Media Technologies 31 Series Guide

Installation and Assembly
Instruction Guide
Bookmark Charleston SST Tables
Checkmate Denions VectorTables
Heritage Lexington FloangVectorTables
Malibu Metro WorkspaceTables
31Series Revaes Z-Tables
www.mediatechnologies.com

WoodFrameShelving(AllLines)
Single Sided .......................................... 4-7
Double Sided ...................................... 9-12
SteelFrameShelving
31 Series & Revaes ........................... 14-16
31 Series Magazine Shelving ..................17
31 Series Mobile Shelving ......................18
Carrels(AllLines)
Panel End.......................................... 20-21
Hex ................................................... 22-24
WoodTables(AllLines)........................ 26
Charleston ..............................................27
NewspaperRack .................................... 28
SteelFrameTables
SST ..........................................................30
Vector, Floang Vector ...........................31
Z Tables...................................................32
WCT, Steel Frame....................................33
WCT, Panel End Frame............................34
WCT, Leg Base Frame Assembly .............35
www.mediatechnologies.com•email:[e-mail]
Phone:231-861-2194•Fax:231-861-6678
Table of Contents

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
3
WoodFrameShelving
Single Faced
Bookmark•Metro•Transit•Checkmate
Twist•Lexington•Charleston
Heritage•Malibu
Bookcases - shelving per unit
Dimension # of shelves
30" H 1 adjustable
36" H 2 adjustable
42" H 2 adjustable
48" H 2 adjustable
60" H 3 adjustable
72" H 4 adjustable
84" H 5 adjustable
90" H 6 adjustable

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
4
⁄-18 x 3 ½”
bolts
⁄-18 x ¾”
bolts
⁄-18 x 1 ¾”
bolts
⁄ nuts
washers
“Z” brackets
#8 x ⁄” screw #8 x 1 ½” screw
Tools Required:
Two 5/16 wrenches
Philips head screwdriver
Parts Included:
Wood Frame Shelving, Single Faced
STEP1-Aachingtheboomstothesides
ForInialBookshelfUnit:
Aach the boom frame to one end panel with the (4)
5
/ 16 -18 x 1
3
/ 4 ''
bolts and washers.
• Save second end panel for the end of run- if assembling
stand alone unit aach second end panel now.
• Posion boom frame with groove facing up and align with
groove in side panel.
ForAdderUnits:
Aach one boom frame to the intermediate panel and the next
boom frame with
5
/ 16 -18 x 3
1
/ 2 '' bolts and washers
• Grooves on all inial and adder units should be installed
toward the bookshelf back.
Lay out all inial, adder and end units but
DO NOT ghten bolts, yet.
• All booms must be level relave to each other
shim if necessary.
Side Panels
Boom Shelf
Boom Frame
Top
Back
Shelves
A
ATTENTION: UNITS ARE ASSEMBLED STANDING UP
General Assembly:
Special applications may require
shelving unit be oor-anchored.
Failure to do so could cause
instability and injury.
!
C A U T ION
B
C
A

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
5
STEP2-Aachingthebacks
Slip the back into the grooves in the side panels and boom frame.
The side panels will push outward because the bolts on the boom
frame are not ghtened.
• Start sliding the back into the groove at a height in which
the width of the back will t in the grooves so as not to
scratch the side panels.
STEP3-Aachingthe“Z”brackets
(Forunitstallerthan72"skiptoSTEP5)
ForInialBookshelfUnit:
Loosely aach the (2) “Z” brackets to the sides using the (4)
5
/ 16 -18
x
3
/ 4 " bolts.
ForAdderUnits:
Use (2)
5
/ 16 -18 x 1
3
/ 4 " bolts and nuts to bolt through both “Z”
brackets on either side of each end panel
STEP4-Aachingthetops
Properly posion the top slightly below top edge of side panels and
fasten it to the “Z” brackets using the (4) #8 x
5
/ 8 " screws.
• A groove in the rear valance of a single-sided top captures
the back panel.
• Make sure back edge of top is ush with back edge of end
panel
B
Wood Frame Shelving, Single Faced
Back in boom frame
groove for single-sided
shelving
Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
ForAachingCommonTops:Seeseparateinstruconsheetinsert
Note: Common tops span mulple bookcases and a slightly modied bookcase design is used for units receiving
common tops.
• End panels do not receive edgebanding on top edge.
• End panels will have threaded inserts near top edge for aaching the valance box.
For single faced units, common top aligns ush with back of unit and overhangs on front and side edges.
Note: Common tops for longer runs of bookcases may be manufactured in secons. Seconed tops will be
assembled using ght joints and splines.
Groove for
Back Panel

