MEDIATEK MT7612 User manual

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
Version: 1.02
Release date: 2013-11-21
© 2010 - 2013 MediaTek Inc.
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Specifications are subject to change without notice.
MT7612
802.11 b/g/n/ac Wi-Fi single chip
EEPROM Content
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 2 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Document Revision History
Revision
Date
Author
Description
0.0
2013/07/09
AlexCC Lin
Initial version
1.01
2013/10/11
SP Hsu
Update initial value and description for TC function
1.02
2013/11/21
SP Hsu
Update TC function example (0xF2~0xF5)
Update eLNA gain description (0x44,0x45,0x49,0x4D)
Update NIC setting description (0x25)
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 3 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Table of Contents
Document Revision History............................................................................................................. 2
Table of Contents.............................................................................................................................3
1 General Description................................................................................................................5
1.1 General Descriptions.....................................................................................................5
2 MT7612 EEPROM Layout........................................................................................................6
2.1 E2PROM layout version # (02h)..................................................................................... 11
2.2 WiFi External Component Setting (0x25)........................................................................11
2.3 NIC Configuration 0 (0x34/0x35).................................................................................... 11
2.4 NIC Configuration 1 (0x36/0x37).................................................................................... 12
2.5 Country Region Code for 5G band(0x38).......................................................................14
2.6 Country Region Code for 2.4G band (0x39) ................................................................... 15
2.7 Frequency offset (0x3A)................................................................................................. 16
2.8 LED Mode Setting (0x3B) ..............................................................................................16
2.9 NIC Configuration 2 (0x42/0x43).................................................................................... 16
2.10 External LNA Gain for 2.4GHz (0x44) ............................................................................18
2.11 External LNA Gain for 5GHz (0x45/0x49/0x4D).............................................................. 18
2.12 20M/40M BW Power Delta for 2.4GHz band (0x50h)......................................................19
2.13 20M/40M BW Power Delta for 5G band (0x51h)............................................................. 20
2.14 20M/80M BW Power Delta for 5G band (0x52h)............................................................. 20
2.15 Thermal Sensor Calibration (0x55h)...............................................................................21
2.16 TX0 2.4G PA TSSI Slop /offset (0x56h~0x57h).............................................................21
2.17 TX0 2.4G Target Power/ALC code (0x58h).................................................................... 21
2.18 TX0 2.4G TX Power offset low/middle/high (0x59h~0x5Bh)............................................ 21
2.19 Tx1 2.4G PA TSSI Power Slop /offset (0x5Ch~0x5Dh).................................................. 22
2.20 TX1 2.4G Target Power/ALC code (0x5Eh)....................................................................22
2.21 TX1 2.4G TX Power offset low/middle/high (0x5Fh~0x61h)............................................ 22
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 4 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
2.22 TX0 5G Goup0 PA TSSI Power Slop /offset (0x62h~0x63h)........................................... 22
2.23 TX0 5G Group0 Target Power/ALC code (0x64h)........................................................... 23
2.24 TX0 5G Group0 TX Power offset low/high (0x65h~0x66h)..............................................23
2.25 TX0 5G Goup1 PA TSSI Power Slop /offset (0x67h~0x68h)........................................... 23
2.26 TX0 5G Group1 Target Power/ALC code (0x69h)........................................................... 23
2.27 TX0 5G Group1 TX Power offset low/high (0x6Ah~0x6Bh)............................................. 24
2.28 5G Group0~5 Offset Channel Mapping(0x62~0x9D)...................................................... 24
2.29 XTAL trim 2 (0x9Fh).......................................................................................................26
2.30 TX rate power configuration (0xA0h~0xBFh)..................................................................26
2.31 Reserved for Customer (0x1B8h~0x1BFh)...................................................................28
2.32 Configured 2.4G Channels (0xB0h~B1h) ....................................................................... 28
2.33 USB Vendor ID (0x1C2~0x1C3h)...................................................................................28
2.34 USB Product ID (0x1C4h~0x1C5h)................................................................................28
2.35 USB String Descriptor Index (0x1D6h~0x1DFh)............................................................. 29
2.36 2G/5G Temperature Compensation Enable/Disable (0x36,0x43,0x55)........................... 29
2.37 2G/5G ePA Slope for Temperature Compensation (0xF2h~0xF5h) ................................ 30
2.38 2G/5G ePA Temperature Compensation limit(0x53h~0x54h) .........................................30
2.39 2G/5G ePAeLNA GPIO function (0x25, 0x35, 0x36).......................................................31
2.40 TSSI off 2.4/5G TX power SKU (0xF7, 0xF8).................................................................32
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 5 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
1 General Description
1.1 General Descriptions
The MT7612 EEPROM layout provides configuration for vendor/product ID, SW setting, RF
TX power setting.
