ 11
Wiring Diagram.........................................................................................................................12
Installation.................................................................................................................................13
Exploded-view & Part List .......................................................................................................15
Optional.....................................................................................................................................17
Guide Specications................................................................................................................18
Contents
“McQuay” is a registered trademark of McQuay International. All rights reserved throughout the world.
© 2009 McQuay International.
Bulletin illustrations cover the general appearance of McQuay International products at the time of publication. We reserve the right to change
design and construction specications at any time without notice.
Note: Installation and maintenance are to be performed only by qualied personnel who are familiar with
local codes and regulations, and experienced with this type of equipment.
Caution: Sharp edges and coil surfaces are a potential injury hazard. Avoid contact with them.
Warning: Moving machinery and electrical power hazard may cause severe personal injury or death.
Disconnect and lock off power before servicing equipment.
Literature No.: TM-MCWDA-0901A
Supersedes: TM-MCWDA-0708A
Part No.: M08039110019

2
Nomenclature
MCW 200 DA 8 R X F A A F1 E
Export
1-100mm Extended Drain Pan
2-200mm Extended Drain Pan
Omitted for Standard Drain Pan
Description of Products:
A-Standard Drain Pan
F-Extended Drain Pan
Material of Drain Pan
A-Coated Cold Rolled Steel
S-Stainless Steel
Power Supply: A-220-240V/1PH/50Hz
F 8mm Nylon Filter
G 25mm Nylon Filter
H 25mm Aluminium Filter
Back Rerurn Air Plenum With Bottom Removal Filter
Pipe Connection: R-Right Hand
L-Left Hand(Facing Air Flow)
75Pa External Static Pressure
Design Series: DA-4 Rows and 2 Pipes
Nominal Air Flow(CFM)
McQuay Horizontal Ceiling Concealed Fan Coil Unit

3
Main Features
General
The new MCW-DA FCUs are specically designed to satisfy high cooling capacity application requirement. They
represent one of the most cost effective solutions to provide a comfortable environment for both commercial and
residential applications. Their quiet operation, compact dimensions and particularly low height, make units ideal
for ceiling concealed installation even in buildings with narrow ceiling spaces. Units are standard supplied with
soundproofed suction plenum and air lter. Centrifugal fans, with forward-curved blades, are statically and dynamically
balanced and driven by single-phase motors with three speeds.They feature elegant design, advanced structure,
high efciency, low noise, convenient installation and low maintenance. They are widely used in houses, shopping
malls, hospitals and ofce etc.
Higher Cooling Capacity in High Delta T Application
These units are particularly suitable for high External Static Pressure and high Delta T(chilled water temperature
difference)applications.Theycandelivery more cooling capacityinhighDeltaTconditions with the speciallydesigned
fans & motors, coils and excellent combination of them.
Low Chilled Water Pressure Drop
In order to meet even the most demanding customer requirements, the new FCUs adopt the most reasonable and
optimized water circuit design and utilize the National accredited thermal test room to guarantee both the perfect
performance and a low chilled water pressure drop.
Extra High Air Flow Volume at High ESP
These units can supply more air ow at high ESP. 11 models of MCW-DA cover an air ow range from 200 to 1600
CFM at medium speed with ESP of 75Pa.
High Efciency and Energy Saving
A boundary layer lm of air adhering to the n surface will insulate the n surface and severely reduces the heat
exchange efciency. McQuay slit designed and HYDROPHILIC BLUE FIN eliminates this boundary layer of air and
creates continuous turbulence for best heat exchange efciency.
Flexibility
Units are available with left or right hand water connections, which can be easily switched in the eld by changing the
positions of the fan-motor assembly and the supply air ange assembly if required.
Compact Design
The low height design makes this fan coil unit series ideally suited for the tight ceiling concealed installation
Low Noise Design
Enlarged fan wheels design allows lower fan speed selection for the same external static pressure and airow
requirement. Thereby noise level is signicantly reduced.
Powerful Selection Software
Powerful select software makes various conditions selection precise and cost saving.

