MDV MOBA30-12CFN1-BP0W User manual

TM_AB_R410A_INV_US_NA_2009
R410A INVERTER CONTROL
TECHNICAL MANUAL

Table of Contents Page
1. Specifications ................................................................................................ 3
1. Model Reference
2. General Specifications
3. Dimensional Drawings
4. Centre of Gravity
5. Electrical Wiring Diagrams
6 Refrigerant Cycle Diagrams
7. Capacity Tables
8. Noise Criterion Curves
9. Electrical Characteristics
2. Product Features ........................................................................................... 49
1. Operation Modes and Functions
2. Remote Controller Functions
3. Installation .................................................................................................... 56
1. Installation Overview
2. Location Selection
3. Indoor Unit Installation
4. Outdoor Unit Installation
5. Refrigerant Pipe Installation
6. Vacuum Drying and Leakage Checking
7. Additional Refrigerant Charge
8. Electrical and Gas Leak Checks
9. Test Operation

Contents
1. Model Reference....................................................................................................4
2. General Specifications...........................................................................................5
3. Dimensional Drawings ........................................................................................11
4. Electrical Wiring Diagrams..................................................................................13
5 Refrigerant Cycle Diagrams ................................................................................20
6. Capacity Tables ....................................................................................................21
7. Noise Criterion Curves.........................................................................................42
8. Electrical Characteristics......................................................................................48
Specifications

Specifications
Page 4 
1. Model Reference
Refer to the following table to determine the specific indoor and outdoor unit model number of your purchased
equipment.
Outdoor Unit Model Indoor Unit Model Capacity (Btu/h) Power Supply
MOBA30-12CFN1-BP0W MSABB-12CRDN1-BP0W 12k
1Φ, 115V~, 60Hz
MOX130-11CFN1-BT0W MSABB-11CRFN1-BT0W 11k
MOBA30-09CFN1-MQ0W MSABA-09CRDN1-MP0W 09k
1Φ, 220~230V~, 60Hz
M0BA30-11CFN1-MQ0W MSABB-12CRDN1-MP0W 12k
MOX130-11CFN1-MT0W MSABB-11CRFN1-MT0W 11k
MOBA30-17CFN1-MR0W MSABD-17CRFN1-MQ0W 18k
MOCA30-22CFN1-MR0W MSABE-22CRDN1-MS0W 22k

Specifications
Page 5 
2. General Specifications
Model MSABB-12CRDN1-BP0W MSABB-11CRFN1-BT0W
Power supply V- Ph-Hz 115-1-60 115-1-60
Max. input consumption W 1679 1850
Max. current A 14.6 16.5
Compressor
Model KSN98D22UFZ KSK103D33UEZ3
Type ROTARY ROTARY
Brand GMCC GMCC
Capacity W 3095 2035/3255
Input W 790 325/826
Rated current(RLA) A 5.3 2.4/5.65
Locked rotor Amp(LRA) A / /
Thermal protector / /
Thermal protector position INTERNAL INTERNAL
Capacitor uF / /
Refrigerant oil/oil charge ml RB74A F/370 VG74/310
Indoor fan motor
Model YKFG-15-4-28-1 ZKFP-20-8-113
Input W 46.0 35.0
Output W 15 20
Capacitor uF 3 /
Speed(Hi/Mi/Lo) r/min 1100/1000/750 1200/1000/750
Indoor coil
Number of rows 2.0 2
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
Fin spacing mm 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 605x210x26.74+605x84x26.74 605x210x26.74+605x84x26.74
Number of circuits 2 2
Indoor air flow (Hi/Mi/Lo)
m3/h 400/350/250 595/496/378
CFM 235/206/147 350/292/222
Indoor sound pressure level dB(A) 38.5/35.5/24.5 40.5/35/26
Indoor unit
Dimension(W*D*H)
mm 802x189x297 802x189x297
inch 31.57x7.44x11.69 31.57x7.44x11.69
Packing (W*D*H)
mm 875x285x380 875x285x380
inch 34.45x11.22x14.76 34.45x11.22x14.96
Net/Gross weight
Kg 8.5/11 8.6/11
lbs. 18.74/24.25 18.96/24.25
Outdoor fan motor
Model ZKFN-34-8-1-3 ZKFN-34-8-1
Input W 58.0 80.0
Output W 34 20
Capacitor uF / /
Speed r/min 960 850/500
Outdoor coil
Number of rows 1.0 1
Tube pitch(a)x row pitch(b) mm 19.5x11.6 14.5x12.56
Fin spacing mm 1.2 1.2
Fin type (code) Unhydrophilic aluminium Unhydrophilic aluminium
Tube outside dia.and type mm Ф5,Inner groove tube Ф5,Inner groove tube
Coil length x height x width mm 760x507x11.6 750x464x12.56
Number of circuits 3 2
Outdoor air flow (Hi/Mi/Lo)
m3/h 2000 1800
CFM 1176 1059
Outdoor sound pressure level dB(A) 51.5 52