Note :
If hardware selects external EEPROM, please follow below EEPROM type.
The following table summarizes EEPROM used in MT7612 series configuration.
EEPROM Type EEPROM size (in byte)
MT7612E
2x2 ac, WIFI @PCIe
93c66 512
MT7612U
2x2 ac, USB3
25060 512
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 6 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
2 MT7612 EEPROM Layout
Offset
Default
(hex) b15 ~b8 b7 ~ b0
00h 7662 Chip ID
02h 0000 EEPROM Version
04h FFFF Mac Address [15:0]
06h FFFF Mac Address [31:16]
08h FFFF Mac Address [47:32]
0Ah 7612 WLAN PCIe Device ID
0Ch 14C3 WLAN PCIe Vendor ID
0Eh 0000 ASIC Reserved
10h 0000 ASIC Reserved
12h 7612 WLAN PCIe subsystem ID
14h 14C3 WLAN PCIE subsystem VendorID
16h 0000 ASIC Reserved
18h 0000 ASIC Reserved
1Ah FFFF ASIC Reserved
1Ch FFFF ASIC Reserved
1Eh FFFF ASIC Reserved
20h FFFF ASIC Reserved*
22h D837 ASIC Reserved*
24h 009D
For wifi external component
setting AUX Option
26h 7FFF ASIC Reserved*
28h 9BFD ASIC Reserved*
2Ah FFFF ASIC Reserved*
2Ch FFFF ASIC Reserved*
2Eh FFFF ASIC Reserved*
30h FFFF ASIC Reserved*
32h FFFF ASIC Reserved*
34h FF22 NIC Configuration 0
36h 2000 NIC Configuration 1
38h FFFF Country Region 2.4G band Country Region 5G band
3Ah 0180 LED Mode Frequency offset
3Ch 0000 LED Reserved
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 7 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset
Default
(hex) b15 ~b8 b7 ~ b0
3Eh 0000 LED Reserved
40h 0000 LED Reserved
42h DFFF NIC Configuration 2
44h 0000
External LNA gain for 5G
Band(CH36~CH64) External LNA gain for 2.4G Band
46h 0000 2.4G RSSI1 offset 2.4G RSSI0 offset
48h 0000
External LNA gain for 5G
Band(CH100~CH128) Reserved
4Ah 0000 5G RSSI1 offset 5G RSSI0 offset
4Ch 0000
External LNA gain for 5GBand
(CH132~CH165) ASIC Reserved*
4Eh 01E0
ASIC Reserved*
ASIC Reserved*
50h 0000
20M/40M BW Power delta for 5G
band 20M/40M BW Power delta for 2.4G band
52h 0000
2G ePA temperature compensation
limit 20M/80M BW Power delta for 5G band
54h 0000 ASIC Reserved* 5G ePA temperature compensation limit
56h TX0 2.4G PA TSSI offset TX0 2.4G PA TSSI slope
58h TX0 2.4G TX power offset low
TX0 2.4G TX power (TSSI on)
TX0 2.4G TX ALC CODE (TSSI off)
5Ah TX0 2.4G TX power offset high TX0 2.4G TX power offset middle
5Ch TX1 2.4G PA TSSI offset TX1 2.4G PA TSSI slope
5Eh TX1 2.4G TX power offset low
TX1 2.4G TX power (TSSI on)
TX1 2.4G TX ALC CODE (TSSI off)
60h TX1 2.4G TX power offset high TX1 2.4G TX power offset middle
62h TX0 5G PA TSSI offset (Group0) TX0 5G PA TSSI slope(Group0)
64h TX0 5G TX power offset low(Group0)
TX0 5G TX power(Group0) ( TSSI on )
TX0 5G TX ALC CODE(Group0)( TSSI off )
66h TX0 5G PA TSSI slope(Group1) TX0 5G TX power offset high(Group0)
68h
TX0 5G TX power(Group1)( TSSI on )
TX0 5G TX ALC CODE(Group1)
( TSSI off ) TX0 5G PA TSSI offset (Group1)
6Ah TX0 5G TX power offset high(Group1)
TX0 5G TX power offset low(Group1)
6Ch TX0 5G PA TSSI offset (Group2) TX0 5G PA TSSI slope(Group2)
6Eh TX0 5G TX power offset low(Group2)
TX0 5G TX power(Group2) ( TSSI on )
TX0 5G TX ALC CODE(Group2)( TSSI off )
70h TX0 5G PA TSSI slope(Group3) TX0 5G TX power offset high(Group2)