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
6
(Forunits72"andshorterskiptoSTEP7)
STEP5-Aaching“Z”brackets-unitstallerthan72"
ForInialBookshelfUnit:
The smallest arm of the “Z” bracket should be poinng down as
you screw it LOOSELY to the end panels using the
5
/ 16 -18 x
3
/ 4 "
bolts.• There are 2 “Z” brackets on single-sided units
ForAdderUnits:
Use (2)
5
/ 16 -18 x 1
3
/ 4 " bolts and nuts to bolt through both “Z”
brackets on either side of each end panel.
STEP6-Aachingthetopstounitstallerthan72"
Angle the back of the top higher than the front to slide it under
the “Z” brackets and over the back panel.
Lower the back of the top so the groove in the rear cornice of
a single-sided top captures the back panel. At the same me,
raise the front of the top so that the “Z” brackets slip into the
grooves on either end of the top of the top.
Screw into place using the (4) #8 x
5
/ 8 " screws.
Make sure the back edge of the top is ush with the back edge
of the end panels then ghten the
5
/ 16 -18 bolts.
STEP7-Nowghtenallbolts!
Go back and ghten all bolts from previous steps.
STEP8-Aachingtheboomshelf
Posion the boom shelf onto the toe frame with the back
edge ush to the back panel and the nished front edge slightly
overhanging the front of the toe frame. Screw down using the
(2) #8 x 1
1
/ 2 " screws. Toe frames are pre-drilled to receive the
screws.
Wood Frame Shelving, Single Faced
FLUSH
then ghten
hex bolts
LAST
REMEMBER
STEP 7
C

7
STEP9-Installingshelves
For wood shelves: Slip round pin of shelf clips into appropriate line
holes in side panels and lower shelf into place so pointed poron of
shelf clip is inserted into pre-drilled holes on underside of shelf.
Forsteelshelves: Slip shouldered pins into aligned holes in side
panels and install shelves (4 pins per shelf).
Forxedwoodshelvesonunits60"andtaller:
On shelving units 60” and taller, a xed shelf will be installed at the
beginning and end of the run (as shown below). Fixed shelves will
receive (4) xed shelf supports per shelf that have a swing out cam.
Fixed shelves should be placed mid-height of bookcase and aached
to the end and intermediate panels. One xed shelf should be used
on each side of double faced units.
Forxedsteelshelvesonunits60"andtaller:
Substute (4) Varianta screws for standard steel shelf pins on a
middle shelf of the book case at each end of a run
STEP10-Installingmagazineshelves
Note: There is one less magazine/standard shelf combo
per face than on a similar height standard shelving unit.
Insert one shelf clip into pre-drilled hole in underside of magazine
shelf far enough forward so that shelf can rotate freely and secure
with a small screw (#8 X
5
/ 8 " or equiv.) Place post of shelf clip into
appropriate line hole. Now place post of second shelf clip into
appropriate line hole on other side and posion shelf onto clip.
Aach second clip to underside of shelf.
Wood Frame Shelving, Single Faced
magazine
shelf clip
magazine
shelf
standard adjustable shelf
Make sure bookstack is at against
wall from top to boom.
NOTEFORSTABILITY:
Forsinglefacedunits84"andtaller, an angle bracket is provided for
aaching the bookstack to a wall. Thebracketshouldbealignedto
screwintoasupportorstud. Next, posion bracket with the longer
tab against the underside of the top of the bookcase and make sure
the shorter tab is at against the back of the bookcase. Screw bracket
into top of bookcase rst using #8 X
5
/ 8 " PH screws, then screw into
the wall through the back panel using the approriate anchor for the
wall type.
Forallsinglefacedunitsupto72", secure bookcase to wall by
screwing through the valance into the wall using using the approriate
anchor for the wall type.
Top-aach bracket
to top rst
back panel
Varianta Screw
Steel
Wood
Fixed shelf pin

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
8
WoodFrameShelving
Double Faced
Bookmark
Metro
Transit
Checkmate
Twist
Lexington
Charleston
Heritage
Malibu