4
Specication
General Data
NOTES:
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) THE PERFORMANCE DATA ARE BASED ON THE FOLLOWING CONDITIONS:
A) COOLING: 24°C DB/18°C WB INDOOR AND WATER INLET 5.5°C OUTLET 14.5°C.
B) MEDIUM SPEED,75PA ESP.
C) 220V/1PH/50HZ.
3) ALL THE DIMENSIONSARE FOR THE UNITS WITH STANDARD DRAIN PAN. TO GET DIMENSIONS FOR UNITS
WITH EXTENDED DRAIN PAN, PLEASE INCREASE THE ABOVE LENGTH VALUES ACCORDINGLY.
4) WHEN THE WATER CONNECT DIRECTION IS CHANGED IN FIELD,THE CAPACITY SHOULD BE REDUCED BY 6%.
MODEL 200DA 300DA 400DA 500DA 600DA 800DA 900DA 1000DA 1200DA 1400DA 1600DA
NOMINAL
AIR FLOW
Hm3/h 348 446 665 831 923 1369 1564 1683 2375 2386 3163
cfm 205 262 391 489 543 805 920 990 1397 1404 1861
Mm3/h 304 399 611 794 868 1296 1514 1631 2208 2381 2974
cfm 179 235 359 467 511 762 891 959 1299 1401 1749
Lm3/h 200 270 446 631 694 1089 1294 1376 1668 1931 2312
cfm 118 159 262 371 408 641 761 809 981 1136 1360
COOLING
CAPACITY
TOTAL W1660 2300 3280 3750 4300 6570 7150 7910 9980 10490 12920
Btu/h 5664 7848 11191 12795 14672 22417 24396 26989 34052 35792 44083
SENSIBLE W980 1400 2040 2580 2850 4490 4870 5480 7360 7880 9960
Btu/h 3344 4777 6960 8803 9724 15320 16616 18698 25112 26887 33984
RATED
POWER
INPUT
HW 84 101 116 148 165 297 299 309 507 603 665
MW 78 92 108 133 154 273 277 290 475 523 607
LW 58 69 92 110 133 225 232 250 407 428 529
RATED
CURRENT
INPUT
HA 0.40 0.48 0.54 0.67 0.81 1.44 1.53 1.58 2.37 2.78 3.10
MA 0.36 0.42 0.49 0.62 0.71 1.25 1.28 1.34 2.17 2.46 2.78
LA 0.28 0.32 0.43 0.54 0.61 1.02 1.06 1.14 1.85 2.04 2.42
WATER FLOW RATE m3/h 0.16 0.22 0.31 0.36 0.41 0.63 0.68 0.75 0.95 1.00 1.23
GPM 0.70 0.97 1.36 1.58 1.80 2.77 2.99 3.30 4.18 4.40 5.41
WATER PRESSURE
DROP KPa 3 6 13 6 8 10 13 11 14 16 20
PSI 0.46 0.87 1.89 0.88 1.16 1.45 1.92 1.60 2.03 2.28 2.90
EXTERNAL STATIC
PRESSURE Pa 75 75 75 75 75 75 75 75 75 75 75
in.wg 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
SOUND PRESSURE
LEVEL dB(A) 42.6 45.6 45.3 46.7 49.2 48.7 48.2 50.3 50.9 50.9 52.9
CONDENSATE DRAIN PIPE Rc3/4
UNIT
DIMENSION
LENGTH mm 677 827 927 997 1097 1427 1537 1727 1427 1527 1827
WIDTH mm 530 530 530 530 530 530 530 530 600 600 600
HEIGHT mm 243 243 243 243 243 243 243 243 297 297 297
PACKING
DIMENSION
LENGTH mm 689 839 939 1009 1109 1439 1549 1739 1439 1539 1839
WIDTH mm 542 542 542 542 542 542 542 542 612 612 612
HEIGHT mm 255 255 255 255 255 255 255 255 309 309 309
NET WEIGHT kg 16 21 22 24 28 39 44 48 51 52 62
lb 36 45 49 54 61 85 96 106 111 115 136
GROSS WEIGHT kg 19 24 25 28 31 43 48 53 55 58 68
lb 41 52 56 61 69 95 106 117 122 127 149
OPERATING WEIGHT kg 17 22 24 26 30 41 47 50 54 54 66