72h
TX0 5G TX power(Group3) ( TSSI
on )
TX0 5G TX ALC
CODE(Group3)( TSSI off )
TX0 5G PA TSSI offset (Group3)
74h TX0 5G TX power offset high(Group3)
TX0 5G TX power offset low(Group3)
76h TX0 5G PA TSSI offset (Group4) TX0 5G PATSSI slope(Group4)
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 8 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset
Default
(hex) b15 ~b8 b7 ~ b0
78h TX0 5G TX power offset low(Group4)
TX0 5G TX power(Group4) ( TSSI on )
TX0 5G TX ALC code (Group4) ( TSSI off )
7Ah TX0 5G PATSSI slope(Group5) TX0 5G TX power offset high(Group4)
7Ch
TX0 5G TX power(Group5) ( TSSI
on )
TX0 5G TX ALC code(Group5) ( TSSI
off )
TX0 5G PA TSSI offset (Group5)
7Eh TX0 5G TX power offset high(Group5)
TX0 5G TX power offset low(Group5)
80h TX1 5G PA TSSI offset (Group0) TX1 5G PATSSI slope(Group0)
82h TX1 5G TX power offset low(Group0)
TX1 5G TX power(Group0) ( TSSI on )
TX1 5G TX ALC code (Group0) ( TSSI off )
84h TX1 5G PATSSI slope(Group1) TX1 5G TX power offset high(Group0)
86h
TX1 5G TX power(Group1) ( TSSI
on )
TX1 5G TX ALC code(Group1) ( TSSI
off )
TX1 5G PA TSSI offset (Group1)
88h TX1 5G TX power offset high(Group1)
TX1 5G TX power offset low(Group1)
8Ah TX1 5G PA TSSI offset (Group2)
TX1 5G PATSSI slope(Group2)
8Ch TX1 5G TX power offset low(Group2)
TX1 5G TX power(Group2) ( TSSI on )
TX1 5G TX ALC CODE(Group2) ( TSSI off )
8Eh TX1 5G PA TSSI slope(Group3) TX1 5G TX power offset high(Group2)
90h
TX1 5G TX power(Group3) ( TSSI
on )
TX1 5G TX ALC CODE(Group3)
( TSSI off )
TX1 5G PA TSSI offset (Group3)
92h TX1 5G TX power offset high(Group3)
TX1 5G TX power offset low(Group3)
94h TX1 5G PA TSSI offset (Group4) TX1 5G PA TSSI slope(Group4)
96h TX1 5G TX power offset low(Group4)
TX1 5G TX power(Group4) ( TSSI on )
TX1 5G TX ALC CODE(Group4) ( TSSI off )
98h TX1 5G PA TSSI slope(Group5) TX1 5G TX power offset high(Group4)
9Ah
TX1 5G TX power(Group5) ( TSSI
on )
TX1 5G TX ALC CODE(Group5)
( TSSI off )
TX1 5G PA TSSI offset (Group5)
9Ch TX1 5G TX power offset high(Group5)
TX1 5G TX power offset low(Group5)
9Eh XTAL trim 2 Reserved
A0h 2.4G TX power for CCK 5.5M/11M 2.4G TX power for CCK 1M/2M
A2h 2.4G TX power for OFDM 12M/18M 2.4G TX power for OFDM 6M/9M
A4h 2.4G TX power for OFDM 48M/54M 2.4G TX power for OFDM 24M/36M
A6h
2.4G/5G TX power for HT/VHT
MCS=2,3 2.4G/5G TX power for HT/VHT MCS=0,1
A8h
2.4G/5G TX power for HT/VHT
MCS=6,7 2.4G/5G TX power for HT/VHT MCS=4,5
AAh 2.4G/5G TX power for HT MCS10,11
2.4G/5G TX power for HT MCS8,9
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 9 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset
Default
(hex) b15 ~b8 b7 ~ b0
ACh 2.4G/5G TX power for HT MCS14,15
2.4G/5G TX power for HT MCS12,13
AEh
Reserved
Reserved
B0h
Configured 2.4G Channels
Configured 2.4G Channels
B2h 5G Tx power for OFDM 12M/18M 5G Tx power for OFDM 6M/9M
B4h
5G Tx power for OFDM 48M/54M
5G Tx power for OFDM 24M/36M
B6h
Configured 5G Channels
Configured 5G Channels
B8h
Configured 5G Channels
Configured 5G Channels
BAh Reserved Reserved
BCh Reserved Reserved
BEh
TX power for 2.4G VHT MCS8,9
TX power for 5G VHT MCS8,9
F2h