Specifications
Page 6 
Outdoor unit
Dimension(W*D*H)
mm 770x300x555 720x270x495
inch 30.31x11.81x21.85 28.35x10.63x19.49
Packing (W*D*H)
mm 900x345x595 835x300x540
inch 35.43x13.58x23.43 32.87x11.81x21.26
Net/Gross weight
Kg 28.3/30.7 23.2/25
lbs. 62.39/67.68 51.15/55.11
Refrigerant type Kg R410A/0.59 R410A/0.65
Design pressure PSIG 550/340 550/340
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ6.35/Φ12.7(1/4"/1/2")
Max. refrigerant pipe length
m25 25
ft 82.02 82.02
Max. difference in level
m10 10
ft 32.81 32.81
Connection wiring 16#x4 16#x4
Plug type 14#x3/no-plug 14#x3/no-plug
Thermostat type Remote Control Remote Control
Operation temperature 17-30 17-30
Ambient temperature
Indoor(cooling/ heating) °C 17-32/- 17-32/-
Outdoor(cooling/heating) °C -15-50/- -15-50/-
Qty’per 20’ /40’ /40’HQ 108/225/234 130/276/302
Notes:
1) Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C(80°F) DB /19.4 °C(67°F) WB Heating: - Indoor Temperature 21.1°C(70°F) DB / 15.6°C(60°F) WB
-Outdoor Temperature 35 °C(95°F) DB /23.9 °C(75°F) WB -Outdoor Temperature 8.3°C(47°F) DB / 6.1°C(43°F) WB
-Interconnecting Piping Length 7.5m - Interconnecting Piping Length 7.5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are net capacities.
3) Due to our policy of innovation some specifications may be changed without notification.