5
Components Data
NOTE:
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL 200DA 300DA 400DA 500DA 600DA 800DA 900DA 1000DA 1200DA 1400DA 1600DA
FAN
TYPE Centrifugal (Blade: Forward-curved)
QUANTITY 1 2 2 2 2 3 4 4 3 3 4
MATERIAL Galvanized Steel
DRIVE Direct Drive
DIAMETER mm 160 160 160 160 160 160 160 160 200 200 200
in 6.30 6.30 6.30 6.30 6.30 6.30 6.30 6.30 7.87 7.88 7.88
LENGTH mm 200 160 200 200 200 200 160 200 190 190 190
in 7.87 6.30 7.87 7.87 7.87 7.87 6.30 7.87 7.48 7.48 7.48
MOTOR
TYPE Split-capacitor Motor With Ball Bearing
NUMBER OF MOTORS 1 2
POWER SUPPLY 220-240V/1ph/50Hz
IP/INSULATION CLASS IP20/Class B
POLES 4
COIL
TYPE Seamless Copper Tube Mechanically Bonded To Corrugated Aluminum Fin
TESTING PRESSURE Pressure Test:3.3mpa For 1 Minute; Leakage Test:1.6mpa For 5 Minutes
TUBE
MATERIAL Copper
DIAMETER mm 9.52
in 3/8
THICKNESS mm 0.3
in 0.012
FIN
MATERIAL Hydrophilic Aluminum
THICKNESS mm 0.11
in 0.0043
FACE AREA m20.09 0.12 0.14 0.16 0.18 0.24 0.26 0.30 0.30 0.33 0.41
ft2141 185 217 242 273 377 409 472 472 511 629
ROW 4
FIN PER INCH 10
INSULATION
COIL TOP
PANEL MATERIAL Fibre Glass
THICKNESS mm 8
OTHER
PANELS MATERIAL PE Foam
THICKNESS mm 5 5 5 5 5 5 5 5 5 5 5
DRAIN
PAN MATERIAL PE Foam
THICKNESS mm 7 7 7 7 7 7 7 7 7 7 7
AIR FILTER
MATERIAL Aluminium Frame Nylon Filter
NUMBER 1 1 2 2 3 3 3 3 3 3 3
SIZE
LENGTH mm 485 665 765 805 905 1235 1375 1535 1252 1337 1637
WIDTH mm 236 236 236 236 236 236 236 236 292 292 292
THICKNESS mm 8 8 8 8 8 8 8 8 8 8 8

