MDT SCN-RT1GW.01 User manual

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
1/2015
Technical Manual
MDT
Glass Room Temperature Controller
SCN-RT1GW.01
SCN-RT1GS.01

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
2
1 Content
1 Content................................................................................................................................................. 2
2 Overview............................................................................................................................................... 5
2.1 Overview Devices .......................................................................................................................... 5
2.2 Usage & Areas of Applications ...................................................................................................... 5
2.3 Exemplary circuit diagram............................................................................................................. 6
2.4 Design & Usage.............................................................................................................................. 6
2.5 Functions ....................................................................................................................................... 7
2.7. Starting up .................................................................................................................................... 8
3 Communication objects........................................................................................................................ 9
3.1 Summary and Usage...................................................................................................................... 9
3.1.1 LCD-Display............................................................................................................................. 9
3.1.2 Room temperature controller .............................................................................................. 10
3.1.3 Ventilation Control ............................................................................................................... 15
3.1.4 Key functions ........................................................................................................................ 19
3.2 Default settings of the communication objects .......................................................................... 22
3.2.1 LCD Display ........................................................................................................................... 22
3.2.2 Room Temperature Controller............................................................................................. 22
3.2.3 Lüftungssteuerung................................................................................................................ 24
3.2.4 Key functions ........................................................................................................................ 25
4 General settings.................................................................................................................................. 26
5 Settings LCD-Display ........................................................................................................................... 27
5.1 General ........................................................................................................................................ 27
5.2 LCD-Alarm messages ................................................................................................................... 31
5.3 Display and Operation................................................................................................................. 32
5.3.1 Display in Standby-Mode...................................................................................................... 32
5.3.2 Display of the functional blocks ........................................................................................... 32
5.3.3 Presentation of text messages ............................................................................................. 33

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
3
6 Room Temperature Controller........................................................................................................... 34
6.1 Temperature Measurement........................................................................................................ 34
6.2 Alarm/Messages.......................................................................................................................... 36
6.3 Controller general........................................................................................................................ 38
6.3.1 Controller type ..................................................................................................................... 38
6.3.2 Operating modes & Setpoints .............................................................................................. 39
6.3.2.1 Operating mode - Comfort............................................................................................ 40
6.3.2.2 Operating mode - Night................................................................................................. 40
6.3.2.3 Operating mode - Standby ............................................................................................ 40
6.3.2.4 Operating mode - Frost/Heat protection ...................................................................... 40
6.3.2.5 Priorität der Betriebsarten ............................................................................................ 41
6.3.2.6 Operating mode switchover.......................................................................................... 41
6.3.2.7 Operating mode after reset........................................................................................... 44
6.3.3 Setpoint offset...................................................................................................................... 45
6.3.4 Disable objects ..................................................................................................................... 47
6.3.5 Heating/Cooling request objects.......................................................................................... 48
6.3.6 Guiding ................................................................................................................................. 49
6.3.7 Dead zone............................................................................................................................. 51
6.4 Controller setting......................................................................................................................... 53
6.4.1 Control value ........................................................................................................................ 53
6.4.2 PI control continuous ........................................................................................................... 54
6.4.2.1 Max value of control value............................................................................................ 55
6.4.2.2 Heating/ cooling system................................................................................................ 55
6.4.2.3 Proportional range ........................................................................................................ 55
6.4.2.4 Reset time...................................................................................................................... 56
6.4.2.5 Send control value cyclic ............................................................................................... 56
6.4.3 PI control switching (PWM).................................................................................................. 57
6.4.3.1 PWM cycletime.............................................................................................................. 58
6.4.4 Two-step control (switching)................................................................................................ 59
6.4.4.1 Hysteresis ...................................................................................................................... 60
6.4.5 Direction of controller .......................................................................................................... 61
6.4.6 Additional level..................................................................................................................... 61
6.4.7 Additional settings for heating and cooling ......................................................................... 64
4.5.7.1 - 2 Pipe system .............................................................................................................. 64
6.4.7.2 4 Pipe-System ............................................................................................................. 65
6.4.7.3 Switchover heating and cooling .................................................................................... 67