5G ePA NT to low temp slope
5G ePA NT to high temp slope
F4h
2G ePA NT to low temp slope
2G ePA NT to high temp slope
F6h
TSSI off 2G TX power SKU (54M
dBm)
Reserved
F8h
RF0/1 2.4G RX High Gain (Group0)
TSSI off 5G TX power SKU (54M dBm)
FAh
RF0/1 5G RX High Gain (Group1)
RF0/1 5G RX High Gain (Group0)
FCh
RF0/1 5G RX High Gain (Group3)
RF0/1 5G RX High Gain (Group2)
FEh
RF0/1 5G RX High Gain (Group5)
RF0/1 5G RX High Gain (Group4)
130h
ASIC Reserved*
ASIC Reserved*
132h
ASIC Reserved*
ASIC Reserved*
134h
ASIC Reserved*
ASIC Reserved*
136h
ASIC Reserved*
ASIC Reserved*
138h
13Ah
13Ch
1C2h 0E8D
USB descriptor : idVendor
1C4h 7612
USB descrptor : idProduct
1C6h 0100
ASIC reserved
ASIC Reserved
1C8h 0111
ASIC reserved
ASIC reserved
1CAh 0000
ASIC reserved
ASIC reserved
1CCh E1A0
USB descriptor : Max Power
ASIC reserved
1CEh 0010
ASIC reserved
ASIC reserved
1D0h 0040
ASIC reserved
ASIC reserved
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 10 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset
Default
(hex) b15 ~b8 b7 ~ b0
1D2h 0080
ASIC reserved
ASIC reserved
1D4h FE1E
ASIC reserved
ASIC reserved
1D6h FFFF
USB descriptor : String descriptor
USB descriptor : String descriptor
1D8h FFFF
USB descriptor : String descriptor
USB descriptor : String descriptor
1DAh FFFF
USB descriptor : String descriptor
USB descriptor : String descriptor
1DCh FFFF
USB descriptor : String descriptor
USB descriptor : String descriptor
1DEh FFFF
USB descriptor : String descriptor
USB descriptor : String descriptor
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 11 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
2.1 E2PROM layout version # (02h)
Value
Description
0Version 0.
1 ~ 255 Invalid version. Treat as version 0.
2.2 WiFi External Component Setting (0x25)
Offset Field Description
25h
4:0 Reserved.
7:5 000: No external RF component GPIO ( iPAiLNA )
010 : Support external RF component GPIO (ePAeLNA)
110 : Internal PA 3 antenna mode for WIFI BT combo chip
External component GPIO usage will need to co-setting with 0x35 and 0x36.
2.3 NIC Configuration 0 (0x34/0x35)
0x35
0x34
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Reserved Board
type Reserved
PA
driving
External
PA TX Path setting RX Path setting
Reserved Reserve
d Reserved
PA
driving
1:1TX
2: 2TX
1: 1RX
2: 2RX
NIC Configuration 0 Register Bit Fields Description
Offset Field Description
34h
3:0
RX front-end architecture in the system.
0 (0000): Reserved.
1 (0001): 1 RX front-end in the system.
2 (0010): 2 RX front-end in the system.
3 ~ F (0011 ~ 1111): Reserved.
7:4
TX front-end architecture in the system.
0 (0000): Reserved.
1 (0001): 1 TX front-end in the system.
2 (0010): 2 TX front-end in the system.
3~ F (0011 ~ 1111): Reserved.
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 12 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset Field Description
35h
1:0
external PA
00: 2.4G+5G external PA
01: 5G external PA
10: 2.4G external PA
11: disable
2
External PA current setting –
the IO driving current setting for external PA control
pin
1: 8 mA (default)
0: 16mA
3 Reserved.
5:4 Reserved for define the board type.