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
9
⁄-18 x 3 ½”
bolts
⁄-18 x ¾”
bolts
⁄-18 x 1 ¾”
bolts
⁄ nuts
washers
“Z” brackets
#8 x ⁄” screw #8 x 1 ½” screw
Tools Required:
Two 5/16 wrenches
Philips head screwdriver
Parts Included:
STEP1-Aachingtheboomstothesides
ForInialBookshelfUnit:
Aach the boom frame to one end panel with the (4)
5
/ 16 -18 x
1
3
/ 4 " bolts and washers.
• Save second end panel for the end of run- if assembling
stand alone unit aach second end
panel now.
• Double faced units- Use two boom frames with groove
facing up, and unnished edges face to
face. The seam between them aligns with groove in side
panel.
ForAdderUnits:
Aach two boom frames to the intermediate panel and the next
two boom frames with
5
/ 16 -18 x 3
1
/ 2 " bolts, nuts and washers
• The seam between two boom frames aligns with
groove in side panel.
Lay out all inial, adder and end units but DO NOT
ghten bolts, yet.
• All booms must be level relave to each other- shim
if necessary.
A
Side
Panels
Boom Shelf
Boom Frame
Top
Back
Shelves
A
B
C
C
ATTENTION: UNITS ARE ASSEMBLED STANDING UP
Wood Frame Shelving, Double Faced
Special applications may require
shelving unit be oor-anchored.
Failure to do so could cause
instability and injury.
!
C A U T ION

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
10
Back sits on
boom frame
(not in grooves)
for double-sided
shelving
STEP2-Aachingthebacks
(Forunitstallerthan72"skiptoSTEP5)
Slip the back into the grooves in the side panels and lower onto
thetop of the boom frame. The back on double units is captured
by the boom shelves, not the grooves in the boom frame.
Therefore these backs are 1-
7
/ 16 " shorter than singles.
• The side panels will push outward because the bolts on
the boom frame are not ghtened. Start sliding the back
into the groove at a height in which the width of the back
will t in the grooves so as not to scratch the side panels.
STEP3-Aachingthe“Z”brackets
ForInialBookshelfUnit:
Loosely aach the (4) “Z” brackets to the sides using the
(4)
5
/ 16 -18 x
3
/ 4 " bolts.
Wood Frame Shelving, Double Faced
Back
Panel
B
STEP4-Aachingthetops
Properly posion the top slightly below top edge of side panels and
fasten it to the “Z” brackets using the (8) #8 x
5
/ 8 " screws.
• A groove in the center of a double-sided top captures the
back panel.
ForAachingCommonTops:Seeseparateinstruconsheetinsert
Note: Common tops span mulple bookcases and a slightly modied bookcase design is used for units receiving
common tops.
• End panels do not receive edgebanding on top edge.
• End panels will have threaded inserts near top edge for aaching the valance box.
For double faced units, common top overhangs on all four edges.
Note:Common tops for longer runs of bookcases will be manufactured in secons. Seconed tops will be
assembled using ght joints and splines.
ForAdderUnits:
Use (2)
5
/ 16 -18 x 1
3
/ 4 " bolts and nuts to bolt through
both “Z” brackets on either side of each end panel

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
11
STEP5- Aaching“Z”brackets-unitstaller
than72"
(Forunits72"andshorterskiptoSTEP7)
ForInialBookshelfUnit:
The smallest arm of the “Z” bracket should be poinng
down as you screw it LOOSELY to the end panels using
the
5
/ 16 -18 x
3
/ 4 " bolts.
• There are 4 “Z” brackets on double-sided units
ForAdderUnits:
Use (2)
5
/ 16 -18 x 1
3
/ 4 " bolts and nuts to bolt through both
“Z” brackets on either side of each end panel. Do this on
only one side of all double sided bookstacks.
STEP6-Aachingthetopstounitstaller
than72"
Angle one front edge of the top higher than the other slide
it under the “Z” brackets and over the back panel.
Lower one front edge of the top so the groove in the
middle of the double-sided top captures the back panel.
At the same me, raise the other front edge of the top so
that the “Z” brackets slip into the grooves on either end of
the top of the top.
Now LOOSELY screw on the other 2 “Z” brackets to the
double side of the bookstack using the
5
/ 16 -18 x
3
/ 4 " bolts.
• Make sure to slide “Z” bracket into groove in top.
Screw all 4 “Z” brackets into place using the (4) #8 x
5
/ 8 "
screws.
Make sure the top is centered over both sides of the book
stack then ghten the
5
/ 16 -18 bolts.
STEP7-Nowghtenallboltsandbrackets!
CENTER then ghten bolts LAST
Wood Frame Shelving, Double Faced
Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
REMEMBER
STEP 7