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
4
7 Ventilation control.............................................................................................................................. 68
7.1 Step switch bit coded .................................................................................................................. 68
7.1.1 Day/Night switchover........................................................................................................... 69
7.1.2 Type of thresholds: Control value & Delta T ........................................................................ 70
7.1.3 Type of thresholds: Manual control only ............................................................................. 72
7.1.4 Behavior at lock .................................................................................................................... 72
7.1.5 Behavior at Init ..................................................................................................................... 73
7.1.6 Sticking protection................................................................................................................ 73
7.1.7 Priority .................................................................................................................................. 73
7.1.8 Status.................................................................................................................................... 74
7.2 Step Switch –binary coded ......................................................................................................... 74
7.3 Step switch simply....................................................................................................................... 75
7.4 Step switch as Byte...................................................................................................................... 75
8 Key functions ...................................................................................................................................... 77
8.1 Buttons grouped.......................................................................................................................... 77
8.1.1 Dimmen ................................................................................................................................ 78
8.1.2 Shutter.................................................................................................................................. 80
8.1.3 Switch ................................................................................................................................... 81
8.2 Buttons separately ...................................................................................................................... 82
8.2.1 Switch ................................................................................................................................... 82
8.2.1.1 Switch on key press ....................................................................................................... 82
8.2.1.2 Toggle on key press ....................................................................................................... 83
8.2.1.3 Send value on key press ................................................................................................ 83
8.2.2 Scene .................................................................................................................................... 84
8.2.3 Switch short/long ................................................................................................................. 86
8.2.4 Toggle Heating/Cooling ........................................................................................................ 89
9 Index ................................................................................................................................................... 90
9.1 List of figures ............................................................................................................................... 90
9.2 List of tables................................................................................................................................. 91
10 Attachment....................................................................................................................................... 93
10.1 Statutory requirements............................................................................................................. 93
10.2 Routine disposal ........................................................................................................................ 93
10.3 Assemblage................................................................................................................................ 93
10.4 Datasheet .................................................................................................................................. 93

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
5
2 Overview
2.1 Overview Devices
The manual refers to the following glass room temperature controller (order number printed in bold
letters):
SCN-RT1GW.01 Glass Room temperature controller, white
oController type: Two-position, PI, PWM
oconfigurable LCD display with automatic brightness adjustment and adjustable alarm
messages
oventilation control controllable by bit, byte or binary coded
o2 keys configurable
SCN-RT1GS.01 Glass Room temperature controller, black
osame functions as before
2.2 Usage & Areas of Applications
The Glass Room temperature controller combines the complex temperature control with the simple
operation on the glass LCD display. For this purpose, 4 buttons and a large LCD display are available.
Two of the four buttons are available for free parameterization by the user; the other two buttons
are used to operate with the display. In addition, the screen can show up to 4 alarms that are
triggered via 1-bit objects, as well as a 14-byte text message.
With the control various control schemes can be realized. Applications range reaches from the room
temperature controlling of a room with heating and / or air conditioning as well as in heating or
cooling systems.
The application program of the room temperature controller allows you to use your device for
"heating.", "cooling." or "heating and cooling-systems". Depending on which function is selected, the
ETS displays various parameters and communication objects. All control functions can be used for
"heating" and / or "cooling" with a "2-point control", a "PWM control" or a "continuous PI control".
In addition, an additional stage for heating control can be used. For a better temperature recording
in larger rooms, a temperature value can be received by a further measuring sensor via the bus. The
received measurement value is incorporated in accordance with a set of weighting in the room
temperature control. The temperature controller works with setpoints, which serve as reference
points for the control. Various setpoints for different operating modes can be parameterized. In
addition, these references can be shifted via communication objects. In addition, the glass room
temperature controller has an integrated ventilation control, which can work with the control value
of the temperature controller or can be controlled manual.

