Summer 27990 User manual

Chatham Post Safety Gate
INSTRUCTION MANUAL
Please read the following instructions carefully.
Keep this instruction manual for future reference.
Tools required: Phillips head screwdriver, drill (for top of stair installation),
and pencil (not included), wrench (included).
For use with children from 6 - 24 months.
Keep small parts away from children.
Adult assembly required.
Fits openings from 28.5" - 42" wide.
27990
Text "Install Chatham" to 38344 for a step-by-step installation video.
Have questions? We're here to help. For technical support please contact us at
401-671-6551 or www.summerinfant.com/contact.

components:
Gate Door
Gate Frame
A
B
Small Extension Frame
Large Extension Frame
C
D
Lower Latch
Top Latch
E
Adhesive Mounting Pads (4)
H
Wall Anchors (4)
Wall Cups (4)
I
J
Screws (4)
K
L
Wrench
M
Tension Bolts with Tension Nuts (4)
Extension Pins (4)
F
GDoor Stopper N
C D
B
2
E
A
F
N
hardware:
G
x4 x4
H
I J
K L
x4 x4
x4x4
M
x1
FALL HAZARD! IMPORTANT! KEEP FOR FUTURE REFERENCE!
• Children have died or been seriously injured when gates are not securely installed. ALWAYS install and use
gate as directed using all required parts.
• STOP using when a child can climb over or dislodge the gate.
• Use only with the locking/latching mechanism securely engaged.
• To prevent falls, never use at top of stairs without wall mounting cups and door stopper.
• NEVER use to keep child away from pool.
• NEVER leave child unattended.
• Always close and lock the gate behind you.
• This product will not necessarily prevent all accidents.
• Do not use if any components are missing or damaged.
• Adult assembly required. Exercise care when unpacking and assembling product.
IMPORTANT – Read the instructions carefully before use and keep them for future reference.
CAUTION: KEEP SMALL PARTS OUT OF CHILD’S REACH.
WARNING

gate configurations (choose which best fits your scenario):
Measure the width of the opening where you intend to install the gate.
Refer to the following illustrations to determine the correct installation
configuration. Baseboard molding may change which configuration is
appropriate.
A B
C
(28.5˝- 30.5˝) without extension frames (31.5˝- 34.25˝) with small extension frame
(35.25˝- 38.25˝) with large extension frame
WARNING
NEVER install two extension
frames on the same side of
the gate.
!
Note: This instruction book illustrates installation
of gate configuration D.
If choosing gate configuration A, skip ahead to step
2. Otherwise, follow step 1 using the appropriate
extension frames that best fit your scenario.
3
D
(38.5˝- 42˝) with both extension frames

4
installation:
2
Slide tension bolts
into upper and lower holes
on both sides of
extension frames
(or gate frame if no extensions
are being used).
H
x 4
1
G
x 4
x 4
Connect the extension
frames to the gate frame by
inserting the extension pins into the holes
in the extension frame, or into the gate frame
(if extensions are not being used).

Installation (continued):
Check locations A and B.The
distance between the gate and the
wall should never exceed 2.75”.
IMPORTANT
Use the tension nuts
to tighten both of the
bottom tension bolts.
4
3
5
Use the tension nuts
to tighten both of the
top tension bolts.
AB
Stand the gate in the
center of the opening.
Make sure the bottom of
the gate is completely flush
to the floor. Slide tension
bolts out until they
contact the door frame
or wall on both sides.
tighten!
tighten!
tighten!
tighten!
5
Note: If mounting at top of stairs, proceed
to step 6. Otherwise, follow the directions in
step 14 to tighten the tension nuts.
!

7
6
6
With a pencil, trace
the entire outline
of each tension bolt
directly onto the wall.
Loosen the
lower and upper
tension nuts and
remove gate.
STOP! wall cup/top of stairs installation:
WARNING
For use at top of stairs, wall cup
installation is MANDATORY.
Follow these wall cup installation instructions when using gate at TOP OF
STAIRS (MANDATORY), or if using wall cups for a standard opening (optional).
If opting not to use wall cups for a standard opening, skip ahead to step 14.
x 4
loosen!
loosen!
x 2
x 2

8
Note: If mounting into plaster or
drywall, follow this step and use
the wall anchors provided.
!
x 4
Mark drill
holes with a
pencil through
the center
of each wall cup.
Mark drill
holes with a
pencil through
the center
of each wall cup.
x4
Place a wall cup over
the center of each circular
outline on the wall.
Place a wall cup over
the center of each circular
outline on the wall.
wall cup/top of stairs installation (continued):
1
st
2
nd
Insert wall anchors
into pilot holes.
Insert wall anchors
into pilot holes.
7
9
K
J
Drill a 7/32'' pilot hole
into each of the 4
center marks.
Drill a 7/32'' pilot hole
into each of the 4
center marks.

Attach one pad to
the back of each
wall cup.
peel
peel
2
nd
3
rd
Remove backing
from one side of each
adhesive mounting pad.
Remove
backing.
1
st
10
Align the wall cups so
the center hole is placed
directly over the wall anchor.
Stick wall cups to the wall.
Make sure
all wall cups
are facing up.
Make sure
all wall cups
are facing up.
wall cup/top of stairs installation (continued):
press
press
press
press
11
8
x 4
I
x 4
J
!
!
Note: The bottom wall cups
should rest on the floor.

x4
Screw
wall cups
into wall.
x 4
Repeat "installation"
steps on page 5.
The 4 tension bolts
will rest within
each wall cup.
x 4
wall cup/top of stairs installation (continued):
12
13
9
L
NEVER open gate door over stairs.
IMPORTANT:

door stopper:
M
Tighten all 4
tension nuts
with the provided
wrench.
wall cup/top of stairs installation (continued):
x 4
14
10
FINISHED!
Note: This gate includes a door stopper which prevents the gate door from swinging open
in one direction when used at the top of the stairs.
!
When mounting this
product at the top of the stairs,
locate the door stopper that is
on the opposite side of the stairs.
Swing door stopper 180°
to overlap the gate frame, so that
the door cannot open
over the stairs.
Tighten top tension nuts
so the top latch pins
engage the holes
in the door frame.
!
Note: When door stopper is not
needed (between rooms) rotate both
door stoppers 180° so they are no
longer overlapping the gate frame. This
will allow the gate to open in either
direction.