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
12
Wood Frame Shelving, Double Faced
STEP8-Aachingtheboomshelf
Posion the boom shelf onto the toe frame with the
back edge ush to the back panel and the nished front
edge slightly overhanging the front of the toe frame.
Screw down using the (2) #8 x 1
1
/ 2 " screws. Toe frames
are pre-drilled to receive the screws.
STEP9-Installingshelves
Forwoodshelves: Slip round pin of shelf clips into
appropriate line holes in side panels and lower shelf into
place so pointed poron of shelf clip is inserted into
pre-drilled holes on underside of shelf.
Forsteelshelves: Slip shouldered pins into aligned
holes in side panels and install shelves (4 pins per shelf).
Make sure shoulder is between shelf and end panel.
Forxedwoodshelvesonunits60”andtaller:
On shelving units 60” and taller, a xed shelf will be
installed at the beginning and end of the run (as shown
below). Fixed shelves will receive (4) xed shelf supports
per shelf that have a swing out cam. Fixed shelves
should be placed mid-height of bookcase and aached
to the end and intermediate panels. One xed shelf
should be used on each side of double faced units.
Locate xed shelves mid-height on each end of shelving
run and aach using (4) xed shelf supports per shelf.
For xed steel shelves on units 60” and taller:
Substute (4) Varianta Screws for standard steel shelf
pins on a middle shelf of the book case at each end of
the run. One xed shelf should be installed on each side
of double unit. Install Varianta Screw w/ #2 Pozi Drive.
Forxedshelvesonmobileunits:
Install xed wood or steel shelves as indicated above,
but only one xed shelf is required per mobile unit, not
at each end of run as required above.
STEP10-Installingmagazineshelves
Note: There is one less magazine/standard shelf combo
per face than on a similar height standard shelving unit.
Insert one shelf clip into pre-drilled hole in underside
of magazine shelf far enough forward so that shelf can
rotate freely and secure with a small screw (#8 x
5
/ 8 " or
equiv.) Place post of shelf clip into appropriate line hole.
Now place post of second shelf clip into appropriate line
hole on other side and posion shelf onto clip. Aach
second clip to underside of shelf.
magazine
shelf clip
magazine
shelf
standard adjustable shelf
SteelWood Fixed shelf pin
Varianta Screw
End panels will bow if xed shelves are not installed. Failure to install per instrucons
could result in void of warranty.
C
Fixed adjustable shelf receives
routed grooves to accept xed
shelf pin

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
13
SteelFrameShelving
31Series
Revaes
Bookcases - shelving per unit
Dimension # of shelves
30" H 1 adjustable
36" H 2 adjustable
42" H 2 adjustable
48" H 2 adjustable
60" H 3 adjustable
72" H 4 adjustable
84" H 5 adjustable
90" H 6 adjustable

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
14
SteelFrames-seeSTEP1a
BackPanels-seeSTEP1b
Steel Frame Shelving
STEP1a-Aachingsidepanelstosteelframes
ForStarterUnits:
Aach the tubular steel frames to an end panel using the
shorter (1
3
/ 4 ") connector bolt and nut
• Make sure shelf pin hole lines face in towards shelves
• Single-sided units have specic right and le
end panels
• Single and Double-sided units 48" and shorter use
1 tubular frame
• Single and Double-sided units over 48" use 2
tubular frames
• One person assembly can be started on the oor
ForAdderUnits:
Bolt through one steel frame, then an intermediate panel,
then the next steel frame with the longer (2
3
/ 4 ") connector
bolt and nut
• For easier one person assembly you can aach steel
frame(s) to end panel and rst intermediate panel on
the oor. Next aach toes (next page) then stand unit
upright before adding addional frames and panels
Lay out all inial, adder and end units but
DO NOT ghten bolts, yet.
• All booms must be level relave to each other-
shim if necessary.