6
Sound Pressure Level
NOTES: TEST POINTS ARE AS BELOW:
1) TEST POINTS ARE AS BELOW:
Air Duct
Test Point
1 m
Test
Unit
Back
Return
Plenum
1 m
2) THE SOUND LEVEL IS TESTED UNDER 11.5DBA BACKGROUND NOISE IN A BAFFLE CHAMBER WITH ESP OF 50PA AND 75PA.
ESP 50 Pa 75 Pa
Unit Speed 1/1 Octave Sound pressure level [dB(A),ref 20 uPa] Total
dB(A) 1/1 Octave Sound pressure level [dB(A),ref 20 uPa]Total dB(A)
125 250 500 1k 2k 4k 8k 125 250 500 1k 2k 4k 8k
200DA
H26.1 34.3 37.6 40.4 33.1 22.8 14.1 43.4 24.9 33.9 37.4 40.2 33.6 24.4 15.0 43.3
M27.0 33.4 36.9 39.6 32.1 21.6 13.7 42.7 26.2 33.8 36.4 39.5 32.9 23.5 14.6 42.6
L27.8 29.2 33.5 35.9 28.1 18.1 13.0 39.2 26.6 30.6 34.2 37.2 30.0 20.8 13.7 40.2
300DA
H27.7 35.0 36.5 44.3 36.4 25.4 16.1 46.0 29.2 35.5 37.0 44.7 37.1 26.9 17.5 46.5
M28.3 34.3 35.4 43.1 35.6 24.6 15.5 45.0 29.7 34.5 36.2 43.8 36.1 25.9 16.7 45.6
L27.9 31.2 32.8 40.1 32.2 20.9 14.3 42.0 25.0 32.6 34.2 41.5 34.0 23.6 15.4 43.4
400DA
H26.9 36.7 38.8 42.6 37.8 25.7 14.6 45.7 28.7 36.5 39.2 42.8 38.3 26.2 15.2 46.0
M27.9 35.3 38.2 41.8 36.8 24.6 13.7 44.9 28.2 36.5 38.3 42.1 37.5 25.9 15.0 45.3
L27.3 32.3 35.8 38.4 33.8 20.8 11.4 41.9 27.4 34.3 37.0 40.3 36.3 24.3 14.0 43.7
500DA
H29.7 39.1 40.4 43.9 38.1 29.0 18.3 47.1 30.3 39.3 40.4 43.7 38.3 29.2 18.1 47.1
M28.9 38.7 39.7 43.6 37.9 28.3 17.6 46.8 29.7 38.7 39.9 43.3 37.7 28.7 17.5 46.7
L27.3 36.7 37.8 41.3 35.6 26.2 15.8 44.6 27.3 36.5 38.0 41.5 36.3 27.1 16.2 44.8
600DA
H30.5 40.9 41.8 46.6 42.7 29.8 18.5 49.7 33.2 40.7 42.3 45.8 43.4 29.9 20.5 49.6
M30.8 40.0 41.6 46.1 42.1 29.2 18.3 49.2 30.2 40.5 41.7 46.0 42.1 29.0 17.5 49.2
L31.5 37.5 39.3 43.5 38.8 25.4 15.1 46.6 29.9 38.1 39.8 44.2 40.3 26.9 15.6 47.4
800DA
H34.7 41.1 42.2 45.9 39.8 29.1 19.7 49.1 33.2 40.7 42.3 46.0 40.2 29.9 20.5 49.2
M33.6 40.5 41.9 45.4 39.5 28.8 19.3 48.6 33.4 40.5 41.9 45.5 39.6 29.6 20.0 48.7
L31.7 38.5 40.3 43.9 37.5 26.6 16.8 47.0 32.5 39.0 40.7 44.3 38.3 27.6 18.0 47.5
900DA
H34.1 40.9 42.3 45.7 40.3 29.9 20.6 49.1 35.1 40.9 41.2 45.4 40.0 30.1 20.8 48.7
M34.6 39.8 41.3 45.3 39.8 29.5 20.1 48.5 34.5 40.2 40.9 44.8 39.5 30.0 20.5 48.2
L33.2 38.7 39.9 43.8 38.0 27.7 18.3 47.0 33.4 38.4 39.8 43.8 38.3 28.4 18.9 47.0
1000DA
H33.8 42.5 44.3 47.5 41.2 30.7 20.5 50.7 35.2 41.9 44.4 47.4 41.4 31.1 21.1 50.7
M33.2 41.7 43.9 46.9 40.7 30.0 19.8 50.1 34.0 40.8 44.0 47.3 41.0 31.0 21.3 50.3
L33.2 40.1 42.1 45.3 38.8 28.0 17.3 48.5 33.2 40.1 42.8 45.7 39.6 29.5 19.3 49.0
1200DA
H37.2 44.7 44.1 47.7 42.6 34.0 26.2 51.5 37.4 44.8 44.4 47.9 42.2 33.7 25.6 51.6
M36.1 43.0 43.1 47.2 41.1 32.5 24.6 50.5 37.0 43.7 43.8 47.3 41.5 32.8 24.6 50.9
L34.3 39.9 40.8 43.3 37.2 28.0 19.2 47.1 35.1 41.7 42.0 44.5 38.7 29.6 20.3 48.5
1400DA
H39.2 45.0 43.6 47.7 41.8 33.2 26.5 51.5 39.3 45.5 43.8 47.5 41.6 33.3 26.4 51.5
M37.7 44.7 43.2 47.3 40.9 32.4 25.6 51.0 38.4 44.9 43.1 46.9 41.0 32.6 25.5 50.9
L35.5 41.3 40.2 43.7 37.4 28.4 21.1 47.6 36.4 42.1 40.4 43.7 37.5 28.6 20.9 47.9
1600DA
H41.3 46.1 46.4 51.2 44.1 34.6 27.9 54.1 45.3 45.8 46.0 50.4 43.6 33.7 27.0 54.0
M40.5 45.1 45.7 50.2 42.7 33.2 26.2 53.1 41.6 44.7 45.4 49.8 42.5 32.4 25.5 52.9
L38.2 40.3 42.2 46.0 37.8 27.6 19.8 49.0 43.6 41.2 42.4 46.2 38.4 27.9 20.4 50.1