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
6
2.3 Exemplary circuit diagram
Figure 1: Exemplary circuit diagram
2.4 Design & Usage
The following figure provides an overview of the structure and controls:
Figure 2: Design & Usage
1 = Programming button (lateral notch in the housing below the glass)
2 = Button for switching between the functional blocks
3 = Button for specific functions of the function block shown
4 & 5 = Buttons for switching in each functional block
1
2
3
4
5

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
7
2.5 Functions
The functions of the glass room temperature controller are divided into the areas of LCD display,
temperature control, ventilation control and configuration of the keys. In each area, the following
settings can be made:
LCD Display
The presentation and the brightness of the display can be set here. Furthermore the
language of the Display and an inverting of the colors can be set here.
Temperature Controller
The temperature controller is again divided into the following sub-menus:
oTemperature measurement
In this menu, settings for temperature measurements, such as min / max values and
sensor configurations can be parameterized.
oAlarm/Messages
Alarms / messages, which show falling below or exceeding certain temperatures, can be
set here. Also messages, which are shown at the display, can be set here.
oController general
The desired function (Heating and/or Cooling) are set in this menu. Furthermore the
setpoints and operating modes can be set here.
oController settings
If one type of controller is set, the behavior of the manipulated variable can be set here.
The setting options depend on the used controller.
Ventilation Control
The ventilation control allows the control of fans and can be controlled as well manually as
by the current value of the output value or by the difference between setpoint and current
value.
Key function of button C/D
The key function can be set as well grouped as separately. As well switching function as
shutter and dimming functions can be used.

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de
8
2.6. Settings at the ETS-Software
Selection at the product database:
Manufacturer: MDT Technologies
Product family: Control
Product type: Any
Medium Type: Twisted Pair (TP)
Product name: SCN-RT1GW.01
Order number: SCN-RT1GW.01
2.7. Starting up
After wiring the allocation of the physical address and the parameterization of every channel follow:
(1) Connect the interface with the bus, e.g. MDT USB interface
(2) set bus power up
(3) Press the programming button at the device(red programming LED lights)
(4) Loading of the physical address out of the ETS-Software by using the interface(red LED goes
out, as well this process was completed successful)
(5) Loading of the application, with requested parameterization
(6) If the device is enabled you can test the requested functions(also possible by using the ETS-
Software)

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
9
3 Communication objects
3.1 Summary and Usage
3.1.1 LCD-Display
Nr.
Name
Object function
Data type
Direction
Info
Usage
Tip
Objects for LCD-Display:
27
Day/Night
Switching
DPT 1.001
receive
Display responds
to input telegram
Control buttons,
Visu, external
status, Time
Switch
Communication object is
permanently displayed and
used for switching the
backlight of the display
54
Time
Receive status
DPT 10.001
receive
Display responds
to input telegram
Time Switch,
Group
monitor(once),
Visu
Communication object is
permanently displayed and
used to show the right time of
day. Value should be sent
regularly to achieve sufficient
accuracy.
56-
59
Message 1-4
Alarm input fort text
message
DPT 1.001
receive
Display responds
to input telegram
Status objects,
Alarm objects…
Communication object will
appear if alarms are activated
in the Alarms menu. By
receiving a 1, the set message
is shown on the display

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
10
60
Message 14 Byte
Variable text message
DPT 16.000
receive
Display responds
to input telegram
Visu, Control unit,
Tableau
Communication object is
displayed as soon as this
alarms / messages is enabled
in the menu; can display
arbitrary string.
Table 1: Overview communication objects - LCD Display
3.1.2 Room temperature controller
Objects for room temperature controller:
0
Actual temperature
value
Transmit temperature
value
DPT 9.001
send
Controller sends
current
temperature
Visu, Display,
Diagnostic,…
Communication object is
shown permanent and sends
according to the setting its
current value or can only be
read via the bus
1
max. temperature
Exceeded value
DPT 1.001
send
Controller sends
state
Visu, Display,
Diagnostic,…
Communication object is
shown when messages are
active
2
min. temperature
Below the value
DPT 1.001
send
Controller sends
state
Visu, Display,
Diagosti,…
Communication object is
shown when messages are
active
3
Frost alarm
Send alarm
DPT 1.001
send
Controller sends
state
Visu, Display,
Diagnostic,
Additional stage,…
Communication object is
shown when alarms are active