Specifications
Page 7 
Model MSABA-09CRDN1-MS0W MSABB-12CRDN1-MP0W MSABB-11CRFN1-MT0W
Power supply V- Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60
Max. input consumption W 1385 1400 2050
Max. current A 6 7 9.5
Compressor
Model KSK89D29UEZD KSK89D29UEZD KSK103D33UEZ3
Type ROTARY ROTARY ROTARY
Brand GMCC GMCC GMCC
Capacity W 2805 2805 2035/3255
Input W 735 735 325/826
Rated current(RLA) A 5.05 5.05 2.4/5.65
Locked rotor Amp(LRA) A / / /
Thermal protector / / /
Thermal protector position INTERNAL INTERNAL INTERNAL
Capacitor uF / / /
Refrigerant oil/oil charge ml VG74/170 VG74/170 VG74/310
Indoor fan motor
Model YKFG-20-4-10L YKFG-20-4-10L ZKFP-20-8-6-7
Input W 47.4 47.4 50.0
Output W 20 20 20
Capacitor uF 1.5 1.5 /
Speed(Hi/Mi/Lo) r/min 1050/900/700 1150/1000/750 1200/1000/750
Indoor coil
Number of rows 2 2.0 2
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.3 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 525x84x13.37+525x105x26.7
4+525x105x26.74
605x210x26.74+
605x84x26.74
605x210x26.74+
605x84x26.74
Number of circuits 2 2 2
Indoor air flow (Hi/Mi/Lo)
m3/h 410/350/250 476/422/288 550/430/300
CFM 241/206/147 280/248/170 324/253/177
Indoor sound pressure level dB(A) 38/32/26.5 37.5/34.5/24.5 40/34/25
Indoor unit
Dimension(W*D*H)
mm 722x187x290 802x189x297 802x189x297
inch 28.43x7.36x11.42 31.57x7.44x11.69 31.57x7.44x11.69
Packing (W*D*H)
mm 790x270x375 875x285x375 875x285x380
inch 31.10x10.63x14.57 34.45x11.22x14.76 34.45x11.22x14.96
Net/Gross weight
Kg 7.4/9.8 8.2/10.8 8.9/11.5
lbs. 16.31/21.61 18.08/23.81 19.62/25.35
Outdoor fan motor
Model ZKFN-34-8-1-3 ZKFN-34-8-1-3 ZKFN-34-8-1
Input W 58.0 58.0 80.0
Output W 34 34 34
Capacitor uF / /
Speed r/min 850/700 850/700 850/500
Outdoor coil
Number of rows 1.0 1.0 1
Tube pitch(a)x row pitch(b) mm 19.5x11.6 19.5x11.6 14.5x12.56
Fin spacing mm 1.2 1.2 1.2
Fin type (code) Unhydrophilic aluminium Unhydrophilic aluminium Unhydrophilic aluminium
Tube outside dia.and type mm Ф5,Inner groove tube Ф5,Inner groove tube Ф5,Inner groove tube
Coil length x height x width mm 760x507x11.6 760x507x11.6 750x464x12.56
Number of circuits 3 3 2
Outdoor air flow (Hi/Mi/Lo)
m3/h 2091 2091 1800
CFM 1230 1230 1059
Outdoor sound pressure level dB(A) 51 51.5 53

Specifications
Page 8 
Outdoor unit
Dimension(W*D*H)
mm 770x300x555 770x300x555 720x270x495
inch 30.31x11.81x21.85 30.31x11.81x21.85 28.35x10.63x19.49
Packing (W*D*H)
mm 900x345x595 900x345x595 835x300x540
inch 35.43x13.58x23.43 35.43x13.58x23.43 32.87x11.81x21.26
Net/Gross weight
Kg 24.5/26.9 24.8/27 21.8/23.6
lbs. 54.01/59.30 54.67/59.52 48.06/52.03
Refrigerant type Kg R410A/0.5 R410A/0.53 R410A/0.65
Design pressure PSIG 550/340 550/340 550/340
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4”/3/8”) Φ6.35/Φ12.7(1/4"/1/2") Φ6.35/Φ12.7(1/4"/1/2")
Max. refrigerant pipe length
m25 25 25
ft 82.02 82.02 82.02
Max. difference in level
m10 10 10
ft 32.81 32.81 32.81
Connection wiring 16#x4 16#x4 16#x4
Plug type 14#x3/no-plug 14#x3/no-plug 14#x3/no-plug
Thermostat type Remote Control Remote Control Remote Control
Operation temperature 17-30 17-30 17-30
Ambient temperature
Indoor(cooling/ heating) °C 17-32/- 17-32/- 17-32/-
Outdoor(cooling/heating) °C -15-50/- -15-50/- -15-50/-
Qty’per 20’ /40’ /40’HQ 110/228/248 108/225/234 130/276/302
Notes:
1) Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C(80°F) DB /19.4 °C(67°F) WB Heating: - Indoor Temperature 21.1°C(70°F) DB / 15.6°C(60°F) WB
-Outdoor Temperature 35 °C(95°F) DB /23.9 °C(75°F) WB -Outdoor Temperature 8.3°C(47°F) DB / 6.1°C(43°F) WB
-Interconnecting Piping Length 7.5m - Interconnecting Piping Length 7.5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are net capacities.
3) Due to our policy of innovation some specifications may be changed without notification.

