Spectrum Industries Liberty ADA 38792 User manual

38792 38790
38793 38791
38932 38935
38933 38936
Liberty ADA Desks
44" CLASS
48" CLASS
44" Evolution
48" Evolution
Crank-Adjustable Electric ECS-Adjustable
44" CLASS
48" CLASS
44" Evolution
48" Evolution
Owner's Manual
055311R5 Page 1 of 7
IMPORTANT:
Before you begin, please make sure all parts and proper
quantities are included. Any parts damaged during
shipment must be reported within 15 days of receipt. To
report information regarding damages or if you have any
questions, please call 1-800-235-1262.
CAUTION:
Before using this product, read this manual and follow all
safety and operating instructions.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for choosing Spectrum products!
Crank-adjustable Electric ECS-adjustable
Spectrum Industries, Inc.
Chippewa Falls, WI 54729, USA
055311R5
P
age
1
o
f
7

(32) 026064 (B)
043493 (P)
1/4-20 x 5/8" PHMS
(4) 041289
1/4-20 x 1-3/4" PHMS
(2) 026011 (B)
043771 (K)
1/4-20 x 2" FHMS
(4) 026073
#8 X 3/4" PHSM
(2) 021585
#6 X 1/2" PHSM
(4) 044207
1" Cord Clip
●Read this owners manual before operation
●For indoor use only. Do not install or store the unit where it will be
exposed to weather. Keep unit dry.
●For added safety, plug the unit into a grounded three-prong receptacle
controlled by a GFI (Ground Fault Interrupter) circuit breaker.
Safety
Phillips Head
Screwdriver
Hardware package contents
Tools Required
Crank-Adjustable Desk Assembly / Setup:
Crank-Adjustable Desk Electric-ECS Adjustable Desk
(32) 026064 (B)
043493 (P)
1/4-20 x 5/8" PHMS
(4) 041289
1/4-20 x 1-3/4" PHMS
(2) 026011 (B)
043771 (K)
1/4-20 x 2" FHMS
055311R5 Page 2 of 7
A. Orient the right leg as shown in Figure 1A.
B. Insert the drive shaft assembly through the hole as shown and attach to the
gear box with the (4) #6 x 5/8" PHSM screws included with the drive shaft. Figure 1B.
Right Leg
Drive Shaft
Assembly
#6 x 5/8" PHSM
(4 req'd)
Figure 1A
Figure 1B
Gear Box
1. Attach Drive shaft Assembly to Leg
Crank
Adjustable
Desk
Assembly
/
Setup:
055311R5
Page
2
of
7

Handle
Right-Hand Hex Drive
Bar Assembly
Leg Drive
Shaft
1/4-20 x 5/8" PHMS
Right Leg
Crank Mount
Left Leg
W
o
rk
su
rf
ace
A. Carefully flip the worksurface face-down onto a non-abrasive surface and orient the right leg as shown in Figure 2.
B. Attach the right leg and right-hand hex drive bar assembly to the worksurface using 1/4-20 x 5/8" PHM screws.
(Be sure the drive bar shaft is fully-inserted into the gear box before attaching.)
C. Attach the crank mount to the leg drive shaft, and attach to the worksurface with 1/4-20 x 5/8" PHM screws.
D. Connect the left and right-hand drive assemblies while engaging the drive mechanism. If necessary, the drive
mechanism alignment can be adjusted by turning the crank handle slightly.
E. Attach the left leg and drive assembly to the worksurface using (8) 1/4-20 x 5/8" PHM screws.
Left-Hand Hex Drive
Bar Assembly
2. Attach Legs & Drive Assemblies to Worksurface
055311R5 Page 3 of 7
A. Attach the T-supports to the worksurface using
(4) 1/4-20 x 1-3/4" PHM screws. Figure 3.
B. Attach the cord channel to the T-supports using
(4) 1/4-20 x 5/8" PHM screws.
C. Attach the chair rail using (2) 1/4-20 x 2" FHM screws.
D. Carefully flip the desk upright-this may take
several people.
Figure 3
Worksurface
T-Supports
Cord Channel
Chair Rail
1/4-20 x 5/8" PHMS
(4 req'd)
1/4-20 x 1-3/4" PHMS
(4 req'd)
1/4-20 x 2" FHMS
Figure 2
3. Attach T-Supports, Cord Channel & Chair Rail
055311R5
Page
3
of
7

A. Carefully flip the worksurface face-down onto a non-abrasive surface. Figure 1.
B. Attach each leg to the worksurface using (8) 1/4-20 x 5/8" PHM screws.
Control
Box
Control
Panel
Right Leg
Left Leg
#8 x 3/4" PHSM
(4 req'd)
Electric ECS Desk Assembly / Setup:
1. Attach Legs to Worksurface
055311R5 Page 4 of 7
A. Attach the control box using (4) #8 x 3/4" PHSM screws and the pre-drilled holes. Figure 1.
B. Determine which side of the desk you want to mount the control panel (left or right side.)
C. Attach the control panel using (2) #6 x 1/2" PHSM screws and the pre-drilled holes.
Figure 1
1/4-20 x 5/8"
PHMS
Worksurface
Left-side control
panel location
Right-side control
panel location
2. Attach Control Box & Control Panel
055311R5
Page
4
of
7