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
11
4
Heat alarm
Send alarm
DPT 1.001
send
Controller sends
state
Visu, Display,
Diagnostic,
Additioal stage,…
Communication object is
shown when alarms are active
5
External sensor
Read external sensor
DPT 9.001
receive
Controller receives
external
temperature
Input for external
temperature
Communication object is
shown when sensor is set to at
least 10% external sensor
6
Setpoint comfort
Set setpoint
DPT 9.001
receive
Controller receives
new absolute
setpoint
Visu, Opereating
keys, Control unit
Object is permanent shown
when the controller is active. A
new setpoint can be set via this
object.
7
Manual setpoint value
offset
Reduction/Increase
DPT 9.002
receive
Controller receives
new setpoint
offset
Visu, Display,
Operating keys,
Control unit
Object is shown when the
setpoint offset via 2 Byte
object is active. The setpoint is
shifted according to the
current setpoint.
8
Control value heating
Send control value
DPT 1.001/
DPT 5.001
send
Controller sends
manipulated value
Heating actuator,
actuators
Object is shown when the
controller is set to heating. The
DPT depends to the controller
type (two-level & PWM –
DPT1.001, PI-DPT5.001).

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
12
8
Control value
heating/cooling
Send control value
DPT 1.001/
DPT 5.001
send
Controller sends
manipulated value
Heating actuator,
actuators
Object is shown when the
controller is set to heating and
cooling. The DPT depends to
the controller type (two-level
& PWM –DPT1.001, PI-
DPT5.001).
9
Control value additional
heating
Send control value
DPT 1.001
send
Controller sends
manipulated value
Heating actuator,
actuators
Object is shown when the
controller is set to heating and
an additional stage is activated.
The DPT depends to the
adjusted controller type (two-
level & PWM –DPT1.001, PI-
DPT5.001).
10
Control value cooling
Send control value
DPT 1.001/
DPT 5.001
send
Controller sends
manipulated value
Heating actuator,
actuators
Object is shown when the
controller is set to cooling. The
DPT depends to the controller
type (two-level & PWM –
DPT1.001, PI-DPT5.001).
11
Mode comfort
Switch mode
DPT 1.001
receive
Controller
switches mode
Visu, Opereating
keys, Control unit
Object is always shown and
switches the operating modes
according to the adjusted
priority.
12
Mode Night
Switch mode
DPT 1.001
receive
Controller
switches mode
Visu, Opereating
keys, Control unit
Object is always shown and
switches the operating modes
according to the adjusted
priority.
13
Mode Frost/Heat
protection
Switch mode
DPT 1.001
receive
Controller
switches mode
Visu, Opereating
keys, Control unit
Wird standardmäßig
eingeblendet. Betriebsart
schaltet in Abhängigkeit der
eingestellten Priorität.

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
13
14
Heating disable object
Disable heating
DPT 1.003
recieve
Controller
diasables heating
Visu, Opereating
keys, Control unit
Can be activated in the settings
when the controller is set to
heating.
15
Cooling disable object
Disable cooling
DPT 1.003
recieve
Controller
diasables cooling
Visu, Opereating
keys, Control unit
Can be activated in the settings
when the controller is set to
cooling.
17
Heating request
Send request
DPT 1.001
send
Controller sends
heating request
Actuator for
switching the
heatig pup…
Can be activated in the settings
when the controller is set to
heating.
18
Cooling request
Send request
DPT 1.001
send
Controller sends
cooling request
Actuator for
switching the
oolig pup…
Can be activated in the settings
when the controller is set to
cooling.
19
Heating/Cooling
switchover
0 = heating, 1 = cooling
DPT 1.001
receive
Controller
switches between
heating and
cooling
Visu, Opereating
keys, Control unit
Can be activated in the
parameter when the controller
is set to heating and cooling.
20
Outside temperature
Read external sensor
DPT 9.001
receive
Controller receives
temperature from
outside sensor
Outdoor
temperature
sensor
Object is shown when the
guiding is activated in the
parameter
21
Max memory value
Read memory
DPT 9.001
send
Controller sends
max. temperature
Visu, Display,
Diagnostic…
Object is shown when the
min/max values are activated
22
Min memory value
Read memory
DPT 9.001
send
Controller sends
min. temperature
Visu, Display,
Diagosti…
Object is shown when the
min/max values are activated
23
Min/Max Memory Reset
Reset memory
DPT 1.001
receive
Controller resets
min/max values
Visu, Opereating
keys, Control unit
Object is shown when the
min/max values are activated