7:6 Reserved.
2.4 NIC Configuration 1 (0x36/0x37)
Bit[7:0]=0xFF will be treated as INVALID and used Default Value.
Bit[15:8]=0xFF will be treated as INVALID and used Default Value
0x36
7
6
5
4
3
2
1
0
WPS
PBC
5G side band
for 40M BW
2.4G side band
for 40M BW Proprietary
Test bit
EXT LNA
5G
EXT LNA
2.4G
Tx temp.
scheme en
HW CTRL
0: off (D)
1: on 0: off(D)
1: on 0: off
1: on(D) 0: off(D)
1: on 0: off
1: on 0: off
1: on 0: off(D)
1: on 0: off(D)
1: on
0x37
7
6
5
4
3
2
1
0
DAC
test bit BT Coexist
TSSI Power
compensation
en
Antenna Diversity Broadband
EXT LNA
40M BW in
5G band
40M BW in
2.4G band
0: off (D)
1: on 0: off (D)
1: on 0: off(D)
1: on 00: Disable (D) 0: off
1: on 0: on (D)
1: off 0: on (D)
1: off
NIC Configuration 1 Register Bit Fields Description
Offset Field Description
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 13 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset Field Description
36h
0
Hardware Radio Control.
0: disable hardware radio control (default value).
1: enable hardware radio control.
When “hardware radio control” bit is enabled (=1), the driver will read MAC’s
GPIO
status. When GPIO pin is low, the radio is disabled. When GPIO
pin is high, the
radio is enabled.
The Radio ON/OFF is controlled by both software UI and MAC’s GPIO pin.
1
TX power temperature compensation scheme enable (TC enable)
0 : disable temperature compensation
1 : Enable temperature compensation
This bit will disable/enable temperature compensation scheme.
While this bit is enable, it means Tx power TSSI scheme is disable(0x37 bit5 = 0)
and using TC scheme.
User must fill 0x53~0x54 and 0xF2~0xF5 for TC usage.
2 External 2.4GHz band LNA.
0: Board without external LNA for 2.4GHz band must set this bit to 0.
1: Board with external LNA for 2.4GHz band must set this bit to 1 (default value).
3 External 5GHz band LNA.
0: Board without external LNA for 5GHz band must set this bit to 0.
1: Board with external LNA for 5GHz band must set this bit to 1.
4 Proprietary TEST BIT.
For debug purpose. Default value is 0.
5 2.4GHz side band for 40MHz BW.
For debug purpose.
6 5G side band for 40M BW
For debug purpose.
7
WPS Push Button Configuration control.
0: disable WPS PBC control (default value).
1: enable WPS PBC control.
The WPS PBC function is controlled through GPIO[11].
If LED mode set to “Signal strength”(64), WPS PBC will be disabled.
37h 0 40M BW in 2.4GHz band.
0: enable 40MHz bandwidth for 2.4GHz band
1: disable 40MHz bandwidth for 2.4GHz band
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 14 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset Field Description
1 40M BW in 5G band
0: enable 40MHz bandwidth for 5GHz band.
1: disable 40MHz bandwidth for 5GHz band.
2 Broadband EXT LNA
0: Board without external LNA must set this bit to 0.
1: Board with external LNAmust set this bit to 1.
4:3
Antenna Diversity control.
Bit[12:11]:
00: disable diversity function (default value).
Not support
5
TSSI power compensation enable
0 : disable TSSI power compensation , use per-group ALC code , like ePA case
1 : enable TSSI power compensation, TSSI slop offset scheme.
6 BT Coexist
0: Disable BT coexistence.
1: Enable BT coexistence.
7 DAC test bit
0: Disable DAC test.
1: Enable DAC test.
2.5 Country Region Code for 5G band(0x38)
Default value = FFh, which means read from INF and registry, more flexible than reading from
EEPROM, this is our current InstallShield CCS implementation. We do not recommend
customers to read SKU from EEPROM. therefore, FFh is our default value.
