Genio 700 Evaluation Kit
Quick Start Guide

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
2
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
Version istory
Version Date Author Description
0.1 2023-03-08 MTK Draft Release

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
3
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
Table of Contents
Version History ··········································································································································································· 2
Table of Contents ······································································································································································· 3
1 Packing list ········································································································································································· 4
2 Genio 700-EVK System Setup ············································································································································ 5
3 Genio 700-EVK Board overview ········································································································································· 6
4 LCM Holder setup ······························································································································································ 7
5 DC Camera DTB board installation ····································································································································· 8
6 How to Power up the Gneio 700 EVK ································································································································ 9
List of Figures
Figure 2-1. Genio 700 EVK System ·············································································································································· 5
Figure 3-1. Genio 700 EVK Board Overview ······························································································································· 6
Figure 4-1. LCM Holder Setup ···················································································································································· 7
Figure 5-1. D2 Camera DTB board ·············································································································································· 8
Figure 6-1. Plug AC Adapter , Press Power Key and LEDs Status ································································································ 9
List of Tables
Table 1-1. Packing List ································································································································································ 4

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
4
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
1Packing list
S.No Part Number or Marking Item Name Description Quantity
1 IoT-Genio 700 EVK-P1V3 Genio 700 Main Board 1
2 Camera Board (Genio 700- Camera Board Camera sub-board using onsemi AP1302 Image
Sensor Processor 1
CAM DTB-D1V1-D2) (D2 Version)
3 IMX214 Camera Module Camera Module for D2
Camera Module using SONY IMX214 CMOS
Digital Image Sensor, preconnected to AP1302
ISP Camera Board
1
4 With Touch Panel and FFC cable 7” LCD Panel LCM Module 1
5 M.2 WIFI6 Module
AW-XB468NF (IC: MT7921L) WIFI Module 1
6 WIFI Antenna 2
7 WIFI Antenna Cable 2
8 12V AC adaptor 1
9 AC Power cord 1
Table 1-1. Packing List

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
5
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
2Genio 700 EVK System Setup
Please refer below pictures for entire assembled Genio 700 EVK, the entire peripherals include:
1: LCD Module with Touch Panel * 1 set
2: D2 Camera board with IMX214 Camera module
3: Connectivity module with 2 antennas * 1 set
4: Power Adapter * 1 set
Figure 2-1. Genio 700 EVK System

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
6
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
3Genio 700-EVK Board overview
Please refer below picture for IO function overview of EVK.
Figure 3-1. Genio 700 EVK Board verview
Camera CSI1
Connector
Camera CSI0
Connector
Raspberry Pi
Connector
Earphone
Connector
Speaker
Connector
DC
Jack
Battery
Connector
USB(Charger)
Connector
UART2 Debug
Connector
UART1 Debug
Connector
UART0 Debug
Connector
eDP LCM
Connector
DMI Monitor
Connector
USB-C (DP)
Connector
Micro USB
Connector
RJ
-
45
Connector
PWR/RST/ ome/
Download Key
JTAG Connector
MT7921
Module
- M.2 Connector
RF ANT3
Connector
RF ANT1
Connector
RF ANT2
Connector

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
7
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
4LCM older Setup
LCM Holder set up :
Use your hand to turn the screw plastic head
Move the LCD to need a location and twist the screw plastic head tight, as in the picture below.
Figure 4-1. LCM Holder Setup

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
8
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
5Camera DTB board installation
D2 camera install procedure:
Install D2 Camera board into Genio 700 EVK mainboard. Connecter location can be referred to in the picture below.
Figure 5-1. D2 Camera DTB board

MediaTek Proprietary and Confidential. © 2022 MediaTek Inc. All rights reserved. Unauthori ed reproduction or disclosure of this document, in whole or in part, is strictly prohibited.
9
Genio 700
EVK
Genio 700EVK
Q
uick Start Guide
6ow to Power Up the Genio 700 EVK
1. You must install the Camera DTB on the Genio 700 EVK board.
2. Connect UART0 (CN3200) to the computer via an USB cable. (If you want to see the logs.)
3. Power on the system by long pressing Power Key for 4 seconds or Plug a Jumper at J3001 and Auto power on by plug
in of AC adaptor.
4. You will see the boot-up picture on LCD display and trace logs come out from UART0.
Figure 6-1. Plug AC Adapter , Press Power Key and LEDs Status
After the EVK power on, pay attention to the LED indicator is
lighted on.
In normal conditions, there are total 2 LED indicators that will light
Please refer to the marks of above Figure1-2