Specifications
Page 9 
Model MSABD-17CRFN1-MQ0W MSABE-22CRDN1-MS0W
Power supply V- Ph-Hz 208/230-1-60 208/230-1-60
Max. input consumption W 2200 2950
Max. current A 11 14.5
Compressor
Model KSN140D21UFZ ATN150D30UFZA
Type ROTARY ROTARY
Brand GMCC GMCC
Capacity W 4385 4500
Input W 1140 1160
Rated current(RLA) A 7.5 12.0
Locked rotor Amp(LRA) A / /
Thermal protector / /
Thermal protector position INTERNAL INTERNAL
Capacitor uF / /
Refrigerant oil/oil charge ml VG74/440 VG74/450
Indoor fan motor
Model ZKFP-30-8-3 YKFG-45-4-13
Input W 36.0 89.0
Output W 30 45
Capacitor uF / 3
Speed(Hi/Mi/Lo) r/min 1100/800/700 1100/900/800
Indoor coil
Number of rows 2.0 2.0
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
Fin spacing mm 1.2 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 750x210x26.74+750x126x26.74 820x210x26.74+820x126x26.74
Number of circuits 4 4
Indoor air flow (Hi/Mi/Lo)
m3/h 900/750/600 988/776/562
CFM 529/441/353 581/456/331
Indoor sound pressure level dB(A) 42/34.5/30.5 46/40.5/34.0
Indoor unit
Dimension(W*D*H)
mm 965x215x319 1080x226x335
inch 37.99x8.46x12.56 42.52x8.90x13.19
Packing (W*D*H)
mm 1045x305x410 1155x415x320
inch 41.14x12.01x15.94 45.47x16.34x12.40
Net/Gross weight
Kg 11.4/14 14.3/17.9
lbs. 25.13/30.86 31.53/39.46
Outdoor fan motor
Model ZKFN-34-8-1-3 ZKFN-50-8-2
Input W 58.0 115.0
Output W 34 50
Capacitor uF / /
Speed r/min 850/700 800/550
Outdoor coil
Number of rows 2.0 2.0
Tube pitch(a)x row pitch(b) mm 19.5x11.6 19.5x11.6
Fin spacing mm 1.2 1.2
Fin type (code) Unhydrophilic aluminium Unhydrophilic aluminium
Tube outside dia.and type mm Ф5,Inner groove tube Ф5,Inner groove tube
Coil length x height x width mm 760x507x23.2 768x663x23.2
Number of circuits 4 4
Outdoor air flow (Hi/Mi/Lo)
m3/h 2030 3100
CFM 1194 1824
Outdoor sound pressure level dB(A) 53.5 57.0

Specifications
Page 10 
Outdoor unit
Dimension(W*D*H)
mm 770x300x555 845x363x702
inch 30.31x11.81x21.85 33.27x14.29x27.64
Packing (W*D*H)
mm 900x348x625 965x395x775
inch 35.43x13.70x24.61 37.99x15.55x30.12
Net/Gross weight
Kg 29.9/32.8 40.2/43.5
lbs. 65.92/72.31 88.62/95.90
Refrigerant type Kg R410A/0.9 R410A/1.16
Design pressure PSIG 550/340 550/340
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ15.9(3/8"/5/8")
Max. refrigerant pipe length
m30 30
ft 98.42 98.42
Max. difference in level
m20 20
ft 65.62 65.62
Connection wiring 16#x4 16#x4
Plug type 14#x3/no-plug 14#x3/no-plug
Thermostat type Remote Control Remote Control
Operation temperature 17-30 17-30
Ambient temperature
Indoor(cooling/ heating) °C 17-32/- 17-32/-
Outdoor(cooling/heating) °C -15-50/- -15-50/-
Qty’per 20’ /40’ /40’HQ 108/225/234 130/276/302
Notes:
1) Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C(80°F) DB /19.4 °C(67°F) WB Heating: - Indoor Temperature 21.1°C(70°F) DB / 15.6°C(60°F) WB
-Outdoor Temperature 35 °C(95°F) DB /23.9 °C(75°F) WB -Outdoor Temperature 8.3°C(47°F) DB / 6.1°C(43°F) WB
-Interconnecting Piping Length 7.5m - Interconnecting Piping Length 7.5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are net capacities.
3) Due to our policy of innovation some specifications may be changed without notification.