7
Performance Data
Cooling Capacity (The tables below are two examples)
NOTES:
1) THE FIRST TABLE IS UNDER MEDIUM SPEED,BUT THE SECOND TABLE IS BASED ON THEARI STANDARD 440-2005 IN HIGH SPEED.
2) CAPACITY UNDER DIFFERENT CONDITIONS CAN BE DERIVED BY SELECTION SOFTWARE.
Model ESP Entering air
Temperature( ) Chilled water Temperature( ) Cooling Capacity (kw) Water ow Water Pressure Drop
Pa DB WB In Out Total Sensible m3/h kPa
MCW200DA 75 24 18 5.5 14.5 1.65 0.98 0.16 3
MCW300DA 75 24 18 5.5 14.5 2.30 1.41 0.22 6
MCW400DA 75 24 18 5.5 14.5 3.30 2.04 0.31 13
MCW500DA 75 24 18 5.5 14.5 3.75 2.58 0.36 6
MCW600DA 75 24 18 5.5 14.5 4.30 2.86 0.41 8
MCW800DA 75 24 18 5.5 14.5 6.59 4.50 0.63 10
MCW900DA 75 24 18 5.5 14.5 7.17 4.88 0.68 13
MCW1000DA 75 24 18 5.5 14.5 7.91 5.48 0.75 11
MCW1200DA 75 24 18 5.5 14.5 9.96 6.77 0.83 11
MCW1400DA 75 24 18 5.5 14.5 10.43 7.84 0.98 15
MCW1600DA 75 24 18 5.5 14.5 13.00 9.97 1.23 20
Model ESP Entering air
Temperature(℃)Water Temperature(℃)Cooling Capacity (kw) Water ow Water Pressure Drop
Pa DB WB In Out Total Sensible m3/h kPa
MCW200DA 50 26.7 19.4 7.2 15.6 2.33 1.47 0.24 6
MCW300DA 50 26.7 19.4 7.2 15.6 3.16 2.08 0.32 12
MCW400DA 50 26.7 19.4 7.2 15.6 4.20 2.81 0.43 23
MCW500DA 50 26.7 19.4 7.2 15.6 4.64 3.40 0.47 10
MCW600DA 50 26.7 19.4 7.2 15.6 5.38 3.83 0.55 14
MCW800DA 50 26.7 19.4 7.2 15.6 8.10 5.89 0.83 17
MCW900DA 50 26.7 19.4 7.2 15.6 8.76 6.34 0.89 20
MCW1000DA 50 26.7 19.4 7.2 15.6 9.51 7.03 0.97 16
MCW1200DA 50 26.7 19.4 7.2 15.6 10.39 8.53 1.06 17
MCW1400DA 50 26.7 19.4 7.2 15.6 11.84 9.36 1.21 22
MCW1600DA 50 26.7 19.4 7.2 15.6 15.18 12.36 1.55 30

8
Air Flow vs ESP Table
NOTES:
1) AIR FLOW IS IN DRY COIL CONDITIONS.
2) ESP OUT OF THE RANGE 40-100PA APPLICATION IS NOT RECOMMENDED.
3) FOR MORE AIR FLOW UNDER DIFFERENT CONDITION,PLEASE REFER TO THE SELECTION PROGRAM.
Model fan speed Air ow(m3/h) at ESP(Pa)
40 50 60 70 75 80 90 100
200DA
H468 436 402 367 349 330 292 253
M437 400 362 324 304 285 245 205
L316 285 253 218 201 182 145 105
300DA
H624 578 529 475 446 417 355 289
M581 535 484 429 400 370 306 239
L434 388 342 295 271 247 198 148
400DA
H858 809 755 696 665 633 566 494
M794 748 697 642 612 581 515 445
L595 558 516 470 446 421 367 309
500DA
H1018 970 918 861 831 800 734 664
M977 931 880 824 795 764 700 631
L774 742 703 657 632 605 546 480
600DA
H1167 1106 1038 963 923 882 794 699
M1104 1044 978 906 869 830 748 660
L865 828 782 726 694 660 585 501
800DA
H1662 1587 1506 1417 1369 1320 1216 1104
M1592 1516 1433 1344 1296 1247 1144 1033
L1318 1263 1200 1129 1090 1049 961 865
900DA
H1916 1830 1733 1623 1564 1502 1369 1223
M1863 1778 1681 1573 1515 1453 1321 1178
L1611 1534 1447 1348 1294 1238 1118 986
1000DA
H2047 1952 1850 1740 1683 1623 1498 1366
M1995 1902 1800 1690 1631 1571 1443 1307
L1677 1604 1520 1427 1376 1322 1207 1082
1200DA
H2577 2522 2465 2406 2376 2345 2281 2215
M2379 2334 2286 2235 2209 2182 2126 2066
L1738 1723 1704 1681 1668 1655 1624 1590
1400DA
H2637 2562 2490 2421 2387 2353 2288 2226
M2594 2536 2475 2413 2381 2349 2284 2216
L2059 2027 1992 1953 1932 1910 1863 1813
1600DA
H3464 3384 3299 3210 3164 3116 3018 2916
M3229 3162 3091 3014 2975 2934 2848 2758
L2430 2407 2376 2336 2313 2288 2232 2168