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
15
Cam
Steel Frame Shelving
STEP1b–Aachingsidepanelstobackpanels
ForStarterUnits:
Screw the long cam studs into the 5 mm holes bored along
the inside face near the rear edge of a single
end panel.
• For Double-sided units the 5 mm holes are bored
in the center of the end panels
Drop the 15 mm cam into the pre-bored holes in the back
panel (makesurethetriangleonthecampointstowardthe
sidepanelandlongcamstudit’sghtening) then twist cam
about
1
/ 4 turn clockwise to ghten.
ForAdderUnits:
Screw the long cam studs into both sides of an intermediate panel.
Drop the 15 mm cam into the pre-bored holes in the back
panel (makesurethetriangleonthecampointstowardthe
sidepanelandlongcamstudit’sghtening) then twist cam
about
1
/ 4 turn clockwise to ghten.
STEP2-AachingtheToes
Screw the toe/bracket assembly to the side panels using the
#8 x
5
/ 8 " screws.
Then aach the angle mounng brackets to either end of
the rear face of the toes by screwing the #8 x
5
/ 8 " screws.
• Toes will be oset to the inside of the front edge
of the side panels but should be ush with the
boom of the panel.
• One toe is provided for single unit and two toes are
provided for each double-sided unit
STEP3-AachingtheTops
Screw the short cam studs into every pre-bored 5mm holes
at the top of each face of each side panel.
• 2 holes in a single end panel, 4 holes in a single
intermediate panel or double-sided end panel, 8
holes in an double-sided intermediate panel
Insert cams into pre-drilled holes in top, then align cams
onto the studs and ghten the cam about
1
/ 4 turn clockwise.
• Make sure the unnished edge of a single top faces
to the rear
Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
Back Panel
NoteTriangle

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
16
STEP4-InstallingFixedShelvesinunits60"andtaller
(ForUnitsshorterthan60"skiptoSTEP5)
VARIANTA SCREWS MUST BE
INSTALLED ON TALLER UNITS
Shouldered pins must be replaced with Varianta screws on mid-
height shelves of the bookcases at both ends of a run
Note: Units not using the oponal tops must also substute
Varianta screws for the top shelf at the beginning and end of a run.
STEP5-InstallingShelves
Slip shouldered pins into aligned holes in side panels and install
shelves (4 pins per shelf)
• Pins in boom line holes will hold the boom shelf just
above the toe
Steel Frame Shelving
31 Series Magazine Shelf
Standard 31 Series Shelf
Varianta Screw

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
17
31 Series Magazine Shelf
Steel Frame
Installingmagazinedisplayshelf
Install standard adjustable shelf as usual and then rest magazine shelf on top of it.
Li rear of shelf to desired lt angle and slip smooth 5 mm shelf pins through the pivot slots in the rear of each
side ange.
PivotandStoreFeature
To use the pivot and store feature, just place two shelf
pins in the two line holes opposite the smooth shelf pins
that act as pivots for the magazine shelf.
• (1) Swing the shelf up so the addional shelf
pins slip through one of the “L” shaped slots in
the side anges
• (2) Push the shelf back to hold in place

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
18
31 Series Mobile Shelving
• Mobile 31 Series shelving is assembled in the same manner as standard, non-mobile 31 Series shelving
with the excepon of the toes.
• Individual toes and brackets are replaced by a toe frame, shipped assembled with casters and metal
caster support frames.
• To assemble, simply bolt through the metal caster frame and toe frame into the threaded inserts at the
boom of the side panels using the
5
/ 16 " x 1 -
3
/ 4 " bolts provided.

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
19
Carrel-PanelEnd
Bookmark
Metro
Checkmate
Twist
Heritage
Malibu

Assemble units only as described in this guide.
All screws, nuts & bolts and other fasteners must
be tightened securely and checked regularly.
Failure to do so could cause instability and injury.
!
C A U T ION
20
Panel End Carrel
STEP1-Aachinglevelers
Screw levelers into the 8mm banded boom edge of all end and
intermediate panels. Actually level carrels last, once assembled.
STEP2-Aachingendandintermediatepanelsto
backpanels
Screw Mod-eez studs into holes in vercal center line of double end/
intermediate panels or back edge of single end/intermediate panels.
Slide Mod-eez studs into factory installed Mod-eez clips on either
end of back panels.
Tools Required:
Phillips screwdriver
6mm wrench