CountryCode— Specify the domain code, can be FFh or one of the followings,
Index Support Channels
0 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165
1 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136,
140
2 36, 40, 44, 48, 52, 56, 60, 64
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 15 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
3 52, 56, 60, 64, 149, 153, 157, 161
4 149, 153, 157, 161, 165
5 149, 153, 157, 161
6 36, 40, 44, 48
7
0, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149,
153, 157, 161, 165
8
6, 60, 64
9
0, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140, 149, 153, 157, 161,
165
10
0, 44, 48,149, 153, 157, 161, 165
11
0, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 149, 153, 157, 161
12
0, 44, 48, 52, 56, 60,
64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140
13
6, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161
14
0, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 136, 140, 149, 153, 157, 161, 165
15
153, 157, 161, 165
, 169, 173
16
0, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149,
153, 157, 161, 165, 169, 173
30
al Channels (Refer to 0x11A
h~11Dh)
Note: 1.) If set to Index #12, it will also turn on 802.11h and Carrier Detection by default
2.) The index value is decimal system.
2.6 Country Region Code for 2.4G band (0x39)
Default value = FFh, which means read from INF and registry, more flexible than reading
from EEPROM, this is our current InstallShield CCS implementation. We do not
recommend customers to read SKU from EEPROM. Value FFh is the default value.
CountryCode— Specify the domain code, can be FFh or one of the followings,
Index Support Channels
0 CH 1 ~ 11
1 CH 1 ~ 13
2 CH 10 ~ 11
3 CH 10 ~ 13
4 CH 14
5 CH 1 ~ 14
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 16 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
6 CH 3 ~ 9
7 CH 5 ~ 13
30 Manual Channel (Refer to 0x118h~119h)
31 CH1 ~ 14 (CH1 ~ 11 active scan, CH12 ~ 14 passive scan)
32 CH1 ~ 13 (CH1 ~ 11 active scan, CH12 ~ 13 passive scan)
33 802.11b: CH1 to CH14 are active scan.
802.11g/n: CH1 to CH13 are active scan. CH14 is disallowed
Notes: If set to read SKU from EEPROM, only available if 2.4G Country Region code
registers are programmed.
2.7 Frequency offset (0x3A)
Used for crystal calibration. 0x3Ais used for MTK FT test only for crystal calibration-free feature.
MTK wafer manufactory used 0x3A, bit 0~6, to store frequency offset value which is measured under
MTK FT environment. Each IC has each corresponding frequency offset .
If customers want to re-burn crystal trim value, please use 0x9F as 2nd crystal trim offset.
Offset Field Description
3Ah
6:0 Crystal trim value ( Cap ID )
K-free IC will fill value in MTK FT production line for each chip.
7 0: DIP type
1: SMT type
2.8 LED Mode Setting (0x3B)
2.9 NIC Configuration 2 (0x42/0x43)
0x43
0x42
Bit <7:5>
4
3
2:1
0
7
6
5
4
3
2
1
0
Co-
exist stream
mode Reserved
25C
Temperature
Disable
Xtal
option HW
Ant
Div
TX Stream RX Stream
1: 1 Stream
2: 2 Stream
1: 1 Stream
2: 2 Stream
Note:
1. The 1 stream support MCS0~MCS7. The 2 stream support MCS0~MCS15.
2. Stream setting should be equal or less than path setting of EEPROM (0x34)
3. Default=0xFF means that based on the path setting (0x34) for MAX capability.
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 17 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
NIC Configuration 2 Register Bit Fields Description
Offset Field Description
42h
3:0
RX stream.
0 (0000): Reserved
1 (0001): 1 RX stream
2 (0010): 2 RX stream
3 ~ F (0011 ~ 1111): Reserved.
7:4
TX stream.
0 (0000): Reserved
1 (0001): 1 TX stream
2 (0010): 2 TX stream
3 ~ F (0011 ~ 1111): Reserved.
43h
0 Not support
2:1
Xtal option:
00 : reserved
01 : One crystal, enable co-clock out
10 : reserved
11 : reserved
3 25C Temperature disable bit
0 : Enable
1 : Disable
4 Reserved.
7:5
Reserved
Co-exist stream mode : default is 110
1 : 1x1 , no co-exist , Pure BT
2 : 1T2R, no co-exist , Pure WIFI
3 : 1T2R, no co-exist, Pure WIFI
4 : WLAN 1x1 and BT co-exist ,
5 : WLAN 2x2, no co-exist
6 : WLAN 2x2 and BT co-exist
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 18 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
2.10 External LNA Gain for 2.4GHz (0x44)
0x44
7
6
5
4
3
2
1
0
Sign
bit External LNAGain for 2.4G
External LNA Gain for 2.4GHz Register Bit Fields Description
Offset Field Description
42h
6:0
External LNA gain for 2.4GHz
000000 : 0dB
000001 : 1dB
000010 : 2dB
This value should be reasonable for external component spec.