Specifications
Page 11 
3. Dimensional Drawings
3.1 Indoor Unit
Capacity (Btu/h) Unit W D H
9k mm 722 187 290
inch 28.43 7.36 11.42
11k&12k mm 802 189 297
inch 31.57 7.44 11.69
18k mm 965 215 319
inch 37.99 8.46 12.56
22K mm 1080 226 335
inch 42.52 8.90 13.19

Specifications
Page 12 
3.2 Outdoor Unit
Single Fan Outdoor Unit
Model unit W D H W1 A B C
MOBA30-12CFN1-BP0W
MOBA30-09CFN1-MQ0W
M0BA30-11CFN1-MQ0W
MOBA30-17CFN1-MR0W
mm 770 300 555 840 487 298 322
inch 30.3 11.8 21.9 33.1 19.2 11.7 12.7
MOX130-11CFN1-BT0W
MOX130-11CFN1-MT0W
mm 720 270 495 790 452 255 281
inch 28.35 10.63 19.49 31.10 17.80 10.04 11.06
MOCA30-22CFN1-MR0W mm 845 363 702 914 540 350 375
inch 33.27 14.29 27.64 35.98 21.26 13.78 14.8
MOTCA30-18HFN1-NC9W

Specifications
Page 13 
4. Electrical Wiring Diagrams
4.1 Indoor unit
Abbreviation Paraphrase
Y/G Yellow-Green Conductor
ION Positive and Negative Ion Generator
CAP Capacitor
PLASMA Electronic Dust Collector
L LIVE
N NEUTRAL
Heater The Electric Heating Belt of Indoor Unit
T1 Indoor Room Temperature
T2 Coil Temperature of Indoor Heat Exchanger
MSABB-12CRDN1-BP0W,MSABA-09CRDN1-MP0W, MSABB-12CRDN1-MP0W

Specifications
Page 14 
MSABB-11CRFN1-BT0W, MSABB-11CRFN1-MT0W, MSABD-17CRFN1-MQ0W

Specifications
Page 15 
MSABE-22CRDN1-MS0W

Specifications
Page 16 
4.2 Outdoor Unit
Abbreviation Paraphrase
4-WAY Gas Valve Assembly/4-WAY VALVE
AC-FAN Alternating Current FAN
DC-FAN Direct Current FAN
CT1 AC Current Detector
COMP Compressor
T3 Coil Temperature of Condenser
T4 Outdoor Ambient Temperature
TH Compressor Suction Temperature
TP Compressor Discharge Temperature
EEV Electirc Expansive Valve
L-PRO Low Pressure Switch
H-PRO High Pressure Switch

Specifications
Page 17 
MOBA30-12CFN1-BP0W, MOX130-11CFN1-MT0W

Specifications
Page 18 
MOX130-11CFN1-BT0W, MOBA30-09CFN1-MQ0W, M0BA30-11CFN1-MQ0W

Specifications
Page 19 
MOBA30-17CFN1-MR0W, MOCA30-22CFN1-MR0W

Specifications
Page 20 
5. Refrigerant Cycle Diagrams
5.1 Cooling only
Capacity(Btu/h).
Pipe Size (Diameter:ø)
mm(inch) Piping length (m/ft) Elevation (m/ft)
Additional Refrigerant
Gas Liquid Rated Max. Rated Max.
9k 9.52(3/8) 6.35(1/4) 5/16.4 25/82 0 10/32.8
15g/m (0.16oz/ft)11k&12k 12.7(1/2) 6.35(1/4) 5/16.4 25/82 0 10/32.8
18k 12.7(1/2) 6.35(1/4) 5/16.4 30/98.4 0 20/65.6
22K 15.9(5/8) 9.52(3/8) 5/16.4 30/98.4 0 20/65.6 30g/m (0.32oz/ft)