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
14
24
Reset setpoint value
Parameter read in
DPT 1.001
receive
Controller resets
the setpoints to
the values which
are set in the
parameter
Visu, Opereating
keys, Control unit
Object is always shown when
the controller is active
25
DPT_HVAC Status
Send controller status
-
send
Controller sends
current state
Visu, Display,
Diagosti,…
Object is always shown when
the controller is active
28
Error external sensor
Error message
DPT 1.001
send
Controller sends
state
Visu, Display,
Diagosti,…
Object is always shown when
the controller is active
29
Actual setpoint
Send setpoint
DPT 9.001
send
Conntroller sends
current setpoint at
a read request
Visu, Display,
Diagosti,…
Object is always shown when
the controller is active
30
RHCC Status
Send controller status
DPT 22.101
send
Controller sends
current state
Visu, Display,
Diagosti,…
Object is always shown when
the controller is active
31
Mode selection
Select mode
DPT 20.102
receive/
send
Controller
switches between
operating modes
and sends the
current operating
mode if activated
Visu, Operating
keys, Control unit,
Display,
Diagosti, …
Communication object is
permanently displayed when
the controller was activated.
Via the paaete “ed status
o ojet  ode seletio,
the sending of this object can
be activated. So this object can
be directly used by home
servers and visualizations.

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
15
32
Manual setpoint value
offset
Increase/Reduction
(1 = + adjusted step,
0 = - adjusted step)
DPT 1.001
receive
Controller receives
setpoint value
offset via a 1 Bit
object
Visu, Operating
keys, Control unit,
Display,
Diagosti, …
Object is shown when
paaete “etpoit alue
offset ia is set to  Bit ojet
and shifts the set value
depending on the current
setpoint. The amount of
displacement can be set in the
parameters.
Table 2: Overview communication objects - Room Temperature Controller
3.1.3 Ventilation Control
Objects for Ventilation Control:
38
Ventilation Control
Block
DPT 1.003
receive
Controller locks
ventilation control
Visu, Operating
keys, Control unit,
Displa, …
Object is only shown when the
locking function was activated
in the settings
39
Ventilation Control
Level 1
DPT 1.001
send
Controller
switches level 1
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch bit coded
39
Ventilation Control
Bit 0
DPT 1.002
send
Controller
switches Bit 0
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch binary coded

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
16
40
Ventilation Control
Level 2
DPT 1.001
send
Controller
switches level 2
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch bit coded
40
Ventilation Control
Bit 1
DPT 1.002
send
Controller
switches Bit 1
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch binary coded
39
Ventilation Control
Level 1+2
DPT 1.001
send
Controller
switches level 1
und 2
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch simply
41
Ventilation Control
Level 3
DPT 1.001
send
Controller
switches level 3
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch bit coded
41
Ventilation Control
Bit 2
DPT 1.002
send
Controller
switches Bit 2
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch binary coded
41
Ventilation Control
Level 1+2+3
DPT 1.001
send
Controller
switches level 1, 2
und 3
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch simply