111111 won’t be invalid.
7 Sign bit
1: plus “ + “
0: minus “ – “
Example:
The default eLNA gain value would be 0x8C and it means “ +12dB”.
2.11 External LNA Gain for 5GHz (0x45/0x49/0x4D)
0x45
7
6
5
4
3
2
1
0
Sign
bit External LNAGain for 5G(CH36~CH64)
0x49
7
6
5
4
3
2
1
0
Sign
bit External LNAGain for 5G(CH100~CH128)
0x4D
7
6
5
4
3
2
1
0
Sign
bit External LNAGain for 5G(CH132~CH165)
External LNA Gain for 5GHz Register Bit Fields Description
Offset Field Description
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 19 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
Offset Field Description
45h
49h
4Dh
6:0
External LNA gain for 5GHz
000000 : 0dB
000001 : 1dB
000010 : 2dB
This value should be reasonable for external component spec.
111111 won’t be invalid.
7 Sign bit
1: plus “ + “
0: minus “ – “
Example:
The default eLNA gain value would be 0x8C and it means “ +12dB”.
2.12 20M/40M BW Power Delta for 2.4GHz band (0x50h)
Driver compensates the TX power value of 40M BW with this configured value. (unit : 0.5dm)
TX power delta configuration Register Bit Fields Description
Offset
Field
Description
50h
5:0
40M BW TX power delta value (MAX=4dBm).
000001: 0.5dBm
000010: 1dBm
000011: 1.5dBm
000100: 2dBm
000101: 2.5dBm
000110: 3dBm
000111: 3.5dBm
001000: 4dBm
6 1: increase 40M BW TX power with the delta value.
0: decrease 40M BW TX power with the delta value.
7 1: enableTX power compensation.
Example:
The default calibrated TX power as followings with the TX power delta configuration is not
enable.
- 40M BW TX power= 14dBm and 20M BW TX power = 14dBm
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY

[email protected],time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 20 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictlyprohibited.
If want keep 20M BW TX power in 14dBm and reduce 40M BW TX power to 10dBm
(delta=4dBm), set 50h = 88h (1000 1000).
2.13 20M/40M BW Power Delta for 5G band (0x51h)
Offset Field Description
0x51h
5:0
40M BW TX power delta value (MAX=4dBm).
000001: 0.5dBm
000010: 1dBm
000011: 1.5dBm
000100: 2dBm
000101: 2.5dBm
000110: 3dBm
000111: 3.5dBm
001000: 4dBm
6 1: increase 40M BW TX power with the delta value.
0: decrease 40M BW TX power with the delta value.
7 1: enable TX power compensation.
2.14 20M/80M BW Power Delta for 5G band (0x52h)
Offset
Field
Description
0x52h
5:0
80M BW TX power delta value (MAX=4dBm).
000001: 0.5dBm
000010: 1dBm
000011: 1.5dBm
000100: 2dBm
000101: 2.5dBm
000110: 3dBm
000111: 3.5dBm
001000: 4dBm
6 1: increase 80M BW TX power with the delta value.
0: decrease 80M BW TX power with the delta value.
7 1: enable TX power compensation.
MEDIATEK CONFIDENTIAL
FOR danielwu@ synnex.com.tw USE ONLY
Table of contents
Other MEDIATEK Motherboard manuals

MEDIATEK
MEDIATEK Genio 350 User manual

MEDIATEK
MEDIATEK Genio 1200 User manual

MEDIATEK
MEDIATEK Genio 700 EVK User manual

MEDIATEK
MEDIATEK Genio 700 EVK User manual

MEDIATEK
MEDIATEK LinkIt Smart 7688 Specification sheet

MEDIATEK
MEDIATEK Genio 1200 User manual

MEDIATEK
MEDIATEK Genio 350 Installation manual

MEDIATEK
MEDIATEK LinkIt 7697 HDK User manual

MEDIATEK
MEDIATEK Genio 700 Installation manual

MEDIATEK
MEDIATEK LinkIt Smart 7688 Instruction Manual