9
Operating Limit
OPERATING LIMITS
Maximum water side pressure 16 Bars
Minimum entering water temperature 3 ℃
Maximum entering water temperature 95 ℃
Minimum air inlet temperature 5 ℃
Maximum air inlet temperature 43 ℃
Power supply 220-240V/1Ph/50Hz

10
Water Flow vs Pressure Drop Chart
NOTE:
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

11
Outline and Dimension
NOTES:
1) ALL DIMENSIONS ARE IN MM;
2) ALL STANDARD UNITS ARE WITH BACK AIR PLENUM AND BOTTOM REMOVAL FILTERS;
3) WHEN SELECT EXTENDED DRAIN PAN,PLEASE ADD THE INCREMENT TO THE LENGTH ACCORDINGLY.
4) RIGHT HAND COIL CONNECTION SHOWN;
5) WIRING CONNECTION SIDE IS THE SAME AS COILAND DRAIN CONNECTIONS.
Model A B C D E F G H I J K L Fan number
MCW200DA 677 452 487 469 522 540 151 143 530 211 243 382 1
MCW300DA 827 592 627 649 702 820 151 143 530 211 243 382 2
MCW400DA 927 692 727 749 802 820 151 143 530 211 243 382 2
MCW500DA 997 772 807 789 842 860 151 143 530 211 243 382 2
MCW600DA 1097 872 907 889 942 960 151 143 530 211 243 382 2
MCW800DA 1427 1202 1237 1219 1272 1290 151 143 530 211 243 382 3
MCW900DA 1537 1302 1337 1359 1412 1420 151 143 530 211 243 382 4
MCW1000DA 1727 1502 1537 1519 1572 1580 151 143 530 211 243 382 4
MCW1200DA 1427 1202 1237 1219 1272 1290 201 194 600 266 297 413 3
MCW1400DA 1527 1302 1337 1319 1372 1390 201 194 600 266 297 413 3
MCW1600DA 1827 1602 1637 1619 1672 1690 201 194 600 266 297 413 4
242
262
131
I
104
14
20 20
16 J
G
28H
K
35
B
C
A
35
44 187
L
D
E
F
WATER SUPPLY Rc3/4
WATER RETURN Rc3/4
MOUNTING HOLES 4-10 x 16
CONDENSATE DRAIN R3/4
AIR VENT VALVE
TERMINAL BOX

12
Electrical wiring connection must be done according to the following wiring diagram. The unit must be GROUNDED
to the earth system of the building. All eld wiring must be installed in accordance with the national wiring regulation
and Fire Department regulation.
Wiring Diagram
NOTE:
FOR MCW DA SERIES, (H. M. L.) ARE CONNECTED TO (SHF. HF. MF.) RESPECTIVELY.
MODEL: MCW 200-1600
POWER
SOURCE
ORANGE
N
L
MF
LF
SHF
HF
L
M
BROWN
H
YELLOW
FAN BLACK
FAN SPEED
SWITCH
NOTE:
MOTOR
1BLACK
FAN MOTOR
CAPACITOR
MOTOR CAPACITOR
2BLACK
FAN MOTOR
BLACK
FAN
RED
RED
YELLOW
BROWN
ORANGE
BLUE
BLUE
HF: HIGH SPEED
MF: MEDIUM SPEED
LF: LOW SPEED
SHF: SUPER HIGH SPEED
FIELD WIRING
FAN MOTOR2 APPLY TO 800~1600 UNITS