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
17
42
Ventilation Control
Level 4
DPT 1.001
send
Controller
switches level 4
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch bit coded
42
Ventilation Control
Level 1+2+3+4
DPT 1.001
send
Controller
switches level 1, 2,
3 und 4
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
step switch simply
43
Ventilation Control
1 Byte Status ventilation
level
DPT 5.010
send
Controller sends
current status
Visu, Operating
keys, Control unit,
Displa, …
Object must be activated in the
settigs  the paaete Use
status ojet  as. Ojet
sends the current level: Value 1
= Leel , Value  = Leel …
43
Ventilation Control
Status for ventilation
active
DPT 1.001
send
Controller sends
current status
Visu, Operating
keys, Control unit,
Displa, …
Object must be activated in the
settigs  the paaete Use
status ojet  as. Oject
sends whether the ventilation
is active or not.
44
Ventilation Control
Control value
DPT 5.001
send
Controller sends
manipulated value
Actuator for
controlling a
ventilation
system, Fan-Coil
actuator
Object is shown at the setting
„“tep sith as Bte
45
Ventilation Control
Object priority
DPT 1.001
receive
Controller receives
incoming telegram
Visu, Operating
keys, Control unit,
Displa, …
Object must be activated in the
settings and can call several
states.

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
18
46
Ventilation Control
Switch automatic
DPT 1.001
send &
receive
Conbtroller
switches between
automatic and
manual mode and
sends its current
value if the value
was toggled at the
display
Visu, Operating
keys, Control unit,
Displa, …
Object is always shown when
the ventilation control is
active.
47
Ventilation Control
Control levels manually
DPT 1.008
receive
Controller
switches controller
level according to
the incoming
telegram, 1 = 1
level up, 0 = 1
level down
Visu, Operating
keys, Control unit,
Displa, …
Object is always shown when
the ventilation control is
active.
Table 3: Overview communication objects - Ventilation Control

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
19
3.1.4 Key functions
Objects for key functions –Buttons grouped:
61
Button C/D
Dimming On/Off
DPT 1.001
send
Display sends
current value
Dimming actuator
Object is shown at the setting
Buttons grouped->Dimming
61
Button C/D
Shutter down/up
DPT 1.008
send
Display sends
current value
Shutter actuator
Object is shown at the setting
Buttons grouped->Shutter
61
Button C/D
Switch On/Off
DPT 1.001
send
Display sends
current value
“ith atuato…
Object is shown at the setting
Buttons grouped->Switch
62
Button C/D
Dimming
DPT 3.007
send
Display sends
current value
Dimming actuator
Object is shown at the setting
Buttons grouped->Dimming
62
Button C/D
Stop/Slats Open/Close
DPT 1.009
send
Display sends
current value
Shutter actuator
Object is shown at the setting
Buttons grouped->Shutter
63
Button C/D
Status dimming value
DPT 5.001
receive
Display receives
current state
Dimming actuator
Object is shown at the setting
Buttons grouped->Dimming
63
Button C/D
Status absolute position
DPT 5.001
receive
Display receives
current state
Shutter actuator
Object is shown at the setting
Buttons grouped->Shutter

Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
20
Objects for key functions –Buttons separately:
61
Button C
Switch
DPT 1.001
send
Display sends
value
“haltakto…
Object is shown at the setting
Buttons separately->Switch-
>Switch/Toggle on key press
61
Button C
Send value
DPT 5.001
send
Display sends
value
Akto…
Object is shown at the setting
Buttons separately->Switch-
>Send value
61
Button C
Short key press
DPT 1.001
send
Display sends
value
Akto…
Object is shown at the setting
Buttons separately->Switch
short/long->On/Off
61
Button C
Short key press
DPT 5.001
send
Display sends
value
Akto…
Object is shown at the setting
Buttons separately->Switch
short/long->Send value
61
Button C
Toggle Heating/Cooling
DPT 1.001
send
Display sends
value
Regler, interne
Veaeitug…
Object is shown at the setting
Buttons separately->Toggle
heating/cooling
62
Button C
Value for toggle
DPT 1.001
receive
Display receives
current state
Akto…
Object is shown at the setting
Buttons separately->all
functions with toggle function;
object must be connected with
the state of the actuator
63
Button C
Scene
DPT 18.001
send
Display sends
value
Akto…
Object is shown at the setting
Buttons separately->Scene
63
Button C
Long key press
DPT 1.001
send
Display sends
value
Akto…
Object is shown at the setting
Buttons separately->Switch
short/long->On/Off
