Medion S88411 User manual

User Manual
WIFI HARD DRIVE 1 TB
S88411

2
A
1
11
3
4
5
7
8
9
10
6
2

3
Scope of delivery/device parts
1NFC transponder
2Battery LED
3Hard drive LED
4WiFi LED
5Internet LED
6SD card reader
7LAN socket (RJ45 socket)
8RESET button
9USB 3.0 Micro-B connection for charging the internal battery/
exchanging data
10 ON/OFF switch
11 USB connection for charging another device (when WiFi hard
drive/exchange of data switched off/ when switched on with a
WiFi connection)

Contents
4
Contents
Scope of delivery/device parts ..................................... 3
Package contents ..........................................................6
General information ......................................................6
Reading and safekeeping of operating instructions....6
Symbols and key words used in these instructions......7
Intended use..................................................................9
Safety information.........................................................9
General information ..........................................................9
Declaration of conformity.............................................13
Before use .....................................................................14
System requirements ...................................................... 14
File format of the hard drive........................................... 14
Overview of the LED displays.......................................... 15
Connections.................................................................. 16
USB connection on the right side of the device........... 16
USB 3.0 Micro-B connection ............................................ 16
RJ45 LAN socket................................................................. 16
SD card reader ...................................................................17
NFC transponder ...............................................................17
Using the device for the first time............................... 18
Charging the battery ....................................................... 18
Switching on the device.................................................. 19
Operation ..................................................................... 19
Admin access and guest access .....................................20
Network connection to a notebook/PC.........................20
Installing the Smart Storage app on an Android/
iOS smartphone/tablet PC................................................21

Contents
5
Establishing a network connection to a
smartphone or tablet ......................................................22
File management via the Android/iOS app ................ 23
Home screen for the app ................................................24
Videos, photos, music and documents.........................25
Files ....................................................................................26
Navigation in the app...................................................... 27
System ...............................................................................28
Web interface on the WiFi hard drive...........................31
Videos, photos, music and documents.........................33
Explorer .............................................................................33
Settings ........................................................................ 35
Information.......................................................................35
User ....................................................................................36
Network.............................................................................36
Services..............................................................................38
System ...............................................................................39
Wizard ............................................................................... 40
WLAN HDD Tool ............................................................. 42
Resetting the device.................................................... 43
Do you need more help?..............................................44
Cleaning .......................................................................44
Disposal........................................................................ 45
Technical data ..............................................................46
Glossary........................................................................ 47
Legal notice..................................................................50

Package contents
6
Package contents
WARNING!
Risk of suffocation!
There is a risk of suffocation from plastic
packaging.
− Keep plastic packaging out of the reach
of children.
After unpacking the product, please ensure that the following
parts have been supplied:
• WiFi hard drive
• Mains adapter (KSAS0050500100VAU, manufacturer:
Ktec, China) with USB cable
• Operating instructions and warranty documents
General information
Reading and safekeeping of operating
instructions
These operating instructions are for this WiFi hard
drive. They contain important information about set-
up and operation.
Before using the device for the first time, read these
operating instructions thoroughly and follow the
safety advice! This device may only be used as
described in the operating instructions.

General information
7
Always keep these operating instructions at hand and store
them safely so that you can pass them on to the new owner if
you sell the device!
Symbols and key words used in these
instructions
The following symbols and signal words are used in these
operating instructions, on the device or on the packaging.
DANGER!
This signal word indicates a hazard with a high degree of risk
which, if not avoided, will result in death or serious injury.
WARNING!
This signal word indicates a hazard with a medium level of risk
which, if not avoided, could lead to death or serious injury.
CAUTION!
This signal word indicates a hazard with a low level of risk
which, if not avoided, could result in a minor or moderate
injury.
NOTICE!
This signal word warns of possible damage to property or
gives useful additional information on assembly or operation.