A. Attach the T-supports to the worksurface using (4) 1/4-20 x 1-3/4" PHM screws. Figure 3.
B. Attach the cord channel to the T-supports using (4) 1/4-20 x 5/8" PHM screws.
C. Attach the chair rail using (2) 1/4-20 x 2" FHM screws. (These screws will attach to the T-support ends.)
Chair Rail
1/4
-
20 x 2" FHMS
T-Support
Cord Channel
1/4-20 x 5/8" PHMS
(4 req'd)
1/4-20 x 1-3/4" PHMS
(4 req'd)
Wk f
3. Attach T-Supports, Cord Channel, & Chair Rail
055311R5 Page 5 of 7
Worksurface
Figure 4
Figure 3
A. Connect the cords to the control box as shown in Figure 4.
B. Use the cord clips to secure the cords to the underside of the worksurface.
C. Carefully flip the desk upright-this may take several people.
Control Box
Leg Cords Control Panel
Cord
Power Cord
4. Connect Cords
055311R5
Page
5
of
7

Reset Procedure:
1. Unplug, then re-plug-in the power cord into a wall outlet or power strip.
2. Make sure all lift mechanism wire connections are in place and secure.
3. Press and hold the “down” button until the monitor column has bottomed-out for 10 seconds.
4. Release, then press and hold the “Down” button again for another 10 seconds.
5. Release the “down” button.
A. Plug in the power cord. Route cord so it is not a tripping hazard.
B. To adjust the desk height, press the "Up" or "Down" arrow keys until the preferred height is achieved. Figure 5.
C. Numbers "1, 2, & 3" are memory settings. After a preferred height is reached, the height setting can be saved by pressing "S" and then
number "1, 2, or 3." To adjust from one memory setting to another, press and hold the number until the pre-programmed height
is attained.
123S
Figure 5
Control Panel
5. Control Panel Operation, Memory Presets, & Reset Procedure
CAUTION
Use caution when raising or lowering the worksurface. Do not
sit at, under, or on the worksurface when operating the lift
mechanism and be sure desk movement does not interfere with
objects or people. Keep clear of pinch points during
worksurface movement. The lift actuators are rated at a
maximum capacity of 180 lbs.
Note:Occasionally it may be necessary to reset the
lift mechanism. This should be performed if the
lectern does not extend or retract.
055311R5 Pa
g
e 6 of 7
The lift mechanism has now been reset and normal operation can resume.
Flat Panel Monitor Arm
95512 (for monitors weighing 4-11.5 lbs)
95522 (for monitors weighing 10-27.5 lbs)
95509 (for monitors weighing 14-31 lbs)
Evo Flat Panel Monitor Arm
95523 (for 15"-19" monitors weighing 6-13 lbs)
95524 (for 19"-21" monitors weighing 13-21 lbs)
6-Outlet Power Strip
w/ 12' cord
115/16"W x 11/16"D x 13/16"H
99023
7-Outlet Power Strip, insured
w/surge protector, bracket, and 12' cord
10"W x 2"D x 11/8"H
99024
Note:Monitor arms can be mounted to
the worksurface with a 3/8" mounting
hole or clamped to the edge.
Liberty ADA Desk Options
055311R5
Page
6
of
7

Warranty
WE WILL MAKE IT RIGHT FOR YOU!
We guarantee all Spectrum products to be free of all defects in materials and workmanship, for the original owner, for a period of ten years.
Any item deemed defective by Spectrum or the original manufacturer, under normal use conditions, will be repaired or replaced at
Spectrum’s discretion. This warranty applies to all products manufactured and distributed by Spectrum except the products listed below.
DESIGNED FOR INDOOR USE ONLY - Spectrum’s products have been designed and constructed for indoor use only. Moving or using
outdoors, or on excessively rough surfaces, may cause damage to the products and may void the warranty. If an outdoor application is
desired please contact us to discuss potential custom design solutions.
Spectrum is committed to provide complete customer satisfaction. Each of our products are manufactured from the best materials available
and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet
Customer Expectations).
Our Customer Service Help Line 1-800-235-1262 is ready to provide immediate attention to any questions, comments or concerns. Weare
available to answer your calls Monday through Friday from 7 am to 5 pm CST. In addition your product comments or concerns are welcome
via e-mail at: [e-mail].
Items that have a varying warranty include, but are not limited to, the following:
• Adjustable Crank/Electric Desk Legs (1 yr)
• Flat Panel Desk Gas Cylinders (1 yr)
• Adjustable Height Chair Parts – including frames, gas cylinders, wood and plastic parts, and control handles (7 yrs)
• Adjustable Height Chair Parts Casters (2 yrs)
• Adjustable Height Chair Upholstery - In-Stock Upholstery (2 yrs)
• Adjustable Height Chair Upholstery - Graded-In Fabrics and C.O.M (no warranty)
• Height Adjustable Columns and Lifts (1 yr)
• General Use Casters (1 yr)
• Electrical – ECA (1 yr)
• Electrical - Power Strips (1 yr)
• Electrical Surge Suppressors (lifetime)
• Electrical - Retractable Power Cords (1 yr)
• Keyboard/Mouse Trays (1 yr)
•
Flat Panel Monitor Arm
–
General Parts (5 yrs)
055311R5 Pa
g
e 7 of 7
Flat
Panel
Monitor
Arm
General
Parts
(5
yrs)
• Flat Panel Monitor Arm – Gas Cylinders (2 yrs)
• CRT Monitor Arm (1 yr)
The warranty, as stated above, is effective as of 05/28/2009
