Mediso Nucline SPIRIT DH-V User manual

Nucline
TM SPIRIT DH-V
DUAL - HEAD SPECT AND WHOLE BODY
DIGITAL GAMMA CAMERA
Operator's Manual
Revision 3.04

Part number: DV-93-10-03
The information and drawings set forth in this manual are the property of
Mediso Ltd. No part of this document may be copied without the prior consent
of Mediso Ltd.
Manufacturer reserves the right to revise or update the contents of this manual
due to modifications or improvements in the design of the equipment without
obligation to notify any person or organization of such changes.
Nucline is a registered trademark of Mediso Ltd.
Other brand or product names are trademarks or registered trademarks of their
respective holders.
Mediso Ltd. - Medical Imaging Systems
Address: H-1022 Budapest, Alsótörökvész út 14. HUNGARY
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]

Revision 3.04 3/195
Disclaimer
Mediso Ltd. and its official representatives may not be held responsible for
personal injury or damage of any kind, expressed or implied, caused by, or
emerging out of the use of this equipment, if equipment is not operated in
adherence to operating and maintenance procedures set forth in this manual.
Users exchanging files and diskettes should beware of the risk of computer
viruses. Damage caused by user provided programs, scripts, or computer
viruses are NOT warranted by Mediso Ltd.
Warning
Electrical
Failure to provide an adequate earth ground circuit can result in a
shock hazard which can cause serious personal injury.
Only properly trained personnel should be permitted access to any
internal part of the equipment. Live electrical terminals and components inside
electronics cabinets can present a shock hazard and can cause serious or fatal
injury.
Maintenance and service routines beyond those mentioned in this manual must be
referred to service personnel authorized by the manufacturer. In the absence of
appropriate instructions in this manual do not attempt to make service work on the
equipment.
When this equipment is interconnected with other electrical appliances in its normal
operation, it is important, that these other appliances also be provided with adequate
grounding protection. Faults occurring in any interconnected appliance can degrade
the safety of this product.
Mechanical
All moveable assemblies and supporting structures should be operated with care and
routinely inspected. Any collision which could damage the equipment, worn
components, unusual noises or difficulties in operation should be reported to the
manufacturer's office immediately.
Radiation
This equipment does not generate any hazardous radiation. When using radioactive
isotopes or compounds, safe and proper handling techniques should always be
observed. If radioactive contamination occurs, use the decontamination agent and
method as described in your site protocol to clean the outside of the equipment.

Nucline SPIRIT DH-V Operator’s Manual
4/195 26/07/2007
ECN Rev. Date Description Pages Approved
0000307 3.01 24.01.2006. upgrade all
0000869 3.02 26.07.2007. Warning label on the
collimator cart. 46 Daniel Cser
0000970 3.03 13.11.2007. Collimator exchange 65-75
0000972 3.04 14.11.2007. ECG connections 112

Revision 3.04 5/195