13
Installation
Receiving
All units leaving the factory have been inspected to ensure the shipment of high quality products and reasonable
means are utilized to properly pack the fan coil units to protect them in transit.
Carefully inspect all shipments immediately upon delivery. When damage is visible, note this fact on the carrier’s
freight bill and request that the carrier send a representative to inspect the damage. This may be done by telephone
or in person, but should always be conrmed in writing.
The shipment should be unpacked in the presence of the agent so that the damage or loss can be determined. The
carrier’s agent will make an inspection report and a copy will be given to the consignee for forwarding to the carrier
with a formal claim.
Location
Before installation, please check the following:
1. There must be enough space for unit installation and maintenance. Please refer to the outline and dimensions and
g.1 for the minimum distance between the unit and obstacle.
2. In case of installation in free blow, the unit must be installed at a minimum height of 2.5m to avoid contact with the
appliance.
3. Please ensure enough space for piping connection and electrical wiring.
4. Please make sure that the hanging rods can support weight of the unit.
Installation
1. The unit is designed for concealed ceiling installation.
2. There are holes on the top of the unit for hanging. Please refer to Fig.1. Fig.2 and Fig.3.
3. Make sure that the top of the unit is level.
Insulation
1. The insulation design and materials should be complying with local and national codes and regulations.
2. Chilled water pipes and all parts on the pipes should be insulated.
3. It is also necessary to insulate the air duct.
B
CEILLING
OBSTACLE
A
OBSTACLE
≥400mm ≥200mm
DRAIN PIPE
The suggested slope of the
drain pipe is at least 1:50
Fig. 1

14
Fig.3 DETAIL A:
FAN COIL UNIT
NUT
FLAT WASHER
HANGING ROD
EXPANSION SCREW
Detail A
Air Duct Connection
1. Circulatory air pressure drop should be within External Static Pressure.
2. Galvanized steel air ducts are suitable.
3. Make sure there is no leak of air.
4. Air duct should be re-proof, refer to concerned country national and local regulations.
Pipe Connection
1. Using suitable ttings as water pipe connections with reference to the outline and dimensions.
2. The water inlet is on the bottom while outlet on top.
3. The connection must be concealed with rubberized fabric to avoid leakage.
4. Drain pipe can be PVC or steel.
5. Tightening torque should not be too high when connecting water pipes, in order to avoid brass deformation or
water-leakage by torsion split.
6. The suggested slope of the drain pipe is at least 1:50.
Wiring
1. Wiring connection must be done according to the wiring diagram on the unit.
2. The unit must be GROUNDED well.
3. An appropriate strain relief device must be used to attach the power wires to the terminal box.
4. A 7/8” hole is designed on the terminal box for eld installation of the strain relief device.
5. Field wiring must be complied with the national security regulations.
6. Amain switch or other means for disconnection, having a contact separation in all poles, must be incorporated in
the xed wiring in accordance with the relevant local and national legislation.
A
DISCHANGE AIR RETRUN AIR
CEILING ACCESS PANEL
CEILLING WITH AIR RETRUN
L
M
N
NOTE:
Dimension M and N was
determined by air duct design, air
duct should be fire-proof, refer to
concerned country national and
local regulations.
Circulatory air pressure drop should
be approximately equal to the
External Static Pressure.
≥300mm
:$7(5,1/(7
:$7(5287/(7
Fig. 2 WITH AND WITHOUT PLENUM FORM:

15
Exploded-view & Part List
Item Description
1 Motor
2 Top Panel For Air Return Plenum
3 Blower Left
4 Flange top/bottom For Air Return Plenum
5 Filter
6 Flange left/right For Air Return Plenum
7 Filter Cover
8 Bottom Panel For Air Return Plenum
9 Side Panel Right For Air Return Plenum
10 Fan Deck
11 Terminal Box
12 Drain Guide
13 Drain Pan
14 Coil Assy
15 Top Panel
16 Blower Right
17 Side Panel Left For Air Return Plenum