General information
8
Heed the advice in the operating instructions
This symbol gives you useful additional
information on operation
Recycling symbol
WEEE symbol (in accordance with the directive
on electrical waste)
Symbol indicating that batteries must be
disposed of separately
Declaration of conformity (see section
“Declaration of conformity”): Products that
feature this symbol meet the requirements of
the EC directives.
DC current

Intended use
9
Intended use
This device is a USB hard drive whose data can be made
available to other wireless communicating devices via the
integrated WLAN access point. In addition, the device has
USB connections for transferring data, charging the internal
battery and charging another device.
Never use the device for any other purpose.
Only use the device indoors.
This device is only designed for private use and is not suitable
for commercial purposes.
Safety information
General information
WARNING!
Danger for children and people with
reduced ability to operate devices
− This device is not intended for use
by people (including children) with
reduced physical, sensory or mental
abilities or by those without experience
and/or knowledge, unless they are
supervised by a person responsible for
their safety or they have been instructed
in its use by that person. Children should

Safety information
10
be supervised to ensure they do not play
with this device.
− Always adhere to the user instructions of
the devices that you connect to the WiFi
hard drive.
− Do not place liquid-filled containers,
such as vases, on or near the device. The
container may tip over and the liquid
may impair the electrical safety of the
product.
− Keep the device away from moisture and
from splashes or sprayed water. Avoid
knocks, dust, heat and direct sunlight
in order to prevent malfunction. The
operating temperature is 5-35° C.
− Never open the housing of the device.
This invalidates the warranty and may
render the device unusable.
− After transporting the device, wait until
it has reached room temperature before
switching it on. Major fluctuations in
temperature or humidity can lead to
condensation which could cause an
electrical short-circuit.

Safety information
11
− The device is intended to be connected
to computers with power supply fuse
protection (limited power source
according to EN60950).
− Position the cable so that it cannot be
stepped on or tripped over.
− Do not place any objects on the cables as
they may be damaged.
− To avoid static charges, you should not
operate the device in extremely dry
conditions.
− In circumstances where there are
electrostatic discharges, the device could
malfunction. In this case, the device
must be reset to the factory settings.
WARNING!
Risk due to an improper electrical
connection
− Only operate the mains adapter for the
WiFi hard drive from an easily accessible
and earthed socket with an AC 100-240
V~ 50 Hz power supply.
− Use only the mains adapter supplied
(KSAS0050500100VAU, manufacturer:

Safety information
12
Ktec, China). Never try to plug the mains
adapter into other sockets as this may
cause damage.
Notes on data security
We do not accept any liability for
claims for compensation due to loss
of data or any damages that are
incurred as a result. Always backup
your data onto an external storage
device (e.g. CD-R) before updating it.

Declaration of conformity
13
Declaration of conformity
Medion AG hereby declares that the product MD
92411 conforms to the following European
requirements:
• R&TTE Directive 1999/5/EC
• EMC Directive 2014/30/EU
• Low Voltage Directive 2014/35/EU
• RoHS Directive 2011/65/EU
Full declarations of conformity are available at
www.medion.com/conformity.

Before use
14
Before use
System requirements
In order to use the WiFi hard drive, the following device
configuration is required:
• WiFi standard 802.11b/g/n
• Windows 10/Windows 8/Microsoft Windows® 7,
Mac OS 10.6 or newer
Android 2.2 or newer, iOS 4.0 or newer
File format of the hard drive
The WiFi hard drive is formatted using the NTFS file system on
delivery.
− You can also format the hard drive via your PC in FAT32 or
exFAT format.

Before use
15
Overview of the LED displays
LED Colour Status Description
Battery
LED
Green Lit Battery is charged
Flashing Battery charging
Red Lit Battery needs charging
Hard drive
LED
White Lights
up
Hard drive is ready
(connected via a USB2
connection)
Flashes Hard drive activity
Blue Hard drive is ready
(connected via a USB3
connection)
Hard drive activity
WLAN LED Blue Lights
up
The WLAN access point
is ready.
Flashes The WLAN access point
is starting
Off The WLAN access point
is switched off
Internet
LED
Green Lights
up
Internet connection
Off No Internet connection

Connections
16
Connections
USB connection on the right side of the
device
If the device is switched off, you can charge batteries in other
devices such as e.g. smartphones via the USB connection on
the side of the device.
Push the Power button to charge the device.
If the device is in WiFi mode, this USB connection can be used
to transfer data between a USB stick and the hard drive.
USB 3.0 Micro-B connection
The USB 3.0 Micro-B connection is used for charging the
internal battery. When the device is switched off, you can use
this connection to access the hard drive from a PC.
RJ45 LAN socket
The WiFi hard drive can be directly connected to a router via
the RJ45 LAN socket.
Devices that log into the access point on the WiFi hard drive
can thus wirelessly access the Internet access provided by the
router.
In this case, the Internet access settings need to be
set to "cable connection" (see “Internet settings” on
page 28 or “WiFi & LAN” on page 36).