16
MODEL MCW200DA MCW300DA MCW400DA MCW500DA MCW600DA MCW800DA
CLASS B
MOTOR
MOTOR 1 YDK36-4Be
M03034065200 YSK56-4B4 M03034065201 YSK71-4B4 M03034065202 YSK100-4B4 M03034065203 YSK150-4B6 M03034065204 YSK150-4B6
M03034065204
MOTOR 2 \\\\\YDK71-4B4
M03034065205
DRAIN PAN M50014063363 M50014063364 M50014063365 M50014063366 M50014063367 M50014063368
BLOWER LEFT M03029000980 M03024060001 M03029000980 M03029000980 M03029000980 M03029000980
RIGHT \ M03024060002 M03029000981 M03029000981 M03029000981 M03029000981
COIL LEFT HAND M50024065190 M50024065191 M50024065192 M50024065193 M50024065194 M50024065195
RIGHT HAND M50024065180 M50024065181 M50024065182 M50024065183 M50024065184 M50024065185
FILTER 8mm NYLON M03084066197 M03084066198 M03084066199 M03084066200 M03084066201 M03084066202
25mm NYLON M03084066187 M03084066188 M03084066189 M03084066190 M03084066191 M03084066192
MODEL MCW900DA MCW1000DA MCW1200DA MCW1400DA MCW1600DA
CLASS B
MOTOR
MOTOR 1 YSK150-4B6
M03034065204 YSK150-4B6
M03034065204 YSK240-4B8
M03034065206 YSK280-4B8 M03034065208 YSK240-4B8 M03034065206
MOTOR 2 YSK150-4B6
M03034065204 YSK150-4B6
M03034065204 YDK95-4B6
M03034065207 YDK125-4B6 M03034065209 YSK240-4B8 M03034065206
DRAIN PAN M50014063369 M50014063370 M50014063368 M50014063369 M50014063797
BLOWER LEFT M03024060001 M03029000980 M03024060003 M03024060003 M03024060003
RIGHT M03024060002 M03029000981 M03024060004 M03024060004 M03024060004
COIL LEFT HAND M50024065196 M50024065197 M50024065202 M50024065203 M50024065204
RIGHT HAND M50024065186 M50024065187 M50024065199 M50024065200 M50024065201
FILTER 8mm NYLON M03084066203 M03084066226 M03084066204 M03084066205 M03084066206
25mm NYLON M03084066193 M03084066225 M03084066148 M03084066195 M03084066196
NOTE:
LEFT OR RIGHT HAND COIL IS CONSIDERED FACING THE AIR FLOW.

17
1. Drain pan
100mm and 200mm extended cold-rolled steel drain pan and stainless steel drain pan available, meet various
application requirements.
2. Insulation
Aramex Class 0 insulation material ensure more effective thermal and sound insulation together with re-proof
safety.
3. Casing
Anti-corrosion powder coating, looks elegant and more endurable to erosive environment.
4. Filter
25mm nylon lter and 25mm aluminum lter optional.
Different material lter meet various customer requirements.
5. Motor
Class F insulation motor provides reliable operation and suits harder applications.
Optional

18
Unit Description
Factory-assembled, horizontal, blow-thru type, galvanized casing, ceiling ducted fan coil unit is complete with water
coil, fans, motors, drain pan, lters and all required wiring, with full access to internal components.
Quality Assurance
Each coil is factory tested for leakage at 3.3MPa air pressure with coil submerged in water. Each unit and its moving
components (fans and motors) are factory computer-tested and recorded after unit is complete and before it is
packed.
Component Specications
1. Casing
Construction is of 0.8mm thickness galvanized steel, lined inside with 8mm bre glass and 5mm PE thermal and
acoustical insulation. Return air plenum is lined with 5mm PE foam and has a 20mm ange for return duct connection.
Supply duct connection also has a 20mm ange. Removable bottom panel is provided for access to the fan/motor
assembly.
2. Coil
Standard unit is equipped with a 4-row coil for installation in a 2-pipe system. Coil has 3/8 inch seamless copper
tubes, slit type aluminum blue ns bonded to the tubes by mechanical expansion. Each coil has a manual air vent
and two Rc3/4 water pipe connections with a working pressure of 1.6MPa.
3. Fan
Direct-driven centrifugal fan wheel has forward-curved blades which are statically and dynamically balanced. The fan
housing and blades are constructed of high quality hot-galvanizing steel.
4.Motor
Fan motor is 4-speed, 220V-240V, single-phase, 50Hz, permanent split-capacitor with ball type bearing and build-in
automatic reset thermal overload protection. The motor’s insulation is class B, class F optional.
5. Drain pan
The drain pan plate body is constructed of cold-rolled steel by way of integral cupping. Both its sides are sprayed
with plastic coating. And its outer wall is lined with 7mm heat insulating PE foam and high quality adhesive by way
of integral adhering and pressing. It extends under the full length and width of the coils and is pitched for positive
drainage with features of high anti-corrosion, anti-condensation and high re reluctance.
6. Filter
Filter is with washable type double-layer nylon media in 8mm or 25mm thickness aluminum frame or 25mm aluminum
lter.
Guide Specications

©2009 McQuay International [phone] www .mcquay. com
While utmost care is taken in ensuring that all details in the publication are correct at the time of going
to press, we are constantly striving for improvement and therefore reserve the right to alter model
specications and equipment without notice.
Details of specications and equipment are also subject to change to suit local conditions and requirements
and not all models are available in every market.