Connections
17
SD card reader
You can use the SD card reader to connect SD cards (up to 64
GB SDHC) to the WiFi hard drive.
One Touch Copy function
You can directly copy data from an SD card onto the hard drive
at the touch of a button. The data is saved in the
"SD-BACKUP" directory.
1. Switch the WiFi hard drive on.
2. Insert an SD card into the SD card reader on the WiFi hard
drive.
3. Press the POWER button twice in succession.
The hard drive LED and the WiFi LED will flash quickly. All of the
data on the SD card will now be copied to the WiFi hard drive.
Once the copying process has been completed, both of the
LEDs will be permanently lit again.
NFC transponder
This function is only available for Android devices.
iOS devices do not generally have any NFC
transponders.
The NFC (Near Field Communication) function enables the
wireless configuration of the WiFi connection between an NFC-
enabled smart device and the WiFi hard drive.
1. Switch on the WiFi hard drive by holding down the
ON/OFF switch until the battery LED lights up (see
“Switching on the device” on page 19).
2. Switch on the NFC function on your smart device.

Using the device for the first time
18
3. Hold your NFC-enabled smartphone over the area
marked 1.
4. The smartphone will now automatically establish a WiFi
connection to the WiFi hard drive. The WiFi LED flashes
while the connection is being established.
The pairing process for both devices is complete when the
WiFi LED is permanently lit. The Smart Storage app will
automatically open on the smart device.
It is firstly necessary to install the app on your smart
device as described under “File management via
the Android/iOS app” on page 23.
Using the device for the first time
Charging the battery
The WiFi hard drive has an integrated battery.
You can charge the battery either using the supplied USB
mains adapter or via a USB connection on your PC or another
device with a USB connection.
− Connect the USB cable to the USB 3.0 Micro-B connection
on the WiFi hard drive.
− Connect the other end of the cable to the USB mains
adapter and plug it into the mains socket.
− Alternatively, connect the USB cable to the USB
connection on your PC or another device which delivers 5
V output voltage at its USB connection.
If charging the WiFi hard drive via a PC, the WiFi hard
drive must be switched on and set to WiFi mode.

Operation
19
Charge status LEDs
• The battery LED flashes continuously during the
charging process.
• When the battery is fully charged, the battery LED will be
permanently lit.
Switching on the device
− In order to switch the WiFi hard drive on, hold down the ON/
OFF switch (for at least 5 seconds) until the battery LED is lit.
• The battery LED will flash while the system is starting up.
• Afterwards, the Battery LED will be permanently lit. The
WiFi hard drive is now ready to use.
Switching off the device
• Hold down the ON/OFF switch for about 5 seconds to
switch off the WiFi hard drive.
All LEDs will switch off.
Operation
The WiFi hard drive is configured as a wireless access point (AP).
Other wireless communication devices (clients) such as tablet PCs,
smartphones or notebooks can log into the access point and thus
access the data on the hard drive via the WiFi connection.
When using the device as an access point for the
first time, place the client as near as possible to the
WiFi hard drive. Following a successful installation,
the hard drive can be set up in any position within
range.

Operation
20
Admin access and guest access
Admin access enables you to change all of the system settings
and provides you with access to all directories and connected
data media.
You can set up guest access via the admin access. Users who
are logged in as a guest only have read and write access to
files and folders in the "SHARE" directory on the WiFi hard
drive. In addition, guests can only change the cache and the
language in the system settings and are only able to view
information on the firmware.
In order to activate guest access, move the "Guest" setting in
the system settings to the right while logged in with admin
access.
Network connection to a notebook/PC
− Switch the WiFi hard drive on.
− Search for the "WLAN-HDD XXXX" network in the
list of available wireless networks on your notebook/PC
and connect the device to this network.
Example connection via Windows
− When prompted, enter the network password
(Password) given on the type plate on the rear of the
WiFi hard drive.
